Condition: new, neu Bulgarien 55100 € 1041.39 € 600 mm 2000 mm 0 mm 80 mm 400 mm 400 mm 8 90 M 3 20 - 100; 80 - 400; 400 - U/Min 120 64 0.5 - 120 mm 60 - 1/4 Gänge/" 315 mm 1 mm 90 mm 5 MK 2 mm 11 kW 3600 mm 1500 mm 1650 mm 3110 kg In contrast to the universal lathes, here the adjustment of the revolutions is infinitely variable by means of a frequency inverter. It is possible to ensure a "constant cutting speed" (V-const), i.e. when changing the diameter to be machined, the speed remains unchanged and thus a higher accuracy and smoothness of the surface is achieved. At the customer's request, the machines can be manufactured with a reading of the linear displacement and positioning by mounting a digital display. driven by variable speed control (3 steps) 3-axes digital readout Fagor with CSS (constant surface speed) quick change toolpostAmestra type Multifix with 4 holders (3 square, 1 round) Bjdpfxsyq Stpo Ah Ijwi 3-jaw chuck Bison 3204/DIN6350, Ø 250 mm spindle dead center main motor with frequency invertor four way rapid traverse device longitudinal stop for 1 position coolant equipment full length rear splash guard leadscrew and shaft protection safety guard for the chuck toolholder guard levelling bolts and plates quick release tailstock low voltage machine lamp operating manual machine according to "CE" FURTHER TURNING LENGTHS: turning length1.000 mm € 52 250,00 turning length1.500 mm € 53 290,00 turning length3.000 mm € 59 990,00 turning length4.000 mm € 65 540,00 turning length5.000 mm € 80 860,00

Condition: new, neu Bulgarien 85520 € 1616.33 € 760 mm 3000 mm 380 mm 132 mm 520 mm 560 mm 11 140 M 3 7 - 42; 28 - 170; 165 - 1 U/Min 150 0.039 - mm/U 0.02 - 9 mm/U 0.5 - 0 mm 60 - 1/6 Gänge/" 410 mm 150 mm Bwedpfx Aeyq Sn Tsh Ioi 105 mm 6 MK 225 mm 15 kW 4470 kg driven by variable speed control (3 steps) 3-axes digital readout FAGOR with CSS (constant surface speed) quick change toolpostAmestra type Multifix with 4 holders (3 square, 1 round) 3-jaw chuck Bison3295/DIN6350, Ø 400 mm spindle dead center main motor with frequency invertor four way rapid traverse device foot pedal brake longitudinal stop for 1 position coolant equipment full length rear splash guard leadscrew and shaft protection safety guard for the chuck toolholder guard levelling bolts and plates quick release tailstock tailstock quill reducer mechanized movement of tailstock low voltage machine lamp operating manual machine according to "CE" FURTHER TURNING LENGTHS: turning length 1.500 mm € 71 280,00 turning length2.000 mm € 74 190,00 turning length4.000 mm € 91 680,00 turning length5.000 mm € 104 390,00 turning length6.000 mm € 1 230,00

Condition: new, neu Bulgarien 60660 € 1146.47 € 6 mm 2000 mm 315 mm 103 mm 4 mm 400 mm 11 120 M 3 16 - 63; 63 - 250; 315 - U/Min 120 0.04 - 12 mm/U 0.02 - 6 mm/U 0.5 - 120 mm Gänge/" 315 mm 1 mm 90 mm 5 MK 2 mm 11 kW 3310 kg driven by variable speed control (2 steps) 3-axes digital readout FAGOR with CSS (constant surface speed) quick change toolpostAmestra with 4 holders (3 square, 1 round) 3-jaw chuck Bison 3204/DIN6350, Ø 315 mm spindle dead center longitudinal stop for 1 position coolant equipment full length rear splash guard Bwedpfeyq Sm Nox Ah Ioi leadscrew and shaft protection safety guard for the chuck toolholder guard levelling bolts and plates quick release tailstock low voltage machine lamp operating manual machine according to "CE" FURTHER TURNING LENGTHS: turning length 1.000 mm € 57 710,00 turning length1.500 mm € 58 850,00 turning length3.000 mm € 65 550,00 turning length4.000 mm € 71 0,00 turning length5.000 mm € 86 620,00

