Condition: ready for operation (used), Year of construction: 2017, machine/vehicle number: 17.650.001, functionality: fully functional, pressing force: 250 t, stroke length: 400 mm, throat depth: 250 mm, working width: 3,100 mm, TECHNICAL DETAILS Pressing force: 250 t Max. working width: 3,100 mm Frame spacing: 3,200 mm Overhang: 250 mm Rear gauge depth: 750 mm Max. stroke: 400 mm MACHINE DETAILS Control system: CNC Power: 34 kW Dimensions & Weight Dimensions (L x W x H): 4,850 x 2,390 x 3,340 mm Weight: 20,500 kg Transport packages: 3 pcs. EQUIPMENT Tools Documentation CE marking Bsdszxdtcspfx Afwedg CE certificate

Condition: ready for operation (used), Year of construction: 2007, operating hours: 16,159 h, pressing force: 229 t, total width: 2,788 mm, total height: 3,310 mm, overall weight: 21,800 kg, product length (max.): 5,475 mm, Press brake manufactured in 2007. This Bystronic Hammerle 225 3P 4100 features a pressing force of 2250 kN and a bending length of 4100 mm. The machine includes hydraulic die and punch clamping systems, ensuring efficient operation. If you are looking to get high-quality bending capabilities, consider the Bystronic Hammerle 225 3P 4100 machine we have for sale. Contact us for further details regarding this machine. • Note: Nameplate shows 3100 mm, but seller confirms 225/410 configuration (4100 mm) • Machine structure: • Distance between uprights: 4200 mm • Throat depth: 250 mm • Standard installation height: 917 mm Bdedpfx Aszwm D Ijfweg • Standard stroke: 400 mm • Ram thickness: 80 mm • Below-floor installation: No • Table: • Working height with WZ 86 mm tooling: 1056 mm • Table width: 93 / 108 mm • Table height: 130 mm • Lower beam thickness: 160 mm • Movements: • Max approach speed: 150 mm/s • Max working speed: 10 mm/s • Max return speed: 150 mm/s • Y-axis tolerance: ±5 µm • Clamping system: Hydraulic die clamping (standard), Hydraulic punch clamping (standard) • Electrical / Utilities: • Connected load: 40 kW • Operating voltage: 400 / 480 V AC • Frequency: 50 / 60 Hz • Rated slow-blow pre-fuse: 80 A • Hydraulic oil: 600 l • Compressed air: 0.6 MPa • Condition: Machine operational Additional equipment • Bending aids: • Right bending aid (operational) • Left bending aid (installed, not operational) • Tooling package (Hämmerle): • Straight upper tooling, code 001-005: approx. 5,410 mm total • Gooseneck upper tooling, code 014-005: approx. 2,905 mm total • Bottom die set, code 007.20-02: approx. 4,735 mm total • Bottom die set, code 013.00-03: approx. 4,825 mm total • Bottom die set, code 016.10-01: approx. 3,225 mm total • Tooling suitable for various bending applications and material thicknesses Technical Specification Bending Length 4100 mm

