Condition: like new (used), Year of construction: 2021, functionality: fully functional, machine/vehicle number: 21.C.350.314, Centreless Cylindrical Grinding Machine Tschudin Cube 350 ! The machine is in like-new condition and has only been used occasionally. It is fully operational, currently connected to power, and can be demonstrated on site. Sale is due to business reasons only! ● Year of manufacture: 2021 ● Machine no.: 21.C.350.314 ● Condition: Not inspected ● Delivery terms: Free loaded on truck ● Location: 79353 Bahlingen a.K. ● Availability: By arrangement ● Payment terms: Advance payment by bank transfer ● Internal reference no.: MÄ1 ● Under power for inspection: YES Technical Data: ● Control: Fanuc 0i ● Through-feed grinding range Ø: 0.1–20 mm ● Plunge grinding range Ø: 0.1–20 mm ● Grinding wheel width / plunge grinding length: 180 mm (optional 205) ● Grinding wheel diameter: 350 mm ● Grinding wheel bore: 203.2 mm ● Regulating wheel diameter: 275 mm ● Regulating wheel bore: 175 mm ● Grinding spindle drive power: 7.5 / 12 kW ● Grinding spindle peripheral speed (constant-V): max. 63 m/s ● Regulating wheel speed (stepless): 5–1000 rpm ● Resolution: 0.1 µm Equipment: ● Dressing spindle without counter bearing: - Tool holder: up to 10 mm width - Clamping diameter: ID 40 mm h2 - Power: 2.14 kW - Speed: max. 6000 rpm ● External cooling for grinding and regulating spindle ● W-axis ● Balancing unit type ● Needle nozzles ● Diamond dresser for grinding wheel ● Diamond dresser for regulating wheel ● Diamond dressing wheel ● Blowing device ● W-axis safety light curtain ● LED lighting lamp ● Cooling and filtration system ● Paper band filter Knoll Scope of delivery: ● Available manuals Dimensions & Weights: ● Installation size L x W x H approx.: 2558 x 1735 x 1320 mm ● Weight approx.: 4000 kg For any questions or to arrange a viewing, please feel free to contact us! Additional information: ►Transport to the destination can be offered upon request Cpjdpfoyrpx Sex Ah Isw ►The offer price is net plus VAT ►The goods are sold under exclusion of any warranty ►Technical data subject to change and not guaranteed ►Subject to prior sale ❗Sale of goods is strictly to businesses only❗

Condition: excellent (used), Control SIEMENS 840D Cpsdpfxeyrhl Re Ah Isw

Condition: used, Year of construction: 1970, Technical details: grinding diameter max.: 400 mm Codpfjypm Ifjx Ah Ijpw max. width of grinding wheel: 180 mm grinding range: 2-100 mm total power requirement: 24 kW weight of the machine ca.: 3,2 t Out of valve production *

Condition: used, TSCHUDIN GL 600 is a CNC centerless grinding machine designed for precision, high accuracy and reliable operation. Working capacities: grinding diameter 2–100 mm; grinding wheel Ø600 mm × 350 mm; regulating wheel Ø350 mm × 350 mm, swivelling range ±5°. Key specs: grinding spindle stepless, speeds up to 45 m/s; regulating spindle stepless 0–290 t/min; voltage 50 Hz 3x400 V; grinding motor 22 kW; total power 26 kVA; overall dimensions L2300 × W2000 × H2150 mm. Enables tight tolerances; suitable for automotive, watchmaking, machine tools, aerospace and medical sectors Csdpfx Ahjyn Ra Aj Ispw

Condition: ready for operation (used), Year of construction: 1991, Max. grinding diameter: 250mm Cjdeyn Amzspfx Ah Ijpw Grinding wheel length: 300mm Grinding wheel diameter: 600mm

Condition: used, Year of construction: 1961, functionality: fully functional, grinding wheel width: 100 mm, grinding wheel diameter: 300 mm, grinding diameter: 50 mm, grinding length: 500 mm, type of input current: AC, workpiece diameter (max.): 50 mm, input voltage: 380 V, bar length: 500 mm, disc diameter: 300 mm, control cabinet height: 1,800 mm, control cabinet length: 400 mm, control cabinet width: 700 mm, nominal power: 5 kW (6.80 HP), year of last overhaul: 2019, Equipment: rotational speed infinitely variable, We offer this used Herminghausen SR 2 G centreless cylindrical grinding machine, year of manufacture 1961, complete with coolant tank. Machine type: SR 2 G Machine no.: 460690 / 548794-2-12 Power consumption: 5 kW Voltage: 380 V Year of delivery: 1961 Cjdjynwi Rjpfx Ah Iopw Other accessories: New Ø300 mm grinding wheel, new Ø150 mm regulating wheel, various carbide guide rails Puller for grinding and regulating wheel If you have any questions or require further information, please feel free to send us a message or give us a call.