Condition: used, turning diameter over bed 1250 mm turning diameter over slide rest 940 mm turning length 10000 mm spindle diameter 105 mm speed 1,6 - 315 (x24) m/min voltage 380 V 4-jaw faceplate Power compound Bwodpfx Ahsyqvrco Iei The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, turning diameter over bed 1800 mm turning diameter over slide rest 1200 mm turning length 16000 mm turning dia. in gap 2300 mm spindle diameter 150 mm speed 1 - 300 U/min 4-jaw face plate Ø 1.500 mm 4x work rest 4-way toolpost Power compound Rapid traverse Powerised tailstock The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop Bwedoyqthhopfx Ah Ioi If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1971, functionality: fully functional, Center distance: 2.000 mm turning diameter: 1.200 mm turning diameter in the gap (with guide spindle pulled out to the right): approx. 1.460 max. width of the adjustable bed: 900 mm spindle bore: 85 mm turning rate: 14 - 710 U/min dimensions: 4.705 x 2.060 x 2.000 mm Bodpfxeynk Srs Ah Iowi equipment: 4 fold tool clamping system, HEIDENHAIN three-axis digital readout, Three jawchuck FORKARDT F400, Vibration damping elements

Condition: new, Year of construction: 2025, turning diameter over top slide: 575 mm, center height: 385 mm, turning length: 1,500 mm, total length: 3,000 mm, total width: 1,100 mm, total height: 1,450 mm, spindle speed (max.): 1,600 rpm, spindle speed (min.): 36 rpm, metric thread diameter (min.): 1 mm, metric thread diameter (max.): 14 mm, metric thread steps: 22, bed width: 405 mm, Turning diameter in gap: 1,050 mm, type of input current: three-phase, overall weight: 3,500 kg, rapid traverse X-axis: 5 m/min, rapid traverse Y-axis: 2 m/min, quill mount: MK 5, three-jaw chuck diameter: 325 mm, Centre distance ----- 1500 mm Centre height ----- 385 mm Swing diameter ----- 770 mm Main spindle bore ----- 105 mm Bed width ----- 405 mm Spindle speed ----- 36-1600 rpm Motor ----- 7.5 kW Weight ----- 3500 kg INCLUDES * 3-axis digital readout, brand SINO Bwjdpfx Aeym Eccjh Isi * Quick-change tool post type Multifix TOOC3 with 4 tool holders * 3-jaw chuck 325 mm * 4-jaw chuck 400 mm * Faceplate 750 mm * Fixed and travelling steady rest * LED work lamp and coolant system * Box with various tools

Condition: not inspected (used), functionality: unexamined, turning length: 3,000 mm, spindle speed (max.): 1,800 rpm, overall weight: 8,000 kg, three-jaw chuck diameter: 310 mm, No reserve price – guaranteed sale to the highest bidder! Bidding obligates the buyer to collect the machine within one of the specified periods: either between 11/05/2026 and 13/05/2026 or between 18/05/2026 and 21/05/2026. TECHNICAL DETAILS Turning length: 3,000 mm Bedpfx Ajym Dcuoh Ijwi Center height over bed: 300 mm Swing diameter over bed: 600 mm Center height over carriage: 200 mm Swing diameter over carriage: 400 mm Spindle speed: 9 to 1,800 rpm Spindle bore: 110 mm Three-jaw chuck diameter: 310 mm Steady rest diameter: 200 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 6,000 x 1,400 x 2,000 mm Weight: 8,000 kg EQUIPMENT Tailstock Multifix turning tool holder Three-jaw chuck Two-axis digital readout (SONY) Steady rest External Reference: Pieper – Lot 57

Condition: used, Year of construction: 2019, LITZ HITECH - LTC-3530 - 2019 - system FANUC - center distance 3100 mm - swing over bed d660 mm - swing over saddle d480 mm - max turning diameter d500 mm - X/Y moves 250+25/ 3165 mm - spindle 2500 RPM - spindle bore d165 mm - bar capacity d116 mm - live tools speed max 2000 RPM - turret 10 pos. - working hours 5600 - condition very good Bwsdsyl Svgopfx Ah Ioi

