Automatics & Machinery

Condition: ready for operation (used), Year of construction: 2015, operating hours: 43,196 h, spindle motor power: 25,000 W, spindle speed (max.): 5,000 rpm, bar diameter (max.): 65 mm, total width: 1,990 mm, total height: 2,300 mm, overall weight: 9,500 kg, controller manufacturer: FANUC, controller model: 310, product length (max.): 4,500 mm, number of axes: 8, This 8-axis DMG MORI Sprint 65 linear was manufactured in 2015. It features a maximum main spindle speed of 5000 rpm and a maximum main spindle bar diameter of 65 mm. The machine includes two turrets, each with 12 driven tool positions, and a robust coolant tank capacity of 650 liters. If you are looking to get high-quality turning capabilities, consider the DMG MORI Sprint 65 linear multi-spindle turning machine we have for sale. Contact us for further details. • Total hours: 64274 h; Operating hours: 43196 h • Counter spindle: 17 kW; max speed 5000 rpm; max bar diameter 45 (65) mm • CNC controlled axes: • X1: stroke 165 mm; rapid 30 m/min; acceleration 5 m/s2 • Z1: stroke 678 mm; rapid 30 m/min; acceleration 5 m/s2 • Y1: stroke 80 (+50/-30) mm; rapid 30 m/min; acceleration 5 m/s2 • X2: stroke 165 mm; rapid 30 m/min; acceleration 5 m/s2 • Z2: stroke 640 mm; rapid 30 m/min; acceleration 5 m/s2 • W2: stroke 690 mm; rapid 30 m/min; acceleration 5 m/s2 • Turrets: 2; 12 driven positions per turret; Tool system VDI 30; Max driven tool speed 4000 rpm • Coolant system: tank approx. 650 l; pump capacity per turret 20 l/min; pressure 7 bar • Power supply: 91 kVA • Base machine configuration and functions: • Drive for slide 1 and 2 (all 12 positions) • C-axis for main and counter spindle • Y-axis for slide 1 • Counterspindle collet cleaning with coolant • Mechanical preparation for oil mist filter • Electrical and software interface for bar loader • Angular synchronism between main and counter spindle • Automatic machine shut down • 2 additional on/off outputs (4 M-functions) • Rigid tapping • Piece and time counter • Software for polygonal turning (slide 1 and 2) • Constant cutting speed • Helical interpolation (slide 1) • Spindle speed control • Quadruple warning light • Cooling device for electrical cabinet • Control options: • Tool wear monitoring system (FANUC monitor) • Sister tool selection system (FANUC monitor) Additional equipment • IEMCA MASTER 865 MP 43 L bar feeder • Swarf (chip) conveyor, belt type Pgsdpfx Anszhkl Djpon • Workpiece unloading device including belt • Main spindle collet chuck MPF 65/140 (no axial feed), max Ø 65 mm • Manual collet changer SACO MPT65/140 and MPF65/140 • Counter spindle chuck SMW 175-BBD, incl. adapter • 1 set of soft jaws for SMW 175-BBD • Differential clamping pressure for counter spindle (two selectable pressures) • External flushing of jaws/collets with coolant on main and counter spindle • Various new spare parts available Technical Specification Counter Spindle Yes

