Condition: ready for operation (used), Year of construction: 1994, quill travel distance: 170 mm, throat depth: 900 mm, power: 3 kW (4.08 HP), High-speed radial drilling machine Manufacturer: HKS, Type: HKS 34 MG Year of manufacture: 1994 Technical data Manufacturer: HKS Type: 34MG Year of manufacture: 1994 Drill spindle mount: MK 4 Overhang: max. 900 mm Drilling capacity: 32/38 mm, see data sheet Drill spindle stroke: 170 mm Distance spindle – table: 300 / 750 mm Motor power: 3 kW Clamping area with T-slots: 1050 x 420 mm External dimensions W x D x H: 1400 x 2000 x 2450/2900 Weight approx.: approx. 2000 kg Equipment - Thread cutting device Gijdpfx Ajzbr Ibohvju - Hydraulic column and arm clamping - Coolant system - Swivel table 510 x 310 mm All information without guarantee. A demonstration is possible at any time in our showroom.

Condition: ready for operation (used), DONAU DR 23 - High-speed radial drilling machine - Drilling capacity / steel approx. 28 mm - Arm length 700 mm - Morse taper MK 3 - Speed range 70-1550 rpm (gearbox) Gsdpfx Ahoy Uv Tvsveiu - Automatic feeds 0.075-0.3 mm - Thread cutting device - Drilling depth approx. 130 mm - Hydraulic clamping - Documentation Dimensions: L x W x H 2 x 1.7 x 1.9 meters / Weight 1900 kg Subject to errors and omissions.

Condition: used, table dimensions 500 x 1.200 mm number of T-slots 30 distance t-slots 125 mm distance spindlenose to table 110 - 760 mm Swing radius 535 - 1.135 mm boring range 600 mm work height max. 800 mm quill stroke 200 mm Height adjustment of the drill head 450 mm no. of turning speeds 18 turning speed range 35 - 1.800 U/min bore capacity in St 60 - in full material Ø40 mm bore capacity in GG 22 - in full material Ø50 mm In our assessment, the machine is in good used condition and can be inspected under power by appointment. Gsdpfx Aey Umg Tshvjiu Accessories, as well as the tools and clamping devices shown in the images, are included in the scope of delivery only if explicitly noted in the additional information. Subject to changes, errors in technical data and specifications, and prior sale!

Condition: good (used), Year of construction: 1998, functionality: fully functional, DONAU DANUMERIC 440, year of manufacture 1998 Technical specifications: Gjdpfxey Txlrs Ahvjiu - Table 1800 x 600 mm, 4 T-slots - Drilling radius 540 – 1590 mm - Spindle taper SK40 - Speed range 15 – 2800 rpm - Motor power 5.5 kW - Weight approx. 2,800 kg

