Condition: used, Year of construction: 2018, Milling machines Travel distance X: 1100 mm Travel distance Y :560 mm Travel distance Z: 510 mm Number of axis: 3 milling machine / machining center Control: HEIDENHAIN TNC 620 spindle chuck: SK 40 / ISO 40 spindle revolutions: 12000 rpm Speed range from: 20 U/min Speed range to: 12000 U/min Hfjdpfsz A Apuox Ac Ajl table size X: 1400 mm table size Y: 560 mm max. workpiece weight: 1000 kg tool changer: 30 - time input Power : 13 kW Rapid traverse: 30 m/min spindle cooling chip conveyor control Heidenhain DMG MORI CMX 1100 V Year of manufacture: 2018 3-axis vertical machining center HEIDENHAIN TNC 620 control 12 bar high-pressure coolant system 30-position tool magazine 30 ISO 40 tool holders included Chip conveyor Electronic handwheel Machine is currently under power Demonstration under power possible by appointment

Condition: excellent (used), Year of construction: 2015, operating hours: 28,000 h, functionality: fully functional, travel distance X-axis: 1,150 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 550 mm, spindle speed (min.): 14,000 rpm, operating hours of spindle: 14,500 h, coolant supply: 20 bar, number of slots in tool magazine: 30, Equipment: chip conveyor, documentation/manual, Machining center Deckel Maho DMC 1150V Technical data CNC control: Siemens Ergoline Travel in X-axis mm: 1150 Hfodpfxsz Ayg To Ac Ael Travel in Y-axis mm: 700 Travel in Z-axis mm: 550 Feed rates m/min: 42 Max. spindle speed rpm: 14000 Coolant supply through the spindle bar: 20 Tool holder: SK 40 Magazine: 30 Chip conveyor Tank capacity liters: 600 Measuring probe Infrared tool measurement TT140 Coolant gun Direct measuring system XYZ Operating hours: 26,600 h Spindle operating time: 11,000 h Base machine: Dimensions/Weight L/W/H mm: 3600 x 2300 x 2700 Weight kg: 5750

Condition: good (used), Year of construction: 1995, travel distance X-axis: 1,000 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, 4-axis machine Hfodpfxjz Aqx Ho Ac Ajl X-axis travel: 1000 mm Y-axis travel: 600 mm Z-axis travel: 600 mm Control system: Heidenhain TNC 426 Spindle nose: 100-700 mm Work table: 1,080 x 580 mm Maximum workpiece weight: 550 kg T-slots: 7 T-slot width: 14 mm Tool magazine with: 36 positions Maximum tool weight: 8 kg Maximum tool length: 340 mm Machine weight (approx.): 6.2 t Space requirement (approx.): 4,790 x 5,330 x 2,905 mm

Condition: ready for operation (used), Year of construction: 2011, operating hours: 16,140 h, functionality: fully functional, machine/vehicle number: 111214, travel distance X-axis: 1,100 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 610 mm, controller model: Heidenhain 530, overall weight: 7,800 kg, TECHNICAL DETAILS Travel range X-axis: 1,100 mm Travel range Y-axis: 610 mm Travel range Z-axis: 610 mm Number of positions in tool changer: 30 Table dimensions: 1250 x 610 mm MACHINE DETAILS Hodpfx Acjz Apdzs Asfl Control system: Heidenhain 530 Operating hours: 16,140 h Machine weight: approx. 7,800 kg

Condition: good (used), Year of construction: 2002, functionality: fully functional, MAZAK Vertical Machining Center VC-NEXUS 510 Year 2002 X-axis travel: 1020 Y-axis travel: 510 Z-axis travel: 510 Control unit: FUSION 640 Spindle speed: 12,000 rpm Hsdpfx Acez Akrts Ajfl Coolant pressure: 15 bar Spindle connection: ISO 40 Table width: 550 Table length: 1300 Number of tools (ATC): 30

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, Vertical machining center WELE Model CV-1060 Hfjdpfsz Akqpex Ac Ael Year 2016 Table size 1150 x 600 mm X-axis travel 1020 Y-axis travel 600 Z-axis travel 600 Number of tools (ATC magazine) 24 Maximum spindle speed 10,000 rpm Spindle power KW 7.5 - 11 Spindle connection BT 40 Rapid traverse rate X-axis 36000 Rapid traverse rate Y-axis 36000 Rapid traverse rate Z-axis 36000 High-pressure system through the spindle 15 Bar Automatic tool pre-setter Yes, contact type Chip conveyor SCREW CONVEYOR Machine dimensions 3550 x 2200 x 2230 mm Weight 5500 Kg

