Maschinenhandel M.Ercetin

Condition: excellent (used), Year of construction: 1998, functionality: fully functional, turning diameter over cross slide: 570 mm, spindle bore: 62 mm, turning length: 1,250 mm, turning diameter over bed slide: 365 mm, center height: 280 mm, overall weight: 4,000 kg, O F F E R We can offer you, subject to prior sale and errors excepted, ex-stock and without obligation: V D F - BOEHRINGER Cycle-Controlled Universal Lathe Model DUS 560 Year of Manufacture 1998 / completely overhauled in 2008 _____ Centre height 280 mm Bodjyqw Eqjpfx Ah Ield Max. swing diameter over bed 570 mm Max. swing diameter over cross slide 365 mm Cross slide / top slide travel 345/125 mm Centre distance / max. turning length 1,250 mm Spindle bore 62 mm Spindle speeds, 2-step infinitely variable 3–500 / 15–2,500 rpm Infinitely variable longitudinal and facing feeds 0.01–50 mm/rev Rapid traverse longitudinal/cross 5 and 10 m/min Max. feed force facing/longitudinal 6.5 / 12.5 kN Workpiece weight max. between centers/with tailstock 400 / 1,000 kg Thread pitches 0.1 – 400 mm/pitch Spindle drive motor 15/21 kW Total drive 25 kW - 400 V - 50 Hz Weight approx. 4,000 kg Accessories / Special Equipment: • SIEMENS 2-axis cycle control, type 805, with direct input of all turning parameters via interactive user interfaces and suitable software, controller and monitor integrated in the sliding door, with memory extension and software for free contour entry, graphics, etc. • 2 electronic handwheels for fine adjustment of carriage movement in Z and X axes, and new joystick for rapid traverse +Z/-Z and +X/-X, joystick for main spindle with stepless forward and reverse speeds • Mounted 3-jaw chuck model SCA Ø 300 mm, faceplate approx. Ø 500 mm, 4-jaw chuck Ø 315 mm, driver plate approx. 250 mm, single faceplate 500 mm, various jaws • Mounted MULTIFIX toolpost type CD with 5 different Multifix holders • Separate toolpost block for mounting CAPTO toolholder with internal coolant supply, various holders, partially with collets • Tailstock with air bearing for easy movement, work light • Mobile chip trolley with coolant pump and oil skimmer, 2 rear sliding doors • Separate electrical cabinet, adjustable spindle end stop, work light, etc. Condition: very good – guides in very good condition, machine is under power and ready for demonstration Please click here for a video of the machine: Delivery: ex stock – as inspected Payment: strictly net before delivery We look forward to receiving your order. Further lathes of all sizes in stock – please enquire.

Condition: good (used), functionality: fully functional, spindle bore: 70 mm, turning length: 1,500 mm, turning diameter: 500 mm, overall weight: 3,300 kg, Monforts KNC5-1500 Lathe in good condition for sale. The machine operates perfectly. Included accessories comprise all documentation, a quick-change toolholder, and a chip conveyor as shown in the photos. Inspection under power is gladly possible. Loading can be arranged by forklift or crane. Working area: Distance between centers: 1,580 mm Swing over bed: 500 mm Swing over cross slide: 290 mm Cross slide travel: 265 mm Top slide travel: 140 mm Bed width: 360 mm Cross slide width: 220 mm Bed slide guide length: 615 mm Turning tool shank size: 32x25 mm Spindle diameter at front bearing: 100 mm Spindle nose as per DIN 55027, Size 8 Bar capacity: 70 mm Spindle taper (metric): 80 Main drive: steplessly variable, three-phase AC motor Drive power (50/100% duty cycle): 15/11 kW Total speed range: 2-2,800 rpm Gear stage I: 2-280 rpm Gear stage II: 7-1,120 rpm Gear stage III: 28-2,800 rpm Three-phase servo drive with mechanical safety clutch Rapid traverse speed longitudinal/cross: 10/5 m/min Thread cutting range: longitudinal and taper threads, pitch 0.001-500 mm Tailstock: quill diameter 80 mm Quill stroke 160 mm Internal taper MK5 Bjdpfx Ajypbcdeh Isld Tool system: Multifix quick-change toolholder, size C Coolant system: pressure/delivery rate 0.4 bar / 10 l/min Machine dimensions (LxWxH): 3,330 x 1,550 x 1,790 mm Weight (transport unit): approx. 3,300 kg Bed: – Torsion-resistant bed, guideways hardened and ground Gearbox: 3-stage with limit switch monitoring Spindle: – Front spindle bearing: double-row cylindrical roller bearing with tapered bore combined with double-row angular contact bearing – Electric holding brake in main drive motor – Full-length cross slide with adjustable gib Longitudinal and cross feed driven by variable-speed three-phase AC motor via precision ball screw Feed and rapid traverse operated via cross selector lever Longitudinal and cross movements via electronic handwheels Increment selector switch in combination with electronic handwheel Additional contour handwheel Automatic central lubrication for guideways and ball screws Clampable top slide – Quick-change toolholder – Bedway clamping by excenter lever – Additional clamping via tension bolts for heavy workpieces – Quill adjustment by handwheel – Quill tip holder MK5 Connection voltage: 3 x 400 Volt +/-10%, 50 Hz for TN-S or TN-C networks without RCD Total connected load: 16 kVA Transistor-controlled three-phase main drive with speed monitoring If you have any questions, please feel free to contact us at any time.

