SIRtec GmbH

Condition: good (used), Year of construction: 1999, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,150 mm, total length: 6,000 mm, total width: 5,200 mm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 10 m/min, Control: Siemens 840 D Powerline Tool holder: HSK-A63 Max. rpm: 16,000 X-travel: 3,000 mm Y-travel: 2,500 mm Z-travel: 1,150 mm Kdjdexx Twkspfx Aayow A-axis: +/- 100 mm C-axis: +/- 181.5 mm Table size: 3,000 mm x 2,500 mm Option: External blowing air Kinematics: Fork head

Condition: excellent (used), Year of construction: 2013, operating hours: 64,269 h, functionality: fully functional, travel distance X-axis: 2,200 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,000 mm, table length: 2,300 mm, table width: 1,600 mm, spindle speed (max.): 20,000 rpm, overall weight: 30,000 kg, For sale is a well-maintained Parpas Diamond Linear. – C-axis (milling head): (degrees) +/- 370 – A-axis (milling head): (degrees) +/- 105 Distance between columns: (mm) 2,700 Distance between table surface and spindle nose with milling head mounted, max.: (mm) 1,220 – X and Y axis rapid traverse: (m/min) 60 – Z axis rapid traverse: (m/min) 40 Spindle: 5-axis orthogonal milling head – Internal coolant supply (ICS): (bar) 20 – Maximum spindle speed: (rpm) 20,000 – Drive power S1 / S6: (kW) 29 / 37 – Torque S1 / S6: (Nm) 92 / 115 Tool magazine – Tool holder: HSK 63 A – Tool positions: 42 – Tool diameter: (mm) 80 – Tool length: (mm) 350 – Tool weight: (kg) 6 Machine table – Table size L x W: (mm) 2,300 x 1,600 – T-slot spacing: (mm) 200 – T-slot dimensions: (mm) 22 – Max. workpiece weight: (kg/m²) 6,000 FEATURES & EQUIPMENT + Heidenhain iTNC 530 control + Portal (gantry) design: U-shaped "monoblock" construction with one crossbeam and stationary workpiece + Milling head (A- and C-axis), A-axis with torque motor and hydraulic clamping, A-axis positioned perpendicular to the C-axis + No foundation required + Glass scales in X, Y, and Z linear axes + C-axis with Heidenhain angle measurement system, resolution 0.001 degrees + Heidenhain HR 520 electronic handwheel + 2 chip conveyors (one at the front and rear of the table) + Internal coolant supply (ICS) 20 bar + Paper filter unit + Sliding roof with opening for loading and unloading Kedpfexxvp Nex Aayjdw

Condition: good (used), Year of construction: 2012, Ref. -No.: 10290 Manufacturer: KOLB KLUEPPELBERG Type: Cubimat YC 2000 Year of construction: 2012 Type of control: CNC Control: Siemens Sinumerik 840 D Storage location: Halberstadt Country of origin: Deutschland Machine number: 016453-20.1 Kdjdpfsxxn Uqjx Aayow X-Travel: 7000 mm Y-Travel: 4000 mm Z-Travel: 4000 mm W-Travel: 2.000 mm Speed work spindle: 4.000 RPM Max. Torque: 2.100 Nm Max. Workpiece Weight: 20 t Table-Size (Lxw): 2.800 x 2.000 mm Table load max.: 18.000 kg Tool Taper: SK 50 Tool places: 360 Distance Between Columns: 3.200 x 4.000 mm Further information: - 4 milling heads available - 1 universal head - Pick Up Head Station The machine can be viewed under power by arrangement.

Condition: used, Year of construction: 2010, travel distance X-axis: 3,020 mm, travel distance Y-axis: 1,520 mm, • Monoblock structure in welded steel with a mobile gantry in steel. Kdjdpjxxii Aefx Aayew • Processing speed up to 18 m/min. • Worktable: fixed table made of high-thickness aluminum profiles. • Hardened linear guides and preloaded ball-bearing carriages. • Transmission via precision ball screws on all 3 axes. • CN7000 numerical control with touch screen and brushless servo drives. • Available in 5 sizes for maximum flexibility. • Z 350 option for 3D applications. • Quality and performance suitable for good productivity. • Well-known ease of use. • Compliant with European safety regulations. • Numerous options: brushless servomotors, micro-lubrication, automatic tool changer, vacuum table (with turbine or vacuum pump), high-frequency spindles, contact engraving spindles, fourth axis.