Condition: new, Year of construction: 2026, Main Advantages of the CORMAK 660 × 2000 Universal Lathe Electromagnetic foot brake ensures maximum safety and significantly reduces downtime by allowing fast and reliable stopping of the machine. Rapid longitudinal and cross feeds considerably shorten tool travel time, increasing machining efficiency and operator comfort. Universal application – external and internal turning, taper turning, threading (metric, inch, module, DP), drilling, broaching, and polishing. Hardened and ground cast iron bed (400 mm wide) provides maximum vibration reduction and high machining accuracy. Large spindle bore Ø105 mm and D1-8 camlock spindle nose enable machining of shafts and large-diameter components. High drive power – 7.5 / 9 kW spindle motor ensures stable performance during heavy-duty cutting operations. Wide threading range without changing change gears, saving time and increasing production flexibility. 3-axis Digital Readout (DRO) enhances precision of settings and overall turning process control. Standard Equipment 3-axis digital readout (DRO) 315 mm 3-jaw chuck 400 mm 4-jaw chuck 400 mm faceplate Fixed steady rest and traveling steady rest Cooling system and work light Polish user manual and CE declaration Optional Equipment Set of turning tools 25 × 25 mm – 7 pcs Precision live center MT5 Grinding attachment for shafts and bores Coolants and cutting oils Technical Specifications Swing over bed: Ø 660 mm Swing over cross slide: Ø 455 mm Swing in gap (diameter × width): 885 × 170 mm Bsdpeyk Dabefx Ah Iewi Center height: 330 mm Distance between centers: 2000 mm Bed width: 350 mm Maximum tool size: 25 × 25 mm Total cross slide travel: 355 mm Total compound slide travel: 130 mm Spindle bore: Ø 105 mm Spindle nose: D1-8 Spindle taper: Ø 113 mm (1:20) Number of spindle speeds: 12 Spindle speed range: 25–1500 rpm Leadscrew diameter and pitch: Ø 40 mm × 6 mm Inch thread range: 2–112 TPI (60 ranges) Metric thread range: 0.2–14 mm (47 ranges) DP threads: 4–112 DP (50 ranges) Module threads: 0.1–7 MP (39 ranges) Longitudinal feed: 0.059–1.646 mm/rev (35 ranges) Cross feed: 0.020–0.573 mm/rev (35 ranges) Tailstock quill travel: 180 mm Tailstock quill diameter: Ø 75 mm Tailstock taper: Morse taper No. 5 Main spindle motor: 7.5 kW (10 HP), 3-phase Coolant pump motor: 0.1 kW (1/8 HP) Required installation space (L × W × H): 334 × 115 × 151 cm Packing dimensions (L × W × H): 340 × 115 × 182 cm Weight: 3200 kg

Condition: used, Year of construction: 1990, functionality: fully functional, Used parallel lathe complete with accessories Bwjdpoykl Imefx Ah Isi

Condition: refurbished (used), Year of construction: 2026, functionality: fully functional, spindle bore: 140 mm, turning diameter: 630 mm, turning diameter over bed slide: 380 mm, center width: 3,000 mm, turning length: 3,000 mm, The lathe has been fully overhauled and meets the technical parameters specified in the technical documentation (DTR), technical acceptance conditions (WOT), and Polish Standards. The lathe is covered by a full 12-month warranty. Availability: In stock, ready for operation, connected to power. The universal lathe TUR 630A x 3000 is designed for single-piece and small-batch production of shaft-type and disc-type parts. The machine can be used for turning, facing, boring, and cutting metric, inch, module, and DP threads, both right-hand and left-hand. It is suitable for use in serial production departments as well as in maintenance and repair workshops. Its compact design, wide range of spindle speeds, and feed rates enable both roughing and finishing machining of cast iron, steel, non-ferrous metals, and plastics. Technical Data – TUR 630A x 3000: Swing over bed [mm]: 630 Swing over cross slide [mm]: 380 Spindle bore diameter [mm]: 140 Distance between centers [mm]: 3000 Number of spindle speeds: 21 Spindle speed range [rpm]: 18–1800 Number of feeds: 42 Bwedpfxsyi U Uao Ah Iei Feed range [mm/rev]: Longitudinal: 0.08–3.26 Cross: 0.04–1.63 Motor power [kW]: 15 Overall dimensions [mm]: Length: 3700 Width: 1420 Height: 1650 Machine weight [kg]: 3400

