Condition: used, Excel XL 420 Lathe x 2m Between Centres, 2 Axis Digital Readout, Fitted With 3 Jaw Chuck, complete with quick change tools (3), 4 jaw chuck and steady rest. Hnedpfoyabcfjx Ahueg

Condition: refurbished (used), Year of construction: 2002, operating hours: 2,500 h, functionality: fully functional, machine/vehicle number: 350523, Equipment: CE marking, Voltage: 380V Net weight: 1400 kg Customs tariff number: 8458.1120 Dimensions: 180x128x172 cm TECHNICAL SPECIFICATIONS CAPACITIES Maximum turning diameter: 270 mm Maximum diameter above cross slide: 115 mm Height of center above cross slide: 60 mm Turning length B32: 265 mm Center height above floor: 1,162 mm Hnodex Upugjpfx Ahueg SPINDLE A2-4 / Camlock D1-3’’ Spindle for Schaublin collets: Hainbuch / F38 / B32 Spindle speed: 50–5,000 rpm AC motor drive: continuous/intermittent power: 5.5 / 7.5 kW AC motor drive: continuous/intermittent torque: 42 / 58 Nm Spindle bore (without clamping key): 39 mm Maximum bar capacity with collet: 32 mm Maximum bar capacity with automatic chuck: 32 mm PNEUMATIC CLAMPING Adjustable axial clamping force, force at 5 bars: 1,150 daN CROSS SLIDE Cross travel, X-axis: 190 mm Resolution, X-axis (radius): 0.0005 mm AC motor drive: continuous/intermittent torque: 4 / 14 Nm Ball screw, diameter x pitch: Ø 20 x 5 mm Longitudinal travel, Z-axis: 390 mm Resolution, Z-axis: 0.001 mm AC motor drive: continuous/intermittent torque: 4 / 14 Nm Ball screw, diameter x pitch: Ø 32 x 5 mm FEED RATES Working feed rates, X and Z axes, stepless: 0–5 m/min Rapid traverse, X and Z axes: 8 m/min TURRET TOOL SYSTEM Standardized toolholder mounting: VDI 20 Number of fixed/tool stations: 8 / - Maximum tool section: 16x16 mm Integrated coolant and bi-directional indexing: yes COOLANT SYSTEM Tank capacity: 55 L Pump flow rate: 10 L/min Pump pressure: 1.7 bar PNEUMATIC TAILSTOCK Quill taper: MT3 Outside diameter of quill: 45 mm Quill stroke: 70 mm Adjustable tailstock pressure: 25–260 daN Subject to errors or omissions, all technical details are provided without commitment. Completely overhauled: Mechanics, geometry, hydraulics, and electrical parts checked and/or replaced Headstock Disassembly, parts cleaning, replacement of worn and defective parts, replacement of bearings, replacement of belts, spindle disassembly, replacement of seals and O-rings, adjustment. New paint. Turret Disassembly, cleaning, replacement of worn/defective parts. New paint and face resurfacing. Tailstock Disassembled, inspected, and serviced. New paint. Hydraulic and pneumatic circuits Disassembled, motor inspected, hoses, defective and worn parts replaced. X-Axis Disassembly, replacement of worn parts such as O-rings, seals, rings. New ball screw and new sliding block. Z-Axis Disassembly, replacement of worn parts such as O-rings, seals, rings. New ball screw and new sliding block. Electrical cabinet Complete inspection, various relays replaced. Paintwork Colors: White RAL 9003 and grey RAL 7011 Geometry according to manufacturer's protocol. Various accessories checked and cleaned Year: 2002

Condition: good (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 500571, turning length: 800 mm, spindle bore: 100 mm, travel distance X-axis: 200 mm, travel distance Z-axis: 500 mm, total height: 3,300 mm, total length: 6,000 mm, total width: 3,000 mm, overall weight: 8,000 kg, controller manufacturer: SIEMENS, controller model: SINUMERIK, INDEX G 300 CNC Lathe - Operating voltage: 400 V Hodox Tz Snopfx Ahujng - Rated current: 80 A - Connection: 47 kW - Frequency: 50 Hz - Including a double turret each with a 12-station tool turret, as well as a tailstock and main spindle - Includes chip conveyor and two manuals, as well as a BÜCHEL manufacturer filter extraction system Note: The machine can be transported on a standard truck. Note: The item must be collected between 18 and 26 February 2026 on a binding, to-be-agreed date. FCA D-78087 Mönchweiler – loaded onto truck

