Condition: ready for operation (used), functionality: fully functional, Manufacturer: Cosen Model: NC4038H Horizontal Dual-Column Band Saw Itedpfx Aoz Ap A Dsiyol Rectangular Capacity (Height): 401.32 mm Rectangular Capacity (Width): 381 mm

Condition: new, cutting diameter 300 mm capacity 90 degrees: flat 330 x 250 mm capacity 90 degrees: square 250 x 250 mm capacity 45 degrees: round 260 mm capacity 45 degrees: flat 260 x 200 mm capacity 60 degrees: round 180 mm capacity 60 degrees: flat 170 x 170 mm band speed 15 - 100 m/min dimensions of saw-band 3650 x 27 x 0.9 mm Control MEP CNC total power requirement 2.2 kW weight 1190 kg Fully automatic electro-hydraulic band saw, featuring additional operating modes: * semi-automatic * semi-automatic dynamic * manual Description: - Robust, fully automatic electro-hydraulic band saw (INDUSTRIAL grade) * MEP Direct control technology * User interface with intuitive 10" touchscreen display * Mechanical buttons for saw operating functions * Guarantees reliable, simple, and intuitive operation * Real-time monitoring of all cutting parameters * Pivoting arm allows for convenient and safe operation * Display and logging of alarm and error messages * Massive data storage: up to 100,000 programs and 9,999 cutting sequences - Miter cuts in automatic cycle from 0° to 60° left - Semi-automatic, semi-automatic dynamic, and manual cycles * Miter cuts from 45° right to 60° left - Selectable manual or semi-automatic dynamic cycle * For performing cuts without programming Itodpfxjz Albio Aiyol - Protective enclosure for operator safety - Infinitely variable cutting speed regulation from 15 to 100 m/min * Via frequency inverter - Latest-generation hydraulic power unit * High performance with low energy consumption - Material feed via stepper motor and recirculating ball screw * Mounted on opposed ball bearings * Repeatable 600 mm single stroke for cutting any length - Saw head positioning and feeder movement via joystick - Automatic detection of the initial cut position - Manual band tension monitoring with display readout * Via electronic transducer - Automatic cutting load monitoring * Via a servo valve mounted directly on the cylinder - Coolant tank integrated into the machine base - Chip-clearing brush - Bi-metal saw blade for solid and profile material - Tools and operating instructions with spare parts list * Angularity = 2/12 degrees * Length accuracy = +/- 0.1 mm per feed stroke Manufacturer information – please note: If this saw is installed on a mains circuit equipped with a residual current device (RCD), the RCD must be universal-current sensitive (Type B) and rated at no less than 300 mA.

Condition: good (used), Fully automatic band saw from Imet Type BS 400 60 AFi-NC Iedpfx Aijzz Rpijystl Year of manufacture 2013 Capacity ø 310mm Single-sided miter cut max. 60 degrees Material selector switch

Condition: used, Year of construction: 1997, machine/vehicle number: 6169, power: 20 kW (27.19 HP), cutting height (max.): 406 mm, cutting width (max.): 500 mm, control type: NC control, pivoting range: 105 °, total height: 2,300 mm, total length: 3,200 mm, total width: 3,250 mm, overall weight: 3,200 kg, Equipment: documentation/manual, See the datasheet and images for details. Itedpfx Aszz Hdcjiysl

Condition: good (used), Year of construction: 2006, cutting diameter 335 mm capacity 90 degrees: flat 500 x 335 mm saw band length 4400 x 34 x 1.1 mm speed 15.0 - 150 m/min work height max. 750 mm workpiece weight 250 kg/m coolant tank capacity 80.0 ltr. oil volume 30.0 ltr. power capacity 5.5 kW Isdpfxezy Sd Es Aiyjtl weight of the machine ca. 1800 kg range L-W-H 2000 x 2200 x 1900 mm current list price: approx. 45.000 euros Special price available upon request Features: - MEBA - Fully automatic "two-column linear guide system" * Fully automatic machine for 90° cuts only - Automatic material feed - Continuously variable lowering speed 0â??300 mm/min - Band saw speed controlled by frequency-regulated AC drive (15â??150 m/min) - Automatic cutting pressure and feed monitoring - Hydraulic full-stroke material clamping - Automatic movement of the clamping blocks - Operatorâ??s manual