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, turning diameter: 630 mm, - Complete overhaul of the machine (description of work see below) - New electrical installation in CE-compliant version: chuck guard Ø 315 mm with limit switch, front chip guard on the carriage, rear movable guard, leadscrew cover - Accuracy certificate - Electrical installation inspection protocol - Delivery: immediately Key Features: - Simple and ergonomic operation - Hand scraping of critical machine parts – high machining precision - Long service life - Low operating costs - Low maintenance requirements - Capability for cutting various thread types with wide pitch range Technical Specifications: Working Area: Swing over bed: 630 mm Swing over carriage: 340 mm Swing in gap: 880 mm Effective gap length from spindle face: 300 mm Distance between centers: 2000 mm Center height above bed: 315 mm Bed width: 450 mm Spindle: Speed range: 10–1000 rpm Number of speed steps: 16 Spindle nose: Bayonet B8 Spindle bore: 71 mm Internal taper: Metric 80 Slides: Cross slide travel: 400 mm Compound slide travel: 180 mm Max. tool size: 40 x 25 mm Longitudinal feed range: 0.05 – 6.4 mm/rev Cross feed range: 0.025 – 3.2 mm/rev Rapid longitudinal feed: 3000 mm/min Rapid cross feed: 1500 mm/min Compound rest swiveling angle: ±90° Tailstock: Quill diameter: 90 mm Quill stroke: 240 mm Quill taper: Morse 5 Transverse offset: ±10 mm Thread Cutting: Metric threads (number/pitch): 29 / 0.5 – 40 mm Whitworth threads (number/pitch): 35 / 1–80 TPI Modular threads (number/pitch): 26 / 0.25–20 mm Diametral pitch threads (number/DP): 31 / 2–72 DP Drives: Total power input: 15 kVA Main drive motor: 11 kW Coolant pump: 0.1 kW Rapid traverse motor: 0.95 kW Dimensions: Total length: 4000 mm Width: 1440 mm Height: 1100 mm Weight: 2940 kg Operating Data: Supply voltage: 3 x 400 V ±10% Frequency: 50 Hz ±2% Achievable machining accuracy: IT7 Spindle nose: Bayonet B8 Spindle bore: Ø 71 mm Bjdpeyf Dnusfx Ah Iowi Square turret Electrical system for 3 x 400 V / 50 Hz, circuit breaker equipped Slide box controls on right side Gap for increasing swing over bed to 880 mm for 300 mm from spindle face Rapid traverse Tailstock Main drive 7.5 kW Swarf tray + coolant system LED machine lighting Supply line in armored hose Folding handle for X axis Folding handle for Z axis Color – RAL 7035-3 / 7016-3 / 6153 Set of change gears for thread cutting Shear pin, 3 pcs

Condition: used, Parallel Lathe SCULFORT type MAXICAP SENIOR 380 x 4000 RN Between points: 4000 mm Maxi Ø on bench: Ø 780 mm Maxi Ø over saddle: Ø 580 mm (rear trolley dismantled) - Ø 500 mm (without rear trolley dismantled) Maxi diameter in brocken bed: Ø 1160 mm Width in brocken bed: 400 mm Spindle: Ø 80 mm Spindle speed: from 16 to 1280 RPM Square turret 3-jaws chuck Ø 400 mm Threadings: Metric + Withworth 3 points steady max Ø 350 mm Tailstock CM6 Motor power: 13 CV Feeds: auto transverse + longitudinal Clutch rapid used Lubricant tank Dimensions (L x W x H): 6500 x 1800 x 1900 mm Bsdpfx Ajyarw Hsh Iowi Weight: approx 7 T

