Year of construction: 2002, condition: ready for operation (used), overall weight: 5,000 kg, total height: 2,050 mm, This JUNKER EJ29 CNC was manufactured in 2002. It features a FANUC 21i-TB CNC control, servo drives for spindle and table axes, and a hydraulic/manual tailstock. The machine can handle workpieces up to 280 mm in diameter and 800 mm in length, with a grinding wheel diameter of 400 mm. Consider the opportunity to buy this JUNKER EJ29 CNC cylindrical grinding machine. Contact us for more information. • Distance between centers / workable length: approx. 800 mm • Center height: approx. 180 mm • Maximum workpiece diameter: up to approx. 280 mm • Grinding wheel diameter: around 400 mm (typical for European versions) • Grinding wheel peripheral speed: approx. 45 m/s • Grinding wheel motor power: 4.5 kW • Construction/features: Servo drives (spindle and table axes), auxiliary spindle support, hydraulic/manual tailstock Additional equipment • 4 wheel hubs • 1 hydraulic CM5 workholding spindle Bedpfx Ahoyq E Srs Iswi • 3-micron cartridge filtration system Dimensions Machine Depth 3340 mm

Year of construction: 2022, operating hours: 7,315 h, condition: used, machine/vehicle number: 100644, Max. grinding wheel diameter: approx. Ø 915 mm, max. workpiece diameter: approx. Ø 440 mm, max. workpiece weight: approx. 250 kg, max. grinding wheel speed: approx. 80 m/s, operating pressure: approx. 6 bar, control system, manufacturer: DANOBAT/SIEMENS/MARPOS, type: Sinumerik/P7, 1 automated workpiece removal station JOVI 1113B, year of manufacture: 2022, net weight: approx. 300 kg, 1 air filter unit IFS M 1600, year of manufacture: 2022, serial no.: 567663, net weight: approx. 85 kg, connected load: 380-460 V, 50/60 Hz, 0.7 kW, 1.5-2.1 A, 1 hydraulic unit REXROTH Depósito HE-16120, 1 coolant filtration unit MICRONFILTER Easy 250/KMT350, year of manufacture: 2022, serial no.: 0201, tank capacity: approx. 2,300 l, connected load: 400 V/50 Hz, 2.44 kW, 1 immersion cooler HASCH MCS-120ST-05AOP6R7S7UZ1-3405C, year of manufacture: 2022, serial no.: 1003220300954, net weight: approx. 206 kg, 1 magnetic separator MICRONFILTER KMT350, serial no.: 0211, 1 tool loading unit, DANOBAT rotary table lift, year of manufacture: 2022, serial no.: 3130490901, net weight: approx. 350 kg, max. payload: approx. 360 kg Bjdpfsyn Nlwex Ah Iewi

Year of construction: 2022, operating hours: 2,737 h, condition: used, machine/vehicle number: 110000503, Grinding wheel speed: up to 120 m/s, workpiece weight: up to 80 kg, control system, manufacturer: SIEMENS/MARPOS, type: Sinumerik/P7, 1 automated workpiece unloading station, manufacturer: JOVI, type: 1113A, year of manufacture: 2022, net weight: approx. 300 kg, 1 air filter unit, manufacturer: IFS, type: VARIO M 2000, serial number: 568113, year of manufacture: 2022, net weight: approx. 120 kg, connected load: 400/460 V, 50/60 Hz, 0.7 kW, 1.7/1.6 A, 1 water cooling unit, manufacturer: HASCH, type: MCW-50CT-17AUZ1-3407C, serial number: 1001220302582, year of manufacture: 2022, net weight: approx. 150 kg, tank capacity: approx. 15 l, 1 coolant filtration system, manufacturer: MICRONFILTER, type: Easy 250/KMT350, serial number: 0201, year of manufacture: 2022, tank capacity: approx. 2,300 l, connected load: 400 V/50 Hz, 5.34 kW, 1 immersion cooler, manufacturer: HASCH, type: MCS-120ST-05AOP6R7S6UZ1-3407C, serial number: 1003220400836, year of manufacture: 2022, net weight: approx. 206 kg, 1 coolant tank, manufacturer: MICRONFILTER, type: VR200L/MIN-150L, serial number: 0201, year of manufacture: 2022, tank capacity: approx. 150 l, connected load: 400 V/50 Hz, 1.1 kW, 1 magnetic separator, manufacturer: MICRONFILTER, type: KMT350, serial number: 0212, 1 loading unit, manufacturer: DANOBAT, type: rotary table lift, serial number: 3810490908, year of manufacture: 2022, net weight: approx. 170 kg, max. load capacity: approx. 230 kg, 1 rotary table transport trolley Bwedpfxsyn Nlqs Ah Isi