Condition: excellent (used), Year of construction: 2003, Kasto Kastotec AC3 full automatic sawing machine Year: 2003 Technical details: Itsdpfx Aiozxdd Ieysl Max cutting diameter 90° 330 mm Max Cutting flat 90° 430 x 330 mm Cutting speed Vario 12 - 120 m/min Blade size 6830 x 41 x 1,3 mm Blade motor power 5.5 kW Dimensions 4245x2140x2310 mm( including the swarf conveyor ) Max workipece weight 2275 kg Machine weight 3300 kg Operationg hours: 15724 Saw on hours: 12839 Under power in our warehouse, ready to use. Video available upon request!

Condition: new, Year of construction: 2025, functionality: fully functional, COSEN G320+ Full Cover – High-Performance Bandsaw Machine | Available Immediately Fully automatic sawing for precise cuts and economical series production. The COSEN G320+ Full Cover combines modern NC control, high cutting accuracy, and extensive automation functions – ideal for industry, metalworking, and series production. Technical Data Cutting range: Ø 325 mm or 380 × 325 mm Saw band: 4242 × 34 × 1.1 mm Saw drive: 3.75 kW Weight: 2,200 kg Working height: approx. 820 mm Connection: 400 V / 50 Hz Equipment & Automation Smart NC control with 5.7" HMI touch screen, up to 100 cutting programs Mitsubishi PLC control V-Drive frequency control, cutting speed continuously adjustable from 15–100 m/min Digital display for saw feed, chip removal rate & saw frame position Material database for automatic parameter selection depending on the material Infeed automation with freely programmable head cutting length LED traffic light for machine status display & LED work light Hydraulic chip conveyor (adjustable) & coolant system with cleaning nozzle Hydraulic band tension with band breakage monitoring Vibration-damping roller for a smooth cutting action Automatic band guide arm positioning Itsdpfszw E Tuex Aiyel Material retraction after cutting to protect the saw band Slow-motion function for manual material positioning Infeed-side material support approx. 1,500 mm Outfeed table with coolant return approx. 500 mm AVAILABLE IMMEDIATELY – READY FOR DEMONSTRATION The machine is connected and powered up in our showroom and ready for demonstration. See for yourself the cutting quality, ease of operation, and automation in a live demonstration. Would you like to use the machine directly in your production? If desired, we will organize the professional loading and safe transport directly to your location. Inspection, consultation, and live demonstration by appointment. Inquire now – we will be happy to prepare an individual offer for you.

Condition: used, Year of construction: 1996, cutting diameter 15 - 300 mm saw band length 4640 mm cutting width 1,3 mm cutting range - square - 300 x 300 mm feed length 600 mm feed length: multiple 5400 mm dimensions of saw-band 4640 x 41 x 1,3 mm cutting speed 19 - 130 m/min min. cut-off length 10 mm Itodpfx Aozwxxkjiyel height of material-table 700 mm total power requirement 7 kW weight of the machine ca. 2,7 t dimensions of machine L x W x H 2,35 x 2,34 x 1,95 m Accessories: chip conveyor, DRO for cutting length, coolant

Condition: excellent (used), Year of construction: 2020, functionality: fully functional, Kaltenbach KBS 400 NA metal bandsaw, automatic (2020) Manufacturer: Kaltenbach Type: KBS 400 NA Year of manufacture: 2020 Condition: used, very good, operational Bandsaw blade (mm): 5,730 x 41 x 1.3 mm Motor power (kW): 4 Cutting speed (mm/min): 15-90 Bandsaw blade feed rate (m/min): 0-300 Swivel range: 115° Round stock 90°: 350 mm Round stock 45°: 350 mm Square stock 90°: 400x350 mm Square stock 45°: 315x350 mm Working height: 720 mm Weight: 3600 kg CNC-controlled cutting angle adjustment Isdpfx Aiszww Aueystl Separately driven chip brush Automatic material feed gripper with a stroke length of 2,600 mm for single stroke Hydraulic blade tensioning Electronic bandsaw blade slippage monitoring