Condition: ready for operation (used), Year of construction: 1980, functionality: fully functional, turning diameter over cross slide: 800 mm, spindle bore: 70 mm, turning diameter: 800 mm, turning diameter over bed slide: 510 mm, turning length: 2,750 mm, total length: 5,600 mm, total width: 1,400 mm, spindle speed (max.): 900 rpm, spindle speed (min.): 20 rpm, rotational speed (max.): 900 rpm, rotational speed (min.): 20 rpm, We offer this ready-to-use TOS Hostivař SU 80 A lead/traverse spindle lathe, year of manufacture 1980. Machine type: SU. 80 S A Main spindle power: 15 kW Main spindle speed range: 20–900 min⁻¹ Longitudinal feed range: 0.09–0.90 mm/rev Cross feed range: 0.05–0.50 mm/rev Metric thread range: 0.1–22 mm/rev If you have any questions or need further information, feel free to send us a message or give us a call. Bwedpfx Ahex Uymto Isi

Condition: good (used), Year of construction: 2013, Centre height: 330 mm Centre distance: 2000 mm Spindle bore diameter: 103 mm Max. turning diameter over bed: 660 mm Bwsdpfxex Ux D Do Ah Iji Max. turning diameter over carriage: 420 mm Spindle speed range: 36 – 1600 rpm (12 steps) Spindle nose: ISO 702/II No. 8 Longitudinal feed range: 0.063 – 2.52 mm/rev (65 steps) Cross feed range: 0.027 – 1.07 mm/rev (65 steps) Metric threads: 1 – 14 mm (22 steps) Inch threads: 28 – 2 TPI (25 steps) Module threads: 0.5 – 7 mm (18 steps) Diametral pitch: 56 – 4 DP (24 steps) Motor power: 7.5 kW Weight: 3200 kg Dimensions: 3635 x 1050 x 1450 mm

Condition: good (used), Year of construction: 2007, Manufacturer: Volz BMT Year of manufacture: 2007 Control: conventional with digital readout (DRO) Country of origin: Taiwan Swing diameter: 660 mm Bodpfxjx Uw S Hs Ah Iowi Max. turning length: 2000 mm Spindle bore: 85 mm Spindle mount: D1-8 Spindle motor: 7.5 kW Spindle speed: 17–1200 rpm with steady rest with digital readout (DRO) with thread cutting function

Condition: good (used), Year of construction: 2005, Ref. -No.: 10314 Bwsdpfx Aex Sw Dqoh Iji Manufacturer: PINACHO Type: S-90/ 310-155 Year of construction: 2005 Type of control: Konventionell Storage location: Halberstadt Country of origin: Spain Bar passage: 90 mm Travel quill: 180 mm Turning Diameter: 630 mm Turning Length: 3000 mm Turning Diameter Over Bed: 620 mm Tip length: 3000 Cross Movement. (X-Axis): 365 mm Spindle Bore: 155 mm Tailstock Quill Diameter: 72 mm Turning diameter over cross slide: 880 mm Jaw chuck diameter: 380 mm Turning Speed Range: 16 - 750 rpm Further information: - The lathe has two jaw chucks on the headstock - metric, Whitworth and inch trapezoidal threads can be turned - adjustable feeds for cross face and longitudinal face turning (0.05 to 1.5 mm/u)

Condition: used, total length: 4,500 mm, total width: 1,600 mm, total height: 1,500 mm, Empty weight: 5.000 kg Price: On request - Documentation available: No - CE certificate present: No - Serial number: 0440922 - Drive system: Conventional - Power [kW]: 18.5 - Centre height [mm]: 315 - Swing over bed [mm]: 630 - Carriage turning diameter [mm]: 400 - Distance between centres [mm]: 3000 - Bed width [mm]: 580 - Spindle bore [mm]: 82 - Min. spindle speed [rpm]: 9 - Max. spindle speed [rpm]: 1120 - Options: Three-jaw chuck, Four-jaw chuck - Transport dimensions: 4500mm x 1600mm x 1500mm (l x w x h) Bwjdpfx Aex Ryv Toh Iei - Transport weight [kg]: 5000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, functionality: fully functional, turning diameter over bed slide: 630 mm, turning length: 3,000 mm, Swing diameter over bed 655 mm Swing diameter over support 390 mm Turning length 5000 mm Spindle bore 82 mm Bwsdjx N Iq Nepfx Ah Isi Spindle speed 9-1120 rpm Feed rate 0.049-3 mm/rev Total connected load 12 kW

