Maschinentechnik Hofgeismar GmbH

Condition: good (used), Year of construction: 1988, Description: Heavy-duty, high-precision horizontal lathe with Rohm hydraulic clamping system, slide with two working positions, Sauter 4-position tool turret, circular turning unit, CNC 6 axes, tailstock, chip conveyor. Suitable for both high-volume material removal and high-precision turning. Machine modified with a 2000 mm face clamping plate and increased in size. Year of production: 1988 Made in: Germany Turning diameter over bed: 2500 mm Turning diameter over telescopic covers: 2200 mm Turning diameter over slide: 1400 mm Turning length: 6000 mm Three-jaw chuck table: 2000 mm Spindle bore: 200 mm Fgodpfxsxmb Ade Afpjh Attachment for circular turning Workpiece weight: 4,500–40,000 kg Turret head: 4 positions Spindle speed range: 4 – 400 rpm Main motor Siemens 95.5 kW Maximum torque: 40,000 Nm Overall power requirement: 125 kW Control: CNC SIEMENS 8T, 6 controlled axes Machine weight: 43,000 kg Required space: 13,000 x 4,000 mm

Condition: like new (used), Year of construction: 2021, operating hours: 1,200 h, functionality: fully functional, turning diameter: 1,100 mm, power: 46 kW (62.54 HP), distance between centers: 2,000 mm, load hours: 1,200 h, A DMT CD1100 lathe with Heidenhain control and only 1200 operating hours is available. The working area includes a swing diameter of approx. 1100 mm over bed and approx. 800 mm over cross-slide. The tool holder is a Multifix D1. The distance between centers is 2000 mm. The main spindle drive is a motor with 46 kW power at 60% duty cycle and features a two-speed gearbox. Tailstock: - Quill diameter: 125 mm - Taper: 6 Mk Electrical equipment: - Three-phase current: 400 V, 50 Hz - VDE and EMC directives EN50081-2 / EN50082-2 Delivery: Collection by the buyer Fjdpfx Afsxlza Hepjgh Payment: 100% prepayment by bank transfer immediately upon invoicing All details are subject to change and prior sale is reserved. The machine is sold without any warranty claims and remains our property until full payment has been received.

Condition: good (used), Year of construction: 1960, Ref. -No.: 10605 Fedpfxexhbuie Afpsgh Manufacturer: VDF WOHLENBERG Type: E 1000 Year of construction: 1960 Type of control: CNC Control: Sinumerik Storage location: Halberstadt Country of origin: Germany Machine-No.: 32XX Turning Diameter Over Bed: 1500 mm Turning Diameter Over Slide Rest: 1150 mm Centre Height: 750 mm Centre Distance: 9000 mm Faceplate Diameter: 1000 mm Spindle Bore: 80 mm Spindle Speed Min.: 1,4 - 280 RPM Turning diameter over cross slide: 800 mm Swing diameter over cross slide: 800 mm Space requirement: 13000 x 2650 x 2250 mm Power Capacity: 320 kW Weight Of The Machine Ca.: 8 t Max. turning diameter (in the offset): 2000 mm Size of the inner cone: metr. Kegel 1:20 quill cone: 80 O

Condition: excellent (used), Tacchi HD/1450 X 4M Large Spindle Bore (515mm) Year 2002 Siemens CNC Control Swing over bed 1450mm Swing over saddle 1000mm Fgedpsxg Ivdofx Afpeh Hollow spindle 515mm Chucks front and rear of Headstock Speed range 1.5 – 450 rpm 15,000kg weight between centres Baruffaldi 4 way Auto Toolpost 2 x 3 point steadies

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, Equipment: documentation/manual, The used, FULLY REFURBISHED self-learning CNC lathe GEMINIS GHT4 720X3000 is a robust, medium-large parallel bed lathe equipped with FAGOR 8055 CNC, center height 360 mm, distance between centers 3000 mm, spindle bore 106 mm. Fgsdpfexdvbcex Afpoh The machine is COMPLETELY REFURBISHED AS NEW, including bed grinding, carriage grinding, Turcite overlays, spindle bearings, axis bearings, axis screws, electrical system, motor overhaul, new drives, new FAGOR keyboard, etc. The equipment is completed with prearrangement for automatic turret, manual self-centering chuck, and 2 steadies.

