Condition: used, Year of construction: 1998, turning diameter / mm turning length / mm control / Technical Specifications Working Area Max. swing diameter: 540 mm Max. turning diameter: 540 mm Max. turning diameter over ways: 520 mm Max. turning length: 1029 mm Main Spindle Speed range: 35–5,000 rpm Main drive power: 22 kW Max. torque: 349 Nm Spindle nose: A2 – 6 inches Spindle bore: 61 mm Spindle positioning C-axis: 0°–360°/0.001° Tool turret Tool turret type: Single-spindle turret Driven tools Speed range: 15–6,000 rpm Drive power: 7.5 Kw Max. torque: 103 Nm Tool magazine Number of tool positions: 40 Max. tool weight: 7 kg Machine weight: approx. 5700 kg Rjdpfxsyyqthe Afper A wide range of accessories included – see photos A backup from 3 September 2012 is available

Condition: ready for operation (used), Mori Seiki Duraturn 2550 Still in production Year: 2007 Rjdpfx Aoyyqhrefpsr Weight: 4,250 kg Motor spindle: 19.5 kW 3,000 RPM Turning length: 436 mm Turning diameter: 340 mm Dimensions: 2375 x 1793 x 1832 mm Also for sale: DMU 50 V, DMU 70, CTX 320

Condition: as good as new (ex-display), Year of construction: 2023, • Hwacheon Cutex 180 AL SMC, year of manufacture 2023, new machine • CNC control: Fanuc 0i-TF Plus LCD with Manual Guide I • Rapid traverse X / Z / B: 36 / 36 / 36 m/min • Max. turning diameter: Ø 300 mm • Max. turning length: 478.5 mm • Chuck size: 6" / Ø 150 mm, 5" / Ø 120 mm • Max. spindle speed: Main spindle 6,000 rpm / Sub-spindle 6,000 rpm • Bar capacity: Ø 51 / 32 mm • Main/sub-spindle motor power: 11 / 15 kW, 3.7 / 5.5 kW • 12-station turret, all stations driven • 5,000 rpm, 3.7 / 5.5 kW • Robust full slant bed made from stabilized Meehanite cast iron with precision linear guides on all axes • High-performance spindles with spindle nose A2-5 / sub A2-4 • Automatic tool measurement arm • Parts catcher • Full enclosure • Hydraulic system • Coolant system with retractable tank, 6 bar pump • Ergonomically designed, swiveling control panel • Electronic handwheel • Waterproof LED work area lighting Rjdpfx Aoyypvbsfpsr • Transformer

Condition: as good as new (ex-display), Year of construction: 2023, • Hwacheon Cutex 180 AL YSMC, year of manufacture 2023, new machine • Control: Fanuc 0i-TF Plus LCD with Manual Guide I • Rapid traverse X / Z / B: • 36 / 36 / 36 m/min • Y-axis travel: +/- 55mm • Max. turning diameter: Ø 300mm • Max. turning length: 478.5mm • Chuck size: • 6” / Ø 150mm, 5” / Ø 120mm • Max. spindle speed: • Main spindle 6,000 rpm Rodoyypuwspfx Afpsr • Sub spindle 6,000 rpm • Bar capacity: Ø 51 / 32mm • Main/Sub spindle motor power: • 11 / 15 kW, 3.7 / 5.5 kW • 12-station turret, all stations driven • 5,000 rpm 3.7 / 5.5 kW • Robust one-piece slant-bed made from stabilized Meehanite cast iron, with precision linear guideways on all axes • Powerful spindles with spindle nose A2-5 / Sub A2-4 • Automatic tool presetter • Parts catcher • Full enclosure • Hydraulic system • Coolant system with movable tank, 6 bar pump • Ergonomic pivoting control panel • Electronic handwheel • Waterproof LED work area lighting • Transformer