Condition: used, Centerless grinder, made by CINCINNATI Bars diameter : 8 - 35 mm Cpodpfx Aheymcnvo Isw Bars diameter: 8 - 35 mm

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 17655, grinding wheel width: 139 mm, grinding wheel diameter: 400 mm, total height: 2,400 mm, total width: 3,000 mm, total length: 4,000 mm, overall weight: 7,000 kg, No reserve price – guaranteed sale to the highest bidder! Cjdpfxjyk Dk Ho Ah Ispw Placing a bid obligates you to collect the item on time between 08.04.26 and 16.04.26. TECHNICAL DETAILS Grinding wheel diameter: approx. 400 mm Grinding wheel width: approx. 138.5 mm MACHINE DETAILS Operating voltage: 380 V Frequency: 50 Hz Control voltage: 220 V Connected load: 75 kVA Dimensions & Weight Dimensions (L x W x H): 4000 x 3000 x 2400 mm Machine weight: 7 t

Condition: reconditioned (used), Year of construction: 2017, functionality: fully functional, grinding wheel width: 150 mm, grinding wheel diameter: 305 mm, year of last overhaul: 2025, Grinding wheel diameter 305x150 mm, workpiece diameter 1-40 mm, machine for plunge and through-feed grinding, PLC control, coolant system, hardened and ground guideways, grinding and regulating spindles with hydraulic slide bearings via three-point bearings, hydraulically adjustable dressers for grinding and regulating wheels, regulating wheel drive adjustable via AC motor, new German-made electrical system with Siemens components, Siemens S7 control system Csdpjyfm Rlefx Ah Ispw

Condition: used, Grinding wheel dimensions (OD x ID x width): Ø508 x Ø304.8 x 305 mm Min./max. diameter to grind: 150 mm Grinding wheel width: 305 mm Maximum plunge grinding length: 305 mm Regulating wheel dimensions (OD x ID x width): Ø330 x Ø203 x 305 mm Regulating wheel motor power: 4 kW Grinding wheel head motor power: 37 kW Total power: 45 kW Length: 3,500 mm Width: 2,500 mm Cpodpfx Aheydz S Ue Isw Height: 1,100 mm Weight: 6,500 kg

Condition: used, Grinding wheel dimensions (OD x ID x width): Ø406 x Ø229 x 254 mm Min./max. diameter to be ground: 125 mm Csdpfxoydy Emj Ah Iopw Grinding wheel width: 254 mm Max. plunge grinding length: 254 mm Regulating wheel dimensions (OD x ID x width): Ø280 x Ø165 x 254 mm Grinding wheel motor power: 30 HP Total power: 34 HP Approx. weight: 5,500 kg Dimensions: 2,600 mm length x 1,200 mm width x 1,200 mm height

Condition: used, Grinding wheel dimensions (od x id x width): 610 x 355 x 304.8 mm Min/max diameter to be ground: 2 / 150 mm Regulating wheel speed steps: infinite Min/max regulating wheel speed (rpm): 10 / 225 rpm Cjdpfx Ahjydqfws Iopw Dressing (auto/manual): Automatic - CNC Lubrication (auto/manual): Automatic Control type (CNC/manual): CNC CNC brand: FANUC CNC model: Oi TD Plunge (auto/manual): Automatic Regulating wheel dimensions (od x id x width): Ø350 x Ø203.2 x 355 mm Maximum plunge grinding length: 355 mm Coolant motor power: 0.70 kW Grinding wheel head motor power: 37 kW Total power: 45 kW Voltage: 220/380V Length: 1,165 mm Width: 3,398 mm Height: 1,700 mm Weight: 14,000 kg Accessories: Inline loader, Coolant filter, Supporting rulers

Condition: not inspected (used), functionality: unexamined, Several machines are to be sold as a package. Centerless grinding machine. Manufacturer: NOMOCO, Type: M100 Max. grinding diameter: 100mm Max. grinding length: 180mm Grinding wheels: Ø 400mm Max. grinding wheel width: 180mm Weight: 3,200kg Application: plunge grinding ----- The concentricity testing device is not included in the scope of delivery. The machine has been disconnected from the power supply, i.e., it cannot be demonstrated under power. Removal and loading are at the buyer's expense. Cjdpeyc N D Nofx Ah Iopw Under the "Documents" section (PDF file), you will find the prices at which the machines are being sold. A forklift for loading the machine is not available but can be arranged if necessary.