Condition: ready for operation (used), Year of construction: 1972, Immediately available from university: L & Z Lathe Boehringer VDF Model E 560 Turning length: 4000 mm Year of manufacture: 1972 Very few operating hours Centre height: 305 mm Swing over bed: 610 mm Swing in gap: 810 mm Bledsypai Ajpfx Ah Iod Swing over cross slide: 375 mm Spindle bore: 82 mm Spindle speeds: 7 – 1400 rpm Drive: 12.5 kW Heidenhain digital readout Chuck Faceplate Multifix tool post with numerous inserts Steadies Weight: 7 t Price: EUR 10,500.— plus VAT, ex location

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, spindle bore: 83 mm, turning diameter: 570 mm, swing diameter over cross slide: 340 mm, center height: 280 mm, spindle speed (max.): 2,500 rpm, The machine is designed for heavy-duty turning and series production due to its robust construction! TECHNICAL DETAILS Speed range: 1 – 2,500 rpm Torque: 1,300 – 1,600 Nm Swing diameter over bed: 570 mm Swing diameter over cross slide: 340 mm Bodpfx Ahjymx N Ns Ijld Center height: 280 mm Distance between centers: 2,000 mm Spindle bore: 83 mm (optional 128 / 165 mm) Number of turret positions: 8 Turret tool holder: VDI 40 shank Tailstock quill diameter: 80 mm Tailstock taper: MK5 MACHINE DETAILS Control system: WEILER SIEMENS 810D Main drive power: 20 / 17 kW (60% / 100% duty cycle) Dimensions & Weight Dimensions (L x W x H): 3,850 mm × 1,850 mm × 1,750 mm Machine weight: 4,200 kg

Condition: good (used), Year of construction: 2015, functionality: fully functional, turning diameter over cross slide: 360 mm, turning diameter: 570 mm, swing diameter over cross slide: 570 mm, quill diameter: 95 mm, rapid traverse Z-axis: 12 m/min, spindle speed (max.): 2,500 rpm, feed length X-axis: 7 mm, feed rate X-axis: 7 m/min, type of input current: three-phase, overall weight: 2,970 kg, Technical Data: - Swing diameter - Centre distance - Spindle speed - Power - Feed - Rapid traverse - Quill diameter - Quill stroke - Quill taper - Tool turret - 570 mm over bed - 360 mm over cross slide - 2000 mm - max. 2500 rpm - 11 kW - max. 7.5 m/min (longitudinal) - max. 7.5 m/min (cross) - 12 m/min (longitudinal) Bledpoymtbgefx Ah Ied - 15 m/min (cross) - 95 mm - 220 mm - Morse Taper 5 (MK 5) - automatic - 8-position (see also options) - CAPTO turret disk Technical Description: - Machine bed - Cross slide - Tailstock - Operator station - Control system - Accuracy - Electrical equipment - Machine enclosure - Paintwork 2) Additional Features / Options - Accessories - made from pearlitic cast iron GG-26 - high rigidity due to heavy ribbing - guideways hardened and ground - automatic lubrication of bedways - manual - quick clamping - two movable handwheels on the control panel - one movable handwheel - CNC control "Siemens 828 D" - Siemens "Comfort" (incl. ShopTurn and rest material detection) - as per DIN 8605 - electronic handwheels (X and Z axes) - low-voltage lighting - full enclosure - RAL 7035 (light grey) / RAL 9023 (pearl dark grey) - Options - coolant system - chip tray - chip conveyor - operating manual - 3-jaw wedge-bar chuck, Ø 250 mm Condition: all existing base jaws / top jaws from Sommer must be compatible! - Removable tool turret (can be exchanged for Multifix) Dimensions: 3.8 m x 1.3 m x 2 m (L x W x H) Weight: 2.97 t Tools are not included in this offer!

