Condition: used, Year of construction: 1997, functionality: unexamined, machine/vehicle number: 322379, Cycle-controlled lathe Kern CD 480, year of manufacture 1997, control system Heidenhain MANUALplus. Isdpfx Asz A Ui Tekzoig Machine no. 322379. Equipment: Protective enclosure with viewing windows, tailstock with rotating center, Multifix quick-change tool holder, coolant supply, coolant unit, handwheels for the cross slide and longitudinal slide. Location: Homburg (Saar), Germany. Inspection by appointment only. Price on request, net plus VAT, ex works; dismantling and loading by arrangement. All information without guarantee.

Condition: new, Year of construction: 2018, functionality: fully functional, turning length: 3,060 mm, turning diameter: 494 mm, spindle speed (max.): 2,000 rpm, overall weight: 17,500 kg, controller model: Fanuc 0i-TD, An unused CNC lathe is for sale! TECHNICAL DETAILS Maximum turning diameter: 800 mm Turning diameter: 494 mm Maximum turning length: 3,060 mm Iisdpfx Aksz Ar Rkjzog Spindle speed max.: 2,000 rpm Bar capacity: 115 mm X-axis travel: 300 + 20 mm Z-axis travel: 3,100 mm Chuck: 15″ Spindle nose: A2-11 Tool stations: 12 Boring bar diameter: 50 mm Rapid traverse X-axis: 15 m/min Rapid traverse Z-axis: 20 m/min Tailstock diameter: 110 mm Tailstock taper: MK 5 Incline: 45° MACHINE DETAILS Control model: FANUC 0i-T C-axis: Duplomatic VDI60 Spindle motor power: 30 kW Motor power X-axis: 4 kW Motor power Z-axis: 7 kW Electrical connection: 55 kVA Dimensions & Weight Dimensions (L x W x H): 6,500 x 2,120 x 2,310 mm Machine weight: approx. 17,500 kg EQUIPMENT Linear scale on the X-axis Hydraulic steady rest SMW SLUB-5 D50-D310 Tool presetter Renishaw HPMA Warning light Chip conveyor High-pressure pump (10 bar)

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, turning length: 1,050 mm, turning diameter: 465 mm, spindle speed (max.): 3,250 rpm, overall weight: 7,600 kg, controller manufacturer: Heidenhain, TECHNICAL DETAILS Maximum turning diameter: 465 mm Maximum swing diameter: 680 mm X-axis travel: 300 mm Iedpfx Aksz Apduozoig Z-axis travel: 1,050 mm Turning length: 1,050 mm Maximum spindle speed: 3,250 rpm Spindle bore: 76 mm Torque at 40% duty cycle (ED) max.: 630 Nm Torque at 100% duty cycle (ED): 420 Nm Number of tool positions in tool turret: 12 stations Chuck diameter: 250 mm Maximum workpiece weight between centers: approx. 350 kg MACHINE DETAILS Control system manufacturer: Siemens Spindle power at 40% duty cycle (ED): 33 kW Spindle power at 100% duty cycle (ED): 22 kW Electrical connection: approx. 50 kVA Mains connection: 400 V Frequency: 50/60 Hz Dimensions & Weight Dimensions with chip conveyor: approx. 5,300 × 1,900–2,200 × 1,700–2,000 mm Machine weight: approx. 7,500 kg EQUIPMENT Chip conveyor

Condition: used, Year of construction: 1989, machine/vehicle number: 1115.5117-25, turning diameter over cross slide: 700 mm, feed rate X-axis: 10 m/min, turning diameter over bed slide: 750 mm, controller model: Fanuc 15, distance between centers: 3,000 mm, TECHNICAL DETAILS Swinging diameter over bed: 750 mm Swinging diameter over cross slide: 700 mm Distance between centers: 3,000 mm Feed rate: 0.1 – 10,000 mm/min Rapid traverse: 10 m/min Iijdjz Apc Rjpfx Akzog Spindle torque (max.): approx. 4,000 Nm Spindle power: approx. 65 kW Spindle nose: Size 11 according to DIN 55026 Spindle bore: 130 mm Tool holder: 6 × VDI 60 according to DIN 69880 Tailstock diameter: 130 mm Tailstock travel: 120 mm MACHINE DETAILS Control system: Fanuc 15 Power chuck: Forkardt 3 FNC 500-125 Dimensions & Weight Machine dimensions (L x W x H): approx. 8.0 × 3.5 × 2.9 m Shipping dimensions (L x W x H): 8.0 × 2.3 × 2.9 m Machine weight: approx. 28,000 kg

