Condition: used, Year of construction: 2007, HOLZ-HER – 6310 CUT 110 580 Computer-controlled Panel Saw Watch the video of the machine: Year of manufacture: 2007 Machine number: 136 The machine has been overhauled in all essential mechanical components. New PC, new label printer, etc. in 2023 Technical Specifications and Description: Base machine: Pressure beam saw Version: Fence on the right Saw cycle: away from the fence Cutting length: 5,850 mm Cutting width: 5,850 mm Saw Blades: Main saw blade Ø 400 x 4.4 x 30 mm, Z72, FZ/TZ (not included!) Tungsten carbide pre-scoring blade Ø 180 x 4.4/5.4 x 30 mm, conical (not included!) Cutting Height Cutting height: 110 mm Saw blade projection: 120 mm Pressure beam: pneumatic, pressure adjustable Extraction: Central moving dust channel on the unit Extraction port base machine: 1x Ø 160 mm, positioned on the right side Dust channel in pressure beam: 2x Ø 120 mm – 1x top left, 1x top right with cutting length 5,850 mm: 3x Ø 120 mm – 1x top left, 1x top center, 1x top right Extraction air velocity: 30 m/s Air volume: 4,000 m³/h at 30 m/s Compressed Air Air consumption approx. 32 l/min at 6 bar per cutting cycle Switchable collet chuck pressure Switchable from the control panel For sensitive panel materials Automatic cutting length limitation The saw unit detects the workpiece end using a non-contact sensor and optimizes the cutting cycle Offcut device For cutting without leftover piece Clamps retract into recessed pressure beam Width Stop Precision-guided, freely programmable width stop with clamps Rack-and-pinion drive for precise positioning With surface-hardened linear guides Return speed of panel pusher: 80 m/min Forward speed of panel pusher: 80 m/min (EU – max. permissible forward speed 25 m/min) Max. opening for clamps: 120 mm for longitudinal and cross cuts Clamps, floating design Compensate for internal stress in panel packs upwards – 6 pcs for 3,250 mm cutting length – 7 pcs for 4,250 mm cutting length – 8 pcs for 5,850 mm cutting length Control CUTCONTROL 2 with 15" TFT display Operating system Windows 2000 RJ45 network connection 10/100 Base-T Fast Ethernet Intel Celeron processor Midi tower US keyboard Nedpfxsw I Uxpj Ah Dodd Optical mouse CD ROM drive Control panel located on fence side Clearly arranged graphic-based operator interface for easy handling and order/material management on Windows basis Realtime display Large, clearly structured buttons All functions accessible from one level No limits in input fields and unlimited job inputs possible Control Functions Direct Cut: Cutting by direct entry of cutting dimensions. Processing of absolute, serial, or format cuts, with integrated grooving, notching, or positioning cuts. Unlimited jobs programmable. Job prioritization (prioritization possible at any time). Order programming parallel to cutting. NC Cut: Processing of optimized jobs. Graphical machine overview with machine process flow function ...

Condition: used, Year of construction: 2002, functionality: fully functional, machine/vehicle number: 19711, cutting length (max.): 5,300 mm, saw blade diameter: 294 mm, cutting height (max.): 2,200 mm, collet bore: 30 mm, overall weight: 1,050 kg, power: 4.5 kW (6.12 HP), The vertical panel saw features a solid and compact structure to ensure stability during operation. This configuration allows for consistently high cutting quality, even on large or particularly challenging materials, delivering smooth and linear movements for safe and efficient work. The machine is supplied with 29 blades, each with 50% remaining service life. Transport not included. Ndsdpswqmyrefx Ah Dod

Condition: new, Year of construction: 2025, Cutting length 3200 mm Ndsdpfx Ahewiipme Djd Cutting height 1600 mm Motor output 1,3 kW Dimensions (L/W/H) 4000x1500x2000 mm machine weight ab. 350 kg

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 6000x1150x2980 mm Weight 850 kg Total power requirement 3 kw Nedpfxovz E D Eo Ah Dsdd

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 6000x1150x2980 mm Ndodpfx Asvz Eukoh Dsd Weight 800 kg Total power requirement 3 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 5000x1150x2980 mm Weight 665 kg Nedpjvz Eudefx Ah Dsdd Total power requirement 3 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 6000x1150x2980 mm Weight 800 kg Nedpjvz Et Tjfx Ah Dsdd Total power requirement 3 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 5000x1150x2980 mm Weight 665 kg Total power requirement 3 kw Nedevz Ervjpfx Ah Dsdd