Condition: used, cutting diameter / mm saw band length / mm cutting width / mm Manufacturer: KASTO Type: SSB 260 VA Machine type: Fully automatic band saw Design: Hydraulic, automatic feed Iedpfxszu Dauj Aiyotl Cutting range (round): approx. 10–260 mm Cutting range (square): approx. 260 × 260 mm Minimum cut length: approx. 5 mm Automatic feed: approx. 600 mm Multiple feed: up to approx. 5,400 mm (depending on version) Cutting speed: approx. 15–125 m/min, infinitely variable Saw band length: approx. 4,115 mm Saw band width: approx. 38–41 mm (depending on version) Saw band thickness: approx. 1.0–1.3 mm Saw motor: approx. 4.0 kW Total connected load: approx. 6.5 kW Machine weight: approx. 2,000–2,200 kg Dimensions: approx. 2,160 × 2,080 × 2,015 mm (depending on version) SUBJECT TO CHANGE AND WITHOUT GUARANTEE – TECHNICAL DATA

Condition: used, Year of construction: 1996, cutting diameter / mm saw band length / mm cutting width / mm Manufacturer: KASTO Type: HBA 360 AU Year of manufacture: 1996 Machine number: 6016 109 181 Weight: approx. 2,600 kg Electrical connection: 400 V Frequency: 50 Hz Power supply: 3~ (three-phase current) Connected load: 10.0 kW Rated current: 35.0 A Maximum cutting range: approx. 360 × 360 mm Maximum round cut: approx. 360 mm Saw band length: approx. 5,334 mm Saw band dimensions: approx. 41 × 1.30 mm (depending on version) Cutting speed: approx. 14–102 m/min Automatic material feed: approx. 600 mm stroke Saw band drive: approx. 5.5–6.0 kW Version: automatic high-performance band saw machine Suitable for sawing round, square, and profile material CE marking present Note: The technical data listed above has been compiled based on the nameplate of the specific machine and available information regarding the KASTO HBA 360 AU. Individual technical specifications may vary depending on the year of manufacture, serial number, and equipment configuration. Iodpfx Aiszu A Tyeystl SUBJECT TO CHANGE AND WITHOUT GUARANTEE – TECHNICAL DATA

Condition: used, cutting diameter / mm Itsdpfjzu A Tmex Aiyol saw band length / mm cutting width / mm

Condition: good (used), Year of construction: 2009, Thomas Super Trad 350 AO CN, a fully automatic bandsaw from 2009. This professional machine is designed for the precise and efficient cutting of steel, stainless steel, aluminum, and other metals. Thanks to its fully automatic operation, the machine is suitable for both serial production and single-piece work. Year of manufacture: 2009 Fully automatic CNC control Hydraulic material feed, clamping, and Automatic saw blade movement Miter cutting up to 60° Integrated coolant system and mist lubrication system User-friendly operation Includes bundle clamps for cutting bundles Technical specifications Cutting capacity 90°: Ø 270 mm / rectangle 350 × 240 mm Cutting capacity 45°: Ø 230 mm / rectangle 230 × 150 mm Cutting capacity 60°: Ø 140 mm / rectangle 140 × 140 mm Iodpfx Aszur Aqjiystl Saw blade speed: 36 and 72 m/min Saw blade dimensions: 2,925 × 27 × 0.9 mm Maximum clamping opening: 355 mm Motor power: 2.0 kW Weight: approx. 1,180 kg