Condition: ready for operation (used), functionality: fully functional, grinding wheel width: 100 mm, grinding wheel diameter: 350 mm, overall weight: 2,000 kg, The machine was retrofitted and modernised in 2025. The modernisation includes the addition of automatic loading and automatic cycle functions. The user interface and control panel are available in English, German, and French. TECHNICAL DETAILS Grinding wheel dimensions (outer diameter x inner diameter x width): 350 x 127 x 100 mm Grinding wheel width: 100 mm Grinding wheel speeds: Infinitely variable Regulating wheel speed: 10 - 250 rpm Feed: Automatic Regulating wheel dimensions (outer diameter x inner diameter x width): 230 x 76.2 x 100 mm Regulating wheel width: 100 mm Maximum length to be straightened: 200 mm Workpiece diameter to be straightened: 1.5 - 50 mm MACHINE DETAILS Cedpfx Aeyb R R Ioh Ispw Dimensions & Weight Dimensions (L x W x H): 1,800 x 1,300 x 1,600 mm Weight: 2,000 kg EQUIPMENT New coolant tank with paper filtration system

Condition: used, Year of construction: 1984, type of input current: AC, We are offering this used Cincinnati Milacron 3.300 centreless cylindrical grinding machine, year of manufacture 1984. Manufacturer: Cincinnati Milacron B.V. Model: 3.300 Serial number: 78 460282 Date of manufacture: 07/84 Rated voltage (single phase): 110 V Frequency (single phase): 50 Hz Rated voltage (three phase): 380 V Number of phases: 3 Frequency (three phase): 50 Hz Rated current: 95 A Wiring diagram number: OE A 54230 Cpodpfx Ajx U D Uhoh Ijw If you have any questions or require further information, please feel free to send us a message or give us a call.

Condition: good (used), Year of construction: 2014, Offered here is a centerless cylindrical grinding machine from the manufacturer Tschudin, including automation. The machine is in very good condition and can be inspected upon request. Technical data – see PDF. Cjdpfx Asx Urh Aoh Iepw

Condition: excellent (used), Brand: ESTARTA Model: 312 Type: Centerless grinding machine Grinding Wheel dimensions: 508 x304,8 x 160 mm Ø min/max to grinding: 1,5 / 75 mm Regulating wheel width: 160 mm Cedpfex Iu E Dex Ah Iepw Regulating wheel dimensions : 304,8 x 190,5 x 160 mm Maximum length to rectify in plunge : 160 mm Maximum length to rectify in plunge : 160 mm Grinding wheel head motor power : 11 kw Machine size : 2015 x 1280 x 1440 mm Weight : 3500 kgs

Condition: ready for operation (used), Year of construction: 1989, number of axes: 2, This Schaudt Mikrosa SASL 125 was manufactured in 1989. A centerless external grinding machine, it features NC-controlled operations and hydrodynamic axis bearing. Both wheels can be dressed via a controlled axis. Refurbished by UHLMAN Werkzeugmaschinen-Service in 2021/22, it has been regularly maintained. Consider the opportunity to buy this Schaudt Mikrosa SASL 125 centerless grinding machine. Contact us for more information. Additional equipment • Optional: Additional equipment available Codpfox Enapox Ah Ispw Machine Benefits Technical Machine Benefits • Hydrodynamic axis bearing • Regular maintenance during series production • Refurbished by uhlman werkzeugmaschinen-service in 2021/22

Condition: ready for operation (used), Year of construction: 2013, total height: 1,900 mm, overall weight: 6,000 kg, controller manufacturer: FANUC, controller model: 21i-MB, General Data Measurements width 2400 mm Measurements depth 2000 mm Measurements height 1900 mm Machine weight 6000 kg Control Unit Csdpfjx D Nzcox Ah Ispw Brand FANUC Model 21i-MB Additional Equipment Kraft & Bauer Fire extinguishing system, Type FB703S-UV3-TFM70°/KLA 6-S-MV / Knoll microfilter, Type Micro Pur 240 F / Streuli lifting station, Type SHSRT300-TL142/180 This TSCHUDIN ecoLine 400 centerless grinding machine was manufactured in 2013. It features a Fanuc 21i-MB control system, a grinding wheel with a max outer diameter of 400 mm, and a regulating wheel with a speed range of 0-265 rpm. Additional attachments include a Kraft & Bauer fire extinguishing system and a Knoll microfilter. Consider the opportunity to buy this TSCHUDIN ecoLine 400 centerless grinding machine. Contact us for more information about this machine. Application Types Grinding