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Technical details turning diameter 820 mm turning length 6000 mm control Siemens Si 840 D sl total power requirement 155 kW weight of the machine ca. 65 t dimensions of the machine ca. 16350 x 3700 x 3850 m Additional information Redjyymvlepfx Afpjr Purchase price EUR 1.550.000 Time recording from Feb. 2025 Operating hours = 38601 h Main spindle = 1958 h Milling spindle = 1760 h CNC control Si 840D sl Working area 6000 mm Working height 1390 mm Swing diameter over bed slide/bed 820 mm X-axis travel +850 -25 mm Z-axis travel 6820 mm C-axis, smallest increment +/-0.001° Workpiece spindle Spindle head according to DIN 55026 A15 Bathing through 160 mm Front diameter Bearing 240mm 2-stage gearbox, infinitely variable programmable Drive power at 100/60% duty cycle: 78/87kW Speed ranges: 2 Speed range I: 10-501 rpm Speed range II: 10-1750 rpm Torque I, 60% duty cycle: 8000 Nm Torque II, 60% duty cycle: 2308 Nm C-axis Holding torque with backlash-free spindle brake: 3000 Nm Speed: 0-50 rpm Maximum torque (100/60% duty cycle): 3700/4430 Nm Steady rest clamping range: 70-425 mm Turning, drilling, milling head Front diameter: Bearing 110mm Interface HSK100/C8 Tool magazine Storage locations: 2 magazines, Baluff chip system Max. tool diameter (each position/every 2nd position) 125/200mm Max. tool length 600mm Tool weight 25kg Tailstock Quick diameter 180mm Stroke 170mm Internal taper MK6 Axially force, manually adjustable 5-30 kN Quick tip height adjustment +/-0.15mm Other: Collision monitoring sensor ACS 3-ARTIS Chip conveyor system Coolant system 980l tank and more

Condition: good (used), Year of construction: 2007, functionality: fully functional, CNC turning and milling centre with Y-axis, 2 turrets, subspindle and bar feeder. A total of over 44.000,- EUR has been invested in necessary repairs and maintenance over the last 5 years by DMG MORI (replacement of the main spindle S4, ball-screws, etc.). Redsyymhzspfx Afpsr Technical details turning diameter 100 mm turning length 320 / 345 mm control Siemens 840 D swing diameter 145 mm spindle distance 580 mm slide I - cross travel (X1) 220 mm slide I - longitudial travel (Z1) 320 mm y-axis +/- 30 mm rapid traverse (X/Y/Z) 30/15/30 m/min slide II - cross travel (X2) 120 mm slide II - longitudial travel (Z2) 345 mm rapid traverse (X/Z) 30 m/min Travel subspindle (Z3) 380 mm vertical stroke (X3) 145 mm bar material dia. max. 36 mm rapid traverse (X/Z) 20/30 m/min power capacity (40/100 % ED) 26/21 kW spindle turning speed range 40 - 7200 U/min total power requirement 42 kVA weight of the machine ca. 5,3 t Equipment: - SIEMENS 840 D powerline CNC control - Number of controlled axes: 9 - 2 x C-axis - Y-axis in upper turret - Pick-up device with gripper - 2 SAUTER turrets with 12 tool positions (driven), VDI 25 - Tool drive with a speed range of 30 to 6000 rpm - Coolant system with paper band filter - Chip conveyor - Collet chuck on main and subspindle - Bar loading magazine, make: IEMCA BOSS 332 E 32 L, max. bar length 3180 mm