Condition: ready for operation (used), Year of construction: 2015, operating hours: 42,222 h, spindle speed (max.): 5,000 rpm, bar diameter (max.): 65 mm, total width: 1,990 mm, total height: 2,300 mm, travel distance X-axis: 165 mm, travel distance Y-axis: 80 mm, overall weight: 9,500 kg, controller manufacturer: FANUC, controller model: 310, product length (max.): 4,500 mm, number of axes: 8, This 8-axis DMG MORI Sprint 65 linear was manufactured in 2015. It features a maximum workpiece diameter of 175 mm and a maximum bar diameter of 65 mm. The machine is equipped with two turrets, each with 12 driven tool positions, and offers a maximum spindle speed of 5000 rpm. If you are looking to get high-quality turning capabilities, consider the DMG MORI Sprint 65 linear multi-spindle turning machine we have for sale. Contact us for further details. Podpozhklwjfx Anpegn Control system: CNC 310 isTotal hours: 61295 hOperating hours: 42222 hMain spindle power 20/25 kWCounter spindle power 17 kWMax. main spindle speed: 5000 rpmMax. counter spindle speed: 5000 rpmMax. main spindle bar diameter: 65 mmMax. counter spindle bar diameter: 45 (65) mmCNC CONTROLLED AXESStroke X1 165 mmRapid speed X1 30 m/minAcceleration X1 5 m/s2Stroke Z1 678 mmRapid speed Z1 30 m/minAcceleration Z1 5 m/s2Stroke Y1 80 (+50/-30) mmRapid speed Y1 30 m/minAcceleration Y1 5 m/s2Stroke X2 165 mmRapid speed X2 30 m/minAcceleration X2 5 m/s2Stroke Z2 640 mmRapid speed Z2 30 m/minAcceleration Z2 5 m/s2Stroke W2 690 mmRapid speed W2 30 m/minAcceleration W2 5 m/s2Number of turrets 2Number of rotating tools each station 12 all driven positionsTool system VDI 30Max driven tool speed 4.000 rpmApprox. coolant tank capacity 650 lCoolant pump acity (per each turret) 20 l/minPump pressure 7 barPower supply 91 kVALxWxH of the machine 4.500x1.990x2.300 mmApprox. machine weight 9.500 kgIEMCA MASTER 865 MP 43 L (4m) bar feederBase machine configuration:- Drive for slide 1 and 2 (all 12 pos.)- C-axis for main and counter spindle- Y-axis for slide 1- Swarf conveyor belt type- Counterspindle collet cleaning with coolant- Workpiece unloading including belt- Mechanical preparation for oil mist filter- Electrical and software interface for bar loader- Angular synchronism between main and counter spindle- Automatic machine shut down- 2 additional on/off outputs (4 M-functions)- Rigid tapping- Piece and time counter- Software for polygonal turning for slide 1 and 2- Constant cutting speed- Helical interpolation for slide 1- Spindle speed control- Quadruple warning light- Cooling device for electrical cabinetAdded options:I-V50011 Collet chuck Type "MPF 65/140" without axial feed for main spindle max. diameter: mping elements and other equipment:I-V50025 Manual collet changer type "SACO MPT65/140 and MPF65/140"I-V50092 Differential pressure for counterspindle, possibility of setting two different clamping pressures.I-V50083 1 set of soft jaws for chuck type "SMW 175-BBD"I-V50080 Chuck type "SMW 175-BBD" For counter spindle, including adapter for adapting the spindleI-V60050 Tool holder for drilling tools with internal cooling and cylindrical shank Ø 32mm,with clamping shank according to DIN 69880 (VDI 30) - 4pcsI-V60010 Radial tool holder for external machining type C1 with clamping shank according to DIN 69880 (VDI 30) - 5pcsControl system options:I-V12060 Tool wear monitoring system Monitor for CNC FANUCI-V12070 Sister tool selection system for Tool Monitor for CNC FANUCHydraulic and filtration equipment:I-V40045 External flushing of jaws/collets with coolant on main spindle and counter spindleSpecial optionsSK001 Special clamping device with mandrel for counter spindle product HAINBUCH AXFIX 811 including 2 colletsVarious new spare parts are included. Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: used, Year of construction: 2005, Technical details: spindle passage: 36 mm Article: CNC-controlled multi-spindle automatic lathe Manufacturer: Schütte Psdpszg Aw Njfx Anpegn Type: A36PC Yob: 2005 Loading magazine by Pietro Cucchi Knoll unit 7 radial cross-type carriages 2 additional speed motors in 4th and 5th positions 2 additional speed motors for front spindles in position D (pick-up) and B (for front motorized spindle) 1 polygon cutter 1 motorized front spindle 1 radial motorized in position IV for cross-type carriage 1 radial motorized in position V to be mounted on X-type carriage only (no cross-type carriage) 1 straight head for motorized position IV 1 90-degree tilted head for motorized position IV 1 tilt-adjustable head for motorized position IV Please, contact us for getting more information and pictures on mail(at) or *

