Condition: ready for operation (used), empty load weight: 1,000 kg, cap: 50 x 2 x 2,5 mm length: 6000 mm Hnsdjyac U Nopfx Ahusg

Condition: excellent (used), Year of construction: 2023, tube diameter 42.0 x 3.0 STAHL mm tube diameter 30.0 x 2.0 EDELST mm bending angle max. 180 ° bending radius max. 100 mm bending speed 2.0 U/min. Control NC voltage 400 V total power requirement 0.55 kW weight of the machine ca. 115 kg Current new price approx. 4.200 Euro Very good condition / with machine base Description: - NC electro-motor tube bending machine - mandrelless * up to 50 programs can be stored Hedpfox U El Iex Ahusng - Automatically returns to the starting position - Maximum bending capacity for 42 x 3.0 mm steel tubes - Excellent bending quality with very tight bending radii (from 2x tube diameter) . and bending angles between 0° and 180° - Easy operation - High accuracy and reliability - Quick tool change (within seconds) - Easy to transport - Includes machine base

Condition: used, Year of construction: 1979, weight 200 kg Hnedpox U A Srsfx Ahueg 931855500

Condition: used, Year of construction: 1984, ja positioning automatic ja documentation ja ja Hjdpjx U A Sfsfx Ahujng

Condition: new, tube diameter 60.3 x 4.5 mm ST tube diameter 60.3 x 5.4 mm ALU tube diameter 2" x 3.91 mm GAS bar material - diameter 35.0 mm revolutions per minute 2.0 U/min Hnodpfjx Urtlex Ahusg bending radius min. 10.0 mm bending radius max. 270 mm external diameter min. 5.0 mm external diameter min. 1/8 Zoll voltage 230 V total power requirement 1.5 kW weight 76.0 kg range L-W-H 302 x 243 x 674 mm Equipment: - mandrel-less tube bending machine - Model "M" = ELECTRO-HYDRAULIC SINGLE-PHASE - high performance and compact design - completely hydraulic machine - bends 210° without the need to catch up - no electronic control - Ercolina patent n. 102017000142179 - control of the bending angle via adjustable angle scale - mobile machine base BENDING SEGMENT AVAILABLE AT AN EXTRA CHARGE

Condition: good (used), Year of construction: 1998, Tube diameter: 20 - 60.3 mm Tube feed length: 4500 mm Machine weight approx.: 0.11 t Hnjdex T Dhfopfx Ahusg Total power requirement: kW Space requirement approx.: 5700 x 1600 x 900 mm - Preselection of 4 bending angles via rotary selector

Condition: good (used), Year of construction: 1994, control type: CNC control, controller manufacturer: Siemens, controller model: 840 D, Pipe diameter: 168.3 x 11 mm Pipe insertion length: 6000 mm Maximum bending radius: 700 mm Control system: Siemens 840 D Minimum bending radius: 80 mm Maximum bending angle +/-: 190 ° Connected load: 400 V / 50 Hz / 85 A Dimensions (L/W/H): 11.9 x 2.7 x 2.45 m Machine weight approx.: 33 t Additional information: - CNC control: CNC MMI Multicontrol 2000 - Control system NCU - PLC: Siemens Simatic S7 - Electrical connection: 400V / 50 Hz / 85 A Hnjdpfx Asx T Dgujhujg The machine is fully automatic and equipped with a tool changer. The following tooling is available: Pipe Ø 48.3 mm; Radius 105 mm Pipe Ø 60.3 mm; Radius 120 mm Pipe Ø 63.5 mm; Radius 150 mm Pipe Ø 76.1 mm; Radius 190 mm Pipe Ø 88.9 mm; Radius 222 mm Pipe Ø 114.3 mm; Radius 285 mm Pipe Ø 139.7 mm; Radius 350 mm Pipe Ø 141.3 mm; Radius 700 mm Pipe Ø 168.3 mm; Radius 420 mm A few mandrels have a direct engraved marking. These have the following specifications: 88.9 x 8 mm; 88.9 x 4.5 mm; 114.3 x 8.8 mm; 139.7 x 8.8 mm; 168.3 x 12.5 mm; 168.3 x 8.8 mm The following outside diameters of the mandrels were measured: 23.2 mm; 32.3 mm; 37.1 mm; 41.5 mm; 59.3 mm; 70.3 mm; 77.7 mm; 80.9 mm; 88.7 mm; 93.2 mm; 94.7 mm; 103.0 mm; 112.8 mm; 118.8 mm; 128.9 mm; 138.5 mm; 147.2 mm; 153.6 mm The accessory package is valued at approximately €150,000.

