Condition: ready for operation (used), Year of construction: 1991, pressure 25 t stroke 7 - 62 mm no. of strokes 120-600 Hub/min Gbodpfx Afoxiy Abopeu total power requirement 4 kW weight of the machine ca. 2,5 t

Condition: excellent (used), Year of construction: 2020, operating hours: 20,000 h, functionality: fully functional, machine/vehicle number: KDH 1600, total height: 4,200 mm, feed length X-axis: 300 mm, ram adjustment: 120 mm, installation height: 751 mm, table height: 200 mm, total width: 2,200 mm, total length: 1,600 mm, drop-through hole in table: 250 mm, table length: 1,400 mm, table width: 1,000 mm, conveyor belt width: 400 mm, pressing force: 160 t, control cabinet height: 2,500 mm, control cabinet length: 5,000 mm, control cabinet width: 600 mm, type of input current: AC, stroke length: 110 mm, stroke adjustment: 100 mm, clearance between the columns: 1,500 mm, working width: 300 mm, input voltage: 400 V, distance between side stands: 600 mm, distance between stands: 1,500 mm, overall weight: 22,000 kg, control voltage: 24 V, product height (max.): 5 mm, year of last overhaul: 2024, pressure: 6 bar, sheet thickness steel (max.): 5 mm, compressed air connection: 6 bar, height adjustment type: hydraulic, punching force: 160 t, space requirement height: 4,200 mm, space requirement length: 13,000 mm, space requirement width: 2,500 mm, sheet thickness aluminum (max.): 5 mm, Press force: 1600 kN (at 60 strokes/min) Table size: 1500 x 1100 mm (W x D) Clamping area (table): 1400 x 1000 mm Clamping area (ram): 1400 x 1000 mm Installation height: 751 mm (stroke at bottom, adjustment at top) Stroke rate: 20–120 strokes/min, infinitely variable Stroke: 8–110 mm, automatically adjustable Ram adjustment: 120 mm (motorized) Features: - Equipped with servo technology, programmable ram speed - Table clamping plates are split and manually movable - 8-way slide guide - Motorized central oil lubrication - Automatic ram adjustment - Pneumatic ram weight compensation - Hydraulic stroke adjustment - Siemens S7 control system - Visualization via Siemens panel PC - Tool protection for 6 tools - Tool data storage (1000 entries) - 2-channel press force measurement - Hydraulic overload protection - T-slots in table and ram - Longitudinal groove for tool centering in the ram - Vibration-damping machine feet - Split table with 3 adjustable scrap bridges - Various 400V and 220V sockets configurable via the control (e.g. for conveyor belt) - 2 cams for rotary table - Feed adjustable electrically 120–275 mm - Strip lubricator adjustable via control - ERP connection/data transmission possible via LAN cable - The press is currently at the manufacturer’s site and will be retrofitted with an intermediate gearbox (if desired) Feed: - Rollers: 120 mm - Width: 400 mm - Length: unlimited - Pneumatic intermediate ventilation Gbsdpfxexiwzhe Afpou Strip lubricator by Raziol 400 x 80 mm, various rollers (frequency, quantity, and medium 1 or 2), control via S7 (on request, not included) Decoiler/Straightener (on request, not included): - Max. 5 tons - Outer diameter 1800 mm - Inner diameter 508 mm - Width: 400 mm - 7 rollers 90 mm with supports (Alligator 200 mm) - Controllable via S7

Condition: used, Year of construction: 1992, pressure 10 t stroke 8-40 mm no. of strokes 120-600 Hub/min ram - range of adjustment 40 mm table surface area 380x240 mm ram surface 220x140 mm hole in the table 220x110 mm table height 910 mm tool hole in ram Ø 30 mm throat 135 mm weight of the machine ca. 1,2 t Gjdpfxjxh Szaj Afpebu dimensions of the machine ca. BxTxH 1000x1500x2000 mm

Condition: used, Year of construction: 2000, pressure 130 t no. of strokes 50-250 Hub/min sheet width 250mm mm stroke 8-120 mm ram - range of adjustment 100 mm Gbodpfx Asxh Sypofpou table surface area 1600x800 mm ram surface 1600x800 mm hole in the table 1100x250 mm table height 1000 mm 370 mm weight of the machine ca. 24 t dimensions of the machine ca. BxTxH 3900x2500x3800 mm

Condition: new, Year of construction: 2025, pressure 75 t stroke 8-80 mm no. of strokes 80-200 Hub/min ram - range of adjustment 70 mm table surface area 900x600 mm ram surface 900x470 mm hole in the table 450x180 mm Gsdpfx Aoxh Swuofpsbu dist. between columns - front to rear 500x350 mm dist. between pillars (front to rear) 788 mm total power requirement 10 kW weight of the machine ca. 10 t dimensions of the machine ca. BxTxH 1600x1200x2800 mm

Condition: ready for operation (used), Year of construction: 1976, Pressing force: 20 t Table size: 340 x 320 mm (W x D) Ram size: 160 x 230 mm with wedge plate Table opening: 70 x 180 mm Stroke rate: max. 150 strokes/min, infinitely adjustable via PIV gearbox Stroke: 10...50 mm Gbsdpfoxg Rvajx Afpou Ram adjustment: 50 mm Equipped with: • Swiveling extension plate for feed • Motorized central oil lubrication • Slide guide with V-prisms • Machine body made of cast iron • PIV gearbox for stroke rate control • Free-standing control panel • 3 cams for feed, etc. • Manual setup via hand lever • Forward and reverse operation • No documentation or electrical diagrams available Optionally, we can offer a pneumatic feed for the press.

