Graff-Pinkert

Condition: ready for operation (used), Year of construction: 2011, operating hours: 27,865 h, bar diameter (max.): 24 mm, controller manufacturer: SIEMENS, controller model: Sinumerik 840D, number of axes: 6, This 6-axis Index MS 22 multi-spindle turning machine was manufactured in 2011. It features a Siemens Sinumerik 840D control system and includes a bar loader system with a maximum pressure of 6 bar. The machine is equipped with a Knoll coolant/filter system and various tooling attachments for enhanced versatility. If you are looking to get high-quality turning capabilities, consider the Index MS 22 machine we have for sale. Contact us for further details. Hfodpjz Ahy Ijfx Ac Ajl - Nominal Voltage: 400 V- Rated Current (In): 99 A- Short Circuit Current (Icu): 50 kA- Peak Current (I2): 3.6 kA- Maximum Backup Fuse: 100 A- Rated Power: 64 kW- Connected Load: 67 kVA- Frequency: 50 Hz- Control Voltage: 24 VDC- Operating Hours: 124,075 h- Hydraulic Operation Hours: 61,189 h- Operating Time: 37,971 h- Production Time: 27,865 h- Control System: Siemens Sinumerik 840D powerline (Index C200-4D) with Dual NCU- Bar Loader System: IEMCA / SIR MS22 P flat loader, Type 33 (YOM: 2011, Pressure: 6 bar, Mass: 100 kg, Voltage: 400 V / 50 Hz, Current: 7 A)- Material Feeders: 1 set Ø12 with reducer tubes, 1 set Ø18 with reducer tubes, 1 set Ø24- Clamping Heads: Ø9, Ø10, Ø12 – Ø18, Ø20 – Ø22- Knoll Coolant/Filter System (YOM: 2011): 1x high-pressure pump (80 bar, 24 l/min), 1x high-pressure pump (40 bar, 55 l/min), 1x low-pressure pump (300 l/min at 4 bar)- Tooling Drive Connections: 2x electrical connections on NCU 1, 3x electrical connections on NCU 2- Tooling Attachments: 1x polygon turning device, 3x powered tool holders ER11 (i = 1:2, max speed 12,000 rpm), 1x powered tool holder VDI25 (i = 1:1, max speed 6,000 rpm)- Back-machining Unit: on slide 6.3 (with 2x powered tool holders, 1x fixed holder, i = 1:2, max speed 12,000 rpm)- Optional Equipment: Fire suppression system, Coolant mist extraction and filtration system (SH 2000-PEV-T/TR, two-stage design), Integrated ARTIS process monitoring system Technical Specification Counter Spindle Yes

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, bar diameter (max.): 32 mm, turning length: 80 mm, rotational speed (min.): 3,150 rpm, drilling depth: 80 mm, No minimum price – guaranteed sale to the highest bidder! The machine is sold complete with collets, holders, and additional accessories! For more Schütte multi-spindle machines from the same location, see below! TECHNICAL DETAILS Maximum turning length: 80 mm Maximum drilling depth: 80 mm Largest material passage: 32 mm Maximum bar feed: 125 mm Spindle speed (turning): 200–3,150 rpm Spindle speed (right-hand threading): 11.2–1,575 rpm Thread cutting unit: Right-hand thread via undercut MACHINE DETAILS Coolant capacity: 600 l Pump output: 170 l/min Dimensions & Weight Footprint: 7.3 x 2.5 m Height: 2 m Weight: 8,300 kg Voltage: 380 V Frequency: 50 Hz Main drive: 20.5 kW Immersion pump: 1.5 kW Hsdpfxjz Ag A Ie Ac Ajfl Feed drive: 1.5 kW Hydraulic pump: 1.5 kW Circulating oil pump: 0.25 kW EQUIPMENT 6 cross slides 6 longitudinal slides 6 cams for cross slides 6 cams for longitudinal slides Operating tools Collets Holders Additional accessories