Condition: excellent (used), Year of construction: 2017, cutting diameter 350 mm saw band length 4780 x 34 x 1.1 mm capacity 90 degrees: flat 500 x 340 mm capacity 45 degrees: round + 350 mm capacity 45 degrees: flat + 380 x 340 mm capacity 60 degrees: round 230 mm capacity 60 degrees: flat 220 x 340 mm capacity 45 degrees: round - 350 mm capacity 45 degrees: flat - 220 x 340 mm coolant capacity ca. 100 l band speed 20 - 100 m/min Control SIEMENS voltage 3x 400 V total power requirement 3.0 kW AC weight 2150 kg range L-W-H 3030 x 3150 x 2000 mm In very good condition Demo machine from the manufacturer PEGAS With a wide range of special features Original price about 60.000 euros Special price upon request - in checked conditions - machinevideo - ?v=dv_wXIT9BaQ Features: - Robust, highly efficient electro-hydraulic miter band saw * Fully automatic (INDUSTRIAL) = with automatic material feed * Model: Two-column band saw * Maximum stability and vibration damping during cutting * Powerful saw band drive with a 3.0 kW motor - Material feed unit with ball screws * "Longstep feed gripper" for a maximum feed length of 1.000 mm - Includes SIEMENS PLC control unit * Selectable semi-automatic or fully automatic cycle * 200 programs, each with 99 programmable cut lengths and quantities Ijdpfx Aiezqgf Seyotl * When the remaining length is 500 mm, the machine interrupts the sawing cycle * Protection against damage or jamming of the material - For angles from 0° to 60°, with a ball-bearing rotary table * Programmable CNC adjustment of the miter angle * Right (0° to 60°) and left (0° to 45°) * Stepless adjustment of the miter angle * Adjustment via a robust gear train - Saw blade guides made of carbide plates - Saw feed infinitely adjustable via a fine-adjustment knob - Sturdy machine bed and torsion-resistant saw frame - Infinitely variable speed adjustment of the saw blade - Coolant system - Operating instructions for the machine and control system

Condition: new, Year of construction: 2026, machine/vehicle number: K00629, functionality: fully functional, operating hours: 2 h, power: 3 kW (4.08 HP), input voltage: 400 V, input frequency: 50 Hz, cutting height (max.): 320 mm, cutting width (max.): 320 mm, control type: PLC-controlled, total height: 2,100 mm, total length: 2,600 mm, total width: 2,000 mm, Equipment: CE marking, documentation/manual, lighting, With the bandsaw automation system SA 320 ZA, the Sägemaschinenfabrik Bauer GmbH offers a powerful, fully automatic sawing solution for demanding series production. The robust, column-guided design ensures the highest cutting accuracy, long service life, and reliable operation – even in multi-shift operations. Itodpfxjzqdtyo Aiyol Whether in the steel trade, metal construction, mechanical engineering, or contract manufacturing, the SA 320 ZA impresses with its high productivity, ease of operation, and durable quality.

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, semi-automatic band saw Itedpfx Aozly Aasiysl

Condition: good (used), Year of construction: 2004, functionality: fully functional, cutting height (max.): 200 mm, cutting width (max.): 250 mm, total height: 1,750 mm, total length: 2,500 mm, total width: 2,300 mm, overall weight: 2,500 kg, For sale is a fully functional KASTO twin AE3 – a robust horizontal bandsaw machine for the reliable and economical cutting of solid and profile materials in general mechanical engineering, as well as in series and single-piece production. With a maximum material width of approximately 250 mm and a clamping height of approximately 200 mm, the machine is suitable for clean cutting of a wide variety of materials and cross-sections. The well-thought-out design, with a feed length of approximately 2200 mm and a material discharge length of approximately 1600 mm, ensures a comfortable and efficient material flow. The machine is complemented by two discharge roller conveyors, each with a length of approximately 1000 mm, resulting in a total material discharge length of approximately 4000 mm – ideal for the safe handling of even longer workpieces. The compact design, with dimensions of 2500 x 2300 x 1750 mm and a weight of approximately 2500 kg, offers high stability and smooth operation, which has a positive effect on cutting quality and service life. The scope of delivery also includes approximately 8 spare saw blades, which enable immediate and uninterrupted use of the machine. Overall, this is a reliable and versatile bandsaw machine that combines precision, performance, and efficiency in industrial production. --- Optional accessories A conveyor belt in lengths of 310 cm and 420 cm can be purchased separately to optimize material flow and provide comfortable handling of the cut material. --- You are welcome to inspect the machine in our workshop while it is running. If you are interested, we will gladly send you demonstration videos of the machine. Upon request, we offer delivery and commissioning of the machine as part of a comprehensive, hassle-free package. Itsdpfx Aijzk Hd Ueysl You are in the best hands with us – professional, reliable, and with a passion for machines! PS CNC Service Germany GmbH & Co. KG