Condition: used, Year of construction: 2000, functionality: fully functional, feed length X-axis: 4,000 mm, feed length Y-axis: 1,050 mm, feed length Z-axis: 200 mm, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, Dimensions and Travel Ranges Tool holder: SK 40 Table dimensions: mm 4000 x 800 Number of T-slots: 6 T-slot spacing: mm 140 Gsdpfjy Ttrtjx Ahvsiu Distance: - Spindle bottom edge: min. mm 140 - Table top edge: max. mm 740 Boring radius: - min. mm 540 - max. mm 1590 Travel range U-axis: mm 2600 Travel range Y-axis: mm 1050 Quill stroke (Z-axis): mm 200 Column stroke (W-axis): mm 400 Machining Data Drilling performance in solid material: - St 60: mm 40 - GG 22: mm 50 Thread cutting: - St 60: M 36 - GG 22: M 42 Main spindle drive AC motor, frequency-controlled kW 5.5 at 100% duty cycle Speed range: min-1 15 - 2800 Torque: Nm max. 250 Constant from: min-1 15 - 200 Feed drives X-axis - AC servo motor kW 0.25 Y-axis - AC servo motor kW 0.25 Z-axis - AC servo motor kW 4.50 W-axis - AC servo motor kW 2.50 U-axis - AC servo motor kW 2.50 Rapid traverse speeds (X/Y/Z): m/min 7.5 / 7.5 / 5 Rapid traverse speeds (U/W): m/min 7.5 / 3 Feed rates, infinitely variable: mm/min 5 - 2000 Feed force: N 12000 Accuracy Positional accuracy X, Y axis at 1200 mm: mm ± 0.075 Repeatability X, Y axis: mm ± 0.03 Positional accuracy Z axis: mm ± 0.05 Repeatability Z axis: mm ± 0.03 Positional accuracy W axis: mm ± 0.05 Repeatability W axis: mm ± 0.03 Electrical data Operating voltage / frequency: V / Hz 400 / 50 Control voltage: V 24 Total connected load: kVA 13.0 CNC control Axes: 5 (X, Y, Z, W, U), expandable Screen: TFT flat screen, backlit, easily readable from all sides Position data: Cartesian or polar, dimensions absolute or incremental, Unit of measurement: mm or inch, or in degrees Interpolation: 2 axes (X, Y) Technology database: Tool management, tool suggestions according to machining process, material-dependent cutting data suggestions Tool management: max. 500 tools Subprogram technology: yes Machining cycles: Cycles for centering, drilling, threading, reaming, countersinking and boring, freely programmable cycle for special tools, dwell time possible in each cycle Chip breaking / chip removal: possible in drilling cycle Drilling patterns: Hole pattern, hole circle, matrix Basic software: Programming in dialog mode, 38 zero-point offsets, rotation and mirroring, teach-in for X, Y, Z, restart in program with selection functions for targeted entry Zero point determination: Cycles for determining zero points by manually probing the workpiece for: - any clamped rectangular parts - any clamped round parts - aligning cast and sintered parts - Angle detection for round parts by probing the reference edges or surfaces Data interfaces Paint finish with signs of use Standard paint finish, two-component textured paint Machine upper part: light grey RAL 7035 Machine lower part: light blue RAL 5012 Documentation Operating and programming manual Electrical wiring diagram Spare parts drawings Test report for mechanics, electrical system and safety devices

Condition: good (used), Machine type: Donau radial drilling machine DR 32 Year of manufacture: unknown MK 4 spindle taper Giedpsy Tpq Eefx Ahvsu Spindle speed: 41 – 1800 rpm Threading device Coolant pump Weight: approx. 2500 kg Drilling capacity in steel: 32 mm Table size: approx. 1200 x 600 mm

Condition: excellent (used), Rapid radial drilling machine / Radial drilling machine / Drilling machine (used) Manufacturer: Mikrosa Year of manufacture: 2001 Type: SRB 35 Drilling capacity: - Steel: 35 mm - Cast iron: 40 mm Gjdpfx Ahsy Skrzoveiu Thread cutting: - Steel: M20 - Cast iron: M24 Spindle taper: MK 4 Spindle speed: 20 – 2800 rpm, infinitely variable Automatic feed: infinitely variable Spindle stroke: 140 mm Arm reach: 1000 mm Table size: 1050 x 400 mm Column diameter: 200 mm Installation height: 600 mm Connected load: 7.8 kW Space requirement: approx. width 1250 mm, depth 2100 mm, max. height 2700 mm Weight: approx. 2000 kg Hydraulic clamping Thread cutting device Depth stop Lateral clamping surface Drill chuck 2 gearbox stages The machine is in very well-maintained condition, runs very smoothly, and is ready for immediate operation. Forklift available, free loading on truck. Affordable shipping possible. Location of the machine: 48477 Hörstel

Condition: new, SPS gear shift control card New for old For self-installation or installation by one of our service technicians Gijdpfxsy Rkkho Ahveu

Condition: new, Spare parts for Donau high-speed radial drilling machines Donau DR Donau Danuflex Donau Danumeric Giodpfxjy Ri H Is Ahveu Donau Danusys Donauflex Donaumeric

Condition: like new (used), Suitable for your Donau DR 28Z, DR 40Z, DR 40 Digi, Danuflex 128 Gedpey Ri Hnofx Ahvsiu

Condition: refurbished (used), Repair of speed control board Gsdpfxsy Rfzus Ahvoiu

Condition: ready for operation (used), Year of construction: 1995, Drilling capacity St 60/GG 22: 40/50 mm Gsdpfxey I Ua Is Ahvjiu Thread cutting St 60/GG 22: M 36/M 45 Clamping area of the table: 600 x 1800 mm Height adjustment of the boom: 450 mm Min./max. drilling radius: 305/1305 mm Spindle taper: SK 40 Quill stroke: 200 mm Infinitely variable spindle speeds: 15 - 2800 rpm Infinitely variable feeds: 5 - 2000 mm/min Spindle drive, frequency controlled: 5.5 kW Electrical connection: 400 V, 14 kVA Weight: 3400 kg Space required: 3800 x 2000 x 2500 mm

