Condition: used, functionality: fully functional, Table size (X-Y / mm) 2730 x 1270 Kdjdpfxoz Dua Uj Akwst Travel (X / mm) 2500 Travel (Y / mm) 1270 Travel (Z / mm) 950 Control type DNC Fidia F1 Manual tool changer Manual 360° rotating head

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 52335, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, table load: 6,000 kg, controller model: Heidenhain TNC 155, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 3,000 mm Travel range, Y-axis: 1,000 mm Travel range, Z-axis: 1,000 mm Table load capacity: 6 t Kjdpfx Aszz Rmnskwedt MACHINE DETAILS Control system: Heidenhain TNC 155 Apparent power: 45 kVA Phases: 3 Voltage: 380 V Frequency: 50 Hz Current: 85 A EQUIPMENT Manual swivel head, 0.1°

Condition: good (used), Year of construction: 1999, functionality: fully functional, Table 3.000 x 1.000mm, X 2,700 Y 1,200 Z 1,500mm, Auto index head, Kdjdpfx Aezzk T Uskwot

Condition: ready for operation (used), Year of construction: 1992, functionality: fully functional, machine/vehicle number: 9220212, travel distance X-axis: 3,200 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 2,000 rpm, workpiece weight (max.): 4,000 kg, TECHNICAL DETAILS X-axis travel: 3,200 mm Y-axis travel: 1,000 mm Z-axis travel: 1,000 mm B-axis rotation: 360° C-axis rotation: 360° Spindle speed range: 40 – 2,000 rpm Tool holder: ISO 50 Main spindle power: 15 kW Number of axes: 3 Table length: 3,500 mm Table width: 800 mm Maximum workpiece weight: 4,000 kg MACHINE DETAILS Control system: Conventional Model: Bed milling machine with traversing table Dimensions & Weight Dimensions (L x W x H): 5,300 x 3,000 x 2,700 mm Shipping weight: 11,000 kg Number of shipping packages: 1 EQUIPMENT Digital display: Sony 3-A Kdsdpezza U Isfx Akwjt

Condition: ready for operation (used), Year of construction: 2006, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,500 mm, table load: 10,000 kg, rotational speed (max.): 3,000 rpm, overall weight: 22,000 kg, CNC Heidenhain TNC 530 Travel: 4000 x 1200 x 1500 mm Table: 4200 x 1000 mm Maximum table load: 10,000 kg Ksdszx El Topfx Akwjdt Maximum spindle speed: 3000 rpm Spindle center coolant supply Chip conveyor Weight: 22,000 kg

Condition: used, Year of construction: 2006, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 6,000 rpm, spindle speed (min.): 20 rpm, table width: 1,000 mm, table load: 11,000 kg, table length: 3,200 mm, type of input current: AC, workpiece weight (max.): 11,000 kg, overall weight: 18,500 kg, input voltage: 400 V, Technical Description CNC bed milling machine in very good condition, manufactured by MTE. Year of manufacture: 2006 Control system: HEIDENHAIN iTNC 530 24-position tool changer Chip conveyor Travel range: Longitudinal (X) = 3,000 mm Transverse (Y) = 1,200 mm Vertical (Z) = 1,500 mm Work table/clamping surface: Length = 3,200 mm Width = 1,000 mm Maximum table load: 11,000 kg Tool holder: ISO 50, DIN 69871 AD Draw bolt: DIN 69872 Form A Main drive: Maximum drive power: from 198 rpm, 30 kW Spindle speed range: Spindle speed = 20 to 6,000 rpm Feed rates: X, Y, and Z axes mm/min 2 – 15,000 Maximum rapid traverse rate: X, Y, and Z axes mm/min 25,000 Kjdpfjzu R Raex Akwsdt Space requirement: Length approx. mm 8,100 (without transverse conveyor + 1,280 mm) Height approx. = 3,300 mm Width approx. (at Y = 1,200 mm) mm 5,000 Weight: approx. 18,500 kg Connection power: approx. 52 kVA