Condition: good (used), Year of construction: 2014, cutting range 300 mm capacity 90 degrees: flat 330 x 260 mm capacity 90 degrees: square 260 x 260 mm capacity 45 degrees: round 260 mm capacity 45 degrees: flat 270 x 200 mm capacity 45 degrees: square 250 mm capacity 60 degrees: round 180 mm capacity 60 degrees: flat 170 x 170 mm capacity 60 degrees: square 180 mm automatic feeds 9999,9 mm feed minimum 2.0 mm cutting diameter minimum 5.0 mm band speed 15 - 100 m/min vice 340 mm Öffnung dimensions of saw-band 3650 x 27 x 0,9 mm Control MEP CNC total power requirement 2.2 kW weight 1240 kg range L-W-H 1800 x 1900 x 1750 mm actual NEW price about 23.000 Euro special price on request Itodezkbn Uepfx Aiyjl Equipment: - robust electro-hydraulic fully automatic band saw (INDUSTRY) - with additional semi-automatic function, for cuts from 0° to 60° left - WINDOWS “CE” based MEP 50 – control and 7” touch screen display * simple and quick setting of all machine parameters * with additional soft keys + backlit display * 10 programs, each with a maximum of 9999 pieces and . a maximum length of 9999.9 mm - material feed with stepper motor via ball screw * single stroke 600 mm repeatable to saw any length * accuracy of ± 0.1/600 mm - feeder with protective cover and safety limit switch - precise setting of the cutting feed with indication in mm/min - positioning of the saw head and movement of the feeder using a joystick - automatic detection of the start of the cut - large deflection discs, adjustable from cast steel - Saw blade tension with blade tension control and display - Hard metal blade guides for maximum cutting precision - Automatic monitoring of the cutting load - Vice with quick adjustment * with interchangeable clamping and stop jaws - Large, laterally extendable chip tray and coolant container * equipped with 2 electric pumps for lubricating and cooling the saw blade * Coolant gun for cleaning the machine - Chip removal brush for cleaning the saw blade - Operating instructions DE Information from the manufacturer: When installing this saw in a network with a residual current device (FI), this should be universally current sensitive and not less than 300 mA.

Condition: used, Year of construction: 1999, functionality: fully functional, USED AUTOMATIC BAND SAW, BIANCO 320, BTM 42-32, BUNDLE CUTTING UP TO 250x250 WITH CHIP EXTRACTOR, fully refurbished. TECHNICAL DATA: Cutting capacity at 90° round mm. 320 Cutting capacity at 90° square mm. 320 Cutting capacity at 90° rectangular mm. 320-420 Ijdszhul Uepfx Aiyetl Cutting capacity at 90° bundle mm. 250-250 Standard blade speed (variable) m/min. 12 - 115 Bar feed (single stroke) mm. 500 Main motor power KW 2.2 Hydraulic pump motor power KW 1.5 Coolant pump motor power KW 0.2 Chip extractor motor power KW 0.18 Blade dimensions mm. 5300 x 34 x 1.1 Coolant tank L. 100 Hydraulic unit tank L. 25 Worktable height mm. 830 Machine dimensions mm. 1910 x 3250 x 2100h Net weight Kg. 2300 Accessories: paddle chip extractor, automatic hydraulic bundle cutting up to 250x250