Condition: ready for operation (used), Year of construction: 1992, functionality: fully functional, bar diameter (max.): 32 mm, turning length: 80 mm, drilling depth: 80 mm, No reserve price – guaranteed sale to the highest bidder! The machine is sold with collets, holders, and additional accessories! For more Schütte multi-spindle machines available at the same location, see below! TECHNICAL DETAILS Max. turning length: 80 mm Hsdpfxjz Ag Ano Ac Ajfl Max. drilling depth: 80 mm Maximum bar diameter round: 32 mm Maximum bar diameter square: 22 mm Maximum bar diameter hexagonal: 27 mm Maximum bar diameter octagonal: 29 mm Spindle circle diameter: 300 mm Standard bar feed: 125 mm Special bar feed: 290 mm Normal longitudinal slide total travel: 100 mm Normal longitudinal slide working travel: 80 mm Special longitudinal slide total travel: 145 mm Special longitudinal slide working travel: 115 mm Cross slide upper slide total travel: 50 mm Cross slide upper slide working travel: 33 mm Cross slide middle slide total travel: 50 mm Cross slide middle slide working travel: 30 mm Cross slide lower slide total travel: 60 mm Cross slide lower slide working travel: 37.5 mm Maximum material passage: 32 mm Maximum material feed: 125 mm MACHINE DETAILS Voltage: 400 V Frequency: 50 Hz Coolant capacity: 700 l Pump: E-submersible pump Pump capacity: 180 l/min EQUIPMENT Rapid drilling device Gripper device Reaming device Independent auxiliary longitudinal control Motorized cross slide adjustment Collets Holders Additional accessories

Condition: ready for operation (used), Year of construction: 1992, functionality: fully functional, bar diameter (max.): 32 mm, turning length: 80 mm, drilling depth: 80 mm, No minimum price – guaranteed sale to the highest bidder! This machine is sold complete with collets, tool holders, and additional accessories. Hfodpfx Aez Ag Aboc Asl For more Schütte multi-spindle lathes available from the same site, please see below! TECHNICAL DETAILS Maximum turning length: 80 mm Maximum drilling depth: 80 mm Maximum bar diameter, round: 32 mm Maximum bar diameter, square: 22 mm Maximum bar diameter, hexagonal: 27 mm Maximum bar diameter, octagonal: 29 mm Spindle pitch circle diameter: 300 mm Standard bar feed up to: 125 mm Special bar feed up to: 290 mm Standard longitudinal slide travel, total: 100 mm Standard longitudinal slide travel, working travel: 80 mm Special longitudinal slide travel, total: 145 mm Special longitudinal slide travel, working travel: 115 mm Upper cross slide travel, total: 50 mm Upper cross slide travel, working travel: 33 mm Middle cross slide travel, total: 50 mm Middle cross slide travel, working travel: 30 mm Lower cross slide travel, total: 60 mm Lower cross slide travel, working travel: 37.5 mm Maximum material passage: 32 mm Maximum material feed: 125 mm MACHINE DETAILS Voltage: 400 V Frequency: 50 Hz Coolant capacity: 700 l Pump: Submersible electric pump Pump output: 180 l/min EQUIPMENT High-speed drilling unit Gripper unit Reaming unit Independent auxiliary longitudinal control Powered cross slide adjustment Collets Tool holders Additional accessories

Condition: ready for operation (used), Year of construction: 1991, functionality: fully functional, bar diameter (max.): 32 mm, turning length: 80 mm, rotational speed (max.): 3,150 rpm, drilling depth: 80 mm, No minimum price – guaranteed sale to the highest bidder! The machine is sold with collets, tool holders, and additional accessories! For more Schütte multi-spindle machines from the same location, see below! TECHNICAL DETAILS Maximum bar capacity: 32 mm Maximum bar feed: 125 mm Maximum turning length: 80 mm Maximum drilling depth: 80 mm Spindle speed for turning: 200–3,150 rpm Spindle speed for right-hand thread cutting: 11.2–1,575 rpm Hfodpfxjz Agz Ds Ac Aol MACHINE DETAILS Coolant capacity: 600 l Pump output: 170 l/min Dimensions & Weight Required space: 7.3 x 2.5 m Height: 2 m Weight: 8,300 kg Voltage: 380 V Frequency: 50 Hz Main drive: 20.5 kW Immersion pump: 1.5 kW Feed drive: 1.5 kW Hydraulic pump: 1.5 kW Circulating oil pump: 0.25 kW EQUIPMENT 6 cross slides 6 longitudinal slides 6 cams for cross slides 6 cams for longitudinal slides Operating tools Collets Tool holders Additional accessories