Condition: used, Year of construction: 2005, functionality: fully functional, OMERA-ROSS 500-R2-M2P8 Eccentric Press Description: Capacity (Tons): 500 Table Size: 2300 x 1400 mm Ram Stroke: 300 mm Minimum Number of Strokes: 12-44 SPM Subtype DM Cdc: DM2B CE Marked: Yes Eccentric Drive Linkage System: Knuckle-joint flywheel with screw, eccentric type Ram Width: 2300 x 1300 mm Ram Mounting: 200 mm Number of Pressure Points: 2 Number of Guides: 8 Ram Adjustment System: Guided wedge ball seat Gbsdpfjxfk E Ejx Afpeu Daylight (Slide Opening): 1150 mm Side Window (Between Uprights): 1020 mm Weight: 66 tons (66,000 kg) Foundation Depth: 1000 mm Motor Power: 76 kW Electrical Panel Connections - Operation - Condition - To be overhauled Front/Rear Photocells: Yes Front/Rear Safety Guards: Yes Mechanical/Hydraulic Overload Protection: Yes Accessories / Other data: Compact Feed Line Presses 600x4 Motor Power: 76 kW Table Length: 2300 mm Table Width: 1400 mm Strokes per minute: up to 44 spm Distance between uprights: 1020 mm Total Weight: 66,000 kg

Condition: used, Year of construction: 1996, Manzoni Presse Type: 4MR 15000 Press force: 1,500 t Strokes: 10-60 1/min Stroke: 160 mm Ram adjustment: 160 mm Installation height: 900 mm Gbjdpfx Afoxfcanjpeu Table surface: 2,400 x 2,200 mm Ram surface: 2,250 x 2,200 mm

Condition: ready for operation (used), Punching machine, hole punch, blanking press, eccentric press, Used machine Gedpfx Ajxdxbxefpebu Manufacturer: Haulick + Roos Werkzeugmaschinen GmbH, Pforzheim, Germany Type: RVD 32-540 HS Serial number: 1201847 Year of manufacture: 1985 Pressing force: 320 kN (≈ 32 tons) Stroke rate (speed range): 30 – 1200 strokes/min Drive (motor power): ~18 kW Stroke length: 0 – 40 mm Ram adjustment: 0 – 50 mm Centre hole in ram: Ø 52 mm This is a high-speed eccentric press (HS = High Speed), suitable for pressing thin sheet metal in mass production, for example in the electronics or automotive industries for small components.

Condition: new, Year of construction: 2025, pressure 315 t distance between columns 2800 mm stroke fix 35 mm no. of strokes 100 - 250 Hub/min dayligth (stroke and adjustment up) 560 mm column travel -side 600 mm Gjdpfxexcp Itj Afpjbu table surface area 2700 x 1200 mm hole in the table 2450 x 450 mm ram surface 2700 x 800 mm Weight 80,0 t dimensions of the machine (WxDxH) 5,1 x 2,65 x 5,25 m

Condition: new, Year of construction: 2025, pressure 315 t distance between columns 3800 mm stroke fix 35 mm no. of strokes 100 - 250 Hub/min Godpfxjxcp Ims Afpjbu dayligth (stroke and adjustment up) 560 mm column travel -side 600 mm table surface area 3700 x 1200 mm hole in the table 3400 x 450 mm ram surface 3700 x 800 mm Weight 110,0 t dimensions of the machine (WxDxH) 6,1 x 2,65 x 5,6 m

Condition: excellent (used), Year of construction: 1995, Press force 320 kN Stroke rate 1,100/min Ram stroke 3-50 mm Ram adjustment 50 mm Drive power 19 kW Gbedsxcmkfepfx Afpju Table length 760 mm Including soundproof cabin Including control cabinet Including BANDMOTION servo feeder Including KEYENCE camera monitoring Including decoiler Including valid UVV (safety regulations)

Condition: used, Year of construction: 1989, machine/vehicle number: 4588/23, Press capacity: 60 ton Ram stroke adjustable: 20 - 76 mm Slide adjustment: 80 mm Free frontal opening L-R: 650 mm Free lateral opening F-B: 260 mm Table surface area : 770 x 620 mm Slide area: 700 x 456 mm Hole in table: 600 x 250 mm Bruderer Double Roll Precision Feed: BBV 202/120 Number of strokes: 70 -700 s.p.m. Dimensions L x W x H: 2.600 x 2.100 x 2.220 mm Weight of machine approx.: 7,5 ton Standard configuration clutch is overhauled Automation Gjdpsxch D Tofx Afpebu Bruderer feeder BBV 202/120

