Condition: reconditioned (used), STUDER S 20-12 is a cylindrical grinder engineered for precision, high accuracy and reliable performance. Capacities: centre height 100 mm, distance between centres 400 mm; wheel Ø300×30 mm, bore 127 mm; work-spindle 20°, table tilt 30°. Specs: work-spindle speeds 60–1200 rpm (stepless); wheel speed up to 45,000 rpm; table feed 100–3500 mm/min; wheel motor 4.5 CV; 3×380 V; weight ≈1900 kg; dims 1500×1400×1600 mm. Key accessories: swivelling internal grinding unit, dressing devices, 120 mm magnetic chuck. Achieves tight tolerances; typical sectors: automotive, aerospace, toolmaking, medical, watchmaking Ksdpfxsxx U T Ho Aayodw

Condition: used, Year of construction: 2019, controller manufacturer: Sonstige, controller model: MAPPS IVB, _____ Description: Year of manuf. : 2019 Control : Sonstige MAPPS IVB Grinding length : 150 mm Technical Details: Grinding-ø (max.):350 mm Grindinglength (max.):150 mm Grindingwheel-ø:25-180 mm Swivelrange Grindingwheelhead (max.):230° Grindingspindle: Technology:Internalgrinding spindle Speedrange:3-20.000 rpm Power (max.):11 kW Grindingwheelholder:HSK-A63 Drillingspindle: Technologie:Drillingspindle Speedrange:1.500-3.500 rpm Power (max.):7,5 kW Taper:HSK-A63 Kdsdpfx Aajxx Eraeyew Workpiecespindle: Technology:Directdrive Clmapingsurface:ø265 mm Tableloadiing (max.):200 kg Workpiececlamping:Pneumatic chuck In general: Movement in X/Z:965/532 mm Rapid travers in X/Z:24/20 m/min Equipment/Accessory: Positionsensor:Direct Scales in X/Z Chipmanagement:Magneticbeltconveyor Coolingmanagement:Coolant unit with Paperbeltfilter and Temperature control Workpiecemeasurement:Touch probe, Renishaw MP 250 with Master Gauge Station Toolmagazine:8 Stations (each 4 stations for Grinding- and Drillingtools) Dresser:Wheeldresser + Single point diamond (Marposs) Setup operations:Electronic handwheel Automation:Fanuc-Robot M-20iA with Stocker (30 Stations ø329 mm) Grindingmistseparation:Akamatsu HVS-100-CE 044 Further Equipment:Spindle chiller, Trafo

Condition: good (used), Year of construction: 1970, functionality: fully functional, Data : Kedpfx Asxw Etnjayedw Tip width 300 mm Tip height 150 mm External grinding spindle 4.0 kW Grinding wheel max. 400 x 80 x 127 mm Spindle cone MK4 Workpiece headstock 0.55 kW Workpiece speeds 30 - 450 rpm Internal grinding spindle 1.5 kW

Condition: reconditioned (used), Year of construction: 1979, functionality: fully functional, Fully rebuilt Danobat grinding machine. Disassembled, adjusted, painted, and operational. Includes various accessories. Video available for interested parties. Kjdpsxwln Ssfx Aaysdw

Condition: excellent (used), Myford cylindrical grinding machine Max. grinding lenght : 305 mm. Max. grinding dia. : 76 mm. RPM : 2500 With internal grinding Coolant Delivery : 1. December 2025 Kedpfx Aaexwd Nzsyodw

Condition: used, Year of construction: 1998, centre height 125 mm centre distance 400 mm Control FANUC 21i Capstan diameter max. 406 mm wheel dimensions 406 x 127 x 40 mm workpiece weight 30 kg longitudinal slide -travel 483 mm cross slide - travel 254 mm total power requirement max. 20 kVA weight of the machine ca. 4,0 t dimensions of the machine ca. 3,0 x 2,0 x 2,1 m including 2 Pcs. internal grinding spindle incl. B axis 1° Hirt, controlled incl. C-axis incl. Quick-Set Probe including Sensitron Kedpfx Aasxwdwfjyodw including Magnetic Jaw including hydraulically foldable dresser including other small accessories including documentation without a coolant system, as it was previously connected to a central unit Power On hours approx. 71,000 h Spindle hours approx. 25,900 h

