Condition: good (used), Working area Maximum turning diameter 400 mm Maximum turning length 5000 mm Swinging diameter over bed 840 mm Swinging diameter over carriage 530 mm Spindle speed 14.6 – 1250 rpm Drive power 18.5 kW Dimensions 8.0 × 1.9 × 1.7 m Rsdpfx Adsy Ug U Dsiju Weight approx. 6.3 – 8.2 t

Condition: excellent (used), Year of construction: 2004, Technical data: Maximum turning height: 300 mm Maximum turning diameter over bed: 600 mm Maximum diameter over slide: 500 mm Distance between centers: 1500 mm CNC control: FANUC 21i-TB Revolutions: 16 – 4,000 RPM Redpoy Ub Ufsfx Adiju Spindle motor power: 18.5 / 30 kW 3-jaw chuck: 315 mm Tool changer: 12 stations CE marking Dimensions (length x width x height): approx. 6000 x 2300 x 2100 mm Weight: approx. 7.5 tons Accessories: 12-position tool turret Numerous tools Numerous driven tools Hydraulic chuck with additional jaws Tailstock W+W filter system Chip conveyor The seller is not liable for typographical or data transmission errors. The machine’s appearance, technical condition, and wear are consistent with its age; used machines are sold without any warranty.

Condition: used, Year of construction: 2000, centre height 400 mm centre distance 3.000 mm max. swing over bed 810 mm max. swing over facing slide 510 mm max. swing-dia. in gap 850 mm control WEILER max. workpiece weight 3.800 kg spindle diameter in front bearing 150 mm spindle bore 106 mm faceplate diameter 630 mm worktool system Parat tailstock quill taper MT 6 dia. of quill 115 mm spindle turning speed range 1 - 1.800 U/min Lathe - cycle-controlled | WEILER - E80 x 3000 equipped with 630mm faceplate, 400mm SCHUNK ROTA-S plus chuck, boring bar attachment, PARAT tool system as well as a chip conveyor. Rodpfx Aoy Ty Ihodiju A comprehensive tool package is included in the scope of delivery. The machine video from the production plant will be shared on request. The machine is in good condition and can be inspected under power at any time. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: E-80 | E 80 | E80 x 3000 | E80x3000 | E 80 x 3000

Condition: ready for operation (used), Year of construction: 2003, Weiler E50 x 1000 precision lathe (2003) Rsdpfx Ajy Ti Iwsdisu Manufacturer: Weiler Type: E50 x 1000 Year of manufacture: 2003 Condition: good, used, under power Operating hours: 43.000h Technical data see pictures. Included in delivery: - Original documentation - Rota S Plus 250-62 - Bezel - Parat 4 compartment tool turret

Condition: used, Year of construction: 1994, operating hours: 26,793 h, functionality: fully functional, machine/vehicle number: 054204, turning diameter over cross slide: 520 mm, spindle bore: 70 mm, turning length: 1,500 mm, turning diameter: 520 mm, swing diameter over cross slide: 290 mm, spindle speed (min.): 2,000 rpm, Lathe Ø520 x 1500 mm. 70mm through-bore and MK5 in the tailstock. Super precise bench. Has had the side rails and spindle in X renovated. Forkardt 315 mm centering chuck with many extra jaws and Multifix quick-change steel holder. Nice beginner bench if you want to try your hand at CNC. We have the chip tray and cooling water tank with the pump. It's just not shown in the photo. The control can be set to German, English, Spanish or Italian. Redpfx Adey Sbh Tsiou I have all the documentation on the machine. The control is Phillips-Grundig and I can possibly help with training. The bench weighs 3,000 kg so we can't load it with a forklift. It has to be picked up by crane truck.

