Holzwerkstatt Jochen Dreckmann

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, Maximum milling height: 120 mm Gisdpfx Alsy Sg Ufoxet Maximum milling depth: 50 mm Maximum milling width: 260 mm Spindle diameter: 40 mm Motor power: 11 kW Spindle speed: 5,400 rpm Feed rate: 0–3.5 m/min Weight: approx. 400 kg

Condition: like new (used), Year of construction: 2014, functionality: fully functional, SCM TF130 CLASS Spindle Moulder Used machine Year: 2014 Features: - Manual adjustment for the lifting of the spindle arbor, equipped with a digital display for accurate working height positioning - Programmable fence with wooden infeed/outfeed tables, dust extraction hood, and wooden table extension; maximum tool diameter Ø250 mm - Spindle speeds: 3,000 / 4,500 / 6,000 / 7,000 / 10,000 rpm - Digital display indicating selected spindle speed - Electrical pre-equipment for power feed unit - Spindle rotation reversal with electric interlock for start-up safety - Automatic star-delta motor starting - Motor power [S6 -40%]: 7kW / 9.5 HP / 50Hz - Safety guard for spindle operations (max tool Ø160 mm) - Emergency stop button - Safety micro-switches for spindle lock - Safety micro-switch on the motor access door - Main isolator switch with lock - Thermal-magnetic overload protection - Transformer for auxiliary circuit: 110V - Automatic motor brake on the main motor - CE conformity certificate Technical Data: - Working table dimensions: 1,200 x 730 mm - Useful spindle length CE Ø30/35 (40/50): 140 (180) mm - Spindle arbor projection from the table: 52 mm - Spindle arbor projection from the table with interchangeable arbor: 92 mm - Maximum retractable tool diameter below table, with ring table: 320 x 85 mm (with sector table Fast=300 x 85 mm) - Fence travel with mechanical programming: 125 mm (positioning from spindle axis: -125 to +125 mm with MK5 arbor) - External diameter of dust extraction port on spindle hood: 120 mm - External diameter of extraction ports on the base (for forced air-cooling of the electrospindle): 120 mm - Extraction system air speed: 20 m/s - Extraction system air consumption: 1,700 m³/h Options on machine: Gedpfx Aloy R Tw Dsxoit - Bar fence - “TL” version for tenoning and profiling (CE compliant) - includes manually operated tenoning carriage - eccentric clamp - adjustable telescopic fence with 4 reference stops for programming workpiece length - break-out preventer on the fence with reference stop - infeed table extension with adjustable front support bar for large workpieces - tenoning hood with dust extraction: - quick tool change, max tool diameter 300 mm - with 30 to 35 mm arbor, max tool diameter 300 mm - with 40 to 50 mm arbor, max tool diameter 350 mm - emergency stop button - operator protection bar - micro-switches for monitoring and limiting to 3,000/4,500 rpm during tenoning operations. Note: - Available only for machines compliant with CE standards. - Available only with mechanically adjustable spindle fence or, alternatively, the "Flex" fence. - Minimum required main motor power: 7 kW.

Condition: used, Technical data: Spindle diameter: 30 mm Spindle height: 160 mm Speeds: 3000/4000/6000/8000 rpm Manual spindle height adjustment Spindle lock Worktable dimensions: 900x1100 (2400) mm Gsdpfoy R Sqvox Alxsit Adjustable fence arms Motor power: 3 kW Power supply: 380 V Overall dimensions: Length: 2400 mm Width: 900 mm Height: 1100 mm

Condition: excellent (used), Catalogue number 7340 TECHNICAL DATA - spindle diameter: 25mm - spindle working height: 120mm - exchangeable spindle - spindle locking - height adjustable up/down - original cast iron fence with full adjustment - 4 spindle speeds + right/left rotation Gjdpoy R A N Nofx Alxoit - table dimensions: 1030x900mm - motor: 3.8kW - overall dimensions (L/W/H): 1030x1000x1080mm - weight: 614kg ADVANTAGES – manufactured in Poland – very good condition – used milling machine Net price: 6,900 PLN Net price: 1,640 EUR depending on the exchange rate of 4.2 EUR (Prices may fluctuate due to exchange rate changes)