Year of construction: 2023, operating hours: 1,376 h, condition: used, machine/vehicle number: 180073, Swivel range: approx. 200 mm, machining length travel: approx. 100 mm, number of axes: 3 axes (X/Y/Z), SIEMENS Sinumerik control, IFS IFMC 1800 air filter unit, year of manufacture: 2021, serial no.: 565760-02, HYFRA E-Chilly 5-400V-S cooling unit, year of manufacture: 2022, serial no.: 10129303PC01240522, cooling capacity: approx. 5,480 m³/32° Celsius, LEHMANN UMT KSS0119 hydraulic unit, year of manufacture: 2022, net weight: approx. 610 kg, comprising: 1 HYFRA TRK-Chilly-45-EF-S cooling unit, year of manufacture: 2022, serial no.: 10132616PC01290722, 1 LEHMANN UMT FB100 chip conveyor, year of manufacture: 2022, serial no.: AUF007093-1, net weight: approx. 80 kg, 1 LEHMANN UMT VMA 100S GM WA magnetic unit, year of manufacture: 2022, serial no.: AUF007093-1, net weight: approx. 60 kg, 1 JOTKEL two-door steel cabinet, contents: various consumables. Bsdpfx Ahsyn Nldo Iewi

Year of construction: 2021, operating hours: 5,475 h, condition: used, machine/vehicle number: 100000736, max. centre distance: 60 cm, max. grinding diameter: 44 cm, max. workpiece weight: 500 kg, control: SIEMENS Sinumerik/Balance Systems VM25, handling robot YASKAWA YR-1-06VXH12-A00, year of manufacture: 2022, serial number: 6V2272528290001, automation system/workpiece storage EGS Automation Danobat CG600-BL1, year of manufacture: 2023, serial number: 190605-6, 2-fold, filter 3FS M1600, no.: 565209, year of manufacture: 2021, weight: 85 kg, oil band filter MICROFILTER Easyband 150, serial number: 0202, year of manufacture: 2021, pump REXROTH HM-46, safety enclosure Bwjdpfjyn Nk Tox Ah Iei

Year of construction: 2018, operating hours: 28,658 h, condition: used, machine/vehicle number: 18E400239, Through-feed grinding, grinding range Ø: 10 cm, plunge grinding, grinding range Ø: 15 cm, weight: 9,000 kg, FANUC 0i-MF control, 2 handling robots YASKAWA YR-MH005LS-E000, serial numbers: R17507-979-3 / R19033-789-1, automation system/workpiece storage EGS Automation Tschudin, year of manufacture: 2018, serial number: 180100, 4-way, oil cooling and filtration system ARO, year of manufacture: 2018, serial number: PRA0032086, protective guard Bjdpfx Aoyn Nk Hjh Iewi

Year of construction: 2016, condition: ready for operation (used), Table dimensions X/Y/Z: approx. 1400mm/800mm, grinding wheel diameter: 150mm, spindle speed: 2000rpm, swivel range: 180°, machine dimensions X/Y/Z: approx. 1600mm/1300mm/1750mm, weight: approx. 400kg. An on-site inspection is possible. Bwodpfxeynluhs Ah Isi