Condition: used, Year of construction: 2016, functionality: fully functional, machine/vehicle number: 0712-100481, feed length X-axis: 1,050 mm, feed length Y-axis: 560 mm, feed length Z-axis: 460 mm, controller manufacturer: Okuma, controller model: OSP, table width: 560 mm, table length: 1,300 mm, overall weight: 7,500 kg, type of input current: three-phase, Equipment: documentation/manual, For sale: used Okuma Genos M560R-V milling machine. X/Y/Z: 1050 x 560 x 460 mm, Table: 1300 x 560 mm Hjdoz Ahx Rjpfx Ac Aefl OSP control system VAT invoice provided. Please contact me for further details. Type: GENOS M560R-V Serial number: 0712-100481 Year of manufacture: 2016 Gross weight: 7500 kg

Condition: used, functionality: fully functional, Equipment: chip conveyor, documentation/manual, For sale here is a CNC machining center, DMC 1035V, including a Microset UNO tool measuring system, mounting bracket for the SK 40 tool holders, a tool cabinet, and approximately 140 tools and SK 40 tool holders. The machine is well-maintained and clean and has a 30-position tool changer, including a band filter system. The only defect on the machine is that the rotary through-spindle is leaking for the internal coolant supply (IKZ). Furthermore, the milling machine has a DXF converter and an offline programming station. Sold with VAT shown. No returns, no warranty. Hjdpfx Asz Ahgzec Ajfl

Condition: used, Year of construction: 1992, x-travel 1000 mm y-travel 500 mm z-travel 700 mm table surface area 1250 x 700 mm spindle tunring speed 20 - 3.200 U/min main drive motor 22 kW quill stroke 100 mm distance spindlenose - table min./max. 138/600 mm Feed ( x / y / z) 3.000 mm/min rapid traverse ( x / y / z ) 60/50/60 m/min total power requirement 27 kW In our opinion, the machine is in very good used condition and can be viewed under power by appointment. Accessories, tools and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Hfsdpfx Aezz S Rhsc Ael Changes and errors in the technical data and information as well Subject to prior sale!

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: AB1038, travel distance X-axis: 1,160 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 610 mm, controller model: Siemens Sinumerik 840D, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Hsdpfx Aszzx Hisc Aefl Travel range, X-axis: 1,160 mm Travel range, Y-axis: 610 mm Travel range, Z-axis: 610 mm Table length: 1,320 mm Table width: 610 mm Accuracy: ±0.01 mm Feed rate, X-axis: 30 m/min Feed rate, Y-axis: 30 m/min Feed rate, Z-axis: 30 m/min Spindle speed: max. 12,000 RPM MACHINE DETAILS Control system model: Siemens Sinumerik 840D Input voltage: 400 V Weight: 7,000 kg EQUIPMENT Chip conveyor Documentation Oil mist separator Note: The machine has undergone regular electronic and mechanical maintenance. New ball screws were installed approximately 1 year ago.

Condition: ready for operation (used), Year of construction: 2011, travel distance X-axis: 1,020 mm, travel distance Y-axis: 540 mm, travel distance Z-axis: 510 mm, overall weight: 6,800 kg, spindle speed (max.): 12,000 rpm, number of axes: 3, This 3-axis DOOSAN DNM 500 was manufactured in 2011. It features a table size of 1200 x 540 mm and impressive travels of 1020 mm in the X-axis, 540 mm in the Y-axis, and 510 mm in the Z-axis. The machine is equipped with a 30-position automatic tool changer and a spindle speed of 12,000 rpm. If you are looking to get high-quality machining capabilities, consider the DOOSAN DNM 500 vertical machining centre we have for sale. Contact us for further details. Table • Outer length: 1200 mm • Outer width: 540 mm • Full Load Current: 55.31 A • Interrupting Capacity: 5 kA • Short Circuit Withstand: 10 kA Hfjdpozzw Hnefx Ac Aol • Carousel/disc-type automatic tool changer • 30-position tool magazine loaded with tooling • Top-mounted mist extraction / air filtration unit (POSMA) • Machine status light tower