Condition: good (used), Year of construction: 1995, functionality: fully functional, Control system: Heidenhain iTNC 530 Operating hours: 54631 h X-axis 3500 mm Y-axis 1000 mm Z-axis 900 mm Drive power 30 kW Speed range 20–3800 rpm Rapid traverse 15 m/min Feed rate 4 m/min Clamping surface 2x 1600 x 960 mm Max. table load 2 x 4000 kg Machine weight (approx.) 21 t Machine dimensions (WxDxH) 10770 x 4100 x 3150 mm Technical data / Accessories Universal bed-type milling and boring machine Milling head position: Vertical, horizontal (top, center, left, right) Heidenhain TS 120 3D touch probe Kekeisen TW 32 drum-type tool changer Knoll hinged-belt chip conveyor Kdjdpfxjzufi Rj Akwjt

Condition: used, Year of construction: 2000, x-travel 3000 mm y-travel 1400 mm z-travel 1500 mm table-size 3200 x 1100 mm control TNC 430 B spindle turning speed range 60 - 4000 U/min spindle taper ISO 50 feeds mm/min table load 10 t milling drive 24 kW Center of spindle to wall or column 1229 mm total power requirement 50 kW weight of the machine ca. 22 t dimensions of the machine ca. 6,5 x 3 x 3 m control: Heidenhain TNC 430 B digital. Universal milling head is automatically Kdjdpfxozrpnxe Akwet swivable and turnable in 1,5° steps. Machine has a 20 position ATC, a chip conveyor, an adaptable high speed spindle (30.000 rpm) and a mist cooling arrangement. Machine in program for 25.616 hours.

Condition: used, Year of construction: 2002, x-travel 3000 mm y-travel 1600 mm z-travel 1500 mm table-size (2x) 2000 x 2000 mm control TNC 430 B spindle turning speed range 60 - 3600 U/min spindle taper ISO 50 feeds mm/min table load 10 t milling drive 28 kW total power requirement 48 kW weight of the machine ca. 47 t dimensions of the machine ca. 6,5 x 3 x 3 m control: Heidenhain TNC 430 B digital. Machine has 6 axes controled, X/Y/Z, C- Kdsdezrpnrjpfx Akwet axe table rotation and A/B axes for universal head. Machine has a 40 position ATC, cooling through spindle, a chip conveyor, an adaptable high speed spindle (30.000 rpm) and two pallets in the pallet changer. Machine in program 22.347 hours.

Condition: ready for operation (used), Year of construction: 2000, operating hours: 22,000 h, functionality: fully functional, machine/vehicle number: 28217, travel distance X-axis: 2,700 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 6,000 rpm, overall weight: 18,500 kg, The combination of the Zayer 20 KF 3000 machine, the Heidenhain TNC 426 control system, and a swivel universal head (Huron type) transforms this milling machine into a versatile and powerful production hub. The swivel head completely eliminates the biggest drawback of large machines – the need to constantly reposition and re-clamp heavy workpieces for machining at different angles. Here’s how precisely this head works with the Heidenhain system and what possibilities it offers. Kinematics and capabilities of the swivel head. The head in ZAYER machines consists of two inclined dividing planes that rotate relative to each other. This design allows for: Transition from vertical to horizontal: In a few moments, you can change the machine from a vertical machining center to a horizontal milling machine. This makes it possible, for example, to simultaneously machine the top of a workpiece and, a moment later, mill its sides. Milling at any angle: The head allows you to position the spindle in space at unusual angles, which is crucial for machining inclined surfaces, chamfering large plates, or creating converging pockets. Enormous rigidity: Although the head is movable, its design locks with tremendous force (mechanically or hydraulically). The machine does not lose any of its ability to perform heavy rough machining (so-called “hogging” with a large chip). Cycle 19 and PLANE in Heidenhain TNC 426 – The magic of software. The biggest challenge with a swivel head is the mathematics – when you tilt the tool, the zero points in the X, Y, and Z axes change. Heidenhain TNC 426 solves this automatically using dedicated geometric functions: Cycle 19 (Machining Plane): You inform the control system of the angle at which you have physically rotated the head. The computer immediately recalculates the entire coordinate system. The tool moves in the axis at an angle, and you program as if you were working on a flat surface. Coordinate transformation: You don't have to manually calculate the tool offset after rotating the head. The controller knows the exact dimensions of the machine's kinematics and automatically corrects the position of the X, Y, and Z axes. Angular drilling: After calling Cycle 19, the standard drilling cycle (e.g., deep drilling) automatically performs the feed movement in the inclined axis – the operator writes the program in the Z axis, and the machine physically moves with a combination of the X, Y, and Z axes. Production benefits in the workshop. Machining 5 sides of a workpiece from a single setup: You place a 5-ton steel block on the table. You clamp it once. By rotating the head, you machine the top and all four sides without moving the workpiece with a crane. This guarantees perfect maintenance of geometric tolerances (perpendicularity and parallelism of the surfaces). Time savings and safety: Repositioning a large workpiece on the table often takes hours and carries the risk of accidents or damage to the table. With this head, you only reposition the tool – manually using dividing plates or in an automatic version from the program. Kdsdozrd Tvepfx Akwjt