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 2352, center height: 200 mm, grinding length: 500 mm, grinding diameter: 55 mm, rotational speed (max.): 5,970 rpm, controller model: Siemens Sinumerik 840-D, TECHNICAL DETAILS Grinding diameter: 5–55 mm Grinding length: 500 mm Workpiece diameter: 5–55 mm Workpiece length: max. 500 mm Grinding wheel arrangement: right, 30° inclined Grinding wheel dimensions: 600 x 30 x 203.2 mm Drive power: 7 kW X/Z-axis drive: ball screw Travel speed: 0.01 – 10,000 mm/min Resolution: 1 µm Workpiece spindle runout: < 1 µm Spindle speed max.: 5,970 rpm Workpiece changing system: Fanuc robot Control system: Siemens Sinumerik 840-D MACHINE DETAILS Total power requirement: 44 kW Centre height: 200 mm Machine weight: 7,000 kg EQUIPMENT Kdsdpsxvxl Ijfx Aayew Tailstock Longitudinal adjustment: manual Rotating centre: Junker standard, diameter 75 mm Clamping pressure: adjustable via hydraulic system Tailstock dimensions: diameter 100 mm × 430 mm

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, center height: 200 mm, workpiece weight (max.): 30 kg, grinding length: 400 mm, grinding wheel diameter: 350 mm, total width: 2,600 mm, total length: 1,800 mm, grinding diameter: 100 mm, workpiece weight between centers: 30,000 g, distance between centers: 400 mm, type of input current: AC, spindle speed (max.): 1,000 rpm, spindle speed (min.): 90 rpm, grinding spindle motor power: 3,700 W, grinding spindle speed: 2,000 rpm, overall weight: 2,000 kg, pivoting range: 30 °, input voltage: 400 V, Equipment: rotational speed infinitely variable, General Diameter over table: 200 mm Distance between centers (ABC): 400 mm Grinding length: 400 mm Grinding diameter (max. / min. OD): 100 / 6 mm Grinding diameter (max. / min. ID): 85 / 6 mm Max. weight between centers: 30 kg Max. weight incl. chuck: 10 kg Grinding Spindle Wheel size: 350 x 127 x 50 mm Minimum usable wheel diameter: 300 mm Spindle speed: 1800 – 2000 rpm Spindle motor power: 3.7 kW (Circumferential) speed: 33 m/sec Rapid traverse: 40 mm Rapid traverse with handwheel: 20 mm Max. automatic infeed on diameter: 1.7 [3.4] mm Minimum diameter increment: 0.001 mm Infeed speed on diameter (coarse/fine): 0.015 – 6 / 0.015 – 3 mm/min TABLE Table speed: 0.1 – 5 m/min Table stroke: 450 mm Minimum travel: 2 mm Maximum table swiveling: -2º to +30º Work Spindle Taper bore: MT-4 Spindle speed: 90–1000 rpm Spindle motor power (2 steps): 0.28 / 0.37 kW TAILSTOCK Morse taper: MT-3 Quill stroke: 25 mm Quill offset range (optional): [±0.03] HYDRAULIC UNIT Tank capacity: 40 l INTERNAL GRINDING ATTACHMENT Kdedpfx Asxvr Hfsaysw Spindle size (diameter x length (max. rpm)): 60 x 250 mm (18,000 rpm) Spindle housing bore: 60 mm Motor power: 1.5 kW GENERAL Operating voltage: 415 Volt Alternating current, 3-phase Total power requirement: 6.5 [8.5] kW Footprint including standard coolant tank (LxW): 2600 x 1800 mm Machine weight: 2000 kg