Condition: used, Year of construction: 2007, pipe diameter (max.): 35 mm, overall weight: 2,700 kg, total length: 2,400 mm, total width: 1,400 mm, total height: 2,000 mm, Tube forming machine Brand: BLM Model: TUBE-FORM Hnjdpfx Aox Tt H Rjhusg Year: 2007 Serial number: 415050200004 Weight: 2700kg Power: 12KVA Three-phase 380V Dimensions: 2400x1400x2000(h)mm Maximum tube diameter: 35mm Pushing force: 3.5t Clamping force: 5t Max. working stroke: 130mm

Condition: good (used), functionality: fully functional, Year of construction: 2002, machine/vehicle number: 361, control type: CNC control, degree of automation: automatic, actuation type: electric, overall weight: 1,100 kg, Equipment: centralized greasing system, emergency stop, foot remote control, Profile bending machine PBT 25-PC300 Original price in 2002: €72,500 Performance data and features: Hodjx Trn Hopfx Ahusng Drive & Control: - 3 driven rolls (electric) with up to 22 rpm - Control: PC 200 (CNC) - Power: approx. 7 kW motor output (PBT25 model) Rolls & Geometry: - Roll height: 300 mm - Roll diameter: typically 105 mm - Minimum front roll distance: from 200 mm - Roller support/steady rest for all three shafts as standard Capacities (examples): - Flat material: 80 x 80 mm with R = 1000 mm - Tube: Ø 114 x 3 mm with R = 2000 mm - T-profile: 80 x 80 x 8 mm with R = 1000 mm Flexibility: - Usable in both horizontal and vertical positions - Bilateral operation possible (bending at the front, flanging at the rear) Dimensions & Weight: - Weight: approx. 1,150 kg Additional Technical Data: - Bending force: 27 t - Max. torque: 1,600 Nm - Rotational speed: 1-24 rpm - Positioning accuracy: 1/100 mm - Roll spacing: 200-1000 mm - Roll height: 300 mm - Roll diameter: 105 mm - Shaft length: 265 mm - Motor power: 3 kW and 3 × 1.1 kW - Voltage: 400 V, 16 A - Dimensions (L×W×H): 1480 × 1200 × 1365 mm - Weight: 1,100 kg

Condition: used, Automatic Tube Bending Machine Brand: B.L.M. Model: B/90/M Description: Automatic tube bending machine designed for industrial applications, equipped with automatic programming for producing multiple bends in sequence. The machine allows adjustment of the reference distance, ensuring high precision and repeatability in the bending process. Hnsdpfxjx Swbio Ahuog For all technical details, please refer to the technical data sheets available in the photos.

Condition: good (used), functionality: fully functional, Year of construction: 2011, operating hours: 34,797 h, machine/vehicle number: 2011-0250, pipe diameter (max.): 600 mm, pipe length (max.): 1,500 mm, bending angle (max.): 180 °, bending radius (max.): 200 mm, wall thickness: 3 mm, Original machine year: 1996. In 2011, fully overhauled by the manufacturer for approx. EUR 250,000: electrical and mechanical components extensively renewed. TECHNICAL DETAILS Tube diameter: 16 – 60 mm Wall thickness: max. 3.0 mm Bending radius: 20 – 200 mm Tube feed length: 1,500 mm Bending angle: max. 180° + spring-back Tube length: 400 – 1,500 mm Tube outside diameter: 28 mm – 60 mm Material specifications Tensile strength stainless steel: max. 750 N/mm² Tensile strength mild steel: max. 450 N/mm² Capacity (steel): Ø 60 x 3 mm Capacity (stainless steel): Ø 57 x 2 mm Axes/Movements Bending direction: left Bending speed (forward): max. 22.0 rpm (infinitely variable) Bending speed (return): constant 22.0 rpm Rotational positioning: max. 360° Rotational speed: 50 rpm Multi-radius height adjustment: lowest tube center 55 mm Height travel: suitable for 3-groove bending tools MACHINE DETAILS Overrun time: 125 ms Machine weight: approx. 8.0 t Machine dimensions (L × W × H): 6,300 × 3,300 × 1,900 mm Control cabinet (L × W × H): 2,700 × 700 × 2,000 mm Control console (L × W × H): 900 × 600 × 1,850 mm Tube magazine (L × W × H): 1,800 × 2,400 × 1,750 mm Operating hours: approx. 34,797 h Performance data Hjdpfox Srklox Ahuong Total power requirement: 55 kW Hydraulic oil volume: 340 l Control Bending planes: up to 6 (CNC programmable) Positioning device: NTB configuration Control unit: Schwarze-Robitec operation and control console FEATURES - Automatic cold tube bending machine - Tube positioning device - Gripper - Schwarze-Robitec tube magazine - Hydraulic operation for bending table, tool clamping, sliding rail, mandrel retraction, reinforced sliding rail feed and retraction - Various bending tools for Ø 60 mm tubes - Various accessories - Control cabinet cooling unit - Dual foot switch - Schwarze-Robitec control console - Rittal control cabinet cooling unit, type SK 3361100 Note: Machine could only be tested in setup mode due to lack of operating know-how. No faults are known. The machine is currently disassembled.