Condition: used, Year of construction: 2014, functionality: fully functional, For sale is a Steelcut precision CNC gantry milling machine. The machine has been regularly serviced and is in excellent visual and technical condition. It is fully functional, inspected, and ready for immediate use. Our service promise: Quality, expertise, and customer satisfaction are our top priorities. Our team consists of qualified and experienced technicians who specialize in Mazak machines as well as other brands. We place great value on personalized support and are always happy to assist you even after your purchase. With us, you are in the best hands – professional, reliable, and passionate about machinery! PS CNC Service Germany GmbH & Co. KG Kjdpfxjxwa A Rs Aaysdw All details provided without guarantee.

Condition: used, Year of construction: 2020, functionality: fully functional, travel distance X-axis: 850 mm, travel distance Y-axis: 570 mm, travel distance Z-axis: 250 mm, For sale is a used, but like-new SK0805 gantry milling machine. The machine has been regularly serviced at all times and is in excellent visual and technical condition. It is fully functional, tested, and ready for immediate operation. Kodjxwau Hjpfx Aaysdw Our service commitment: For us, quality, expertise, and customer satisfaction are top priorities. Our team consists of qualified and experienced technicians specializing in Mazak machines as well as other machinery. We place great value on personal support and are happy to assist you at any time, even after the purchase. With us, you are in the best hands – professional, reliable, and passionate about machines! PS CNC Service Germany GmbH & Co. KG All information without guarantee.

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 6,000 mm, travel distance Z-axis: 1,250 mm, spindle speed (max.): 12,000 rpm, controller model: Heidenhain iTNC530 mit Handrad, Machine with 4th axis as a swivel axis & regularly serviced by the machine manufacturer! TECHNICAL DETAILS Working areas X-axis: 3,000 mm Y-axis: 6,000 mm Z-axis: 1,250 mm Milling head A-axis: controllable, tiltable Milling spindle Spindle power: 4.4 kW Kedjxvx U Ajpfx Aayodw Spindle speed: 12,000 rpm Tool holder: 78/8 flange Tool clamping: manual with clamping nut Linear axis drives Feed rate X, Y, Z axes: up to 20 m/min Axis acceleration X, Y, Z axes: up to 1.5 m/s² MACHINE DETAILS Control: Heidenhain iTNC530 with handwheel Connected load: approx. 25 kW Main fuse: 42 A Dimensions & Weight Space requirement for machine: approx. 5,500 x 9,000 x 4,500 mm Total weight: 9,600 kg FEATURES Conversion to high-frequency spindle possible Important: Table and the wooden board shown in the photos are not included in the scope of delivery.

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 3.6002, travel distance X-axis: 4,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 6,000 rpm, table load: 12,000 kg, TECHNICAL DETAILS X axis: 4,000 mm Y axis: 3,000 mm Z axis: 1,500 mm Passage height: 1,550 mm Passage width: 2,500 mm Table width: 2,000 mm Table length: 3,000 mm Kodpfx Aaoxvrb Neysdw max. table load: 12,000 kg Tool holder: HSK-A100 max. tool weight: 30 kg max. tool diameter: 250 mm max. tool length: 500 mm Drilling spindle speed range: 5–6,000 rpm max. permissible torque at milling spindle: 800 Nm MACHINE DETAILS Total power requirement: 30 kW Space requirement approx.: 9.5 x 6.7 x 6.2 m EQUIPMENT Demmeler pallet changer

Condition: excellent (used), Table length: 8000mm Kjdpoxuz D Rsfx Aayjdw Table width: 2500mm Between columns: 3100mm Weight of workpiece: 65t Weight: 127t