Condition: ready for operation (used), Year of construction: 2021, operating hours: 5,073 h, functionality: fully functional, machine/vehicle number: 80171, grinding diameter: 500 mm, overall weight: 10,000 kg, controller model: FANUC SERIES OI-TF, Equipment: bar feeder, No reserve price – guaranteed sale to the highest bidder! Payment for the machine is due by 04/12/2025! Placing a bid obligates you to collect the item within the specified period between 10/12/2025 and 12/12/2025! The machine can be inspected on 25/11/2025! TECHNICAL DETAILS Grinding diameter: 500 mm Lining width: max. 32 mm Cut-off wheel permitted diameter: max. 520 mm Cut-off wheel lining width: max. 3 mm Cut-off wheel lining height: max. 5 mm Kdodpfx Aexvbufeaysw MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 8,500 x 3,500 x 2,900 mm Total weight: 10,000 kg Control model: FANUC SERIES OI-TF Operating hours Machining hours: 5,073 h Run time: 12,219 h Control power-on hours: 32,335 h EQUIPMENT FMB Minimag 20 bar feeder Extraction system Various documentation

Condition: ready for operation (used), Year of construction: 2016, operating hours: 8,834 h, functionality: fully functional, machine/vehicle number: 80042, grinding wheel diameter: 500 mm, overall weight: 10,000 kg, controller model: FANUC SERIES OI-TD, No minimum price – guaranteed sale to the highest bidder! The payment deadline for the machine is 04/12/2025! Placing a bid obligates timely collection between 10/12/2025 and 12/12/2025! The machine can be inspected on 25/11/2025! TECHNICAL DETAILS Grinding Wheel Grinding wheel diameter: 500 mm Grinding wheel width: max. 32 mm Cut-off Wheel Permitted diameter: max. 520 mm Wheel width: max. 3 mm Wheel height: max. 5 mm Workpiece Mounting Left workpiece spindle head Chuck type: Hydraulic clamping Right workpiece spindle head Chuck type: Hydraulic clamping MACHINE DETAILS Control model: FANUC SERIES OI-TD Electrical Data Operating voltage: 400 V Frequency: 50 Hz Control voltage: 24 V Rated current: 3 x 125 A Dimensions & Weight Dimensions (L x W x H): 8,500 x 3,500 x 2,900 mm Total weight: 10,000 kg Operating Hours Machining hours: 8,834 h Runtime: 20,892 h Kdjdpexvbn Ejfx Aayow Control on-hours: 43,292 h EQUIPMENT Bar feeder FMB

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: VECTOR078, total width: 3,000 mm, total length: 5,000 mm, total height: 2,500 mm, overall weight: 10,000 kg, No minimum price – guaranteed sale to the highest bidder! The payment deadline for the machine is 04/12/2025. Placing a bid obligates you to timely collection between 10/12/2025 and 12/12/2025! The machine can be inspected on 25/11/2025! MACHINE DETAILS Electrical Data Operating voltage: 400 V Frequency: 50 Hz Rated current: 32 A Dimensions & Weight Dimensions (L x W x H): 5,000 x 3,000 x 2,500 mm Total weight: 10,000 kg EQUIPMENT Component placement system Coolant unit Kdedsxvbhrepfx Aayjw