Condition: used, Tornos CNC-controlled multi-spindle automatic lathe Type/Model: Tornos MultiDeco 20.6 Condition: used Operating hours: 45,300 h Psdjzgwtxspfx Anpjgn Bar stock: Ø 5-22 mm Max. part length without secondary operation: 100 mm Max. part length with secondary operation: 80 mm Spindle rotation speed up to: 4000 rpm Max. spindle power: 15 kW Max. drilling/internal threading power: 3.7 kW Counter-spindle motor power: 1.1 kW Number of numerical axes: 17 Axial slide: 5 Cross slide: (radial and axial) 5 (Pos. 1 to 5) Facing slide: 1 CNC-controlled secondary operation slide with up to two secondary operation tools (Pos. 7) Connection value: 35 kW Dimensions (L x W x H): approx. 8053 mm x 1508 mm x 2210 mm Weight: approx. 8500 kg Equipment/Accessories: - Control system: Tornos PNC Deko - HIRTH - Gear cutting drum locking system - Spindle stop at Pos. 4 (activated via installation curves) - 2 quick-change drilling spindles XC06020.01; GWS Modular 40004; up to 80 bar - 3 fixed drilling units GWS Modular 40004; up to 80 bar - 7 base plates for tool holders GWS 60 AD60032 (Göltenbodt) - 7 base holders for turning tools GWS 60/41 (Göltenbodt) - Bar feeder integrated: TORNOS MSF 522/6 - Material guide channel for bar feeder - CO2 extinguishing system Kraft und Bauer - Oil treatment system Knoll: VRF 500/1550 - 2 high-pressure pumps, each 40 L/40 bar - 1 pump, 20 L/35 bar - Oil capacity approx. 2000 liters - Chip conveyor Knoll - No discharge chute

Condition: not inspected (used), MURATEC MT 12 horizontal axis cnc lathe with gantry FANUC 18 i numerical control Turning diameter (mm) 160 Rot. diameter on bench (mm) 250/210 Max. turning length (mm) 220 Spindle taper type ASA 5 Min spindle speed (rpm) 10 Spindle speed max (rpm) 4500 Spindle speed ranges 2 ELECTRONIC Rapid feed rate (mm/min) 24,000 Longitudinal travel (mm) 200 Z1 axis Transverse travel (mm) 200 X1 and X2 axis Turret type 2 x 15 Spindle motor power 7.5 kw Voltage (volts) 400 Year of construction 2005 Serial no. 04KX23750001 Weight (Kg) 5500 Height (mm) 2200 Width (mm) 2700 Depth (mm) 1850 gantry workpiece size diameter 120 mm x 100 mm; max. allowable workpiece weight 3 kg for No. 2 workpieces; rapid speed 120 m/min. Spindle bore (mm) 62 Accessories no. 2 axial motorized modules, no. 2 radial motorized modules, chip conveyor, Z-axis counter spindle 2 stroke 650 mm; counter spindle speed 4500 rpm; C-axis continuous, motorized tool speed 4000/min; motorized tool motor power 3 kw. YOM 2013 Psdpfozfw A Rex Anpogn

Condition: good (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: M130.67989, (Please tell us your offer price) Sale only within Europe, incl. Turkey Price without packaging; delivery condition: FCA (machine location) ===== Technical data see handout. All warranty rights are excluded. For the correctness of the technical data and year of construction, for the completeness of accessories and tool equipment, and for compliance with all safety and environmental protection requirements specified in the accident prevention regulations. No sale to private individuals. Pgodpfx Anozfwqnjpjn Sales only within Europe, incl. Turkey Price without packaging; Delivery condition: FCA (machine location) ===== Technical data please see handout in attachment. German text leading language. Without any guaranty and warranty, including completeness of tools & accessories as well as environmental and safety regulations. No private sales.