Year of construction: 2022, condition: ready for operation (used), number of axes: 2, Cylindrical grinding machine manufactured in 2022. This ELMAG CG 800 features a maximum grinding diameter of 200 mm and a grinding length of 800 mm. It is equipped with a robust headstock spindle and transverse feed guide, ensuring precision in grinding operations. If you are looking to get high-quality grinding capabilities, consider the ELMAG CG 800 machine we have for sale. Contact us for further details. • Max. Grinding diameter: 200mm • Max. Grinding length: 800m • Total equipment capacity: 7 kVA • Voltage: 400 V • Phase: 3 PH • Frequency: 50 Hz • Protection class: IP54 • Total current: 25 A • Bed guide • Headstock spindle • Internal grinding tool Bsdpfx Asym Ar Uoh Iswi • Transverse and longitudinal screw bearings • Tailstock sleeve • Transverse feed guide • Grinding wheel spindle (dynamic and static pressure) • Grinding wheel spindle (tiles)

Year of construction: 1970, condition: ready for operation (used), A total of three cylindrical grinding machines and one internal cylindrical grinding machine are available. 1/2) Two identical cylindrical grinding machines SMW AGL 125/5PC, year of manufacture: approx. 1970, center height: 160mm, max. workpiece width: 63mm, max. workpiece diameter: 180mm, speed: 1000rpm, machine dimensions X/Y/Z: approx. 2800mm/2800mm/2400mm, weight: approx. 5500kg. 3) Cylindrical grinding machine Fortuna RSE300/II, max. grinding wheel diameter: 300mm, grinding length: 600mm, machine dimensions X/Y/Z: approx. 1600mm/1400mm/1550mm, weight: approx. 2000kg. 4) Internal cylindrical grinding machine Jung D14 MP7z, grindable bore: 8mm-10mm, max. grinding depth: 150mm, swing diameter: 450mm, workpiece spindle bore: 35mm, max. swiveling range: 30°, machine dimensions X/Y/Z: approx. 2700mm/1300mm/1700mm, weight: approx. 2500kg. An on-site inspection is possible. Individual sale possible. Bedpeympcyefx Ah Ijwi

Year of construction: 2006, condition: ready for operation (used), controller manufacturer: SIEMENS, controller model: SINUMERIK 840D with SIMODRIVE 611D, overall weight: 6,200 kg, number of axes: 2, Cylindrical grinding machine manufactured in 2006. This GEIBEL & HOTZ RS 1000 CU features a center distance of 1000 mm and a maximum swing diameter of 355 mm. It is equipped with an electromechanical X-axis and Z-axis, offering feed rates of up to 12,000 mm/min. If you are looking to get high-quality grinding capabilities, consider the GEIBEL & HOTZ RS 1000 CU machine we have for sale. Contact us for further details. • Current defects: • Measuring probe is defective • Switch in the coolant reservoir for controlling the pump is defective • Axis configuration: 2-axis (X, Z) • Center distance: 1000 mm • Center height: 180 mm • Max. swing diameter: 355 mm • Max. workpiece weight: 150 kg between centers; 60 kg in chuck (including clamping device) • X-axis: • Drive: electromechanical with ball screw • Feed rate: 0.01–8,000 mm/min • Measuring system: glass scale, 0.0005 mm resolution • Z-axis: • Drive: electromechanical with ball screw • Feed rate: 0.01–12,000 mm/min • Measuring system: rotary encoder, 0.001 mm resolution • Workpiece spindle: • Motor power: 2.0 kW • Speed: 0–1000 rpm • Taper: MK5 and KK5 (DIN 55026) • Grinding spindle: • Motor power: 9 kW • Speed: 1400 rpm Bsdpfeymn Ihjx Ah Ijwi • Grinding wheel size (standard): 500 × 80 × 203.2 mm • Bearings: precision rolling bearings • Lubrication: lifetime lubrication • Required space: approx. 3900 × 2450 × 1800 mm • Power supply: 400 V, 50 Hz, 3-phase • Control voltage: 230/24 V • Installed power: approx. 23 kW

