Condition: used, Year of construction: 1986, grinding length 5000 mm grinding width 2500 mm workpiece height 1600 mm column daylight 2680 mm Passage height 1720 mm table surface area 5500x2240 mm T-slot - distance 250 mm T-slot - width 36H12 mm T-slots 9 workpiece weight 50.000 kg table speed -stepless- 1-40 m/min grinding motor 22 kW turning speeds 960 U/min total power requirement 146 kW weight of the machine ca. 140 t Bljdpfx Ajyqu A Hsh Ijd dimensions of the machine ca. 17,5x10,5x6,6 m Peripheral grinding support: 960 rpm, 22 kW Universal grinding support: 7 kW, 500-2900 rpm Crooked grinding device The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, grinding length 4000 mm grinding width 1450 mm workpiece height 1250 mm column daylight 1500 mm Passage height 1420 mm table surface area 4240x1250 mm T-slot - distance 160 mm T-slot - width 28H12 mm T-slots 10 workpiece weight 20.000 kg table speed -stepless- 1-50 m/min grinding motor 22 kW turning speeds 960 U/min total power requirement 125 kW weight of the machine ca. 67 t dimensions of the machine ca. 13,2x7,8x5,1 m Peripheral grinding support: 960 rpm, 22 kW Universal grinding support: 7 kW, 500-2900 rpm Dressing device The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity Blodpjyqr Ugsfx Ah Ied More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: good (used), Year of construction: 2015, operating hours: 250 h, functionality: fully functional, For Sale: Guideway Grinding Machine (Retrofitted from Metal Planing Machine) We offer a robust guideway grinding machine, which has been professionally converted from an original metal planing machine. The main advantage lies in its relatively compact footprint in relation to the workpiece capacity. Technical Specifications: • External dimensions (LxWxH): 4,800 x 2,500 x 2,000 mm • Required floor space: 4,800 x 3,500 x 2,700 mm (+ control cabinet, coolant tank, access) • Table size: 2,000 x 800 mm • Distance between columns: 1,000 mm • Travel paths (X/Y/Z): 2,000 / 1,000 / 600 mm Upgrades & Features: • New ball screw spindles and bearings • 2 new motors + 2 overhauled motors • 3 new frequency inverters • New Siemens SINUMERIK 802C baseline CNC system • Large grinding spindle: 2,840 rpm – refurbished + new motor • Small grinding spindle: 18,000 rpm – refurbished • Including control cabinet, coolant tank with pump, and separate, wall-mounted inverter for small spindle Inspection and trial run possible by appointment. Please contact us for more information. Bsdpjxx Uudefx Ah Isld

Condition: good (used), Year of construction: 1972, Slideway grinding machine WMW SFBZ 2200/6000 Manufactured by WMW Germany in 1972 Main technical data: Table size: 2240x6000 mm Max. grinding width: 2200 mm Max. grinding length: 6000 mm Max. grinding height: 2000 mm Max. workpiece weight: 15,000 kg Machine weight: 130 tons For more information, please contact us. Bjdsw U A Rmopfx Ah Iold

Condition: ready for operation (used), Year of construction: 1979, functionality: fully functional, machine/vehicle number: 2.4212.06, grinding width: 1,450 mm, workpiece weight (max.): 11,000 kg, grinding length: 3,000 mm, table width: 3,000 mm, table length: 1,250 mm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Table and Workpiece Clamping area of the table: 3,000 x 1,250 mm Overall table size: 6,000 x 1,800 x 1,000 mm Clearance between columns: 1,650 mm Grinding length: 3,000 mm Grinding width: 1,450 mm Max. workpiece height: 1,250 mm Cross beam adjustment: 1,250 mm Max. workpiece weight: 11 t Table feed rate: 1 to 45 m/min Control System and Grinding Supports Universal grinding support: 7.5 kW Swiveling range of grinding spindle: +/- 110° Grinding wheels (universal support): 500 x 60 mm Vertical adjustment (universal support): 350 mm Bedpfxow Srzco Ah Ijld Peripheral grinding support: 22 kW Grinding wheels (peripheral support): 600 x 120 mm Vertical adjustment (peripheral support): 150 mm MACHINE DETAILS Electrical Data Total connected load: 40 kW Dimensions & Weight Weight: approx. 45 t Installation dimensions: 12,000 x 6,000 x 4,800 mm Note: The machine can be dismantled and loaded for €10,000.