Condition: used, Year of construction: 2007, For sale: Bystronic Beyeler P225/410 hydraulic press brake, manufactured in 2007 in Germany. This high-quality CNC press brake offers a 225-ton pressing force and a 4,100 mm bending length, making it ideal for precision sheet metal fabrication in steel, stainless steel, and aluminum. The machine is renowned for its robust construction, reliability, and accuracy, making it suitable for both small batch production and high-volume manufacturing environments. Technical Specifications General Information - Manufacturer: Bystronic Beyeler - Model: P225/410 - Year of Manufacture: 2007 - Country of Origin: Germany - CE Marked: Yes Capacity - Press Force: 225 tons (2,250 kN) - Maximum Bending Length: 4,100 mm - Stroke: 400 mm - Throat Depth: 250 mm - Daylight Opening / Installation Height: 917 mm Speed - Fast Approach Speed: 150 mm/s - Working Speed: 1 - 10 mm/s - Return Speed: 150 mm/s Dimensions & Weight - Overall Length: 5,475 mm - Overall Width: 2,257 mm - Overall Height: 3,310 mm Bodjzwg Imepfx Afwodg - Machine Weight: 20,500 kg Electrical Specifications - Main Motor Power: 30 kW - Connected Load: 40 kW - Power Supply: 380 V, 3 Phase - Frequency: 50 Hz - Control Voltage: 24 V DC Hydraulic System - Maximum Hydraulic Pressure: 315 bar - Hydraulic Oil Capacity: 600 liters - Maximum Oil Temperature: 65°C Pneumatic System - Minimum Air Pressure: 6 bar - Operating Air Pressure: 6 bar Tooling - Maximum Upper Tool Weight: 400 kg - Maximum Workpiece/Tool Weight: 13 kg Please Note: The information was obtained to the best of our abilities and - where possible - from the manufacturers. It is given in good faith, however, its accuracy cannot be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. Specific tooling must be requested before purchasing because in most cases the offered machines are still in production when the pictures were taken. We advise you to check any vital details! * Manufacturer: Bystronic Beyeler * Model: P225/410 * Year of Manufacture: 2007 * Press Force: 225 tons (2,250 kN) * Maximum Bending Length: 4,100 mm * Working Speed: 1 - 10 mm/s * Machine Weight: 20,500 kg * Stroke: 400 mm * Throat Depth: 250 mm Working hours: 16159

Condition: used, Year of construction: 2002, Hydraulic Guillotine Shear HACO TS 3006 Capacity: 3100 x 6,5 mm Back gear gauge travel: 1000 mm Year of construction: 2002 Motor power: 7,5 kW SP8 Command Bdodpfx Ajzwclujfwog Blades with 4 cutting edges Voltage: 380 V Photocells at the back Length: 4000 mm Depth with photocells : 2800 mm Depth without photocells: 2200 mm Height: 1900 mm Weight: approx 5 T

Condition: used, Hydraulic Press Brake SAGITA BEYELER 200/4000 Slide travel: 150 mm Throat depth: 300 mm Distance between uprights: 3100 mm Motor power: 15 kW Manual Back gear gauge The machine was only used for pre-bending of Hardox sheet Voltage: 380 V Dimensions (L x W x H): 4100 x 1800 x 2700 mm Weight: approx 15 T Bdedpfxozwclne Afweg

Condition: good (used), Year of construction: 2010, functionality: fully functional, bending force (max.): 230 t, number of axes: 5, Equipment: CE marking, documentation/manual, safety light barrier, Bending length [mm] 3230 Press force [tons] 230 Control system TRUMPF TASC 6000 Standard equipment: Machine - Robust machine frame as a welded construction in all-steel design - Press beam with high bending strength - Spherical bearing of the press beam with press beam inclination - Proportional valve technology and switchable double pump - Modern block hydraulics with control valves mounted on the cylinder - Electronic pressure gauge - Measuring system with centrally mounted glass scales and temperature compensation - Oil cooler - Control cabinet cooling - Modern machine design Back gauge system - Rear back gauge system, 2-axis, with rack and pinion drive for X and R axis - 2 back gauge fingers with secure adjustment from the front Tool clamping - Upper tool clamping system "New Standard Clamping", manual, hardened, self-centering; for vertical tool change - Lower tool holder with hydraulic clamping, hardened Lower tool movement - Lower tool movement programmable (pneumatic, 2 positions) Bedpfx Aezv Sbiefwodg Control - Machine control: TRUMPF TASC 6000, graphical - Workshop programming - Windows XPe, Pentium 4 with 2.8 GHz clock frequency - 2 GB RAM - 15" touch screen - Network-enabled - Teleservice via analog telephone connection Operation - Control panel with LCD keypad, foot switch for up, down and emergency stop - Communication bus for the use of ACB angle sensor tools Safety - Safety device: integrated side doors + Rear back gauge system, 5-axis (X, X1, R, Z1, Z2) + Upper tool clamping, hydraulic + CNC crowning + BendGuard + Additional foot switch + 2 support consoles + 1 MobileControl + ACB prepared