Condition: good (used), Year of construction: 1968, Malcus MC40 Centerless Cylindrical Grinding Machine Manufacturer: Malcus Halmstad, Sweden Cpjdpfx Ajx Aq A Eeh Iew Model: MC-40 Year of Manufacture: 1968 Control Panel: Mechanical push-button control with main switch and emergency stop Grinding Units: Two opposing units with adjustable guide and grinding supports Machine Construction: Heavy-duty cast iron frame Condition: Used, fully functional The Malcus MC40 is a robust centerless cylindrical grinding machine made in Sweden, renowned for its reliable precision during continuous industrial operation. The machine features a solid cast iron construction which minimizes vibration and ensures consistent grinding results. Its opposing grinding and guide assemblies can be precisely adjusted, making it ideal for machining rotationally symmetrical workpieces. An integrated dressing device keeps the grinding wheel in optimum condition during use. The mechanical control panel with its clearly arranged elements enables intuitive operation of the grinding process. Designed for high stability and long service life, this machine is an excellent choice for workshops and production facilities seeking a dependable solution for centerless grinding. No guarantee is provided for the accuracy, completeness, or currency of the information given.

Condition: used, Year of construction: 1995, Centerless Cylindrical Grinding Machine Ghiringhelli M100SP400 Workpiece diameter: 1–50 mm Maximum plunge grinding length: 100 mm Grinding wheel diameter max.: 406 mm Grinding wheel diameter min.: 260 mm Grinding wheel width: 80 mm Grinding wheel speed (new): 2,140 rpm Grinding wheel speed (worn): 2,579 rpm Peripheral speed: 45 m/s Drive wheel indexability: ±6° Drive wheel diameter max.: 200 mm Drive wheel diameter min.: 80 mm Drive wheel speed: 0–140 rpm Cpjdpfoxz R U Ejx Ah Iew Dressing speed: 200 rpm CNC control: Siemens 810 GA3 Machine width: 3,100 mm Machine depth: 2,700 mm Machine height: 2,000 mm Total weight: 2,500 kg Total power: 12 kVA Supply: 380 V/50 Hz Hydraulic pressure: 2–3 MPa Pneumatic pressure: 0.5 MPa No guarantee is given for the correctness, completeness, or accuracy of the information provided.

Condition: used, TECHNICAL DETAILS - Workpiece diameter : 1 - 80 [mm] - Max. plunge grinding length : 140 [mm] WORKING GRINDING WHEEL - Minimum wheel diameter : 360 [mm] - Maximum wheel diameter : 508 [mm] - Grinding wheel width : 200 [mm] - Peripheral speed : 45 [m/s] - Grinding wheel speed : 1900 [rpm] REGULATING WHEEL - Grinding wheel width : 40 [mm] - Wheel tilt : +/- 7 [°] - Minimum diameter of drive wheel : 220 [mm] - Maximum diameter of drive wheel : 305 [mm] SUPPLY - Installed power : 30 [kW] Cpjdpjxz Hrmjfx Ah Iew - Supply : 400V, 50 [Hz] DIMENSIONS - Floor dimensions : 6000 x 4200 [mm] - Machine height : 3000 [mm] - Machine weight : 3100 [kg] EQUIPMENT - CNC SIEMENS SINUMERIK 840 D - Double slides for the plunge grinding wheel - Automatic loading through vibrating bowl

Condition: used, Centerless grinding machine Cjdpfxjxzu E Uo Ah Ispw PARAGON RC16 200*400 G.W. through-feed grinding under power in our warehouse (see video)

Condition: used, Year of construction: 1998, serial number 908278 max. dia. of grinding wheel 1,5-75 mm switchgear cabinet Ohne Cpedpfxexzu A Tj Ah Iew weight of the machine ca. 3,7 t

Condition: used, Year of construction: 1999, max. dia. of grinding wheel 1,5-75 mm Csdpfx Aexzu A Heh Ispw switchgear cabinet mit serial number 910279 weight of the machine ca. 3,7 t