Condition: ready for operation (used), functionality: fully functional, Zayer milling machine, model 60BM, with a table of 2030mm x 700mm, featuring a dimension display, and a motorized ram. Longitudinal travel: 1,524 mm, ram travel: 712 mm, vertical travel: 560 mm, ISO 50, speeds: 24-1685 rpm, spindle motor power: 15 hp. The machine has been inspected. Approximate machine weight: 6,500 kg, in good condition. Ksdpfxezmp Ine Akwjdt

Condition: like new (used), Year of construction: 2018, operating hours: 500 h, functionality: fully functional, LAGUN BM4RT Bed Milling Machine Kedpfx Aszmpydekwsdt Manufacturer: Lagun Type: BM4RT Year of manufacture: 2018 Condition: operational, used, like new Operating hours: 1650 h Spindle hours: 438 h Control system: Heidenhain iTNC 640 Video available. Further information upon request.

Condition: excellent (used), Year of construction: 2003, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,400 mm, spindle speed (max.): 4,000 rpm, table width: 1,200 mm, table load: 4,000 kg, table length: 3,860 mm, mount diameter: 50 mm, total height: 3,640 mm, total width: 4,500 mm, total length: 8,900 mm, rotational speed (max.): 4,000 rpm, workpiece weight (max.): 4,000 kg, overall weight: 24,000 kg, FIBRO indexing rotary table 800 mm Closed covered machine with doors for easy acces Indexing head 2.5 x 2.5 Degrees Automatic lubrication Double chain chip conveyor Under power 1e owner machine X - Travel: 3500mm Y - Travel: 1200mm Z - Travel: 1400mm Table Length: 3860mm Table Width: 1200mm Table load: 4000 Table Ø: 800mm Feed rate X-Axis: 20000mm/min. Feed rate Y-Axis: 20000mm/min. Feed rate Z-Axis: 20000mm/min. Spindle Taper: 50ISO/Bt/Mk Power on spindle: 30kW Speeds / ranges: 4000Rpm ATC / revolver: 30 Number of controlled axis:3 + 1 Chip conveyor: Yes Coolantsystem: Yes Kdedpfozl Afdjx Akwjt Length: 8900mm Width: 4500mm Height: 3640mm Weight: 24000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: ready for operation (used), Year of construction: 2002, operating hours: 22,347 h, functionality: fully functional, machine/vehicle number: 190347, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 1,500 mm, table load: 10,000 kg, controller model: Heidenhain TNC 430 B, No minimum price – guaranteed sale to the highest bidder! Kjdpfszku Sgox Akwjdt TECHNICAL DETAILS 6 axes (X, Y, Z, table C, swivel head A, B) Travel range X-axis: 3,000 mm Travel range Y-axis: 1,600 mm Travel range Z-axis: 1,500 mm Table size (2x): 2,000 x 2,000 mm Table load: 10 t Spindle speeds: 60 - 3,600 rpm Spindle mounting: ISO 50 MACHINE DETAILS Control system: Heidenhain TNC 430 B digital Number of controlled axes: 6 Milling drive: 28 kW Total power consumption: 48 kW Dimensions & Weight Space requirement: approx. 6.5 x 3 x 3 m Machine weight: approx. 47 t Program runtime: 22,347 h EQUIPMENT Integrated coolant supply (ICS) 40-position automatic tool changer Chip conveyor High-speed spindle (30,000 rpm) 2 pallets