Condition: used, Year of construction: 2011, Technical details: tube diameter: 60 mm wall strength: 3,0 mm bending radius min.: 20 mm tube diameter max.: 60 mm wall thickness max.: 3,0 mm tube pipe draw up length: 1500 mm bending angle max.: 180 + Auffederung ° Number of working hours: ca. 34 797 h Total power requirement: 55 kW Weight approx.: 8,0 t machine dimensions LxWxH: 6,3 x 3,3 x 1,9 m dimensions electric cabinet LxWxH: 2,7 x 0,7 x 2,0 m dimension device 1: Steuerpult: 0,9 x 0,6 x 1,85 m dimension device 2: Rohrmagazin: 1,8 x 2,4 x 1,75 m This is an automatic pipe cold bending machine. Multiple radii can be bent. Radius differences freely programmable via CNC control up to 6 levels. Pipe positioning device in NTB design Pipe diameter: min. Tube Ø : 16mm max. capacity of machine Tube Ø x wall thickness: mild steel=Ø 60x3 mm and stainless steel=Ø 57x2 mm Bending radius to pipe center: min. Ø 20 mm max. Ø 200 mm Bending to left. max. tensile strength of the material to be bent: Stainless steel 750 N/mm² mild steel 450 N/mm² max. bending speed: FORWARD, infinitely variable / programmable 22.0 1/min. RETURN, constant 22,0 1/min. Hodpfjx Sll Ajx Ahusng Height adjustment multiple radii: lowest tube center 55 mm Height travel suitable for 3-groove bending tools Twisting: Twisting angle max. 360°; speed 50 min-1 -gripper -tube magazine Schwarze-Robitec, tube length min./max.: 400 7 1500 mm, tube outer Ø min./max.: 28 7 60 mm -Hydraulic filling volume 340 liters -Hydraulic operation for: bending table drive; tool clamping; slide rail pressure, direct acting; reinforced slide rail feed and return; mandrel return feed device -operator/control panel from Schwarze Robitec -2x foot contact operation -cooling unit on control cabinet Rital, type SK 3361100 accessories: div. bending tools for Ø 60 mm tube div. auxiliary tools *

Condition: good (used), Ring bending machine, profile bending machine, three-roll bending machine, bending machine, pipe bending tool Hsdpox R Sw Njfx Ahusng -Pipe bending tool: 10 pieces -Profile diameter: 26 to 67 mm see photos -Hole: Ø 31 mm -Shipping/Price: complete -Transport dimensions: 630/310/H125 mm -Weight: 48.5 kg

Condition: new, Year of construction: 2025, Pipe Bending Machine Zopf Model KB 100: Capacity: - Maximum pipe diameter: 100x5 mm (St. 37) - Square profiles: 80x80x3 mm - Solid material: 45 mm - Maximum tool diameter: 900 mm - Bending angle up to 210 degrees - Bending speed: 0 - 2.2 RPM - Motor: 11 kW, 400 Volt, 50 Hz, 3-phase - Weight: 1850 kg - Dimensions: 140x80x160 cm Features: - Digital display - Programmable bending angle Hnjdex I Afxopfx Ahusg - With foot pedal - Equipped with inverter - Powerful motor and reduction gearbox for high torque - Control unit for setting the bending angle - Counter for positioning the counter bearing - Mobile control panel - Quick tool change - All shafts hardened and ground - Manual material clamping - Worktable made of CK 45 steel

Condition: good (used), functionality: fully functional, Year of construction: 1995, Tube bending machine by MARK / Ridgid Type: 2H B Without tools Hodpfx Ajx Ivpwehusng