Condition: used, Year of construction: 1987, We are offering this used Donau DR 40-Z high-speed radial drilling machine, year of manufacture 1987. Manufacturer: Donau Model: DR 40-Z Serial number: 1146-3 Gsdjy Dn E Nepfx Ahvoiu If you have any questions or require further information, please feel free to send us a message. The machine is located in Osterode/Harz. Viewing can be arranged by appointment. This is a used machine, therefore we sell under exclusion of any warranty.

Condition: used, Year of construction: 1989, bore capacity in steel (diameter) 32 mm arm length 1230 mm table surface area 1200 x 500 mm bore stroke 180 mm feed - independent 0,10 - 0,15 - 0,20 - 0,30 mm turning speeds 60 - 1800 U/min taper MK 4 total power requirement 2,7 kW weight of the machine ca. 1,8 t Gjdpfx Aey Aa H Nehvjiu dimensions of the machine ca. 2,2 x 1,8 x 2,3 m Quick radial with: - Feed - Thread cutting device

Condition: good (used), Year of construction: 1979, functionality: fully functional, Drilling capacity into full 32 mm Tapping capacity into full M 32 mm Motor power 1.5 / 3 kW Gisdpjyzxziofx Ahvsu Tool holder MK 4 Quill stroke 170 mm Stroke approx. 400 mm Speeds : Range 1 , infinitely variable from 38 - 192 rpm Range 2 , infinitely variable from 119 - 596 rpm Range 3 , infinitely variable from 400 - 2000 rpm

Condition: good (used), Year of construction: 1999, functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, Machine Specification • Work table 1800 x 600 mm with 4 T-slots • Traversing arm travel 1050 mm • Drilling spindle SK 40 with tool clamping device • Infinitely variable speed programming • Infinitely variable quill feed via three-phase servo motor • 2 T-slots, 18 mm, rear side of machine base • 2 T-slots, 18 mm, left side of machine base • Thread cutting unit • Central lubrication • Coolant system • Machine light • CE marking • Safety device • USB interface Dimensions and Travel Ranges Tool holder: SK 40 Column diameter: 195 mm Gisdpfsyxw Ddex Ahvsu Table dimensions: 1800 x 600 mm Number of T-slots: 4 Distance between T-slots: 125 mm Quill travel (Z-axis): 200 mm Column travel (W-axis): 410 mm Distance spindle nose – table (min): 70 mm Distance spindle nose – table (max): 680 mm Distance spindle nose – floor (min): 970 mm Distance spindle nose – floor (max): 1580 mm Drilling radius: 540 – 1590 mm Working table height: 900 mm Machining Capacities Drilling capacity (solid): St 60: ⌀ 40 mm GG 22: ⌀ 50 mm Tapping: St 60: M36 GG 22: M42 Main Spindle Drive AC motor, frequency controlled: 5.5 kW at 100% duty cycle Speed range: 15 – 2800 rpm Torque: max. 250 Nm Constant torque from 15 – 2000 rpm Feed Drives X-axis - AC servo motor: 0.25 kW Y-axis - AC servo motor: 0.25 kW Z-axis - AC servo motor: 4.50 kW W-axis - AC servo motor: 2.50 kW Rapid traverse (X/Y/Z): 7.5 / 7.5 / 5 m/min Rapid traverse (W): 3 m/min Infinitely variable feeds: 5 – 2000 mm/min Accuracy Positioning accuracy X, Y axis (over 1200 mm): ± 0.075 mm Electrical Data Operating voltage/frequency: 400 V / 50 Hz Control voltage: 24 V Hydraulic unit for clamping: 0.75 kW Total connected load: 13.0 kVA Weight (Danumeric 440, without packaging, with 1800 x 600 mm table): 2800 kg CNC Control Axes: 4 (X, Y, Z, W), expandable Processor: 32-bit CPU Display: TFT flat screen, backlit, easily readable from all sides, 215 x 160 mm Position indication: Cartesian or polar, absolute or incremental Measurement units: mm or inch or degrees Interpolation: 2 axes (X, Y) Technology Database: Tool management, tool suggestions based on machining operation, material-dependent cutting data suggestions Tool management: max. 500 tools Subprogram function: yes Machining Cycles Standard software options: Conversational programming, 38 reference point shifts, rotation and mirroring, teach-in for X, Y, Z, program restart with selectable entry functions Zero point determination: cycles for determining reference points by manual probing of the workpiece for: - Arbitrary clamped rectangular parts - Arbitrary clamped round parts - Centering of cast and flame-cut parts - Angle position detection for round parts by probing reference edges or surfaces Test graphics: Graphical display of drilling patterns