Condition: used, Year of construction: 2001, turning diameter 500 mm turning length 1000 mm control MONFORTS CONTROL control SYSTEM EURO TURN turning diameter over bed slide 290 mm spindle bore 70 mm spindle turning speed range 3 - 2800 U/min spindle power 15 kW max. torque on the spindle 1530 Nm spindle head DIN 55027 Gr. 8 feed power X/Z axis 11300 N rapid travel - longitudinal/face 10 / 5 m/min bed width 360 mm Redpfjy Nnw Aox Adieu travel of cross-slide 265 mm upper slide travel 140 mm turning tool - shaft cross cut 32 x 25 mm tailstock quill diameter 80 mm tailstock quill stroke 160 mm tailstock taper MT 5 weight of the machine ca. 3,1 t Accessories: 3-jaw chuck ROTA-S plus 250 mmø, 4 pos. toolholder PARAT, coolant

Condition: used, spindle bore: 90 mm, turning length: 2,000 mm, turning diameter over bed slide: 554 mm, turning diameter over top slide: 370 mm, center height: 280 mm, rotational speed (min.): 16 rpm, rotational speed (max.): 1,800 rpm, CNC Lathe Colchester Electronic Mastiff – Fanuc 20-T Manufacturer: Colchester Model: Electronic Mastiff Control: Fanuc Series 20-T Year of manufacture: unknown Rjdpfoy Nl Hnsx Adiou Technical Data (information without guarantee) Swing diameter over bed: approx. 550 mm Swing diameter over cross slide: approx. 370 mm Centre distance: approx. 1000 / 2000 mm Spindle bore: approx. 90 mm Speed range: approx. 16 – 1800 rpm Spindle power: approx. 11 kW Feed rate range: approx. 0.01 – 500 mm/rev Condition & scope of delivery Machine in working condition (according to previous owner) Inspection by appointment Sale as seen

Condition: used, Year of construction: 1999, total length: 3,350 mm, total width: 1,550 mm, total height: 1,800 mm, Colour: White Empty weight: 3.300 kg In very good condition. In 2017 Refurbished for €32.000 - Year: 1999 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Drive system: Teach-in - Power [kW]: 15.0 - Centre height [mm]: 250 - Swing over bed [mm]: 500 - Carriage turning diameter [mm]: 290 - Distance between centres [mm]: 1500 - Spindle bore [mm]: 70 - Min. spindle speed [rpm]: 2 - Max. spindle speed [rpm]: 2800 - Options: Fixed steady, Three-jaw chuck Rjdoy Ivx Eopfx Adiou - Transport dimensions: 3350mm x 1550mm x 1800mm (l x w x h) - Transport weight [kg]: 3300kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: defective spare-parts repository (used), Year of construction: 1994, operating hours: 68,921 h, functionality: not functional, spindle bore: 70 mm, turning length: 1,500 mm, turning diameter: 500 mm, swing diameter over cross slide: 290 mm, quill stroke: 180 mm, spindle speed (max.): 2,800 rpm, overall weight: 3,200 kg, Good day, We hereby offer you, without obligation, a used, defective cycle lathe from the manufacturer Gildemeister. Manufacturer: Gildemeister Model: NEF 500 Plus Year of manufacture: 1994 Rsdsy Hr U Hjpfx Adisu Total operating hours: 68,921 hours Turning diameter: 500 mm Turning length: 1,500 mm Control system: Manual Plus Spindle bore diameter: 70 mm Speed range: 8 – 2,800 rpm Gear stages: 3 Maximum swing diameter over cross slide: 290 mm Spindle nose: DIN 55027 size 8 Tool holder type: C Tailstock quill stroke: 180 mm Machine weight: approx. 3.2 t Dimensions (L x W x H): 3.0 x 1.8 x 1.8 m Note: The above technical data have been taken from the operating manual, manufacturer brochures, or other sources, for the accuracy and completeness of which we cannot accept any liability. Scope of supply: 1 used Gildemeister NEF 500 Plus cycle lathe Condition: The cycle lathe is not operational because the control does not power up. The machine can be inspected under power in our workshop, but cannot be put into operation. We are therefore selling the machine as defective. We would be pleased if this machine is of interest to you. Your Serviceteam Mertens & Frowein GmbH

