Alexander Müller Feinblechverarbeitung

Condition: used, Year of construction: 1998, Max. bending length: 1020 mm Dcodpfx Aoyrrg Sjh Iod Max. sheet thickness: 1.5 mm steel Weight: approx. 300 kg

Condition: new, Year of construction: 2026, control type: manual, degree of automation: manual, actuation type: manual, working width: 1,020 mm, bending angle (max.): 135 °, sheet thickness (max.): 2 mm, Bernardo TB 1020 is a universal, manual segmented bending machine with a working length of 1020 mm, ideal for sheet metal work in repair and craft workshops. The machine features a robust construction and a foot-operated upper beam clamping system, allowing the operator to position the workpiece freely with both hands. Thanks to the exchangeable segmented upper beam, the machine precisely forms various profiles and boxes from sheet metal up to 2.5 mm thick. - Bending machine for universal use in repair and metalworking workshops - Compact, stable design with a modern look - Simple adjustment of the upper beam clamping via foot pedal; both hands remain free to accurately position the workpiece - Manual bender for standard tasks - Segments on the upper clamping beam expand bending possibilities - Offered at a competitive price - Fast and easy operation with a handle - Pedal covered with non-slip rubber sheath - Simple lower beam clamping adjustment to suit sheet thickness - High upper beam clamping force for tall bend profiles - Segment sizes: 2.5 / 3 / 3.5 / 4 / 4.5 / 5.0 / 7.5 / 10 / 15 / 20 / 27 cm Technical specifications: Working length: 1020 mm Max. sheet thickness (mild steel): 2.5 mm Max. opening: 48 mm Bending angle: 0 - 135° Dimensions (width): 1350 mm Dcodpfjyn Iiuex Ah Isd Dimensions (depth): 1115 mm Dimensions (height): 1140 mm Weight approx.: 290 kg

Condition: used, Year of construction: 2017, gebraucht 2017 8063 Dcjdpfsynnamox Ah Ied prompt, Zwischenverkauf v China 1710 € 1 1020 mm 1.5 mm 135 ° 1348 mm 850 mm 1175 mm 285 kg upper beam with sectioned rail booster cylinder user manual in GERMAN and ENGLISH

Condition: good (used), functionality: fully functional, working width: 1,040 mm, sheet thickness (max.): 4 mm, Counterweight in large protective housing Dodpfx Ahsynhuds Iscd

Condition: used, Manufacturer: TOS Model: XO 100/3A Year of manufacture: 1961 Machine number: 0211319 Working width: 1,030 mm Material thickness: 3 mm Material thickness (coil metal): 4 mm Stroke of upper beam: 150 mm Condition: good Dedpoyl Ihfsfx Ah Ijcd Footprint: 1,400 x 500 mm Weight: 0.8 t Dimensions: 1,800 x 500 x 1,100 mm

Condition: used, Technical details: Djdpfx Aoya Eq Hsh Ijcd sheet width: 2004 mm plate thickness: 2,5 mm distance between columns: 2040 mm Total power requirement: 3 kW bending angle max.: 180 ° Weight approx.: 1700 kg dimension machine xH: 2,7 x 1,3 x 2,0 m

Condition: new, sheet width 1270 mm plate thickness 2,0 mm distance between columns 1295 mm daylight opening 46 mm 135 ° total power requirement Handbetrieben weight of the machine ca. 0,4 t Djdox Dnfyopfx Ah Iecd dimensions of the machine ca. 1,6 x 0,8 x 1,2 m Segment bending machine, new. Segment widths: 25, 30, 35, 40, 45, 50, 75, 100, 150, 200, 250, 270 mm. Including material stop, max 660mm

Condition: like new (used), Year of construction: 2020, Metallkraft Sickenbiegemaschine SBM 140-12 E Dedpfx Ahjxqp R Rj Iecd Motor-driven bead forming machine with machine base, control console, and stop plate for producing various bead profiles and depths. Roller length: 140 mm Bending capacity steel 400 N/mm²: max. 1.2 mm* Rollers: Ø 62 mm Throat depth: 100 mm Roller speed: 8 m/min Motor power: 0.75 kW | 400 V - 50 Hz Protection class: IP 55 Dimensions (LxWxH): 900 x 1350 x 450 mm Weight (net): approx. 110 kg Includes standard rollers S1-S8 and tool key Demonstration machine, used once

Condition: new, sheet width 1050 mm plate thickness 1.0 mm daylight opening 95.0 mm angle adjustable from - to 0 - 150 Grad total power requirement manuell Dcedpfx Ahjxcuxws Isd weight of the machine ca. 180 kg range L-W-H 1320 x 790 x 1050 mm characteristics - Universally applicable bending machines for plumbing and repair shops - Simple pivoting movement of the bending beam using a bow handle - Easy adjustment of the upper beam for efficient work - High upper beam for producing high-edged profiles - The piano inserts in the upper, lower and bending beam result in a large number of bending options - Cassettes and special profiles with opposite bends are with these Models easily feasible Scope of delivery : - Segmented upper, lower and bending beam - bending segments 25 | 30 | 35 | 40 | 45 | 50 | 75 | 100 | 150 | 2 x 250 mm