Condition: ready for operation (used), Year of construction: 1983, functionality: fully functional, spindle speed (max.): 3,150 rpm, bar diameter (max.): 32 mm, overall weight: 8,300 kg, No reserve price – guaranteed sale to the highest bidder! The machine is sold with collets, tool holders, and additional accessories! For more Schütte multi-spindle machines being sold from the same location, please see below! TECHNICAL DETAILS Maximum bar diameter, round: 32 mm Maximum bar diameter, square: 22 mm Maximum bar diameter, hexagonal: 27 mm Maximum bar diameter, octagonal: 29 mm Spindle circle diameter: 300 mm Bar feed normal/special up to: 125 / 290 mm Longitudinal slide travel, standard, total/work stroke: 100 / 80 mm Longitudinal slide travel, special, total/work stroke: 145 / 115 mm Cross slide travel, upper slide, total/work stroke: 50 / 33 mm Cross slide travel, middle slide, total/work stroke: 50 / 30 mm Cross slide travel, lower slide, total/work stroke: 60 / 37.5 mm Number of spindle speeds: 49 Spindle speed range I: 450–3,150 rpm Spindle speed range II: 200–1,400 rpm Workpiece revolutions per operation, standard: 60–425 Workpiece revolutions per operation, shortened: 33.5–236 Workpiece revolutions per operation, extended: 95–670 Number of main times per spindle speed: 35 MACHINE DETAILS Drive motor rated power: 18.5 kW Drive motor speed: 1,500 rpm Dimensions with control cabinet (L x W): 3,850 x 1,510 mm Length with bar feeder: 6,453 mm Machine weight: 8,300 kg Space requirement for packed machine: 15 m³ EQUIPMENT Hfsdpjz Agzqsfx Ac Ajl Collets Tool holders Additional accessories

Condition: ready for operation (used), Year of construction: 1982, functionality: fully functional, spindle speed (max.): 3,150 rpm, bar diameter (max.): 32 mm, overall weight: 8,300 kg, No reserve price – guaranteed sale to the highest bidder! The machine is sold complete with collets, toolholders, and additional accessories! For more Schütte multi-spindle machines available from the same location, see below! TECHNICAL DETAILS Maximum bar diameter, round: 32 mm Maximum bar diameter, square: 22 mm Maximum bar diameter, hexagonal: 27 mm Maximum bar diameter, octagonal: 29 mm Spindle pitch circle diameter: 300 mm Standard/special bar feed: up to 125 / 290 mm Standard longitudinal slide travel, total/traverse: 100 / 80 mm Special longitudinal slide travel, total/traverse: 145 / 115 mm Cross slide travel – upper slide, total/traverse: 50 / 33 mm Cross slide travel – middle slide, total/traverse: 50 / 30 mm Cross slide travel – lower slide, total/traverse: 60 / 37.5 mm Number of spindle speeds: 49 Spindle speed range I: 450–3,150 rpm Spindle speed range II: 200–1,400 rpm Workpiece revolutions per cycle, standard: 60–425 Workpiece revolutions per cycle, reduced: 33.5–236 Workpiece revolutions per cycle, extended: 95–670 Number of main times per spindle speed: 35 MACHINE DETAILS Drive motor: 18.5 kW Drive motor speed: 1,500 rpm Dimensions & Weight Dimensions with control cabinet (L x W): 3,850 x 1,510 mm Hjdpez Agzdofx Ac Asfl Length with bar feeder: 6,453 mm Machine weight: 8,300 kg Space required for packed machine: 15 m³ EQUIPMENT Collets Toolholders Additional accessories