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 5000x1150x2980 mm Weight 665 kg Nodpfsvz Eihox Ah Dodd Total power requirement 3 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 6530x1150x2980 mm Nsdpfxevz Eg Hs Ah Djdd Weight 900 kg Total power requirement 3 kw

Condition: reconditioned (used), Year of construction: 2007, functionality: fully functional, cutting length (max.): 5,750 mm, cutting height (max.): 120 mm, cutting width (max.): 2,600 mm, main saw diameter: 460 mm, power: 27 kW (36.71 HP), Machine type: fh6 580 HT260 ERB-L / MCS-Evolution / Win 10 Cutting length: 5.750 mm Ndedovx Ru Depfx Ah Dsd Cutting width: 2.600 mm Year of construction: 2007 Saw blade projection max .: 135 mm Saw blade diameter max .: 460 mm Main saw motor: 27 kW Scorer aggregate Scorer saw blade diameter max .: 200 mm Package height max .: 120 mm Package height min .: 3 mm Saw aggregate forward: 6 up to 150 m / min Saw aggregate backward: up to 150 m / min Feeder: up to 80 m / min (Europe: forward 25 m/min acc. EN 1870-13) Number of clamps: 8 pcs grip push clamp Clamp opening: 125 mm Lifting / lowering device for clamps Strip aligner before and after the pressure beam Air cushion tables: 1 pcs. (2100 x 700 mm) Turn table: 1 pcs. (5800 x 2200 mm) 90° turnable Machine table: heavy-duty steel construction „Closed Frame Construction“ machine table surface is precision machined Machine table lips Automatic cutting length adjustment Lift table, max. panel width: 2600 mm Feeding roller conveyor: 7100 x 2600 mm Recesses for forklift trucks: 2 pcs Frequency converter for feeding roller conveyor Positioning stop: 2 pcs Push-off trolley Push-off device: 3 pcs Book aligning device for longitudinal board edges: 3 pcs Retaining device: 3 pcs Roller table Cross alignment stop at the roller table This machine is in very good conditions and works very well. The machine is reconditioned, checked and tested in our company. Errors and alterations in the technical datas and informations excepted! (displayed photos are symbol photos)

Condition: used, Year of construction: 1984, used Make Holz-Her Type 1215 Year of manufacture 1984 Motor 4.0 kW Cutting length approx. 5300 mm Cutting height approx. 2200 mm Center support Ndjdpfevwgi Iex Ah Dsd Saw blade diameter approx. 300 mm, cutting depth 80 mm Free-standing Slatted frame moves away Storage location 97447 Gerolzhofen, free loading, unpacked Handed over in the current condition as viewed, without guarantee or warranty

Condition: used, Year of construction: 1985, used, good conditionmake Striebigtype 6220 Ayear of manufacture approx. 1985motor 4.4 kWcutting length approx. 5300 mmcutting height approx. 2100 / 2200 mmcenter supportcutting depth 80 cmsaw blade diameter approx. 303 mmwall mountingslatted frame moving awaysupport rails woodsuction connection D 120 mmspace requirement approx. 6300 mm x 1250 mm x 2720 mmWeight approx. 1200 kgTotal connected load approx. 4.4 kWStorage location 97447 Gerolzhofen, free loaded, unpackedHandover as seenwithout guarantee and warranty Nodpfxsvwfgxj Ah Dedd

Condition: used, Year of construction: 2023, Cutting length ca. 5300 mm Nsdovwfcaspfx Ah Dodd Cutting height ca. 2150 mm

Condition: excellent (used), Numerical Control Power Control + Software Cadmatic 4 Professional No. 1 Infeed roller tracks (ca.) 32,000 mm Lifting table (mm) 5600 x 2200 VAC loader (sliding bridge) with fan suction for loading special or delicate panels 1° Rear-pusher, with No. 6 clamps/grippers Turning device (rotating unit) at 90° 1° Panel Saw - Max cutting width mm 5600 (cutting line with air cushion) Max blade projection (mm) 190 Scoring Unit (max. diameter saw / power) mm 200 (Kw 2,2) Main Sawing Unit (max. diameter saw / power) mm 600 ( Kw 36) Adjustable speed of the saw carriage (QS) (m/min) 1 - 130 m/min 2° Rear-pusher, with No. 14 clamps/grippers 2° Panel Saw - Max cutting width mm 2200 (cutting line with air cushion) Max blade projection (mm) 190 Scoring Unit (max. diameter saw / power) mm 200 (Kw 2,2) Main Sawing Unit (max. diameter saw / power) mm 600 (Kw 36) Adjustable speed of the saw carriage (QS) (m/min) 1 - 130 m/min Waste evacuation system with grinder (Kw 19.5) Nsdpfx Ahevnq H Eo Dodd No. 2 Front supporting tables with Air blowing system (mm 800 x 2160) Plastic wheels coated with special material to avoid scratching delicate panels Automatic unloading System of the cut panels: N° 2 x Liftomat HAU-A 25/12 Automatic Stacking System with 8 stations