Condition: new, Year of construction: 2026, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, cutting height (max.): 330 mm, cutting width (max.): 330 mm, control type: CNC control, actuation type: electric, rotational speed (max.): 85 rpm, rotational speed (min.): 34 rpm, total height: 1,400 mm, total length: 2,150 mm, total width: 2,000 mm, overall weight: 1,499 kg, table height: 650 mm, Equipment: CE marking, documentation/manual, lighting, motor brake, rotational speed infinitely variable, SALE – 5% OFF CNC COLUMN TYPE METAL BANDSAW M2-330C The MTP 330×330 Column Type Metal Bandsaw is a professional cutting machine designed for manufacturing facilities, metal workshops, and steel processing companies. Thanks to its rigid column construction, efficient hydraulic system, and large cutting capacity, the machine delivers excellent cutting accuracy, reliability, and operator comfort. The column-guided design ensures stable movement of the saw frame, resulting in precise cuts and extended blade life. The machine is ideal for cutting profiles, pipes, shafts, bars, and solid materials made of structural steel, stainless steel, aluminum, and other non-ferrous metals. MAIN ADVANTAGES • Rigid column-type construction • Maximum cutting capacity: 330 × 330 mm • Hydraulic feed system • 4 blade speed settings • Efficient coolant system • High cutting accuracy and repeatability • Designed for continuous operation • CE certified PRECISE CUTTING The rigid construction and professional blade guidance system ensure high-quality cutting results while reducing material waste. The hydraulic feed allows smooth adjustment of the cutting process according to the type and size of the material being processed. Isdszd T H Aepfx Aiyjtl POWERFUL DRIVE SYSTEM The bandsaw is equipped with a 4 kW main motor and a 0.75 kW hydraulic power unit, ensuring reliable performance even when cutting large material sections. COOLING SYSTEM An integrated coolant pump with a power output of 60 W effectively removes heat generated during cutting, extending blade life and improving cutting quality. APPLICATIONS • Steel profiles • Round and rectangular tubes • Solid bars • Steel shafts • Structural components • Stainless steel • Aluminum and non-ferrous metals Thanks to its large cutting capacity, the machine is suitable for both single-piece and serial production. SAFETY The machine is equipped with protective covers, safety switches, and CE-compliant safety features to ensure safe operation in accordance with European standards. TECHNICAL SPECIFICATIONS Maximum cutting capacity: 330 × 330 mm Blade speed: 34 / 51 / 60 / 85 m/min Feed stroke: 500 mm Blade size: 34 × 1.1 × 4115 mm Main motor power: 4 kW Hydraulic motor power: 0.75 kW Coolant pump power: 60 W Material feeder dimensions: 600 × 360 × 630 mm Working table height: 650 mm Weight: 1499 kg Machine dimensions: 2150 × 2000 × 1400 mm DELIVERY AND SUPPORT We organize machine transportation throughout Europe. We provide technical support, assistance with machine selection, and access to spare parts and service. CONTACT US If you require additional information or a personalized quotation, our specialists will be happy to assist you. We also invite you to explore our full range of metalworking machinery available on our website.

Condition: used, Year of construction: 2008, cutting diameter 335 mm saw band length 4400 mm table height 750 mm 500 mm 335 mm 500 x 335 mm re. 330 li. 305 mm cutting speed re. 320x335 li. 305x335 mm down speed re. 180 mm Itsdpozdu Uzofx Aiyel dimensions of saw-band re. 170 x 335 mm workpiece weight 18 - 115 m/min capacity 90 degrees: round 0 - 300 mm/min. capacity 90 degrees: flat 4400 x 34 x 1,1 mm capacity 45 degrees: round max. 250 kg/m 4,0 kW work height max. 2400 kg connected load 3500 x 2350 x 1900 mm Features: - Material bundle clamping - Automatic feed - Laser light for cut line indication - Micro-dosing device - Motorized chip brush - Clamping pressure control on the control panel - Fully automatic sawing process after entering the length and quantity - Operating instructions