Condition: good (used), Year of construction: 1997, functionality: fully functional, Used CNC turning machine Manufacturer: Böhringer Type: VDF 250 Cm Year of manufacture: 1997 with accessories. Isdpfxsz Anv No Akzeig

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, machine/vehicle number: 12081614, type of input current: three-phase, overall weight: 3,300 kg, Title: 5-Axis CNC Machining Center ARIX V450, Year 2012, Functional/In Operation Condition: Functional, in operation Year of Manufacture: 2012 Location: West Saxony Price: Negotiable Technical Data: Manufacturer: ARIX CNC Machines Co., Ltd. (Taiwan) Type: V450 (Mini High Speed Machining Center) Serial Number: 12081614 Control: ARIX CNC (Fanuc-compatible) 5-Axis Version (4th/5th axis rotary table) Travel: X 450 mm / Y 350 mm / Z 400 mm Spindle Power: 7.5 kW Tool Magazine: 20 positions (cone magazine) Connection: 400 V, 3-phase, 6 kVA Weight: approx. 3,200 kg Operating Hours: Not documented Iisdpfszyktfex Akzeg Description: For sale is a compact 5-axis CNC machining center, ARIX V450, manufactured in 2012, with ARIX CNC control. The machine features a cone magazine with 20 tool positions and is designed for the precise complete machining of smaller to medium-sized workpieces in 5 axes. The machine is functional and currently in operation. Operating hours are not documented. Inspection and test run at the location in West Saxony are possible by arrangement. Price: Negotiable Other machines available from site liquidation. Site takeover negotiable. If you have any questions or require further information, please send us a message or call us.

Condition: used, Year of construction: 2015, functionality: fully functional, turning length: 1,275 mm, turning diameter: 481 mm, spindle bore: 102 mm, travel distance X-axis: 260 mm, travel distance Z-axis: 1,350 mm, 2-axis CNC lathe Doosan Puma 2600LB Year of manufacture: 2015 Siemens 828D control system with Shop Turn interface Axis travel: X - 260 mm Z - 1350 mm Max. turning diameter: 481 mm Max. turning length: 1275 mm 12-inch (315 mm) chuck with a large spindle bore of 102 mm 12-tool turret Tailstock Very good machine condition Included with the machine: - Documentation - LNS chip conveyor Iedpfxezxz I Rs Akzeig

Year of construction: 1997, condition: used, Specification Data Manufacturer VDF Boehringer Model VDF 250 Cm Year 1997 Serial No. 1114.3705-24 Machine type CNC turning center / CNC lathe Control Siemens Sinumerik 840C Design Slant-bed Tailstock No Swing over bed 550 mm Swing over cross slide 480 mm Maximum turning length 1,000 mm X-axis travel 405 mm Z-axis travel 1,099 mm Spindle bore 103 mm Spindle nose Size 8, DIN 55026 Front spindle bearing Ø 150 mm Maximum chuck Ø 315 mm Spindle power 53 kW (50% duty) Maximum spindle torque 780 Nm Spindle speed 30–3,000 rpm* Turret 12 positions Tool interface VDI 50, DIN 69880 Rapid traverse X/Z 10 m/min Maximum feed rate 10,000 mm/min Iiedpfx Ajzw D I Rjkzjg Maximum feed force 15 kN Dimensions L × W × H approx. 5,400 × 3,200 × 2,400 mm Machine weight approx. 11,000 kg