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, Technical details turning diameter 660/275 mm turning length 1498 mm control Fanuc/Mori Seiki MSX 701 total power requirement 90 kVA weight of the machine ca. 26,6 t dimensions of the machine ca. 5301 x 2997 x 2788 mm Additional information 9-axis CNC turning and milling centre * Fanuc MSX-701 CNC control * Milling spindle at top (B axis), as full 4th axis, positioning 0.0001 deg. * 40-position tool magazine * 10-position turret at bottom, all positions driven * 2 x 3-jaw quick-change chuck KNCS-N 315/91 * KNOLL high-pressure coolant system, pressure setting 12/25/35/45/55/62 and 72 bar, with maintenance-free rotary filter system Rsdpfx Afsyyk R Tspor * Chip conveyor * Drain system for main spindle chuck (controlled via M function) * Drain system for tool cutting edge (controlled via M function) * Coolant gun incl. accessories * Oil mist extraction * Direct measuring system X1, X2, Y-axis * Bar loader interface * Double foot switch for both spindles * Islands and pocket programming for MAPPS * High-speed fixed cycle for MAPPS * Programm memory extension to 8 MB * Programm restart * 3-stage signal lamp * 512 MB memory card (CF card) Swing diameter over cross slide (tool spindle 1): 750 mm Swing diameter over cross slide (turret 2): 400 mm Max. turning diameter (tool spindle 1): 660 mm Max. turning diameter (turret 2): 275 mm Max. machined workpiece length: 1498 mm Max. bar material: 90 mm Travels: X1 axis (tool spindle): 750 mm Y axis (tool spindle): 420 (+/- 210) mm Z1 axis (tool spindle): 1635 + 100 mm for tool change B axis (tool spindle): +/- 120 deg., full B-axis 1 deg. indexed and 0.0001 deg. braked X2 axis (turret): 195 mm Z2 axis (turret): 1525 mm SZ axis (subspindle): 1610 mm Rapid traverse: (X1,Z1) 50 m/min. / (Y,X2,Z2,SZ) 30 m/min. Main and subspindle: Spindle speeds infinitely variable (spindle 1 + 2): 30-3000 rpm. C axis (spindle 1 + 2): 0.001 deg. Main spindle motor: 22/18.5 kW Subspindle motor: 22/18.5 kW Torque (spindle 1 + 2): 1000 Nm Disc turret: Number of tool positions: 10 Speed of driven tools: 6000 rpm. Drive power: 5.5/3.7 kW Milling spindle head: Tool holder: HSK A63 Max. speed: 12,000 rpm Drive power: 18.5/11 kW Torque: 120/44 Nm Tool changer: 40-stations Tool diameter 70/140 mm Tool length 400 mm Tool weight 8/10 kg Total power requirement 90 kVA Main dimensions Length x width x height 5301 x 2997 x 2788 mm Machine weight 26.6 t Accessories: Measuring arm (picture) tool measurement in machine Tool holder + box, reduction sleeves, driven tools Clamping jaws package Collets package

Condition: good (used), Year of construction: 2014, functionality: fully functional, Technical details turning diameter 356 mm turning length 510 mm control M 730 BM travel -x axis 260 mm travel -y axis -50 / +50 mm travel -z axis 590 mm Travel subspindle (B) 624 mm bar material dia. 65 mm main spindle speeds: 5000 transmission ratio 2 power capacity 15 / 11 kW Subspindle spindle speeds 6000 power capacity 11 / 7,5 kW rapid traverse (X,Y,Z,B) 30/10/30/30 m/min weight of the machine ca. 6,6 t Additional information * CNC control Mitsubishi M 730 BM * Mainspindle with 3-jaw power chuck KITAGAWA N-08, diameter 210 mm * Subspindle with 3-jaw power chuck HAINBUCH B-TOP 165-43 Redpfxsyycggj Afpsr * 12-station turret, tool spindle speed 10000 rpm, power 5.5/3.7 kW * Y-axis travel * C-axis * High/low pressure chuck system for main and subspindle * MABEO high-pressure pump with 1.5 MPa filter unit * Coolant sprayer on the chuck for main and subspindle * Coolant sprayer for the machine bed cladding * Oil mist separator * Chip conveyor * Renishaw workpiece measuring system with optical signal transmission, subspindle * Cooling of the ball screw in the X-axis * Gantry loader, left-hand installation, 14-station storage, 20-pallet workpiece storage, Double gripper conveyor

Condition: excellent (used), Year of construction: 2020, functionality: fully functional, Technical details turning diameter 760 mm turning length 1540 mm control Fanuc 31i-B dimensions of machine 5500 x 2700 x 3110 mm chip conveyor 6900 x 2400 mm total power requirement 94,42 kW weight of the machine ca. 15,5 t Additional information Turning center with infinitely variable swiveling milling head and Y-axis, motorized lower turret and subspindle. Condition: Very well preserved, machine comes from a company liquidation. Time recording: Control unit on: 13127 hours Runtime: 3833 hours Processing time: 2835 hours The upper head is fed by a tool magazine and can turn or mill at various angles. Even highly complex components can be completely machined without further repositioning. Fanuc 31i-B CNC control Swing diameter over bed: 1000 mm Maximum turning diameter: 760 mm Maximum turning length: 1540 mm Maximum bar diameter (manual/continuous): 76/76 mm Y-axis travel: 230 mm (±115 mm) Clamp (counter spindle) ASA interface: A2-8 Spindle speed: 4000 rpm AC motor power (cont./30 min.) 22/26 kW Turning/milling head B-axis rotation / indexing 240 deg. (±120 deg.) Tool holder Capto C6 Speed in revolutions per minute 12000 rpm AC motor power 30 min. 15/18.5 kW Number of tools 40 (Opt. 80) Tool turret Redpfsyycd Esx Afpsr Number of driven tools 12 (12) Number of driven tools 7.8 kW/30 min.