Condition: like new (used), functionality: fully functional, Year of construction: 2019, operating hours: 250 h, machine/vehicle number: 0131, control type: NC control, degree of automation: semi-automatic, actuation type: hydraulic, pipe diameter (max.): 48 mm, pipe length (max.): 3,000 mm, tube wall thickness (max.): 4 mm, bending angle (max.): 180 °, overall weight: 670 kg, input voltage: 400 V, input frequency: 50 Hz, number of digital displays: 1, Equipment: CE marking, centralized greasing system, documentation/manual, emergency stop, T U B O M A T – simply smart. TUB-C G3001 The tube bending machine is ideally suited for single parts and small series production. The software allows individual tubes to be parameterized, simulated, and saved. Bending data is then transmitted to the machine via network (LAN). Standard bending equipment - Electronic Siemens SIMATIC control system - Function selection and operation via 4.3-inch touch panel - Familiar 4-fold preselection of bending angles or program mode - 80 memory locations for up to 10 sets - Actual/target value display for bending angles - Compact, forward-positioned bending head - Optimized tooling concept - Hydraulic bending drive, operated via proven hand lever - Hydraulic tube clamping - Hydraulic pressure die actuation - Hydraulic mandrel extraction - Mobile use possible - Saw unit for optimal right-angle cuts - Deburring unit for internal and external deburring - Universal base holder as drive unit for assembly attachments Technical Data - Tube capacity up to: 48.3 x 3.25 mm (E235, Rm = 2 x D) - Bending radius up to: 125 mm - Control: electronic - Max. bending angle: 180° (+10° overbend) - Bending accuracy: ±0.2° - Bending speed: 20°/s - Dimensions L/W/H: 3880 / 800 / 1250 mm - Weight: approx. 700 kg - Power: 2.4 kW - Electrical connection: 400 V / 50 Hz / 3 phase - Power supply requirements: CEE 16 A - Colour: RAL 9006 / 7021 / 5015 Software (Windows 11) PIPEFAB 4.0 BE Basic tube bending software package - Oracle Express database for single-user application - Creation of isometries (single tube) - ConCSVImp – import interface for CSV format - Calculation of bending data taking springback, elongation, and spring-in into account - Checking of clamping lengths, start and end lengths - Output of bending data (printout) - BendSim – bending simulation and graphical representation via parametric tool design - BendCon – creation and transfer of NC bending data for TUBOMAT - Data transfer via LAN Tool holders 1 set of adapters for bending rollers with 25 mm bore 1 clamping piece adapter installation space 100 mm 1 support for fixed pressure die installation space 100 mm Tools Bending tools consisting of bending roller, clamping piece, and pressure die (fixed) Tube diameters / Bending radii - Ø8.0 mm R=20 mm - Ø10.0 mm R=20.5 mm - Ø12.0 mm R=24.0 mm - Ø15.0 mm R=30.0 mm - Ø16.0 mm R=32.0 mm - Ø18.0 mm R=36.0 mm - Ø20.0 mm R=40.0 mm Hjdsx E Rdwopfx Ahusng - Ø22.0 mm R=44.0 mm Mandrels 3000 mm for steel tubes Design with lubrication channel for minimal quantity lubrication (MQL) - 18.0 mm x wall thickness - 20.0 mm x wall thickness - 22.0 mm x wall thickness Pre-assembly studs for cutting ring fittings (L = light, S = heavy design) Tube Ø - 6 mm L - 6 mm S - 8 mm L - 8 mm S - 10 mm L - 10 mm S - 12 mm L - 12 mm S - 15 mm - 16 mm - 18 mm - 20 mm - 22 mm Back-up plates for cutting ring pre-assembly with automatic pressure adjustment for steel and stainless steel tubes Tube Ø - 6 mm L + S - 8 mm L + S - 10 mm L + S - 12 mm L + S - 15 mm - 16 mm - 18 mm - 20 mm - 22 mm Other tube diameters and wall thicknesses possible. The machine is used but in like-new condition. The machine can be inspected and demonstrated by prior arrangement. The machine must be collected from our premises but can be loaded by us. Commercial sale. Price plus 19% VAT. Subject to prior sale and errors.