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, turning length: 3,000 mm, turning diameter over bed slide: 480 mm, controller model: Siemens 840D, TECHNICAL DETAILS Swinging diameter over bed: 520 mm Swinging diameter over carriage: 480 mm Turning length: 3,000 mm C-axis: yes C-axis speed range: 0–20 rpm Number of tools: 12 Driven tools: 6 Iedjzwmztspfx Akzeig Spindle bore: 103 mm Main spindle head size: 8 MACHINE DETAILS Control system: Siemens 840D Main drive Main drive: 1-stage AC main drive Drive power: 53 kW Duty cycle: 50 % Speed range: 30–3,000 rpm EQUIPMENT Forkardt 3 NHF 315-82 A8 power chuck with centrifugal force compensation and hard, ground-in top jaws Outer diameter of power chuck: 315 mm Bore diameter of power chuck: 82 mm Maximum bar diameter: 63 mm Including draw tube and mounting for power chuck

Condition: good (used), Year of construction: 2009, control FANUC 18i-TB Control x-axis 0 mm z-axis 0 mm spindle taper 0 number of spindle speeds 0 engine output 0 kW weight of the machine ca. 8.200 kg dimensions of the machine ca. 1905,0 × 2720,0 × 3260,0 m DOOSAN PUMA TL 2500LM with IFS extraction system, multi-turret turning centres for shaft machining The PUMA TL series stands out thanks to its innovative design, featuring both upper and lower turrets. This advanced configuration makes it the ideal choice for the demanding machining of shafts, such as camshafts and crankshafts. Thanks to the capability for simultaneous 4-axis machining, complex machining Isdpfx Akjzvq Dpszeig processes can be carried out precisely, efficiently and in a single operation. --> Technical Specifications Mains connection: AC 200/220 V, 3-phase with earth, 50/60 Hz --> Rated power: 52.33 kVA --> Max. connected load: 22.0 kW --> Full-load current: 137.33 A --> Short-circuit current: 33.0 kA --> Max. turning diameter: 350 mm --> Max. turning length: 700 mm --> Spindle bore: 76 mm --> Main spindle: Integrated motorised spindle drive with oil cooling --> Tool holder: VDI 40 --> Number of turrets: 2 --> Tool stations: 20 (12 upper / 8 lower) --> Tailstock: Hydraulic --> Lubrication: Automatic centralised lubrication --> Coolant system: Separate coolant tank, 210 litres --> Machine bed: Meehanite cast iron bed with hardened box-type slideways --> Chuck: Hydraulic chuck Manufacturer: SCHUNK --> Type: ROTA NC 315-86 --> ID No. > Design: 3-jaw wedge-hook power chuck --> Chuck diameter: 315 mm --> Through-bore: 86 mm --> Piston stroke: 25 mm --> Stroke per jaw: 5.8 mm --> Max. clamping force: 155 kN --> Max. actuating force: 58 kN --> Max. speed: 3,500 min?¹ --> Jaw pitch: 1/16" × 90°

Condition: used, Technical details: turning diameter over bed: 230 mm turning diameter over support: 135 mm centre distance: 2000 mm Iisdpfxszvnq Ts Akzog spindle bore: 60 mm tailstock quill taper MT: MK 5 tailstock quill adjustment:: 300 mm total power requirement: 5,5 kW weight of the machine ca.: 2,5 t dimension machine approx.LxWxH: 3,7 x 1,20 x 1,30 m

Condition: used, Year of construction: 1997, turning diameter / mm turning length / mm control / Technical Data – MAZAK QTN-30 Manufacturer: MAZAK / Yamazaki Mazak Type: QTN-30 Year of manufacture: 1997 Machine type: Horizontal CNC turning center Control system: MAZATROL T PLUS Number of axes: 2 Max. swing diameter: approx. 510 mm Max. machining diameter: approx. 310–320 mm Max. machining length: approx. 1,000 mm X-axis travel: approx. 200–201 mm Z-axis travel: approx. 1,010 mm Spindle speed: approx. 33–3,300 rpm Spindle bore: approx. 80 mm Spindle nose: A2-8 Spindle motor: approx. 22 kW Chuck: Hydraulic, approx. 250–300 mm Turret: 8-station / 16 tool positions, depending on configuration Tool holder: approx. 25 × 25 mm Tailstock: Fully automatic, MT 5 Automatic tailstock: Included Chip conveyor: Included Coolant system: Included (depending on equipment) Machine weight: approx. 4,300–5,300 kg (depending on configuration) Dimensions: approx. 2,800 × 1,950 × 1,950 mm (depending on configuration) Iijdpfezu Dazox Akzeg The specifications regarding the 1997 model year and the QTN-30—featuring MAZATROL T PLUS, Ø510 × 1,000 mm capacity, Ø80 mm spindle bore, 33–3,300 rpm speed range, and a 22 kW spindle motor—are confirmed by a specific QTN-30 offer from 1997. Subject to change and without guarantee – Technical data