Condition: used, Year of construction: 2008, machine/vehicle number: 147233, Ref. no. 20312 Technical Data: - Workpiece thickness: 0.8 to 51 mm - Max. working width: 1370 mm - Max. grinding height: 100 mm - Grinding diameter: 150 mm - Grinding speed: 1720 rpm - Feed rate: 3.7 m/min - Drive: 400 V / 9.7 kW - Working height: 1100 mm Bwedpeylylisfx Ah Ioi - Space requirement approx.: W 1700 x H 1200 x D 1200 mm - Weight approx.: 800 kg - Separate mobile motorised grinding dust extraction unit

Year of construction: 1979, condition: ready for operation (used), Components: headstock, main spindle, faceplate flange, taper, table, guideway, longitudinal guide, cross guide, tailstock, workpiece holder, tailstock taper, workpiece spindle. With documentation and records. An on-site inspection is possible. Bwodpfx Aheyln Dtj Ioi

Year of construction: 2007, condition: ready for operation (used), A surface grinding machine is offered. Condition: as new - never used, Design: micro granite, STC control system, Grinding area X/Y/Z: 600mm/400mm/475mm, Table load: max. 400kg, Table speed: approx. 2-30m/min (infinitely variable), Grinding wheel dimensions X/Y/Z: 300mm/50mm/76.2mm, Installation dimensions X/Y/Z: approx. 2800mm/2200mm/2500mm, Machine weight: approx. 3900kg. Viewing possible by appointment. Bwodpoylnzxsfx Ah Iei

Year of construction: 2016, condition: ready for operation (used), Offered is a high-precision worm and thread grinding machine MIKROMAT 20G, used as a test and trial machine, nearly all available options included, technically flawless condition. Capabilities: external thread grinding, internal thread grinding, whirling Whirling, grinding length max. 2000mm, workpiece diameter max. 320mm, distance between centers: 2250mm NC tailstock option: 2050mm, workpiece weight max. 200kg 350kg NC tailstock, pitch range: 0-400mm, 7-axis system, feed speed: up to 15000mm/min, setting angle: +/-40°, positioning accuracy: uncertainty 0.0024mm P, upgrade to 23.5kW continuous power/45kW maximum power, grinding wheel speed: up to 50m/s, special equipment internal grinding: internal thread diameter up to 100mm, length up to 50mm, coolant system: KNOLL compact unit vacuum rotary filter, 2500l tank volume and oil cooling, installation dimensions X/Y/Z: approx. 6500mm/4000mm/3000mm, total weight: approx. 13000kg, inspection possible by arrangement. Bwedpfjylbr Djx Ah Isi

Year of construction: 1997, condition: ready for operation (used), Color: RAL 7035 light grey, RAL 7012 basalt grey, RAL 5012 blue grey, the machine’s inverter is defective. Accessories: electromagnetic clamping plate 400x250mm, with pole pitch 5mm and holding force control, automatic vertical infeed with infeed program and digital display for vertical and cross movement, automatic central lubrication system, wet grinding unit with paper belt filter system for filter paper 460x200mm with filter fineness 0.016–0.025mm, electric wheel dresser with dimensional compensation and operating manual. An on-site inspection is possible. Bwedpfx Aheylbrwe Ioi

Condition: ready for operation (used), A used manual tool grinding machine from Saacke is offered. Table size X/Y approx.: 850mm/145mm, travels X/Y/Z approx.: 450mm/250mm/250mm, center height approx.: 125mm, max. grinding length approx.: 500mm, machine dimensions X/Y/Z approx.: 1500mm/1100mm/1500mm, weight approx.: 850kg. Inspection by appointment possible. Bwjdpjyk Hb Iofx Ah Isi

Condition: ready for operation (used), Offered is a used high-precision Studer S35 CNC cylindrical grinding machine. Center distance: 1000mm, center height: 175mm, swing diameter max. approx. 350mm, workpiece weight: approx. 80kg, resolution: measuring systems glass scales range 0.0001mm 0.1µm. Inspection by appointment possible. Bodpsykuucjfx Ah Iswi