Condition: not inspected (used), Year of construction: 1998, functionality: limited functionality, machine/vehicle number: 13189, VERTICAL PANEL SAW WITH ELECTRIC MOVEMENTS & DIGITAL DISPLAYS FOR CUTS Brand: GMC MACCHINE SRL Model Type: KGS 660S Serial No.: 13189 Year: 1998 (Photos taken prior to any potential refurbishment, machine offered as-is) MACHINING CAPACITIES: - Max. horizontal cutting length: 5300 mm - Max. horizontal cutting height: 2100 mm - Max. vertical cutting height: 2200 mm - Max. cutting depth: 80 mm OTHER FEATURES: - Power supply: 380V Three-phase+T - Installed power: 7.5 kW - Main motor power: 4.4 kW (6 hp) - Saw blade speed: 5,200 rpm Pneumatic blade feed - Carbide-tipped saw blade: Ø 300 mm, bore Ø 30 mm - Welded steel frame, PVC slat frame with automatic retraction via pneumatic cylinders - Fully lengthwise pneumatic retractable intermediate support with 2 adjustable and retractable stops - Retractable rollers for panel handling - Pneumatic locking of the saw carriage - 8 bar pneumatic feed - Digital display for cuts - Complete extraction system DPS Back cover spans the entire rear of the machine Lower longitudinal channel for sawdust collection Multiple extraction points in the lower section Extraction port: Ø100 mm - Support for floor-mounted installation - CE Marked Total space required when mounted on supports: 6300 x 1600 x 3040 mm (includes operator and maintenance area) Njdpfx Ahou R Ulhe Dedd Transport dimensions, 2 packages: . 1 frame 6300 x 860 x h.2620 mm . 1 pallet 3150 x 1000 x 1000 mm Total weight: 1250 kg Please contact us for supply of consumables, accessories, and/or extraction systems. Offered as a lot, without refurbishment or warranty. Ex works price, excluding VAT. Transport and services on request.

Condition: good (used), Year of construction: 2005, Panel saw Schelling FMH580 Year 2005 Without lifting table Saw blade diameter 450 mm Scoring saw blade diameter 200 mm Saw blade over table max 125 mm Clamping opening max 113 mm max package height 110 mm min package height 15 mm Motor power main saw 50 Hz, 19 kW Working height 970 mm Overall height 2070 mm Panel lengths / widths: Njdpfx Ahjq Apige Dedd Fiber cement board max 2500 / max 1250 mm Plywood/ chipboard/ OS boards 2400- 5600 / 1200 - 2600 mm

Condition: used, Cutting length 4300 mm Cutting height 2150 mm automatic , ELCON precision panel saw type D 215 ----- Cutting height: vertical 2,150mm, horizontal 2,100mm Cutting length: 4,300mm ----- Technical description: Cutting depth: max. 60mm Saw blade outlet behind the plate: max. 25mm Saw blade: diameter 250mm, bore 30mm, Z=48 hollow roof tooth Ndedpoi Hc S Djfx Ah Ded Saw blade rotation: 5,100 rpm. Motor: 4 kW (S 6) Measurement reading for: horizontal saw cuts: via scale and strip cutting stop vertical saw cuts: above scale Extraction nozzle: 100 & 80mm Required air pressure: 6 bar Features: -Material support with 1 roll per meter of cutting length, switched on and off by foot pedal suspendable -1 infeed and outfeed roller -pneumatically yielding slatted frame -Central support, 1 support element per meter of cutting length, individually manually fold out -Scoring system: double cut of the main saw blade - Torsion-free, free-standing machine frame -Two folding stops for vertical saw cuts (above and below the middle support) ----- Special price "Partnership Edition" ex works in this version: on request! ----- plus pre-freight, freight, installation and instruction (if the machine does not have to be dismantled) Applies only within Germany. Unloading and cross transport to Installation location is determined by the customer. Price: EUR 1,900.00 plus statutory VAT ----- Options with extra charge: Cutting length 5,300mm instead of 4,300mm Order number: ELCO0075/O049 Surcharge: EUR 2,590.00 plus statutory VAT ----- Technical information according to the manufacturer - without guarantee!