Condition: repair required (used), Year of construction: 2006, functionality: not functional, turning diameter: 450 mm, travel distance X-axis: 303 mm, travel distance Z-axis: 1,160 mm, overall weight: 10,000 kg, swing diameter over bed slide: 700 mm, controller model: Siemens 810D ShopTurn, Note: The main drive motor is currently not functional; an inspection and/or repair is required. TECHNICAL DETAILS Maximum turning diameter: 450 mm Swinging diameter over bed: 700 mm Swinging diameter over cross slide: 500 mm Maximum workpiece length: 1,100 mm Iiodpfx Aszt Sbkokzeg X-axis travel: 303 mm Z-axis travel: 1,160 mm C-axis resolution: 0.001° Spindle speed max.: 3,500 rpm Distance between centers: 1,230 mm Chuck diameter: 315 mm Bore in draw tube: 95 mm MACHINE DETAILS Control: Siemens 810D ShopTurn Total weight: approx. 10,000 kg EQUIPMENT C-axis Tailstock Steady rest Hollow chuck cylinder Chip conveyor Extraction system

Condition: ready for operation (used), Year of construction: 1993, turning length: 1,900 mm, turning diameter: 700 mm, spindle speed (max.): 4,000 rpm, spindle speed (min.): 25 rpm, rotational speed (min.): 25 rpm, rotational speed (max.): 4,000 rpm, total height: 2,520 mm, total length: 9,000 mm, total width: 4,100 mm, overall weight: 21,000 kg, Equipment: documentation/manual, rotational speed infinitely variable, -Turning length: 1900 mm -Maximum workpiece diameter over the bed: 700 mm -Spindle head A11 DIN 55026 -Tool system: 2 x 12 pieces Isdpfx Akjztr N Iezoig -Tool holders according to DIN 69880, diameter 50 mm -Automatic door sliding mechanism -Tailstock prepared for diameters of 80 mm - 262 mm -Pressure booster pump

Condition: excellent (used), Year of construction: 1985, Control: Philips B2T Swinging diameter: 640 mm Machining diameter, longitudinal: 550 mm Iisdpezpy Rrefx Akzsg Machining diameter on the turret: 450 mm Turning length: 1000 mm Spindle speed: 2,240 rpm Spindle bore: 103 mm 12-position turret, VDI 60 Chip conveyor

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, turning length: 1,000 mm, spindle bore: 65 mm, spindle speed (max.): 4,500 rpm, spindle speed (min.): 100 rpm, Microcut Challenger CNC Lathe Model: BNC-1840 Control: FAGOR 8055 FL Year: 2004 Swing over Bed: 475mm Distance between centres: 1000mm Spindle Speeds: 100 – 4500 RPM Spindle Bore: 65mm Machine with: Quick Change Toolpost Filtermist Unit 3-jaw chuck Dimensions: 3000 x 1850 x 2000mm high Weight: 3000 kgs Isdpfxezlhm Hs Akzsig

Condition: excellent (used), Year of construction: 2012, INDEX V300 CNC vertical turning center Power: 87 kW Year: 2012 1 tool turret with 10 positions CNC: SIEMENS SINUMERIK 840D sl with parts conveyor Approximately 19 tool holders, including powered tool holders, and tool displays for 10 tools Chip conveyor Tilting and fork-liftable chip bin, GOUBARD model. Iedpfx Aszlaluskzsig

