Condition: excellent (used), Year of construction: 2015, - Travel X=3000 mm, Y=1500 mm, Z=1400 mm - Heidenhain iTNC 530 with handwheel HR 410 - NC rotary table for multi-sided machining 1600 mm x 1250 mm - 1-axis NC universal drilling and milling head, for simultaneous and positioning positioning operation (A-axis, 45°-axis) - Motor spindle 7,000 rpm max. SK 50, 530 Nm spindle torque - Tool changing system SK 50 / 40 places for 400 mm long tools tools Fgodpfx Aexmr Uwjfpeh - Chip screws in X-axis, optimum chip transport - Chip conveyor (hinged belt conveyor) for transverse conveying, Fabr. Knoll, front ejection - Coolant supply 950 l, made by Knoll - Outside/inside air at the spindle - IKZ 60 bar for deep hole machining - Operating mode 4 - Full enclosure with safety glass panes with sliding doors, optimized for crane loading - Split sliding doors on the front side - Split sliding doors on the operator side - RMP 60 radio measuring probe - incl. washing gun - Short delivery time by arrangement, subject to prior sale - Used machine - Z-axis KGT renewed in September 2023 incl. bearings - Optional fixators and tie rods - optional commissioning/installation - optional transportation

Condition: reconditioned (used), Year of construction: 2014, Immediately available: Traveling column machine FS 1200 • Total travel X=12,000 mm, ideal for flexible large-scale machining • Travel X=12,000 mm, Y=1,500 mm; Z=3500mm • Control iTNC 530 with wireless radio handwheel HR 550 FS, operator cabin on the traveling column • 2-axis NC universal drilling, milling head, fully simultaneous and positioning operation per traveling column • Spindle HSK-A 100, 10,000 rpm, 220 Nm spindle torque • IKZ air up to 6 bar • Dust protection packages to protect the guides and drives • BA 4 per traveling column • Radio measuring probe RMP 60, Renishaw make • Work area monitoring with network camera and monitor on the back of the system • Process monitoring ToolScope basic system • Additional control panel on the back of the system • Partial housing consisting of work area and sheet metal door, back with protective fence with a clear view into the work area • incl. fixators Fodoxmr Uqopfx Afpsgh • Cooling units • incl. internal tool cooling (closed cooling circuit) with Cooling unit • short delivery time, available immediately, ---subject to prior sale--- Viewing possible by arrangement Spindle hours: approx. 9079 SPECIAL PRICE!

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: 3589720, Equipment: chip conveyor, rotational speed infinitely variable, - 80 bar high-pressure pump - Spindle speed: 20,000 rpm - 38,237 operating hours - 10,169 spindle hours (a new spindle was installed at the beginning of the year) - The Y-axis is also new - A laser bridge from Blum - Magazine capacity: 60 tool stations - and Renishaw OMP 60 3D probe Fjdsxmr T Hopfx Afpjgh

Condition: good (used), Year of construction: 2004, Maho DMC 160 U Duoblock, year of manufacture 2004, Mill Plus control, X/Y/Z travel 1600/1250/1000 mm, double pallet 1,250 x 1,000 mm, spindle speed up to 10,000 rpm, SK 50 taper, 120-tool magazine, rack-type tool magazine, high-pressure coolant, chip conveyor, band filter, rotary table (C axis), horizontal/vertical head. Fgjdpfxjxmhzao Afpsh

Condition: good (used), Year of construction: 2010, Ref. -No.: 10530 Manufacturer: DöRRIES - SCHARMANN Type: Alpha 1000 Year of construction: 2010 Type of control: CNC Control: Siemens SINUMERIK 840 D Storage location: Halberstadt Country of origin: Deutschland X-Travel: 2000 mm Y-Travel: 2000 mm Z-Travel: 2000 mm A-Axis: 0 - 90 x 0,001 ° B-Axis: 360 x 0,001 ° Number of T-slots: 1 + 8 Max. Workpiece Weight: 5000 kg T - groove width: 22 mm T - slot spacing: 100 mm T-Slots: DIN 650 mm Tool Taper: HSK - A 100 Tool Piece Magazine With: 207 + 10 Pcs./pcs. Max. Torque: 1250 Nm Feed Speeds X/Y/Z Axis: 1 - 30000 mm / min Rapid Travel X/Y/Z: 30,00 mm / min Drive Capacity - Spindle Motor: 45 kW Total Power Requirement: 100 kW Dimensions Of The Machine Ca.: 13 x 8 x 4,5 m Size Of Pallet: 2 x 1000 x 1000 mm Spindle speed gear stage 1: 1 - 1096 1 / min Spindle speed gear stage 2: 1096 - 6000 1 / min Further information: - Measuring probe - Chip conveyor - Coolant system - Coolant through the spindle - Pallets with 5-way media connection and clamping hydraulics - Extraction system - Swivel spindle A-axis 0 - 90 - NC rotary table B-axis Fodpfxsxmd Tlj Afpjgh