Condition: ready for operation (used), Year of construction: 1980, operating hours: 15,339 h, functionality: fully functional, grinding width: 2,650 mm, grinding length: 11,500 mm, table load: 10,000 kg, grinding height: 2,000 mm, grinding wheel diameter: 600 mm, The machine was retrofitted by the seller in 2020! The machine remained powered until 01.08.2025! TECHNICAL DETAILS Grinding Area: Bsdow I Ebuopfx Ah Ijld Maximum grinding width: 2,650 mm Maximum grinding length: 11,500 mm Maximum grinding height: 2,000 mm Maximum workpiece height: 2,120 mm Maximum distance between columns: 2,670 mm (by removing the guideways, a width of 2,750 mm can be achieved) Table size: 2,240 x 12,000 mm Maximum table load with even weight distribution: 10,000 kg/m Travel and Adjustment Ranges: Cross slide travel: 1,800 mm Vertical adjustment of universal grinding support: 450 mm Vertical adjustment of grinding support with horizontal spindle: 250 mm Head inclination: ±90° Grinding Spindle: Wheel diameter: 600 mm Wheel width: 120 mm Wheel bore: 200 mm Wheel speed: 1,000 rpm Spindle power: 30 kW MACHINE DETAILS Control: Fanuc CNC 31i Model A Operating hours: 15,339 hours EQUIPMENT Enclosure without roof

Condition: excellent (used), x: 3200mm Blodpfx Aowrx U Dsh Ijd y: 1500mm z: 1000 CNC FAGOR 8050 (7 axes)

Condition: used, Year of construction: 2000, functionality: fully functional, grinding width: 2,600 mm, workpiece weight (max.): 35,000 kg, grinding length: 12,000 mm, distance between stands: 2,800 mm, grinding height: 1,600 mm, Portal Grinding Machine 12x2.6m Brand: GIORIA Year:2000 Controller: Siemens 840C (twin operator panel with HPU) Table: 12.500 x 2.600mm Heigh feed: 1.600mm Hydrostatic table Including grinding disc etc. Bedpfx Aswql H Deh Ijld

Condition: used, Technical details: grinding length: 12000 mm grinding width: 2800 mm workpiece height: 2510 mm max. workpiece weight: 24.000 kg table surface area: 11990 x 2500 mm distance between columns: 2820 mm cross rail adjustment: 2510 mm table feed: 1 - 40 m/min total power requirement: 110 kW weight of the machine ca.: 151 t dimensions of the machine ca.: 32,5 x 9 x 6,73 m .....machine is in top condition for high precision work! with CNC SIEMENS 840 D 1 universal grinding head, 22 kW swivelling of the grinding spindle +/-110° grinding wheel dimension 700 x 130 mm vertical stroke 1000 mm with dressing unit 1 surface grinding head, 30 kW grinding wheel dimension 600 x 150 mm vertical stroke 230 mm with dressing unit coolant and filtering unit diverse grinding wheel flanges Bledpfx Ahowc A Sne Iod *

Condition: used, grinding length 4000 mm grinding width 1450 mm workpiece height 1250 mm control Siemens 840 D workpiece weight 11000 kg column daylight 1460 mm Blsdpfxowa Dx Do Ah Iod table surface area 4000 x 1250 mm table feed 1 - 45 m/min cross rail - adjustment 1250 mm total power requirement 40 kW dimensions of the machine ca. 12,3 x 6 x 4,8 m Equipment/Accessories: - 1 universal grinding support, 7.5 kW Swivel range grinding spindle +/- 110° grinding disc dimensions Ø 500 x 60 mm Vertical adjustment 350 mm with puller - 1 peripheral grinding support, 22.5 kW Grinding wheel dimension Ø 600 x 100 mm Vertical adjustment 150 mm with puller - with 6 magnetic plates arranged on the table - seperate clamping table - various grinding wheels and flanges - Technical documentation

Condition: used, grinding length 12000 mm grinding width 2800 mm workpiece height 2510 mm control Siemens 840 D workpiece weight 24000 kg Bledpfx Aowa Dxwsh Iod column daylight 2820 mm table surface area 11990 x 2500 mm table feed 1 - 40 m/min cross rail - adjustment 2510 mm total power requirement 110 kW dimensions of the machine ca. 32,5 x 9 x 6,73 m weight of the machine ca. 151 t Equipment/Accessories: - 1 universal grinding support, 22 kW swivel range of grinding spindle +/- 110° grinding wheel dimensions Ø 700 x 130 mm vertical adjustment 1000 mm with puller - 1 peripheral grinding support, 30 kW grinding wheel dimension Ø 600 x 150 mm vertical adjustment 230 mm with puller - Coolant and filter unit - Various grinding wheels and flanges - Technical documentation

Condition: excellent (used), Year of construction: 1973, grinding width: 1,600 mm, grinding length: 3,500 mm, Waldrich Coburg 15-10 S20 20 Bedpfsv Th Hgsx Ah Isld

