Control unit

Franz Kessler DMQ .4.AF I Hauptspindelmotor

Year of construction: 2016, condition: ready for operation (used), Offered is a high-precision worm and thread grinding machine MIKROMAT 20G, used as a test and trial machine, nearly all available options included, technically flawless condition. Capabilities: external thread grinding, internal thread grinding, whirling Whirling, grinding length max. 2000mm, workpiece diameter max. 320mm, distance between centers: 2250mm NC tailstock option: 2050mm, workpiece weight max. 200kg 350kg NC tailstock, pitch range: 0-400mm, 7-axis system, feed speed: up to 15000mm/min, setting angle: +/-40°, positioning accuracy: uncertainty 0.0024mm P, upgrade to 23.5kW continuous power/45kW maximum power, grinding wheel speed: up to 50m/s, special equipment internal grinding: internal thread diameter up to 100mm, length up to 50mm, coolant system: KNOLL compact unit vacuum rotary filter, 2500l tank volume and oil cooling, installation dimensions X/Y/Z: approx. 6500mm/4000mm/3000mm, total weight: approx. 13000kg, inspection possible by arrangement. Dedpfx Akoylbr Domewc

Condition: new, DAWN DN Series (Single Spindle) Dawn Machinery Machine overview Suitable for grinding inside and outside diameters as well as the end surface of heavy or non circular work pieces. Heavier work pieces can be more easily loaded to the machine by overhead hoist Fully enclosed covers and oil mist reclaiming device prevent leakage of grinding oil and mist. Dodpfxsubbp Ss Akmowc Machine options Model DN-500 Specification Model DN-500 Grinding Diameter (Max) 610mm ø Swing (Max) 610mm ø Max work height 400mm Motor Power 18/23kW CNC Control System SIEMENS 828D

Condition: refurbished (used), Year of construction: 2018, functionality: fully functional, travel distance X-axis: 350 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 256 mm, GF AgieCharmilles CUT 2000S Year of manufacture: 2018 Travel ranges: X = 350 mm, Y = 250 mm, Z = 256 mm Travel ranges U/V axis: +/- 70 mm Maximum taper: 30° at a height of 100 mm Maximum workpiece dimensions: 750 x 550 x 250 mm Maximum workpiece weight: 200/450 kg AGIE IPG-V generator Achievable surface quality: Ra: 0.05 µm Available wire diameters: 0.05 – 0.30 mm incl. option KIT 50 Wire EDM machine with automatic wire threading With automatically lowerable tank (accessible from 2 sides) Incl. AGIEJOGGER handheld control box for convenient setup VISION 5 control system 15" LCD color screen, jog shuttle and mouse Dwedpfjzlx A Sox Akmoc Incl. AGIESETUP 3D Incl. Conic-Plus option for improved taper Dimensions (length x width x height): 2095 x 1950 x 2232 mm Net weight: 3600 kg The machine will be completely overhauled and tested by us. We will gladly perform an individual test cut. We also offer commissioning and training on-site for this machine.

Condition: refurbished (used), Year of construction: 2012, functionality: fully functional, travel distance X-axis: 350 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 256 mm, GF AgieCharmilles CUT 2000 Oiltech Year of manufacture: 2012 Travel distances: X = 350 mm, Y = 250 mm, Z = 256 mm Travel distances U/V axis: +/- 70 mm Maximum taper: 30° at 100 mm height Maximum workpiece dimensions: 750 x 550 x 250 mm Maximum workpiece weight: 200/450 kg AGIE IPG-VO generator Achievable surface quality: Ra: 0.05 µm Available wire diameters: 0.07 – 0.30 mm including option KIT 70 Water bath machine with automatic wire threading With automatically lowering tank (accessible from 2 sides) Includes AGIEJOGGER hand box for comfortable setup VISION 5 control 15" LCD color screen, jog control panel and mouse Includes AGIESETUP 3D Includes Fast-Threading option Dimensions (length x width x height): 2095 x 1950 x 2232 mm Net weight: 3600 kg The machine will be completely overhauled and tested by us. A customized test cut is also possible. We also offer commissioning and on-site training for this machine. Dwsdpfxsztp Emj Akmoc