Condition: excellent (used), Year of construction: 2012, INDEX V300 Vertical CNC Turning Center Iodszlalnspfx Akzjig Power: 87 kW Year: 2012 1 turret with 10 tool positions CNC: SIEMENS SINUMERIK 840D sl Part conveyor Approximately 8 tool holders, including powered tool holders Chip conveyor Tilting and forkliftable chip bin, GOUBARD 5-level shelving

Condition: ready for operation (used), functionality: fully functional, turning diameter over cross slide: 402 mm, turning length: 758 mm, turning diameter: 450 mm, spindle speed (max.): 3,000 rpm, turning diameter over bed slide: 582 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Maximum turning diameter: 450 mm Maximum turning length: 758 mm Diameter of rotation over the bed: 582 mm Diameter of rotation over the cross slide: 402 mm Spindle speed: 3,000 rpm Maximum spindle torque: 351 Nm Distance between centers: 744 mm Bar diameter: 81 mm Chuck size: 260 mm (10") Ijdezgt U Sepfx Akzeig Maximum bar diameter: 40 mm Axes: X, Z Number of tool positions in the tool changer: 12 Tool shank size: 25 × 25 mm Travel in the X-axis: 250 mm Travel in the Z-axis: 790 mm Rapid traverse rate in the X/Z direction: 30 m/min MACHINE DETAILS Control model: Hurco WinMax Spindle power: 22 kW Power supply: 400 V / 50 Hz (market-dependent) Machine weight: approx. 5,000 kg

Condition: ready for operation (used), Year of construction: 2023, functionality: fully functional, machine/vehicle number: ML0313-000510, turning length: 1,275 mm, turning diameter: 481 mm, spindle speed (max.): 2,800 rpm, travel distance X-axis: 260 mm, travel distance Z-axis: 1,350 mm, The machine has only been in operation for approximately one year! MACHINE DETAILS Power supply: AC 380 V, 3 phases, 50/60 Hz Rated power: 36.11 kVA Full load current: 54.87 A Machine weight: 6,900 kg FEATURES CNC control with operator panel Tool turret Tailstock Spindle chuck Enclosed working area Long-bed design CE marking The following data is taken from a manufacturer's data sheet. The seller assumes no liability for its accuracy: Iiedpfezf I Scex Akzsg TECHNICAL DETAILS Standard spindle chuck, main spindle: 12″ Maximum turning diameter: 481 mm Maximum turning length: 1,275 mm Travel distances Rapid traverse X-axis: 24 m/min Rapid traverse Z-axis: 30 m/min Travel X-axis: 260 mm Travel Z-axis: 1,350 mm Main spindle Spindle speed max.: 2,800 rpm Spindle power max.: 35 kW Spindle torque max.: 1,613 Nm Tool changer Number of tools: 10 MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 4,633 x 2,394 x 2,110 mm Machine weight: 6,900 kg

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 95950 € 1813.46 € 630 mm 2000 mm 85 mm 400 mm 350 mm D1-8 1/16 MK 3 37 - 2250 1/min 5000 mm/min 8000 mm/min 280 mm 75 mm 5 MK 190 mm 9 / 13.5kW (S1 / S6 40%) kW X: 0.02 Z: 0.04 mm X: 0.01 Z: 0.035 mm ISO3655 3840 mm 1905 mm 2235 mm 4200 kg THREE OPERATING MODES: CNC / TEACH-IN / MANUAL Siemens 828D CNC control • 12-inch colour screen • Linear interpolation • Circular interpolation • Helical interpolation • Skip function • Workpiece coordinate system • Coordinate system rotation • Rigid tapping • Mirror image, scaling and rotation Iisdpfx Aszcqx Uokzeg • Turning cycle • ShopTurn software Large spindle bore, with precision bearings for high accuracy and consistent cutting stability. Precision ball screw Ø 40 mm (Class C5) on the Z-axis and ball screw Ø 25 mm (Class C3) on the X-axis. 2-axis AC servo motors 50-300 mm roller-type tailstock. Manual tailstock quill, diameter 75 mm (MK5), travel 190 mm. Programming and operating instructions. Electronic handwheel for X and Z axes Manual 4-station tool holder (25 x 25 mm) Automatic lubrication system Fully enclosed splash guard with sliding door and window Chip container with coolant tank Inspection report LED work light Coolant system Preparation for oil cooling system OPTIONS (PRICES ON REQUEST): Fagor control system instead of Siemens Manual or hydraulic chuck 8-station turret (VDI, slot type o BMT version), optionally with driven tools Electrically rotatable 4-station tool holder Chip conveyor High-pressure coolant pump Further options on request ALTERNATIVE: FCL-2540 variant with 1000 mm centre distance FCL-2560 variant with 1500 mm centre distance