Condition: used, Year of construction: 1980, Wickman 1" SN: 17069 Mfd. 1980 6 Spindles 1" Capacity Motor and Controls Stock Stand and Reel Chip Conveyor Psdszfa U Nopfx Anpjgn Universal Threading Pickoff and back finish Recently Reconditioned

Condition: good (used), Year of construction: 2003, functionality: fully functional, Bored to Ø 36 mm Pedpfx Anozdttispogn 6 spindles KADIGO tool monitoring system with IEMCA PRA 52/42 F bar loader (4m bars) Accessories

Condition: good (used), Year of construction: 2001, functionality: fully functional, 6 spindles Pgsdpfx Aszdtn Tonpjn KADIGO tool monitoring system with IEMCA PRA 52/42 F bar feeder (4m bar length) Accessories

Condition: good (used), Year of construction: 2021, Description: The machine is in good technical condition, and can be tested upon prior arrangement. It features an automatic feeder and a Cucchi BLT rod loader, Type MULTI F-6, Model AN/PB20, Variant 3.3 M. Pedpfozcqa Eex Anpjgn

Condition: ready for operation (used), Year of construction: 2012, spindle motor power: 5,500 W, spindle speed (max.): 6,000 rpm, bar diameter (max.): 47 mm, total width: 1,650 mm, total height: 2,300 mm, travel distance X-axis: 130 mm, overall weight: 3,500 kg, controller manufacturer: FANUC, controller model: 31i-TA, product length (max.): 1,550 mm, number of axes: 4, This 4-axis Muratec MW 100 GT multi-spindle turning machine was manufactured in 2012. It features a maximum turning diameter of 168 mm and a turning length of 145 mm. The machine is equipped with two turrets, each with 8 stations, and a gantry loader for efficient operation. If you are looking to get high-quality turning capabilities, consider the Muratec MW 100 GT machine we have for sale. Contact us for further details. • Control Model: FANUC 31i-TA • Distance Between Spindles: 340 mm • Max. Swing Diameter: 295 mm • Max. Turning Diameter: 168 mm • Max. Turning Length: 145 mm • Spindle Nose: JIS A2-5 • Max. Chuck Diameter: 165 mm (6") • Spindle Bearing I.D.: 80 mm • Rapid Traverse X-Axis: 24 m/min • Rapid Traverse Z-Axis: 24 m/min • Number of Turrets: 2 • Turret Stations: 8 • Tool Shank Size: 20 x 20 mm • Max. Drill Diameter: 40 mm • Turret Index Time: 0.2 sec • Max. Workpiece Diameter: 80 mm • Max. Workpiece Length: 60 mm • Jaw Stroke Diameter: 12 mm • Max. Workpiece Weight (per Hand): 2.0 kg • Standard Loading Time: 4.5 sec • Minimum Machining Time: 16 sec • Loader X-Axis Travel: 1,420 + 1,420 mm • Loader Y-Axis Travel: 435 mm • Loader Z-Axis Travel: 135 mm • Loader Hand Swivel Range (Alpha Axis): 180° • Loader Hand Rotation Speed: 0.4 sec / 180° • Rapid Traverse Loader X-Axis: 150 m/min • Rapid Traverse Loader Y-Axis: 120 m/min • Rapid Traverse Loader Z-Axis: 55 m/min • Pallet Capacity: 14 • Max. Stacking Height: 450 mm • Workpiece Diameter Range: 30 - 160 mm • Max. Workpiece Weight per Pallet: 40 kg • Machine Footprint (with Accessories): 3,300 x 2,380 mm • Connected Load: 30 kVA • Portal Loader Systems: 2 • Part Chutes for Inspection Parts: 2 • Hydraulic Power Chucks: 2 x SMW Autoblok BHM 165, 6" • Hydraulic Cylinder (Left): SMW SIN-S 100 • Hydraulic Cylinder (Right): SMW VNK 70/37 • Air-Controlled Workpiece Presence Monitoring: Yes • Workpiece Clamping Monitoring: Both Sides • Spindle Orientation Positions: 4 (Both Sides) • Coolant Through Chuck: Both Sides • Automatic Coolant Pump Capacity: 200 l • 8-Station Turrets: 2 • Signal Tower Light: Yes • Oil Mist Extraction Preparation: Yes Pgedpfx Anszb It Hspjn • Automatic Machine Stop: Yes • Automatic Central Lubrication: Yes • RS232C Interface: Yes • External Transformer: Yes Optional: • Gantry Loader Type: 3-Axis Gantry Loader • Chip Conveyor Technical Specification Counter Spindle Yes Driven Tools No