Condition: ready for operation (used), Year of construction: 2000, operating hours: 25,616 h, functionality: fully functional, machine/vehicle number: 184640, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 1,500 mm, table load: 10,000 kg, controller model: Heidenhain TNC 430 B, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel in X-axis: 3,000 mm Travel in Y-axis: 1,400 mm Travel in Z-axis: 1,500 mm Table size: 3,200 x 1,100 mm Table load: 10 t Spindle speeds: 60 - 4,000 rpm Spindle mounting: ISO 50 MACHINE DETAILS Control system: Heidenhain TNC 430 B digital Milling drive: 22 kW Total power consumption: 50 kW Dimensions & Weight Space requirement: approx. 6.5 x 3 x 3 m Machine weight: approx. 22 t Program run time: 25,616 h Machine operating hours: 53,291 h Control system operating hours: 55,029 h EQUIPMENT 20-position automatic tool changer Milling head automatically swivels and rotates in 1.5° increments Chip conveyor Ksdpozku R Ajfx Akwsdt Adaptable high-speed spindle (30,000 rpm) Mist coolant system

Condition: ready for operation (used), Year of construction: 2001, travel distance X-axis: 1,300 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, spindle speed (max.): 3,000 rpm, overall weight: 10,000 kg, Heidenhain TNC 426 control Table: 1400 x 700 mm Travel: 1300 x 800 x 800 mm Spindle: SA 50 Maximum spindle speed: 3000 rpm Kdodpfx Ajzbrilokwot Weight: 10,000 kg

Condition: like new (used), Year of construction: 2015, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,500 mm, rapid traverse X-axis: 20,000 m/min, rapid traverse Y-axis: 20,000 m/min, rapid traverse Z-axis: 20,000 m/min, position of the milling head: 0.001, spindle speed (max.): 3,500 rpm, table width: 1,500 mm, table load: 10,000 kg, table length: 1,500 mm, type of input current: three-phase, workpiece weight (max.): 10,000 kg, overall weight: 26,000 kg, input voltage: 400 V, LAGUN GORATU GTM 3 MILLING MACHINE (TYPE T) TECHNICAL SPECIFICATIONS Brand: Lagun Model: GTM3 Year: 2016 CNC: Heidenhain iTNC 530 Table: 1500 x 1500 mm X: 3000 mm Y: 1200 mm Z: 1500 mm V (Column cross travel: 1000 mm Automatic milling head - ISO 50 Spindle speed: 4,000 rpm Rotary table (capacity 10 tons) Internal coolant system: 40 Bar Spindle power: 28/34.5 Kw Coolant filter PRICE AND FURTHER INFORMATION AVAILABLE UPON REQUEST (CNC, SIEMENS, HASS, LAGUN, FAGOR, CINCINNATI, HEIDENHAIN, MACHINING, PINACHO, MORISEIKI, MILLING MACHINE, LATHE, GRINDER, Kodpfx Aksy T Sffowsdt BORING MACHINE, PRESS, LASER, SHEAR, PRESS BRAKE)

Condition: used, Year of construction: 1998, x-travel 4000 mm y-travel 1400 mm z-travel 1500 mm Control Heidenhain type TNC 426 power capacity 30 kW transmission ratio 2 turning speeds 20-2800 U/min spindle taper ISO 50 Feed 4000 mm/min Rapid movement 10000 mm/min surface area 4200x960 mm T-slot - width 22 mm T-slot - distance 140 mm table load 8500 t total power requirement 57 KVA weight of the machine ca. 24 t dimensions of the machine ca. 9,3x4x3,7 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale Ksdpfsy Sukbsx Akwedt apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: ready for operation (used), Year of construction: 2005, operating hours: 28,246 h, functionality: fully functional, travel distance X-axis: 3,200 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,600 mm, table load: 20,000 kg, overall weight: 28,000 kg, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS X-axis travel: 3,200 mm Y-axis travel: 2,000 mm Z-axis travel: 1,600 mm B-axis: 360° C-axis: 360° Spindle taper: SK 50 Rotary table (L x W): 2,500 x 2,000 mm Table load capacity: 20,000 kg Tool magazine: 100 pcs. MACHINE DETAILS Dimensions & weight Dimensions (L x W x H): 7,300 x 7,700 x 4,350 mm Kdodpfxsy R Dpkj Akwjt Machine weight: 28,000 kg Operating hours Operating hours: 75,377 h Spindle hours: 28,246 h EQUIPMENT H- / V- head