Condition: used, Year of construction: 2005, travel distance X-axis: 8,000 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 850 mm, controller manufacturer: HEIDENHAIN, controller model: ITNC 530, total height: 3,300 mm, table width: 600 mm, table length: 8,930 mm, overall weight: 28,000 kg, spindle speed (max.): 15,000 rpm, space requirement length: 11,200 mm, space requirement width: 3,300 mm, CONTROLS .. CNC controls HEIDENHAIN ITNC 530 BASIC DESIGN .. basic design: moving column WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 5 .. X-axis travel: 8000 mm .. Y-axis travel: 700 mm .. Z-axis travel: 850 mm .. rotating range B-axis from: 90 ° .. rotating range B-axis up to: -90 ° .. distance of axis of horizontal spindle - clamping surface (max.): 1030 mm TABLE .. table surface (left-right): 8930 mm .. table surface (front-back): 600 mm SPINDLE / HEAD .. tool fixture: HSK A63 .. spindle revolutions (min): 30 /min .. spindle revolutions (max): 15000 /min .. tool fixture: HSK A63 .. drive power S6 40%: 30 kW .. spindle torque S6 40%: 143 Nm AXIS DRIVES .. traverse velocity X (max): 10000 mm/min .. traverse velocity Y (max): 10000 mm/min .. traverse velocity Z (max): 10000 mm/min .. rapid traverse X: 40000 mm/min .. rapid traverse Y: 40000 mm/min .. rapid traverse Z: 30000 mm/min TOOL MAGAZINE .. number of positions: 36 .. tool diameter max.: 85 mm .. - with free neighbour positions: 135 mm .. tool length max.: 400 mm .. tool weight max.: 10 kg .. tool changing time: 5 s ELECTRICAL SPECIFICATIONS .. mains power supply: 55 kVA .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 11200 mm .. space requirements -front/back-: 3300 mm .. total height: 3300 mm .. total weight approx.: 28000 kg Fgjdpfx Ajxmb D Ijfpeh ATTACHMENTS .. guideway covers: yes .. chip conveyor: yes .. coolant unit: yes .. band filtration unit: yes .. through spindle coolant attachment: yes .. closed cabin: yes .. European CE standards: yes X = 8000mm or 2x 3750mm pendulum stroke (vertical) - Internal cooling 40 bar - Coolant tank 800 liters - Belt filter - 3 D radio measuring probe - Raising the machine table by 70mm - Table load 1200kg/m² - Machines currently in storage and no longer powered - 2 round tables with clamping cubes

Condition: used, Year of construction: 2003, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,400 mm, controller manufacturer: HEIDENHAIN, controller model: ITNC 530, total height: 3,850 mm, overall weight: 24,000 kg, spindle speed (max.): 4,000 rpm, space requirement length: 13,500 mm, space requirement width: 5,000 mm, CONTROLS .. CNC controls HEIDENHAIN ITNC 530 Fodpfx Afexmb Dzjpjgh BASIC DESIGN .. basic design: bed type WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 5 .. .. among of them simultaneous CNC axes: 3 .. X-axis travel: 3500 mm .. Y-axis travel: 1200 mm .. Z-axis travel: 1400 mm TABLE .. workpiece load (max): 4000 kg .. - mode of operation: automatic SPINDLE / HEAD .. - positioning/indexing: 2.5 ° .. - positioning/indexing: 2.5 ° .. spindle revolutions (max): 4000 /min .. tool fixture: ISO SK 50 AXIS DRIVES .. rapid traverse: 20000 mm/min TOOL MAGAZINE .. magazin type: chain magazine .. number of positions: 30 ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 13500 mm .. space requirements -front/back-: 5000 mm .. total height: 3850 mm .. total weight approx.: 24000 kg ATTACHMENTS .. angular milling head: yes .. guideway covers: yes .. chip conveyor: yes .. through spindle coolant attachment: no - Includes complete tooling - The machine does not have an internal cooling system. - The table (centered) remains in place -> can be deselected and completely removed. - The left and right clamping cubes are not included.