Condition: good (used), Year of construction: 2000, Hurco BMC 2416 Year of manufacture: 2000 Hedpfx Ajzzqwtsc Aofl Number of axes: 3 X-axis travel: 610 mm Y-axis travel: 406 mm Z-axis travel: 540 mm Ultimx control system

Condition: good (used), Year of construction: 2023, functionality: fully functional, Brother W-1000 XD1, Year of manufacture 2023 / Commissioned 2024, CNC control system, X/Y travel 1000/500 mm, Z travel 480 mm + column extension of 150 mm, 4-axis NC swivel head Brother T 200 with counter bearing, Spindle speed up to 16,000 rpm, BBT 30 tool holder, High-speed tool changer, 21 positions, Internal coolant pressure 15 bar, Side loading by robot, Twin chip disposal system, Extraction system, 2 x rotary joint, 4 channels, Hfodpjzzlmcjfx Ac Aol Workpiece clamping pressure 80 - 210 bar, Tool breakage monitoring Renishaw, Robot interface, Part clamping control, Robot cell, Fanuc robot, 6 axes - payload 25 kg, Automatic part loading and unloading via a 212-station pallet system.

Condition: used, Year of construction: 2013, x-travel 1020 mm y-travel 610 mm z-travel 610 mm control Heidenhain iTNC530 Hsdozzfb Hspfx Ac Ajfl

Condition: used, Year of construction: 2015, x-travel 1020 mm Hsdpfx Acszzfbms Aefl y-travel 610 mm z-travel 610 mm control Heidenhain iTNC530 weight of the machine ca. 7390 kg

Condition: used, Year of construction: 2011, Used 2011 Hardinge Bridgeport XR760. Supplied with Heidenhain iTNC 530 Control, 12,000 RPM Spindle with Through Spindle Coolant, 30 Station ATC, Renishaw spindle and table probing, Swarf Conveyor, Coolant Equipment & Manual Set. SPECIFICATION: TRAVELS: X Axis 760 mm, Y Axis 610 mm, Z Axis 610 mm Spindle Gauge Plane to Table (~ max) 710 mm, Spindle Gauge Plane to Table (~ min) 100 mm TABLE: Length 1000 mm, Width 600 mm Hfedjzzairjpfx Ac Asl T-Slot Width 18 mm, T-Slot Centre Distance 100 mm, Number of Std T-Slots 5, Max Weight on Table (evenly distributed) 900 kg SPINDLE: Max Rating 25 kW (S6 40%), Max Speed 12,000 rpm, Max Torque 159.2 Nm, Taper BT 40 Through Spindle Coolant, Coolant Flow Rate at Cutter 160 L/min, Through Spindle Coolant Pressure 20 bar (Std) FEEDRATES: Rapid and Jog (Max.) 20 m/min Cutting Feed Rate (Max.) 20 m/min BALL SCREWS: X & Y Axis 45 x 16 mm Z Axis 45 x 12 mm TOOL CHANGER: Type Rapid ATC, Capacity 30 Max Tool Diameter 125 mm (adjacent pocket), 80 mm Tool Length Max. 300 mm Tool Weight Max. 7 kg COOLANT & CHIP MANAGEMENT: Swarf Conveyor, Coolant Capacity 355 L Wash Down Standard, Wash Gun Standard, Cutter Air Blaster Standard Washdown Flow Rate 140 L/min ACCURACY – ISO 230-2: Positioning Accuracy 0.010 mm Repeatability 0.004 mm GENERALS: Machine Dimensions (W x D) 2528 x 3000 mm Air Required 4.9 cfm Power Supply 25 kVA / 415 V / 3 Phase / 50 or 60 Hz Control: Heidenhain iTNC 530 Spec: X760 Y610 Z610 mm | 12000RPM | BT40 Accessories: Renishaw Probing, Through spindle coolant, 30 Position Side mount tool changer, Swarf conveyor, Chilled 12000RPM Spindle

