Günthner Schleiftechnik GmbH

Condition: good (used), Year of construction: 2005, functionality: fully functional, Technical details measuring range X-axis 300 mm measuring range Y-axis 250 mm measuring range Z-axis 600 mm weight 700 kg dimensions of machine 2600 x 1400 x 1900 mm coolant tank 800 x 600 x 920 mm Additional information Presetting, shrinking and measuring machine Dcjdpeyrnrkofx Ah Ijd Software saturn 1 Zoller Multivision II Without toolholders. On 30. May 2022 the machine was checked by a technician from ZOLLER. Shrinking is currently not possible. The induction spool and the control unit for it must be renewed. The purchase price of a comparable new machine (incl. software) from ZOLLER is approx. 100.000 EUR, with a current delivery time of approx. 52 weeks !

Condition: used, Year of construction: 2009, measuring range X-axis 0 - 160 mm Dcjdpfx Ahsynbfio Ijd measuring range Z-axis 0 - 300 mm tool adaptor SK 40 / BT 40 Resolution 0,001 mm Ambinent temperature 0 - 45 °C dimensions of the machine ca. 0,60 x 0,50 x 0,85 m weight ca. 60 kg Tool Presetter PWB - Tool Master 10 - incl. Measuring Electronics TC100

Condition: used, Year of construction: 2016, measuring range X-axis 0 - 200 mm measuring range Z-axis 0 - 300 mm Dcjdpoynbfcofx Ah Ied tool adaptor SK 40 / BT 40 Resolution 0,01 mm repeating accuracy 0,01 mm Ambinent temperature 0 - 40 °C dimensions of the machine ca. 0,30 x 0,19 x 0,64 m weight 44 kg Tool Presetter KELCH - set line V123

Condition: used, Year of construction: 1999, functionality: unexamined, machine/vehicle number: 5072, Used tool presetting device Dcsdpeyklypefx Ah Ied Manufacturer: KELCH Model: Kalimat a 1010 Year of manufacture: 1999

Condition: ready for operation (used), Year of construction: 1986, functionality: fully functional, total width: 550 mm, total length: 1,160 mm, total height: 950 mm, overall weight: 200 kg, MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 1,160 x 550 x 950 mm Net weight: 200 kg Djdpfx Ahjyf A Aks Iscd

Condition: used, Year of construction: 2003, travel -x axis 180 mm Dcedpfx Ahsydqnfs Isd travel -z axis 370 mm Total weight, approx. 65 kg dimensions of the machine ca. 2,0 x 1,2 x 2,0 m Tool Presetter DMG Microset - ECO 1

Condition: used, Year of construction: 2003, travel -x axis 300 mm Dodpfx Ahsydqm Us Ijcd travel -z axis 400 mm tool taper VDI 40 / VDI 50 Total weight, approx. 141 kg dimensions of the machine ca. 1,2 x 0,8 x 0,85 m Tool Presetter ULMER - Präzisa 400

Condition: used, Year of construction: 2011, functionality: limited functionality, machine/vehicle number: 782, Technical characteristics: Measuring Capabilities - Measuring range (Z-axis): 600 mm (≈ 23.6") - Measuring range (X-axis): 200 mm (≈ 7.8") - Max. tool diameter: 400 mm (≈ 15.7") - Snap gauge diameter: Up to 100 mm (optional) Performance Features - Spindle type: High-precision SK50 spindle with integrated calibration surfaces - Spindle locking: Power-operated brake with 4 × 90° indexing - Image processing: ZOLLER »pilot« software (version 3.0) Dedpfxjyanf Ts Ah Iecd - Camera: CCD with telecentric lens and 20× magnification - Cutting edge detection: Automatic, including edges >90° - Focus system: Analog focus display with dynamic cross hairs Control & Interface - User interface: Touchscreen with graphical guidance - Manual control: Ergonomic »eQ« single-hand operating handle - Fine adjustment: Electronic control for X and Z axes - Data transfer: RFID tool identification, label printing, and CNC integration Construction & Environment - Frame: Lightweight metal with optimal thermal conductivity - Scales: Heidenhain glass scales for high measurement accuracy - Software options: Tool management, adapter calibration, concentricity/run-out programs - Mounting/Measurement interfaces: # HSK63 # HSK100 # ISO40 # ISO30/BBT30 # BMT55 Machine status: FUNCTIONAL in manual mode only. For optimal performance, overhaul by the machine supplier is recommended.