Condition: good (used), Year of construction: 2011, Turning diameter 376mm, Redoyyakvopfx Afper turning length 760mm, bar capacity 76mm, Y axis -/+ 52.5mm, C axis 0.001 degrees, 12 station turret, 22KW Motor, Main spindle 4000rpm. milling -spindle 5000rpm, Fanuc I series, 3 jaw chucks, swarf conveyor, tool setter

Condition: excellent (used), Year of construction: 2007, turning length: 744 mm, turning diameter: 430 mm, spindle bore: 65 mm, Control: CNC path control with 10.4" TFT color display Siemens Sinumerik 840 D powerline TECHNICAL DATA Swing diameter * over bed: 600 mm * over cross slide: 500 mm Distance between main and sub spindle: 975 mm Max. turning diameter: 430 mm Max. turning length: 744 mm Max. bar diameter: 65 mm Max. workpiece size with sub spindle: ø 200 x 200 mm Redpfx Aeyx U Hijfpsr Main spindle Drive power: 29 kW Speed range: 0 – 5000 rpm Max. bar capacity: 65 mm Max. chuck size: 200 mm C-axis *resolution: 0.001° Sub spindle Drive power (100/40% ED): 17/22 kW Speed range: 0 – 7000 rpm Max. chuck size: 200 mm Travel (Z-axis): 750 mm C-axis *resolution: 0.001° Upper tool turret Disc turret with directional logic Number of stations: 12 of which driven: 12 Tool holder DIN 69880 VDI 30 Drive power: 6.7 kW Speed range: 0 – 4000 rpm Travel range * X-axis: 270 mm * Z-axis: 750 mm * Y-axis: +50 mm Lower tool turret Disc turret with directional logic Number of stations: 12 of which driven: 12 Tool holder DIN 69880 VDI 30 Drive power: 6.7 kW Speed range: 0 – 4000 rpm Travel range * X-axis: 205 mm * Z-axis: 750 mm EQUIPMENT/ACCESSORIES - Fully enclosed guard electrically interlocked, with sliding doors and machine light - IEMCA Master 890 MP bar loader (left side) for bar length 3300 mm, including: guide channel, centering unit, axial movement - Thermocompensation systems for integrated spindle motors (liquid cooled) - Hollow clamping cylinder with draw tube for main spindle - Solid clamping cylinder with draw bar for sub spindle - C-axes for main and sub spindle - Transmit software for easy C-axis programming - Y-axis on the upper turret (cutting force is distributed over 2 axes, resulting in extremely high rigidity) - Drive units in upper and lower turret - Parts ejector and flushing through the sub spindle - Finished parts pick-off device Maximum finished part: ø 65 x 200 mm Maximum finished part weight: 4.5 kg - Conveyor belt for removing finished parts from the machine - Turret steady rest including VDI 30 basic holder, controlled centrally via the coolant supply (14 bar), in the tool turret Clamping diameter range: 10 – 70 mm - Coolant system with 2 high-pressure pumps each at 14 bar and 2 rinsing pumps each at 3.7 bar - Cleaning gun for cleaning clamping devices, covers, and the entire working area with coolant - Swarf conveyor (hinge belt type) in extended version for gantry design, suitable for: long steel chips, chip nests, wool chips, dry and wet machining - Electronic oil mist separator 800 – 1000 m³/h - Automatic central oil lubrication for guideways and ball screws - Grease lubrication for main and sub spindle - Foot pedal for actuation of clamping devices - HAINBUCH collet chuck size 65 for main spindle, without stop (without collets) - HAINBUCH collet chuck size 65 for sub spindle, with stop type 100 (without collets) - 3-color signal lamp (red, green, white) - Serial interface - Mounting elements - Documentation

