Condition: used, Year of construction: 1985, LORENZ - LS 1000 - 1985 Bwsdpfx Ahsyl Snvo Iji - used machine - good condition Main technical data: - max. Modul 10 - stroke max. 200 mm - with two extra tables diameter 850 mm and 1.500 mm - saddle of the column 250 mm - some cutting tools - set of change gears - programm for cutting in 1-2-3-4- pass/cycles - programm for spiral cutting - some supports and clamps of the workpieces

Condition: used, Year of construction: 2017, LIEBHERR - LSE 200 - 2017 - used condition as shown on photos - under power, can be tested - more photos available Bodpeyl Si Tjfx Ah Iewi

Condition: used, Year of construction: 1988, TOS - OHA 16 CNC - 1988/2022 - system NCT (hungarian FANUC, 99% same as normal FANUC) - 5 axis, 5 drives (but yellow rotary table is not part of delivery) - max module 5 - max diameter 200mm - max stroke 50mm - number of stokes 100-600 Bwjdpfx Asyl Nmvoh Ioi - max stroke 140 mm - full CNC controll, Shaping head movable, max stoke 140mm - internal and external spur gear - keyway, spline possible - under power - very good condition

Condition: repair required (used), Year of construction: 2008, functionality: not functional, machine/vehicle number: 06-13633, Technical characteristics: Work Area - Elevation: 160 mm - Minimum center distance between table axis and spindle: -30 mm - Maximum center distance between table axis and spindle: +150 mm - Minimum distance between table surface and cutter spindle: 275 mm - Maximum distance between table surface and cutter spindle: 345 mm - Manual transverse movement of the column: ±20 mm - Maximum workpiece external diameter: 250 mm - Bore diameter: 100 H7 mm Workpiece Specifications - Maximum nominal module (for steel with an approximate tensile strength of 600 N/mm²): 3 mm - Minimum pitch diameter (internal gearing): 60 + d0s mm, where d0s is the external diameter of the cutter (in mm) - Maximum external diameter (internal gearing): 280 mm - Maximum band (toothed area) width: 42 mm - Maximum stroke length for toothing: 50 mm - Maximum spindle travel: 70 mm Load Capacity - Maximum load supported by the table (including fixtures): 150 kg - Maximum force exerted by the tailstock: 1,500 kg - Maximum attainable helix angle (with hydrostatic guide): ~45° Cutter Spindle - External diameter: 85 mm - Cutter holder bore: 45 H3 mm Electrical Equipment - Operating voltage: 400 - 480 V - Control voltage: 24 V - Magnetic voltage: 24 V - Cable cross-section: 16 mm² - Connected power: 15 kW - Protection: 50 A Dimensions - Overall dimensions: Length = 2980 mm, Width = 1650 mm, Height = 2165 mm - Weight: 5700 kg Main Features and Capabilities: - Vertical Design: Optimized for chip evacuation and easy loading/unloading - Control: Siemens Sinumerik 810D/840D - High Precision: Positioning accuracy via Heidenhain linear scales - Measurement system: Marposs T25 (for angle alignment or zero-point rotation definition) - Oil filtration and cooling system Bedpfx Aoxwl Tzjh Iowi - Magnetic chip conveyor Machine Status: NOT WORKING: NC does not start

Condition: good (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: 06-13796, Technical characteristics: Work Area - Elevation: 160 mm - Minimum center distance between table axis and spindle: -30 mm - Maximum center distance between table axis and spindle: +150 mm - Minimum distance between table surface and cutter spindle: 275 mm - Maximum distance between table surface and cutter spindle: 345 mm - Manual transverse displacement of the column: ±20 mm - External diameter: 250 mm - Bore diameter: 100 H7 mm Workpiece - Maximum nominal module (in steel with a tensile strength of approximately 600 N/mm²): 3 mm - Minimum pitch diameter (internal gearing): 60 + d0s mm - Maximum external diameter (internal gearing): 280 mm - Maximum width of the toothed band: 42 mm - Maximum stroke length for tooth cutting: 50 mm - Maximum spindle travel: 70 mm Load Capacity - Maximum load on the table (including fixtures): 150 kg - Maximum force applied by the tailstock: 1,500 kg - Maximum achievable helix angle (hydrostatic guide): approx. 45° Cutter Spindle - External diameter: 85 mm - Cutter holder bore: 45 H3 mm Electrical Equipment - Operating voltage: 400 - 480 V, Control voltage: 24 V, Magnetic voltage: 24 V, Cable cross-section: 16 mm² - Connected power: 15 kW, Protection: 50 A Dimensions - Overall dimensions: Length = 2980 mm, Width = 1650 mm, Height = 2165 mm - Weight: 5700 kg Main Features and Capabilities: - Vertical design: Ensures optimal chip evacuation and easy loading/unloading. - Control: Siemens Sinumerik 810D/840D Bwsdpfx Ajxwl N Aoh Isi - High Precision: Positioning accuracy by Heidenhain linear scales - Measuring system: Marposs T25 (for angular alignment or zero-point rotation definition) - Oil filtration and cooling system - Magnetic chip extraction conveyor

Condition: good (used), Year of construction: 2010, functionality: fully functional, machine/vehicle number: 06-13795, Technical characteristics: Work Area: - Elevation: 160 mm - Minimum center distance between table axis and spindle: -30 mm - Maximum center distance between table axis and spindle: +150 mm - Minimum distance between table surface and cutter spindle: 275 mm - Maximum distance between table surface and cutter spindle: 345 mm - Manual transverse displacement of the column: ±20 mm - External diameter: 250 mm - Bore diameter: 100 H7 mm Workpiece: Bodpfoxwlmuex Ah Iewi - Maximum nominal module (in steel with tensile strength approx. 600 N/mm²): 3 mm - Minimum pitch diameter (internal gearing): 60 + d0s mm - Maximum external diameter (internal gearing): 280 mm - Maximum width of the toothed band: 42 mm - Maximum stroke length for tooth cutting: 50 mm - Maximum spindle travel: 70 mm Load Capacity: - Maximum table load (including fixtures): 150 kg - Maximum force exerted by the tailstock: 1,500 kg - Maximum achievable helix angle (hydrostatic guide): ~45° Cutter Spindle: - External diameter: 85 mm - Cutter holder bore: 45 H3 mm Electrical Equipment: - Operating voltage: 400 - 480 V - Control voltage: 24 V - Magnetic voltage: 24 V - Cable cross-section: 16 mm² - Connected power: 15 kW - Protection: 50 A Dimensions: - Overall dimensions: Length = 2980 mm, Width = 1650 mm, Height = 2165 mm - Weight: 5700 kg Main Features and Capabilities: - Vertical design: Optimal chip evacuation and easy loading/unloading - CNC control: Siemens Sinumerik 810D/840D - High precision: Positioning accuracy via Heidenhain linear scales - Measuring system: Marposs T25 (for angular alignment or rotation zero-point definition) - Oil filtration and cooling system - Magnetic chip extraction conveyor Machine status: Operational (WORKING)

Condition: used, Specifications Manufacturer LORENZ Model LS 630 Condition Used Stock Number DCL1722 Bjdpjwr Dx Usfx Ah Iewi Module 12 Max diameter 630 mm Working stroke 220 mm Center distance worktable / cutter spindle 450 mm Machine weight 10.000 kg Spindle diameter 110 mm Table diameter 730 mm distance between table and spindle 580 mm Ø table hole 450 mm Description Equipped with : Change gears Manuals