Condition: ready for operation (used), Year of construction: 1992, functionality: fully functional, spindle speed (max.): 3,750 rpm, bar diameter (max.): 26 mm, overall weight: 6,800 kg, No reserve price – guaranteed sale to the highest bidder! Hfjdpfx Acjz Agy Ho Ael The machine is sold complete with collets, toolholders, and additional accessories! For further Schütte multi-spindle machines for sale from the same location, see below! TECHNICAL DETAILS Bar diameter round: 26 mm Bar diameter square: 19 mm Bar diameter hexagonal: 22 mm Bar diameter octagonal: 24 mm Spindle circle diameter: 270 mm Standard bar feed: 125 mm Special bar feed: 290 mm Longitudinal slide travel, standard total: 80 mm Longitudinal slide travel, standard working length: 63 mm Longitudinal slide travel, special total: 125 mm Longitudinal slide travel, special working length: 98 mm Cross slide travel, upper slide total: 40 mm Cross slide travel, upper slide working length: 25 mm Cross slide travel, middle slide total: 40 mm Cross slide travel, middle slide working length: 25 mm Cross slide travel, lower slide total: 50 mm Cross slide travel, lower slide working length: 31 mm Number of spindle speeds: 49 Spindle speed range I: 530–3,750 rpm Spindle speed range II: 236–1,700 rpm Workpiece revolutions per working cycle, standard: 60–425 Workpiece revolutions per working cycle, short: 33.5–236 Workpiece revolutions per working cycle, extended: 95–670 Number of main times per spindle speed: 35 MACHINE DETAILS Rated drive motor power: 18.5 kW Drive motor speed: 1,500 rpm Dimensions & Weight Dimensions with control cabinet (L x W): 3,500 x 1,450 mm Length with bar guide: 6,470 mm Machine weight: 6,800 kg Space requirement for packed machine: 14 m³

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, spindle motor power: 26 W, number of spindles: 2, spindle speed (max.): 5,000 rpm, spindle bore: 77 mm, Equipment: documentation/manual, MAZAK QTN-250 II MSY turning center + Fanuc robot with Meccano automation for flanges Year 2015 Control unit: MATRIX II Maximum swing (capacity): 640 Workable diameter / standard workable diameter (capacity): 380 Maximum workable length*1 (capacity): 500 Hsdpfx Acezz Rh Eo Ajfl Bar capacity (capacity): 77 Chuck size (main spindle): 250/210 Spindle speed (main spindle): 4500/5000 Spindle nose (main spindle): ASA 8 / ASA 5 Spindle speed (powered tool spindle): 5000 Rapid traverse rate axis X (feed): 36,000 Rapid traverse rate axis Z (feed): 36,000 Rapid traverse rate axis C (feed): 550 Travel (tailstock): 500 Main spindle motor (continuous / 40% duty) (motors): 26 kW Coolant tank (coolant): 300 l Sub-spindle chuck diameter: 210 Sub-spindle speed: 5000 Travel axes X, Z, Y: 230mm, 575mm, 100mm

Condition: used, Year of construction: 2011, Micro 8 automatic lathes and LNS Tryton bar feeders. Hfodpfx Acjzz Nl Ne Asl

