Condition: used, Year of construction: 2002, turning diameter 280 mm turning length . mm control Mazatrol 640 T x-travel 190 mm y-travel 309 mm z-travel 330 mm turning speeds 4000 U/min feed 30 m/min number of tools 12 bar loader ja total power requirement 24 kvA weight of the machine ca. 3,5 t dimensions of the machine ca. . m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. Hnodpfx Ajzdu T Djiton We look forward to your visit. Your Markus Hirsch Team

Condition: excellent (used), Year of construction: 2018, - Siemens Sinumerik 828D control system - Accessories: Collet chuck Working area Swinging diameter over bed ø250 mm Swinging diameter over cross slide ø85 mm Maximum turning diameter ø85 mm Maximum turning length 225 mm Maximum bar capacity ø25.5 mm Distance between centers (spindle nose – tailstock center) 405 mm Slide travel range Slide travel X 100 mm Slide travel Z 300 mm Main spindle Spindle mounting (centering flange) ø70 h5 Spindle outer diameter at front bearing ø50 mm Main spindle – clamping system Hodpfx Aozdp U Asitsnn Hollow cylinder chuck (pneumatic) with draw tube with max. capacity ø25.5 mm Max. chuck size ø100 mm Main spindle drive AC motor, power (100%/40% ED) with integrated holding brake for driven tools 3.7 / 5.5 kW Speed range (continuously adjustable) 60-6300 rpm Max. torque 35 Nm Dimensions Height of turning axis above floor 1130 mm Overall height 1820 mm Footprint (width x depth, without options) 1700 x 1270 mm Weight 1400 kg

Condition: like new (used), Year of construction: 2023, MAZAK INTEGREX i-250H S Max. machining diameter: 670 mm Max. machining length: 1,011 mm Max. milling speed: 12,000 rpm Max. spindle speed: 5,000 rpm Max. bar diameter: 65 mm The machine is equipped with: - CNC control system Mazatrol SmoothAi - IRCO short bar loader magazine - Integrated robot system TA20/200 - Tool magazine for 112 tools (HSK) - Three-jaw chuck for main spindle, diameter 254 mm Hsdpfx Aiezdkr Astenn - Three-jaw chuck for second spindle, diameter 254 mm - Tool Eye - C-axis - Y-axis - B-axis - Counter spindle with full C-axis - Interface for bar loader magazine - Automatic parts catcher - 5-axis machining, basic package - Preparation for multi-tool and flash tool holders - Preparation for MAZAK Monitoring System B - High-pressure pump, 70 bar - KNOLL compact filter system KF400/2300

Condition: ready for operation (used), Year of construction: 2021, operating hours: 600 h, functionality: fully functional, turning diameter over cross slide: 300 mm, turning length: 1,350 mm, turning diameter: 510 mm, spindle bore: 102 mm, spindle speed (max.): 1,800 rpm, spindle speed (min.): 10 rpm, travel distance X-axis: 510 mm, travel distance Z-axis: 1,350 mm, spindle motor power: 7,500 W, rapid traverse X-axis: 8 m/min, rapid traverse Z-axis: 8 m/min, rotational speed (max.): 1,800 rpm, total width: 3,200 mm, quill stroke: 160 mm, feed rate X-axis: 2 m/min, feed rate Z-axis: 2 m/min, type of input current: three-phase, overall weight: 2,700 kg, swing diameter over bed slide: 300 mm, bar passage: 100 mm, chuck outer diameter: 315 mm, swing diameter over top slide: 300 mm, spindle nose: D1-8, center height: 330 mm, bar diameter (max.): 100 mm, For sale: STYLE 510 CNC LATHE This lathe is in like-new condition and has only 600 operating hours. It looks as good as new. Built in 2021. The machine is user-friendly thanks to its CNC touch control. You can see what you are programming, and the control is accessible on your own PC. The STYLE control system comes with the latest software. The bore diameter of this machine is 102 mm, and the main motor has a power of 15 kW (S6) with a maximum speed of 1800 RPM. It features an automatic tool changer with 8 positions (VDI-40) and an automatic chip conveyor and LED machine light. Hnsdpfozc Rz Asx Aitsn It also has a network connection.