Condition: used, Year of construction: 2002, Manufacturer: Schuler Gräbener Press force: 400 t Stroke rate: 20-100 1/min Stroke adjustment: 66-203 mm Shut height: 700 mm Slide adjustment: 150 mm Table area: 3,200 x 1,200 mm Slide area: 3,200 x 1,200 mm Coil line: Manufacturer: Schuler Automation Gbsdpfxjxcgwxj Afpju Coil width: 100 - 1000 mm Coil thickness: 0.7 - 5.0 mm Decoiler load capacity: 8,000 kg

Condition: used, Year of construction: 2001, MANUFACTURER: SANGIACOMO PRESS FORCE: 250 t Gsdpfexcgqrox Afpsbu YEAR OF MANUFACTURE: 2001 STROKE ADJUSTMENT: 21-230 mm RAM ADJUSTMENT: 120 mm STROKES PER MINUTE: 75 TABLE SIZE: 2,300 x 1,090 mm INSTALLATION HEIGHT: 550 mm If interested, we can also offer the machine mechanically and/or electrically overhauled.

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, table length: 2,000 mm, table width: 1,200 mm, pressing force: 200 t, stroke length: 100 mm, Raster punching machine with Desch compact drive 3-piece tie-rod cast construction Fixed stroke 100 mm Hydraulic overload protection Gbjdpjxcbcvsfx Afpeu Mechanically overhauled in 2021 Siemens S7 control system Optional with straightening machine and strip feeding line

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, ram adjustment: 150 mm, table length: 2,000 mm, table width: 1,200 mm, pressing force: 250 t, stroke adjustment: 40,200 mm, overall weight: 55,000 kg, DGUV certified until: 09/2026, Raster Punching and Forming Press RSU 2500 - 2000 P Desch compact drive 3-part tie rod cast iron construction Ram area: 1000 x 2000 mm Hydraulic overload protection Stroke rate: 20 - 150 Gsdpsxcbbrjfx Afpebu Optional with Kohler strip feeding line 20030.400/9-2000 .2H

Condition: refurbished (used), pressing force: 60 t, Machine for order High speed press BSTA 60 Retrofit and general overhaul Conversion to electronic drive und new Unidor PC-control system. Tool area enlargement possible. Please contact us for detailed offers. Gjdpfx Ajxb D Dasfpjbu

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, table length: 2,000 mm, pressing force: 200 t, stroke adjustment: 30,150 mm, overall weight: 32,000 kg, DGUV certified until: 09/2026, year of last overhaul: 2023, Raster servo punching press. Mechanically overhauled in 2023 with new bearings, eccentric shaft, servomotor, and gearbox. Stroke adjustment from 30 to 150 mm. Ram adjustment 100 mm. Press force measurement system. Hydraulic overload protection. Guide rails. Raster feed rollers hydraulically pressed. 3-piece tie rod cast construction. Gbedpfx Afjxbf Nwepeu

Condition: good (used), . Technical data . Pressing force 30 t Stroke 100 - 600 mm Godpfsxa Ef Aox Afpobu Ram stroke, adjustable 8 - 40 mm Installation height 200 mm . Various reels in stock up to 300 kg . . Ongoing purchase of used German machines without NV or CNC control

Condition: good (used), Year of construction: 1995, functionality: fully functional, machine/vehicle number: 95-1292, pressing force: 25 t, Schaal SEP 25 (1995) [25 ton] – For Sale Well-maintained Schaal SEP 25 from 1995 in good condition. The machine is in full working order and ready for immediate use. Available now and can be tested in Boxtel, Netherlands. Gbedpfx Afjxawi Hspou

Condition: good (used), Year of construction: 1990, functionality: fully functional, machine/vehicle number: 1058, pressing force: 40 t, Schaal SEP 40 (1996) [40 ton] – For Sale Well-maintained Schaal SEP 40 from 1984 in good condition. The machine is in full working order and ready for immediate use. Godpfx Afexawimopebu Available now and can be tested in Boxtel, Netherlands.

Condition: good (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 00-1564, pressing force: 80 t, Schaal SEP 80 (2000) [80 ton] – For Sale Well-maintained Schaal SEP 80 from 2000 in good condition. The machine is in full working order and ready for immediate use. Gjdpfx Afsxawiajpobu Available now and can be tested in Boxtel, Netherlands.

Condition: good (used), Year of construction: 1996, functionality: fully functional, machine/vehicle number: 1365, pressing force: 80 t, Schaal SEP 80 (1996) [80 ton] – For Sale Well-maintained Schaal SEP 80 from 1996 in good condition. The machine is in full working order and ready for immediate use. Godpexawhvsfx Afpebu Available now and can be tested in Boxtel, Netherlands.

Condition: good (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 53, Bruderer BSTA 18 PH1000 E (2000) – For Sale Gsdpfx Asxawcyefpobu Well-maintained Bruderer BSTA 18 PH1000E from 2000 in good condition. The machine is in full working order and ready for immediate use. Available now and can be tested in Boxtel, Netherlands.