Condition: ready for operation (used), Year of construction: 2011, pressing force: 224 t, stroke length: 350 mm, overall weight: 18,000 kg, This AMADA HFP NT 220-4L press was manufactured in 2011. It features a maximum press force of 2200 kN and a stroke up to 350 mm, weighing 18000 kg. A robust choice for heavy-duty operations, the AMADA HFP NT 220-4L machine we have for sale is ideal for your pressing needs. Contact us for more information. Bdedpfxezvvxlj Afwjg Machine Benefits Qualitative Machine Benefits • Stability and robustness ensured by the heavy machine weight. • Reliable construction for long-term performance. Technical Machine Benefits • Power supply: number of phases: 3 • Versatile stroke to accommodate various bending requirements. Technical Specification Bending Length 4000 mm

Condition: good (used), Year of construction: 2019, pressure 220 t chamfer lenght 4100 mm distance between columns 3150 mm stroke of upper beam 400 mm dayligth 570 mm working feed 21.0 mm/sec return speed 200.0 mm/sec work height max. 970 mm Control LVD Touch-B CNC 18" total power requirement 37.0 kW weight 27500 kg range L-W-H 5100 x 1950 x 2850 mm well-maintained condition (!!) Special price on request Equipment: - CNC electro-hydraulic press brakes * Intuitive, touchscreen-based user interface * Simple navigation * Tool and program library * X-axis control and position display * Y-axis control and position display * Swiveling control panel (front left) - CNC-controlled - CNC electric backgauge (X-axis) * CNC electric gauge fingers (R-axis) * Includes height adjustment (R-axis) * Intelligent tool storage (automatic tool changing) * Bending aid - LVD upper tool holder * Hydraulic upper tool clamping - LVD lower tool holder * Hydraulic die clamping - Side safety guards (swiveling doors) - Rear safety guard (swiveling door) - 1x movable foot pedal - Machine documentation Bjdpfx Afezu A Rxswjdg ToolCell is a fully equipped hydraulic press brake with an integrated automatic tool changer. It is the ultimate bending solution for small to medium-sized batches, high product variety, and increased workpiece complexity.

Condition: good (used), Year of construction: 1996, machine/vehicle number: 090171, Offer 26222 Technical data: - Pressing force: 200 t - Working width: 4100 mm - Distance between uprights: 3050 mm - Table width: 220 mm - Overhang: 500 mm - Installation height: 550 mm - Approach speed: 80 mm/s - Working speed: 0 to 7 mm/s - Retraction speed: 70 mm/s - Stroke: 300 mm - Pneumatic connection - Drive: 400 V / 18 kW - Space requirement: approx. W 4800 x H 3150 x D 2200 mm - Weight: approx. 17000 kg - Includes: - Swivel arm – Control panel with DELEM DA 65 control, year of manufacture 2009 - Safety light curtain Bdsdpfx Aozuziasfweg - Motorized back gauge - Punch and universal die - Two-hand control panel with foot pedal

Condition: ready for operation (used), Year of construction: 2000, machine/vehicle number: 331.00465, functionality: fully functional, power: 2.2 kW (2.99 HP), input voltage: 380 V, input frequency: 50 Hz, pressing force: 16 t, stroke length: 100 mm, operating speed: 90 mm/s, overall weight: 950 kg, Model:PE6-16 Bdodpfx Afszux Ruswog Pressure/Tonnage: 16 Tons Distance Over Bed: 600mm Full Length Top and Bottom Tooling Guarding Control: CNC 402