Condition: excellent (used), Year of construction: 2020, - Siemens Sinumerik 828D control system - Accessories: Collet chuck Working area Swinging diameter over bed ø250 mm Swinging diameter over cross slide ø85 mm Maximum turning diameter ø85 mm Maximum turning length 225 mm Maximum bar capacity ø25.5 mm Distance between centers (spindle nose – tailstock center) 405 mm Slide travel range Slide travel X 100 mm Hjdpfxszcv Rio Aitsnn Slide travel Z 300 mm Main spindle Spindle mounting (centering rim) ø70 h5 Spindle outer diameter at front bearing ø50 mm Main spindle clamping system Hollow cylinder (pneumatic) with draw tube, max. passage ø25.5 mm Max. chuck size ø100 mm Main spindle drive AC motor, power (100%/40% ED) with integrated holding brake for driven tools 3.7 / 5.5 kW Speed range (continuously variable) 60-6300 rpm Max. torque 35 Nm Dimensions Height of the turning axis above the floor 1130 mm Overall height 1820 mm Footprint (without options) 1700 x 1270 mm Weight 1400 kg

Condition: used, Year of construction: 1992, operating hours: 53,500 h, functionality: fully functional, CNC turning machine Manufacturer: GILDEMEISTER Model: CTX-400 Year of manufacture: 1992 Control system: EPL-2 Operating hours: approx. 53,500 h Serial number: 310549 Technical data: - Turret: 12 stations VDI-30 of which 6 stations are driven - Spindle speed: 25 - 5,000 rpm Drive power: 27.5 kW at 60% duty cycle - Spindle bore: Ø 72 mm - X-axis travel: 212 mm - Z-axis travel: 640 mm - Max. turning diameter: 500 mm - Turning diameter over guide: 290 mm - Hydraulic steady rest (following rest) Quill stroke 100 mm / MK4 mounting - Hydraulic steady rest SMW Autoblok - Hydraulic 3-jaw chuck 200 mm - Collet chuck Hainbuch Hnsdpfxozcd Hlj Aitjn - Chip conveyor - Parts catcher (disassembled / incomplete) - Complete programming manual - Mechanical and electrical documentation - Large accessory package of jaws / holders - Spare parts package (drive belts / small parts) - 2x foot switches - Machine weight: 5.2 t - Loading onto truck included

Condition: good (used), Year of construction: 1999, functionality: fully functional, turning diameter over cross slide: 450 mm, turning length: 580 mm, turning diameter: 300 mm, spindle speed (max.): 6,000 rpm, For sale: SPINNER TC46 CNC lathe, manufactured in 1999 and equipped with a Siemens Sinumerik control system. Hedpozar Nvsfx Aitenn The machine is in good technical condition and has been regularly maintained. It is suitable for precision turning operations and serial production of shafts, flanges and other turned components. Considering its age, the machine is well preserved and remains fully operational. Inspection under power is possible by prior appointment.

Condition: not inspected (used), Year of construction: 1999, rand: MORI SEIKI Type: ZL150SMC Year of build: 1998 Turning Ø: 440 mm Spindle boring Ø: 45 mm Speed till n=: 5000 rpm Number of tool changer stations: 24 Chip conveyor: true CNC control, brand, type: MSC501 Manual present: true Machine weight: 7000 kg Terms of delivery: Loaded on truck Hodpfozagrfex Aitsnn

Condition: good (used), Year of construction: 1999, CNC lathe Mori Seiki SL-150SY – MSC-501 Manufacturer: Mori Seiki Co., Ltd., Japan Model: SL-150SY Serial number: 1077 Year of manufacture: 1999 Weight : Approximately 4.4 tons Control system Mori Seiki MSC-501 (Fanuc 18) CRT display with softkeys MDI / EDIT / AUTO modes Axis display: X, Z, C, Y, B Operating time power on 55000h Operating time approx.: 20000h Machine configuration CNC lathe with Y-axis C-axis on main spindle Subspindle (dual spindle configuration) Turret head, 12 positions Prepared for/equipped with powered tools Closed work zone Capacity: Max turning length: Max turning length 350 Max turning diameter: 300 normally, Ø170 if there are more tools on the turret Rod diameter: approx. Ø 45 mm Spindle speed main and sub spindle: up to approx. 5,000 rpm Driven tools: 4000 rpm Revolver: 12 stations Y-axis travel: approx. ±40–30 mm Spindle & clamping Hydraulic chucks (Kitagawa) Foot pedals: 4 pcs (separate control for main and counter spindle) Main spindle + counter spindle Automatic transfer between spindles Media & systems Hydraulic unit Central lubrication Cooling system Chip conveyor Electrical data 3~ 200V 50Hz Installed power: 41 kVA Full load current: 119 A Spindle motor: 76 A Breaking capacity: 5 kA Control panel & operator interface Hnedezagqzepfx Aiton Full keypad Feed/spindle override MPG handwheel Key switch and safety interlock Condition / Function Regularly serviced machine Control system in operation, operated until it was recently disconnected. The brake on the main spindle can get stuck when operating with powered tools. Other CE marked Made in Japan