Condition: good (used), Year of construction: 2003, functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, Machine configuration • Work table 1200 x 750 mm with 5 T-slots • Arm travel 1050 mm • Drilling spindle SK 40 with tool clamping device • Infinitely variable spindle speed programming • Stepless quill feed via three-phase servomotor • 2 T-slots 18 mm at the rear of the machine base • 2 T-slots 18 mm on the left side of the machine base • Thread cutting device • Central lubrication • Coolant system • Machine lamp • CE marking • Safety device Dimensions and Travel Ranges Tool holder SK 40 Column diameter mm 195 Table size mm 1200 x 750 Number of T-slots 5 Distance between T-slots mm 125 Quill travel (Z-axis) mm 200 Column travel (W-axis) mm 410 Distance spindle lower edge – table top min mm 70 / max mm 680 Distance spindle lower edge – floor min mm 970 / max mm 1580 Drilling radius mm 540 - 1590 Working table height mm 900 Machining Capacities Drilling capacity solid St 60 Ø 40 GG 22 Ø 50 Thread cutting St 60 M 36 GG 22 M 42 Main Spindle Drive AC motor, frequency controlled kW 5.5 @ 100% duty cycle Speed range: min⁻¹ 15 - 2800 Torque Nm max. 250 Constant from min⁻¹ 15 – 2000 Feed Drives X-axis AC servo motor kW 0.25 Y-axis AC servo motor kW 0.25 Z-axis AC servo motor kW 4.50 W-axis AC servo motor kW 2.50 Rapid traverse speeds (X/Y/Z): m/min 7.5 / 7.5 / 5 Rapid traverse speed (W): m/min 3 Feed rate stepless mm/min 5 – 2000 Accuracy Positioning accuracy X, Y axes over 1200 mm mm ± 0.075 Electrical Data Operating voltage / frequency V / Hz 400 / 50 Control voltage V 24 Hydraulic unit for clamping kW 0.75 Total connected load kVA 13.0 Gisdpfxjyuqmio Ahvou Weight Danumeric 440 (without packaging) with table 1800 x 600 mm kg 2800 CNC Control Axes: 4 (X, Y, Z, W), expandable Processor: 32-bit CPU Screen: TFT flat screen, backlit, easily readable from all sides, 215 x 160 mm Position indication: Cartesian or polar, values absolute or incremental Units: mm or inch or in degrees Interpolation: 2 axes (X, Y) Technology database: Tool management, tool suggestions by machining operation, material-dependent cutting data suggestions Tool management: up to 500 tools Subroutine technology: yes Machining Cycles Standard software options: Conversational programming, 38 zero point offsets, rotation and mirroring, teach-in for X,Y,Z axes, program re-start with selectable functions for targeted entry Zero point determination: Cycles for zero point determination by manual probing of the workpiece for: - arbitrarily mounted rectangular parts - arbitrarily mounted round parts - alignment of cast and flame-cut parts - angular position detection for round parts by probing reference edges or surfaces Test graphic: Graphical display of drilling patterns.

Condition: like new (used), Donau Donauflex 135 High-Speed Radial Drilling Machine Manufacturer: Donau Model: Donauflex 135 Year of manufacture: 2020 Condition: Very good, used but like new Available immediately from stock. Godpfx Ajyucahjhvsiu

Condition: refurbished (used), functionality: fully functional, table length: 1,200 mm, table width: 500 mm, spindle mount: MK 3, height adjustment type: electric, Donau DR23 Radial Drilling Machine – Robust Quality Machine For sale is a reliable Donau DR23 radial drilling machine, ideal for workshops, metalworking, or industrial applications. The machine impresses with its sturdy design, high precision, and versatile applications for drilling, countersinking, and thread cutting. Details: Manufacturer: Donau Model: DR23 Radial drilling machine overhauled by Vaumtec Quick-change chuck Stable cast construction Adjustable arm for flexible machining of large workpieces Suitable for steel, aluminum, and other metals Gjdpfxsyrtkxj Ahvjiu Forward and reverse rotation