Condition: excellent (used), Year of construction: 1998, turning diameter 570 mm turning length 1000 mm control Siemens / Weiler D2 Rsdpoy D T Uvjfx Adiju weight of the machine ca. 3,2 t dimensions of the machine ca. 3,0 x 2,0 x 1,9 m

Condition: used, Year of construction: 2004, control Heidenhain turning length 1.000 mm turning diameter over bed 500 mm turning dia. over slide 290 mm centre distance 1.500 mm x-axis 260 mm z-axis 1.000 mm spindle bore 70 mm spindle tunring speed 3.000 U/min spindle motor 12 kW In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Redpfoy A Tdbox Adiju Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, turning diameter over cross slide: 480 mm, spindle bore: 103 mm, turning length: 2,000 mm, turning diameter: 520 mm, turning diameter over bed slide: 520 mm, three-jaw chuck diameter: 400 mm, spindle diameter: 110 mm, workpiece length between centers: 2,000 mm, CNC: Siemens Sinumerik 840 D Swing over bed: 520 mm Permissible swing over carriage: 480 mm 12-position turret Speed range: 7-2800 rpm Distance spindle nose to faceplate: 2171 mm Maximum turning diameter: 520 mm Maximum turning length: 2000 mm Rsdpoyxv D Nefx Adiju X axis: 405 mm Z axis: 2049 mm Spindle speed: 7-3000 rpm Spindle bore: 103 mm Spindle nose: A11 No tailstock.

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, TECHNICAL DETAILS: Manufacturer: MAG IAS GmbH (Boehringer) – Germany Model: DUS 400 ti Year of manufacture: 2010 Control system: Heidenhain Operation voltage: 400V / 50Hz Control voltage: 24V Rsdpfx Adoyxp I Uoieu Short circuit rating: 50 kA Main motor current: 23.5 A Total nominal current: 33 A Main supply fuse: 50 A Made in Germany

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, turning diameter over cross slide: 365 mm, spindle bore: 62 mm, turning length: 2,000 mm, turning diameter: 57 mm, swing diameter over cross slide: 365 mm, rapid traverse X-axis: 5 m/min, rapid traverse Z-axis: 10 m/min, spindle speed (min.): 3 rpm, spindle speed (max.): 2,500 rpm, bed width: 360 mm, total length: 5,000 mm, total width: 2,100 mm, total height: 2,000 mm, workpiece weight (max.): 1,600 kg, travel distance cross slide: 345 mm, overall weight: 5,000 kg, rotational speed (min.): 3 rpm, rotational speed (max.): 2,500 rpm, The VDF Boehringer DUS 560 Ti is, in terms of turning diameter, the most popular teach-in lathe from VDF Boehringer. With a standard chuck size of 315mm or larger, these machines offer optimal machining efficiency for single-piece and small batch production. This machine is currently set up in our showroom and can be viewed on site! Comes as standard with: - Original documentation - Set of tool holders + drill chuck - Fixed steady rest - 3-jaw Forkardt 315-F Ø315mm chuck Weight & dimensions: - 5,500 kg - 5,000 x 2,100 x 2,000 mm (LxWxH) Rsdpfxeyvuhze Adisu For all specifications of this machine, please see the last images!

Condition: used, Year of construction: 1993, Böhringer DUS 560 lathe, year of manufacture 1993 Redpoytcylofx Adiju

Condition: excellent (used), Year of construction: 1998, turning diameter 410/ 440 mm turning length 950 mm control Siemens / Weiler D2 workpiece weight max 900 kg spindle head Gr 6 MK 6 spindle bore 54 mm face stroke 230 dia. of quill MK 4 mm quill stroke 120 mm centre height 200 mm thread pitch max. in mm 0,1 - 250 mm spindle turning speed - stepless 1 - 3000 U/min Rjdsyrh Apjpfx Adieu total power requirement 12 kW weight of the machine ca. 2,1 t dimensions of the machine ca. 2,3 x 1,5 x 1,8 m

