Guillotine shear

Geka ETS 300

Condition: excellent (used), Year of construction: 1999, AMADA MODEL GPN 840 HYDRAULIC SHEAR MAXIMUM CUTTING LENGTH 4000 mm MAXIMUM THICKNESS M.S. 45 kg/mm/2 8 mm MAXIMUM THICKNESS S.S. 60/kg/mm2 6 mm STROKES PER. MIN 10 - 35 BACK GAUGE RANGE 10 - 1000 mm MOTOR SIZE 15 KW MACHINE WEIGHT 10100 kg STANDARD EQUIPMENT PROGRAMMABLE MOTORISED BACK GAUGE Hsdpfx Aetrkmnjkrenu 1.5 METRE SIDE GAUGE 1.5 METRE FRONT SUPPORT SHADOW LINE LIGHT AUTOMATIC HYDRAULIC HOLD DOWN CLAMPS CENTRALISED LUBRICATION FOOTSWITCH SHADOW LIGHT BEAM CYCLE COUNTER AUTOMATIC SHEARING CONTACTS IN BACK GAUGE BLADE GAP AND RAKE ANGLE ADJUSTMENT FRONT FLIP STOPS ONE SET OF BLADES 4 CUTTING EDGES ADJUSTABLE STROKE WORK CHUTE HOUR COUNTER AUTO-DIAGNOSTICS

Condition: used, Year of construction: 1999, sheet width 3060 mm plate thickness 8.0 mm Hnsdexaci Espfx Akreu thickness at "Niro-steel" 6.0 mm distance between columns 3100 mm down holder 16 Stück no. of strokes max. 10 - 15 Hub/min oil volume 160 ltr. cutting angle 1.6 ° back stop - adjustable 6.0 - 750 mm Control ELGO P9521 total power requirement 18.5 kW weight 6300 kg range L-W-H 3900 x 2300 x 1630 mm Features: - Robust electro-hydraulic swing beam shear - ELGO digital display model P9521, for electric backgauge * Backgauge travel X = 750 mm * Backgauge-free ball screw drive * Travel speed 100 mm/s - 1x stable side stop * With T-slot, flip-stop, and millimeter scale - 2x stable front support arms - Electric cutting length limiter * Cutting length limiter to increase the stroke rate/min. - Manual cutting gap adjustment * Centrally operated on the right side stand - Front support plates - Front finger/interference guard - Inching operation with push buttons on the left control panel - Protective grille = safety device behind the machine - Operating instructions (PDF)

Condition: ready for operation (used), Year of construction: 2006, pressure 90.0 t chamfer lenght 3050 mm distance between columns 2550 mm stroke of upper beam 135 mm dayligth 180 mm throat 350 mm working feed 8.0 mm/sec return speed 68.0 mm/sec work height max. 805 mm back stop - adjustable max. 620 mm Control ENC 310 oil volume 100 l total power requirement 7.5 kW weight 5840 kg range L-W-H 4000 x 2040 x 2450 mm Hnedpfoyy A H Tex Akrou from a maintenance workshop very good conditions (!!) - in checked conditions - machinevideo - ?v=PIiHc2e7h28 Features: - NC electro-hydraulic press brake - with DURMA NC control "ENC 310" * Illuminated LCD display * X-axis control & value display * Y-axis control & value display - Swiveling operator panel, front left - NC controlled axes: Y1/Y2 + X - NC electro-motorized backgauge (X-axis) * with 2x manually adjustable backgauge fingers * including lateral and height adjustment (Z+R axes) - NC electro-motorized depth adjustment (Y-axis) - AMADA/PROMECAM upper tool holder * with top wedge crowning & quick-change adapter * Split deer foot upper tool (AMADA) - AMADA/PROMECAM Lower tool holder * Split 4V universal die, in die shoe - Side guard (swinging doors) - Rear guard (swinging door) - 1x freely movable foot switch - Operating instructions (PDF)