Condition: good (used), Year of construction: 1998, Used CNC turning lathe by Okuma Type: LCS 15 Includes tool holder Turning length: 280 mm Hodpsy U Iz Sefx Aitsnn Turning diameter: 270 mm Tool changer Year of manufacture: 1998 Excluding bar feeder and chip extraction system.

Condition: good (used), Year of construction: 2004, functionality: fully functional, Colchester CNC lathe Model Tornado T 220 S Year : 2004 Hodoy T E Tcspfx Aitjnn Turning lenght : 540 mm. Turning diameter : 290 mm. Sving over bed : 510 mm. RPM : 3500 Spindle borer : 66 mm. Tools in revolver :12 stk. Control : FANUC 21i - TB Chuck - Toolholder - Interface RS-232 C - Coolant

Operating hours: 68,816 h, condition: ready for operation (used), functionality: fully functional, overall weight: 5,500 kg, total length: 4,500 mm, total width: 1,950 mm, total height: 1,750 mm, torque: 263 Nm, turning diameter: 290 mm, bar diameter (max.): 72 mm, bar passage: 72 mm, chuck outer diameter: 200 mm, feed length X-axis: 212 mm, feed length Z-axis: 640 mm, quill diameter: 80 mm, quill stroke: 100 mm, rapid traverse Z-axis: 15 m/min, rapid traverse X-axis: 10 m/min, rotational speed (max.): 5,000 rpm, rotational speed (min.): 25 rpm, swing diameter over bed slide: 500 mm, swing diameter over cross slide: 290 mm, turning length: 640 mm, type of input current: three-phase, machine/vehicle number: 310142, Equipment: documentation/manual, Basic Data Manufacturer: Gildemeister Type: CTX 400 Machine No.: 310142 Year of Manufacture: Not specified, presumably early 1990s Control System: Gildemeister EPL / Grundig Operating Hours: 68,816 h Weight: 5,140 kg Dimensions L x W x H: 4,527 x 1,940 x 1,730 mm Connection: 400 V / 50 Hz Power: 45 kVA Turning Data Minimum Spindle Speed: 25 rpm Maximum Spindle Speed: 5,000 rpm Maximum Torque: 210 / 263 Nm Turning Diameter: 290 mm Turning Diameter over the Way Rest: 500 mm Turning Diameter over the Facing Slide / Facing Guide Cover: 290 mm Turning Length: 640 mm Bar Diameter / Spindle Bore: 72 mm Chuck Outer Diameter: 200 mm Axes / Travels Feed Travel X-axis / Facing Travel: 212 mm Feed Travel Z-axis / Longitudinal Travel: 640 mm Rapid Traverse X-axis: 10 m/min Rapid Traverse Z-axis: 15 m/min Y-axis: Not available / leave blank Tailstock Quill Diameter: 80 mm Quill Stroke: 100 mm Hodpfx Aoy Tx Awoitonn Quill Taper: MK 4 Maximum Quill Pressure: 800 daN Tool Holder Tool Stations: 12 Tool Holder: VDI 30 Powered Tools: Not available / do not enter C-axis: Not available / do not enter

Condition: excellent (used), Year of construction: 1999, 1 Nakamura-Tome WT-250 CNC lathe with dual spindle and dual turret 4 axes Hodpfxsy Ta Iuj Aitenn Year 1999 CNC: Fanuc Series 18i-T Supplied with 8 tool positions And all tooling and tool holders 1 Iemca MASTER 880/38/P bar feeder

Condition: excellent (used), Year of construction: 1998, 1 Nakamura-Tome WT-250 CNC lathe with dual spindles and dual turrets 4 axes Year 1998 Hnedpjy Ta Ihsfx Aitsn CNC: Fanuc Series 18i-T Supplied with 5 tool stations And all tooling and tool holders 1 Iemca MASTER 880/38/P bar feeder