Condition: used, Year of construction: 2008, functionality: fully functional, MEBAeco 335 A Bandsaw Machine Technical Specifications Type: Straight cut 90° Sawing process: NC automatic Automation: Automatic series cutting Cutting range: Round material at 90°: Ø 335 mm Flat material at 90°: 500 × 335 mm Drive power: 3 kW Saw blade: 4400 × 34 × 1.1 mm Maximum load weight: 250 kg/m Year of manufacture: 2008 MEBAeco 335 A bandsaw machine, year of manufacture 2008, for automatic series cutting. Cutting capacity up to Ø 335 mm or 500 × 335 mm. Equipped with NC control, 3 kW drive, and saw blade 4400 × 34 × 1.1 mm. Maximum material load 250 kg/m. Itsdpszdlx Defx Aiysl

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, cutting height (max.): 335 mm, cutting width (max.): 500 mm, cutting speed: 150,000 mm/min, saw band length: 4,400 mm, saw band width: 34 mm, TECHNICAL DETAILS Saw blade dimensions: 4,400 x 34 x 1.1 mm Cutting range at 90° (round): 335 mm Cutting range at 90° (flat): 500 x 335 mm Cutting speed: 15–150 m/min MACHINE DETAILS Machine weight: 1,550 kg Itsdpfjzapq Rox Aiysl Control system: NC

Condition: ready for operation (used), Year of construction: 2018, cutting diameter 300 mm saw band length 3660 x 27 x 0.9 mm capacity 90 degrees: flat 320 x 290 mm capacity 45 degrees: round 290 mm capacity 45 degrees: flat 260 x 280 mm capacity 60 degrees: round 200 mm capacity 60 degrees: flat 180 x 170 mm coolant capacity ca. 100 l Control SPS total power requirement 2.4 kW AC weight 904 kg range L-W-H 2410 x 1920 x 2020 mm in good conditions Original price approx. 22.000 euros Special price on request Features: - Robust electro-hydraulic miter band saw, fully automatic (INDUSTRIAL) * Fully automatic with automatic material feed * Material feed unit with recirculating ball screws Itjdpsy Uy S Aofx Aiyel - Includes PLC MITSUBISHI control unit * 20 programs, each with 15 cutting lengths + number of pieces programmable - For angles from 0° to 60°, with ball-bearing rotary table * Mitre cuts up to 45° possible in automatic mode * Mitre cuts up to 60° possible in semi-automatic mode * Manual mitre adjustment * Stepless adjustment of the mitre angle - Saw blade guides made of carbide plates - Saw feed continuously adjustable via fine throttle - Strong machine bed and torsion-free saw frame - Stepless speed adjustment of the saw blade - Coolant device - Operating instructions for machine + control system * Special accessories included: - 1x PEGAS chip conveyor

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, control type: CNC control, actuation type: pneumatic, rotational speed (max.): 3,000 rpm, overall weight: 640 kg, Equipment: CE marking, documentation/manual, The MACC TA 400 A CNC is an automatic circular saw designed for cutting aluminium and non-ferrous materials in industrial serial production. Main Technical Data Parameter Value Machine Type Automatic CNC circular saw for aluminium Blade Diameter Ø 400 mm Blade Bore 32 mm Motor Power 2.2 kW Power Supply 3 × 400 V Blade Speed 3000 rpm Vice Opening 180 mm Cooling System Emulsion cooling system Clamping System 2 pneumatic vices Ijdpfsy Uvqzox Aiyotl Weight Approx. 510–640 kg Machine Dimensions Approx. 3450 × 1700 × 1420 mm Cutting Capacities at 90° Profile Type Capacity Solid Round Material 60 mm Tube / Round Profile 140 mm Square Profile 110 × 110 mm Rectangular Profile 180 × 100 mm
