NGM GmbH

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, ABERLINK Axiom too 600, coordinate measuring machine. Made in the UK, year 2013, resolution 0.5µm – optimal temperature 18-22°C. Win 10 PRO. Excellent condition. Regularly serviced and calibrated. Inspection possible by appointment. Ffodox Sykyepfx Agmot

Condition: like new (used), Year of construction: 2025, functionality: fully functional, controller model: DC241 EEC, workpiece height (max.): 3 mm, swivel angle A-axis (max.): 105 °, swivel angle B-axis (max.): 180 °, As-new Hexagon Global S Blue Coordinate Measuring Machine! TECHNICAL DETAILS Probe Interface (CMM): TKJ Probe Weight: 350 g Total Weight: 480 g Measuring Performance Probing Force: 5 µm Measuring Range: 2 mm Maximum Measuring Distance: 14 mm Resolution in Z-Axis: 66 nm Lateral Resolution: 6 µm Angular Acceptance: ±30 ° Max. Measurable Thickness: 3 mm Spot Diameter: 12 µm LED Area Light Illuminated Area: 780 × 780 mm Overall Dimensions: approx. 860 × 840 × 20 mm Weight: approx. 19 kg Load Capacity: max. 50 kg Stylus Shank Diameter: 3 mm Ffedpfox Sx Nusx Agmjt Shank Length: 50 mm Ruby Ball Diameter: 5 mm Thread: M3 Angular Rotation Steps: 2.5° A-Axis: ±105° B-Axis: ±180° Rotation Speed: 90° in 2.5 s Max. Extension Length: 450 mm Recommended Drive Torque: max. 1.4 Nm Positioning Repeatability: 0.5 µm at 100 mm from the A-axis center MACHINE DETAILS Control System: DC241 EEC Control Compatibility: HH-C-V2.0, HH-CA-V2.0 with HR-R automatic probe changer rack Electrical Data Supply Voltage: DC 5 V to 6 V Current Consumption (normal): 50 mA Current Consumption (min): 30 mA Current Consumption (max): 150 mA (pulsed) Protection Class: IP40 (IEC 60529) Temperature Range: 16 °C to 26 °C EQUIPMENT Windows 10 Operating System Interactive 3D Graphical Capability Computer-Simulated Measuring Machine Environment Bidirectional Interface to CAD Systems: IGES, VDA, DXF, and STEP Processing of 2D, 3D, wireframe, and surface models Curve and Surface Scanning (CurveAnalyzer) Includes PC-DMIS-SHEETMETAL Functions for measuring thin-walled components Automatic White Light Probe – TKJ 2.5 HP-OW-2.14 Sensor Kit, incl. controller and reference sphere, Ø 30 mm, ceramic matte HP-SX1H Scanning Probe Sensor LED area light for mounting on the coordinate measuring machine Reference price mechanical frame for supporting the area light HP-CTS5.10 Optical Sensor HP-S-X1C/H Stylus Holder (1× M3) HH-C-V2.1 Controller HR-OW-2.14 Short End Cap HR-R3 Sensor Acceleration HH-CA-V2.0 Interface Active Probe Rack, HR-RA-65 HR-X1-3P Stylus Rack Reference Sphere, Ø 60 mm, ceramic, with stand M3 Stylus (R-5-SS-3.50) Stylus Tray Computer & Software PC-DMIS CAD++ PC-DMIS Operator Interface with order system PC-DMIS CWS Interface PC-DMIS Probe Change Support Software PC-DMIS Vision for Tactile Sensors Touchscreen including computer system Desk for computer system

