ANB-Baliu

Condition: ready for operation (used), Technical characteristics Power and Motors Voltage: 400 V Pluging: Three-phased Power: 12,5 Kw Overall dimensions Lenght: 4388 mm Width: 1165 mm Height: 1385 mm Weight: 1200 Kg Fgodpoupqb Uofx Afpjh

Condition: ready for operation (used), Technical characteristics Power and Motors Voltage: 380 V Pluging: Three-phased Power: 5 Kw Fedpfx Aoui Ebnefpogh Overall dimensions Lenght: 2910 mm Width: 1800 mm Height: 1240 mm Weight: 850 Kg

Condition: ready for operation (used), Technical characteristics Panel thickness 10 to 60 mm Edge thickness 0,4 - 3 / 8 mm Minimum panel length 150 mm Calibration Gluing End cutting Trimming Rounding Radius scraper aggregate Glue scraper Brushing Power and Motors Fjdpfxouaih Tj Afpegh Power: 8.6 Kw Overall dimensions Weight: 1600 Kg

Condition: ready for operation (used), Technical characteristics Part thickness : 8 to 50 mm Edge thickness: 0.4 to 8 mm Programmable control with group indexing Feed rate 11 m/min Composition: Edge insertion device Milling unit (straightening) Pre-melting device Edge magazine End cutting unit Milling unit (flush) Fgsdpfx Afet Hncwepoh Form milling unit Surface scraping unit Polishing brushes Suction nozzles : 1 x ⌀ 120 mm / 3 x ⌀ 60 mm / 1 x ⌀ 100 mm 6 bar pneumatic system Compact and complete machine Power and Motors Voltage: 400 V Pluging: Three-phased Power: 10,5 Kw Overall dimensions Lenght: 4860 mm Width: 900 mm Height: 1610 mm Weight: 2000 Kg

Condition: ready for operation (used), Technical characteristics Power and Motors Voltage: 400 V Pluging: Three-phased Fodetu R Sdopfx Afpjgh Overall dimensions Weight: 1428 Kg

Condition: ready for operation (used), Technical characteristics Epaisseur de panneau maxi50mm Epaisseur de panneau mini8 mm Epaisseur de chant maxi3mm Epaisseur de chant mini0.4 mm Caractéristiques plaqueuseEnd cut unit Fgodpfx Afetupfdopoh Power and Motors Overall dimensions

Condition: ready for operation (used), Technical characteristics Calibration of 2 diamond tool holders Gluing with hot melt glue tray Automatic edge feeding Pressure group Tiltable end cutting Straight / chamfer / 1/4 round trimming Edge scrapers Brush Capacity : panel thickness 50 mm edge thickness roll 0.4 - 3 mm edge thickness strips 8 mm Feed 10m/min Fgjdpfx Aettrp Sefpoh Power and Motors Overall dimensions Lenght: 3700 mm

Condition: ready for operation (used), Technical characteristics motorized scraper edge length cut workpiece height max: 65 mm - min 11 mm max temperature setting 400 ° C feed speed 4m / min quick settings easy to use without compressed air for pre-glued PVC, melamine and polyester Power and Motors Fodpfx Afjtriiajpogh Voltage: 220 V Overall dimensions

Condition: ready for operation (used), Technical characteristics Panel width : 240 mm to 1200 mm Panel length : 240 mm to 3000 mm Panel thickness : 10 mm to 60 mm Band thickness : 0,3 mm to 3 mm Pin inner axis : 500 mm ENTRY / EXIT : Transfer realised with special chains covered in stainless long lasting rubber Entry pivoting guides adjustable depending on panel type Closing device on above pressor to assure the pressing of the panel against the pins Delaying device in entry for optimization of different width panel dimensions Single part rigid structural longitudinal chassis ADVANCE CHAIN : Continuous speed tuning from 10 to 40 m/min by INVERTER CN direct numerical command The stop pins are automatically adjusted in height by CN and can have : height/thickness 12- 18-23 mm from the chain level Chain pin inner axis 500 mm BELT PRESSOR SOUNDPROOF CABINS All machining groups inside the machine are surrounded by soundproof material Internal lighting CN command placed at entry of the machine, fixed chassis side NUMERICAL CONTROL Video interface Positioning axis control Chain advance speed tuning Pressor height adjusting depending on panel thickness Automatic adjustment of band changing and band charger Moulding list management Sequenced motor startup Possibility of connection to a barcode reader Module NC410 Fgodpfx Aotrihvofpsh MILLING GROUP Timed pneumatical anti shard action for transversal milling Tool rotation speed : 6000 rpm Motor power : 5.8 kW Tool Ø : 200 mm DOUBLE SUPERPOSED SPLINTERS Simultaneous displacement for thickness adjustment and independent adjustment vertical and horizontal Cast iron bearing structure Tool speed rotation : 6000 rpm Motor power : 5.8 kW Tool Ø : 205 to 250 mm EXTENSION MACHINE to 3200 mm AUTOMATIC CENTRAL SUPPORT 10.5 This device allows support of parts that due to their dimensions or thickness can subdue central bending Fully automatic activation GLUING GROUP SP3 Straight bands in resin, melamine, ABS, PVC, PP EVA basis thermoplastic glue Independent Teflon covered changeable glue tank Glue level sensor inside the tank Glue input roller speed synchronized with the chain advance Breveted pre fusion device Glue granule container (8kg) Band presence detection device Automatic band changing procedure 6 POSITION MOBILE BAND CHARGERS END CUTTING End cutting unit for edge thicknesses up to 3 mm Device for quick removal in stroke Automatic exclusion of the unit when the motors are stopped Speed : 12000 rpm Panel projection : 35 mm Edge thickness : 0.3 to 3 mm Panel thickness : 10 to 60 mm Interval between 2 consecutive panels : 350 mm WHOLESALE TRIMMING UNIT 2 superimposed motors with horizontal axis Automatic pneumatic exclusion of the group Speed : 12000 rpm Motor power : 1.3 + 1.3 kw Panel thickness : 10 to 60 mm Tool diameter : 80 mm ANGLE TRIMMING GROUP The adjustment of the position of the tool in relation to the material is automatic with predefined dimensions on 4 pre-adjustable in-line stops The in-line stops are automatically selected by the control Use on the MULTIPROFIL tool group to change profile/shape without replacing the tool Tools are equipped with 20° chamfer and 1.5-2-3 mm radius Speed : 12000 rpm Motor power : 0.65 + 0.65 kw Panel thickness : 10 to 60 mm TOP / BOTTOM ROUNDING GROUP Rounding copier for the upper and lower stops of the panel with oscillating movement for the continuation of the panel Quick release system of the motor-holder groups Automatic exclusion of the tool with stopped motors Tool rotation speed : 12000 rpm Motor power : 0.3 kw

Condition: ready for operation (used), Technical characteristics Composition : Pre-milling unit Gluing unit End cutting unit Milling unit Glue scraping unit Touch screen control Maximum workpiece thickness : 55 mm Maximum edge thickness: 2 mm Feeding speed : 5.5 m/min Extendable parallel bar 5 x 100 mm diameter suction nozzles Power and Motors Voltage: 380 V Pluging: Three-phased Power: 9,8 Kw Overall dimensions Lenght: 2389 mm Width: 1125 mm Fgedpfjtrihnox Afpeh Height: 1305 mm

Condition: ready for operation (used), Technical characteristics Fodpfx Afstrihkopjgh Power and Motors Voltage: 400 V Pluging: Three-phased Overall dimensions Lenght: 5250 mm Width: 1600 mm Height: 1500 mm Weight: 1600 Kg