Condition: used, Year of construction: 1995, turning diameter 560 mm turning length 1250 mm control Sinumerik 805 turning dia. over face-slide 340 mm spindle bore 63 mm spindle turning speed range 3 - 2500 U/min feeds - longitudinal 0,001 - 3 mm/U feeds - cross 0,001 - 3 mm/U rapid traverse longitudinal 7 m/min rapid traverse cross 3,5 m/min thread - mm pitch 0,5 - 140 mm thread - inch 1/4 - 56 Gang/ inch. thread - module mm Bljdpeymp Suofx Ah Ijd main drive 19 kW clamping length max. 2250 mm total power requirement 24 kW weight of the machine ca. 4,8 t dimensions of the machine ca. 4,0 x 1,65 x 1,75 m controll Siemens 805, for cone turning, contour turning and threat cutting. Machine has MULTIFIX toolholder system size "C", steady and 3 jaw chuck.

Condition: good (used), Year of construction: 2013, operating hours: 12,000 h, functionality: fully functional, turning diameter over cross slide: 370 mm, spindle bore: 104 mm, turning length: 3,000 mm, turning diameter: 554 mm, center width: 3,000 mm, turning diameter over top slide: 370 mm, overall weight: 4,000 kg, chuck outer diameter: 315 mm, Equipment: chip conveyor, We are offering this well-maintained Alpha Colchester Alpha cycle-controlled lathe, year of manufacture 2013. Manufacturer: Alpha Model: Colchester Alpha Year of manufacture: 2013 Condition: good Bodpfxsydkane Ah Ijld Category ID: 1616 Type ID: 2488 Machine type: cycle-controlled lathe If you have any questions or need further information, please send us a message or give us a call.

Condition: used, Year of construction: 2007, Number of controlled spindles (C axes): 2 Number of controlled axes: 8 Number of channels: 3 Max. bar diameter: 65 mm Bodpfjydfq Ijx Ah Isld Bore in tie rod: 75 mm Chuck diameter: 175 mm Spindle nose: 140 mm Max. speed: 5,000 rpm Nominal torque: 191 Nm Nominal power: 20 kW DATA FOR THE W2 AXIS OF THE COUNTER SPINDLE Stroke: 690 mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 2,400 N X1 AXIS DATA Stroke: 165 mm Rapid traverse: 40 m/min Max. acceleration: 10 m/s² Nominal force: 2,400 N Z1 AXIS DATA Stroke: 678 mm Rapid traverse: 30 mm Max. acceleration: 5 m/s² Nominal force: 5,000 N Y1 AXIS DATA Stroke: 80(+50/-30) mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 5,000 N X2 AXIS DATA Stroke: 165 mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 5,000 N Number of tool stations: 12 Tool holder diameter: 30 mm Driven stations: 12 mm Max. speed of driven tools: 4,000 rpm

