Condition: excellent (used), Year of construction: 2017, Machine Model: ALZMETALL GS 1200 Year of manufacture: 2017 Technical Data: 1. Machine Concept:    · Gantry design for closed force flow    · All dynamically loaded components manufactured from spheroidal graphite cast iron EN-GJS 500 (GGG50) 2. Working Area:    · Travel X-axis: 1000 mm    · Travel Y-axis: 1200 mm    · Travel Z-axis: 800 mm    · Spindle to rotary table distance min./max.: 167 mm / 967 mm 3. Control System:    · Path control system: Heidenhain TNC 640 with digital drive control    · Operator panel: rotatable and tiltable    · 19" TFT color flat screen with touch pad    · Hard drive, linear and circular interpolation, helical interpolation, 3D interpolation    · Look-ahead calculation (1024 blocks)    · Standard drilling and milling cycles, probing cycles    · Parallel operation, file management    · Programming in Heidenhain plain text and DIN/ISO    · Graphical support for free contour programming    · Multiple workpiece zero tables    · Interfaces: 1× V.24/RS-232-C (up to 115 kbit/s), 2× Gigabit Ethernet (1000 Base-T) 4. Lubrication: Iodoyag Tvepfx Ahueht    · Central grease lubrication of all axis guideways and drive systems    · Permanent grease lubrication of high-frequency motor spindle    · Lubrication interval control via PLC 5. Coolant & Chip Disposal:    · Only coolants with high mineral oil content permitted    · No synthetic or semi-synthetic coolants allowed    · Coolant filtration designed for water-based coolants    · For emulsions: Flashpoint > 140°C    · Fire protection standards for oil-based coolants and flammable materials (e.g. magnesium) 6. Hydraulics/Pneumatics:    · Hydraulics: max. 140 bar, max. 6.8 l/min    · Pneumatics: 2 channels, max. 8 bar, max. 4.8 l/min 7. Accessories/Options (selected items):    · Electronic handwheel HR 510 (portable)    · 3D probing system with infrared transmission (M&H Inprocess, Type IPR 40.01)    · Safety foot approval switch for setup mode    · Continuous air operation without lubrication interval (max. 10 bar pressure)    · Flush hose with spray gun incl. pump    · Preparation for stationary extraction system (2 units, make Reven)    · Production Package C: Chip conveyor with coolant tanks, band filter, pumps    · Safety laminated windows, automatic roof enclosure 8. Machine Cladding:    · All-round protective enclosure made of sheet steel 9. Table Data:    · Max. table load: 2500 kg (dynamically balanced)    · Swing diameter around C-axis at center of A-axis: Ø 1220 mm    · Swing diameter around A-axis at center of X-axis: Ø 1240 mm    · Rotary table C-axis under center of A-axis: max. 100 mm 10. Tool Change:     · Max. tool weight per chain: 250 kg     · Chip-to-chip time: approx. 7 s

Condition: excellent (used), Year of construction: 2022, 5-axis simultaneous machining center. Travel paths: X 900 mm, Y 850 mm, Z 700 mm. Iedpfoyabkpjx Ahueht Max. spindle speed: 18,000 rpm Tool magazine positions: 80 Control system: Heidenhain

Condition: excellent (used), Year of construction: 2013, 5-axis machining center (BAZ) Ihsdpfeyaba Dsx Ahujt Control: Heidenhain Travel paths: X 2000 mm, Y 600 mm, Z = H 800 mm, V 700 mm. Max. clamping weight (rotary table): 1200 kg Max. spindle speed: 18,000 rpm

Condition: excellent (used), Year of construction: 2016, 5-axis simultaneous machining center Year of manufacture: 2016 Röders proprietary control system With internal coolant supply (IKZ) Details to follow... Isdoyaa T Nopfx Ahujht

Condition: excellent (used), Year of construction: 2019, Delivery at the beginning of June 2026!!! Control: CELOS with Heidenhain TNC 640 Milling head: Universal milling head with controlled A-axis HSK63A Spindle options: Spindle tool holder HSK-A 63 Tool magazine: Tool magazine, wheel type, 63 positions HSK63A Coolant / Chip removal: Through-spindle coolant system, 80 bar, frequency controlled; oil/emulsion mist extraction unit; cooling device with air blast Ihjdpfjx Uqykox Ahuet Measuring / Monitoring: Heidenhain infrared probe SK 40, 3D quickSET; MPC Machine Protection Control Further options: Operating mode 4 Options for HEIDENHAIN control: Electronic handwheel Documentation: 1 set documentation in German; electrical schematic in German Display language: German