Condition: good (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: 004-040.0004, CNC Cylindrical Grinding Machine Manufacturer: STUDER Model: S22 CNC Year of manufacture: 2009 Machine / Workpiece Data Distance between centers: approx. 650 mm Center height: 175 mm Maximum workpiece weight: 150 kg Kodjxtpnzepfx Aaysdw Maximum grinding length: approx. 800 mm Linear Axes / Guides X-axis (cross slide): Maximum travel approx. 310 mm X-axis feed rate up to approx. 15,000 mm/min (depending on configuration) Z-axis (longitudinal slide): Maximum travel approx. 850 mm Z-axis feed rate up to approx. 30,000 mm/min Grinding Spindle / Grinding Wheel Main spindle power, e.g. 12.5 kW in the standard version Standard grinding wheel diameter e.g. Ø 500 × 80 × 203 mm, circumferential speed up to approx. 50 m/s Optional high-speed grinding (HSG): e.g. grinding wheel Ø 400 x 40 x 127 mm, circumferential speed up to approx. 140 m/s Control / Software / Equipment Control, standard: e.g. FANUC 31i-A (PC integrated) with StuderWIN operator interface Guideways: Machine bed made from Granitan® S103 (mineral cast) for thermal stability and damping Dimensions / Electrical Data Machine weight approx. 8,500 kg Power supply, typically 400 V / 50 Hz (country-specific)

Condition: good (used), Internal item no.: 25087 Cylindrical grinding machine Schaudt Kdodjxtpbbspfx Aayow AR 500 + Magnetic chuck D160mm + Internal grinding attachment! Grinding length: max. 500mm Grinding diameter: max. 300mm Centre height: 150mm Centre distance: 500mm Tailstock taper: MK4 Machine dimensions (LxWxH): 2700 x 2000 x 1800mm Weight: approx. 2000kg

Condition: used, Cylindrical Grinding Machine TSCHUDIN type HTG 400 Between points: 400 mm Centre height: 100 mm Cone: CM4 Spindle speed: from 70 to 500 RPM Max table travel: 420 mm Table orientation at 15° Kedpfextmv Nox Aayjdw Grinding wheel: Ø 300 mm Retractable tailstock CM3 Machine rebuilt by REWITECH SA (Switzerland) in 1995 Equipped with one settling tank PHILIPS Voltage: 380 V Dimensions (L x W x H): 2000 x 1400 x 1600 mm Weight: approx 1,5 T

Condition: not inspected (used), functionality: unexamined, machine/vehicle number: 70292, grinding length: 500 mm, grinding wheel diameter: 400 mm, grinding diameter: 200 mm, workpiece weight between centers: 15,000 g, bar passage: 270 mm, No reserve price – guaranteed sale to the highest bidder! The machine is being auctioned due to a business closure. Placing a bid obligates you to collect the machine within the specified period from 26.01.2026 to 29.01.2026! Ksdpfx Asxqgb Teayodw TECHNICAL DETAILS Grinding wheel diameter: 400 mm Maximum workpiece passage: 270 mm Maximum grinding diameter: 200 mm Grinding length between centers: 300 – 500 mm Maximum workpiece weight between centers: 15 kg MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 4,000 x 2,000 x 2,000 mm Weight: 2,000 kg EQUIPMENT HEIDENHAIN digital readout Matching workbench with contents Suitable grinding wheels Arbors Suitable spare parts

Condition: ready for operation (used), functionality: fully functional, TECHNICAL DETAILS - Distance between centers: 1000 [mm] - Centers height: 125 [mm] - Table swivel: -/+ 8 [°] - Universal wheelhead - Grinding wheel dimensions: 400 x 50 x 127 [mm] - Motor power: 3 [kW] - Spindle speed: 1500 / 1700 / 2200 Kdedpfx Asxphcijayjw - Grinding wheel holder orientation: 270 [°] (3 x 90°) Headstock - Bore for internal spindle: 90 [mm] - Part holder headstock orientation: 180 [°] - Spindle speed: 20 - 400 [Rpm] - Spindle internal taper: Morse 5 - Motor power: 0.9 [kW] - Tailstock inner taper: Morse 4 - Tailstock sleeve travel: 30 [mm] - Dimensions: 2860 x 1680 x 1670 [mm] - Weight: 2,500 [kg]