Condition: good (used), Year of construction: 2006, Brand: GEMINIS Model: GHT4 G2 700x 2000 Cnc: FANUC 21 TB Distance between centers: 2000 mm Fgedpfx Afoxdub Iopeh Ø Swing over bed : 720 mm Ø Over carriage: 470 mm Spindle diameter : 104 mm Maximum piece weight between points : 2.560 kg Spindle nose: DIN 55027-11 Spindle speed: 0-1600 m/min Total power : 28 kw

Condition: used, turning diameter over bed 2400 mm turning diameter over slide rest 2200 mm turning length 10000 mm power capacity 185 kW faceplate diameter 1650 mm turning speeds 1,5 -150 U/min max. workpiece weight 70000 kg clamping diameter 1400 mm Technical data Working range Maximum turning diameter over support: 2200 mm Maximum swing diameter over bed: 2400 mm Maximum turning length: 10,000 mm Clamping diameter in the headstock faceplate: 300 - 1,600 mm with special jaws up to 2,050 mm Clamping diameter in the tailstock faceplate: 300 - 1,400 mm Mounting in roller blocks: 1000 - 2250 mm Mounting in roller steady rests: 300 - 1100 mm Maximum workpiece weight: 70000 kg Main drive, faceplate Faceplate diameter: 2000 mm Faceplate speeds, continuously adjustable in 4 stages: 1.5 - 150 rpm Maximum torque at rated speed: 220,000 Nm Drive power of main motor: 185 kW Flange centre point angle: 70° Supports Travel of the plunge slide: 500 mm Travel of the face slide: 1400 mm Quick adjustment, longitudinal: 2000 mm/min Quick adjustment, face: 800 mm/min Infinitely variable feed, longitudinal: 0.6 - 300 mm/min Infinitely variable feed, face: 0.3 - 120 mm/min Max. cutting force at support: 20,000 kg Tailstock Faceplate diameter (removable): 1650 mm Faceplate clamping diameter: 1400 mm Flange centre point angle: 70° Quick adjustment: 1250 mm/min Fgsdpfxoxddvne Afpsh Special equipment Copying device for first support Copying length 8500 mm Max. copying depth in one pass 500 mm Boring device: Boring bar 460 x 390 mm Drilling diameter 600 - 1000 mm Maximum drilling depth in one pass 2700 mm At Ks of 200 kp/mm² - s max. = 1.5 mm/rev a = max. chip cross-section 30 mm² at a projection of 1000 mm Reduced chip cross-section with increasing drilling depth A guide ruler for cone turning, adjustment angle up to 8° and a maximum cone length (in one pass) of 2000 mm, adjustment accuracy ± 5 minutes. A guide ruler for cone turning, adjustment angle up to 15° and a maximum cone length (in one pass) of 1000 mm, adjustment accuracy ± 5 minutes. A base for sliding jaw steady rests for the 3401 cylindrical grinding machine. 125 kg auxiliary crane on spindle box.

Condition: used, VTL SC 17 CC Vertical Turret Lathe Specification: Faceplate diameter: 1450 mm Fgjdpfx Asxdcxuofpoh Swing diameter: 1700 mm Turning height: 1200 mm Weight of the machine ca.: 22 t

Condition: good (used), Year of construction: 1985, Ref. -No.: 10595 Manufacturer: GILDEMEISTER MAX MüLLER Type: MD 6S Year of construction: 1985 Type of control: CNC Control: EPL 4 Storage location: Halberstadt Country of origin: Germany Tool holder type: 2 x VDI 50 Centre Distance: 1765 mm Spindle passage: 101 mm Swing diameter over bed: 720 mm Swing diameter over cross slide: 490 mm Lathe chuck diameter, max.: 400 mm Fodpfsxc Tuwex Afpjgh Power Capacity: 50 kW Weight Of The Machine Ca.: 16 t Turning Speed Range: 10 - 2800 rpm Quill holder: MK 5 Further information: - Equipment - Powered tools - Tailstock - Automatic quill stroke - Chip conveyor - Automatic sliding safety doors - Hydraulic steady rest - 2 turrets