Condition: ready for operation (used), Year of construction: 2015, functionality: fully functional, KIMLA five-axis machining center TYPE 5 AXIS 2070. Working table 7 meters Technical parameters: Travel range X x Y: 2000 x 7000 mm Travel range Z: 1700 mm Spindle 5D HSD 12 kW 24000 rpm Vacuum table 3D control module Drive – digital AC servomotors High Speed Machining technology Tool length correction sensor Control cabinet Control computer Becker vacuum pump Automatic oil mist unit Automatic tool changer Rotary tool magazine 10 HSK63 cones Permanent service in Poland Ihodpfxox Tv Ukj Ahujt New machine price in 2015: PLN 978,000.00 net Plotter purchased as new in 2015 VAT invoice 23%

Condition: used, WILLEMIN MACODEL W 408 S is a 5-axis machining center offering high precision, excellent accuracy and proven reliability. Travels X 250 mm, Y 200 mm, Z 300 mm; B axis -105°/+35° (140°), C axis 360°, resolution 0.001°. Spindle nose HSK 40, speeds 500–12,000 t/min (stepless). Work feed 15 m/min, rapid traverse 30 m/min. Supply 3x 380 V 50 Hz, air 6 bar; weight ≈1700 kg; dimensions L1700×W1950×H2200 mm. Tool magazine 24 positions. Enables tight tolerances; typical applications: watchmaking, automotive, aerospace, medical and machine tool sectors Ijdpfx Ahex S N Eajusht

Condition: excellent (used), HERMLE C 42 U is a 2 x 5‑axis machining centres with loading robot, engineered for high precision and reliability. Table 400×400 mm, table load 450 kg, travels X800 Y800 Z550 mm, A ±130°. Spindle HSK‑A63 0–18,000 rpm, 42 kW, 148 Nm; rapid 45/45/40 m/min. Tool magazines 42+160, 54 pallets, KUKA robot, coolant 80 bar, Renishaw/BLUM. Suited for tight tolerances in automotive, aerospace, watchmaking, medical. Isdpfx Aex S I Akehusht

Condition: ready for operation (used), Year of construction: 2000, A complete manufacturing cell with four horizontal machining centers Makino and a pallet storage and transport system is available. Makino A55: Travels X/Y/Z: 560mm/560mm/600mm, pallet dimensions X/Y: 400mm/400mm, max. table load: 500kg, max. workpiece diameter: 630mm, max. workpiece height: 1000mm, rapid traverse: 84m/min. Complete system dimensions: approx. 24000mm/8000mm, weight: approx. 8500kg. The images and videos show an identical system. The configuration of the offered and the illustrated cells is essentially identical. Documentation available. On-site inspection is possible. Iedpfxjx Syv Ao Ahuoht

Condition: good (used), Year of construction: 2008, 5-axis machining center usefull lenght : 10350 mm 3D software Camplus 8 pneumatic clamps Ijdpfxjx Svn Us Ahusht Automatic positioning of clamps Automatic toolchanger for 9 tools

Condition: used, Year of construction: 1999, functionality: fully functional, The machine is operational. Specifications: Info: Year of manufacture: 1999 X axis (longitudinal): 1500 mm Y axis (transverse): 800 mm Z axis (vertical): 710 mm Center pin - column: 800 mm Ihedpjx R Dvkefx Ahust Spindle head - table: 200 – 910 mm Machine weight: 12 tons Power: 21 kW Maximum speed: 6000 rpm Table: Work surface: 1700 × 650 mm Maximum load capacity: 2000 kg T-slots: 5 Slot width: 18 mm Slot spacing: 125 mm Rapid traverse: 12 m/min Feed speed: 1 - 6500 mm/min Positioning accuracy / 300 mm: ± 5 µ