Condition: ready for operation (used), Donau Danumeric 440 Radial Drilling Machine Drilling capacity (steel): Ø 40 mm Thread cutting: up to approx. M36 (depending on material) Tool holder: SK 40 Spindle speed: approx. 15 – 2,800 rpm (infinitely variable) Feed: infinitely variable approx. 5 – 2,000 mm/min Quill stroke (Z): 200 mm Column stroke (W): 410 mm Arm traverse: 1,050 mm Drilling radius: approx. 540 – 1,290 mm Arm swivel range: approx. 330° Column diameter: 195 mm You are welcome to arrange a viewing. We can also organize affordable shipping for you! You will receive a proper invoice. For international customers, a net invoice can be issued (a valid VAT ID number is required). Gijdpfsyrdc Sex Ahvsu Interim sale reserved. Visit our shop and take a look at our other offers. All company names and trademarks mentioned are the property of their respective owners and are used for identification and description purposes only. Technical data may vary and errors in the item description are reserved.

Condition: good (used), Year of construction: 1999, functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, • Worktable 1200 x 750 mm with 5 T-slots • Arm travel 1050 mm • Drill spindle Morse taper 4 • Infinitely variable speed control • Infinitely variable quill feed • Thread cutting device • 2 T-slots (18 mm) each, machine base rear and left • Machine lamp • Central lubrication • Table surface machined on all sides • Safety guard on drill • Coolant system Dimensions and Travel Tool holder MT 4 Column diameter mm 195 Table dimensions mm 1200 x 750 Number of T-slots 5 Godpoynt Ucofx Ahvjiu T-slot spacing mm 125 Quill stroke mm 220 Column stroke mm 450 Distance spindle nose to table min. mm 40 max. mm 710 Distance spindle nose to base plate min. mm 840 max. mm 1510 Drilling radius min. mm 540 max. mm 1590 Working table height mm 900 Machining Data Drilling capacity solid material St 60 Ø 45 mm GG 22 Ø 55 mm Thread cutting St 60 M 36 GG 22 M 45 Main Spindle Drive AC motor, frequency-controlled kW 5.5 at 100% duty cycle Speed range rpm 15 - 2800 Torque Nm max. 250 Constant from rpm 15 - 200 Feed Drives Feed, stepless mm/rev 0.02 - 0.7 Feed force N 12,000 Electrical Data Operating voltage / frequency V / Hz 400 / 50 Control voltage V 24 Total connected load kVA 9.3 Weight DANUFLEX 145 (without packaging) with 750 x 1200 mm table kg 2,600 Documentation Operating manual, incl. Lubrication and hydraulic diagram Electrical schematic

Condition: good (used), Year of construction: 1999, functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, • Worktable 1200 x 750 mm with 5 T-slots • Arm travel 1050 mm • Drill spindle Morse taper 4 • Infinitely variable speed control • Infinitely variable quill feed • Thread cutting device • 2 T-slots (18 mm) each, machine base rear and left • Machine lamp • Central lubrication • Table surface machined on all sides • Safety guard on drill • Coolant system Dimensions and Travel Tool holder MT 4 Column diameter mm 195 Table dimensions mm 1200 x 750 Number of T-slots 5 T-slot spacing mm 125 Quill stroke mm 220 Column stroke mm 450 Distance spindle nose to table min. mm 40 max. mm 710 Distance spindle nose to base plate Giedpfx Ahoylnpisvsu min. mm 840 max. mm 1510 Drilling radius min. mm 540 max. mm 1590 Working table height mm 900 Machining Data Drilling capacity solid material St 60 Ø 45 mm GG 22 Ø 55 mm Thread cutting St 60 M 36 GG 22 M 45 Main Spindle Drive AC motor, frequency-controlled kW 5.5 at 100% duty cycle Speed range rpm 15 - 2800 Torque Nm max. 250 Constant from rpm 15 - 200 Feed Drives Feed, stepless mm/rev 0.02 - 0.7 Feed force N 12,000 Electrical Data Operating voltage / frequency V / Hz 400 / 50 Control voltage V 24 Total connected load kVA 9.3 Weight DANUFLEX 145 (without packaging) with 750 x 1200 mm table kg 2,600 Documentation Operating manual, incl. Lubrication and hydraulic diagram Electrical schematic