Condition: excellent (used), CATALOG NUMBER 7855 Technical specifications: - Spindle diameter: 40mm - Spindle working height: 160mm - Interchangeable spindle - Spindle locking - Height adjustable up/down - Original cast iron fence with full adjustment - 4 spindle speed settings + forward/reverse: 3000, 4500, 6000, 9000 rpm - Table dimensions: 1520x1000mm - Extendable table support - With side carriage for tenoning - Carriage with height adjustment - Electric brake - 3-roller power feed - Number of speeds: 4 - Forward/reverse rotation - Power feed motor: 0.65 kW - Main machine motor: 5.9 kW - Extraction port diameter: 3x120mm - Overall dimensions (L/W/H): 2030x1250x1400mm Godpfxsy Rrw Ne Alxsit - Weight: 1100kg ADVANTAGES – Made in Poland – Top-mounted control panel – With side carriage for tenoning – 3-roller power feed – DTR technical documentation included – Not repainted – Used spindle moulder, in very good condition Net price: 16,900 PLN Net price: 4,020 EUR Net price calculated at 4.2 PLN/EUR exchange rate (Price may change in case of major exchange rate fluctuations)

Condition: excellent (used), Catalogue number 7882 TECHNICAL DATA - Spindle diameter: 30 mm - Spindle working height: 200 mm - Interchangeable spindle - Spindle lock Gedey Rrrmepfx Alxoit - Height adjustable (up/down) - Cast iron fence with full adjustment - 3 spindle speeds + clockwise/counterclockwise rotation - Table dimensions: 1000 x 950 mm - Cast iron table - With side carriage: 1100 x 330 mm - Clamping device - Motor power: 3.7 kW - Brake - Extraction port diameter: 120 mm - Dimensions (L/W/H): 1750 x 1400 x 1250 mm - Weight: 683 kg ADVANTAGES – German-made – With side carriage – Used spindle moulder – In very good condition Net price: 7,900 PLN Net price: 1,880 EUR (based on 4.2 exchange rate) (Prices may vary with significant exchange rate fluctuations)

Condition: used, Stehle milling machine from company liquidation, as shown in the pictures, fully functional. Giodpfx Aey Nzmqslxot

Condition: used, total length: 1,150 mm, total width: 900 mm, total height: 1,800 mm, Colour: Green Empty weight: 400 kg - Documentation available: No - CE certificate present: No - Spindle diameter [mm]: 25 - Table length [mm]: 1150 - Table width [mm]: 900 - Tiltable spindle: - └ Min. tiltability [°]: 0 - └ Max. tiltability [°]: 45 - Feeding device present: Yes - Brand: Holz-her - Number of wheels [pcs]: 3 - Tool key included: Yes - Tools (milling heads) included: Yes - Spindle speed: Manual - Min. spindle speed [rpm]: 1400 - Max. spindle speed [rpm]: 1200 Gjdpsy Nc Aaefx Alxoit - Voltage [V]: 400 - Fuse [A]: 32 - Transport dimensions: 1150mm x 900mm x 1800mm (l x w x h) - Transport weight [kg]: 400kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: good (used), - spindle diameter: 25 mm - working spindle height: 100 mm - interchangeable spindle - height adjustable (up/down) Giedpfx Aoy Ivkuslxet - original cast iron fence - table dimensions: 1020x900 mm - motor: 5 kW

Condition: good (used), - Spindle diameter 25 mm - Spindle working height 100 mm - Interchangeable spindle - Adjustable up/down - Original cast iron fence Gsdpfoy Ivknsx Alxoit - Table dimensions 1020x900 mm - Motor 3.8 kW

Condition: excellent (used), Year of construction: 2000, machine/vehicle number: AB /139622, functionality: fully functional, input frequency: 50 Hz, pivoting range: 56 °, rotational speed (max.): 10,000 rpm, rotational speed (min.): 3,300 rpm, Equipment: CE marking, rotational speed infinitely variable, We are offering this well-maintained SCM T 150 Class spindle moulder, year of manufacture 2000. Description: Spindle moulder with 3-axis control and 999 program memory slots (spindle height, fence, spindle tilt, revolutions) Spindle tilt -10° to +46° Inverter motor, adjustable spindle speed from 3,300 to 10,000 rpm Giedpfoy Ir Ezjx Alxot Table extensions at front and rear Swivelling fence Clearance between cutter and table is adjustable Very good condition, minor signs of use Including accessories: • 5 additional SK40 quick-change spindles • Curved fence • Power feeder with stand • Various hand tools If you have any questions or require further information, please feel free to send us a message or call us.