Condition: as good as new (ex-display), Year of construction: 2026, operating hours: 5 h, functionality: fully functional, ISELI BNR-100 – Fully Automatic Leveling Center for Bandsaw Blades The ISELI BNR-100 is a state-of-the-art, fully automatic leveling center designed for the complete processing of bandsaw blades in a single clamping operation. It combines leveling, tensioning, and straightening in one workflow, delivering consistently precise results thanks to its patented measuring and control technology. Operation is intuitive via a large touch display, offering a comprehensive process overview and flexible control. Key Features Ijdpsx N Ib Uofx Ahujht • Fully automatic complete processing (leveling, tensioning, straightening) of a bandsaw blade in a single clamping cycle. • High-resolution sensors and process-reliable control system (Linux-based). • User-friendly interface with touch-screen operation. • Freely programmable tensioning and straightening curves for efficient workflows. • Remote maintenance possible via VPN. Technical Data (Extract) • Blade width: 70–360 mm (depending on model) • Blade thickness: 0.8–2.1 mm • Blade length: from 5,000 mm or 8,000 mm (optional) • Working speed: 18 m/min • Power supply: 400 V / 50 Hz, compressed air connection 6 bar

Condition: ready for operation (used), Year of construction: 1998, A universal machining center is offered with control: Heidenhain TNC 426. Operating hours: approx. 45380h, spindle hours: approx. 14384h. Viewing possible by appointment. Iodpfjx Ivi Dox Ahujht

Condition: ready for operation (used), A defective vertical CNC machining center DMG Mori is available. Travel X/Y/Z: 835mm/510mm/510mm, tool stations: 20, tool holder: SK40, speed: 10000rpm, table dimensions X/Y: 1000mm/560mm, T-slot spacing: 100mm, max. table load: 800kg, table height: 720mm. Control: Heidenhain TNC 530, operating hours: approx. 29836h. Either the pneumatic release cylinder or the spindle is defective. Documentation available. On-site inspection is possible. Isdpsx Ivkzefx Ahujht

Condition: ready for operation (used), Year of construction: 2015, A CNC vertical long-bed machining center Mazak is available. Travel X/Y/Z: 3000mm/800mm/720mm, B-axis: 110°, C-axis: 360°, table diameter: 600mm, long-bed table dimensions X/Y: 3500mm/820mm, max. table load: 2500kg, spindle interface: BT40, speed: 18000rpm, rapid traverse: 50m/min, tool stations: 48, coolant pressure: 70bar. Machine dimensions X/Y/Z: approx. 5250mm/3650mm/3200mm, weight: approx. 16100kg, control: Mazatrol Matrix 2, spindle hours: 18502h. Including rotary table Nikken CNC 601MA, high-pressure coolant, center partition wall, Renishaw probe, touch probe RMP 60Q, CAD/CAM software Topsolid 7.18 and postprocessor. Documentation available. An on-site inspection is possible. Ihedpfx Ahex Ih Dmouot

Condition: used, Year of construction: 2007, x-travel 1.050 mm y-travel 610 mm z-travel 610 mm control HEIDENHAIN iTNC 530 Distance between table and spindle 100-710 mm table-size 1.200 x 600 mm table weight 1.200 Kg rapid travel x/y/z 30.000/20.000 mm/min feed 12.000 m/min spindle taper BT-40 spindle turning speed range 60 - 10.000 U/min spindle drive 7,5/11 kW Tools changer 20 pos. Internal cooling system 20 bar Ijdpfx Ajx Hp Dlehujht Chip coveyor 2 handwheel HEIDENHAIN HR-410 tool diameter 100 mm tool length - max. 320 mm weight of tools max. 10 kg weight of the machine ca. 7 t dimensions of the machine ca. 2.900 x 3.420 x 2.888 m Complete installation 4th axis - Rotary table Golden Sun CNCT 321 (4th/5th axis)- Rotary table diameter 200 mm. - Rotary table tailstock - ZF box - Electrical cabinet air conditioning

Condition: used, Year of construction: 2019, Leadwell Vertikal Flerop BC-700T Fanuc 0i-MF controller with 10.4" LCD Chip conveyor + bucket Transformer Without linear scale Pallet package CTS function Air gun / Water gun HSK63 tooling system 12000 rpm spindle CE4 20 bar high pressure pump Automatic workpiece measurement OMP-60 Auto tool length measurement NC-4 Oil skimmer Auto door Network connection Isdpjx Hfx Sjfx Ahueht Spindle coolant ring X axis: 1300mm Y axis: 610mm Z axis: 610mm vertical / 750mm Horizontal Distance from table top to spindle end : 110-750mm Table LXW: 1480x610mm 600mm rotary table C Axis speed: 120-800Rpm Tool storage capacity: 30pcs