Condition: good (used), Year of construction: 2015, HAAS ST 30 SSY CNC Turning-Milling Center Year of manufacture: 2015 Control System: HAAS Machine No.: 3102813 Only approx. 9,950 operating hours (as of 25.03.26) Features: CNC turning-milling center with Y-axis Travel paths: max. 406 mm x 584 mm Swing diameter: 806 mm Y-axis travel: ±50.8 mm Vector drive (22.4 kW) 4,500 RPM A2-6 spindle 10-inch chuck (254 mm) Hybrid turret with 24 tool stations (12 VDI/12 BOT) Driven tools with higher torque and C-axis 15" LCD color display Memory lock key switch Spindle orientation USB port Synchronized tapping Automatic tool presetting system Hinged belt chip conveyor Rodpfx Ajyx Dwqefpsr Parts catcher Programmable hydraulic tailstock Ethernet interface "Visual Quick Code" programming system VectorCam Turning - HAAS Edition Special HAAS bar feeder Ø 76 mm Hainbuch collet chuck combo, Axial-pull, size 80 Chip guard for GR80 Vario Quick standard stop system, size 80 Scope of delivery includes: BOT/VDI holders / turret Turning tools Hainbuch collets Collets for tools Driven tools Hinged-door tool cabinet Machine mounting elements Chip trolley Operating manual/documentation Machine parameters on USB stick Features, technical data, manufacturer's brochure, and machine layout – see PDF. Illustration, content, and details are provided without guarantee and are therefore not binding. All other accessories visible in photos and videos are not included in the delivery scope and are therefore not part of this sale. The scope of delivery includes only the accessories expressly listed here, in the order confirmation, and the invoice. FCA (Free Carrier, loaded truck) D-32457 Porta Westfalica Packaging only Delivery time: immediately Subject to prior sale / Payment due immediately upon purchase

Condition: excellent (used), Year of construction: 2007, operating hours: 10,066 h, functionality: fully functional, CTX 410 V3 2-axis universal lathe with HEIDENHAIN Plus iT CNC control and SlimLinePanel - C-axis - Driven tools - AC main drive 21 kW, 240 Nm - Sauter disc turret - Partial hollow clamping device - Chip conveyor - Tailstock Turret disc with 12 tool stations, shank diameter 40 mm according to DIN 69880 instead of diameter 30 mm Bar machining package consisting of: Rsdpfeyx Ax Tex Afpsr - Hydraulic hollow clamping device Pull tube inner dia. max. 66 mm - Workpiece removal unit, pneumatically swiveling for parts Ø65 mm x 120 mm long, - 4-color signal light (Note: Additional connection for bar feeder or bar loading magazine required)

Condition: good (used), Year of construction: 2007, operating hours: 4,262 h, functionality: fully functional, machine/vehicle number: R7AV13, turning diameter: 65 mm, Can be powered up, the condition of the bar feeder is unknown, removed from production due to arrival of a new machine. On both turret heads, the use of a driven tool holder is possible in all positions. Redpfxoyxxhqj Afpjr

Condition: excellent (used), Year of construction: 1995, turning length: 710 mm, Specifications: Rsdpfsyxrczex Afper Control system: Siemens Maximum turning length: 710 mm Maximum turning diameter: 270 mm

Condition: used, Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Rsdpfx Asyxqniefper Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, TECHNICAL DETAILS: Manufacturer: DMG Gildemeister Model: NEF 400 Year of manufacture: 2009 Control system: Heidenhain Redpfx Ajyxqa Ejfper Power supply: 400 V / 50 Hz Connected load: approx. 21 kVA Current: 31 A Control voltage: 230 V / 24 V Cable specification: L ≤ 5 m, 230 V – 150 W Made in Europe