Condition: ready for operation (used), Year of construction: 1992, spindle speed (max.): 36,000 rpm, bar diameter (max.): 60 mm, total width: 2,000 mm, total height: 1,900 mm, travel distance X-axis: 510 mm, travel distance Y-axis: 180 mm, overall weight: 4,300 kg, controller manufacturer: MAZATROL, controller model: T32-2, product length (max.): 2,700 mm, number of axes: 2, Multi-spindle turning machine manufactured in 1992. This Mazak Quick Turn 18 NSP features a maximum turning diameter of 260 mm and a turning length of 500 mm. It includes a tool turret with 8-fold / 16 positions and a spindle speed range of 36 - 3,600 rpm. If you are looking to get high-quality turning capabilities, consider the Mazak Quick Turn 18 NSP machine we have for sale. Contact us for further details regarding this machine. - Control: MAZATROL T32-2- Max. Turning Diameter: 260 mm- Max. Turning Length: 500 mm- Speed Range Main Spindle: 36 - 3,600 rpm- Speed Range Sub-Spindle: 36 - 3,600 rpm- Travel Z-Axis: 510 mm- Travel X-Axis: 180 mm- Spindle Bore: Ø 70 mm- Bar Loader Length: 3,000 mm- Collet Chuck Holder: For 185 E collets- Collet Chuck Range (Main Spindle): Ø 4 - 60 mm- Sub-Spindle: 3-jaw chuck, Ø 125 mm to Ø 70 mm- Tool Turret: 8-fold / 16 positions- Tool Eye: Measuring probe for tool measurement in working area- Main Spindle Chuck: KITAGAWA 3-jaw chuck Ø 254 mm- Coolant System: Complete coolant equipment- Foot Switch: 2 double foot switches for opening/closing both chucks- Machine Weight: 4,300 kg- Machine Dimensions (L x W x H): 2.7 x 2.0 x 1.9 m Psdpfozarf Rox Anpjgn Optional - Drip pan (2500 x 2700 mm), IRCO 3000 mm bar loader Technical Specification Counter Spindle Yes

Condition: excellent (used), Year of construction: 2007, Schutte SG18 with automatic bar loader IEMCA PRA. Includes numerous books, cams, etc. It is in excellent condition. We never use it in our facility. It was purchased for a project, but the volumes are too low for this excellent machine. Pedpfx Anszal Swepjgn

Condition: used, Year of construction: 2007, machine/vehicle number: 7041219, CNC control Traub System TX8 I, bar capacity 42 mm, max. turning length 450 mm, max. spindle speed 8000 rpm, 2 turrets each with 10 tool stations, driven tools, chip conveyor KNOLL 240 S-1/50, filtration system/compact band filter RESY KBF 452/500 Pgjdpfxsy Sqg Ss Anpon

Condition: used, Year of construction: 2008, machine/vehicle number: 7041245, CNC control Traub system TX8 I, bar capacity 42 mm, max. turning length 450 mm, max. spindle speed 8000 rpm, 2 turrets each with 10 tool stations, driven tools, coolant system, chip conveyor KNOLL 240 S-1/50, filtration system/compact band filter RESY Pgedpfx Anoy Sqg Eopjn

Condition: used, Year of construction: 1992, machine/vehicle number: 690, CNC control Traub system TX8 D, with 1 turret with 14 tool stations and 1 turret with 9 tool stations, driven tools, max. turning length approx. 1000 mm, bar capacity 80 mm, power 73 kW, with fleece filtration system and chip conveyor. Pgedpfxjy Sqimo Anpon