Condition: used, Year of construction: 1995, turning diameter 570 mm turning length 2000 mm control num + CNC Keller centre height 280 mm turning dia. over face-slide 365 mm spindle bore 62 mm spindle turning speed range 3 - 2500 U/min spindle head DIN 55 027 Gr. 8 cutting speed Konstant 1 - 9999 m/min feed in x - axis 0,01 - 50 mm/U feed range Z-direction 0,01 - 50 mm/U rapid travel - longitudinal/face 10 / 5 m/min feed power x-Achse 7100 N feed power z-Achse 12.500 N travel of cross-slide 345 mm upper slide travel 125 mm Redpfoyrhm Uex Adieu bed width 360 mm tailstock quill diameter 80 mm tailstock quill stroke 190 mm tailstock taper MT 5 max. workpiece weight -without tailstock 400 kg max. workpiece weight between centres 1000 kg kpiece weight:each extra steadyrest 300 kg threading metric 0,1 - 400 mm/Stg. dimensions of machine L x W x H 3,98 x 1,87 x 1,81 m Accessories: 3-jaw chuck RÖHM, 250 mmø; MULTIFIX-toolpost, solid steady, coolant

Condition: excellent (used), Year of construction: 1998, functionality: fully functional, turning diameter over cross slide: 570 mm, spindle bore: 62 mm, turning length: 1,250 mm, turning diameter over bed slide: 365 mm, center height: 280 mm, overall weight: 4,000 kg, O F F E R We can offer you, subject to prior sale and errors excepted, ex-stock and without obligation: V D F - BOEHRINGER Cycle-Controlled Universal Lathe Model DUS 560 Year of Manufacture 1998 / completely overhauled in 2008 _____ Centre height 280 mm Max. swing diameter over bed 570 mm Max. swing diameter over cross slide 365 mm Cross slide / top slide travel 345/125 mm Centre distance / max. turning length 1,250 mm Spindle bore 62 mm Spindle speeds, 2-step infinitely variable 3–500 / 15–2,500 rpm Infinitely variable longitudinal and facing feeds 0.01–50 mm/rev Rapid traverse longitudinal/cross 5 and 10 m/min Max. feed force facing/longitudinal 6.5 / 12.5 kN Workpiece weight max. between centers/with tailstock 400 / 1,000 kg Thread pitches 0.1 – 400 mm/pitch Spindle drive motor 15/21 kW Total drive 25 kW - 400 V - 50 Hz Weight approx. 4,000 kg Accessories / Special Equipment: • SIEMENS 2-axis cycle control, type 805, with direct input of all turning parameters via interactive user interfaces and suitable software, controller and monitor integrated in the sliding door, with memory extension and software for free contour entry, graphics, etc. • 2 electronic handwheels for fine adjustment of carriage movement in Z and X axes, and new joystick for rapid traverse +Z/-Z and +X/-X, joystick for main spindle with stepless forward and reverse speeds • Mounted 3-jaw chuck model SCA Ø 300 mm, faceplate approx. Ø 500 mm, 4-jaw chuck Ø 315 mm, driver plate approx. 250 mm, single faceplate 500 mm, various jaws • Mounted MULTIFIX toolpost type CD with 5 different Multifix holders • Separate toolpost block for mounting CAPTO toolholder with internal coolant supply, various holders, partially with collets • Tailstock with air bearing for easy movement, work light • Mobile chip trolley with coolant pump and oil skimmer, 2 rear sliding doors • Separate electrical cabinet, adjustable spindle end stop, work light, etc. Condition: very good – guides in very good condition, machine is under power and ready for demonstration Please click here for a video of the machine: Redpfx Aeyqw Eqsdiju Delivery: ex stock – as inspected Payment: strictly net before delivery We look forward to receiving your order. Further lathes of all sizes in stock – please enquire.