Condition: ready for operation (used), Year of construction: 2013, operating hours: 22,100 h, bar diameter (max.): 104 mm, overall weight: 13,000 kg, controller manufacturer: SIEMENS, controller model: Sinumerik, number of axes: 4, This 4-axis DMG CTX beta 800 4A was manufactured in 2013. It features a maximum turning diameter of 340 mm and a turning length of 735 mm. The machine is equipped with two 12-station tool turrets and an integrated spindle motor with a maximum speed of 4000 rpm. If you are looking to get high-quality turning capabilities, consider the DMG CTX beta 800 4A multi-spindle turning machine we have for sale. Contact us for further details. - Control: Siemens 840D Solutionline with ERGOline Control and ShopTurn 3G- Max Turning Diameter: 340 mm- Max Turning Length: 735 mm- Main Spindle (HS): Integrated spindle motor ISM 102, 40/48 kW (100/40% ED), 0-4000 rpm, 570/680 Nm- Counter Spindle (GS): Integrated spindle motor ISM 76, 25/32 kW (100/40% ED), 0-5000 rpm- Draw Tube Inner Diameter: 104 mm- Tool Turrets: 2x 12-station Sauter star turrets (VDI 40 with Trifix interface, DIN 69880-40)- Driven Tool Drive: 2x Direct Drive, 40-10,000 rpm, 14.2 kW, 34 Nm- Axis Configuration: 4 Main Motion Axes (X1, Z1, X2, Z2), 2 C-Axes with hydraulic spindle brake (HS + GS), Y-Axis for Slide 1 and Slide 2 (stroke 40 mm), NC cross-stroke X3 axis for counter-spindle slide (180 mm)- Counter Spindle Slide: Includes NC cross-stroke X3 (180 mm) with linear scale, and integrated tailstock- Tailstock: Automatic quill stroke 300 mm, tailstock force 1.5 - 6.3 kN, revolving center MT5- Measuring Systems: Direct measuring systems (Glass scales) in X1, X2, and X3 axes- Coolant System: 980 Liter tank with band filter, cooler, 8/20/80 bar pressure options, and expansion for Turret 2- Additional Equipment: Chip conveyor, automatic electric sliding hood, workpiece in-process measurement system (Renishaw), Brankamp CMS collision monitoring system, mechanical oil mist separator (1,100 m³/h) Hsdezzpxpepfx Ac Asfl Technical Specification Counter Spindle Yes

Condition: used, Year of construction: 2004, Tornos MultiDeco 20/8 Number of spindles: 8 Hedpfx Acjzy Spuo Aofl Maximum bar diameter: 20 mm Spindle speed: 5000 rpm Main spindle power: 15 kW / 18.5 kW Maximum part length: 100 mm without backworking; 75 - 80 mm with backworking Number of backworking spindles: 1 Backworking spindle axial travel: 160 mm Backworking spindle motor power: 1.1 kW CNC control unit: Fanuc Programming system: TB-DECO software platform IEMCA integrated automatic bar feeder High-pressure coolant pump and fine filtration system Automatic chip conveyor The machine is in working condition and can be inspected upon request.

Condition: used, Year of construction: 2019, functionality: fully functional, feed length X-axis: 318 mm, feed length Y-axis: 51 mm, feed length Z-axis: 584 mm, number of spindles: 2, spindle speed (max.): 4,500 rpm, spindle bore: 51 mm, Equipment: cooling unit, documentation/manual, The DS-30Y Y-axis turning center combines turning with two spindles, a Y-axis, a C-axis, and powered tooling to create a powerful “one-hit” solution for any workshop. Milling, drilling, and off-center threading can be enhanced for increased machining capabilities. It comes standard with a 12-station BMT65 turret and a synchronized C-axis for versatile 4-axis capabilities. Counter spindles support fully synchronized rotation and enable workpiece transfer during operation to reduce cycle times. Hjdpfxezvy D Es Ac Aefl Spindle | CHUCK-10"-A2-6 4.8K-20HP-A2-5-DS | CHUCK-8.3"-A2-5 LT-BMT65-12 Live Tooling 4000 rpm CONVEYOR ATP Automatic Tool Presetter PCAT Part Catcher HPC High-Pressure Coolant CABCOOL NGC | 1GB, ETHERNET, WIFI, EPFDM SO, MACRO, RTAP, 8M