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, Time recording from Feb. 2025 Operating hours = 16085 h Main spindle = 616 h Milling spindle = 369 h Rsdpeyxp H Defx Afper CNC control Siemens Sinumerik Si 840D sl Max. center distance 4500 mm Working height 1375 mm X-axis travel -15 +725 mm Y-axis travel -245 + 4756 mm Swing diameter over cross slide 780 mm Swing diameter over bed 820 mm C-axis, smallest increment +/-0.001° Main spindle A15 with BVG; 3135 N;/2000 rpm Spindle head DIN 55026 Form A 15 Max. speed 3000 rpm Max. torque 3135 Nm Drilling/milling unit Milling power (40/100% duty cycle) 36.5/29.8 kW Torque up to 1110 rpm (40/100% duty cycle) 328/261 Nm Max. spindle speed 5000 rpm Swivel range (B-axis) -105 +95° Vertical travel (Y-axis) -250 +250 mm SR5 steady rest with eccentric fine adjustment 45–310 mm C8 tool system Tool magazine (2 magazines) 144 Tailstock Quad diameter MK6 180 mm Quad stroke 170 mm Quad force (adjustable) 5–28 kN Quad fine adjustment +/- 0.15 mm Optional equipment Coolant tank capacity 990 l Workpiece measurement MC (Reinshaw) Software Gear hobbing &more

Condition: used, Year of construction: 2012, operating hours: 20,000 h, machine/vehicle number: IntNr231536, High-end CNC turning centre with 2 turrets, 2 Y-axes and IRCO bar feeder Control: SIEMENS 840D SolutionLine with ShopTurn interface Year of manufacture: 2012 Spindle hours: 20,000 Rsdpfx Ajyxpz Iefpor Maximum turning diameter: approx. 390 mm Maximum turning length: 1,250 mm Bar capacity: 76 mm (standard) X-axis travel: 300 mm Z-axis travel: 1,250 mm Y-axis travel: +/- 60 mm (both turrets) Spindle specifications: Speed: up to 5,000 rpm Drive power: 34 kW (40% duty cycle) Torque: up to 380 Nm 4-axis kinematics 2 x 12-position turrets (all stations suitable for driven tools) Speed up to 6,000 rpm, power 11.3 kW Gear cutting software, including specialised tool holders for gear hobbing/cutting. IRCO MUK short bar loader Hinged belt chip conveyor 20 bar high-pressure coolant system with paper belt filter Subject to prior sale. Specifications subject to change and errors excepted!

Condition: used, Year of construction: 2017, Technical details: turning diameter: 356 mm turning length: 705 mm control: CELOS M730 UM MAPPS swing dia.: 742 mm standard turning diameter: 275 mm travel -x axis: 260 mm Redpfsyxpv Sex Afpor travel -y axis: 100 ( ±50) mm travel -z axis: 795 mm rapid travel - longitudinal/face: 30 / 30 m/min Rapid travel B-axis (parts transfer subspindle): 734 m/min Spindle 1 RPM: 4000 1/min Spindle 1 Power: 15/18,5/18,5 kW Spindle 1 Torque: 409/505 /599 Nm Spindle 1 max. bar diameter: 80 mm Spindle 2 RPM: 4500 1/min Spindle 2 power: 7,5/11 kW turret stations / rotary tool stations: 20 / 20 BMT40 speed of driven tools: 10000 1/min : 3.7/5,5/5,5 kW torque rotary tools: 14 / 24 Nm total power requirement: 38 kVA weight of the machine ca.: 6,3 t dimensions of the machine ca.: 4 (9) x 2,1 x 2,2 m Accerories Chip conveyor Barfeeder Interface Parts catcher Sp. 1 und Sp. 2 Parts and total counter Signal lamp 3 colors Spindle 1 Chuck Kitagawa B 210 (250 mm) Spindle 2 Chuck Kitagawa B 206 (160 mm) Conveyor for partsdisposal Automatic door Interface for coolant through the spindle Coolant through spindle 70 bar Knoll Program restart Tool presetter Spindle 1 & 2 Coolant shower 1m Barfeeder magazine IRCO High precision Turning and Milling Centre with Y-axis and sub spindle. Easy programming by CELOS-MAPPS 4 Control. Very low cutting hours. Machine is like new. All existing toolholders and life tool holders come with the machine. *