Condition: used, turning diameter over bed 2000 mm turning diameter over slide rest 1700 mm turning length 10000 mm control SIEMENS Sinumerik 820 T power capacity 110 kW faceplate diameter 1950 mm turning speeds 1 - 140 U/min max. workpiece weight 70000 kg dia. of quill 450 mm Technical data Working range Maximum turning diameter over support: 1700 mm Maximum turning diameter over bed: 2000 mm Maximum turning length: 10000 mm Clamping diameter in the headstock faceplate: 400 - 1700 mm Mounting in roller block, see conversion instructions: 800 - 1400 mm Mounting in steady rests: Small steady rest with cap: 170 - 550 mm Large steady rest with cap: 500 - 825 mm Maximum workpiece weight between centres: 70,000 kg Main drive, faceplate Faceplate diameter: 1950 mm Faceplate speeds: 1 - 140 rpm Drive power of main motor: 110 kW Support Faceplate travel: 1000 mm Faceplate 80 mm / 35 mm wide 6 x detent points at 71 mm Heavy-duty cutting and BTS system Quick adjustment, longitudinal: mm/min Quick adjustment, horizontal: mm/min Feed rates continuously adjustable, longitudinal: mm/min Infinitely adjustable feed rates, cross: mm/min Tailstock Quill diameter: 450 mm Fedpfxsxc Ny Nj Afpjgh Quill adjustment range: 225 mm Centre point angle: 70° Special equipment Control: Sinumerik 820 T Tailstock faceplate Tailstock clamping system (700–1400 mm diameter) Roller block Boring device

Condition: used, turning diameter over bed 2400 mm turning diameter over slide rest 2270 mm turning length 12000 mm control SIEMENS Sinumerik 820 T power capacity 185 kW faceplate diameter 1850 mm turning speeds 1,6 - 175 U/min max. workpiece weight 70000 kg Technical data Working range Maximum turning diameter over support: 2270 mm Maximum swing diameter over bed: 2400 mm Maximum turning length with 30 mm slide: 12000 mm with 80 mm slide: 11,500 mm Clamping diameter in the headstock faceplate: 300 - 2,040 mm Clamping diameter in the tailstock faceplate: 300 - 1,300 mm Mounting in roller blocks: 1000 - 1750 mm Load capacity: 35 t Mounting in roller steady rests: 800 - 1100 mm Load capacity: 30 t Mounting in roller steady rests of M0911: 300 - 1100 mm Maximum workpiece weight: 70,000 kg Main drive, faceplate Faceplate diameter: 2,200 mm Faceplate speeds, infinitely variable in 4 stages: 1.6 - 175 rpm Maximum torque at rated speed: 220,000 N·m Drive power of main motor: 185 kW Flange centre point angle: 70° Supports Travel of upper support: 735 mm Travel of plunge slide, 35 mm wide: 720 mm Travel of the face slide, 80 mm wide: 720 mm The slides can be adjusted continuously Fsdpfxexc Ny Aj Afpjgh Rapid traverse, longitudinal: mm/min Rapid traverse, face: mm/min Feed rates, continuous, longitudinal: 0.05 - mm/min Stepless feed, face: 0.05 - mm/min Max. cutting force at support: 200000 N Face slide: Heavy-duty machining and BTS system Tailstock Diameter of faceplate (removable): 1850 mm Clamping diameter of faceplate: 1300 mm Flange centre point angle: 70° Quick adjustment: 2000 mm/min Special equipment Sinumerik 820 T control Slider measuring system Boring holder with boring bar holder ø 300 mm

Condition: used, Year of construction: 2006, centre distance 11000 mm centre height 450 mm turning diameter over bed slide 700 control Fagor 8070 T workpiece weight max. 12000 kg spindle bore 150 mm spindle speed U/min dimensions of the machine ca. 14 x 4,2 x 24 m Spindle: Fgsdpsxcbh Eefx Afpoh - Spindle power at the headstock 51/56 kW - Spindle speed at the headstock rpm - Gear stages 2 - Headstock spindle nose DIN 55026-A11 - Through hole of the spindle at the headstock 150 mm Slides: - 2 longitudinal slides with a maximum feed rate of 8 m/min - 2 cross slides with a maximum feed rate of 8 m/min Equipment/accessories: - faceplate Ø 700 mm - manual hollow chuck steady rest through hole up to Ø 300 mm and with 4 jaws chuck Ø 600, - 2 manual tool carriers size 300, 4 positions - 2-channel CNC control with 2 control panels - Manual tailstock - 3 manual closed steady rests Ø 300 and with clamping devices for Ø 600 mm - 2 manual C-steel rings Ø 100-450 mm, for both slides 1+2 - Cooling water unit with pump for each slide 1200 liters - Chip conveyor - Technical documentation