Condition: used, Year of construction: 2003, x-travel 2.000 mm y-travel 1.000 mm z-travel 1.200 mm control TNC 430 Heidenhain turning speed range - main spindle 20 - 5.000 min/-1 transmission ratio 2 power capacity - main spindel 30 (100%) / 45 (40%) kW Torque 1.050 / 1.580 Nm tool taper HSK 100 swivellable B: +/- 180 ° indexing B: 0,001 ° table surface area 1.000 x 2.000 mm max. table load 4.000 kg flute distance 100 mm T-slots 18 H7 number of T-slots 10 number of toolpositions 40 pos. tool taper HSK 100 tool changing time 10 sec max. tool diameter 250 mm max. tool length 400 mm max. tool weight 20 kg feed speeds X,Y,Z: 0 - 20.000 mm/min feed speeds B: 10 1/min output X,Z: 15,7 / Y: 8,5 kW output B: 2,5 kW feed power 22'500 N weight of the machine ca. 23 t Fsdpfx Afoxmag Ijpsgh dimensions of the machine ca. 8,0 x 8,0 x 3,3 m 4-Axis CNC Machining Center - Universal REIDEN - BFR 22 - incl. 2x tool cabinets for collets - incl. 3x pull-out cupboards - incl. 1x workbench - incl. Ringler chip extractor

Condition: excellent (used), Year of construction: 2023, 5-Axis Machining Centre Brand: DMG MORI Model: DMF 300/8 Year: 2023 (1,600 spindle hours) CNC: Heidenhain Celios iTNC640, 21.5'' screen Equipped with: • Integrated rotary table diameter 800 mm / 800 kg • Spindle 46/30 kW – 15,000 rpm • 90-position tool changer • LEHMAN EA520 rotary indexer with tailstock • BLUM LC50 laser • PP60 Infrared probe • Through-spindle coolant 40 bar • Central paper filtration unit 980 litres • Automatic doors • Chip conveyor Specifications: • Table size: 3,300 x 850 mm • X-axis travel: 3,000 mm Fodpexl Ufcjfx Afpsgh • Y-axis travel: 800 mm • Z-axis travel: 850 mm • B-axis: -/+110° • C-axis: 360.000° • Spindle speed: 2 - 15,000 rpm • Spindle power: 46/30 kW • Spindle taper: SK 40 Big Plus • Rapid traverse X/Y/Z: 50 m/min • Machine dimensions approx.: 11,150 x 6,500 x H 2,650 mm • Weight approx.: 23,500 kg

Condition: excellent (used), Year of construction: 2004, CNC Machining Center Helme U 1130 Year of manufacture: 2004 Control: Heidenhain iTNC 530 With HSK 63 and swivel axis Technical data: Traverse paths (X, Y, Z): 1200 x 900 x 500 mm Spindle speed: 16,000 rpm Tool changer - number of positions: 28 -ICS (internal coolant supply) -Controlled B-axis in the milling head Fgsdpfsxl R Hijx Afpoh -Tool measurement -Chip conveyor

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: C121170, travel distance X-axis: 3,000 mm, travel distance Y-axis: 274 mm, travel distance Z-axis: 390 mm, rotational speed (max.): 20,000 rpm, spindle motor power: 4,000 W, For sale: furniture assembly line, total length 42 meters, with conveyor belt 70 cm wide. Fgjdexl Rx Sepfx Afpsh