Condition: used, Year of construction: 2015, Technical details: turning diameter: 65 mm turning length: 120 mm control: Index C200-4D SL z-axis main spindle travel: 390 mm Rjdpfx Afoyxpadjpjr z-axis subspindle travel: 390 mm x-axis subspindle travel: 600 mm Travel Y1: ± 80 mm Travel y2: ± 80 mm x-axis rapids: 45 m/min y-axis rapids: 15 m/min z-axis rapid travel: 45 m/min Spindle 1 RPM: 5000 1/min Spindle 1 Power: 35,5/27,5 kW Spindle 1 Torque: 170 /125 Nm Spindle 2 RPM: 5000 1/min Spindle 2 power: 35,5/27,5 kW Spindle 2 torque: 170/125 Nm c-axis: 0,00014 ° bar material dia.: 65 mm spindle nose: AD 140 spindle bore: 85 mm Milling spindle 1 RPM: 18000 1/min Milling spindle 1 power: 11 kW Milling Spindle1 torque: 19 Nm Milling spindle 2 RPM: 18000 1/min Milling Spindle 2 power: 11 kW Milling spindle 2 torque: 19 Nm B-axes swivel angle: 230 ° B-axes torque: 440 Nm B-axes angle resolution: 0,001 ° Milling spindle 1 & 2 tool magazine: 80 HSK A40 Milling spindle 2 tool magazine static tools : 6 x VDI 25 internal coolant system feed: Knoll 80 bar / Ecofluid weight of the machine ca.: 16,3 t dimensions of the machine ca.: 3,73x2,92x2,58 m Accerories Chip conveyor Spindle 1 Chuck SMW HFKN 165-46 mm Spindle 2 Chuck SMW HFKN 165-46 mm Collet chuck main spindle Hainbuch Spanntop Collet chuck subspindle Hainbuch Spanntop Barfeeder Interface Unimag Short bar loader IRCO ILS RBK 10016 Parts catcher for main- and sub-spindle Conveyor for partsdisposal Air Filter Büchel High performance heavy duty turning and milling center with 2 multi axis milling heads and two spindles. Both milling heads are full 5-axis. The z-axes are installed in the spindle heads The x2 axis is installed in the spindle head of the subspindle Milling1 head has x/y/b -axes Milling head 2 has y/b-axes Both milling heads have B-(Swivel-)axis 230° The machine is equipped with an IRCO short barfeeder and parts gripper for finished parts. Max. dim for finished parts: Ø 65 mm, length 120 mm, weight 5 kg. Rest piece length 200 mm All linear- axes are equipped with linear scales. Coolant through main and subspindle. Tool breakage control from drill Ø 1mm All existing tool from machine are part of delivery Machine is in excellenten Condition! *

Condition: used, Year of construction: 2009, operating hours: 42,497 h, functionality: fully functional, machine/vehicle number: L2203458, turning diameter: 510 mm, spindle motor power: 11,000 W, spindle speed (max.): 6,000 rpm, travel distance X-axis: 175 mm, travel distance Z-axis: 330 mm, bar diameter (max.): 32 mm, overall weight: 3,500 kg, Machine type: CNC lathe Manufacturer: Doosan Model: Lynx 220A Year of manufacture: 02/2009 Redpjyxn D Iofx Afpsr Operating hours: 42,497h (power-on hours, as of 17.12.2025) Max. turning diameter: 510 mm X-axis travel: 175 mm Z-axis travel: 330 mm Spindle speed: 6,000 rpm Spindle power: 11 kW Tool changer: 12 positions Bar feeder: Ø8-32 mm Weight: 3,500 kg Transport, collection, and dismantling must be organized by the buyer.

Condition: good (used), Year of construction: 2006, operating hours: 14,119 h, functionality: fully functional, machine/vehicle number: 6682NL151EG0306J, turning diameter: 260 mm, spindle speed (max.): 6,000 rpm, total height: 2,000 mm, total length: 2,185 mm, total width: 2,460 mm, bar diameter (max.): 45 mm, overall weight: 5,300 kg, Machine type: CNC lathe Manufacturer: DMG Mori Model: NL1500/500 Year of manufacture: 2006 Operating hours: 14,119h (as of 17.12.2025) Control: MSX-850 BM Rsdpfxoyxnu Ho Afpor Spindle speed: 6,000 rpm Machining diameter: with bar loader Ø16-45mm Tool stations: 12 plus tailstock Weight: 5,300kg Dimensions (W×D×H): 2460×2000×2185mm Transport, collection, and dismantling must be organized by the buyer.