Condition: good (used), Year of construction: 1994, functionality: fully functional, Technical data will follow... Ksdpfx Asy Rgt Sskwjdt

Condition: defective spare-parts repository (used), Year of construction: 2004, Spare parts from Deckel Maho DMF 360 linear for sale. The machine is used exclusively as a spare parts donor. The machine is complete in all components. For example: iTNC 530 control, complete control cabinet, SK50 spindle as new, cooling unit, partition wall, rack wall, SK50 swivel head Hirth (defective), chip conveyor, high-pressure coolant system 80 bar, various other used parts in good condition. Prices on request, plus 19% VAT. Kdodpfeytx Dmex Akwot

Condition: used, Year of construction: 1970, x-travel 3000 mm y-travel 1350 mm z-travel 1400 mm spindle taper ISO 50 turning speeds 22-1400 U/min Rotary table 800x600 mm Table dimensions 2500x1200 mm Feed 5-3000 mm/min ball screw The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More Kjdpfeyqu Rqsx Akwjdt than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1993, functionality: fully functional, machine/vehicle number: 52334, travel distance X-axis: 2,750 mm, travel distance Y-axis: 1,060 mm, travel distance Z-axis: 1,550 mm, feed length X-axis: 3,000 mm, feed length Y-axis: 1,060 mm, feed length Z-axis: 1,600 mm, rapid traverse X-axis: 7,000 m/min, rapid traverse Y-axis: 7,000 m/min, rapid traverse Z-axis: 7,000 m/min, feed rate X-axis: 5,000 m/min, feed rate Y-axis: 5,000 m/min, feed rate Z-axis: 5,000 m/min, spindle speed (max.): 1,600 rpm, spindle speed (min.): 5 rpm, table width: 900 mm, table load: 8,000 kg, table length: 3,000 mm, mount diameter: 1,200 mm, table height: 600 mm, total height: 2,850 mm, total width: 2,450 mm, total length: 4,900 mm, type of input current: three-phase, rotational speed (max.): 1,600 rpm, rotational speed (min.): 5 rpm, workpiece weight (max.): 8,000 kg, overall weight: 16,000 kg, Equipment: rotational speed infinitely variable, ZAYER BF3 3000 HEIDENHAIN TNC150 ZAYER BF3 3000 HEIDENHAIN TNC 155 ZAYER BF3 3000 HEIDENHAIN TNC 155 ZAYER BF3 3000 HEIDENHAIN TNC 355 4 fully functional machines can be demonstrated under power Price of machine with TNC150 Magnetic tables not included Kedoyn Ir Ajpfx Akwedt

Condition: good (used), Year of construction: 2000, x-travel 3500 mm y-travel 1600 mm z-travel 1200 mm spindle turning speed range 250 - 3000 U/min tool taper ISO SK-50 tool change unit 40 Ksdpfx Asykvayekwedt rapid traverse: 15000 mm/min. feed 5000 mm/min table dimension - longitudinal 3860 mm table dimension - cross 1000 mm control HEIDENHAIN TNCi530 weight of the machine ca. 24 t dimensions of the machine ca. 8000 x 5000 x 4000 m

Condition: excellent (used), operating hours: 8,064 h, Brand : LAGUN Model : GBM-22E Type : CNC 5 EJES Cnc :HEINDENHAIN 530 Table dimensions : 2.200 x 1000 mm Number and width of T slot: 7 x 22 mm Distance between T slots: 140 mm Axis travels (X,Y,Z) : 2.000 x 1.200 x 1.000 mm Head type : Automático Spindle speed : 4.000 rpm Taper : ISO 50 DIN 2080 Main motor : 28 kw Continuusly variable speeds : 50➗ 4.000 Speed range : 2 Rapid traverse : 10.000 mm/min Machine weight : 15 tn Electronic hand-wheel : Yes Kdedpoyg R Abofx Akwst Working hours : Machine running: 22.924 h Control on : 23.132 h Automatic cycle: 8.064 h