Condition: ready for operation (used), Year of construction: 2021, Control Unit Brand HEIDENHAIN Model iTNC530 HSCI Main Drive Spindle speed range 20-28000 rpm Spindle motor power 55/43.5 kW (40/100%DC) Movement X-Axis Movement 1050 Y-Axis Movement 800 Z-Axis Movement 560 Additional Equipment Fjdpfxexl H Ens Afpogh Tool Taper: HSK-A63 DIN 69893 / Tool Magazine: 30-position disk tool magazine, 60-position pickup chain type Scraper Belt Chip Conveyor and Machine Bed Flushing / Separate Water Treatment Unit: 980-liter tank and paper filter / Pump: 40 bar / 23 l/min for internal cooling through spindle / Extended Chip Flushing / Rotating Inspection Window / Manual Coolant Flushing Gun / Internal Compressed Air Cooling: Through spindle / EROWA Pallet Handling System Preparation Documentation: English, Hungarian / Display Text: German/Hungarian / Screen Text: German/Hungarian DMG MORI Monitoring: D-ME406* DMG MORI Messenger V4 / DMG MORI Software Solutions: DMG MORI Service Agent, DMG MORI NETSERVICE, DMG MORI IoTconnector This 5-axis DMG MORI HSC 105 universal machining center was manufactured in 2021. It offers advanced capabilities for precision machining. Consider the opportunity to buy this DMG MORI HSC 105 universal machining center. Contact us for more information. Application Types Milling

Condition: excellent (used), Year of construction: 2016, operating hours: 26,678 h, functionality: fully functional, This machine is available exclusively through Montrasio GmbH and is being sold in the interest of the authorized parties. DMG DMU 100P duoBLOCK – 5-Axis CNC Machining Center (2016) Year of manufacture: 2016 Control: HEIDENHAIN Travel / Capacities X-axis: 1,000 mm Y-axis: 1,250 mm Z-axis: 1,000 mm Workpiece diameter: 1,100 mm Workpiece height: 1,600 mm Workpiece weight: up to 2,200 kg Table / Axes Table size: 1,100 × 900 mm Table rotation speed: 35 rpm Max. table load: 2,223 kg B-axis universal milling head swivel range: −30° to +180° Spindle / Tool Fgjdpfxoxl Arke Afpeh Spindle speed: 0 – 12,000 rpm Spindle motor power: approx. 69 HP (≈ 51.5 kW) Spindle taper: HSK-A100 Tool magazine: 63 positions Installation dimensions Footprint: approx. 24 m² Machine height: approx. 3,606 mm Machine weight: approx. 24,540 kg Accessories / Equipment CNC-controlled universal milling head (B-axis) Workpiece probe Tool measuring system 3D Quickset Chip conveyor

Condition: new, travel distance X-axis: 1,500 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 700 mm, controller manufacturer: SIEMENS 828D, controller model: SIEMENS 828D, spindle nose: SK50 DIN69871, TECHNICAL SPECIFICATIONS: Travel: - X-axis travel: 1500 mm - Y-axis travel: 800 mm - Z-axis travel: 700 mm Table: - Table dimensions: 1600 x 800 mm - Spindle-to-table distance: 160–860 mm - Maximum table load: 1500 kg - Number / Pitch / T-slot size: 22T x 7 x 110 mm Accuracy: - Repeat positioning accuracy: ±0.005/300 mm - Positioning accuracy: ±0.005/300 mm Spindle power 18.5 kW: - Standard spindle speed: 6000/8000 rpm (optional) - Spindle motor power: 18.5 kW - Spindle drive type: Belt drive - X/Y/Z axis drive: Direct drive - X/Y/Z axis motor power: 4.5/4.5/4.5 kW Automatic Tool Changer: - Tool capacity: 24 - Tool holder type: SK50 DIN69871 Fsdpfx Afoxlyzvspogh - Maximum tool weight: 15 kg - Maximum tool diameter: 200 mm - Maximum tool length: 300 mm

Condition: used, Year of construction: 2018, CNC machining center ELUMATEC SBZ 607 equipped with 11 tool stations (9 motors + 2 screwdrivers), designed for all main standard machining operations on window and door profiles. It enables milling operations such as drainage slots, lock cases, recesses for mounting plates, ventilation holes, as well as drilling for reinforcement brackets, transoms, tilt-and-turn locks, pins, and accessories. It is also prepared for free-form milling of gasket grooves and marking of closing components. Technical specifications: Tool stations: 11 Fodpfx Asxltxhefpogh Maximum profile length: 4,000 mm Maximum profile depth: 400 mm Spindle speed: 24,000 rpm Perfectly suited for the complete processing of aluminum or PVC profiles, ideal for window and door manufacturers or industrial producers.

