Horizontal Machining Centre

GIDDINGS & LEWIS HMC 410

Condition: excellent (used), Year of construction: 2017, operating hours: 3,200 h, pressing force: 130 t, Space requirement: 11,500 mm x 10,000 mm + Increased installation height/lift + 230 mm + 4-axis backgauge system + Rear work area lighting + Front work area lighting - TruBend documentation Automation BendMaster (60) Standard equipment: BendMaster - Sturdy base frame and manipulator made of cast aluminum construction Cgodpfx Afjxayl Djper - Load capacity 60 kg, sheet plus gripper - Low-level floor track in welded construction - Sheet sensor for contour detection - Rotary feedthrough for quick gripper change Gripper coupling on the BendMaster - Sensor system for 4-axis backgauge system - Electric drives - Double sheet detection - NC regrip station - Vacuum generation for suction grippers Control - TRUMPF PC control with operator terminal - Teleservice via internet - Convenient operation: screen, mouse, keyboard Safety - Safety fence with access door Special equipment + Track extension to 10 m + Gripper change console + Modular vacuum gripper without separation (materials for 3 grippers) + Modular vacuum gripper with separation (materials for 3 grippers) + Clamp gripper with rotary axis + Sheet removal station with linear axis + Additional pallet for sheet removal station + Right-hand side door for safety fence (or left-hand side in combination with ToolMaster) Machine - Robust machine frame entirely in steel construction - Press beam - Spherical mounting of pressure beam with inclined position - Electro-hydraulic upper drive system with 4-cylinder technology - Optical set-up and positioning assist with control valves - Generous free space for bending - Flat front covers - Block hydraulic system - Electronic pressure gauge - Measuring system with glass scale and spring-back compensation - Hydraulic oil in machine (lifetime lubrication) - Oil cooler - Electrical cabinet cooling via air-to-air heat exchanger - Modern machine design Backgauge System - 2-axis backgauge system, X and R axes Tool Clamping - Hydraulic upper tool clamping - Lower tool holder, hydraulic clamping, hardened - Lower tool displacement, 2 positions, pneumatic Crowning - CNC crowning Control - TRUMPF TASC 6000 - Graphical workshop programming - Windows XPe (embedded), Pentium 4 with 2.8 GHz clock speed - 2 GB RAM - 15-inch touch screen - Network capability - Teleservice via internet Operation - Control panel with LCD keypad and foot switch - Communication rail - MobilControl Safety - Standard safety equipment - CE marking

Condition: ready for operation (used), Year of construction: 2008, operating hours: 56,089 h, Swing diameter over bed/cross slide: 820mm/550mm, distance between centers: 2666mm, max. turning diameter: 610mm, max. workpiece length: 2500mm, travel X/Z: 410mm/2560mm, travel Y: -80mm/100mm, max. workpiece weight without/with tailstock: 500kg/1500kg, tool positions: 12, rapid traverse X/Z/Y: 24m/30m/12m/min, feed force X/Z/Y: 17kN/20kN/17kN. Machine dimensions X/Y/Z: approx. 5500mm/2250mm/2550mm, weight: approx. 15000kg, operating hours: approx. 56089. Documentation available. An on-site inspection is possible. Expected to be available from mid-2026. Cgjdpfsw Dfhuox Afpor

Condition: refurbished (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: 30214501, turning length: 2,000 mm, total length: 12,000 mm, WFL Millturn M60/2000 WORKING RANGE center distance mm 2000 swing over bed, turning diameter mm 690 MAIN DRIVE AC-drive with 2 gear steps drive power 100% duty cycle kW 40 max. speed min-1 3300 max. torque at the spindle 100% duty cycle Nm 1830 TAILSTOCK quill diameter mm 140 quill travel mm 160 quill force (adjustable) N 3500-31000 quill with installed live center MK 5 TOOL HOLDER (single tool holder, turning-boring-milling unit) AC-drive drive power 100% duty cycle kW 30 speed range max. min-1 6000 max. torque at the spindle 100% duty cycle Nm 315 travel vertical to the X/Z-plane (Y-axis) mm 300[-125/+175] pivot capability of the milling spindle (B-axis) ° -110/+90 spindle head acc. DIN 69893 HSK-A100 Cedou Hl R Tspfx Afpsgr spindle diameter in front bearing mm 100 DIMENSIONS length (max. tool magazine) m 11 width/height m 3,9/3,3

Condition: good (used), Year of construction: 2022, UK DELIVERY ONLY Developed for the shop-floor, the TIGO SF is a fully-protected and versatile coordinate measuring machine (CMM) that combines robust construction, innovative technology and flexibility of setup to ensure high-accuracy measurement in the harshest of environments. Tigo SF 5.6.5 HH-A-T5, 5° Automatic Indexing Head HP-S-X1S Analogue Scanning Probe Standard Styli Kit PC-DMIS Measurement Software Year of Manufacture 2022 Please contact us for alternative configurations. Measuring Range: X 500mm, Y 580mm, Z 500mm Cgjdpfx Afou Spvqjpor MPE(E0/E60) (18 °C - 22 °C) 2.2 + L/300 See Datasheet for further information.