Condition: used, Year of construction: 2017, operating hours: 38,141 h, travel distance X-axis: 1,050 mm, travel distance Y-axis: 530 mm, travel distance Z-axis: 510 mm, controller manufacturer: Mazatrol, controller model: Smooth G, total height: 2,810 mm, total length: 3,650 mm, total width: 3,100 mm, table width: 550 mm, table length: 1,300 mm, table load: 1,200 kg, overall weight: 6,800 kg, spindle speed (min.): 12,000 rpm, spindle speed (max.): 35 rpm, operating hours of spindle: 8,074 h, coolant supply: 30 bar, number of slots in tool magazine: 30, input voltage: 19 V, Equipment: chip conveyor, documentation/manual, CNC Vertical Machining Centre CNC Control: Mazatrol Smooth G Machine tablesize: 1300 x 550 mm X-axis travel: 1050 mm Y-axis travel: 530 mm Z-axis travel: 510 mm Spindle speed: 35 - 12.000 rpm Spindle: SK40/DIN 67871A Spindle motor: 18.5/11 kW Positions in tool magazine: 30 and equipped, among other things, with - Chip conveyor belt right - Cooling by the spindle 15 bar - Spindle total time 8.074 hours Hedozy Nxgspfx Ac Ajfl If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, travel distance X-axis: 1,040 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, controller manufacturer: Heidenhain, controller model: TNC 530, workpiece weight (max.): 800 kg, total height: 2,800 mm, total length: 4,060 mm, total width: 2,450 mm, table width: 600 mm, table length: 1,250 mm, table load: 800 kg, overall weight: 8,800 kg, spindle speed (max.): 18,000 rpm, spindle nose: SK 40, number of slots in tool magazine: 30, Equipment: documentation/manual, oil mist separator, The machine is in very good condition, with an accuracy of 3/100. The spindle was replaced in 2017. It has had one owner and has undergone regular maintenance. It will be available in the last week of October, and the price includes loading and technical documentation. It features air conditioning for the electrical cabinet and spindle temperature control. Inspection or re-measurement can be arranged upon request. Hfodpfxezy D Hle Ac Asl

Condition: good (used), Year of construction: 2012, Machining center Eumach TVMC 2000 - 5-axis XYZ: 2000 x 750 x 750 mm A: 360 degrees B: 120 degrees Hfodpozy D Dqjfx Ac Ael Spindle speed: 14,000 rpm Spindle: SK 40 Weight: 22,000 kg

Condition: excellent (used), Year of construction: 2010, Machine type: - Deckel Maho DMC 1035 V ecoline - Year of manufacture: 2010 - Travel ranges: X: 1035mm, Y: 560mm, Z: 510mm Control system: - Siemens 810D / ShopMill control system - Electronic handwheel Spindle: - Tool holder: SK40 - Speed range: max. 10,000 rpm Tool magazine: - Tool changer with 20 magazine positions Table: - Fixed angular table - Clamping surface: 1200 x 560mm Operating hours: - Machine: 33,847 - Spindle: 11,026 Optional extras: - Chip conveyor - Coolant system: 20 bar - Coolant nozzle for chip flushing Delivery time: Hodpfezy Ab Usx Ac Asfl - Immediately or by arrangement

Condition: good (used), Year of construction: 2011, functionality: fully functional, DOOSAN DNM 400A – CNC vertical machining center, FANUC, year 2011 We offer for sale a DOOSAN DNM 400A CNC vertical machining center, equipped with a reliable DOOSAN-FANUC i Series control system. The machine is currently in operation and can be demonstrated and tested upon prior arrangement. Technical specifications: Manufacturer: Doosan Infracore Model: DNM 400A Year of manufacture: 05/2011 CNC control: DOOSAN-FANUC i Series X-axis travel: approx. 762 mm Y-axis travel: approx. 435 mm Z-axis travel: approx. 510 mm Work table dimensions: approx. 920 × 435 mm Max. table load: approx. 600 kg Spindle taper: BT40 / ISO 40 Max. spindle speed: approx. 8,000 rpm Automatic tool changer Coolant system Power supply: 380 V Rated power: approx. 27.4 kVA Machine weight: 4,500 kg Hjdpfx Aszyptdjc Aofl A universal CNC vertical machining center suitable for both single-piece and series production. The combination of a robust DOOSAN design and a FANUC control system ensures easy operation and good service availability. The machine is powered on and can be demonstrated in operation.