Condition: used, Year of construction: 1988, functionality: fully functional, Equipment: documentation/manual, 2-axis CNC lathe, manufactured in 1988, compliant with CE standards FANUC 10-T CNC control Flat guides ASA 5" Bar capacity: 42mm Maximum turning diameter over the bed: 450mm Hnjdey S R E Ujpfx Aiton Maximum turning diameter: 250mm Maximum turning length: 400mm Maximum spindle power: 7.5Kw Weight approximately: 2,600 Kg Complete with: Hydraulic tool holder Tailstock 12-position automatic turret Presetting system Chip conveyor Bar feeder interface Part catcher

Condition: ready for operation (used), Year of construction: 2005, operating hours: 41,000 h, functionality: fully functional, machine/vehicle number: 178979, turning length: 309 mm, turning diameter: 280 mm, travel distance X-axis: 190 mm, travel distance Z-axis: 330 mm, controller model: Mazatrol 640T Nexus, No minimum price – guaranteed sale to the highest bidder! The technical data is based on the manufacturer's specifications. The seller cannot guarantee its accuracy! TECHNICAL DETAILS Max. turning diameter: 280 mm Max. machining length: 309 mm Swinging diameter: 550 mm Travel range X-axis: 190 mm Travel range Z-axis: 330 mm Spindle bore: 61 mm Rapid traverse rates X/Z: 30/33 m/min MACHINE DETAILS Control system: Mazatrol 640T Nexus Main circuit: 3-phase AC Main circuit voltage: 400 V Frequency: 50/60 Hz Control circuit AC: 100 V Control circuit DC: 24 V Main motor current draw: 31 A Main motor voltage: 400 V Rated power: 24 kVA Weight: 3,500 kg Operating hours: approx. 41,000 h Note: The bar feeder is not included in the offer. Hnsdpfsy Sln Rox Aiton

Condition: used, Year of construction: 2012, Lathe fully functional. Hnodpfxjy R Rdno Aiton

Condition: good (used), Year of construction: 1992, functionality: fully functional, turning length: 450 mm, turning diameter: 290 mm, spindle bore: 66 mm, travel distance X-axis: 190 mm, travel distance Z-axis: 450 mm, rotational speed (max.): 5,000 rpm, turning diameter over bed slide: 600 mm, Control: EPL Country of origin: Germany Hsdey N Tdzepfx Aitonn Spindle bore: Ø65 mm Tool turret: 12 driven stations Tool holder: VDI 40 Tool speed: 3,000 rpm Weight: approx. 4,700 kg + 600 kg control cabinet Chip conveyor: BMF Bürener Maschinenfabrik Bar feeder: GIOVANNI CUCCHI, type DB 70 Tools available at extra cost A total of 6 machines with bar feeders are available (price per machine with feeder) 1 machine without feeder available (€8,500)

Condition: used, Year of construction: 1998, functionality: fully functional, turning diameter over cross slide: 250 mm, turning length: 500 mm, turning diameter: 250 mm, spindle bore: 71 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 215 mm, travel distance Z-axis: 510 mm, rapid traverse X-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, total height: 1,800 mm, total length: 4,000 mm, total width: 1,900 mm, overall weight: 5,000 kg, CNC Fanuc 18i - T CAPACITY: Max bar working diameter: mm 54 Max turning diameter (re-chucking): mm 250 Max turning length: mm 500 Max swing diameter: mm 520 MAIN SPINDLE: Speed range: rpm 40 – 4,000 Spindle nose: ASA 6’’ Spindle bore: mm 80 Chuck diameter: mm 250 Motor power: kW 11/15 (50%) SUB-SPINDLE: Speed range: rpm 40 – 4,000 Spindle nose: ASA 5’’ Spindle bore: mm 52 Chuck diameter: mm 165 Motor power: kW 5.5/7.5 (50%) BI-DIRECTIONAL TURRET: Number of stations: 12 Indexing time: sec 0.6 LIVE TOOLS: Number of stations: 6 Speed range: rpm 50 – 3,000 Motor power: kW 3.7 (50%) C AXIS: Type: CS (direct) Minimum programmable increment: 0.001° Max rapid speed: rpm 80 AXES: X axis travel: mm 210 + 5 Z axis travel: mm 500 + 10 B axis travel: mm 510 + 5 Rapid traverse X: m/min 20 Rapid traverse Z: m/min 20 Rapid traverse B: m/min 24 COOLANT: Tank capacity: L 200 Pump flow rate: L/min 100 DIMENSIONS: Overall dimensions with chip conveyor: mm 4,000x1,900x1,800 h Weight with chip conveyor: kg 5,000 Machine equipped with: • Drilling kit with B-axis sub-spindle operating simultaneously with turning • 9 bar pump • Part catcher L 150 mm • Monitoring system Hnedpfx Ajy I A Imeiton • Spindle bore mm 71 • Collet holder, simple cone 42 • Chuck diameter mm 165 • Instruction manuals and CE declaration