Condition: reconditioned (used), Year of construction: 1982, functionality: fully functional, overall weight: 17,500 kg, working width: 1,300 mm, working height: 1,300 mm, working range: 1,300 mm, Amada H1300 Horizontal Bandsaw (1982) Capacity 1300 x 1300mm Power 230 V – 50/60 hz / 400 v – 50hz / 460 v 60hz Blade drive 11 kw Hydraulic drive 3.7 kw Coolant drive 0.4 kw Wire brush drive 0.4 kw Blade size 11380mm x thickness 1.6 x width 65 mm Net weight 17.500 kgs Total power requirement 16 kw Machine Data: Model H1300 Year of Construction 1982 Cgsdpfxetv E Hcs Afper Built in Japan

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, TRUMPF TruBend Cell 5000 – Robotic Bending Cell | Year 2015 Codpfx Afsxdfqmjpsgr TruBend 5130X Press Brake BendMaster Robotic Bending System Control System: TASC 6000 (robot and press are programmed via the machine interface) Press Brake Specifications: Press force: 130 tons Bending length: 3,250 mm Year of manufacture: 02.2016 More information and video available on request ...

Condition: ready for operation (used), Year of construction: 2015, operating hours: 61,469 h, controller manufacturer: TRUMPF, controller model: TASC 6000, This TRUBEND Cell 5000 with TruBend 5085 extended version (2720 mm x 850 kN) and BendMaster 60 was manufactured in 2015. World's first bending automation with image recognition for maximum flexibility. Sheet metal parts up to 40 kg, 6-axis backgauge sensor technology. Maximum repeat accuracy thanks to angle sensor technology (ACB) in automated operation. It features a stable all-steel frame, electro-hydraulic top drive, and a modern block hydraulic system. The control unit is a TRUMPF TASC 6000 with a 15-inch touchscreen and network capabilities. Ideal for precise bending operations, consider the opportunity to buy this TRUMPF TruBend Cell 500 press brake. Contact us for more information about this machine. • Machine: TruBend 5085 (2720 mm x 850 kN) with BendMaster 60 • Stable all-steel machine frame • Press beam with spherical bearing and tilt adjustment • Electro-hydraulic top drive with 4-cylinder technology • Generous edge clearance • Flat front covers • Modern block hydraulics • Electronic pressure balance • Measuring system with glass scale and spring compensation • Hydraulic oil in the machine (lifetime lubrication) • Oil cooler • Control cabinet cooling via air-to-air heat exchanger • Modern machine design • Stop/Backgauge • Stop system • Backgauge system: 2 axes (X and R) • Tool clamping • Upper tool holder, manual clamping, hardened • Lower tool holder, hydraulic clamping, hardened • Lower tool shift, 2 positions, pneumatic • Crowning • Manual crowning • Control • TRUMPF TASC 6000 • Graphical workshop programming • Windows XPe (embedded), Pentium 4, 2.8 GHz • 2 GB RAM • 15-inch touchscreen • Network-enabled • Teleservice via modem • Operation • Control panel with LCD keypad and foot switch • Communication rail • Safety • Standard safety devices • BendGuard safety device for upper tools up to 390 mm • CE marking Additional equipment • TRUMPF BendMaster automation (standard features) • Robot/Handling • Stable base and manipulator in die-cast aluminum • Load capacity 60 kg (workpiece plus gripper) • Low-profile welded floor track • Sheet metal sensor for contour detection • Rotary feedthrough for easy gripper change • Gripper coupling on the BendMaster Cgedpfx Afsx Imqlspjr • Sensors for 4-axis backgauge system • Electric drives • Double sheet detection • NC gripper transfer station • Vacuum generation for suction grippers • Control • TRUMPF PC control with operator terminal • Teleservice via modem • Operation via screen, mouse, and keyboard • Safety • Safety fence with access doorWorld's first bending automation with image recognition for maximum flexibility Sheet metal parts up to 40 kg, 6-axis backgauge sensor technologyMaximum repeat accuracy thanks to angle sensor technology (ACB) in automated operationTruBend 5085 (2720 mm x 850 kN) with BendMaster 60