Condition: ready for operation (used), Year of construction: 2017, operating hours: 29,532 h, General Data Machine weight 27750 kg Control Unit Brand HEIDENHAIN Model iTNC 530 Main Drive Spindle speed range 10000 Tool taper ISO 50 Number of axis 5 Movement X-Axis Movement 2600 mm Y-Axis Movement 1100 mm Fgedpfexllmdox Afpeh Z-Axis Movement 900 mm Table Table load 4000 kg This 5-axis DMG MORI DMF 260-11 Linear was manufactured in 2017. It features a large table (3200 mm x 1100 mm), high load capacity (4000 kg), and extensive axis travel (X: 2600 mm, Y: 1100 mm, Z: 900 mm). With a spindle speed up to 10,000 rpm and a 60-pocket tool magazine, it's ideal for complex machining tasks. If you are looking to get high-quality milling capabilities consider the DMG MORI DMF 260-11 Linear machine we have for sale. Contact us for more information. Application Types Milling

Condition: good (used), Year of construction: 2003, operating hours: 17,500 h, functionality: fully functional, travel distance X-axis: 1,800 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,100 mm, spindle speed (max.): 10,000 rpm, Equipment: chip conveyor, Used 5-axis machining center from DMG with low spindle hours DMG Deckel Maho DMU 200 P Year of manufacture: 2003 Condition: Good and fully functional Spindle hours: 17,580 Control: Heidenhain iTNC 530 X-travel: 1800 mm Y-travel: 2000 mm Z-travel: 1100 mm Technical specifications: - Rotary table D1400 x 1700 mm - Table load capacity 6,000 kg - B-axis - 60-position tool changer - SK 50 - 10,000 rpm - ICS (internal coolant supply) - 980 liter coolant tank - Chip conveyor - Rinse gun - Infrared probe Transport and commissioning can be offered separately. Fedpfx Afsxlifqspogh Interim sale reserved. No guarantee is given for the technical details provided here. Statutory provisions apply.

Condition: ready for operation (used), Year of construction: 2005, Available immediately from CH location : 5 axes machining center Reiden Type Reiden BRF 1 Year of construction 2005 Spindle renewed in 2022 ( 28.000.-Euro ) CNC control Heidenhain iTNC 530 Electronic handwheel Table diameter 800 mm Table load 800 kg Fgjdpfxoxlfa Re Afpeh X axis 1200 mm Y axis 600 mm Z axis 700 A axis minus 180 pkus 180 degrees B axis minus 90 plus 90 degrees SK 40 Magazine 72 places IKZ 20 Bar Number of controlled axles 5 Power on the spindle 25 kw Spindle speeds 0 - 6300 rpm Feed x axis 20000 mm / min Feed Y axis 20000 mm / min Feed Z axis 20000 mm / min Coolant device Chip conveyor Weight 9 to At a price of Euro 36.500.---plus VAT ex location

Condition: good (used), Year of construction: 1998, AXA VHC-3-M/K 5-Axis Universal Machining Center Year of manufacture: 1998 Control: SIEMENS 840C Machine number: 85667 Travels: Longitudinal X-axis: 1,200 mm Transverse Y-axis: 700 mm Vertical Z-axis: 800 mm B-axis: -90° to +90° C-axis: 360,000° Spindle overhaul due: 08/2025 Equipment: Swivel head -90 degrees to +90 degrees, indexed at 2.5-degree increments NC rotary table, brand SEMPUCO, 400 mm Spindle speed: 40 – 6,000 rpm / 17.2 kW 22-position tool changer Internal coolant through spindle External coolant Paper band filter Chip conveyor Scope of delivery includes: Documentation / machine parameters on data carrier Equipment, technical data, and transport details – see PDF. Illustration, content, and information provided without guarantee and therefore non-binding. Fodpfxjxlckgj Afpjgh All other accessories visible in the photos and videos are not included in the scope of delivery and are thus not part of this sale. The scope of delivery only includes the accessories explicitly specified here, in the order confirmation, and on the invoice. FCA (Free Carrier – loaded on truck) D-92729 Weiherhammer Packaging only Delivery time: December 2025 Subject to prior sale / Payment due immediately upon completion of purchase