Condition: good (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 06-00376, measuring range X-axis: 400 mm, measuring range Y-axis: 400 mm, measuring range Z-axis: 150 mm, Manufacturer: Werth Messtechnik GmbH Type / Model: Scope-Check 400 × 400 × 150 3D CNC Machine Type: Multi-sensor Coordinate Measuring Machine (optical / tactile) • Year of Manufacture: 2006 • Serial Number: 06-00376 Condition • Used, well-maintained overall condition • Machine was fully operational in measurement use until recently • Regular calibrations documented • No visible damage to granite, guides, or measurement system Accessories / Delivery Scope • Granite-based machine with measurement glass and protective cover • CNC control with Scope controller • Renishaw probe (multiple stylus inserts included) • PC workstation comprising: • Computer • Monitor(s) • Keyboard, mouse Fjdpfjx Sw R Djx Agmeft • Control panel / joystick • Documentation: • User manuals (WinWerth) • Calibration and inspection reports • Folder with machine and measurement room documentation • Software and calibration data carriers (CD/DVD) • Integrated control cabinet with main switch Application Area • Form and position tolerance inspection • Dimensional inspection of: • Sheet metal forming parts • Turned and milled components • Tools • Prismatic and rotationally symmetric parts The unit is currently still installed and powered. An inspection while operational is possible by appointment. Dismantling, loading, and transport are to be carried out and borne by the buyer. • Measuring range (X/Y/Z): 400 × 400 × 150 mm • Control: CNC • Software: WinWerth, version 8.40 or higher (data carrier included) • Tool holder / probe: Renishaw, MK 2 • Probe system: Renishaw Probe Interface PI 200 • Measurement accuracy: • Length measurement deviation approximately 1.5 µm (according to Werth documentation / calibration records) • Voltage: 230 V AC • Frequency: 50 Hz • Power consumption: max. 10 A

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: E2CO, measuring range X-axis: 200 mm, measuring range Y-axis: 20 mm, measuring range Z-axis: 205 mm, workpiece weight (max.): 25 kg, Equipment: type plate available, High-precision Contour and Roughness Measuring Instrument T4HD Manufacturer: Triebworx GmbH & Co. KG Model: T4HD – High Definition Metrology Fully equipped 4-axis CNC contour and roughness measuring system T4HD from a testing and calibration laboratory. The unit is in excellent condition, currently installed, operational, and powered on. The T4HD is a high-precision measuring system for contour and roughness measurement of workpieces with complex geometries. It is ideally suited for: • Quality assurance • Testing laboratories • Research & development • Series and single-part inspection • Automotive, tool, and mechanical engineering The scope of supply includes: • Contour and roughness measuring instrument T4HD • T4HD USB probe arm (patented technology) • Several probe arms / probes T4HD 100-2x5 USB • Spherical calibration standard for auto-calibration • Industrial joystick for manual operation • Evaluation PC with Windows operating system • 24” Full-HD monitor • Keyboard and mouse • 24 VDC power supply • USB cables (2x USB connection) • Original T4HD operating manual • EC Declaration of Conformity • Several original IMTS wooden boxes for probes and accessories • T4HD E2C0 USB sticks • Software version 02/2016 • Software version 02/2018 • Accessories, cable set, storage boxes • Condition: Very good • Source: Professional test and measurement laboratory • Not disassembled, not surplus stock • Regularly inspected (service/maintenance sheet valid until 2025, all OK entries) • Clean and well-maintained overall condition • System is installed, connected, and ready for operation • Sale as inspected • Collection preferred due to weight and precision • Viewing and function test possible by arrangement (Excerpt from operating manual) • Measuring systems: optical, incremental, non-contact • Measuring range X: 200 mm • Measuring range Z: 205 mm • Adjustment range Y: 20 mm • Y-table dimensions (W x D): 200 x 166 mm • Y-table load capacity: 25 kg • Measuring point spacing: 0.25 µm to 3.5 µm • Measuring force: 0.75 mN to 40 mN, programmable via software • Contour measuring speed: 0.25 – 3.5 mm/s • Roughness measuring speed: 0.25 – 0.5 mm/s • Positioning speed X/Y/Z: 25 mm/s, combined 35 mm/s • Measuring accuracy X/Z: 1 µm + (L[mm] / 100) x 1 µm • Roughness probe tips: diamond, R = 2 µm Fsdpfx Aex Sw D Dsgmoft • Contour probe tips: carbide, R = 25 – 100 µm • Ruby balls: Ø 0.5 – 3 mm • Operating voltage device: 24 VDC • Mains connection: 100 – 230 VAC / 50 – 60 Hz • Device dimensions: 592 x 220 x 511 mm (W x D x H) • Weight: approx. 45 kg

Condition: used, Year of construction: 2023, Due to a new requirement in our production, a KEYENCE XM-5000 is being sold. The measuring system was purchased directly from KEYENCE in 11/23. These additional details may be of interest to you: - Faster and simpler measurement enables significant time savings - Measurements can be performed in the machine / mobile measurements are possible - All users can measure without significant operator influence; additionally, every measurement is documented and thus traceable - Inspection reports simplify communication - The statistical and analysis functions allow for better assessment of product quality, enabling quality improvements - Reverse engineering capability - No maintenance contracts Fjdpfx Aex Sv Stegmoft