Condition: reconditioned (used), functionality: fully functional, Year of construction: 2002, Mandrel bending machine for pipes up to 65 mm diameter Hsdox Dgwzopfx Ahuong

Condition: repair required (used), functionality: not functional, Year of construction: 2004, CNC Tube Bending Machine Manufacturer: Schwarze-Robitec Model: CNC 80 E-MR Year of manufacture: 2004/2006 Condition: Needs repair CNC Control: PC-based Beckhoff CNC control Technical Data: - Maximum tube diameter x wall thickness: 60 mm x 3 mm - Minimum tube outside diameter: 16 mm - Minimum bending radius (to tube center): 25 mm - Maximum bending radius (to tube center): 240 + 50 mm - Maximum bending angle: 180° - Maximum tube feed length: 1000 mm - Bending direction: right - Machine weight: 7,000 kg Hnedpjxzubvefx Ahusg - Total connected load: 39 kW - Voltage: 400 V / 50 Hz - Current: 100 A - Machine dimensions (L x W x H): 6.2 x 3.2 x 2 m Equipment / Accessories: - Hydraulic pressure and feed on slide rails - Automatic tube turning and repositioning unit - Electric mandrel bending device - Pneumatic mandrel rod safety system - PC control Beckhoff - Automatic central block lubrication - Laser scanner, safety fencing Machine condition – repair needed: The planetary gearbox of the transport carriage is defective and must be replaced. Spare parts costs according to quotation: planetary gearbox €1,674 + gearbox flange €1,850 + pinion €850 + VAT – installation not included. Cheaper price – sale in as-is condition Immediate availability, including loading onto truck free of charge.

Condition: ready for operation (used), Year of construction: 2005, Bending direction: clockwise, steel tube diameter: 50mm, steel tube thickness: 3mm, stainless steel tube diameter: 50mm, stainless steel tube thickness: 2mm, max. section modulus: 5cm³, bending angle: 180°+10°, max. tube length: 2000mm, max. radius range: 150mm, bending height: 1050mm, bending head length: 850mm, min. bend spacing: 400mm, nominal pressure: 250bar, operating pressure: 200bar. Machine dimensions X/Y/Z: approx. 3200mm/1400mm/1300mm, weight: approx. 1500kg. Documentation available. An on-site inspection is possible. Hnedpfxexwyw Io Ahuog

Condition: excellent (used), functionality: fully functional, Year of construction: 2021, operating hours: 600 h, control type: manual, degree of automation: semi-automatic, actuation type: hydraulic, pipe diameter (max.): 48 mm, pipe length (max.): 4,500 mm, tube wall thickness (max.): 4 mm, bending radius (max.): 96 mm, mandrel length: 4,500 mm, overall weight: 1,000 kg, For sale is a pipe bending machine, purchased in 2021 and used for only two years. Since then, it has been stored in a dry warehouse. It can bend pipes with a diameter from 12 mm to 48.3 mm and a wall thickness of 4.5 mm. Dies/jaws and mandrels for steel and stainless steel pipes are included. Self-collection required upon sale. Hnsdpfoxvhm Iox Ahujg

Condition: ready for operation (used), Year of construction: 2020, Shaft bottom/top: 30mm/30mm, max. round tube length: 48mm, max. round tube diameter: 3mm, max. flat bar dimensions X/Y: 50mm/10mm, max. square tube dimensions X/Y/Z: 40mm/30mm/3mm, weight: approx. 200kg. Documentation available. An on-site inspection is possible. Hjdpfoxt Rmrjx Ahuong

Condition: new, – Capacity: 34 x 3 mm – Digitally adjustable stroke – Emergency stop switch – With 3 tool sets: 33.7 mm, 21.4 mm, 16 mm Hnsdpoxq Hl Esfx Ahueg – Documentation – Weight: 80 kg – 400V

Condition: ready for operation (used), Elgo CNC controlled machine, very easy and user-friendly max tube cap: dia 76 mm x 4 mm thickness max square tube: 70 x 70 mm max radius: 600 bending angle: 180° Standard tooling 3D Hnjdpfxjxpghqe Ahueg Special tooling on request Length: 1200 mm Width: 800 mm Height: 1300 mm

Condition: good (used), Ring bending machine, profile bending machine, three-roll bending machine, bending machine, pipe bending tool Hjdpfxjxmirto Ahusng -Pipe bending tool: 9 pieces -Profile diameter: 27 to 60 mm see photos -Hole: Ø 32 mm -Shipping/Price: complete -Transport dimensions: 655/350/H120 mm -Weight: 42 kg

Condition: ready for operation (used), A mandrel tube bending machine Sommer is available. Tube diameter range: 15mm-65mm, tube feed length: 3000mm, max. bending radius: 150mm, chuck: 200mm, tube clamping: hydraulic. Including accessories. Documentation available. An on-site inspection is possible. Hnodpfsxl Up Uex Ahuog