Condition: good (used), Year of construction: 2004, functionality: fully functional, turning diameter over cross slide: 600 mm, turning length: 670 mm, turning diameter: 490 mm, overall weight: 6,500 kg, FOR SALE: High-Quality CNC Lathe Biglia B 658 MB (Year of Manufacture 2004) with Driven Tools + KID 70 Bar Feeder Are you looking for a reliable and robust workhorse for metalworking? For sale is a Biglia B 658 MB CNC lathe in good and fully functional condition. The machine is equipped with driven tools, an automatic tailstock, a reliable Fanuc control, and includes an automatic bar feeder. The complete package is available ex stock. General Information Manufacturer: Biglia (Italy) Model: B 658 MB Year of manufacture: 2004 CNC control: FANUC Series 18i-TB Condition: Good, fully functional Availability: Ex stock --- Key Technical Characteristics (Lathe) Maximum turning diameter: 380 mm Maximum turning length: 650 mm Maximum rod/bar diameter: 80 mm Maximum passage: 620 mm Spindle speed range: 30–3000 rpm Spindle drive power: 26/22 kW Spindle end: ASA 8″ Spindle bore diameter: 90 mm Diameter of the lathe chuck: 315 mm Bidirectional turret: 12 positions Turret indexing time (per position): 0.1 s Driven tool stations: 12 positions Max. speed of driven tool stations: 4000 rpm Max. torque of driven tool stations: 3.7 kW Feed in the X/Z/B axis: 220 / 650 / 660 mm Rapid traverse in the X/Z/B axis: 20 / 24 / 12 m/min Automatic tailstock maximum clamping force: 1080 Kg --- Round bar diameter: min. 5 mm (3/16") – max. 70 mm (2" 3/4) Square bar side: min. 5 mm (3/16") – max. 50 mm (2") Hexagonal bar height: min. 5 mm (3/16") – max. 60 mm (2 1/4") Maximum bar length options: 500 mm / 1615 mm Magazine capacity: 250 kg (e.g., approx. 60 bars of 10 mm) Bar change time: 50 sec (with a 1000 mm bar) Feed speed: 0–500 mm/sec Return speed: 1000 mm/sec Supply voltage: 230/400 Volt Control voltage: 24 Volt Installed power: 2 kW Weight: 580 kg Additional Equipment & Features KID 70 Bar feeder Measuring arm (Touch setter) Chip conveyor Collet chuck DIN 6343 Coolant tank capacity: 250 liters Coolant pump capacity: 150 l/min Coolant pump power: 0.73 kW Noise level: 74 dB(A) Physical Dimensions (Lathe) Dimensions (L x W x H): 4000 x 1900 x 1850 mm Weight of the Biglia B658/BM: approx. 6,000 kg Iisdszbx N Ejpfx Akzjg Contact us today to request a quote for this complete production package! The machines are ready for immediate dispatch. > *(All information is given in good faith but we reserve the right to make errors)*