Condition: used, Year of construction: 2023, Due to a new production requirement, a KEYENCE XM-5000 is being sold. The measuring system was purchased directly from KEYENCE in November 2023. These additional details may be of interest to you: - Faster and easier measuring enables significant time savings - In-machine measurement / mobile measurement possible - All personnel can perform measurements with minimal operator influence; measurements are documented and traceable - Inspection reports facilitate communication Ffodpsx Svw Asfx Agmjt - The statistics and analysis functions enable better assessment of product quality, resulting in improved quality outcomes - Reverse engineering functionality - No maintenance contracts

Condition: ready for operation (used), Year of construction: 2021, operating hours: 20 h, functionality: fully functional, machine/vehicle number: SK02UXKP0365, measuring range X-axis: 550 mm, measuring range Y-axis: 600 mm, Auction of a Zeiss T-Scan Hawk with only 20 operating hours! TECHNICAL DETAILS Maximum measuring range: 550 mm x 600 mm Measuring accuracy: 0.02 mm + 0.035 mm/m MACHINE DETAILS Laser class: Class 2M (eye-safe) according to IEC 60825-1:2014 Operating hours: 20 EQUIPMENT Ffjdsx Sqfnjpfx Agmst Notebook GOM Inspect software

Condition: used, Year of construction: 2023, Keyance XM Series Handheld Probe Co-ordinate Measuring Machine, XMH-5000 Scan Head, XMP-500 Probe, XM-MP Base Table. S/No. 4BOP 000122 (2023) Country of Origin: Japan Ffjdpfx Aox R S Uzsgmot Please Note: This lot is located in Coventry, UK. Unfortunately, there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. All/Any tooling is being offered as specifically described.

Condition: refurbished (used), Year of construction: 2013, measuring range X-axis: 650 mm, measuring range Y-axis: 900 mm, measuring range Z-axis: 500 mm, repeat accuracy: 0.002 mm, year of last overhaul: 2026, Measuring Range Fodpfx Aox N S D Hegmeft X – axis 650 mm Y – axis 900 mm Z – axis 500 mm Accuracy acc. ISO 10360 E = [2,9 + 4L/1000]µm retrofiited 2026 (new drives, new probe, new electronic, new software and PC) incl.: Renishaw RTP20 (new) Renishaw MCR20 probe changer (+1 additional module) DEVA004 DCC controller Aberlink 3D software On Demand: Aberlink CAD offline programming/ CAD compare Inca Premium (full 3D incl offline and CAD compare) DEVA joystick (USB or with touchscreen) Insatllation and training

Condition: good (used), Year of construction: 2007, Technical Data Ffedpfx Agsx N H U Homst WENZEL LH 108 Year of Manufacture: 2007 Measuring Range X Axis: 1,000 mm Y Axis: 3,000 mm Z Axis: 800 mm Machine Type Bridge-type coordinate measuring machine Granite guides Air-bearing axes Measuring Accuracy Length measurement deviation approx. 1.3 µm + L/400 (depending on configuration and calibration status) Probe Systems Renishaw probe heads possible Touch trigger and scanning PH10, TP20, SP25, SP80 depending on equipment Workpiece Weight Permissible table load up to approx. 2,000 kg (depending on configuration) Control CNC control with manual control unit Software Metrosoft CM Version 3.112 WENZEL Quartis R16 Electrical Supply 230 V, 50/60 Hz Power consumption approx. 1 kVA Pneumatic Supply Compressed air 6 to 10 bar, filtered and dry The machine can be tested under power. Dismantling will be carried out by Wenzel.

Condition: like new (used), Year of construction: 2020, operating hours: 100 h, functionality: fully functional, Software type: UCCsuite 5.3.3. Renishaw PH20 measuring head (swivel-mounted) Measuring range X = 600 mm Measuring range Y = 800 mm Measuring range Z = 500 mm Ffedpfx Agsx I I Npemst Repeatability 2 µm Table height 850 mm Power consumption 1.5 kVA Air consumption >= 0.6 MPa Dimensions L x W x H = 1380 x 1620 x 2700 mm Max. workpiece weight 500 kg Machine weight 1450 kg With computer and monitor. Made in Italy. Very good condition, hardly used.

