Condition: excellent (used), Year of construction: 2019, functionality: fully functional, overall weight: 1,800 kg, power: 12 kW (16.32 HP), TECHNICAL DETAILS Power: 12 kW Throughput: 1,000 – 2,300 kg/h Weight: 1,800 kg Operating Modes Manual operation Automatic operation EQUIPMENT Screw feeder system in the feed hopper Tool and drum trolley Gujdpszzp T Tefx Adtog Flexible press belt Adjustable perforated drum Waste chute

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, TECHNICAL DETAILS Process and Feeding Low rotational speed Single-screw feeding system Gentle processing of raw materials Preservation of fiber and texture in the end product Application Area Suitable for red meat, poultry, pork, fish, fruits, and vegetables Machine Design Compact design with a small footprint Control elements mounted directly on the machine Versatile for use with different raw materials Guedpfx Aszzp I Redtog Product Quality Gentle separation for a high-quality, minced end product Preservation of fibers and texture EQUIPMENT Control unit arranged directly on the machine Single-screw feeding system Compact machine construction

Condition: used, Year of construction: 1997, functionality: fully functional, GEA Westfalia MSD 140-96-076 Whey Clarifier Gedpezy Rlbsfx Adteug Year: 1997 22,000L

Condition: used, Year of construction: 1980, functionality: fully functional, GEA Westfalia MSA 170-05-076 Whey Cream Separator Year:1980 Gujdpszy Rkwjfx Adtog 22,000L

Condition: excellent (used), functionality: fully functional, overall weight: 1,200 kg, type of input current: three-phase, power: 11 kW (14.96 HP), rotational speed (min.): 6,500 rpm, input voltage: 380 V, input frequency: 50 Hz, Equipment: documentation/manual, CLARIFIER FOR JUICES, WINES, OILS, 11 KW, UP TO 10 M³/H IMMA MICRO, 5.5 KW, 2 M³/H = 7,500 EUR Gjdpozv I Acsfx Adtsug

Condition: used, Year of construction: 1976, Drum speed: 4500/min, drum diameter: 650mm, permissible density of centrifuged material, heavy liquid: 1,1kg/dm³, solids: 1,3kg/dm³, control panel: Siemens SIMATIC HMI. Maintenance was carried out every two years by a specialist company, new control system installed two years ago, very good condition, no maintenance backlog, with documentation. An on-site inspection is possible. Gjdpfx Aezun S Iedtjug

Condition: ready for operation (used), Year of construction: 1980, functionality: fully functional, machine/vehicle number: 1670-736, type of input current: three-phase, power: 7.5 kW (10.20 HP), rotational speed (max.): 7,570 rpm, space requirement height: 1,600 mm, space requirement length: 1,200 mm, input voltage: 380 V, space requirement width: 800 mm, input frequency: 50 Hz, Equipment: documentation/manual, For sale: GEA / Westfalia Separator SA 14-47-076 professional centrifuge, built in 1980, serial number 1670-736. This machine was used in a craft brewery for beer clarification. Specifications: 15–45 hl/h • 7,570 rpm • hermetic version • self-cleaning / automatic sludge removal • flow meter • 7.5 kW motor • 380 V / 50 Hz • 32 A connection. History: The machine was completely overhauled in April 2014. It was acquired in 2018 from another brewery. Gusdpsztma Uofx Adtsg Maintenance work was documented by GEA / Westfalia Separator Belgium in 2021 and 2023, including the replacement of seals, sleeves, oils, greases and other maintenance consumables. Condition: Complete machine, photographed in its current installation. On-site inspection is possible by appointment. Documentation and GEA invoices are available for serious buyers. Asking price: €19,500 (excluding VAT). Transport, disassembly and loading to be agreed upon with the buyer.

Condition: excellent (used), Year of construction: 1977, functionality: fully functional, rotational speed (max.): 3,520 rpm, input voltage: 380 V, input frequency: 50 Hz, Equipment: documentation/manual, Used, very good condition Westfalia SA7-01-576 Separator, year of construction 1977. Packed in wooden crate to IPPC standard, ready to be shipped. Guodpfezryq Rex Adteg - Brand new Time control box with Burkert valves and automatic controls - Performance 500 - 3.000 Ltr - self-cleaning - Motor 4 kw, 380V / 50 Hz - Start-switch including phase changer and emergency stop function - with Tools, Instruction Manual and Spare part list - Made in Germany If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: good (used), Baader 601 Separator Вaader 601 provides soft separation of raw meat material from a waste components – bones, skin etc. A flexible squeezing belt transports the product to a perforated drum. It gently squeezes the softer particles like meat and fat through the holes, then the harder particles such as bones, sinews and cartilage stays outside of the drum. Godjzgtanopfx Adtoug Capacity: up to 800 kg per hour The throughput can vary in dependence of the drum hole size, product and its pre-treatment, the selected pressure etc. Baader 601 is а user-friendly machine. Its cleaning is easy and quick. The machine is built in accordance to worldwide recognised sanitary standards. A pressure system ensuring gentle product processing and reduced machine wear. Machine has castors for easy handling. Manufacturer: Baader Model: 601 Capacity: Up to 800 kg./hour Drum: 3 mm and 5 mm Power: 400V / 50Hz / 3kW Machine dimensions (LxWxH): 950x950x1.800 mm Machine weight: 500 kg.