Condition: ready for operation (used), Year of construction: 2006, travel distance X-axis: 1,020 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, controller manufacturer: FANUC, controller model: MXP-200I, table load: 800 kg, spindle speed (max.): 8,000 rpm, number of slots in tool magazine: 30, number of axes: 4, This 4-axis YCM MV106A vertical machining centre was manufactured in 2006. It features a generous XYZ travel of 1020 x 600 x 600 mm and a robust table size of 1120 x 600 mm, with a maximum table load of 800 kg. The machine is equipped with a 30-tool automatic tool changer and coolant in the spindle. If you are looking to get high-quality machining capabilities, consider the YCM MV106A machine we have for sale. Contact us for further details. Hfjdpfx Aozx Th Ajc Ael Technical Specification Taper Size SK 40

Condition: used, Year of construction: 2018, operating hours: 19,432 h, travel distance X-axis: 1,050 mm, travel distance Y-axis: 530 mm, travel distance Z-axis: 510 mm, controller model: Mazatrol Smooth G, workpiece weight (max.): 1,200 kg, total height: 2,810 mm, total length: 3,650 mm, total width: 3,100 mm, table width: 550 mm, table length: 1,300 mm, overall weight: 6,800 kg, spindle speed (min.): 35 rpm, spindle speed (max.): 12,000 rpm, operating hours of spindle: 3,454 h, number of slots in tool magazine: 30, input voltage: 19 V, Equipment: chip conveyor, documentation/manual, CNC Vertical Machining Centre CNC Control: Mazatrol Smooth G Machine tablesize: 1300 x 550 mm X-axis travel: 1050 mm Y-axis travel: 530 mm Z-axis travel: 510 mm Spindle speed: 35 - 12.000 rpm Spindle: SK40/DIN 67871A Hfjdpfxozx S I Ue Ac Ajl Spindle motor: 18.5/11 kW Positions in tool magazine: 30 and equipped, among other things, with - Chip conveyor belt left - Cooling by the spindle 15 bar - Kitagawa NC Rotary table MR 200 - Spindle total time 3.454 hours If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: excellent (used), Year of construction: 2024, operating hours: 250 h, functionality: fully functional, travel distance X-axis: 1,050 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, feed rate X-axis: 36,000 m/min, feed rate Y-axis: 36,000 m/min, feed rate Z-axis: 36,000 m/min, controller manufacturer: Mazatrol SMOOTHEZ, workpiece weight (max.): 1,200 kg, total height: 2,938 mm, total length: 3,816 mm, total width: 2,902 mm, table width: 600 mm, table length: 1,300 mm, table load: 1,200 kg, overall weight: 7,000 kg, operating hours of spindle: 250 h, spindle motor power: 18,500 W, 3-axis CNC machine (VMC) MAZAK - VCE-600 MACH-ID 9803 Make: MAZAK Type: VCE-600 Control: Mazatrol SMOOTHEZ Year: 2024 Only 250 Spindle Hours  ATC 48 Position Optional Lehmann EA-520 R-Mi4 4e axis integrated Optional Lehman Tailstock  Grundfos IKZ 20 Bar Renishaw 3D Tool probe Renishaw Length probe  Optional tooling package ca 30 units Optional SCHUNK KONTEC KSG Machine vice (4 units) New EUR 200.000 X - Travel: 1050mm Y - Travel: 600mm Z - Travel: 600mm Table Length: 1300mm Table Width: 600mm Table load: 1200 Feed rate X-Axis: 36000mm/min. Feed rate Y-Axis: 36000mm/min. Feed rate Z-Axis: 36000mm/min. Spindle Taper: 40ISO/Bt/Mk Power on spindle: 18.5kW Speeds / ranges: 12000Rpm ATC / revolver: 48 Hfsdpjzx Sprsfx Ac Ael Coolant through spindle / Bar:20 Number of controlled axis: 3+1 Chip conveyor: Yes Coolantsystem: Yes Length: 3816mm Width: 2902mm Height: 2938mm Weight: 7000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Year of construction: 2009, Technical details: x-travel: 1100 mm y-travel: 600 mm z-travel: 510 mm control: Heidenhain iTNC 530 table-size: 1050 x 600 mm table load: 500 kg spindle taper: SK 40 turning speeds: 10000 1/min Hedpfx Ajzxz Evec Aefl power capacity at 100 % load: 9 kW rapid travel x/y/z: 24 m/min feed: 24 m/min Tool changer: 40 SK 40 dimensions of the machine ca.: 4,3 x 2,6 x 2,25 m weight of the machine ca.: 8,8 t POS mill 1100 vertical machining center in very good condition from 2009 Options: - parts measuring M&H receiver without probe - external hand wheel Heidenhain HR 410 - Air supply through spindle - air gun - paperfilter system with coolant through spindle 40 bar - *