Condition: used, Year of construction: 2008, Working area Circulation dia. above bed slide way cover: 680mm Circulation dia. above cross guide cover: 565 mm Facing traverse: 324 mm Longitudinal path: 600 mm Main spindle Spindle nose dia: 170 h5 / 220 h5 mm Bar dia. Max: 65 / 90 mm Spindle nose dia. in front bearing: 120 / 150 mm Spindle boring: 79 / 110 mm Chuck dia: 200 / 250 / 315 mm Drive rating S1 100% duty cycle: 25 / 33 kW Rotational speed range: 5000 / 4000 r.p.m Max. torque S1 100% duty cycle: 270 / 375 Nm Salient rotational speed: 900 / 850 r.p.m C axis (main spindle) Rotational speed: 250 r.p.m Stopping torque: 200 Nm Division accuracy: 0,025 deg. Compound slide X/Z/Y Facing traverse X: 260 / 1852 mm Longitudinal path Z: 635 / 6202 mm Ball spindle Z (dxh): 40x15 mm Vertical path Y: ±40 mm Ball spindle Y (dxh): 40x5 mm Rapid traverse speed X/Y/Z: 60/15/45 m/min Feed force X/Y/Z: 3,5/7/7 kN Tool holder Number of tool stations: 12 Tool mounting cylinder shaft (DIN 69880): 40 mm Tool disk, axial tool holder pitch circle dia: 370 mm Number of driven tools: 12 Drive rating max. 100% duty cycle: 4,9 kW Torque 100% duty cycle: 10,5 Nm Rotational speed range: 4500 r.p.m Tailstock Tailstock traverse path: 580 mm Tailstock force: 8 kN Bledpfxeya Iirs Ah Ijd Tailstock mounting: MT 5 Rapid traverse speed Z2: 6 m/min Part accuracy for positioning: =/< 10 mm Hydraulic Contents: 40 l Pump capacity: 2,2 kW Max. pressure: 80 bar Pressure for clamping unit, tailstock: 10-60 bar Coolant unit Contents: 210 l Pump capacity: 1,7 kW Feed rate at 6 bar: 20 l/min Electrical energy requirement Connected rating: 50 kVA Operating voltage: 400 V Frequency: 50 Hz Fuses (slow blow/VDE 0100) perm: 80 A Voltage fluctuations at 400 V: 6% - 10% Machine dimensions Dimensions (LxWxH) with chip conveyor: 4350/2460/2080 mm Weight without chip conveyor/chip bath: ca. 6.000 kg Workplace based constant noise pressure level: - (DIN 45635 part 1-04.85 (ISO 3740-1980), measured as a chip removing cycle as per DIN 45635 part 1601-07.78): 77 db (A) - in idle running as per DIN 45635 part 1601-07.78: 78 db (A)

Condition: used, Year of construction: 2008, weight of the machine ca. 8,8 t dimensions of the machine ca. 4500x1990x2300 mm Number of controlled spindles (C axes): 2 Number of controlled axes: 8 Number of channels: 3 Max. bar diameter: 65 mm Bore in tie rod: 75 mm Chuck diameter: 175 mm Spindle nose: 140 mm Max. speed: 5,000 rpm Nominal torque: 191 Nm Nominal power: 20 kW Blsdpfx Aheyat Hvs Ied DATA FOR THE W2 AXIS OF THE COUNTER SPINDLE Stroke: 690 mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 2,400 N X1 AXIS DATA Stroke: 165 mm Rapid traverse: 40 m/min Max. acceleration: 10 m/s² Nominal force: 2,400 N Z1 AXIS DATA Stroke: 678 mm Rapid traverse: 30 mm Max. acceleration: 5 m/s² Nominal force: 5,000 N Y1 AXIS DATA Stroke: 80(+50/-30) mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 5,000 N X2 AXIS DATA Stroke: 165 mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 5,000 N Number of tool stations: 12 Tool holder diameter: 30 mm Driven stations: 12 mm Max. speed of driven tools: 4,000 rpm Translated with (free version)

Condition: used, Year of construction: 1984, Lathe Bledex Nw Abjpfx Ah Iod Pfeifer Year of manufacture approx. 1984 Bed length 1.5 meters

Condition: used, Year of construction: 2000, centre height 280 mm centre distance 1200 mm turning diameter over bed 570 mm turning diameter over slide 365 mm turning length 1000 mm spindle taper DIN 55027 Gr. 8 control Sinumerik 810 D SIEMENS bed width 360 mm spindle bore 62 mm turning speed range 3 - 2500 U/min feed: 5000 mm / min rapid travel - longitudinal/face 10 m/min 3-jaw-chuck diameter 250 mm quick change toolholder SANDVIK Coromant Capto Blsdpsx E Dn Asfx Ah Iod drive capacity - spindle motor 25 kW taper in tailstock-quill MK 5 dia. of quill 100 mm quill stroke 190 mm voltage 400 V weight of the machine ca. 5,0 t dimensions of the machine ca. 3,55 x 2,20 x 1,95 m - Serial No.: 2022-3742-03 - CNC-Control SIEMENS Sinumerik 810 D - Rapid feed - Coolant equipment - Machine lamp