Condition: used, Tool presetting device for SK50 / SK40. Used, detailed inspection cannot be carried out by us. Dcedpfxjxyzx So Ah Ied

Condition: used, functionality: fully functional, measuring range X-axis: 500 mm, measuring range Y-axis: 300 mm, Zoller tool presetting device with adapter for SK50, SK40, SK30; turning: VDI30, VDI40, and VDI50. Still in operation, can be tested on site. Dsdpfx Aexlbc Ijh Ijcd

Condition: used, Technical details: Heating: 15 kW rated current: 28 A Heating capacity: 15 kW current: max.71 A cooling water consumption: 11 l/min frequency range: 10-25 kHz frequency range: 50/60 voltage: 400-480 +-10% V current- max.: 3020 A weight: 406 kg dimensions L x W x H: 1,25 x 0,8 x 1,6 m Dedpjxfvldefx Ah Iscd The device is a mobile induction heater with medium power (15 kW), suitable for: Local heating of metals (e.g., bearings, bolts, screws, pipes, sheet metal edges). Preheating for welding processes Soldering and shrinking applications Heat treatments (e.g., tempering or hardening of smaller components). Due to its frequency range of 10–25 kHz, the device is more suitable for medium to large workpieces, as the penetration depth at these frequencies is higher than with high-frequency systems. *

Condition: excellent (used), consisting of: 2 pcs, item no. 47155: Makro Grip 125 centering vice, clamping range 155 mm 1 pc, item no. 41350: Extended stamping station 1 pc, item no. 41010: Center-marking device for stamping station 16 pcs, item no. 45570: Mounting pins, diameter 20 mm 1 pc, item no. 47520: Double mounting body 1 pc, item no. 47355: Makro Grip 125 centering vice, clamping range 355 mm 1 pair, item no. 44251: Avanti base jaws 4 pcs, item no. 44258.76: Top jaw 77x126mm for Avanti 125 4 sets, item no. 45570.10: Spacer for mounting pins, diameter 20 mm 2 pcs, item no. 47255: Makro Grip 125 centering vice, clamping range 255 mm 1 set, item no. 47355-TG27: Twin-Grip retrofit kit for Makro-Grip 125 no. 47355 1 pc, item no. 47520: Double mounting body 1 pc, trolley for stamping station Dcjdsxauacspfx Ah Iod

Condition: good (used), Year of construction: 2002, measuring range X-axis 330 mm measuring range Z-axis 400 mm Dcsdpfx Ahsw N S Epj Ijd 1 tool presetter Make: KELCH, type: Kalimat C34, year 2002 Measuring range X/Z 330 x 400 mm Easy-Wrap Set measuring software 2 adapters VDI / HSK, tool table

Condition: good (used), Year of construction: 1998, measuring range X-axis 330 mm measuring range Z-axis 400 mm range L-W-H 880 x 520 x 990 mm Spindle type: SK 50 (pneumatically fixable, 4×90°) Measuring systems: Heidenhain optoelectronic (LS series) Measurement: via integrated projector (20× magnification) Dcedpfx Ahsw Ht R As Ijd Device weight: approx. 250 kg

Condition: used, Year of construction: 2003, measuring range X-axis 300 mm measuring range Y-axis 290 mm measuring range Z-axis 650 mm tool diameter SK 50 mm Number of revolutions 30 U/min max. workpiecediameter 300 mm Dodpfx Ahjw E Np Ss Ijcd max. workpiece length 500 mm max. workpiece weight 40 kg accuracy +/- 0,002 mm Working speed X/Y/Z: 80 mm/s dimensions of the machine ca. 2,5 x 2,0 x 2,5 m weight of the machine ca. 1,2 t total power requirement 1 kVA Tool-Presetter WALTER - Heli Toolcheck

Condition: used, Year of construction: 1998, measuring range X-axis 330 mm measuring range Y-axis 400 mm weight of the machine ca. 0,250 t dimensions of the machine ca. 0,88 x 0,52 x 0,99 m Tool presetter - year of manufacture 1998 Workshop PC - year of manufacture 2008 Label printer - year of manufacture 1999 --> Measuring axes 2 precision guides on both axes in a recirculating ball bearing system with maximum load capacity, each with 2 recirculating ball bearings per guideway, preventthe measuring slides from yawing and pitching. --> Optoelectronic measuring systems Heidenhain LS, centred in both measuring axes for position determination in the centre of the measuring slides. Dsdpfx Ahjw Ap Rqo Iscd --> Tool holders Hardened SK 50 tool spindle with taper in gauge quality, mounted in precision roller bearings for maximum concentricity and reproducibility. --> Rotation of the tool spindle can be pneumatically clamped at the touch of a button, Positioning 4x 90° for stationary tools via pneumatic index bolts. --> Scanning of cutting edges High-quality profile projector with 150 mm matt disc diameter and 20- x magnification for non-contact measurement and reliable reading of the cutting position in the projector. --> Rotatable and fixed crosshairs for checking the radius and angle of the tool cutting edge. - functional - not in need of repair incl. measuring computer, label printer, screen and keyboard