Condition: used, Year of construction: 1983, grinding length 8400 mm grinding width 1450 mm workpiece height 1250 mm surface area 8000 x 1250 mm table height over floor 920 mm distance between columns 1470 mm workpiece weight max. 59700 kg weight of the machine ca. 59,7 t dimensions of the machine ca. 22 x 5 x 5 m Adjustment ranges: -Crossbeam, vertical 1250 mm -Grinding support, horizontal 3100 mm Adjustment speeds: -Machine table (X-axis) infinitely variable 1-45 m/min Table creep speed 5 m/min Bsdpfx Ahsvr Hgve Isld -Grinding support, horizontal (Y-axis) Rapid traverse 3000 mm/min Feed, step 0.001-0.099 mm Feed rate, continuous 100-3000 mm/min Creep speed 18+1 mm/min Tip infeed 0.001-0.019 mm -Crossbeam (W-axis) Rapid traverse 410 mm/min Table drive: -Oil transmission, Type Iv4 -Cylinder-Ø 185 mm -Piston rod Ø 130 mm -Drive motor 22 kW

Condition: used, Year of construction: 1961, grinding length 4000 mm grinding width 1100 mm workpiece height 1100 mm weight of the machine ca. 21 t Bledpfx Ahevk Nlls Iod Modernisierte Präzisions-Flach-und Führungsbahnschleifmaschine aus Überholungsbetrieb. Geschliffen wurden unter anderem Betten für neue KERN Drehmaschinen. -Digitalanzeigen nachgerüstet -Umbau auf Kugelrollspindeln in der Querachse -Schleifspindel für Umfangsschliff -schwenkbare Schleifspindel für Untergriffe -Originalschabbild in der Längsachse -Elektrik erneuert -Aufspannfläche 4300 x 1500 mm Bei Nutzung einer Grube können wesentlich höhere Werkstücke geschliffen werden!!!

Condition: ready for operation (used), Slideway grinding machine SFBZ 1800x4000 Length of grinding max, mm 4000 Width of grinding max, mm 1800 Dstance between column mm 2200 Bodpfx Ahouug A Es Iold Height of grinding max, mm 1250 Table size, mm 4000 x 1800 Grinder wheel size max, mm 630 x 100 x 305 Weight of workpiece max, kg 15000 Weight of machine, kg 56.000

Condition: good (used), Year of construction: 2012, grinding width: 2,000 mm, workpiece weight (max.): 18,000 kg, grinding length: 8,000 mm, Manufacturer: Waldrich Coburg Type: 30-10 S 3640 Control system: SIEMENS 840D Year of construction: 2012 Guideway / Slide way / Surface Grinding Machine Universal grinding head S10 with 110 Degree tilting / 2500 Rpm / 7.5 kW Vertical grinding head S30 with Ø 600 x 150 / 930 Rpm / 22 kW Double SIEMENS 840D Control panel Left & Right side machine KNOLL HL650/4000 Filtration system new 2023 Automatic doors (4x) for easy machine / load / clamping acces Hydraulic table drive with 18000 kg work load Rebuild in 2012 for 1.5 Mil EUR Large package flanches and stones Large package spare parts / ballscrews / measuring / protection covers Specifications Metric US Standard X - axis 8825 mm Y - axis 3010 mm Z - axis 2500 mm Table length 8000 mm Table width 1800 mm Table load 18000 Feed X - axis 1 - 45.000 mm/min. Feed Z-axis 100 - 3000 mm/min. Grinding stone dimensions 600 x 150 mm Power output Blodjtp T N Tspfx Ah Ijd 22 kW Rotational speed 930 rpm Coolant system Knoll 4000 L Feed Y - axis 1 - 700 mm/min. Dimensions (estimate) length 24360 mm width 9550 mm height 7000 mm weight 80200 kg Please note: The information on this page has been obtained from the manufacturer to the best of our knowledge and belief, and where possible, the information is given in good faith but accuracy cannot be guaranteed. Accordingly, it does not constitute a representation or contract and we recommend that you check all relevant details.

Condition: used, Guideway and surface grinding machine WMW FRITZ HECKERT Aschersleben type SZ 1000 x 1250 x 3000 / 344 make no. 13.2236.2 year of construction 1989 nominal grinding area 3000 x 1250 mm table clamping area 3240 x 1000 mm grinding length max. 3300 mm Machining width 1250 mm Machining height 1250 mm grinding wheel diameter (surface grinding support) max. 600 mm grinding wheel width (flat grinding support) max. 100 mm grinding wheel diameter (swivel support) max. 450 mm Mains connection 400 Volt, 50 Hz - grinding support swiveling, drive power 16,5 kW, infinitely variable speed - grinding support for surface grinding, drive power 15 kW, infinitely variable speed - new electrical control, based on SIEMENS S7 from year 2001 - new electric control cabinet beside, year of construction 2001 - infinitely variable grinding wheel speed at both grinding supports - swiveling wheelhead for guideway and profile grinding - swivel-mounted and height-adjustable control panel - coolant system adjacent - Hydraulic system adjacent - oil circulation lubrication adjacent - Various grinding wheels and holders space requirement complete L x W x H 11900 x 7700 x 4600 mm weight 45 ton. Bjdpfxohv A A Dj Ah Iold very good condition