Condition: good (used), Year of construction: 1999, functionality: fully functional, Machine new white-color in 2014 (order by SIEMENS Energy) Technical Data Working area Max. swing over bed: 570 mm Max. swing over cross slide: 365 mm Max. turning length: 1500 mm Centre height over flat bed: 280 mm Max. workpiece weight: 400 / 1000 kg Max. workpiece clamping length: 1300 mm Work spindle Spindle head DIN 55027, size 8, internal taper 70 Spindle bore: Ø 62 mm Spindle diameter in front bearing: 100 mm Spindle through-hole (depth): 200 mm Max. chuck size: Ø 315 mm Speed range: 3–2500 rpm Max. faceplate diameter: Ø 560 mm Max. faceplate speed: 700 rpm Max. torque: 1800 Nm Carriage – travel Longitudinal travel (Z-axis): 1160 mm Cross travel (X-axis): 345 mm Tooling system: Parat-3 Tool cross-section DIN 770 (h × b): 32 × 25 mm Tailstock Tailstock movement by hand Quill taper: MK5 (MT5) Quill diameter: 80 mm Quill stroke: 190 mm Accessories / special equipment CNC control: SINUMERIK 810 D 32-bit processor, digital control ManualTurn with cycle support 10.4" colour LCD display Operating manual 094.0003.1330-00 3-jaw chuck Ø 315 mm Faceplate Ø 350 mm (up to Ø 560 for thin workpieces) Radius turning function Turret on support: size 3, Parat 4-station, manually indexable 4 × 90° Chip conveyor Bürener Maschinenfabrik Bljdpfox Ahx Djx Ah Ied Particularly suitable for: see production spectrum

Condition: good (used), Year of construction: 1999, turning diameter over cross slide: 365 mm, spindle bore: 62 mm, turning length: 2,000 mm, turning diameter: 570 mm, Swing over bed Ø: 570mm Swing over cross slide Ø:365mm DBC Turning Length: 2000mm Spindle bore: 62mm Spindle power: 25kW Tailstock spindle Ø: 100Ø Stroke pinole: 190mm Blodpfx Ajxxh N Ush Ijd Spindle taper: 4Mk Workpiece weight: 2500 Speeds / ranges: 2500Rpm Feed rate X-Axis: 5000mm/min. Feed rate Z-Axis: 10000mm/min. Length: 5200mm Width: 2200mm Height: 2100mm Weight: 5200kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: ready for operation (used), operating hours: 33,600 h, functionality: fully functional, spindle bore: 83 mm, center width: 2,000 mm, turning diameter over bed slide: 570 mm, spindle speed (max.): 2,500 rpm, controller model: Siemens 810D, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Swing diameter over bed: 570 mm Swing diameter over carriage: 340 mm Centre distance: 2,000 mm Speed range, stage 1: 1–625 rpm Speed range, stage 2: 4–2,500 rpm Spindle bore: 83 mm Spindle nose: Size 8 DIN 55027 Feed range longitudinal/cross: 0–20 mm/rev Metric threads: 0.1–400 mm Inch threads: 1/4–56 TPI Tailstock quill diameter: 80 mm Taper: MK 5 MACHINE DETAILS Control: Siemens 810D Electrical data Main drive: 20/17 kW Connected load: 30 kW Dimensions (L x W x H): 4,000 x 2,300 x 1,800 mm Operating hours: 33,600 hours Bljdsxqpgfepfx Ah Ijd EQUIPMENT Rapid traverse longitudinal/cross 8-position Sauter tool turret incl. holders Mayfran chip conveyor with coolant system Movable chip guard cover 3-jaw chuck Schunk Rota S 250 Manuals Note: The viewing windows and feed selection levers have been replaced. In addition, an oil change has been performed and the oil filter replaced.