Condition: good (used), Year of construction: 2004, functionality: fully functional, measuring range X-axis: 316 mm, measuring range Y-axis: 120 mm, measuring range Z-axis: 315 mm, Zoller Hyperion 320EZ Tool holders for Miyano, Boley, and Index machines Dodpfx Ahswwl S Hj Iscd

Condition: excellent (used), Year of construction: 2018, Serial Number : H300F3-00120 Z-axis measuring range : 350 mm Dcodowhv Nwjpfx Ah Iod X-axis measuring range : 300 mm Machine weight : 250 kg Mouse and USB computer display Turret table available. Multiple tool holders can be mounted on the table Machine was purchased new but never used. Very good condition, never used

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, measuring range X-axis: 400 mm, measuring range Z-axis: 400 mm, incl. Image Controller for SK40 Dcsdpfx Ajwhdx Teh Isd

Condition: used, Year of construction: 1997, diameter - cutter special 30 mm draw-in arbor diameter 40 mm clamping height 310 mm circle diameter 80-300 mm weight 30 kg Dsdpfx Ajv Uchbsh Ijcd

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: SMILE420X-03746, Equipment: type plate available, Zoller smile 420 / pilot 4.0 Pilot 4.0 program HSK-63 tool adaptor Djdpfxjv Sz H Do Ah Iscd See brochure for further details Pick-up only

Condition: used, Year of construction: 1983, longitudinal travel 1 mm Dedeu Sbc Ajpfx Ah Ijcd cross travel 1 mm table length 1 mm weight of the machine ca. 0,5 t dimensions of the machine ca. 1,5x0,8x1,9 m

Condition: used, Year of construction: 2011, Technical details: measuring range X-axis: Länge: 0 - 160 mm measuring range Y-axis: Höhe: 0 - 425 mm Tool table: Auflage: Ø 95 mm tool taper: SK 50 Djdeu N Artopfx Ah Iecd tool taper: drehbar 360° weight: 12 kg dimension L-W-H: 420 x 165 x 775 mm This is a bench top unit. Application: Alignment of rotary milling tools. Measuring method: manual alignment with/via digital display Measuring bar manually movable Measuring beam transverse (X) 160mm and vertical (Y) 425mm movable with measuring sensor Measuring display: both axes digital, voltage 1.5 V (AA battery) *

Condition: used, Year of construction: 1990, Technical details: total power requirement: 125 VA / 50Hz machine weight approx.: 0,3 t dimension machine xH: 0,8 x 0,7 x 1,6 (mit Tisch) m This is a tabletop device according to the optical measuring method. - incl. under table Application: - setting of tools of NC lathes other features: - coordinate of the bridge adjustment=200mm - coordinate of the slide adjustment=350mm - enlargement of the projector 20x - accuracy of cutting adjustment on projector=0,005mm - smallest measuring length=0,002mm - lower edge of measuring holder up to table=150 - 170mm - reading the tool coordinates opt. -4 - table WxDxH: 545 x700 x 110mm - base frame with drawer: WxDxH: 586 x 700 x 730mm Dcedpfju N Ap Eex Ah Isd *

Condition: used, Technical details: x-travel: 100 mm Dodpfx Aheu N Aprs Iocd y-travel: 450 mm z-travel: 400 mm tool taper: SK 40 - Ø 22mm machine weight approx.: 138 kg dimensions L x W x H: 0,72 x 0,38 x 0,99 m characteristics: - measuring area longitudinal axis z=400mm, diameter x= Ø 200mm, diameter y = fixed - tool holder for SK 40 / SK 45 / SK 50, rotation area 360°, max. tools Ø 220mm, receptive cylinder Ø 80mm - dial gauge holder combinable for longitudinal path X and transverse path Y accessories: - 3 pcs tool tapers SK40 + SK45 + SK50 - 2 used dial gauges The device is on sale as described, on sale as is! *