Condition: ready for operation (used), Year of construction: 2009, pressure 170 t chamfer lenght 3170 mm distance between columns 2700 mm column arm 420 mm dayligth 620 mm stroke 350 mm ajustment speed 160 mm/sec working feed 10.0 mm/sec return speed 100 mm/sec oil volume 280 L 0 300 bar controlled axis 7 Anzahl Number of working hours ca. 51.500 h total power requirement 16.5 KW weight of the machine ca. 12700 kg range L-W-H 4550 x 2650 x 3150 mm "LONG STROKE" special version Excellent condition (!!) Original price approx. 200.000 Euro Special price on request ----- "LONG STROKE" electro-hydraulic press brake featuring: * Increased daylight opening (installation height) = 620 mm * Increased cylinder stroke = 350 mm ----- Equipment: - Electro-hydraulic CNC press brake - AMADA CNC control "AMNC" - 7 axes (X1+X2, Y1+Y2, R, Z1+Z2) Hodpfx Akozz S D Iersnu * Swiveling control unit - front left * Touchscreen control panel * Tool & program library * Incl. handheld control unit for manual axis movement - CNC-controlled backgauge adjustment (X1+X2) * Adjustment range .. 700 mm * Adjustment speed .. 500 mm/sec. - CNC-controlled vertical adjustment of gauge fingers (R-axis) * Adjustment range .. 250 mm * Adjustment speed .. 160 mm/sec. - CNC-controlled left-right adjustment of gauge fingers (Z1+Z2) * Adjustment speed .. 1000 mm/sec. - AMADA manual upper tool clamping system * Type: WILSON TOOLS Express * Vertical tool loading/unloading possible * Incl. 1x set of sectional ROLLERI upper tools * "TOP 175.60.R2" ... H 143.8 + 30 mm / 60 degrees - AMADA lower tool holder * Incl. sectional / reversible 4V die * V-openings: 16/32/35/50 mm - FIESSLER laser safety system (front of machine) * Motorized adjustment * Model series: "AKAS III 150" - Side safety guards (swinging doors) - Rear safety guard (swinging door) - 1x movable dual foot pedal - Front emergency stop button - Original operating manual

Condition: new, sheet width 3100 mm plate thickness 13,0 mm thickness at "Niro-steel" 8,0 mm down holder 14 Stück no. of strokes 11 - 20 Hub/min oil volume 310 ltr. cutting angle 0,05 - 2,0 ° throat 350 mm table height 900 mm total power requirement 22,0 kW weight of the machine ca. 13.300 kg range L-W-H 5.110 x 2.570 x 2.400 mm ----- heavy electr. / hydraulic CNC guillotine shears - guided by a backdrop * with CYBELEC CNC touch screen control * with electr. / hydr. Cutting gap and cutting angle adjustment ----- Furnishing: - CNC guillotine guiding shears Hedpfoxabikjx Akronu - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball casters in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German

Condition: used, Year of construction: 2013, pressure 320 t chamfer lenght 4100 mm distance between columns 3600 mm column arm 410 mm ram stroke speed 140 mm/sec work speed 10,5 mm/sec return speed 150 mm/sec work stroke 375 mm dayligth 650 mm table height 900 mm table width 220 mm oil volume 400 ltr. voltage 380 Volt total power requirement 30.0 kW weight 21300 kg range L-W-H 5350 x 2450 x 3150 mm Hnodpfx Aez I Dz Askrju Features: - DELEM DA66T CNC control system - CNC-controlled axes: Y1, Y2, X, R, Z1, and Z2, as well as CNC crowning - FIESSLER AKAS laser safety device in front of the machine (including FPSC) - Rear safety device: light barrier - BOSCH/HOERBIGER hydraulic components - SIEMENS electrical components - 2 front support arms - 1 freely movable dual foot control - Upper and lower tools

Condition: like new (used), Year of construction: 2015, machine/vehicle number: 83888, functionality: fully functional, power: 15 kW (20.39 HP), pressing force: 150 t, distance table to ram: 3,150 mm, total length: 4,100 mm, total height: 2,500 mm, overall weight: 8,500 kg, Equipment: CE marking, documentation/manual, HACO ERM 36150 (83888) Technical condition: New Bending length: 3600 mm Tonnage: 150T Type of press brake: Synchronized Back gauge: Y1 + Y2 + X CNC controlled, R-axis manual Back gauge length: 800 mm Crowning: Yes (manual) Daylight opening: 400 mm Control system: EASYBEND 2D Motor power: 15.0 kW, 400V Tooling: Yes, multiple sets of bending tools Tooling standard: European standard Total length: 4100 mm Total depth: 1700 mm Total height: 2500 mm Weight: 8500 kg Serial number: 83888 Hnsdpfx Akszxgrbereu Delivery and installation at your location are possible; delivery costs and any additional charges will be discussed.

Condition: used, Year of construction: 2005, Press capacity approx.: 3200 kN Bending length approx.: 4280 mm Distance between side frames: 3760 mm Control: Operateur 2000 Term hydraulic: 37900 h Length: 4670 mm Width: 2170 mm Height: 3095 mm Stroke: 350 mm Weight of machine approx.: 24000 kg Hedoz R Rgaepfx Akrsnu Standard configuration 7-axis-backgauge