Condition: used, Year of construction: 2017, New spindel 2025-08 yearly service by Mazak Servicecenter. includes bar feeder Super 80 Max swing Ø 658 mm Swing over X-slide Ø 658 mm Swing when Y-axis is operating Ø 658 mm Max turning diameter Ø 658 mm Max turning diameter from bar Ø 51 mm (option Ø 65) Max part length 1011mm X axis: 615mm Y axis: +/-130mm z axis: 1077mm B axis: 0,0001Deg / 240° Spindle 1 Spindle nose JIS A2-6 Spindle bore 76 mm Through-hole 51 mm (option Ø 65) Spindle motor AC 22 kW 40% ED Speed range 35-5000 rpm Number of speed ranges Direct drive Max torque 467 Nm 25% ED Max part weight including chuck 300 kg Center height from floor 1235 mm Spindle 2 Spindle nose JIS A2-6 Spindle bore 76 mm Through-hole Not applicable (option Ø 65) Spindle motor AC 18.5 kW 40% ED Speed range 33-5000 rpm Number of speed ranges Direct drive Max torque 325 Nm 40% ED Max part weight including chuck 300 kg Center height from floor 1235 mm C-axis 1 Type Direct drive Rapid feed 555 rpm Working feed 1-5000 degrees/min Minimum programmable increment 0.0001 degree C-axis 2 Type Direct drive Rapid feed 555 rpm Working feed 1-5000 degrees/min Minimum programmable increment 0.0001 degree W-axis Movement 1066 Rapid feed 30 m/min B-axis B-movement 240 degrees Max machining feed (ISO) 40 rpm Minimum programmable increment 0.0001 degree Tool Holder Type: Tool changer Tool Shank Size: 25 x 25 mm Tool Change Time, tool to tool: 1.3 seconds Chip-to-chip time, average: 8 seconds Tool Holder for rotating tools: Capto C6 Tool Holder for turning tools: Capto C6 Max Tool Weight: 12 kg Max Tool Length: 400 mm Clamping Force for Tool (Capto C6): 33 kN Tool Magazine: Number of tool positions: 36 pcs Max Tool Diameter: 90 mm Max Tool Diameter when the position before and after is empty: 125 mm Max Tool Length: 400 mm Max Tool Weight: 12 kg Max Torque for Tool: 9.8 Nm Other: Length: 3990/4910 mm Width: 2800 mm Height: 2720 mm Weight: 13100/16600 kg Power Requirement, continuous: 72.34 kVA Air Requirement, min: 5 kg/cm², 410 liters/min Tool Magazine: 36 tools Standard Equipment: B-axis Capto C6 ATC Auto Recovery Auto power on/off, heating schedule 19” LCD touchscreen Mazak tool identification system including 10 ID chips (for Capto C6) Measurement arm for tool length setting, automatic compensation, and tool breakage detection 8” Chuck Type: Kitagawa B208A6 8” Chuck Type: Kitagawa B208A6 Coolant Tank Coolant Pressure for Upper Turret: Max 5 bar, 23 l/min Set of Manuals: (digital) Smooth Standard Software: Mazacc 2D software (shape comp) Mazacc 2D software för roterande axlar (shape comp) Mazacc 3D High Speed software High Smoothing Control Seamless Corner Control Variable Acceleration Control Ultra High Speed Machining Mode Rapid Overlap ISO/EIA Programming: Lathe and milling spindle start unsynchronized Synchronized threading with rotating tools Macro interruption allowing event-driven ISO/EIA programs Macro programming with 600 additional variable pairs for ISO/EIA Helix interpolation for ISO/EIA Coordinate rotation with G68 for ISO/EIA Iedpfx Ahsx Hfl Ejujht Polar coordinates, G122 for ISO/EIA Synchronized interpolation X-C-axis G12.1 for ISO/EIA Coordinate systems G54 - G59 + 300 additional for ISO/EIA Direct input of drawing dimensions, e.g. starting corner for ISO/EIA Inverse Time Feed (G93) 3D Cutter Compensation (G40-G42)