Condition: ready for operation (used), Year of construction: 2023, A Mitutoyo coordinate measuring machine overhauled in 2023 is available. Measuring dimensions X/Y/Z: 705mm/1005mm/605mm, max. workpiece height: 800mm, table dimensions X/Y: 880mm/1720mm, max. table load: 1000kg, resolution: 0.1µm, traverse speed: 520mm/s, measuring speed: 8mm/s. Machine dimensions X/Y/Z: approx. 1500mm/2000mm/2750mm, weight: approx. 2000kg, control: GEOPAK and CAT 1000 PS. Including various probe trees. Documentation available. On-site inspection is possible. Fjdpfx Agox Ih A Nsmoft

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, measuring range X-axis: 300 mm, measuring range Y-axis: 250 mm, measuring range Z-axis: 150 mm, Keyence XM-T2000 coordinate measuring system from 2021, in excellent and fully functional condition. Keyence XMM-1600 controller included. Additional accessories: Keyence case, dongle, user manual, and certificates. Fedpjx H T H Dsfx Agmoft Measuring range: 300 mm × 250 mm × 150 mm Smallest display unit: Distance: 1 μm, Angle: 0.0001 degrees Measuring accuracy: Repeatability: ±3 μm, Measurement deviation: ±8 μm Maximum load capacity: 25 kg #8406

Condition: good (used), Year of construction: 2015, functionality: fully functional, Hexagon Metrology Optiv Classic 432 coordinate measuring machine in good working condition. Measuring range single sensor: 400x300x200 mm Fjdpfx Agjx H T Emsmjft Dimensions: 1232x910x1663 mm Weight: approx. 800 kg Max. workpiece weight: glass plate approx. 30 kg Accuracy: MPEE = 2.9 + L/100 [μm] #8448

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, measuring range X-axis: 1,200 mm, measuring range Y-axis: 2,500 mm, measuring range Z-axis: 1,000 mm, Equipment: type plate available, For sale: Used Wenzel WP-KL coordinate measuring machine, year of manufacture 2007, in excellent condition and immediately ready for operation. The machine is ideally suited for quality assurance, toolmaking, and precision metrology applications. General Condition The machine is in very good technical and visual condition, professionally overhauled and upgraded in 2022. Inspection on site is possible by appointment. Technical Data - Model: Wenzel WP-KL - Year of manufacture: 2007 - Serial number: LH075440 - Machine height incl. extended damper: 3,485 mm (not extended: 3,470 mm) Measuring Range & Accuracy - Measuring range (X/Y/Z): 1200 × 2500 × 1000 mm - Accuracy (MPE E): 2.6 + (L/300) Equipment - CNC control: WPC, 3 axes - Probe system: Renishaw PH10M - Scanning probe: Renishaw SP25 with Scanning Kit 2 (stylus lengths 50–100 mm) - Probe change rack: Renishaw FCR25, 3 positions, not equipped PC System & Software - PC system with Windows 10 Professional - 2 × 24" TFT monitors Fedex H Tqijpfx Agmoft - WM QUARTIS CNC geometry inspection software – Version 2025 - WM QUARTIS CNC freeform surface application – Version 2025 - WM QUARTIS CNC CAD import interface (STEP) – Version 2025 - USB user dongle with software license Accessories (included) - Small M3 stylus kit - Reference sphere - PC and controller trolley with integrated desk - Ergonomic hand control panel HT400 If interested or if you have any questions, please get in touch! Price €89,000 net, negotiable for quick transaction. All details provided to the best of our knowledge and belief. Subject to changes, errors, and prior sale.

Condition: excellent (used), Year of construction: 2020, functionality: fully functional, measuring range X-axis: 700 mm, measuring range Y-axis: 1,000 mm, measuring range Z-axis: 600 mm, MCOSMOS with GEOPAK module (CAD-assisted evaluation). Software - MCOSMOS 3 CNC V4 Ffjdpfx Agox H Nn Remst Equipment: PH10MQ probe head (incl. FCR25 quick-change rack). SP25M scanning probe system with 5-piece probe module set. MCOSMOS 3 CNC V4 incl. dongle (Wibu-Box). CAT1000PS V4 (CAD comparison and evaluation). Software upgrade MCOSMOS-1 from V2 to V4. GEO-EDM add-on module for eroded parts. Part-program generator and GEO-EDM assistant.