Condition: ready for operation (used), Year of construction: 1992, functionality: fully functional, bar diameter (max.): 51 mm, turning length: 102 mm, drilling depth: 102 mm, No minimum price – guaranteed sale to the highest bidder! Pedpfx Aney R R Nwepogn The machine is sold complete with collets, holders, and additional accessories! For more Schütte multi-spindle machines available from the same location, see below! TECHNICAL DETAILS Maximum turning length: 102 mm Maximum drilling depth: 102 mm Maximum round bar diameter: 51 mm Maximum square bar diameter: 36 mm Maximum hexagon bar diameter: 44 mm Maximum octagon bar diameter: 47 mm Spindle drum diameter: 340 mm Standard bar feed: 125 mm Special bar feed: 290 mm Standard longitudinal slide travel, total: 125 mm Standard longitudinal slide travel, working stroke: 100 mm Special longitudinal slide travel, total: 160 mm Special longitudinal slide travel, working stroke: 125 mm Upper cross slide travel, total: 60 mm Upper cross slide travel, working stroke: 36 mm Middle cross slide travel, total: 60 mm Middle cross slide travel, working stroke: 36 mm Lower cross slide travel, total: 70 mm Lower cross slide travel, working stroke: 44 mm Maximum material pass-through: 51 mm Maximum material feed: 125 mm MACHINE DETAILS Coolant capacity: 660 l Pump capacity: 170 l/min EQUIPMENT Thread cutting device Right-hand threading via undercut Electric submersible pump Collets Tool holders Additional accessories

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, spindle speed (max.): 3,150 rpm, bar diameter (max.): 32 mm, turning length: 80 mm, drilling depth: 80 mm, No minimum price – guaranteed sale to the highest bidder! The machine is sold with collets, fixtures, and additional accessories! For more Schütte multi-spindle machines available from the same location, see below! TECHNICAL DETAILS Max. turning length: 80 mm Max. drilling depth: 80 mm Maximum material passage: 32 mm Maximum material feed: 125 mm Turning speed: 200–3,150 rpm Thread cutting speed (right-hand): 11.2–1,575 rpm Pgedpfx Aey R R Igenpen MACHINE DETAILS Coolant capacity: 600 l Pump output: 170 l/min Dimensions & weight: Space required: 7.3 x 2.5 m Height: 2 m Weight: 8,300 kg Voltage: 380 V Current type: 50 Hz Main drive: 20.5 kW Immersion pump: 1.5 kW Feed drive: 1.5 kW Hydraulic pump: 1.5 kW Circulation oil pump: 0.25 kW EQUIPMENT 6 cross slides 6 longitudinal slides 6 cams for cross slides 6 cams for longitudinal slides Operating tools Collets Fixtures Additional accessories

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, bar diameter (max.): 32 mm, turning length: 80 mm, rotational speed (min.): 3,150 rpm, drilling depth: 80 mm, No minimum price – guaranteed sale to the highest bidder! The machine is sold complete with collets, holders, and additional accessories! For more Schütte multi-spindle machines from the same location, see below! TECHNICAL DETAILS Maximum turning length: 80 mm Maximum drilling depth: 80 mm Largest material passage: 32 mm Maximum bar feed: 125 mm Spindle speed (turning): 200–3,150 rpm Spindle speed (right-hand threading): 11.2–1,575 rpm Thread cutting unit: Right-hand thread via undercut MACHINE DETAILS Coolant capacity: 600 l Pump output: 170 l/min Dimensions & Weight Footprint: 7.3 x 2.5 m Height: 2 m Weight: 8,300 kg Voltage: 380 V Frequency: 50 Hz Main drive: 20.5 kW Immersion pump: 1.5 kW Feed drive: 1.5 kW Hydraulic pump: 1.5 kW Circulating oil pump: 0.25 kW EQUIPMENT 6 cross slides 6 longitudinal slides 6 cams for cross slides 6 cams for longitudinal slides Operating tools Collets Pgedpfxsy R Ruto Anpon Holders Additional accessories

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, bar diameter (max.): 32 mm, turning length: 80 mm, rotational speed (min.): 3,150 rpm, drilling depth: 80 mm, No minimum price – guaranteed sale to the highest bidder! The machine is sold complete with collets, holders, and additional accessories! For more Schütte multi-spindle machines from the same location, see below! TECHNICAL DETAILS Maximum turning length: 80 mm Maximum drilling depth: 80 mm Largest material passage: 32 mm Maximum bar feed: 125 mm Spindle speed (turning): 200–3,150 rpm Spindle speed (right-hand threading): 11.2–1,575 rpm Thread cutting unit: Right-hand thread via undercut MACHINE DETAILS Coolant capacity: 600 l Pump output: 170 l/min Dimensions & Weight Footprint: 7.3 x 2.5 m Height: 2 m Weight: 8,300 kg Voltage: 380 V Frequency: 50 Hz Main drive: 20.5 kW Immersion pump: 1.5 kW Feed drive: 1.5 kW Hydraulic pump: 1.5 kW Circulating oil pump: 0.25 kW EQUIPMENT Pgsdpfx Anjy R Rqbopsn 6 cross slides 6 longitudinal slides 6 cams for cross slides 6 cams for longitudinal slides Operating tools Collets Holders Additional accessories