Condition: good (used), Year of construction: 2012, EiMa ALPHA T CONTURA 5-Axis Universal Machining Center Year of manufacture: 10/2012 Control system: SIEMENS 840D sI 720 NCU Machine number: 11744 Travel axes: X – 5,029 mm / Y – 1,202 mm / Z – 772 mm B-axis travel: ±121° C-axis travel: ±211° Feed rates (X/Y/Z): 60/60/40 m/min New milling spindle installed on 19.05.2025 Equipment: - 5-axis fork-type head - Milling spindle 15 kW / 12 Nm / 24,000 rpm - For milling, drilling, sawing - Disc-type tool changer, 12 tools, HSK-63 F Fodjxlchxepfx Afpogh - Pick-up station for saw blade - Spindle cooling unit - Fluidtech minimum quantity lubrication system - Partition wall for pendulum machining - Vacuum clamping plate by WITTE, 2,100 mm x 1,200 x 42 mm - Chip conveyor - Extraction unit by LOSMA NEWTON N6 Scope of delivery includes: approx. 35 tool holders / operating manual / documentation For equipment, technical data, and transport drawings – see PDF. Images, content, and specifications are provided without guarantee and are non-binding. All additional accessories visible in the photos and video are not included in the scope of delivery and are therefore not part of this sale. The delivery includes only those accessories expressly listed here, in the order confirmation, and on the invoice. FCA (Free Carrier, loaded truck) D-97944 Boxberg Packaging only Delivery: immediately Subject to prior sale / Payment due immediately upon conclusion of sale

Condition: ready for operation (used), Year of construction: 2018, operating hours: 11,000 h, Control Unit Brand HEIDENHAIN Main Drive Spindle speed range 15000 Number of axis 5 Movement X-Axis Movement 1350 mm X-Axis Rapid Traverse 30 m/min Y-Axis Movement 1150 mm Y-Axis Rapid Traverse 30 m/min Z-Axis Movement 700 mmm Workpiece Workpiece weight 1600 kg Table Fsdpfx Afoxiriajpjgh Table load 1600 kg Tools Slots in storage 30 This 5-axis +GF+ MIKRON HPM 1350U was manufactured in 2018. Ideal for advanced machining, this universal machining centre ensures precision and efficiency. Consider the opportunity to buy this +GF+ MIKRON HPM 1350U universal machining centre. Contact us for more information. Application Types Milling

Condition: ready for operation (used), Year of construction: 2002, Control Unit Brand SIEMENS Fsdpfx Afjxirg Sepsgh Model 840D Main Drive Spindle speed range 18000 Movement X-Axis Movement 2700 mm Y-Axis Movement 2200 mm Z-Axis Movement 800 mm This FPT DINO was manufactured in 2002. It features a Siemens 840D CNC, a table size of 1200x3000 mm, and travels of X2700, Y2200, Z800 mm. Equipped with a 5-axis continuous head with an electrospindle reaching 18,000 RPM and an 18-position tool changer. Consider the opportunity to buy this FPT DINO universal machining centre. Contact us for more information. Application Types Milling

Condition: ready for operation (used), Year of construction: 1999, General Data Measurements width 3660 mm Measurements depth 4550 mm Measurements height 2400 mm Fgedpfxexirdwj Afpeh Machine weight 17600 kg Control Unit Brand SIEMENS Main Drive Spindle speed range 20000 rpm Spindle motor power 11 kW Number of axis 5 Movement X-Axis Movement 1200 mm Y-Axis Movement 850 mm Z-Axis Movement 600 mm Table Table load 3000 kg This 5-axis OMV BPF-4 1200 universal machining centre was manufactured in 1999. Ideal for precision engineering, it offers robust construction and reliable performance. Consider the opportunity to buy this OMV BPF-4 1200 universal machining centre. Contact us for more information. Application Types Milling