Condition: new, sheet width 1250 mm thickness at "Niro-steel" 0.80 mm VA plate width at 30 kg/mm 2.00 mm ALU plate thickness 1.25 mm ST daylight opening 100 mm bending angle max. 135 ° height OW 100 mm total power requirement manuell weight of the machine ca. 350 kg. dimensions of the machine ca. 1715 x 750 x 1400 mm Equipment: - robust, manual swivel bending machine - divided upper work - lower and rear tool * Height of upper tool = 100 mm * Division 100/100/100/100/100/100/100/100/100/70/60/50/40/30/100 * left + right with horn tool - upper tool with quick-change system - quick foot clamp - angle stop - lockable Dodpfxjxabmpo Ah Ijcd - manual rear stop 500 mm - machine is movable (rollers) - accessories box - rear

Condition: new, sheet width 1050 mm plate thickness 1.50 mm daylight opening 100 mm bending angle max. 135 ° height OW 100 mm total power requirement manuell weight of the machine ca. 330 kg. dimensions of the machine ca. 1600 x 900 x 1450 mm Equipment: - robust, manual swivel bending machine - divided upper tool - lower and rear tool Dcedpoxaa T Ujfx Ah Isd * Height of upper tool = 100 mm * Division 100/100/100/100/100/100/100/70/60/50/40/30/100 * left + right with horn tool - upper tool with quick-change system - quick foot clamp - angle stop - lockable - manual rear stop 500 mm - machine can be moved (rollers) - accessories box - rear * Pictures show identical machine (UFA 1212)

Condition: new, sheet width 1020 mm plate thickness 2.5 mm daylight opening 48.0 mm daylight opening 150 mm ohne Segmente bending angle max. 0 - 135 ° work height max. 900 mm weight of the machine ca. 340 kg dimensions of the machine ca. 1350 x 820 x 1300 mm Furnishing: - Swivel bending machines with segm. Upper, lower and bending beam - Universally usable bending machine for sheet metal works and repair shops Dcedoxaa E Depfx Ah Iod - Robust construction in a modern design - Easy adjustment of the upper beam using a foot pedal - Hands are free for the workpiece - Manual bending machine for standard bending tasks - Segmented upper beam for a large number of bending possibilities - Optimum price-performance ratio - Quick and easy bending process using the bow handle - Non-slip rubber covering on the foot pedal for safe working - Easy adjustment of the lower beam to the respective sheet thickness - High upper beam for the production of high folded profiles Scope of delivery : - Segmented upper, lower and bending beam - manual backgauge - Corner segment left / right each 75 mm | 25 | 30 | 35 | 40 | 45 | 50 | 75 | 100 |200 | 270 mm

Condition: new, sheet width 1020 mm plate thickness 2,5 mm daylight opening 48 mm bending angle max. 0 - 135 ° total power requirement von Hand kW weight of the machine ca. 285 kg dimensions of the machine ca. 1,35 x 0,82 x 1,14 m Djdpfxoxaaxks Ah Iecd Furnishing: - Universally applicable bending machine for plumbing and repair shops - Robust construction in a modern design - Easy adjustment of the upper beam using a foot pedal - Hands are free for the workpiece - Manual bending machine for standard bending tasks - Segmented upper beam for a large number of bending options - Optimal price-performance ratio - Quick and easy bending process using a bow handle - Non-slip rubber coating on the foot pedal for safe working - Easy adjustment of the lower beam to the respective sheet thickness - High upper beam for producing high-edged profiles scope of delivery - Segmented upper cheek - manual backgauge - bending segments 25 | 30 | 35 | 40 | 45 | 50 | 75 | 100 | 150 | 200 | 270 mm

Condition: new, sheet width 1020 mm plate thickness 2,0 mm daylight opening 48 mm bending angle max. 0 - 135 ° work height max. 900 mm total power requirement von Hand kW weight of the machine ca. 285 kg dimensions of the machine ca. 1350 x 820 x 1140 mm Furnishing: - Segmented upper and bending beam for a wide variety of bending options - Clamping by means of a foot pedal - Hands remain free for optimal positioning of the sheet - Universally applicable bending machine for plumbing and repair shops - Robust construction in a modern design Dedpfsxaaufex Ah Iecd - Manual bending machine for standard bending tasks - Segmented upper beam for a large number of bending options - Optimal price-performance ratio - Quick and easy bending process using a bow handle - Non-slip rubber coating on the foot pedal for safe working - Easy adjustment of the lower beam to the respective sheet thickness - High upper beam for producing high-edged profiles Scope of delivery : - Segmented upper cheek - Segmented lower cheek - manual backgauge - bending segments 25 | 30 | 35 | 40 | 45 | 50 | 75 | 100 | 150 | 200 | 270 mm