Condition: like new (used), Year of construction: 2024, operating hours: 10 h, functionality: fully functional, Description Solid/liquid separation unit based on a centrifugal sifter (Centri-Sifter): solids are conveyed along the basket/screen by a paddle, while the liquid is separated and discharged through a dedicated outlet. Adjustable inclination to optimize residence time and separation efficiency. Sold with a 1000 L hopper and a flexible screw conveyor. In like-new condition (used only for testing), fully functional, and available immediately. Main equipment – Centri-Sifter • Type: centrifugal sifter (liquid outlet + solid outlet) • Construction: 304 stainless steel • Basket/screen: wedge wire basket (304 stainless steel) Godpfxozc H H Is Adtsug • Paddle: “expanded 7.5°” (304 stainless steel) • Safety: inspection door with interlock (operator safety) • Weight (machine): ≈ 220 kg • Purge air/gas (seals): clean/dry/filtered air/gas required Motor (motor plate) • Motor 3~: 2.2 kW, 50 Hz, 230 V Δ / 400 V Y • Speed: 1450 rpm (50 Hz) • Protection / efficiency: IP55, IE3 • Mounting: IM B35, service S1 Included equipment (sold with) 1) Hopper • Volume: 1000 L • 304 stainless steel, open design, “food grade” finish (Type C Plus) • Level probes: high + low • 30° outlet 2) Flexible screw conveyor • Supplier: Spiroflow Ltd • Model: 146SH • Length / inclination: 3 m 30° • Outlet: Ø300, 30° standard • Components: reverse bung / drop trap / QR flanges (quick disassembly) Price and conditions • Availability: immediate • Location: Martigny (Switzerland) • Condition: like new, functional • Visit / inspection: upon request Transportation costs are the responsibility of the buyer.

Condition: like new (used), HERMETIC CLARIFIER. POWER: 7.5 kW. COMPLETE TOOL SET. INSPECTED. DOCUMENTATION AVAILABLE. PRICE: 25,000 EUROS PLUS VAT. Gedpfxey S Smyo Adteug

Condition: good (used), Year of construction: 2017, Insulated cyclone by GEA, model CYCLONE CHE 394. Year 2017. With 2 reinforcement brackets. Bottom outlet DN100. Top inlet Clamp 1". Side inlets Clamp 1" and 4". No documentation available. Cyclone dimensions: Gujdpfoy Hfxrjx Adtjg Length: 650 mm Width: 560 mm Height: 1510 mm

Condition: reconditioned (used), Manufacturer: Provisur / Beehive Model: RSDD-04 Godpfxsy Akhds Adteug Type: Separator Dimensions: 2150 x 700 x 1650 mm Power: 21 kW Power supply: 400V 50Hz 3N Sieve hole diameter: 1 mm Material: Acid-resistant stainless steel Machine renovated and ready to work.

Condition: ready for operation (used), Year of construction: 2003, A self-cleaning disc stack centrifuge (disc separator) GEA is available. Drum speed range: 4000-4800rpm, drum diameter: 682mm, max. feed density liquid/solids: 1.1kg/dm³/1.3kg/dm³, drum volume: 125l. An on-site inspection is possible. Gsdpfx Asydpz Djdteug