Condition: refurbished (used), Year of construction: 2000, functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, • Worktable 1200 x 750 mm with 5 T-slots • Arm travel 1050 mm • Drill spindle Morse taper 4 • Infinitely variable speed control • Infinitely variable quill feed • Thread cutting device • 2 T-slots (18 mm) each, machine base rear and left • Machine lamp • Central lubrication • Table surface machined on all sides • Safety guard on drill • Coolant system Dimensions and Travel Tool holder MT 4 Column diameter mm 195 Table dimensions mm 1200 x 750 Number of T-slots 5 T-slot spacing mm 125 Quill stroke mm 220 Column stroke mm 450 Distance spindle nose to table min. mm 40 max. mm 710 Distance spindle nose to base plate min. mm 840 max. mm 1510 Drilling radius min. mm 540 max. mm 1590 Gsdpfxoyhdvke Ahvjiu Working table height mm 900 Machining Data Drilling capacity solid material St 60 Ø 45 mm GG 22 Ø 55 mm Thread cutting St 60 M 36 GG 22 M 45 Main Spindle Drive AC motor, frequency-controlled kW 5.5 at 100% duty cycle Speed range rpm 15 - 2800 Torque Nm max. 250 Constant from rpm 15 - 200 Feed Drives Feed, stepless mm/rev 0.02 - 0.7 Feed force N 12,000 Electrical Data Operating voltage / frequency V / Hz 400 / 50 Control voltage V 24 Total connected load kVA 9.3 Weight DANUFLEX 145 (without packaging) with 750 x 1200 mm table kg 2,600 Documentation Operating manual, incl. Lubrication and hydraulic diagram Electrical schematic

Condition: used, Year of construction: 1984, bore capacity in steel (diameter) 32 mm arm length 950 mm turning speed range 51 - 1000 U/min turning speeds steps 12 bore spindles - Morse Taper MK 4 quill stroke 160 mm feed range 0,075 x 0,3 mm/min table surface area 1200 x 510 mm total power requirement 2 kW weight of the machine ca. 1,9 t dimensions of the machine ca. 1,8 x 1,2 x 2,25 m High-speed radial end mill with - Thread cutting attachment - Vertical table 750 x 620 mm - Horizontal table 1200 x 510 mm Gjdpfx Ajyfwzbehvjiu - Emergency stop device - Documentation Machine-No. 445

Condition: refurbished (used), Year of construction: 2006, functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, • Work table 1200 x 750 mm with 5 T-slots • Arm travel 1050 mm • Drill spindle Morse taper 4 (MK 4) • Infinitely variable speed control • Infinitely variable quill feed • Thread cutting attachment • Two 18 mm T-slots each on rear and left of machine base • 3-axis digital readout • Machine lamp • Central lubrication • Table top machined all around • Drill guard • Coolant system Dimensions and Travels Tool holder MK 4 Column diameter mm 195 Table size mm 1200 x 750 Number of T-slots 5 T-slot spacing mm 125 Quill stroke mm 220 Column travel mm 450 Distance spindle nose - table top min 40 mm, max 710 mm Distance spindle nose - base plate min 840 mm, max 1510 mm Drilling radius min 540 mm, max 1590 mm Work table height mm 900 Machining Capacities Drilling capacity (solid) St 60 ⌀ 45 mm GG 22 ⌀ 55 mm Tapping St 60 M 36 GG 22 M 45 Main Spindle Drive AC motor, frequency controlled kW 5.5 at 100% duty cycle Speed range min⁻¹ 15 – 2,800 Torque Nm max. 250 Constant from min⁻¹ 15 – 200 Feed Drives Feed, stepless mm/rev 0.02 – 0.7 Feed force N 12,000 Electrical Data Giedpfex Uwpxex Ahvju Operating voltage / frequency V / Hz 400 / 50 Control voltage V 24 Total connected load kVA 9.3 Weight DANUFLEX 145 (without packaging) with table 750 x 1200 mm kg 2,600 Documentation Operating manual, incl. Lubrication and hydraulic system diagram Electrical wiring diagram
