Condition: like new (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: 4040, travel distance X-axis: 7,500 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 750 mm, total width: 3,000 mm, total length: 9,000 mm, total height: 2,000 mm, feed length X-axis: 7,500 mm, feed length Y-axis: 600 mm, feed length Z-axis: 645 mm, spindle speed (min.): 1 rpm, spindle speed (max.): 5,000 rpm, input voltage: 400 V, power of the servo motor: 13,100 W, Equipment: rotational speed infinitely variable, sliding door, CMA Drilling/Milling Machine – Efficient Processing for Metalworking Shops & Fabricators Nedpfx Afeyc R Rkocowc The CMA drilling/milling machine is the ideal solution for metalworking shops and fabricators aiming to process their components quickly, precisely, and economically. With the ability to directly import STEP data or program manually, workpieces can be produced without detours – perfect for single parts, series production, and special constructions. A processing length of up to 7,500 mm and a generous working envelope of 600 mm in both X and Y axes allow multiple parts to be clamped and machined in a single setup. This significantly reduces setup times and boosts productivity. An integrated 16-position tool changer provides maximum flexibility for variable machining operations and noticeably cuts cycle times. Your advantages at a glance: ✔ STEP import or manual programming ✔ Processing length up to 7,500 mm ✔ 600 mm in X and Y axes ✔ 16-position tool changer ✔ Multiple components clampable at once ✔ Ideal for steel and metal construction ✔ High productivity & short setup times

Condition: used, Year of construction: 2002, 17 METRES INFEED. GRIPPER FED. 14 METRES OUTFEED. Njdpfxex N Ibze Afcewc APS 1015 3 SPINDLE DRILLING MACHINE. KBS 1001 SAWING MACHINE. INFEED & OUTFEED CROSS TRANSFERS.

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, CMA automatic coordinate drilling machine type GRD 40 CNC 3030 table size: 3000x3000 mm X-axis speed: 18 m/min Y-axis speed: 12 m/min Z-axis speed: 5 m/min spindle-to-table distance: 160-660 mm table height: 770 mm Drilling capacity: Steel 60: 40 mm Cast iron: 40 mm spindle speed: 750-3000 rpm Nedow Tidkopfx Afcswc Spindle taper: BT40 motor power: 7.5 kW total machine weight: 8,500 kg

Condition: used, Year of construction: 2008, Used CMA drilling center Njdpfswc Ndwox Afcowc Type: TRD 40 CN 9000 Table length: 9000 mm Maximum capacity: 40 mm Automatic tool changer Year of manufacture: 2008

Condition: used, Year of construction: 2008, Technical details: Njdpovb Drhjfx Afcowc bore capacity in steel (diameter): 100 mm max. pitch circle: 7000 mm number of spindles: 2 bore spindle turning speed range: 1 - 3000 U/min high speed spindle taper ISO: 50 bore slide stroke: 900 mm feed speeds: 1 - 6000 mm/min max. workpiece weight: 18000 kg total power requirement: 125 kW dimensions of the machine ca.: 13 x 11 x 5,1 m with CNC SIEMENS 840 D Workpiece clamping up to dia. 7000 mm The machine is equipped with 2 drilling spindle supports and through spindle coolant (50 bar)both supports can drill simultaneously. Spindle taper SK 50, 2 stages 1 -600 rpm 1650 Nm and 1 - 3000 rpm. 300 Nm Chip conveyor and coolant device *

Condition: used, TECHNICAL DETAILS Nwedpfx Asuhab Hjfcsc * Spindle speeds : 200-20000 [rpm] * Travel : 38 [mm] - Distance table/spindle axis : 89 [mm] - Table dimensions : 182 x 300 [mm] - Machine height : 342 [mm] EQUIPMENT - Collets set

Condition: new, Year of construction: 2024, travel distance Y-axis: 600 mm, travel distance Z-axis: 450 mm, - Simple graphic programming, including GoTo function in manual mode - Machining lengths from 3000 - 16500mm, depending on version - Free programming in DIN/ISO (G commands) - 2-axis interpolation for X/Y-axis, including arcs - 3-axis linear interpolation (X/Y/Z) - 3-axis interpolation (X/Y/Z) for helical milling and thread milling Nsdpfx Afsrb Afaocswc - Rapid traverse X-axis = 30 m/min., Y-axis = 25 m/min. Main spindle BT 40 - 5 bearings, diameter 110/60 mm (3x angular contact ball bearings 7212, 2x deep groove ball bearings 6212) - Suitable for both high axial and radial loads = drilling and milling - Maximum tool length : 290 mm - Maximum tool diameter : 88 mm Guide X-axis - 2 pieces 45 mm linear guides with 2 full ball bearing carriages each X-axis drive - helical precision rack, travel 3,000 to 16,500 mm Y-axis guide - 2 35 mm linear guides, each with 2 fully spherical carriages Y-axis drive - Ball screw diameter 25 mm, travel 600 mm Z-axis guide - 2 35 mm linear guides, each with 2 fully spherical carriages Z-axis drive - Ball screw diameter 32 mm, travel 450 mm Standard version Automatic tool changer with 10 positions, mounted in the machine column

Year of construction: 2000, condition: good (used), Weight: 4600 kg Dimensions LBH: 4350 x 1070 x 2690 mm Saw blade dimensions: 8250 x 54 x 1.6 mm Fright basis: EXW with disassembling Price: on demand Nodpohkhumofx Afcewc The 2000 Kaltenbach KBS 1001 DG band saw is a semi-automatic, high-performance band saw for cutting and drilling profiles. The Kaltenbach band saw has a two-metal saw blade M42 measuring 8250 mm x 54 mm x 1.6 mm. The motor of the saw is frequency controlled and has a driving power of 7.5 kW. The cutting speed is continuously adjustable between 16 - 100 m / min. -Working height is 450 mm, working width 1000mm. -drill diameter:10- 40 mm -material dimension max: 1000mmx450mm -material dimension min:65mmx65mm -3 drilling axes, one vertical and one horizontal -drill feed rate of 20-200mm/min -5 tool changer position per axis with an iso 40 tool holder The machine can transmit data in different ways: 1. The operator is programmed directly on the control panel. 2. The data is entered into the job preparation via computer and then imported as a CSV file. Data transfer takes place via a floppy disk or network. 3. Data are entered using CAD programs. DSTV data is imported via a floppy disk or network.