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, SFM Sunfirm CNC lathe in good working condition. Specifications: Swing diameter over bed: 1520 mm Swing diameter over cross slide: 1100 mm Swing diameter in gap: 1800 mm Distance between centers: 3000 mm Spindle speed: 6–500 rpm in 4 steps Z-axis travel: 3300 mm Bed width: 850 mm Control: FAGOR 8055 8-position turret Motor power: 30/37 kW Accessories: 4-jaw chuck 1400 mm Chip conveyor Fedew Uqf Sopfx Afpsgh 8-position turret Steady rest

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, CNC long-turning lathe Manufacturer: GEMINIS Model: GHT6-1300 X 6000-2 G Year: 2005 Serial number: 3600006 with FAGOR CNC8055T control with ROTA-S 3-jaw chuck 4-position tool holder Coolant system Turning length: 6000 mm Centre height: 750 mm Chip conveyor 3 steady rests Fgsdpfxow Tdinj Afpjh Face plate

Condition: excellent (used), Year of construction: 1997, High-Performance 3-Bed CNC Lathe Manufacturer: Gurutzpe – Spain Model: B 1400/3 x 8000 Year of manufacture: 1997 Control: NUM Max. swing diameter over bed: 1,420 mm Fedpfxow Snu Eo Afpegh Center height: 710 mm Max. turning diameter over cross slide: 1,150 mm Max. turning length: 8,000 mm Chuck spindle power: 75 HP Chuck speed: up to 600 rpm (4-speed gearbox) Chuck torque: 16,000 Nm Rapid traverse X/Z: 5,000 mm/min X-axis travel: 850 mm Z-axis travel: 8,000 mm Turret with automatic 4-position changer Max. workpiece weight without steady rests: 14,000 kg with 1 steady rest: 17,000 kg, with 2 steady rests: 19,000 kg Machine equipment: – 1 x travelling steady rest – 2 x fixed steady rests – 1 x chip conveyor

Condition: good (used), Centre distance: 6500 mm Centre height: 665 mm Swing diameter over bed: 1270 mm Turning diameter over cross slide: 1000 mm Spindle speed: 3.55-710 rpm Faceplate diameter: 1200 mm X-axis travel: 600 mm Fedew R Avbjpfx Afpjgh Main spindle bore: 128 mm Tailstock quill diameter: 200 mm Tailstock quill travel: 350 mm Tailstock quill taper: DIN 55028 Main spindle nose: DIN 55027 Accessories: 3 steadies, documentation

Condition: used, Year of construction: 1999, turning diameter 1250 mm turning length 1300 mm control Siemens Sinumerik 840 D greates pass round over bed 1250 mm swing diameter max. over cross slide 1000 mm swing in the crank max. 1250 mm spindle diameter in front bearing 500 mm faceplate diameter 1250 mm chucking diameter 1250 mm max. torque 1200 Nm Working spindle: -Spindle head according to DIN 55021 -Max. chuck diameter 1250 mm Equipment/accessories: -Various clamping jaws -Tool measuring probe -Chip conveyor Fgedpfx Asw Rrb Tofpjh -Filter system -Technical documentation

Condition: used, Year of construction: 2008, turning diameter 1000 mm swing diameter 1250 mm turning height 500 mm control Siemens Sinumerik 840 D Workpiece spindle flange diameter 520 mm work piece spindle speed range 0-440 U/min total power requirement 75 kW weight of the machine ca. 25 t dimensions of the machine ca. 5100 x 3034 x 4500 mm With grinding spindle Table travel: - Z1/Z2 axis 1000 mm, - X1/X2 axis approx. 1300 mm Table speed continuously adjustable: - Z axis 0–30 m/min, - X axis 0–50 m/min - Feed speed continuously adjustable 0.01–15 mm/min Fedpfsw Rgcfox Afpsgh - Feed dependent on stroke 0.0005–0.1 mm - Workpiece spindle positioning C axis Equipment/accessories: - Grinding spindle - Kaiser dresser - Tool measuring probe - Filter system - With flushing nozzle connections - 2 Capto holders - 1 set of jaws for chuck - technical documentation

Condition: used, Year of construction: 1998, functionality: limited functionality, turning length: 3,000 mm, turning diameter: 720 mm, Machine for sale on behalf of a customer, open to offers. Inspection possible in the 885xx area. The machine is no longer connected to the power supply. Fjdew Dn Dfepfx Afpsgh Defects: Loss of power in the drive during machining; small parts function without any issues, the problem only occurs when processing larger parts.