Condition: ready for operation (used), Year of construction: 1984, spindle bore: 81 mm, center height: 315 mm, center width: 2,000 mm, overall weight: 3,100 kg, Heidenhain 2-axis digital readout, external electrical cabinet, capacity 2000x725 mm, spindle bore 81 mm, multifix turret, steady rest Bwodpjx H Sdnjfx Ah Isi

Condition: excellent (used), functionality: fully functional, turning diameter over cross slide: 390 mm, spindle bore: 116 mm, turning diameter: 635 mm, turning diameter over bed slide: 390 mm, turning length: 2,000 mm, Used lathe in very good condition, including a 400 mm 3-jaw chuck, 1 x steady rest and a Multifix toolholder. Technical specifications: Turning length: 2000 mm Swing over bed: 630 mm Swing over cross slide: 390 mm Swing in gap: 900 mm Spindle bore diameter: 116 mm Total weight: 4230 kg Chuck mounting: D1 11 in. Camlock Morse taper: No. 6 Bwodpfxex Eln Ro Ah Isi

Condition: like new (used), Center height over bed: 330 mm, max turning diameter over carriage: 408 mm, max turning diameter over bed: 640 mm, max turning diameter in gap: 899 mm, distance between centers: 2000 mm, variable spindle speed, rpm: 18-1500, spindle bore diameter: 105 mm, spindle nose: ASA 11”, tailstock: MT5, quill diameter: 90 mm, travel: 250 mm. cross slide travel: 275 mm. main motor: 15 hp. machine weight: 3450 kg. Bwodpfox Dikkex Ah Isi

Condition: good (used), Year of construction: 2011, functionality: fully functional, turning diameter over cross slide: 700 mm, turning length: 6,000 mm, spindle motor power: 30 W, The lathe is in good technical condition, connected and ready for testing. It features digital readout, faceplate, and steadies. Specifications: Swing diameter over bed: 1,090 mm Distance between centers: 6,000 mm Swing diameter over cross slide: 700 mm Main drive motor power: 30 kW Dimensions (L x W x H): 8,200 x 1,800 x 1,855 mm Machine weight: 11,000 kg Bjdpfx Aox A S Sbjh Ijwi

Condition: good (used), functionality: fully functional, turning diameter over cross slide: 630 mm, LATHE TECHNICAL SPECIFICATION – PERFORMANCE OVERVIEW Workpiece Capacity Turning diameter over bed (nominal / max): 630 mm / 660 mm Turning diameter over carriage: - Short slides: 400 mm - Long slides: 320 mm Max. swing in front of faceplate notch: 720 mm Notch length: 265 mm Over bed: 305 mm Over floor: 1125 mm Machine Construction & Spindle System Bed width: 550 mm Spindle bore: 72 mm Faceplate: - Diameter: 630 mm - Width: 120 mm Tooling & Setup Tool cross-section (cutter): 40 × 40 mm Tool holder side length: 200 mm Spindle & Drive Performance Main motor speed: 1400 rpm Spindle speed steps: 18 Max. permitted faceplate speed: 560 rpm Feed Ranges Longitudinal feeds: - Steps: 68 - Range: 0.035–10 mm/rev Cross feeds: - Steps: 68 - Range: 0.014–4 mm/rev Rapid Traverse Rates Longitudinal: 5000 mm/min Cross travel: 2000 mm/min Thread Cutting Capability Metric threads: - 84 types, 0.2–224 mm Inch threads: - 94 types, 140–1/8 TPI Module threads: - 72 types, 0.1–112 Pitch range: - 94 types, 280–1/4 Machine Dimensions Overall length: 2300 mm + distance between centers Width: 1850 mm Height: 1725 mm Bedpfex Acpdox Ah Iowi Ask for a testing video! Robust and precise heavy-duty lathe featuring wide turning capacity, extensive thread cutting options, and high feed/rapid traverse performance. Ideal for demanding workshops requiring versatility, power, and reliability.