Year of construction: 2004, condition: ready for operation (used), travel distance X-axis: 320 mm, travel distance Z-axis: 1,150 mm, controller manufacturer: HEIDENHAIN, overall weight: 6,000 kg, This KELLENBERGER KEL VARIA RS 175/1000 Grinding machine was manufactured in the year 2004 in Switzerland. It is equipped with a HEIDENHAIN control unit. Machine Benefits Bsdpoyi Eliofx Ah Iswi Qualitative Machine Benefits • Good condition Technical Machine Benefits • Distance between centres: 1000 mm • Centre height: 175 mm • Grinding wheel dimensions right Ø 400 x 50 mm • Grinding wheel head movements -210°/+30° • Rotational speed 8-800 rpm • Spindle type cm5

Year of construction: 2008, condition: ready for operation (used), overall weight: 3,800 kg, spindle speed (max.): 600 rpm, number of axes: 5, This 5s SAACKE UWIF cylindrical grinding machine was manufactured in 2008. It features a maximum spindle speed of 600 rpm and a powerful grinding spindle peak power of 16 kW. The machine supports a variety of workpiece sizes, with a maximum diameter of Ø 20 mm and a weight capacity of 1 kg. If you are looking to get high-quality grinding capabilities, consider the SAACKE UWIF cylindrical grinding machine we have for sale. Contact us for further details. • Workpiece carrier A-axis: Direct drive/hollow shaft motor; indexing accuracy ±15"; indexing possibilities 1–999; cumulative pitch error at 100 mm: 8 µm; speed max. 600 rpm • Tool holder: ISO 50 • Spindle clearance holding sleeve: max. 28 mm (with automatic clamping: Ø20 mm) • Nominal drive power: • Grinding spindle S1-100%: 7.5 kW; peak: 16 kW • X-axis longitudinal travel: 2 kW • A-axis workpiece carrier: 2 kW • Z-axis cross slide: 2 kW • Y-axis grinding head slide height: 2 kW • B-axis grinding head rotation (rotary table): 2 kW • Position measuring systems: • A-axis: Direct measuring system • B-, X-, Y-, Z-axis: Indirect measuring system • Resolution X/Y/Z: 0.0001 mm (0.1 µm) • Resolution A/B: 0.0001° • Electrical connection: 20 kW / 50 A; operating voltage 400 V, 50 Hz; control voltage 24 V; lighting voltage 230 V; backup fuse: separate supply from mains • Compressed air: 15–17 Nm³/h; pressure min/max 6/8 bar (600/800 kPa); quality ≥ Class 4 (ISO 8573-1) • Control & software: CNC NUM Axium Power 1050 with PC, program memory 512 k; NUMROTOplus software (dongle/hardlock required); zero points calibrated using enclosed measuring instructions (no marked reference points) Additional equipment • Workpiece changer options (automation): • Option 1: Pick-up design • Max. workpiece: Ø20 mm × 120 mm; 1 kg • Capacity per pallet: • Ø3.0–5.0 mm shank: 40 pcs • Ø5.1–8.0 mm: 32 pcs Bwjdpfx Aheyiz R Ue Iji • Ø8.1–11.0 mm: 28 pcs • Ø11.1–14.0 mm: 24 pcs • Ø14.1–20.0 mm: 20 pcs • Option 2: Chain loader magazine (with gripper unit) • Capacity: 64 workpieces • Max. workpiece: Ø32 mm × 200 mm; 2.5 kg • Features: Chaotic loading of different workpieces; automatic changing of collets possible • Holding sleeves: Ø6, 8, 10, 12, 14, 16, 20 • External chain loader option: increases machine weight to approx. 3,800 kg and space to 3,000 mm × 1,875 mm • Coolant filter system (TRANSOR): To be provided by customer; air for backwashing approx. 700 Nl/min for 5 min every 6–9 hours