Condition: ready for operation (used), Year of construction: 2006, spindle motor power: 22,000 W, spindle speed (max.): 3,500 rpm, bar diameter (max.): 76 mm, travel distance X-axis: 250 mm, travel distance Y-axis: 50 mm, controller manufacturer: FANUC, controller model: 18i-TB, number of axes: 6, This 6-axis DOOSAN Puma TT 2500 SY was manufactured in 2006. It is a multi-spindle turning machine featuring twin spindles and twin turrets, equipped with a Fanuc 18i-TB control. Key specifications include a maximum turning diameter of 330 mm, turning length up to 500 mm, and bar capacity of 76 mm. Main spindle speed reaches 3500 RPM, while the sub-spindle can go up to 6000 RPM. If you are looking to get high quality turning capabilities consider the DOOSAN Puma TT 2500 SY machine we have for sale. Contact us for more information. Hodpfxszvu Ufj Ac Aefl • Max turning diameter: 330 mm (12.99 in); upper turret: 390 mm • Max turning length: 500 mm (19.6 in) • Bar capacity (main spindle): 76 mm (2.99 in) • Travels: X 250 mm (9.84 in), Y ±50 mm (±1.97 in), Z 580 mm (22.8 in) • Sub spindle speed: 6000 rpm • Sub spindle motor power: 7.5 / 11 kW • Notes: Series introduced mid-2000s Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: good (used), Year of construction: 1990, Index MS 25 E (3 pieces per package) Number of spindles: 6 Spindle bore: 27 mm Turning length: 59 mm Hexagon material: 24 mm Square material: 18 mm Cross slide travel: 36 mm Longitudinal slide travel: 85 mm Hfedpozvpt Nofx Ac Ael Spindle speeds: 366 - 5020 rpm Torque: 95 Nm Control system: INDEX Total power consumption: 20 kW - 6 cross slides - 6 longitudinal slides - Multi-tool turret - Thread cutting device - Hydraulic part removal device - Workpiece conveyor belt - Bar feeder magazine

Condition: used, Year of construction: 2000, No. of axis 10 No. of spindles 2 Hsdpfx Acezvcdue Ajfl Max. spindle bore 10 mm Spindle speeds 100-16000 rpm Control: Fanuc Equipped with: Magazine barfeeder FMB Minimag Chip conveyor

Condition: used, Year of construction: 2003, No. of axis 10 Hfedpfx Acszvb Ryj Ael No. of spindles 2 Max. spindle bore 16 mm Spindle speeds 100-10000 rpm Live toolings on S2, S3, S5 & S6 Control: Fanuc PNC 16i Equipped with: Magazine barfeeder FMB Turbo 2-16

Condition: good (used), Year of construction: 2014, functionality: fully functional, using Stäubli robots Specifications, information, price, images, etc. can be found in the PDF documents attached. Hsdpfx Aozuc T Tec Asfl

Condition: used, Year of construction: 1990, Technical details: number of spindles: 8 Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: AFH130 with CNC Yob: 1990 eight-spindle automatic lathe 8 main spindles Chucker AFH130 for complete machining means front- and back side Control Siemens Sinumerik 840DI Hsdjzubyrjpfx Ac Aofl complete revising and new configuration of this machine in year 2010. loading arm, for loading and disloading Workpiece turn around station in pos. 4 position 4 with workpiece length control CNC compound slide in pos. 5 coolant pump with magnet candle filter delivered tooling: could be different like pictures option: Ergomat TBF42 for cutting off for half finnishing with FMB-Turbo Visiting under production condition is possible Please, contact us for getting more information and pictures on mail(at) or *