Condition: good (used), functionality: fully functional, spindle bore: 70 mm, turning length: 1,500 mm, turning diameter: 500 mm, overall weight: 3,300 kg, Monforts KNC5-1500 Lathe in good condition for sale. The machine operates perfectly. Included accessories comprise all documentation, a quick-change toolholder, and a chip conveyor as shown in the photos. Inspection under power is gladly possible. Loading can be arranged by forklift or crane. Working area: Distance between centers: 1,580 mm Swing over bed: 500 mm Swing over cross slide: 290 mm Cross slide travel: 265 mm Top slide travel: 140 mm Bed width: 360 mm Cross slide width: 220 mm Bed slide guide length: 615 mm Turning tool shank size: 32x25 mm Spindle diameter at front bearing: 100 mm Spindle nose as per DIN 55027, Size 8 Bar capacity: 70 mm Spindle taper (metric): 80 Main drive: steplessly variable, three-phase AC motor Drive power (50/100% duty cycle): 15/11 kW Total speed range: 2-2,800 rpm Gear stage I: 2-280 rpm Gear stage II: 7-1,120 rpm Gear stage III: 28-2,800 rpm Three-phase servo drive with mechanical safety clutch Rapid traverse speed longitudinal/cross: 10/5 m/min Thread cutting range: longitudinal and taper threads, pitch 0.001-500 mm Tailstock: quill diameter 80 mm Quill stroke 160 mm Internal taper MK5 Tool system: Multifix quick-change toolholder, size C Coolant system: pressure/delivery rate 0.4 bar / 10 l/min Machine dimensions (LxWxH): 3,330 x 1,550 x 1,790 mm Weight (transport unit): approx. 3,300 kg Bed: – Torsion-resistant bed, guideways hardened and ground Gearbox: 3-stage with limit switch monitoring Spindle: – Front spindle bearing: double-row cylindrical roller bearing with tapered bore combined with double-row angular contact bearing – Electric holding brake in main drive motor – Full-length cross slide with adjustable gib Longitudinal and cross feed driven by variable-speed three-phase AC motor via precision ball screw Feed and rapid traverse operated via cross selector lever Longitudinal and cross movements via electronic handwheels Increment selector switch in combination with electronic handwheel Additional contour handwheel Automatic central lubrication for guideways and ball screws Clampable top slide – Quick-change toolholder – Bedway clamping by excenter lever – Additional clamping via tension bolts for heavy workpieces – Quill adjustment by handwheel – Quill tip holder MK5 Connection voltage: 3 x 400 Volt +/-10%, 50 Hz for TN-S or TN-C networks without RCD Total connected load: 16 kVA Transistor-controlled three-phase main drive with speed monitoring Rsdpfxeypbcds Adiou If you have any questions, please feel free to contact us at any time.

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, spindle bore: 83 mm, turning diameter: 570 mm, swing diameter over cross slide: 340 mm, center height: 280 mm, spindle speed (max.): 2,500 rpm, The machine is designed for heavy-duty turning and series production due to its robust construction! TECHNICAL DETAILS Speed range: 1 – 2,500 rpm Torque: 1,300 – 1,600 Nm Redpfx Adsymx N Njiou Swing diameter over bed: 570 mm Swing diameter over cross slide: 340 mm Center height: 280 mm Distance between centers: 2,000 mm Spindle bore: 83 mm (optional 128 / 165 mm) Number of turret positions: 8 Turret tool holder: VDI 40 shank Tailstock quill diameter: 80 mm Tailstock taper: MK5 MACHINE DETAILS Control system: WEILER SIEMENS 810D Main drive power: 20 / 17 kW (60% / 100% duty cycle) Dimensions & Weight Dimensions (L x W x H): 3,850 mm × 1,850 mm × 1,750 mm Machine weight: 4,200 kg