Year of construction: 1958, condition: ready for operation (used), Grinding length: 1500mm, center height: 175mm, max. workpiece diameter: 350mm, max. workpiece weight: 300kg, grinding wheel diameter: 450mm, grinding wheel width: 80mm, bore: 203mm. Machine dimensions X/Y/Z: approx. 3600mm/1900mm/1900mm, weight: approx. 4000kg. Documentation available. An on-site inspection is possible. Bwedjyg Nvmjpfx Ah Ioi

Year of construction: 1955, condition: ready for operation (used), A conventional internal cylindrical grinding machine Fortuna is available. Center distance: 1500mm, center height: 225mm, max. workpiece diameter: 450mm, max. workpiece weight: 300kg, grinding wheel diameter: 450mm, grinding wheel width: 80mm, bore: 203mm, speed: 265rpm, machine dimensions X/Y/Z: approx. 3450mm/1450mm/1550mm, weight: approx. 4000kg. Documentation available. On-site inspection is possible. Bsdpfxjyg Nvts Ah Iewi

Year of construction: 2000, condition: ready for operation (used), number of axes: 2, This Parpas RUAP 700 was manufactured in 2000. A used cylindrical grinding machine, fully reconditioned and in excellent condition. Features include Siemens Sinumerik 840C control, 700 mm distance between centers, and a maximum workpiece diameter of Ø 360 mm. If you are looking to get high-quality grinding capabilities, consider the Parpas RUAP 700 machine we have for sale. Contact us for more information. Bedpfxsygmg Ns Ah Iswi • Status: Excellent • Control: Siemens Sinumerik 840C • Distance between centers: 700 mm • Center height: 185 mm • Maximum workpiece diameter: 360 mm • Maximum table travel (Z-axis): 820 mm • Table feed speed (Z-axis): 0–10 m/min • Maximum wheelhead travel (X-axis): 500 mm • Wheelhead feed speed (X-axis): 0–10 m/min • Max wheel size (left): 508 x 203 x 76 mm • Max facing wheel size (right): 450 x 127 x 50 mm • Wheel motor power: 10 hp • Workpiece spindle speed: 0–600 rpm • Wheel spindle speed: 0–2,880 rpm • Workpiece spindle taper: ISO 50 • Tailstock internal taper: Morse 4

Year of construction: 1994, condition: ready for operation (used), Grinding length: 650mm, center height: 125mm, grinding wheel dimensions X/Y/Z: 406mm/60mm/127mm, peripheral speed: 45m/s, spindle power: 4kW, travel X/Z: 210mm/810mm, feed rate: 8m/min, table swivel: 8°, speed: 5000rpm, tool spindle head swivel: -30°/90°. Machine dimensions X/Y/Z: approx. 3600mm/2850mm/2200mm, weight: approx. 4000kg, control: Siemens Sinumerik. The X-axis spindle and the scale were renewed. Including Movomatic measuring system and accessories. Documentation available. On-site inspection is possible. Bjdpfx Aoyf I Hbsh Ijwi

Condition: ready for operation (used), Year of construction: 1977, functionality: fully functional, grinding length: 700 mm, grinding width: 550 mm, travel distance X-axis: 500 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 475 mm, TECHNICAL DETAILS X-axis travel: 500 mm Y-axis travel: 300 mm Z-axis travel: 475 mm Manual grinding area Bwodsyf Ahmjpfx Ah Iji Length: 700 mm Width: 550 mm Height: 400 mm Automatic grinding area Length: 700 mm Width: 470 mm Height: 400 mm Table size: 1,100 x 500 mm Maximum workpiece height: 400 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 3,000 x 1,960 x 2,550 mm Machine weight: 3,300 kg EQUIPMENT Operating manual

Year of construction: 1979, condition: good (used), Flat grinding machine make Brand Type: Compact 600/800 with Heidenhain control We do not have any further technical data. Bwodeydltpepfx Ah Iei