Condition: as good as new (ex-display), Year of construction: 2020, operating hours: 200 h, functionality: fully functional, workpiece weight (max.): 150 kg, grinding length: 500 mm, grinding wheel diameter: 455 mm, grinding diameter: 300 mm, workpiece weight between centers: 150,000 g, type of input current: three-phase, workpiece diameter between centers: 500 mm, grinding wheel width: 75 mm, spindle speed (max.): 500 rpm, spindle speed (min.): 10 rpm, grinding spindle motor power: 7,500 W, overall weight: 4,600 kg, Demonstration CNC cylindrical grinding machine with automation setup Brand OKAMOTO Model OGM-350 P NCIII Year of manufacture 2020 Control: Fanuc Oi Model D Operating hours: approx. 200 hours Technical specifications Maximum swing diameter: 320 mm Maximum distance between centers: 500 mm Maximum workpiece diameter to be ground: 300 mm Maximum workpiece weight between centers: 150 kg Maximum workpiece weight: flange + chuck + workpiece: 40 kg Grinding wheel: Diameter x width x bore: 455 x 75 x 127 mm Wheel speed: Continuously variable Circumferential speed: 45 m/sec Grinding headstock (x-axis) Maximum travel: 300 Swivel angle: Non-swivel Workpiece table (z-axis) Travel: 870 mm Swivel angle: 0 – 10° Workhead Fixed/Live Center Design MK 4 Taper Chuck Spindle Bore Diameter 20 mm Spindle Speed ​​10 – 500 rpm Swivel Angle: Non-Swivel Tailstock Tailstock Type: Manual Fine Taper Adjustment Quill Travel 30 mm MK 4 Taper Chuck Drive Power Grinding Wheel Drive 5.5 kW Total Power 20 kVA Dimensions/Weight Length x Width x Height approx. 3400 x 2330 x 1950 mm Machine Weight approx. 4,600 kg Standard Equipment: 2 Carbide Centers Full FANUC Keyboard with Radius Compensation for Creating ISO Programs Workshop Programming: Graphic Software for Grinding and Dressing Cycles with Teach-in Function GAP Eliminator Shoulder Positioning Constant Table coolant flush 3 color LED lamp Documentation Leveling screws and support plates Operating tool set Accessories Automation preparation Automatic door Automation interface Grinding wheel guard fully open when door is open Miscellaneous Signal lamp Kodpfx Aoxnvpnsayodw Tailstock with electric quill retraction 1 flange 1 grinding wheel Options upon request: Paper belt filter on request Clamping devices on request Commissioning and training on request (Commissioning by Okamoto is required for warranty purposes) Transport on request

Condition: refurbished (used), Year of construction: 1987, operating hours: 200 h, functionality: fully functional, Please make your inquiry by email. Ksdpfx Aaoxmiqceyedw

Condition: used, Year of construction: 1991, operating hours: 2,000 h, Name: Used injection molding machine Manufacturer: Ferromatik Milacron (Klöcker) Type: FX50 R 35 Year built: 1991 Hours of operation: 2000 h Ksdpoxl R Sxsfx Aayedw Driving force: 15 kW Dimensions: L 4300 x W 1400 x H 2200 mm Empty weight: 3400 kg Technical doc.: Yes Message: General Data: Dry cycle rate: 40 min, Pump drive: 15 kW, Total connected load: 25.7, Oil tank capacity: 180 L Injection unit: Screw diameter: 35 mm, Injection pressure: 1730 bar, Displacement: 116 cm3, Screw stroke: 120 mm, Maximum part weight: 99 g, Maximum injection flow: 505 g/s, Calculated injection capacity: 15 kW, Plasticizing flow: 29 g/s, Screw length: 22 LID, Maximum screw speed: 430 min, Maximum screw torque: 360 Nm, Installed heating capacity: 10.7 kW, Number of heating zones: 5, Nozzle compression force: 65 kN Clamping unit: Clamping force: 500 kN, Mold opening stroke: 350 mm, tool installation height min.: 200 mm, platen distance max.: 550 mm, ejector force: 34 kN, ejector stroke: 150 mm, clear distance between columns max.: 355×355 mm, clamping plate max.: 540×540 mm. Accessories: With two tool tempering devices. Condition: Second hand Price: By request