Condition: used, TECHNICAL DETAILS - Number of axes : 3 MAIN SPINDLE - Spindle nose : A2-5 - Spindle power : 11 [kW] - Spindle speeds : 6000 [rpm] - Max. bar diameter : 51 [mm] - Max. turning diameter : 280 [mm] - Max. chuck diameter : 150 [mm] TURRET - Number of positions : 12 - Number of motorized positions : 12 - X/Z stroke : 185/385 [mm] - Live tools speed : 4500 [rpm] - Live tools power : 5.5 [kW] TAILSTOCK - Tailstock type : Automatique - Type of cone : CM4 - Tailstock stroke : 350 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 22.8 [kW] WEIGHT & DIMENSIONS - Machine floor space : 2100/1700 [mm] - Machine height : 2000 [mm] - Machine weight : 3800 [kg] Hnedpfx Ahjx Tvhqeuog MACHINE HOURS - Number of hours under power : 57677 [h] - Number of working hours : 30885 [h] EQUIPMENT - CNC : MATRIX NEXUS - Interactive programming - Coolant tank - Chips conveyor - Tool probe - Parts catcher - Bar loader : LNS QUICKLOAD 65

Condition: excellent (used), Year of construction: 2007, Mori Seiki NL2000Y/500 CNC Lathe (05/2007) Manufacturer: Mori Seiki Hnedsx Tp N Ispfx Ahujg Model: NL2000Y/500 Year of manufacture: 05/2007 Condition: used, very good, in operation Control: MSX-850II Optional with tooling and accessories.

Condition: ready for operation (used), Year of construction: 2008, Takamaz XY-2000 Plus CNC lathe (2008) Manufacturer: Takamaz Model: XY-2000 Plus CNC lathe Year of manufacture: 2008 Condition: Used, powered up and in production. 2x spindles (2x Hainbuch collet chucks) 2x tool turrets, each equipped Parts catcher Bar feeder Video available. Hjdpfxox Ti Hgj Ahujng Further information upon request.

Condition: used, Year of construction: 2017, machine/vehicle number: IntNr231463, Machine Designation: CNC Short-Turning Lathe Manufacturer: Index Model: ABC Year of Manufacture: 2017 Control System: Fanuc 32i-B Operational Status: Fully operational Operating Hours: approx. ___ hours Technical Data Spindle Bore: Ø 42 mm Travel and Feed Data: X-Axis Travel: approx. 90 mm Z-Axis Travel: approx. 280 mm Rapid Traverse X: approx. 27 m/min Rapid Traverse Z: approx. 36 m/min Upper Turret (Main Tool Carrier): Number of Stations: 8 (1 synchronizable) Tool Mount: VDI 25 Capable of powered tooling Lower Turret: Number of Stations: 6 Non-driven Rear Side: 5 stations for back-working operations Simultaneous Machining: Up to 3 tools at the same time Hodpex Tftvofx Ahusng Coolant System & Chip Conveyor Bar Feeder: IRCO ILS MUK 7012-II, Year 2015 Accessories / Tooling / Manuals Machine Dimensions & Weight Machine: approx. 2830 × 1500 × 2200 mm, Weight: approx. 3,500 kg Coolant System & Chip Conveyor: approx. 1600 × 1250 × 1780 mm, Weight: approx. 680 kg Bar Feeder IRCO ILS MUK: approx. 1800 × 1000 × 1280 mm, Weight: approx. 650 kg The machine is fully operational and in good used condition. For further information or to arrange a live demonstration under power, please do not hesitate to contact us. All technical specifications and details are subject to change and error. Subject to prior sale.