Condition: good (used), Year of construction: 2015, functionality: fully functional, turning diameter over cross slide: 360 mm, turning diameter: 570 mm, swing diameter over cross slide: 570 mm, quill diameter: 95 mm, rapid traverse Z-axis: 12 m/min, spindle speed (max.): 2,500 rpm, feed length X-axis: 7 mm, feed rate X-axis: 7 m/min, type of input current: three-phase, overall weight: 2,970 kg, Technical Data: - Swing diameter - Centre distance - Spindle speed - Power - Feed - Rapid traverse - Quill diameter - Quill stroke - Quill taper - Tool turret - 570 mm over bed - 360 mm over cross slide - 2000 mm - max. 2500 rpm - 11 kW - max. 7.5 m/min (longitudinal) - max. 7.5 m/min (cross) - 12 m/min (longitudinal) - 15 m/min (cross) - 95 mm - 220 mm - Morse Taper 5 (MK 5) - automatic - 8-position (see also options) - CAPTO turret disk Technical Description: - Machine bed - Cross slide - Tailstock - Operator station - Control system - Accuracy - Electrical equipment - Machine enclosure - Paintwork 2) Additional Features / Options - Accessories - made from pearlitic cast iron GG-26 - high rigidity due to heavy ribbing - guideways hardened and ground - automatic lubrication of bedways - manual - quick clamping - two movable handwheels on the control panel - one movable handwheel - CNC control "Siemens 828 D" - Siemens "Comfort" (incl. ShopTurn and rest material detection) - as per DIN 8605 - electronic handwheels (X and Z axes) - low-voltage lighting - full enclosure - RAL 7035 (light grey) / RAL 9023 (pearl dark grey) - Options - coolant system - chip tray - chip conveyor - operating manual - 3-jaw wedge-bar chuck, Ø 250 mm Condition: all existing base jaws / top jaws from Sommer must be compatible! - Removable tool turret (can be exchanged for Multifix) Rodpfx Aoymtbgsdieu Dimensions: 3.8 m x 1.3 m x 2 m (L x W x H) Weight: 2.97 t Tools are not included in this offer!

Condition: used, Year of construction: 1995, turning diameter 560 mm turning length 1250 mm control Sinumerik 805 turning dia. over face-slide 340 mm spindle bore 63 mm spindle turning speed range 3 - 2500 U/min feeds - longitudinal 0,001 - 3 mm/U feeds - cross 0,001 - 3 mm/U rapid traverse longitudinal 7 m/min Rsdpfx Adjymp Suoiju rapid traverse cross 3,5 m/min thread - mm pitch 0,5 - 140 mm thread - inch 1/4 - 56 Gang/ inch. thread - module mm main drive 19 kW clamping length max. 2250 mm total power requirement 24 kW weight of the machine ca. 4,8 t dimensions of the machine ca. 4,0 x 1,65 x 1,75 m controll Siemens 805, for cone turning, contour turning and threat cutting. Machine has MULTIFIX toolholder system size "C", steady and 3 jaw chuck.

Condition: used, Year of construction: 2007, Number of controlled spindles (C axes): 2 Number of controlled axes: 8 Number of channels: 3 Rsdpfx Ajydfq Iediju Max. bar diameter: 65 mm Bore in tie rod: 75 mm Chuck diameter: 175 mm Spindle nose: 140 mm Max. speed: 5,000 rpm Nominal torque: 191 Nm Nominal power: 20 kW DATA FOR THE W2 AXIS OF THE COUNTER SPINDLE Stroke: 690 mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 2,400 N X1 AXIS DATA Stroke: 165 mm Rapid traverse: 40 m/min Max. acceleration: 10 m/s² Nominal force: 2,400 N Z1 AXIS DATA Stroke: 678 mm Rapid traverse: 30 mm Max. acceleration: 5 m/s² Nominal force: 5,000 N Y1 AXIS DATA Stroke: 80(+50/-30) mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 5,000 N X2 AXIS DATA Stroke: 165 mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 5,000 N Number of tool stations: 12 Tool holder diameter: 30 mm Driven stations: 12 mm Max. speed of driven tools: 4,000 rpm