Condition: ready for operation (used), Year of construction: 2000, operating hours: 21,269 h, functionality: fully functional, machine/vehicle number: 0082, turning length: 1,500 mm, turning diameter: 580 mm, travel distance X-axis: 598 mm, travel distance Y-axis: 230 mm, travel distance Z-axis: 1,660 mm, TECHNICAL DETAILS Travel X-axis: 598 mm Travel Y-axis: 230 mm Travel Z-axis: 1,660 mm Max. turning diameter: 580 mm Turning length: 1,500 mm Swing diameter over bed: 610 mm Swing diameter over cross slide: 580 mm Main Spindle Main spindle speed range: 12 - 2,800 rpm Spindle bearing diameter: 150 mm Spindle bore: 110 mm Spindle nose: JIS A2-11 Main spindle drive power: 37 (30) kW C-axis accuracy: 0.001° Rapid traverse X/Y: 12,000 mm/min Rapid traverse Z: 20,000 mm/min Rapid traverse C: 100 rpm Cutting feed rate: 0.001 - 1,000 mm/rev Tool Turret Type: H2 ATC Number of tool stations: 2 (1x L-Tool / 1x M-Tool) positions Driven stations: stepless Speed range - driven tool stations: 40 - 3,000 rpm Tool shank height: 25 mm Boring bar holder diameter: 50 mm Tailstock Quill diameter: 120 mm Quill stroke: 170 mm Tailstock taper: MT 5 Tool Magazine Number of tool stations: 50 positions Tool holder: MAS BT 50 Max. tool diameter: 170 mm Max. tool length: 350 mm Max. tool weight: 20 kg Magazine drive: 3.2 kW MACHINE DETAILS Total power requirement: 53 kVA Dimensions & Weight Space requirement: 6.0 x 3.2 x 3.0 m Machine weight: 18.5 t Operating Hours Main switch on-hours: 79,607 h NC operating hours: 27,814 h Main spindle hours: 21,269 h EQUIPMENT Chip conveyor Central coolant system High-pressure coolant system, 20 bar Tailstock Signal lamp C-axis Y-axis Redpeyxmyuefx Afper Hydraulic unit Steady rest Various tool holders (44 pcs.) Three-jaw chuck Schunk - ROTA NC 400-120 Electronic handwheel

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, spindle speed (max.): 7,000 rpm, spindle bore: 42 mm, controller model: Siemens 840 D - SL, counter spindle speed (max.): 7,000 rpm, Equipment: chip conveyor, TECHNICAL DETAILS Bar diameter: 42 mm Travel X-axis 1/2/3: 180 mm Travel Y-axis 1/3: ±45 mm Travel Z-axis 1/2/3: 704 / 620 / 704 mm Rsdeyxmnxopfx Afper Main spindle Speed: 7,000 rpm Drive power: 22 kW / 16.5 kW Spindle torque: 128 Nm / 100 Nm Spindle bore: 42 mm C-axis: 0.001° Spindle nose: 110 mm Counter spindle Speed: 7,000 rpm Drive power: 19 kW / 16.5 kW Spindle torque: 128 Nm / 100 Nm Spindle bore: 42 mm C-axis: 0.001° Spindle nose: 110 mm Tool turret Number of turrets: 2 + 1 pos Number of tool stations: 3 x 12 pos Number of live tool stations: 3 x 12 pos Rotational speed of driven tools: 8,000 rpm Power: 11.4 kW / 2.3 kW Torque: 26 Nm / 14 Nm Tool holder: VDI 25 Rapid traverse (X / Y / Z): 30 m/min Acceleration: 0.5 g MACHINE DETAILS Control: Siemens 840 D - SL Total power requirement: 60 kW Dimensions & Weight Space requirement: approx. 8.2 x 3.3 x 2.5 m Machine weight: approx. 7.5 t EQUIPMENT Documentation Knoll chip conveyor High-pressure coolant (14 bar) Parts catcher Counter spindle Interface for bar feeder Spinner Barload BL 0146 bar loading magazine C-axis: 2x 0.001° Hydraulic unit Hainbuch collet chuck Y-axis: 2x ±45 mm Various tool holders Various collets Tool measuring arm
