Sandblasting unit

Gietart Sprint 2.6

Condition: excellent (used), OMSG CWB 850 4/FAC Type: Wire mesh conveyor Max. width of workpiece: 850 mm Max. height of workpiece: 450 mm Nr. Of turbines: 4 Turbine wheel diameter: 350 mm Ledpfewm Dbxjx Agdjhd Power of turbine: 7,5 kW Max. turbine flow: 105 kg/min x 4 Transport speed: 0,5 - 5 m/min Cleaner type: Airwash Filtering unit: Included Foundation: no Total width of machine: app. 3.000 mm Total height of machine: app. 5.000 mm Total length of machine: app. 7.000 mm Max installed power: app. 70 kW

Year of construction: 2018, condition: ready for operation (used), Components: control cabinets, machine body (cabin, turbines, outlet, inlet), platform with processing unit and bunker, sound insulation cabin, impact box, bucket elevator, gratings, ladder, pre-impact box, small parts, piping, cable ducts, blasting media and refill silo, compressed air connection: 1/2 inch at 4–6bar, compressed air consumption: approx. 1.5m³/h, processed according to DIN ISO 8573-1, solid particle size: 1µm, density: 1mg/m³, water content: pressure dew point 3°C, oil content: 1mg/m³, length: 11,000mm, height: 5907mm. An on-site inspection is possible. Lhedpsxtprtofx Agdod

Year of construction: 1995, condition: ready for operation (used), A Gutmann blasting system completely overhauled by Rösler in 2019 is available. Documentation available. On-site inspection is possible. Lhedpfxewftcpo Agdod

Condition: used, Year of construction: 2010, machine/vehicle number: 0901-260005, Kaltenbach Gietart Sprint 1504 continuous blast system with 4 blast turbines. Technical data Kaltenbach Gietart Sprint 1504 Number of turbines: 4 pcs. type C 380 Turbine output: 11 kW Brush and blow-off unit: 1 piece Sheet thickness min: 6 mm Flat material min: 60 x 80 mm Working speed: 0.8 - 1.5 m/min. Throughput speed: 0.6 - 10 m/min Feed-through opening: 1600 x 650 mm (for sheets up to max. 1510 mm wide) Roller conveyor height 640 mm Power supply: 400 V +/- 5 %, 50 Hz, Control voltage: 24 V DC Total connected load: 84 kW Compressed air supply: 7 bar, dry, oil-free, clean, 20 m³/h The blasting system is suitable for blasting: Profiles: max. 1000 x 300 mm Sheet metal: max. 1510 width Flat bars: min. 60 x 8 mm Transport length: min. 2000 mm Transport weight: max. 1000 kg/m - min. 30 kg/piece Material quality: S 235JR*NEN-EN 10025-2 Structure of the Gietart blasting machine: Lsdpoymy Hisfx Agdohd Machine housing, 10 mm thick Manganese lining, 4 mm thick Manganese wear strips, 8 mm thick Inlet sluice 1400 mm, with rubber curtains Outlet sluice 800 mm, with rubber curtains Collecting hopper with screw conveyor Screw conveyor to the bucket elevator

Condition: excellent (used), Large size blastroom for surface preperation and finishing large workpieces 4 shotblasting units Filtration system NEON Lightning 250 W Lsdpeygk S Nefx Agdohd Automatic front door Service door in BMS System Smooth control by means RACK system 2 Abrasive operator system 2 Opperator platform with basket 2 Magic Blast Controllers 4 ACF Shotblasters SV206 with 205Liter Schneider MAGELIS opperator display control panel Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