Condition: ready for operation (used), Year of construction: 2000, operating hours: 60,334 h, functionality: fully functional, machine/vehicle number: 01510000031, spindle bore: 70 mm, turning length: 1,350 mm, turning diameter: 500 mm, center width: 1,350 mm, spindle speed (max.): 3,000 rpm, No reserve price - guaranteed sale to the highest bidder! The payment deadline for the machine is 20/11/2025! Placing a bid obligates you to collect the machine within the specified period between 01/12/2025 and 05/12/2025! TECHNICAL DETAILS Bsdpfxoxm Slco Ah Iold Turning length: 1,350 mm Swing diameter: 500 mm Swing diameter over cross slide: 290 mm Swing diameter over bed: 500 mm Chuck diameter: 250 mm Maximum spindle speed: 3,000 rpm Cross slide travel: 260 mm Distance between centers: 1,350 mm Spindle nose: 8 Spindle bore: 70 mm MACHINE DETAILS Control: HEIDENHAIN Dimensions & Weight Dimensions (L x W x H): 3,000 x 1,800 x 1,700 mm Total weight: 4,000 kg Electrical Data Type of input current: Three-phase Operating voltage: 400 V Frequency: 50 Hz Rated current: 25 A Connection load: 14 kVA Operating hours: 60,334 h

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, spindle bore: 62 mm, turning length: 2,340 mm, turning diameter: 570 mm, spindle speed (max.): 2,500 rpm, controller model: SIEMENS SIN 810 D, TECHNICAL DETAILS Turning diameter: 570 mm Bjdpfoxf Dk Usx Ah Isld Turning length: 2,340 mm Turning diameter over support: 345 mm Spindle head according to DIN 55027: Size 8 Spindle bore: 62 mm Tailstock quill taper: MK 5 Spindle speeds: 3 - 2,500 rpm MACHINE DETAILS Control: SIN 810 D Total power requirement: 35 kW Dimensions & Weight Dimensions: approx. 4.85 x 2.10 x 2.00 m Machine weight: approx. 5.60 t EQUIPMENT extended machine bed steady rest chip tray cooling system 4-jaw chuck

Condition: ready for operation (used), Year of construction: 2003, Weiler E50 x 1000 precision lathe (2003) Manufacturer: Weiler Type: E50 x 1000 Year of manufacture: 2003 Condition: good, used, under power Bedpsxd Tikjfx Ah Ijld Operating hours: 43.000h Technical data see pictures. Included in delivery: - Original documentation - Rota S Plus 250-62 - Bezel - Parat 4 compartment tool turret

Condition: used, Year of construction: 2017, Emcomat E300 for sale. The machine was manufactured in 2017. Machine type: EM300x1500 SIEM Year: 2017 Some repairs have been carried out, and the following defects are known to us: Bljdpfxjw I S Uus Ah Iod Geometry checked. Z-guides in the area of the main spindle (chuck) are 'slightly' worn. Tool turret checked and adjusted. X-axis belt renewed and machine zero point set. Z-guides in the area of the chuck are slightly worn. Automatic band lubrication oil leak – troubleshooting completed, problem resolved, lubrication oil line renewed. 100% operational. Loaded free of charge. Immediately available. Location: 8740 Zeltweg, Austria