Condition: good (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: R7 A-Q-2701, Used CNC lathe Hodpfxsx Tbcyj Ahueng Manufacturer: EMCO Model: Hyperturn 665 Year of manufacture: 2002 Control: 840 D With chip conveyor

Condition: excellent (used), Year of construction: 2004, A fully operational CNC lathe from Böhringer, model NG180, is available for sale. Hsdpfx Ahex Swigjuong

Condition: good (used), Year of construction: 2008, CNC Lathe Weiler DZ 42 Year of manufacture: 2008 Control: Siemens 840D / Shopturn Hnsdex N H Nkjpfx Ahusg Manual loading up to D 220 mm Material passage: 42 mm Max. turning length: 450 mm Spindle speed: 6300 rpm Machining Turret with 16 driven tools X/Z/Y / C-axis Collet chuck

Condition: good (used), Year of construction: 2014, spindle speed (min.): 2,500 rpm, Year of manufacture: 2014 Chuck diameter: 10" Number of axes: 3 Swing over bed: 250 mm Hjdpfx Aox N A Ebohusng Spindle speed (rpm): 2500 Machinable materials: Steel, Aluminum, Titanium, Graphite, Copper, Invar, Composite, Derlin, Peek

Condition: good (used), Year of construction: 2001, spindle speed (min.): 2,500 rpm, Model Year: 2001 Chuck Diameter: 10" Hnodjx N A Dwepfx Ahueg Number of Axes: 2 Length: 650 mm Swing Diameter: 650 mm Spindle Speed (RPM): 2500 Machinable Materials: Steel, Aluminum, Titanium, Graphite, Copper, Invar, Composite, Delrin, PEEK

Condition: good (used), Year of construction: 2010, spindle speed (min.): 1,500 rpm, travel distance Z-axis: 650 mm, Model Year: 2010 Chuck Diameter: 17" Number of Axes: 2 Length: 650mm Spindle Bore Diameter: 650mm Hnedpfx Asx N A A Tohusg Spindle Speed (RPM): 1500 Machinable Materials: Steel, Aluminum, Titanium, Graphite, Copper, Invar, Composite, Derlin, Peek

Condition: good (used), Year of construction: 2004, spindle speed (min.): 3,500 rpm, travel distance Z-axis: 1,000 mm, Model Year: 2004 Chuck Diameter: 12" Number of Axes: 2 Length: 1000 mm Hnjdjx Nvpajpfx Ahujg Swing Over Bed: 350 mm Spindle Speed (RPM): 3500 Processable Materials: Steel, Aluminum, Titanium, Graphite, Copper, Invar, Composite, Delrin, Peek

Condition: good (used), Year of construction: 2008, spindle speed (min.): 4,000 rpm, travel distance Z-axis: 500 mm, throat depth: 300 mm, Year of manufacture: 2008 Chuck diameter: 8" Number of axes: 3 Length: 500 mm Neck diameter: 300 mm Hnsdpfxex Nvm Ss Ahujg Spindle speed (rpm): 4000 Machinable material types: Steel, Aluminum, Titanium, Graphite, Copper, Invar, Composite, Derlin, Peek

Condition: good (used), Year of construction: 2008, spindle speed (min.): 4,000 rpm, travel distance Z-axis: 500 mm, throat depth: 300 mm, Model Year: 2006 Hnjdpfx Asx Nvm Eohujg Chuck Diameter: 8" Number of Axes: 3 Length: 500 mm Swing Over Bed: 300 mm Spindle Speed (RPM): 4000 Machinable Materials: Steel, Aluminum, Titanium, Graphite, Copper, Invar, Composite, Delrin, PEEK

Condition: good (used), Year of construction: 2008, spindle speed (min.): 5,000 rpm, travel distance Z-axis: 600 mm, throat depth: 300 mm, Year of manufacture: 2008 Chuck diameter: 10" Number of axes: 3 Length: 600 mm Hnsdpfxjx Nvmrj Ahujg Swing diameter: 300 mm Spindle speed (rpm): 5000 Processable materials: Steel, Aluminium, Titanium, Graphite, Copper, Invar, Composite, Delrin, Peek

Condition: good (used), Year of construction: 1995, spindle speed (min.): 4,000 rpm, travel distance Z-axis: 250 mm, throat depth: 300 mm, Year of manufacture: 1995 Chuck diameter: 8" Number of axes: 3 Length: 250 Hnjdpfx Aex Nuxgjhusg Swing diameter: 300 mm Spindle speed (RPM): 4000 Machinable materials: Steel, Aluminum, Titanium, Graphite, Copper, Invar, Composite, Delrin, Peek