Condition: repair required (used), Year of construction: 2019, pressing force: 220 t, overall weight: 12,620 kg, controller model: Delem DA-66T, working width: 3,050 mm, number of axes: 6, The press brake cannot be aligned because the X and R axes are blocked. This is a machine that is to be repaired or is intended for a project. TECHNICAL DETAILS Number of axes: 6 Axes: Y1 + Y2 + X + R + Z1 + Z2 Press force: 220 t Max. working width: 3,050 mm Frame spacing: 2,500 mm Bdsdpfx Afozuw Ewewog Crowning system: CNC-controlled Ram holder: hydraulic Tool holder type: WILA standard MACHINE DETAILS Drive: CNC Control: Delem DA-66T Power: 22 kW Dimensions & Weight Dimensions (L x W x H): 3,750 x 1,900 x 2,900 mm Weight: 12,620 kg Transport packages: 1 EQUIPMENT Tools

Condition: good (used), Year of construction: 2011, total length: 5,100 mm, total width: 2,200 mm, total height: 3,400 mm, overall weight: 19,700 kg, Press force: 230 t Bending length: 4050 mm Distance between uprights: 3550 mm Upright overhang: 420 mm Oil capacity: 400 l Control system: ModEva 10S Machine weight (approx.): 19700 kg Dimensions: 5100 x 2160 x 3420 mm Equipment/Accessories: - Automatic tool clamping, pneumatic Bodeztafqjpfx Afwodg - Motorized crowning - Akas-Fiessler safety laser - Bending aid 1 + 2 (right and left) - Die shifting m1 and m2 - Axis-controlled: Y1, Y2, Xs, Xm, X delta, R, Z1, Z2

Condition: used, Year of construction: 1987, pressure 100 t Working width max. 300 mm Bdjdozr Rq Uopfx Afwsg serial number 55505 voltage 380 V weight 5000 kg

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, operating hours: 50,000 h, Equipment: CE marking, documentation/manual, Trumpf TruBend V200 bending cell + BendMaster 60 Year of manufacture: 2004 Maximum pressing force: 2000 kN Maximum stroke: 365 mm Maximum operating pressure: 340 bar 1 unit B0401A0009 = BendMaster 60 Bdsdpfx Aezrxfasfwjg 1 unit B0106A0073 = TRB V200-6A 1 unit protective enclosure including lighting 1 unit BendMaster track, 14 meters in 2-meter segments 1 unit Trumpf system control

Condition: good (used), Year of construction: 1994, machine/vehicle number: 94 2055, Offer 26226 Technical data: - Pressing force 220 t - Working width 3050 mm - Clearance between the uprights 2550 mm - Table height 950 mm - Overhang 450 mm Bdsdpfszrtyfex Afwog - Installation height 550 mm - Drive 400 V / 18.5 kW - Ground clearance - Space required approx. B 3500 x H 2950 x D 2000 mm - Machine weight approx. 17500 kg - Two-hand control panel with foot switch - Rear stop adjustable from the front via handwheel - Various bending tools

Condition: used, Year of construction: 2008, functionality: fully functional, power: 15 kW (20.39 HP), input voltage: 380 V, input current: 35 A, input frequency: 50 Hz, type of input current: three-phase, pressing force: 160 t, total length: 3,400 mm, total width: 2,180 mm, total height: 2,780 mm, year of last overhaul: 2023, Equipment: CE marking, documentation/manual, safety light barrier, We are offering this used Ermak AP3100-160 press brake, manufactured in 2008, for sale. Power type: 3 AC Frequency: 50 Hz Operating voltage: 380 V Control voltage: 24 V Rated current: 35 A Rated current of the main fuse: 50 A Electrical wiring diagram no.: SN20080089 The machine is fully functional, and the last safety inspection was carried out in 2023. The machine is equipped with a press brake safety device (light curtain), which was also last inspected in 2023. Total weight of the machine: 9 tons Various tools (see photos) as well as the operating manual and safety inspection history are included in the scope of delivery. Bdsdpfezqav Dsx Afweg If you have any questions or require further information, please feel free to send us a message or call us.