Condition: ready for operation (used), Year of construction: 1992, functionality: fully functional, bar diameter (max.): 32 mm, turning length: 80 mm, drilling depth: 80 mm, No reserve price – guaranteed sale to the highest bidder! The machine is sold with collets, holders, and additional accessories! For more Schütte multi-spindle machines available at the same location, see below! TECHNICAL DETAILS Max. turning length: 80 mm Max. drilling depth: 80 mm Maximum bar diameter round: 32 mm Maximum bar diameter square: 22 mm Maximum bar diameter hexagonal: 27 mm Maximum bar diameter octagonal: 29 mm Spindle circle diameter: 300 mm Standard bar feed: 125 mm Special bar feed: 290 mm Normal longitudinal slide total travel: 100 mm Normal longitudinal slide working travel: 80 mm Special longitudinal slide total travel: 145 mm Special longitudinal slide working travel: 115 mm Cross slide upper slide total travel: 50 mm Cross slide upper slide working travel: 33 mm Cross slide middle slide total travel: 50 mm Cross slide middle slide working travel: 30 mm Cross slide lower slide total travel: 60 mm Cross slide lower slide working travel: 37.5 mm Maximum material passage: 32 mm Maximum material feed: 125 mm MACHINE DETAILS Voltage: 400 V Frequency: 50 Hz Coolant capacity: 700 l Pump: E-submersible pump Pump capacity: 180 l/min EQUIPMENT Rapid drilling device Gripper device Pgsdpfoy R Rnyox Anpon Reaming device Independent auxiliary longitudinal control Motorized cross slide adjustment Collets Holders Additional accessories

Condition: ready for operation (used), Year of construction: 1992, functionality: fully functional, bar diameter (max.): 32 mm, turning length: 80 mm, drilling depth: 80 mm, No minimum price – guaranteed sale to the highest bidder! Pgedpfey R Rm Aex Anpsn This machine is sold complete with collets, tool holders, and additional accessories. For more Schütte multi-spindle lathes available from the same site, please see below! TECHNICAL DETAILS Maximum turning length: 80 mm Maximum drilling depth: 80 mm Maximum bar diameter, round: 32 mm Maximum bar diameter, square: 22 mm Maximum bar diameter, hexagonal: 27 mm Maximum bar diameter, octagonal: 29 mm Spindle pitch circle diameter: 300 mm Standard bar feed up to: 125 mm Special bar feed up to: 290 mm Standard longitudinal slide travel, total: 100 mm Standard longitudinal slide travel, working travel: 80 mm Special longitudinal slide travel, total: 145 mm Special longitudinal slide travel, working travel: 115 mm Upper cross slide travel, total: 50 mm Upper cross slide travel, working travel: 33 mm Middle cross slide travel, total: 50 mm Middle cross slide travel, working travel: 30 mm Lower cross slide travel, total: 60 mm Lower cross slide travel, working travel: 37.5 mm Maximum material passage: 32 mm Maximum material feed: 125 mm MACHINE DETAILS Voltage: 400 V Frequency: 50 Hz Coolant capacity: 700 l Pump: Submersible electric pump Pump output: 180 l/min EQUIPMENT High-speed drilling unit Gripper unit Reaming unit Independent auxiliary longitudinal control Powered cross slide adjustment Collets Tool holders Additional accessories