Condition: good (used), Year of construction: 2006, spindle speed (min.): 4,000 rpm, travel distance Z-axis: 700 mm, throat depth: 300 mm, Year of Manufacture: 2006 Chuck Diameter: 8" Number of Axes: 3 Length: 500 Swing Over Bed: 300 mm Hnodpfx Asx Npv Tehusg Spindle Speed (RPM): 4000 Processable Materials: Steel, Aluminum, Titanium, Graphite, Copper, Invar, Composite, Derlin, Peek

Condition: good (used), Year of construction: 2015, functionality: fully functional, turning diameter: 500 mm, travel distance Z-axis: 800 mm, Year of Manufacture: 2015 Chuck Diameter: Collet Number of Axes: 2 Length: With guide Hedex Nn Eyopfx Ahujng Throat Diameter: 35mm Spindle Speed (RPM): 4500 Machinable Material Types: Steel, Aluminum, Titanium, Graphite, Copper, Invar, Composite, Delrin, PEEK

Condition: good (used), Year of construction: 2007, functionality: fully functional, rotational speed (min.): 3,000 rpm, feed length Z-axis: 500 mm, fuel type: electric, fuel: electricity, throat depth: 500 mm, Chuck Diameter: 12" Spindle Bore: 500 mm Hnedpfxjx Nnryj Ahuog Machinable Materials: Steel, Aluminum, Titanium, Graphite, Copper, Invar, Composite, Delrin, PEEK

Condition: good (used), Year of construction: 2013, functionality: fully functional, rotational speed (min.): 4,500 rpm, feed length Z-axis: 500 mm, fuel type: electric, fuel: electricity, throat depth: 500 mm, Model Year: 2013 Chuck Diameter: 12" Number of Axes: 2 Length: 500mm Hsdox Nhx Tepfx Ahueng Swing Over Bed: 500mm Spindle Speed (RPM): 3000 Processable Material Types: Steel, Aluminum, Titanium, Graphite, Copper, Invar, Composite, Delrin, Peek

Condition: good (used), Year of construction: 1991, functionality: fully functional, turning diameter: 250 mm, spindle bore: 75 mm, spindle speed (max.): 3,800 rpm, spindle speed (min.): 70 rpm, travel distance X-axis: 400 mm, travel distance Y-axis: 500 mm, spindle motor power: 7,500 W, total height: 1,800 mm, total length: 3,900 mm, total width: 1,800 mm, overall weight: 4,500 kg, Tool turret: 12 positions Hsdpfx Ahox Naiweujng Power supply: 380V Length with chip conveyor: 3.9 m Machine rated power: 21 kVA

Condition: ready for operation (used), Year of construction: 1987, turning length: 260 mm, turning diameter: 180 mm, Fanuc OT 10-position turret maximum spindle speed 4500 rpm weight 2300 kg Hnsdpfxex Ikuno Ahujg

Condition: good (used), turning length: 500 mm, turning diameter: 300 mm, spindle bore: 62 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 210 mm, travel distance Z-axis: 520 mm, Mori Seiki SL-15 CNC Turning Center Machine Type: CNC Turning Center (2-Axis) Serial Number: 1899 Control System: Mori Seiki MSC-516 Maximum Turning Diameter: approx. 300 mm Maximum Turning Length: approx. 500 mm Swing Over Bed: approx. 510 mm Axis Travels X-Axis Travel: approx. 210 mm Z-Axis Travel: approx. 520 mm Spindle Nose: A2-6 Spindle Bore: approx. 62 mm Maximum Spindle Speed: approx. 4,000 rpm Spindle Motor Power: approx. 11 / 15 kW Tool Turret: 12-Station Tool Size: 25 × 25 mm Equipment & Features Hydraulic Tailstock Tool Presetter 6.5" 3-Jaw Power Chuck Hnodpjx Hp Iksfx Ahusg Coolant System Machine Weight: approx. 4,000 kg Machine Dimensions (L × W × H): approx. 2,700 × 1,600 × 1,700 mm