Condition: used, Year of construction: 2007, functionality: fully functional, turning diameter over cross slide: 435 mm, spindle bore: 70 mm, turning length: 1,500 mm, turning diameter: 640 mm, center width: 1,500 mm, turning diameter over bed slide: 640 mm, swing diameter over cross slide: 435 mm, quill stroke: 190 mm, quill diameter: 100 mm, quill travel distance: 190 mm, center height: 320 mm, rapid traverse X-axis: 5 m/min, rapid traverse Z-axis: 5 m/min, swing diameter over bed slide: 640 mm, spindle speed (min.): 3 rpm, spindle speed (max.): 2,500 rpm, feed length X-axis: 365 mm, feed length Z-axis: 1,500 mm, feed rate X-axis: 10 m/min, feed rate Z-axis: 10 m/min, bed width: 1,800 mm, workpiece weight (max.): 1,600 kg, type of input current: AC, travel distance cross slide: 365 mm, rotational speed (min.): 3 rpm, rotational speed (max.): 2,500 rpm, three-jaw chuck diameter: 315 mm, torque: 640 Nm, travel distance X-axis: 365 mm, travel distance Z-axis: 1,500 mm, workpiece weight between centers: 1,600 g, spindle diameter: 100 mm, workpiece diameter between centers: 640 mm, distance between centers: 1,500 mm, workpiece length between centers: 1,500 mm, chuck outer diameter: 315 mm, Equipment: rotational speed infinitely variable, Model: VDF Boehringer DUS 630 Swing diameter over bed: 640 mm Swing diameter over cross slide: 435 mm Travel of cross slide / top slide: 365 mm / 145 mm Center height over flat bed: 320 mm Distance between centers: 1,500 mm Cross slide dimensions (W x L): 265 x 630 mm Top slide dimensions (W x L): 220 x 425 mm Turning tool section: 32 x 25 mm Spindle bore: 70 mm Front spindle diameter: 100 mm Max. torque (40% / 100% duty cycle): 1,600 / 640 Nm Speed range (overall): 3–2,500 rpm Gear stages: 2 Constant cutting speed: 1–9,999 m/min Feed range transverse/longitudinal: 0.01–50 mm/rev Max. feed rate transverse/longitudinal: 10 m/min Rapid traverse transverse/longitudinal: 5 m/min Feed force transverse/longitudinal: 12,500 N Bjdswywxdspfx Ah Ield Metric thread pitches: 0.1–400 mm Quill diameter / stroke / taper: 100 mm / 190 mm / MT5 Faceplate: Ø 630 mm Setover tailstock center: Ø 150 mm Workpiece weight (max.): Between centers: 400 kg With tailstock & 2 steadies: 1,600 kg Display: 10.4" color LCD, showing (among others) spindle speed, feed rate, position, tool, load

Condition: used, Year of construction: 1996, Technical details: turning diameter: 500 mm turning length: 1500 mm turning diameter over bed slide: 290 spindle bore: 71 mm turning speed range: 3 - 2800 U/min rapid speed: 10 / 5 m/min feed speeds: 1 - 2000 mm/min total power requirement: 22 kW weight of the machine ca.: 3,2 t dimensions of the machine ca.: 3,0 x 1,6 x 2 m Blodpfx Ajwwlvljh Isd with Teach In controll R&D MTC-K PARAT toolpost 1 fixed steday dia. 100 mm 4 jaw face plate dia. 500 mm coolant attachment *

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: F00269, turning diameter over cross slide: 280 mm, spindle bore: 82 mm, turning length: 1,500 mm, turning diameter: 500 mm, spindle speed (max.): 300 rpm, TECHNICAL DETAILS Control: Siemens 802 C Turning diameter: 500 mm Bledswviucopfx Ah Isd Turning length: 1,500 mm Turning diameter over cross slide: 280 mm Spindle bore: 82 mm Spindle speeds: 20–3,000 rpm Feeds – longitudinal: 0–5,000 mm/min Feeds – cross: 0–5,000 mm/min Rapid traverse longitudinal: 5 m/min Rapid traverse cross: 5 m/min Travel – z: 1,435 mm Travel – x: 295 mm Quill stroke: 150 mm Bed width: 350 mm MACHINE DETAILS Machine weight: approx. 3 t Required space: approx. 3.23 x 1.47 x 1.73 m Main motor: 7.5 kW