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, number of spindles: 2, spindle speed (max.): 4,500 rpm, turning length: 145 mm, turning diameter: 240 mm, travel distance X-axis: 130 mm, travel distance Z-axis: 145 mm, Horizontal, twin-spindle CNC lathe with 2 turrets in two working areas and 2 loading portals! The machine underwent an overhaul in 2023! TECHNICAL DETAILS Turning diameter max.: 240 mm Turning length max.: 145 mm Travel X-axis: 130 mm Travel Z-axis: 145 mm Distance between spindles: 340 mm Rapid traverse X/Z-axis: 24 m/min Guidance X-axis: Roller linear guide Guidance Z-axis: Round guide, 145 mm Number of spindles: 2 Spindle drive power: 11 / 7.5 kW Max. spindle speed: 4,500 rpm Torque: 93 Nm Spindle nose: JIS A2-5 Chuck size: 210 mm (8 inches) Number of turrets: 2 Turret type: BT turret Tool positions per turret: 8 Shank size for external turning tools: 20 × 20 mm Max. shank diameter for boring bars: 40 mm MACHINE DETAILS Control: Fanuc 32i-B Working areas: 2 Power connection: 30 kVA Dimensions & Weight Footprint: 4,500 × 2,440 mm Hfjdpfsztxlcex Ac Ael Overall height with loader: 2,550 mm Weight: 4,400 kg Loading portal GT Twin with two independent portals Dual gripper for raw and finished parts Turning station Control unit with cable Max. workpiece diameter: 120 mm Max. workpiece length: 80 mm Max. workpiece weight: 3 kg EQUIPMENT Stack magazine, on the left side Parts conveyor belt, on the right side Chip conveyor, on the rear side Coolant tank Coolant supply through both spindles for flushing the clamping devices Various tool holders Various clamping devices Documentation and wiring diagrams

Condition: ready for operation (used), Year of construction: 2002, operating hours: 63,040 h, functionality: fully functional, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Machine configuration Hsdpfxozrgnpe Ac Aefl Upper linear slides: 2 units Milling unit: 1 unit Transverse drilling units: 2 units Rigid front spindle: 1 unit Machining units Drum 6: Movable only in the X-axis Front position 1: Rotationally rigid spindle, movable only forwards and backwards Front positions 2 to 4: Rotationally fully controllable spindles Front position 5: Internal machining axis for processing internal contours and radii Front position 6: Driven indexing spindle with rear machining slide and two tools, movable towards the viewing side Full electronic equipment Electronically connectable auxiliary drives on the front positions and six drum slides MACHINE DETAILS Operating hours: 98,119 h Spindle hours: 63,040 h EQUIPMENT Chip conveyor High-pressure coolant unit Bar loader Milling unit Two transverse drilling units Collets Spare parts Electronic components for the control cabinet New rigid front spindle

Condition: good (used), Year of construction: 2014, See documents. Hfedpfx Aozqtg Asc Ajl List of individual machines with operating hours, etc. – see documents.