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 87350 € 1650.92 € 540 mm 1500 mm 85 mm 310 mm 350 mm D1-8 1/20 MK 3 27 - 2250 1/min 5000 mm/min 8000 mm/min 280 mm 75 mm 5 MK 190 mm 9 / 13,5 (S1 / S6 40%) kW 0.02 mm 0.016 mm ISO3655 3340 mm 1905 mm 2235 mm 3400 kg THREE OPERATING MODES: CNC / TEACH-IN / MANUAL Siemens 828D CNC control • 12-inch colour screen • Linear interpolation • Circular interpolation • Helical interpolation • Skip function • Workpiece coordinate system • Coordinate system rotation • Rigid tapping • Mirror image, scaling and rotation • Turning cycle • ShopTurn software Isdpfozbvabjx Akzoig Large spindle bore, with precision bearings for high accuracy and consistent cutting stability. Precision ball screw Ø 40 mm (Class C5) on the Z-axis and ball screw Ø 25 mm (Class C3) on the X-axis. 2-axis AC servo motors 50-300 mm roller-type tailstock. Manual tailstock quill, diameter 75 mm (MK5), travel 190 mm. Programming and operating instructions. Electronic handwheel for X and Z axes Manual 4-station tool holder (25 x 25 mm) Automatic lubrication system Fully enclosed splash guard with sliding door and window Chip container with coolant tank Inspection report LED work light Coolant system Preparation for oil cooling system OPTIONS (PRICES ON REQUEST): Fagor control system instead of Siemens Manual or hydraulic chuck 8-station turret (VDI, slot type o BMT version), optionally with driven tools Electrically rotatable 4-station tool holder Chip conveyor High-pressure coolant pump Further options on request ALTERNATIVE: FCL-2140 variant with 1000 mm centre distance FCL-2180 variant with 2000 mm centre distance

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 77850 € 1471.37 € 460 mm 1000 mm 56 mm 230 mm 350 mm D1-6 1/20 MK 3 33 - 3100 1/min 5000 mm/min 8000 mm/min 280 mm 75 mm 5 MK 190 mm 9 / 13,5 (S1 / S6-40%) kW 0.02 mm 0.01 mm ISO3655 2840 mm 1905 mm 2235 mm 2900 kg THREE OPERATING MODES: CNC / TEACH-IN / MANUAL Siemens 828D CNC control • 12-inch colour screen • Linear interpolation • Circular interpolation • Helical interpolation Iedszbu U Rspfx Akzeig • Skip function • Workpiece coordinate system • Coordinate system rotation • Rigid tapping • Mirror image, scaling and rotation • Turning cycle • ShopTurn software With precision bearings ensuring spindle runout of less than 0.005 mm, for high accuracy and consistent cutting stability. Precision ball screw Ø 40 mm (class C5) on the Z-axis and ball screw Ø 25 mm (class C3) on the X-axis. 2-axis AC servo motors 20-160 mm roller-type tailstock. Manual tailstock quill, diameter 75 mm (MK5), travel 190 mm. Programming and operating instructions. Electronic handwheel for X and Z axes Manual 4-station tool holder (25 x 25 mm) Automatic lubrication system Fully enclosed splash guard. Chip container with coolant tank Inspection report LED work light Coolant system Preparation for oil cooling system OPTIONS (PRICES ON REQUEST): Fagor control system instead of Siemens Manual or hydraulic chuck 8-station turret(VDI, slot type o BMT version) Chip conveyor High-pressure coolant pump ALTERNATIVE: FCL-1860 variant with 1500 mm centre distance

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, turning length: 380 mm, turning diameter: 450 mm, spindle bore: 59 mm, rotational speed (max.): 5,000 rpm, controller model: Seicos 40L Multi, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Turning diameter: 450 mm Turning length: 380 mm Maximum machining diameter: 340 mm Travel X-axis: 215 mm Travel Z-axis: 400 mm Bar capacity: 51 mm Spindle speed range: 30 to 5,000 rpm Spindle drive power: 11 / 7.5 kW Spindle nose: A2-6 Spindle bore: 59 mm Bearing diameter: 100 mm Turret: 16 stations Feed rate: 0.001 to 500 mm/min Rapid traverse X/Z: 30 m/min Tool shank diameter: 25 x 25 mm Drill shank diameter: 40 mm Tailstock taper: MT 5 Tailstock quill stroke: 300 mm MACHINE DETAILS Control unit: Seicos 40L Multi Total power requirement: 23 kVA Iodpfsy R Dmijx Akzoig Dimensions & Weight Space requirement: approx. 5.5 x 2.8 x 2.2 m Machine weight: approx. 4.6 t EQUIPMENT Documentation Chip conveyor Tailstock Signal light Parts discharge chute Tool setting arm Work area illumination Tool holder
