Condition: good (used), travel distance X-axis: 8,550 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 3,300 mm, travel distance W-axis: 900 mm, WOTAN B 130 K MOVING COLUMN BORING MILL - X-axis travel: 8,550 mm - Z-axis travel: 3,300 mm - Y-axis travel: 500 mm - W-axis travel: 900 mm - Head power: 30 HP Blsdoyngd Ropfx Ah Ijd - Fagor DRO on 3 axes - Includes complete documentation/mechanical and electrical diagrams - Table not included, machine only

Condition: excellent (used), Year of construction: 2016, travel distance X-axis: 8,000 mm, travel distance Y-axis: 4,000 mm, travel distance Z-axis: 1,000 mm, table length: 8,000 mm, table width: 4,000 mm, Heidenhain 530 Blodpfxjyl Tphs Ah Ied

Condition: used, Year of construction: 1997, functionality: fully functional, travel distance X-axis: 13,000 mm, travel distance Y-axis: 5,000 mm, travel distance Z-axis: 1,000 mm, travel distance W-axis: 1,200 mm, MAKE: PAMA MODEL: SPEEDRAM 4 CATEGORY: Floor type CNC boring machine YEAR OF MANUFACTURE: 1997 CNC CONTROL: Siemens Sinumerik 840C Spindle Spindle taper: ISO 50 Spindle diameter: Ø 160 mm Spindle speed range: 2 ÷ 1,600 rpm Spindle motor power: 100 kW Coolant through spindle (CTS) Work Capacity X axis (column longitudinal travel): 13,000 mm Y axis (head vertical travel): 5,000 mm Z axis (head cross travel / RAM): 1,000 mm W axis (quill travel): 1,200 mm Bjdpfx Ahsyari As Iold V axis (table cross travel): 3,000 mm RAM section dimensions: 440 x 500 mm Machine equipped with Heidenhain linear scales on all axes Table & Floor Plates Rotary table dimensions: 4,000 x 4,000 mm Rotary table load capacity: 80 t Continuous rotary table positioning: 360,000 positions, minimum indexing angle 0.001° Number of floor plates: 2 Each floor plate size: 6,000 x 2,500 mm Total floor plate dimensions: 6,000 x 2,500 mm Accessories Chip conveyor Coolant tank with high-pressure pump for through-spindle coolant (CTS) 1 x 90° milling head, indexing 2.5° (C axis) Spindle oil chiller and hydraulic unit Manuals and electrical diagrams

Condition: used, Year of construction: 1995, travel distance X-axis: 10,000 mm, travel distance Y-axis: 2,600 mm, travel distance Z-axis: 600 mm, spindle speed (max.): 1,950 rpm, feed length W-axis: 700 mm, quill diameter: 140 mm, cnc SELCA 3045 X AXIS STROKE 10000 MM Y AXIS STROKE 2600 MM Z AXIS RAM STROKE 600 MM W AXIS QUILL STROKE 700 MM SPINDLE DIAMETER 140 SPINDLE CONNECTION ISO 50 Bedpfx Ahewnqnue Isld SPINDLE MOTOR POWER 53 KW ROTATION SPEED 6 - 1950 MM ROTARY TABLE TABLE 2000 X 1600 MM CAPACITY 10 TON STROKE AXIS V 2100 MM AUTOMATIC BI-ROTATIVE HEAD UNIVERSAL TUAR 25 PICK UP HEADS INTERNAL AND EXTERNAL COOLANT 60-Place TOOL CHANGE CHIP CONVEYOR ANCHORING PLANE 2500 X 6000 MM HYDROSTATIC X-AXIS RAM WITH HYDROSTATIC GUIDE ON 4 SIDES

Condition: used, Technical details: spindle diameter: 150 mm x-travel: 10000 mm y-travel: 2500 mm bore spindle stroke: 700 mm ram stroke: 700 dimension of the ram: 340 x 340 mm Bjdpfx Ahewg R Swe Ijld spindle taper ISO: 50 Speed of boring spindles: 1,25 - 1250 U/min. feed speeds infinitely variable: 1 - 5000 mm/min rapid traverse: 5 m/min total power requirement: 120 kW weight of the machine ca.: 115 t dimensions of the machine ca.: 15,1 x 10 x 6,4 m with CNC SIEMENS 840 Dsl complete retrofit in 2010 FIBRO CNC rotary table 2500 x 2500 mm, 50 to. loading capacity, longitudinal movement 2500 mm, angular milling head 4 x 90° universal milling head floor plate area ca. 12000 x 6000 mm ( 72 m²) chip conveyor and coolant attachment aerostatic guideways *

Condition: good (used), Year of construction: 2003, travel distance X-axis: 14,000 mm, travel distance Y-axis: 4,000 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 2,500 rpm, feed length W-axis: 900 mm, spindle diameter: 152 mm, FPT MAR-X 3, 2003 CNC SELCA 4045 PLUS DIGITAL, Built 2003, CNC can be changed to Heidenhein 620. FPT TRT25. Rotary Table, 25 Ton. Two axis Head, 144 x 144. X, Column travel 14.000 mm Bledpfx Ahjwdm A He Ijd Y, Headstock vertical travel 4.000 mm Z, Ram stroke 1.500 mm W, Spindle Ø 152,4 mm 900 mm Spindle taper ISO 50 Spindle speed 0 - 2.500 rpm Spindle motor 48 kW Automatic tool changer 40 Tools FPT TRT25. Rotary Table, 360.000° 2.500 x 2.500 mm Rotary Table longitudinal travel 2.000 mm Table load 25 Ton

Condition: used, Year of construction: 2005, X AXIS TRAVEL: 10000 MM Y AXIS TRAVEL: 4000 MM Z AXIS TRAVEL (RAM): 1000 MM W AXIS TRAVEL (SPINDLE): 800 MM TOTAL Z + W AXIS TRAVEL: 1800 MM SPINDLE DIAMETER 160 MM SPINDLE MOTOR POWER 40 KW SPINDLE RPM: 3000 RPM SPINDLE TAPER ISO 50 DIN 69871/1A NR 02 SPEED RANGE RAM DIMENSIONS: 460 X 520 MM RAPID FEEDING 20000 MM/MIN ROTARY TRANSLATION TABLE MODEL MG 50 OF 2500 x 3500 mm , load 50 ton , 360000 position 0,001° stroke 2000 mm HEIDENHAIN iTNC 530 CNC TOOL CHANGER 40 PLACES MANUAL UNIVERSAL HEAD ANCHOR PLATE 6000 X 2000 X 300 MM Bodoup Dclepfx Ah Isld EXTERNAL REFRIGERATION TOTAL INSTALLED POWER 110 KVA YEAR : 2005

Condition: good (used), Year of construction: 1979, functionality: fully functional, machine/vehicle number: 332046, travel distance X-axis: 8,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 2,200 mm, spindle speed (max.): 850 rpm, spindle speed (min.): 6 rpm, feed rate X-axis: 8 m/min, feed rate Y-axis: 6 m/min, feed rate Z-axis: 1 m/min, total width: 10,000 mm, total length: 14,000 mm, total height: 4,500 mm, spindle diameter: 160 mm, table load: 40,000 kg, table length: 3,000 mm, table width: 3,000 mm, workpiece weight (max.): 40,000 kg, overall weight: 71,000 kg, drill spindle length: 1,200 mm, year of last overhaul: 2002, power: 60 kW (81.58 HP), The machine is dismantled on stock, it is fully functionable. Blodpfx Ahouplpte Ijd