Condition: used, Year of construction: 1996, Incl. 3-roller feed, control panel on top, table extensions, pull-out support, tilting from -5° to +45°. Location: supplier Gedpfx Ajy Iddiolxeit

Condition: used, Year of construction: 1990, Design: rigid Table size: 1200x730 mm Table height: 900 mm Speeds: 3000/4500/6000/7000/10000 rpm Milling arbor diameter: 30 mm Spindle adjustment: manual Usable spindle length: 180 mm Spindle right/left rotation: Yes Speed display: optical Automatic motor brake: mechanical Foot brake Jaw stop type: wooden Stop adjustment: manual Power feed unit: with 3 rollers Control panel position: bottom Weight approx.: 600 kg Motor power: 4 kW Extraction diameter: 120/120 mm Storage location: Gsdpfx Alsy H Nhwsxeit

Condition: used, Year of construction: 2019, incl. 4-roller feed unit Felder Variofeed 4 (3–18 m/min), electronically controlled height and angle adjustment, spindle diameter 30 mm, Centrex access protection for spindle moulder, fence for max. cutter diameter 250 mm, continuously adjustable fine setting for the outfeed side (+35/-10 mm) with digital display, fully position-controlled, adjustable spindle fence with flip-up/down function, 550 mm anodised ALU fence rails with safety rulers, quick-clamping device for fence, 1270 mm pull-out frame with emergency stop, EURO cutter guard, 5.5 kW motor with variable speed control, speed range: 1,500–10,000 rpm, speed range high-speed spindle: 8,000–15,000 rpm, operator panel at eye level with x-motion control, table size: 1160 x 770 mm, table opening: 320 mm, swing-away device for feed on F 900 incl. feed extension. Location: Nattheim Gijdsy H Hf Tjpfx Alxot

Condition: used, Year of construction: 1997, Tilting spindle: Yes, -5 to 45° Height adjustment: electric Tilting adjustment: electric Table opening: electric Fence adjustment: manual Height display: digital Tilt angle display: digital Milling fence display: digital Spindle diameter: 30 mm Speeds: 3000, 4500, 6000, 9000 Power consumption: 5 / 6 kW Motor brake: Yes, automatic Extraction port: 2 x 120 mm Machine length: 2500 mm Godpfsy Hqd Hex Alxeit Machine width: 1400 mm Weight: 1100 kg

Condition: good (used), Year of construction: 1960, Make: Bäuerle, including integral fence and HolzHer power feed Model: SFM 2 Tilting range: 0 to 45° Brake Motor with 2 speeds/pole-changeable 6 speed settings: 1,800 - 4,500 - 5,600 - 6,000 - 9,000 - 12,000 rpm Forward/reverse rotation Table size: 1150 x 1200 mm Spindle diameter: 30 mm Milling fence Required space approx. 1200 x 1200 x 1300 mm Weight approx. 1000 kg Gsdpoy E T Ufsfx Alxeit Location: 54634 Bitburg, loaded free on truck, unpacked Delivery in current condition as inspected, function-tested without overhaul, without warranty or guarantee

Condition: good (used), Year of construction: 1966, Spindle moulder type 54F, year 1966, V-belt drive, reversible (left/right rotation), 4 spindle speeds, 30 mm spindle, 3 kW, transport dimensions 940 x 780 x 1200 mm, weight 480 kg. Transport available at extra cost! Gjdpfxoy E Nuhe Alxeit

Condition: used, functionality: fully functional, Gomad FD-2 Spindle Moulder Spindle diameter: 25 mm Spindle length: 140 mm Godpfjy E Nk Asx Alxsit Main motor, 2-speed, output 5.9/4.4 kW Interchangeable spindle Speed change via belt: 3000/4500/6000/9000 rpm

Condition: excellent (used), functionality: fully functional, input voltage: 380 V, input frequency: 50 Hz, spindle diameter: 30 mm, Equipment: CE marking, Spindle moulder with extended tables "SCM" model T130 LL Code: TOU-056 USED, IN EXCELLENT CONDITION – V380/50 – “CE” Spindle diameter: 30 mm Extended tables – total length 2560 mm FAST table Expandable fence for wide workpieces Motorized spindle group height adjustment INVERTER for speed adjustment up to 10,000 rpm Spindle rotation reversal Godpfxoy E I Dns Alxjit Motor power: 5.5 kW