Condition: not inspected (used), Year of construction: 2012, functionality: unexamined, machine/vehicle number: 12.0273 / 121V0308, spindle bore: 128 mm, turning diameter: 530 mm, center width: 3,000 mm, turning diameter over bed slide: 830 mm, spindle speed (min.): 1,800 rpm, No minimum price – guaranteed sale to the highest bidder! Placing a bid obliges you to collect the machine punctually between 28.07.2025 and 31.07.2025. TECHNICAL DETAILS Max. machining diameter: 530 mm Swing diameter over bed: 820 mm Swing diameter over cross slide: 530 mm Distance between centers: 3,000 mm WORK SPINDLE Front spindle nose (DIN 55027, 55029): B11 / C11 Spindle bore: 128 mm Taper in spindle (metric): 132 mm Control: HEIDENHAIN MP620 Spindle speed range: 0–400 / 20–1,800 rpm Torque level 1: 2,150 Nm Torque level 2: 430 Nm X-AXIS Travel: 370 mm Ballscrew diameter/pitch: 32/5 mm Rapid traverse: 10 m/min Max. feed force: 10 kN Repeatability of positioning: 0.01 mm Z-AXIS Ballscrew diameter/pitch: 50/10 mm Stroke: 3,000 mm Rapid traverse: 10 m/min Max. feed force: 20 kN Repeatability of positioning: 0.015 mm TOOL TURRET Type: Multifix D Tool profile: 40 x 40 mm TAILSTOCK Tailstock quill diameter: 115 mm Quill stroke: 225 mm Bedpowu E Icjfx Ah Isld Morse taper in quill: Morse 6 MACHINE DETAILS Connection voltage: TN-C 400/230 V Frequency: 50 Hz Installation dimensions: 5,000 x 2,200 x 1,900 mm Weight: 5,300 kg Connected load: 38 kVA EQUIPMENT With technical documentation Coolant tank capacity: 200 l Chip conveyor capacity: 160 l

Condition: ready for operation (used), Year of construction: 1994, functionality: fully functional, turning length: 1,000 mm, turning diameter: 570 mm, quill stroke: 190 mm, bed width: 360 mm, rotational speed (max.): 2,500 rpm, TECHNICAL DETAILS Swing over bed: 570 mm Swing over cross slide: 365 mm Cross slide travel: 345 mm Center height over flat track: 280 mm Bed width: 360 mm Bed slide guide length: 520 mm Cross slide width: 225 mm Cross slide length: 680 mm Turning tool cross-section according to DIN 770 hxb: max. 20 x 20 mm Thread pitch: 01-400 mm Main spindle Spindle head according to DIN 55 027: Gr. 8 Spindle diameter in front bearing: 100 mm Spindle bore: 62 mm Blsdpfxswmck Ss Ah Isd Main spindle inner taper: 70 mm Speed range gear stage I: 3–500 rpm Speed range gear stage II: 15–2500 rpm Constant cutting speed: 1–9999 m/min Speed control: 50–120% Load display in % on screen: 0–140% Main drive Three-phase AC motor: 0–120 kW Drive power (60%/100% duty cycle): 19/15 kW Maximum torque (60%/100% duty cycle): 1,800/1,400 Nm Total speed range: 3–2,500 rpm Number of gear stages: 2 Feed drives Feed range, flat and Longitudinal: 0.01-50 mm/rev Max. feed rate, transverse (rapid traverse): 5 m/min Max. feed rate, longitudinal (rapid traverse): 10 m/min Conventional rapid traverse, longitudinal: 5 m/min Tool holder Number of tool holders: 8 Diameter of the 8 cylindrical shank holders according to DIN 69 880: 30 mm Tailstock Quill diameter: 80 mm Quill stroke: 190 mm Inner taper of the quill: MK 5 Tip angle, normal: 60° MACHINE DETAILS Dimensions (L x W x H): 3.25 x 2.03 x 1.95 m EQUIPMENT - Disk tool turret for 8 tools with VDI 30. - Not for driven tools - Machine manual, technical documentation; - 3-jaw chuck, various tool holders

Condition: used, Year of construction: 2003, centre height 255 mm centre distance 1.080 mm turning diameter over bed 500 mm turning diameter over slide 290 mm turning length 1.000 mm control EuroTurn spindle bore 70 mm spindle taper KK 8 DIN 55027 3-jaw-chuck diameter 250 mm bed width 360 mm turning speed range 2 - 2.800 U/min rapid travel - longitudinal/face 10 / 5 m/min quick change toolholder PARAT Gr. 2 drive capacity - spindle motor 11,0 kW taper in tailstock-quill MK 5 Bljdewizltspfx Ah Ied dia. of quill 80 mm quill stroke 160 mm voltage 400 V total power requirement 16,0 kVA weight of the machine ca. 3,0 t dimensions of the machine ca. 2,85 x 1,60 x 1,80 m - Serial-No.: 495 / 03 - control: EuroTurn - quick change tool holder PARAT - coolant equipment - machine lamp