Condition: refurbished (used), Year of construction: 1998, overall weight: 33,000 kg, working width: 4,300 mm, HACO hydraulic press brake, Pressmaster 43230 model 4.3 m x 230 tons Retrofit with new Easybend 2DT touch-screen CNC control Bsdpfxjzqabas Afwjdg X-axis back gauge with ball screw Manual crowning table 2 adjustable front supports Machine designed for standard European tooling

Condition: good (used), functionality: fully functional, Capacity 160 tons --- Bending length 1250 mm --- Bodpfx Afezp Uxdewodg Stroke 250 mm --- Thrust 500 mm --- Max. installation height 480 mm --- Weight approx. 11.2 tons --- Power 30 kW --- System tool holder + tools

Condition: ready for operation (used), Year of construction: 2003, pressing force: 204 t, stroke length: 185 mm, total width: 2,400 mm, total height: 2,850 mm, overall weight: 14,050 kg, product length (max.): 5,050 mm, Press brake manufactured in 2003. This Durma HAP 40200 features a press force of 200 tons and a bending length of 4050 mm. It operates at a stroke rate of 6 strokes per minute, with a stroke length of 185 mm. If you are looking to get high-quality bending capabilities, consider the Durma HAP 40200 machine we have for sale. Contact us for further details. Bdsdpfjzpbauex Afwjg • Control system: Durma ENC 310 • Strokes per minute: 6/min • Maximum pressure: 295 kg/cm² (4278 psi) • Oil tank capacity: 150 L • Upper tool weight: 173 kg • Lower tool weight: 312 kg Technical Specification Bending Length 4050 mm

Condition: refurbished (used), Year of construction: 2002, machine/vehicle number: 28668, functionality: fully functional, power: 27 kW (36.71 HP), input voltage: 400 V, input frequency: 50 Hz, type of input current: three-phase, pressing force: 220 t, operating speed: 12 mm/s, table length: 4,000 mm, year of last overhaul: 2025, Equipment: CE marking, safety light barrier, Control:Touch-B Axes:Y,X,R,Z1,Z2,XZ,W and EFL Clamping:wila hydraulic clamping Machine weight: approx. 21000 kg Type: PPEB 220/40 EFL Serial number: 28668 Without tools New R axe spindles Bodezn Arpspfx Afwodg New belts : Z axes and tilting Machine front side repainted. New venillators inside the heat exchanger. Wila clamping system checked and realigned,two middle segment changed to new ones.

Condition: excellent (used), Year of construction: 2002, Technical specifications: Retrofit in 2026 Working length: 4100 mm Distance between uprights: 3700 mm Press force: 220 tons CNC control: CD2000 (new) Color screen size: 14" Controlled axes: Y1/Y2; X; R Motorized adjustable back gauge Bsdpfxeznl U To Afwjdg Overhang: 300 mm Stroke: 200 mm Automatic crowning Motor power: 20 kW Dimensions (length x width x height): approx. 4800 x 2300 x 2900 mm Weight: approx. 17.5 tons Accessories: Segmented AMADA tools, new Lateral safety devices Condition: The machine is in very good overall condition Only approx. 7,500 operating hours The seller is not liable for typing or data transmission errors. The machine's appearance, technology, and wear correspond to its age; used machines are sold without any warranty.

Condition: good (used), Year of construction: 2008, pressure 200 t chamfer lenght 4100 mm distance between columns 3150 mm stroke of upper beam 200 mm dayligth 425 mm throat 300 mm working feed 9.0 mm/sec return speed 90.0 mm/sec work height max. 980 mm back stop - adjustable ca. 700 mm Control PPS-TS Touch oil volume 350 l total power requirement 18.0 kW weight 12.000 kg range L-W-H 5100 x 1950 x 2850 mm Well-maintained condition (!!) Current new price approx. € 110.000 Special price on request - in checked conditions - machinevideo - ?v=ZX9Ap23e__s Equipment: - CNC electro-hydraulic press brakes - with LVD CNC "PPS-TS TOUCH" control unit * intuitive, touchscreen-based user interface * simple navigation * tool and program library * X-axis control and position display * Y-axis control and position display * swivel-mounted control panel (front left) - CNC-controlled axes: Y1/Y2 + X - CNC motorized backgauge (X-axis) * with 4 manually adjustable gauge fingers * includes lateral and height adjustment (Z and R axes) Bdodpozndq Hefx Afwjg - LVD upper tool holder * sectionalized goose-neck upper tool - LVD lower tool holder * sectionalized 1V die - 2x front support arms - side safety guards (swiveling doors) - rear safety guard (swiveling door) - 1x movable foot pedal - machine documentation (NL)