Condition: used, Year of construction: 2008, Working area Circulation dia. above bed slide way cover: 680mm Circulation dia. above cross guide cover: 565 mm Facing traverse: 324 mm Longitudinal path: 600 mm Main spindle Spindle nose dia: 170 h5 / 220 h5 mm Bar dia. Max: 65 / 90 mm Spindle nose dia. in front bearing: 120 / 150 mm Spindle boring: 79 / 110 mm Chuck dia: 200 / 250 / 315 mm Drive rating S1 100% duty cycle: 25 / 33 kW Rotational speed range: 5000 / 4000 r.p.m Max. torque S1 100% duty cycle: 270 / 375 Nm Salient rotational speed: 900 / 850 r.p.m Rodpoya Iirefx Adiou C axis (main spindle) Rotational speed: 250 r.p.m Stopping torque: 200 Nm Division accuracy: 0,025 deg. Compound slide X/Z/Y Facing traverse X: 260 / 1852 mm Longitudinal path Z: 635 / 6202 mm Ball spindle Z (dxh): 40x15 mm Vertical path Y: ±40 mm Ball spindle Y (dxh): 40x5 mm Rapid traverse speed X/Y/Z: 60/15/45 m/min Feed force X/Y/Z: 3,5/7/7 kN Tool holder Number of tool stations: 12 Tool mounting cylinder shaft (DIN 69880): 40 mm Tool disk, axial tool holder pitch circle dia: 370 mm Number of driven tools: 12 Drive rating max. 100% duty cycle: 4,9 kW Torque 100% duty cycle: 10,5 Nm Rotational speed range: 4500 r.p.m Tailstock Tailstock traverse path: 580 mm Tailstock force: 8 kN Tailstock mounting: MT 5 Rapid traverse speed Z2: 6 m/min Part accuracy for positioning: =/< 10 mm Hydraulic Contents: 40 l Pump capacity: 2,2 kW Max. pressure: 80 bar Pressure for clamping unit, tailstock: 10-60 bar Coolant unit Contents: 210 l Pump capacity: 1,7 kW Feed rate at 6 bar: 20 l/min Electrical energy requirement Connected rating: 50 kVA Operating voltage: 400 V Frequency: 50 Hz Fuses (slow blow/VDE 0100) perm: 80 A Voltage fluctuations at 400 V: 6% - 10% Machine dimensions Dimensions (LxWxH) with chip conveyor: 4350/2460/2080 mm Weight without chip conveyor/chip bath: ca. 6.000 kg Workplace based constant noise pressure level: - (DIN 45635 part 1-04.85 (ISO 3740-1980), measured as a chip removing cycle as per DIN 45635 part 1601-07.78): 77 db (A) - in idle running as per DIN 45635 part 1601-07.78: 78 db (A)

Condition: used, Year of construction: 2008, weight of the machine ca. 8,8 t dimensions of the machine ca. 4500x1990x2300 mm Number of controlled spindles (C axes): 2 Number of controlled axes: 8 Number of channels: 3 Max. bar diameter: 65 mm Bore in tie rod: 75 mm Chuck diameter: 175 mm Spindle nose: 140 mm Max. speed: 5,000 rpm Nominal torque: 191 Nm Nominal power: 20 kW DATA FOR THE W2 AXIS OF THE COUNTER SPINDLE Stroke: 690 mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 2,400 N Rjdpfxeyat Hve Adisu X1 AXIS DATA Stroke: 165 mm Rapid traverse: 40 m/min Max. acceleration: 10 m/s² Nominal force: 2,400 N Z1 AXIS DATA Stroke: 678 mm Rapid traverse: 30 mm Max. acceleration: 5 m/s² Nominal force: 5,000 N Y1 AXIS DATA Stroke: 80(+50/-30) mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 5,000 N X2 AXIS DATA Stroke: 165 mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 5,000 N Number of tool stations: 12 Tool holder diameter: 30 mm Driven stations: 12 mm Max. speed of driven tools: 4,000 rpm Translated with (free version)