Condition: ready for operation (used), A machining center with 10-station tool changer is offered. Table clamping surface X/Y: 600mm/300mm, travel X/Y/Z: approx. 420mm/300mm/250mm, spindle speed: 6000rpm. Tool holder: BT30. Control: Brother CNC-400, machine weight: approx. 2000kg, including manual. Inspection possible by appointment. Ihedpex Ecu Eefx Ahust

Condition: used, Year of construction: 2003, Manufacturer: DMG DECKEL MAHO, Model: DMU 125 P retrofit, Year of manufacture: 2003, Serial no.: 11180004143, Control: DMG, Travel X/Y/Z: 1,250 x 880 x 800 mm, Rotary/tilting CNC table 360 x 0.001°, Main spindle drive: 10 kW, Speed range: 20 - 12,000 rpm, Tool changer with 30 stations, Tool holder: HSK 63, Operating hours Run: 13,710 h / Load: 57,369 h, Chip conveyor: Blechtechnik, Skip with forklift receptacle, Belt filter unit: DMG, Accessories: various tool holders. Ijdjx A U Thjpfx Ahuoht This machine is part of an online auction.

Condition: used, Year of construction: 2002, Manufacturer: DMG GILDEMEISTER, Model: DMU 160 P, Year of manufacture: 2002, Serial No.: 11220000223, Control system: Heidenhain, Model iTNC 530 (completely overhauled), Travel ranges X/Y/Z: 1,600 x 1,250 x 1,000 mm, Spindle speed: 18,000 rpm, Table dimensions: 1,250 x 1,500 mm, Tool changer: 60 positions, Tool holder: HSK 100, Rapid traverse: 60 m/min, Feed rate: 20 – 15,000 mm/min, Table rotation speed: 10 rpm, Operating hours: running 13,879 h / load 49,304 h, Oil mist extraction, Chip conveyor, Manufacturer: Blechtechnik, Model: DMU 160 P/U, Year: 2002, Band filter system, Manufacturer: Bürener Maschinenfabrik GmbH, Year: 2002, Model: KA980, Accessories package consisting of: telescopic drawer cabinet, 5 drawers, contents: various T-slot nuts, tool holders, clamps. Isdpfx Aex A U Sqshusht This machine is part of an online auction.

Condition: used, Year of construction: 2019, operating hours: 9,500 h, functionality: fully functional, machine/vehicle number: 56608, Heller MC20 machine in perfect condition. Very low cycle count, approximately 180,000 produced parts. Regularly serviced. Complete machine documentation available. 5-axis machine. More information upon request. Ihsdpfex A Tvnsx Ahujt

Condition: ready for operation (used), Year of construction: 2010, Workpiece diameter: 500mm, workpiece height: 730mm, travel X/Y/Z: 630mm/765mm/600mm, A-axis: -120°/+30°, C-axis: +/-360°, max. table load: 500kg, spindle interface: HSK-A63, speed: 18000rpm, rapid traverse: 52m/min, feed rate: 52m/min, rotary table diameter: 610mm, tool positions: 30, control: Mazak Mazatrol Matrix. Documentation available. An on-site inspection is possible. The machine is located in China. Ihjdpfxox Aunxs Ahujt

Condition: used, Year of construction: 2019, x-travel 900 mm y-travel 550 mm z-travel 500 mm Control FANUC 31i-b tool change unit 30 pos. table-size 1.000 x 500 mm table weight 700 Kg spindle taper HSK - A 63 number of spindle speeds 20.000 U/min/rpm Spindle power 22 Kw Working hours 10.816 h Spindle hours 2.352 h Distance between table and spindle 150/690 mm weight of the machine ca. 9 t dimensions of the machine ca. 2.530 x 2.900 x 3.064 m Ihedpfox Ak E Hjx Ahuot

Condition: used, Make: WMZ / PITTLER, Model: PVSL N1 2/2, Year of manufacture: 2009, Machine No.: ZN022, Control: Siemens Sinumerik 840D sl Powerline, incl. electronic handwheel, 2 spindles, 2 work areas, 2 cross slides, max. turning diameter: 140 mm, max. workpiece height: 80 mm, max. spindle speed: 6,300 rpm, 2x 8-position turrets, live tooling stations, chip conveyor by Knoll, extraction unit by ILT, recooling unit by Hydac, workpiece automation with raw part and finished part storage Ijdpfex Ahfwsx Ahusht +++ Attention: Machine is part of an online auction! +++