Condition: like new (used), Year of construction: 2019, functionality: fully functional, control type: PLC-controlled, Auction of a medicinal and spice processing line. The line is still in its original packaging and has never been used. The video shows a sample machine. The offered line consists of the following components: - ST II VIBRO W - LGU 252 - VIBRO 14 - OGK 1003-A - DOUBLE ZIG-ZAG Gjdpfxox Nnaws Adteug Control system: PLC-controlled Processing capacity: 20 plants in 5–6 fractions ST II VIBRO W TECHNICAL DETAILS - Sieve length: 1,200 mm - Sieve width: 800 mm - Number of sieves: 2 - Sieve inclination: continuously adjustable from min. 5° to max. 10° - Screen perforation: according to customer requirements MACHINE DETAILS Drive - Type of drive: vibratory motors - Motor power: 2 × 0.18 kW - Motor power: 2 × 0.60 kW Machine weight: approx. 480 kg LGU 252 TECHNICAL DETAILS - Number of sieves: 2 - Sieve size: 2,500 × 800 mm - Sieve perforation: "Peterson" - Inclination adjustment: continuously from min. 20° to max. 40° - Conveyor belt with cleats: 600 mm MACHINE DETAILS - Dimensions (W × L × H): 5,000 × 1,700 × 3,000 mm Drive - Motor power: 0.75 kW - Motor power: 1.5 kW - Motor power: 1.1 kW - Motor power: 2 × 0.55 kW - Operating voltage: 380 V OGK 1003-A TECHNICAL DETAILS - Number of sieves: 1 - Number of blades: 2 - Throughput: min. 40 kg/h to max. 100 kg/h MACHINE DETAILS - Dimensions & weight - Dimensions (W × L × H): 2,440 × 1,914 × 2,525 mm - Machine weight: approx. 970 kg - Motor power: 1.1 kW - Operating voltage: 380 V DOUBLE ZIG-ZAG TECHNICAL DETAILS - Throughput: max. 150 kg/h MACHINE DETAILS - Dimensions (L × W × H): 2,400 × 2,000 × 5,000 mm - Exhaust fan: 1 GENERAL EQUIPMENT - Control 208 - PLC - Aspirator I-6 - Control 308 - Belt conveyors (12 units) - Air technology - Magnets - Speed controllers Note: The machine has been dismantled and is in storage (see photos).

Condition: ready for operation (used), Year of construction: 1986, functionality: fully functional, machine/vehicle number: 1670 242, Equipment: CE marking, documentation/manual, Fully functional Westfalia separator, all documents, tooling and cover hoist crane included. Last operational 12.2024. Godpfow Icgbsx Adtoug

Condition: like new (used), Year of construction: 2014, functionality: fully functional, Tetra Alfast Direct Inline standardisation system, designed for inline standardisation of milk and cream. Capacity: 25,000 l/h. Year of manufacture: 2014 Equipped with 2 density meters, 4 electromagnetic flowmeters, and 3 flow control valves for measuring and controlling the fat content in milk and cream. - Including original documentation. - Can be operated via Profibus central system Gedpfxowf Iq Ue Adtsug - Can run stand-alone with SCADA system Sattline; we are currently working on integrating a control screen in the control panel to make stand-alone operation easier. - Excellent condition.

Condition: used, Year of construction: 2012, GEA Milk Separator MSE 100-06-177 Year of manufacture: 2012 Maximum permissible drum speed: 7200 rpm Maximum permissible feed density: 1.0 kg/dm³ Heavy liquid: 1.0 kg/dm³ Solids: 1.1 kg/dm³ Min./max. feed temperature: 5/100 °C Max. throughput: 30 m³/h Godpswayr Tefx Adtoug

Condition: ready for operation (used), A GEA clarifier (skimmer) is available. Bowl speed: 5920 rpm, material density: 1.1 kg/dm³, production capacity: approx. 10000 l/h, motor power: approx. 18 kW, construction material: stainless steel 316, documentation available. On-site inspection is possible. Guedpfx Aju S I D Djdtog

Condition: refurbished (used), Year of construction: 1973, functionality: fully functional, rotational speed (min.): 4,800 rpm, Separator WESTFALIA type SB60-06-076 for beer, fruit juices, wine, vegetable juices, tea, coffee, for citrus and tropical fruits for pectin capacity: 300-13.000l per hour with 4,800 rpm Dimensions and weight: Height: 2500 mm Length: 2000 mm Width: 1800 mm Weight: 2350 kg Technical Data: Manufacturer: Westfalia Type: SB60-06-076 Gusdpjtqf Dbefx Adtsg Year of construction: 1973 Serial number: 1668 021 Ø dl. 568 mm Drum speed: 4800 rpm Permissible density of the centrifuged material: Heavy liquid: 1.0 kg/ dm3 Solids: 1.45 kg/ dm Test books, tools, drawings available!

Condition: excellent (used), Year of construction: 2015, Manufacturer: S+S Separation and Sorting Technology GmbH Type: Unicon-D 2000/400/450/100 Year: 2015 Electrical data: - 230 V - 0,7A Gusdpfxolatz Ds Adteg - 50 Hz - IP 65 Inclusion dimensions: 2060 x 650 x 1260 mm Belt width: 390 mm Belt length: 2000 mm