Condition: ready for operation (used), Year of construction: 2008, spindle motor power: 26,000 W, spindle speed (max.): 3,500 rpm, bar diameter (max.): 76 mm, total width: 2,210 mm, total height: 2,480 mm, overall weight: 12,700 kg, controller manufacturer: FANUC, controller model: Series 31i-MODEL A, product length (max.): 4,050 mm, number of axes: 8, This 8-axis DOOSAN PUMA TT2500SY was manufactured in 2008. It features a maximum turning diameter of 390 mm on the upper turret and 300 mm on the lower turret, with a maximum turning length of 350 mm. The machine includes a robust tool turret with 24 stations and a rapid traverse speed of 20 m/min for X1 and X2 axes. If you are looking to get high-quality turning capabilities, consider the DOOSAN PUMA TT2500SY multi-spindle turning machine. Contact us for further details. • Number of axes: 8 (X1, X2, Z1, Z2, Y, B, C1, C2) • Swing over bed: 800 mm • Swing over saddle: 620 mm • Max. turning diameter: Upper turret 390 mm; Lower turret 300 mm • Recommended turning diameter: 255 mm • Max. turning length: 350 mm • Main/left spindle motor power (30 min / cont): 26 / 22 kW • Main/left spindle nose: ASA A2-8 • Right/sub spindle max. speed: 3500 rpm • Right/sub spindle motor power (30 min / cont): 26 / 22 kW • Right/sub spindle nose: ASA A2-8 Hfjdpfoznwf Dox Ac Ael • C-axis indexing (C1 & C2): 360° in 0.001° increments • Upper turret travel (X1/Z1/Y): 255 / 800 / 120 mm (±60 mm Y) • Lower turret travel (X2/Z2): 190 / 900 mm • Sub-spindle B-axis travel: 810 mm • Rapid traverse (X1/X2): 20 m/min • Rapid traverse (Z1/Z2/B): 24 m/min • Rapid traverse (Y): 7.5 m/min • Turret stations: 24 total (12 upper + 12 lower) • Tooling type/interface: BMT65P • Indexing time: 0.2 s • Rotary tool spindle speed: 4000 rpm • Rotary tool motor power (15 min / cont): 5.5 / 1.5 kW • Machine electric power supply: 95.77 kVA Additional equipment • Chip conveyor • Various static tool holders • Rotary live tool holders • Chucks on both spindles Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, We offer you: Manufacturer: INDEX Type: MS40-6 C Year of construction: 2019 Control: Index control C200-SL, MS40C Double-NCU Technical data: Working spindles: Number: 6 pcs. Spindle bore: max. 40 mm Max. speed: 7,000 rpm Power (100% / 25%): 13 / 24 kW Torque (100% / 25%): 31 / 57 Nm Synchronous spindle: Number: 1 pc. Spindle bore: 40 mm Max. speed: 8,000 rpm Power (100% / 25%): 10 / 14 kW Torque (100% / 25%): 16 / 22 Nm Slide travel z: 150 mm Number of tools for back-end machining: 3 pcs. Swiveling range b: 144 ° Tool holder: Number: 12 pcs. Slide travel x: 73 mm Slide travel z: 120 mm Tool holder, cut-off and back-boring slide: Number: 1 pc. Slide travel x: 82 mm Number of tools for back-end machining: 3 pcs. Electrical connection data: Rated power: 85 kW Connection power: 101 kVA Rated current: 145 A Max. pre-fuse: 160 A Note: Mains voltage: 400V Note: Electrical frequency 50 Hz Technical features & accessories: - Double-NCU - Signal light 'Smartlight' with LED - Machine designed for connection to a TN network. - Coolant: Cutting oil - NC option Synchronous spindle / Multi-sided turning incl. electronic shaft - INDEX loading magazine MBL40-6/3300/Strip loader/50Hz: - Strip loader 50Hz - for bar diameter D13 - D40 - Bar length 3300 mm - with pilot drilling unit - Material storage with 700 mm support area - Profibus-DP-Master interface. - 1 set (6 pieces) reducing sleeves manufactured for bar or corner dimensions, diameter D = * mm, Inner diameter range D14 - D41 - 1 set (6 pieces) material sliders for material diameter D24mm - D32mm, consisting of: - 6 material sliders D23 - 6 rotating sleeves D23 - 1 set (6 pieces) internal clamping sleeves D23mm - for material diameter D24mm - D32mm - pilot drilling diameter D15mm - 1 set (6 pieces) external stops D23mm - for material diameter D24mm - D32mm - pre-machined - 1 set (12 pieces) reducing sleeves for material sliders. The outer diameter of the reducing sleeves corresponds to the material diameter (D13 - D40) - 1 set (6 pieces) adapter sleeves, inner diameter range D13.5 - D40.5. The inner diameter of the adapter sleeves should be bar diameter + 0.5mm. - 1 set (6 pieces) two-part guide intermediate tubes, diameter 29 mm - Assembly aid for the sleeves of the guide intermediate tubes - UNIMAG - Interface for connecting a bar loader - Part discharge via slide into spindle position 6 - Workpiece conveyor belt in spindle position 6, machine-integrated - Hainbuch TOPlus Axfix D40 for synchronous spindle - Multi-sided and thread milling device - Reduction ratio i=5:1 - Inductive encoder for reference query - Internal oil lubrication - INDEX short taper connection - without converter - Back-end machining device on slide position 6.2 for max. three boring positions for fixed tools FURTHER INFORMATION IN THE PICTURES Accessories, tools and clamping devices shown are only included in the scope of delivery if this is stated in the additional information. Changes and errors in the technical data and information, as well as prior sale, are reserved! Hfedozlutmjpfx Ac Asl

Condition: used, Year of construction: 2015, The machine will be delivered as shown in the photos, including the visible tool holders, etc. Hsdpfx Acjzlqave Asfl