Condition: new, functionality: fully functional, Year of construction: 2025, working width: 600 mm, Series: GB-E Bending pressure: 130KN Dsdpfewzqn Uox Ah Ijcd Bending length: 600(mm)

Condition: used, Technical details: plate thickness: 1 mm distance between columns: 2,255 mm bending angle max.: 130 ° total power requirement: 2,25 kW Djdewq I U Rspfx Ah Iscd Weight approx.: 1400 kg dimension machine xH: 2,7 x 1,15 x 1,3 m Machine without foot switch but this is pre-equipped the upper beam was converted to 60 mm adjustment by the previous owner higher is only possible when dismantling for automatic operation the foot control is missing manual operation O.K. No backgauge *

Condition: used, Max. bending length: 1020 mm Dcjdpfxswlp Tqj Ah Ied Max. sheet thickness: 2 mm steel Weight: about 500 kg

Condition: new, Year of construction: 2025, neu 2025 080093 prompt, Zwischenverkauf v Türkei Dcsdpfewiqwrox Ah Ijd 5530 € 106.73 € 1 1050 mm 1.5 mm 1 mm 2.2 mm 150 ° 500 mm 200 mm 1300 mm 750 mm 1515 mm 280 kg Verstellbereich 35 mm Sectioned upper- lower- and bending tool, material 42CrMo4, hardened to 60HRC Manual back gauge Adjustable angle gauge Shelve and box for tools Machine on rolls with brakes Operating manual in German or English

Condition: used, sheet width 1020 mm plate thickness 2,5 mm bending angle max. 135 ° stroke of upper beam 25 mm Dcsdpfxowcg D Ie Ah Isd weight of the machine ca. 285 kg dimensions of the machine ca. 1,35 x 0,85 x 1,20 m PRICE: 2.045,-- EUR - with an oblique segmented upper cheek - distribution segment: 25-30-35-40-45-50-75-100-150-200-270 - done with the foot brake application

Condition: used, Year of construction: 1982, machine/vehicle number: 005-5216, Lg.No. 24586 Technical data: - max. working width 1030 mm - max. material thickness 3 mm Dcodpfx Ahov Hc A No Ijd - bending angle approx. 0 - 135 ° - lockable with end stop - upper beam is operated with a hand crank on the side - max. upper beam stroke 120 mm - max. bending beam adjustment 45 mm - bending process is supported by eccentric weight - space requirement approx. W 1750 x H 1120 x D 450 mm - weight approx. 620 kg

Condition: used, Technical details: plate width: 1000 mm plate thickness: 1 mm distance between columns: 1220 mm knife length: 1030 mm stroke adjustment: Oberwange: 100 mm stroke adjustment: Biegewanne: 45 mm bending angle max.: 140 ° weight of the machine ca.: 0,65 t dimension machine xH: 1,8 x 0,6 x 1,1 m Dcedpfx Ahsu Ibz Ro Iod - This swivel bending machine is equipped with two rear supports. Size of the round steel support = Ø 25 x 750mm, with linear scale. - Left side with counterweight. *

Condition: used, Year of construction: 1982, Technical details: sheet width: 1500 mm plate thickness: 1,5 mm distance between columns: 1760 mm knife length: 152 mm bending angle max.: 160 ° total power requirement: 1,3 kW Weight approx.: ca. 800 kg dimension machine xH: 2,5x0,7x1,5 m - adjustment of the upper cheek 350mm - adjustment of the bending cheek / lower cheek 60/60 motoric - bending edge up to max. 10mm radius Dsdpfx Aju Ibzwjh Iocd - without back gauge - upgrade possible -manual counter - foot pedal (pedal left/right) accessories: - 1 set tools *

Condition: new, sheet width 1020 mm plate thickness 2,5 mm distance between columns 1050 mm daylight opening mm Dsdpeupxf Ujfx Ah Iocd 135 ° total power requirement Handbetrieben kW weight of the machine ca. 0,32 t dimensions of the machine ca. 1,4 x 0,6 x 1,3 m Segment-bending machine Segment widths: 25, 30, 35, 40, 45, 50, 75, 100, 150, 250 and 260mm.

Condition: new, sheet width 915 mm plate thickness 1,0 mm distance between columns 920 mm 135 ° total power requirement Handbetrieben weight of the machine ca. 96 Kg dimensions of the machine ca. 1170 x 400 x 480 m Segment-bending machine Segment widths: 25, 30, 35, 40, 45, 50, 75, 100, 150, 250 and 260mm. Dcedsupxf Iopfx Ah Iod

Condition: used, Folding bench 1m Schroeder Well maintained condition Sheet thickness steel 2mm Bending length slightly over 1m Dodpfx Ajukb U Ush Iocd Further devices available like Schechtl, Cidan etc in 1 - 1,5 and 2m Suitable guillotine shears from 2mm electric or 1.75 hand also available please ask if interested