Condition: good (used), Year of construction: 2011, functionality: fully functional, turning length: 225 mm, turning diameter: 260 mm, travel distance X-axis: 170 mm, travel distance Z-axis: 335 mm, rapid traverse X-axis: 36 m/min, rapid traverse Z-axis: 36 m/min, rotational speed (max.): 5,000 rpm, quill diameter: 60 mm, quill stroke: 80 mm, ATTENTION: A total of 3 machines available. There are 2 additional identical machines with the same equipment (chip conveyor, etc.). EQUIPMENT - Chip conveyor for side mounting and chip bin - Short bar loader magazine - Interface for bar feeder device - Workpiece catch tray (parts catcher) - Chuck confirmation switch (open/close) - C-axis indexing - Driven tools - Programmable tailstock - Linear guides - Manuals Control: Fanuc 0i-TD Control power-on hours: 30,811 h Machining time: 7,738 h Spindle motor power: 15/7.5 kW Feed motor power X/Z-axis: 3.0/1.8 kW Milling spindle motor power: 3.7/2.2 kW Max. turning diameter: 260 mm Max. turning length: 225 mm Chuck size: 6" Hnedpsy Hrngofx Aiton Swing diameter over bed: 550 mm X-axis travel: 170 mm Z-axis travel: 335 mm Rapid traverse X/Z-axis: 36 m/min Main spindle Spindle nose (ASA): A2-5 Max. spindle speed: 6,000 rpm Spindle bore diameter: 56 mm Max. bar capacity diameter: 45 mm Turret Number of turret stations: 12 positions Turret indexing time: 0.15 s Tailstock Quill diameter: 60 mm Quill stroke: 80 mm Taper bore/tailstock mounting: MT 4 Milling Spindle Max. spindle speed: 5,000 rpm Bar feeder magazine Model: Fedek Machine Co. DH-65 Bar length min./max.: 280/1,200 mm Bar diameter: 5-65 mm Dimensions Dimensions (L x W x H): approx. 1,620 × 1,200 x 1,400 mm

Condition: excellent (used), Year of construction: 2013, Swing 806mm, Swing over cross slide 527mm, maximum cutting diameter 305mm, 533mm maximum cutting length, 50mm Bar capacity, 8” chuck, 20Hp Spindle Motor, Hnedpfoy Ex T Tjx Aitsn C axis 0.01 degrees, Y axis +/- 51mm, 4000rpm spindle speed, 6,000rpm milling speed, 12 Station turret, parts catcher, tailstock, tool setter, coolant

Condition: excellent (used), Year of construction: 2013, Control Siemens Sinumerik 840D Max. turning diameter: 280 mm Max. bar capacity main spindle: 61 mm Hjdpfxey Aympj Aitonn Turning length: 490 mm Spindle speed main/sub spindle: 4700 / 6000 rpm 12-position turret with driven tools C-axis Y-axis Parts catcher Workpiece ejector Chip conveyor Various tool holders

Condition: good (used), Year of construction: 2006, Parts shown by hand not come with machine. Hnsdpfsyzyhqjx Aitsn

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, turning diameter over cross slide: 290 mm, turning length: 330 mm, turning diameter: 229 mm, spindle bore: 47 mm, spindle speed (max.): 5,000 rpm, travel distance X-axis: 138 mm, controller model: Fanuc GE 18i-T, Hardinge Conquest T42 CNC turning center (2000) Controller: GE Fanuc Series 18-T, live tooling, C-axis option noted, tailstock included, 12-station turret, Spindle bore 47.6 mm, Hjdoyzbivepfx Aitenn spindle speed 5,000 rpm, Max turning/machining diameter 229 mm, Max turning length 333 mm, X travel 138 mm, Z travel 350 mm.

Condition: excellent (used), Year of construction: 2011, CNC Lathe with y-axis MAZAK - QTN 250 MY MACH-ID 9483 Hsdjyyxzmjpfx Aitsnn Make: MAZAK Type: QTN 250 MY Control: Mazatrol Matrix Nexus Year: 2011 Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