Condition: excellent (used), 5-Axis Machining Center with swivel milling head, pallet station, tool calibration, thermal compensation, work area extraction system, and much more. Year of manufacture: 2016 Spindle hours approx. 1,500 h (after spindle replacement at the beginning of 2025) Fgsdoxhg Dispfx Afpjh Control System: - Heidenhain iTNC 530 HSCI - Heidenhain DCM Collision Monitoring - Heidenhain HR 410 electronic handwheel - Swiveling console with 19" monitor - Teleservice via LAN/WLAN Travel Range: - Travel X 1,000 mm, Y 1,100 mm, Z 810 mm - NC rotary table D 1,000 x 800 mm, swing diameter 1,350 mm Milling Head: - Automatic horizontal/vertical swivel milling head - Fully-fledged stepless NC axis from -1° to +90° - Blowing air through the spindle - External coolant supply via nozzle ring Drive power: 38 kW (100% duty cycle) Speed: 16,000 rpm Torque: 135 Nm at 40% duty cycle Spindle interface: HSK 63-A Media Supply: - Internal coolant feed: 50 bar - capacity 28 l/min - Paper belt filter with additional fine filter - Individual tool pressure regulation during program operation Tool Changer: - Rack magazine with 73 stations (expandable with additional racks) - Swiveling dialog operation panel - Drawer for loading and unloading tools from tool racks Tool Measurement: - 3D wireless touch probe m&h 20.00-Multi, software adapted for HSK 63-A - Including Kinematics-Opt, compatible with iTNC control, and calibration sphere on magnetic stand Pallet Changer: - Double palletizing unit, pallet diameter 1,000 x 800 mm, hole grid 100mm x 100mm, hardened drill bushes D 16mm - Rotary table unit including zero-point clamping system, loading station accessible by crane - Pallet changer unit protected with enclosure Special Equipment: - Micro-Epsilon sensor - For detection and dynamic compensation of thermal spindle growth Chip Conveyor: - Scraper belt conveyor along machine bed - Chip ejection height 1,100 mm Machine Enclosure: - Full-area protective enclosure with large angle door for crane loading and a quick-access door - Easy removal of swarf from the workspace Extraction System: - Oil and emulsion mist extraction, mechanical air filter, extraction capacity 1,800 m³/h Rotating View Window: - Viewing window integrated into the cabin door for workspace observation Camera in Work Area: - Monitor and keyboard at the operator console—allows monitoring of rear-side machining operations Machine Data: - Space requirement (without service area): approx. LxWxH 4,791 mm x 4,100 mm x 4,791 mm (including extraction system) - Machine weight approx. 19,700 kg - Total weight with all equipment plus maximum workpiece load, full tool magazine, and all operating materials: approx. 27,730 kg - Connected load: 50 kVA, 400V, 50/60 Hz This machining center, featuring an exceptionally good and practical configuration, is in very good condition. It operates with the renowned "Swiss precision." There is no service or repair backlog—in fact, the opposite. With an almost new milling spindle, the REIDEN RX 10 5X is well positioned for long-term use. Technical modifications and errors excepted.

Condition: excellent (used), Year of construction: 2016, operating hours: 16,089 h, functionality: fully functional, travel distance X-axis: 1,450 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 550 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, feed length X-axis: 1,450 mm, feed length Y-axis: 700 mm, feed length Z-axis: 550 mm, total height: 3,100 mm, total length: 6,100 mm, total width: 2,800 mm, table width: 750 mm, table length: 1,760 mm, rotational speed (max.): 12,000 rpm, overall weight: 10,000 kg, operating hours of spindle: 16,089 h, coolant supply: 40 bar, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Manufacturer: DMG MORI Year of manufacture: 11.2016 Control: Heidenhain TNC 640 Motor spindle: SK 40 with 12,000 rpm Options: Probe / coolant system / chip conveyor / high-pressure through-spindle coolant (IKZ) Travel: X-axis 1,450 mm / Y-axis 700 mm / Z-axis 550 mm Table dimensions: 1,760 x 750 mm Tool magazine: 30 pockets Machine dimensions / footprint: 6.1 x 2.8 x 3.1 meters (L x W x H) Weight: 10 tons The machine is in well-maintained condition and will be available for delivery from the end of October. 3-axis geometry is within the manufacturer’s tolerances and in good condition. The main spindle was replaced in March 2024. It runs smoothly and achieves an excellent runout of 0.008 mm. Drawbar force is also good at 10 kN. All functions have been tested and all fluids have been replaced. Of course, the machine can be inspected and tested at our facility. Transport and installation on request and at extra cost. Fedpfx Aoxg R Tfofpsgh Chip conveyor / coolant system / high-pressure through-spindle coolant (IKZ) / air blast through the spindle center Handwheel / hand rinsing gun RotorClear viewing window Heidenhain probe TS 649 (replaced in October 2024) Tool measurement TT160 Machine hours: 38,758 h / Automatic mode: 16,089 h