Condition: excellent (used), Year of construction: 2008, functionality: not functional, Faro Gage Plus measuring arm with 6 axes Arm length: 4 ft (approx. 1.2 m) Accuracy: 5+8L/1000µm Includes cart, accessories, and matching transport case User manual included No software available!!! Ffedpfxjx Hfwne Agmjt

Condition: used, Year of construction: 2019, measuring range X-axis: 700 mm, measuring range Y-axis: 1,000 mm, measuring range Z-axis: 600 mm, Measuring Machine Manufacturer: Mitutoyo Model: Mitutoyo Crysta-Apex S7106 Year of Manufacture: 2019 Measuring Ranges X-Axis: 700 mm Y-Axis: 1000 mm Z-Axis: 600 mm Control: UC-400 with temperature compensation Ffodpfxjx E U N Re Agmst Software: MCOSMOS-1 V5.4 Probe Holder: Measuring head Renishaw PH-10MQ Interface PHC10-3 PLUS Probe: Renishaw SP25M with SM module Change system: Renishaw ACR3 and two FCR25 Additional: Bilz vibration damping system

Condition: used, Year of construction: 2007, machine/vehicle number: 75388, Machine: Wenzel LH87 Serial number: 075388 Year of manufacture: 2007 X 800mm Y 1000mm Fjdox Ey Daepfx Agmoft Z 700mm Measuring head: SP80

Condition: excellent (used), Year of construction: 2020, functionality: fully functional, machine/vehicle number: 60586250, measuring range X-axis: 900 mm, measuring range Y-axis: 1,000 mm, measuring range Z-axis: 600 mm, total height: 2,700 mm, type of input current: three-phase, total width: 1,600 mm, total length: 2,000 mm, Equipment: type plate available, Mitutoyo Crysta Apex V9106 – 3D coordinate measuring machine – measuring range 900 x 1000 x 600 mm Manufacturer: MITUTOYO Model: CRYSTA-Apex V9106 Year of manufacture: 2020 Ffodpfx Agox Ekdwsmot Measuring range: X: 900 mm Y: 1000 mm Z: 600 mm Required space approx. 1.6 m x 2 m x 2.7 m

Condition: good (used), Year of construction: 2022, Description: Fedpsx A U Sdofx Agmsft The machine is in good technical condition, and testing can be arranged by prior agreement. Along with the machine, stocks of measuring probes, clamping plates, and connecting elements can also be sold.

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 065014, measuring range X-axis: 800 mm, measuring range Y-axis: 1,000 mm, measuring range Z-axis: 700 mm, Measuring range X/Y/Z: 800 / 1000 / 700 mm Max. length measurement deviation: MPEe = 2.7 + L/300 µm Probe head: PH10M, Renishaw TP200 Fsdpjx Au Hnefx Agmoft Accessories: HT400 control unit, reference sphere, 18-piece set of styli/extensions, rack for stylus change Software: Quartis R2025-2, including additional modules Quartis Surf and Curve for measuring surfaces and curves, without PC Last maintenance: 12/2021, acceptance report available in documents Very good condition, fully functional, documentation available Inspection at the facility is possible Sale without warranty, including transport packaging and loading, available from March 2026

Condition: used, Year of construction: 1998, functionality: fully functional, machine/vehicle number: 1156810C, Mitutoyo BRT-A910 CMM (1998) Ffedpfxjx Ap Ndj Agmot Renishaw Probe CMM Software not included in scope of supply. Sub Location Building 6

Condition: excellent (used), Year of construction: 2015, 3D CNC image processing measuring machine with touch-trigger probe Fjdpfx Agjxztl Tjmoft Measuring range (X × Y × Z): 300 x 200 x 200 mm Scale resolution: 0.1 µm Max. table load: 20 kg Image measurement accuracy: EUX,MPE/EUY,MPE = (1.5+3L/1000) µm EUZ,MPE = (1.5+4L/1000) µm EUXY,MPE = (2+4L/1000) µm L: measuring length in mm Optics: programmable zoom changer 1x-2x-6x Illumination: Transmitted light: white LED Coaxial light: white LED PRL: white LED

Condition: like new (used), Year of construction: 2019, Type: QV AKTIVE 202 Model: QV-L202Z1L-D Range (X, Y, Z axis) with Vision Head: 250 x 200 x 150 mm Max. table load: 10 kg Resolution: 0.1 μm Ffodpfxexztgko Agmot Illumination: (White LED) • Contour • Coaxial • 4-quadrant ring light Magnification system: Zoom optical system with 8 positions, standard 1.5X magnification lens Sensor type: High-resolution CMOS color camera Additional lenses: 1X and 2X magnification Accuracy: E1 (x, y) = (2+0.3 L/100) μm E1(z) = (3+0.5 L/100) μm E2 (XY) = (2.5+0.4 L/100) μm L = measured length (mm)