Condition: ready for operation (used), Year of construction: 1984, turning diameter over cross slide: 1,050 mm, turning length: 4,000 mm, turning diameter: 1,050 mm, spindle speed (max.): 250 rpm, travel distance X-axis: 800 mm, travel distance Z-axis: 4,100 mm, CNC LATHE IKEGAI ANC75 Retrofit 2013 (original 1984) Fanuc-0iTD Chuck: 1250mm, swing over bed: 1500mm, swing over carriage: 1050mm, center distance: 4000mm 1 steady rest Fsdpfjw Dndxsx Afpsgh

Condition: excellent (used), Year of construction: 2006, Center width 11000 mm Center height 450 mm Cross slide 700 mm Max. Workpiece weight 12t Headstock power 51/56 kW Headstock speed 0-166 / 0-800rpm Gear stages 2 Headstock DIN 55026- A11 Headstock through hole 150 mm 2 longitudinal slides with max. feed rate 8 m/min 2 cross slides with max. feed rate 8 m/min 2 manual tool holders size 300 4 positions Accessories: - Face plate 700 mm - Chip conveyor with coolant tank - 3 closed steady rests - 2 open steady rests c-type Fjdpfx Ajw A Naxjfpegh - 1 steady rest with faceplate 600 mm

Condition: ready for operation (used), Year of construction: 2009, turning diameter over cross slide: 925 mm, turning length: 2,800 mm, turning diameter: 1,200 mm, spindle bore: 132 mm, spindle speed (max.): 2,000 rpm, CNC Siemens 840D 48-tool changer, Capto C8 tools chip conveyor Forkardt 400MM chuck, 2 hydraulic steady rests SMW Autoblok capacity 2800x1250MM, spindle bore 132MM weight 23,500 kg Fgsdowzyn Ropfx Afpjh

Condition: used, Year of construction: 2013, An ex University HAAS TL3 with 12” screen, 3 jaw chuck, quick change tool post, tailstock and coolant equipment. ready for a powered demonstration in the Bristol showroom. Specification: Max Turning length 1524 mm Max Turning Diameter 508 mm Swing over bed 508 mm Swind over Cross Slide 330.2 mm X-axis Travel 304.8 mm Z-axis Travel 1524 mm Spindle taper A2-6 Spindle bore 88.9 mm Max spindle speed 1800 rpm Fgodpfxswzyd Se Afpoh Spindle motor power 22.4 kW Tailstock Foot Print LxWxH 3073.4 × 1574.8 × 2032.0 Weight 2949.2 kg

Condition: excellent (used), Brand: GEMINIS Model: CNC 4 PLUS 620 x 2000 Cnc : FAGOR Distance between points : 2000 mm Height of centers : 315 mm Fsdpfx Afswznp Nepogh Max. turning diameter : 620 mm Swing over saddle diameter : 370 mm Bar passage : 80 mm Precision swivelling turret: 1st speed range: 0 to 355 rpm 2nd speed range :0 to 1800rpm Tailstock : Morse 6 Main motor : 15 kw Max. Piece weight : 2.560 kg Tailstock quill diameter : 140 mm Machine size (L x Wx H): 4300x 1900 x 1800 mm

Condition: excellent (used), Year of construction: 2015, CNC Lathe with c-axis GEMINIS - GHT4-G4 MACH-ID 9182 Make: GEMINIS Type: GHT4-G4 Control: FAGOR 8055 TC Year: 2015 Full C-Axis 360.000 Driven tools Axiaal & Radial  Driven tailstock  Steady rest C-Type Front chuck with 180 bore Rear chuck with 180 bore 3 guide way bed width 750 mm Max. turning Ø: 800mm Fgedpowzh Eqofx Afpsh X-Axis: 450mm Z-Axis: 4200mm Spindle bore: 162mm Speedrange: 900Rpm ATC / revolver: 8 Speed live tools:3000Rpm Power live tools:7.5kW Pinole taper: 5Mk Stroke pinole: 250mm Workpiece load: 2500 Length: 8200mm Width: 3200mm Height: 2900mm Weight: 24000kg