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, spindle speed (max.): 3,150 rpm, bar diameter (max.): 32 mm, turning length: 80 mm, drilling depth: 80 mm, No minimum price – guaranteed sale to the highest bidder! The machine is sold with collets, holders, and additional accessories! Pjdpjy R Rkuefx Anpegn For more Schütte multi-spindle machines being sold from the same location, see below! TECHNICAL DETAILS Maximum material passage: 32 mm Maximum material feed: 125 mm Maximum turning length: 80 mm Maximum drilling depth: 80 mm Turning speed: 200–3,150 rpm Thread cutting speed (right-hand): 11.2–1,575 rpm Thread cutting device: Right-hand thread by underspinning MACHINE DETAILS Coolant capacity: 600 l Pump output: 170 l/min Dimensions & weight Footprint: 7.3 x 2.5 m Height: 2 m Weight: 8,300 kg Voltage: 380 V Current type: 50 Hz Main drive: 20.5 kW Immersion pump: 1.5 kW Feed drive: 1.5 kW Hydraulic pump: 1.5 kW Circulating oil pump: 0.25 kW EQUIPMENT 6 cross slides 6 longitudinal slides 6 cams for cross slides 6 cams for longitudinal slides Operating tools Collets Holders Additional accessories

Condition: ready for operation (used), Year of construction: 1991, functionality: fully functional, bar diameter (max.): 32 mm, turning length: 80 mm, rotational speed (max.): 3,150 rpm, drilling depth: 80 mm, No minimum price – guaranteed sale to the highest bidder! Pgsdsy R Rcwopfx Anpen The machine is sold with collets, tool holders, and additional accessories! For more Schütte multi-spindle machines from the same location, see below! TECHNICAL DETAILS Maximum bar capacity: 32 mm Maximum bar feed: 125 mm Maximum turning length: 80 mm Maximum drilling depth: 80 mm Spindle speed for turning: 200–3,150 rpm Spindle speed for right-hand thread cutting: 11.2–1,575 rpm MACHINE DETAILS Coolant capacity: 600 l Pump output: 170 l/min Dimensions & Weight Required space: 7.3 x 2.5 m Height: 2 m Weight: 8,300 kg Voltage: 380 V Frequency: 50 Hz Main drive: 20.5 kW Immersion pump: 1.5 kW Feed drive: 1.5 kW Hydraulic pump: 1.5 kW Circulating oil pump: 0.25 kW EQUIPMENT 6 cross slides 6 longitudinal slides 6 cams for cross slides 6 cams for longitudinal slides Operating tools Collets Tool holders Additional accessories

Condition: ready for operation (used), Year of construction: 1983, functionality: fully functional, spindle speed (max.): 3,150 rpm, bar diameter (max.): 32 mm, overall weight: 8,300 kg, No reserve price – guaranteed sale to the highest bidder! The machine is sold with collets, tool holders, and additional accessories! For more Schütte multi-spindle machines being sold from the same location, please see below! TECHNICAL DETAILS Maximum bar diameter, round: 32 mm Maximum bar diameter, square: 22 mm Maximum bar diameter, hexagonal: 27 mm Maximum bar diameter, octagonal: 29 mm Spindle circle diameter: 300 mm Bar feed normal/special up to: 125 / 290 mm Longitudinal slide travel, standard, total/work stroke: 100 / 80 mm Longitudinal slide travel, special, total/work stroke: 145 / 115 mm Cross slide travel, upper slide, total/work stroke: 50 / 33 mm Cross slide travel, middle slide, total/work stroke: 50 / 30 mm Cross slide travel, lower slide, total/work stroke: 60 / 37.5 mm Number of spindle speeds: 49 Spindle speed range I: 450–3,150 rpm Spindle speed range II: 200–1,400 rpm Psdpfx Asy R N Uljnpsgn Workpiece revolutions per operation, standard: 60–425 Workpiece revolutions per operation, shortened: 33.5–236 Workpiece revolutions per operation, extended: 95–670 Number of main times per spindle speed: 35 MACHINE DETAILS Drive motor rated power: 18.5 kW Drive motor speed: 1,500 rpm Dimensions with control cabinet (L x W): 3,850 x 1,510 mm Length with bar feeder: 6,453 mm Machine weight: 8,300 kg Space requirement for packed machine: 15 m³ EQUIPMENT Collets Tool holders Additional accessories