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, center height: 225 mm, controller model: Fanuc 16T, TECHNICAL DETAILS Centre height: 225 mm Ksdpfxoxlix Do Aayjdw MACHINE DETAILS Control: Fanuc 16T

Condition: excellent (used), functionality: fully functional, machine/vehicle number: 64122, A well-maintained external cylindrical grinding machine Make: STUDER Type: S20-12 Machine No.: 64122 Kjdpfxoxfvxds Aaysdw

Condition: good (used), Year of construction: 2002, operating hours: 9,999 h, functionality: fully functional, machine/vehicle number: 120231, Cylindrical Grinding Machine SCHAUDT / Mikrosa PS 51 N 600 Technical Data – Schaudt / Mikrosa PS 51 N 600 Machine type: Universal / External Cylindrical Grinding Machine Year of manufacture: 2002 Control: Siemens 840D Grinding length (between centers): 600 mm Center height / Height over bed: 180 mm Maximum grinding diameter over bed: approx. 300–360 mm Kedoxdb R Njpfx Aayedw Max. workpiece weight (between centers): approx. 150–200 kg, depending on configuration Grinding spindle power: approx. 22 kW Grinding wheel width: e.g., 220 mm on premium versions; diameter depending on equipment approx. 400–500 mm Grinding wheel speed / surface speed: On some versions approx. 45 m/s; variable depending on equipment Total weight: approx. 10 t

Condition: refurbished (used), Year of construction: 2017, functionality: fully functional, External Cylindrical Grinding Machine Manufacturer: NAXOS-UNION (Germany) Ksdpfexcvr Sox Aayedw Model: W500 500 x 2500 mm Year of Overhaul: 2017 Technical Specifications: • Max. distance between centres: 2500 mm (full length can be ground) • Centre height: 250 mm • Grinding wheel diameter: 600 mm • Grinding support travel: 320 mm • Max. workpiece weight between centres: 1500 kg • Grinding spindle speed, stepless: 900 – 1600 RPM • Workpiece spindle speed: 50 – 450 RPM • Workpiece spindle taper: MK5 / Morse 5 • Motor power: 2.2 kW • Approx. machine dimensions (L x W x H): 7800 x 3300 x 1750 mm • Approx. weight: 13 tonnes Accessories included: • 1x full machine enclosure incl. front sliding door with safety switch • 2x glass scales for X and Z axes incl. digital display Z300 from RSF-Elektrik, measuring system MSA • 1x new belt filter unit by SEITZ, type PFA 100, incl. 100 l/min pump and control system • 1x electromechanical balancing system by MPM, balancing head mounted on spindle, sensor at grinding spindle bearing • 1x live centre, manufacturer RÖHM MK5 • 6x grinding wheel flanges • 7x steady rests • 14x leveling feet Condition: Completely overhauled in 2017, very little use since. Negotiation basis: Price: ex works, loaded free on truck Collection after payment received and by prior appointment. Disclaimer: The seller shall not be liable for typographical or data transmission errors. Machine condition in terms of appearance, technology and wear corresponds to its age; used equipment is sold without any warranty. All prices are net.

Condition: good (used), grinding diameter 450 mm grinding length 600 mm centre height 140 mm workpiece dia. 280 mm number of turns of spindle head 63 - 400 U/min grinding wheel speeds 20-35 m/s dimensions of the machine ca. 2,4 x 1,9 x 2,1 m Ksdpfx Aaexcblqoyjdw

Condition: used, Cylindrical grinder SCHAUDT RFH500 Kdedpjxbt Hkefx Aaysw