Condition: used, Year of construction: 2005, machine/vehicle number: 05/460/013, functionality: fully functional, input voltage: 400 V, input current: 80 A, input frequency: 50 Hz, stroke length: 265 mm, operating speed: 200 mm/s, overall weight: 18,000 kg, Equipment: CE marking, For sale: Betzeler 3200 KN x 3100 MM machine – Hydraulic bending press Manufacturer: Beyeler GmbH, Mühlhäuser Strasse 3, D-99867 Gotha Machine type: PR 3200 kN x 3100 mm Serial number: 05/460/013 Year of manufacture: 2005 Machine weight: 18,000 kg Electrical data Voltage: 400 V Power: 30 kW Frequency: 50 Hz Phases: 3∼ Max. fuse rating: 80 AT Hydraulic/pneumatic data Max. air pressure: 8 bar Technical data (press brake) Bjdpfozm S Ttex Afwsdg Force: 3200 kN Max. stroke: 265 mm Max. closing speed: 200 mm/s Pressing speed: 1–10 mm/s Max. O.A. response time: 90 ms Min. ESPE safety distance: 290 mm

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, power: 26 kW (35.35 HP), pressing force: 230 t, stroke length: 470 mm, throat depth: 400 mm, clearance between the columns: 2,550 mm, total width: 3,750 mm, total height: 3,750 mm, overall weight: 16,200 kg, Equipment: CE marking, Hydraulic press brake Manufacturer: DARLEY, Type: EHP-LS 230.31/25 Year of manufacture: 2003 Technical data Manufacturer: DARLEY Type: EHP-LS 230.31/25 Year of manufacture: 2003 Capacity: 230 t Usable length: 3,100 mm Distance between uprights: 2,550 mm Stroke: 470 mm Installation height: 700 mm Upright overhang: 400 mm Motor power: 26 kW Oil tank capacity: 200 liters Weight: 16.3 t Dimensions: Width 3,750 mm x Depth 2,700 mm x Height 3,550 mm (plus 200 mm for the control arm) Equipment Bdedpfxezmi Hqs Afweg • Control system: Delem DA-66W • Automatic Wila/Trumpf tool clamping system + tool holders (top and bottom) • Controlled axes: Y1, Y2, X1, X2, R1, R2, Z1, Z2 • CNC-controlled crowning • Lazersafe safety light curtain (front) • Rear safety guard via door/grille • 2 adjustable support arms • • Tool set: Top tool: straight, H 158 mm, R3, 28°, 100 t/m, 3000 mm, segmented Top tool: slightly bent, H220 mm, R1, 86°, 2000 mm, segmented All information is subject to change without notice. A demonstration is possible at any time in our showroom.

Condition: ready for operation (used), Year of construction: 2017, machine/vehicle number: 17650001, functionality: fully functional, power: 34 kW (46.23 HP), pressing force: 250 t, stroke length: 400 mm, throat depth: 250 mm, working width: 3,100 mm, TECHNICAL DETAILS Number of axes: 8 Press force: 250 t Max. working width: 3,100 mm Frame spacing: 3,200 mm Overhang: 250 mm Rear gauge depth: 750 mm Max. stroke: 400 mm MACHINE DETAILS Control system: Bystronic ByVision Power: 34.0 kW Dimensions & Weight Dimensions (L x W x H): 4,850 x 2,390 x 3,340 mm Weight: 20,500 kg Bdodpfx Ajzk Dv Iefwsg Transport packages: 3 EQUIPMENT Crowning system: CNC-controlled Ram holder: Hydraulic Tool holder type: WILA standard Tools included Documentation CE marking and certificate Additional finger stop Stroke assistance Finger protection Offline software