Condition: good (used), Code: 0364 Brand: SAC Model: TS 110 - CE Standard Spindle moulder for milling and jointing operations on wood, plastics, composite materials, and various - CE Standard Technical specifications: Table dimensions mm 1100 x 900 Table height mm 860 Giodpfxey Erk Ss Alxjt Spindle diameter mm 40 Max applicable tool diameter mm 240 Spindle vertical stroke 2900-4500-6000-10000 rpm Motor power 5,5 Hp Overall dimensions mm 1100 x 900 x 1100 h Weight kg 780

Condition: used, Year of construction: 2013, machine/vehicle number: AB214206, functionality: fully functional, operating hours: 100 h, power: 7 kW (9.52 HP), input voltage: 400 V, input current: 9 A, input frequency: 50 Hz, type of input current: three-phase, spindle diameter: 30 mm, pivoting range: 90 °, rip fence adjustment: manual, actuation type: manual, rotational speed (max.): 10,000 rpm, rotational speed (min.): 3,000 rpm, table width: 810 mm, table length: 2,500 mm, total length: 2,500 mm, total width: 1,250 mm, overall weight: 640 kg, Equipment: CE marking, We offer this Casadei F25 swivel spindle milling machine, year of construction 2013, but uses only few weeks. Spindle tiltable -45 to 45° Height adjustment: Handwheel Tilt adjustment: Handwheel Height and angle display: mech. counter display Gedpfxey Drras Alxoit spindle diameter: 30 mm spindle speeds: 3000, 4500, 6000, 8000, 10000 rpm power input: 7 kW Suction connection: 1 x 120mm, 2 x 60mm Machine length: 2500mm Machine width: 1250mm Weight: 640kg If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: used, Used machine Equipment and technical data: - Vertical spindle travel: 150 mm - Spindle diameter: 30 mm - Spindle speeds: 3,500 - 7,000 rpm Gedjy Dkgpepfx Alxoit - With fixed spindle - Motor: 2.5–3.1 HP - Table: 830 x 700 mm - Slotting cutters up to 340 mm - With metal-jaw milling fence (Note: The Aigner parallel fence shown in the photos is not included in the scope of delivery!) - With 3-roller feed Weight: 240 kg Availability: short-term Location: Röllbach

Condition: good (used), Year of construction: 1968, Fully functional milling machine with integrated sliding carriage for tenoning. Description: - Sturdy cast machine body for low-vibration operation - Sliding carriage for cross feed - Height adjustment via handwheel - Fixed milling spindle - Connection option for extraction - Milling spindle tool holder / diameter 30 mm - Milling spindle tool holder / diameter 40 mm - The fence can be flexibly adjusted/rotated without changing the measurement. - Spindle speeds: 3000 and 6000; 4500 and 9000 rpm - Motor bearings replaced around 2003. Additionally: ELU feed unit type MVA 2+ with 2 speeds, forward and reverse. Transport dimensions approx. 1100 x 1100 x 1800 mm Giodpfx Aley Dctnjxst Technical data on request All information without guarantee!

Condition: used, used Cleaned, function tested, trial run, partially overhauled Brand: Bäuerle Model: SFM Motor 4, 5.5 HP Motor with 2 speeds/pole-changing 6 speed levels: 2800 / 4500 / 6000 / 5600 / 9000 / 12000 Foot brake Right-left rotation Spindle diameter: 30 + 40 mm Table size: 1100 x 900 mm Wooden fence jaws new Belt new Milling fence with fine adjustment Space requirement approx. 1000 x 900 x 1000 mm Godpjy Ay Awofx Alxoit Weight approx. 600 kg Storage location: 97447 Gerolzhofen, free loaded, unpacked Delivery as is as inspected, without guarantee or warranty.

Condition: excellent (used), Year of construction: 1996, Milling machine, table milling machine, milling unit Gedpfxjyz U Hzs Alxeit Manufacturer: Lazzari Model: Base 45 Year of manufacture: 1996 Tiltable Motor: 4 kW Speed: 3,000 - 10,000 rpm Left/right rotation