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, travel distance X-axis: 2,200 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 18,000 rpm, CNC: Heidenhain TNC 530 TRAVELS Longitudinal: 2.200 mm (+220) Transverse: 1.500 mm (+220) Vertical: 1.000 mm FEEDS Rapid feeds X, Y: 40.000 mm/min Rapid feeds Z: 30.000 mm/min MAXIMUM ACCELERATIONS Acceleration X, Y, Z: 7.000 mm/sec Kjdpjxtqucefx Aayedw AXIS ROTATION C-axis rotation: ±400° (continuous positioning) A-axis rotation: ±105° (continuous positioning) TABLE Table dimensions: 2.300 x 1.600 mm Permitted load: 20.000 kg Machine weight: 30.000 kg Machine complete with: • Milling head 5-axis milling TOE 24 18.000 rpm HSK63 • Tool changer • Through-tool coolant • Chip conveyor • Instruction manuals and CE declaration

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, travel distance X-axis: 3,200 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 920 mm, table length: 3,000 mm, table width: 1,700 mm, spindle speed (max.): 6,000 rpm, HURCO WinMax Dual CNC TRAVELS Longitudinal travel: 3.200 mm Transverse travel: 2.100 mm Vertical travel: 920 mm WORK AREA Table dimensions: 3.000 x 1.700 mm Table load capacity with uniform distribution: 11.000 kg SPINDLE Maximum spindle power: 60 kW (1 min) Maximum spindle torque: 570 Nm at 1.000 rpm (1 min) Maximum spindle rotation speed: 6.000 rpm Tool holder: ISO 50 DIN 69871 Machine complete with: • 40-station tool magazine • Digital motors and drives (axes and spindle) • Thermal conditioning system for headstock temperature control Kdodpfx Aajxtqtloyew • Coolant system with supply around the spindle • Water wash gun and water gun Compressed air • Chip evacuation system consisting of a double auger and evacuator • Complete enclosure • Instruction manuals and CE declaration

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 1,750 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 600 mm, table length: 1,200 mm, table width: 1,000 mm, spindle speed (max.): 22,000 rpm, table load: 3,000 kg, Heidenhain TNC 640 CNC Kodpfoxtqq Rsx Aayodw TRAVELS Longitudinal travel: 1.750 mm Transverse travel: 1.400 mm Vertical travel: 600 mm Feed speed: 35.000 mm/min Acceleration: 6 m/sec WORK AREA Table dimensions: 1.000 x 1.200 mm Table load capacity: 3.000 kg Distance between table and spindle nose: 205-805 mm Maximum horizontal passage: 1.430 mm Work table height from ground: 855 mm DIMENSIONS Maximum height: 3.850 mm Base module dimensions: 6.000 x 4.000 mm Floor area: 24 m2 ELECTROSPINDLE S1 power: 26 kW – 1500 HP 18.5 Maximum spindle torque S1: 105-12 Nm Maximum spindle rotation speed: 22.000 rpm Tool holder: HSK A63 E40 Machine complete with: • 5-axis direct-drive universal milling head with continuous movement of the two bodies • Tool changer • Instruction manuals and CE declaration

Condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 3,400 mm, travel distance Z-axis: 1,000 mm, distance between stands: 2,000 mm, controller model: Siemens 840D SL, TECHNICAL DETAILS Axes: 5 controlled Kdjdsxtb Sxopfx Aayow X travel: 4,000 mm Y travel: 3,400 mm Column clearance: 2,000 mm Z travel: 1,000 mm Control: Siemens 840D SL Spindle power: 37 kW Speed range: 12–2,800 rpm Distance spindle to clamping surface: 280–1,280 mm Taper: ISO SK-50 Table size (longitudinal): 3,000 mm Table size (cross): 1,500 mm C-axis swivel range: 0–360° (in 1° increments) Swivel range: 90°–0°–90° (in 1° increments) MACHINE DETAILS Total power requirement: 70 kVA Machine weight: approx. 82 t Footprint: approx. 10,200 mm x 7,200 mm x 5,925 mm EQUIPMENT Automatic tool changer for 60 tools 1 universal milling head, 1,750 Nm

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, travel distance X-axis: 6,000 mm, travel distance Y-axis: 2,700 mm, travel distance Z-axis: 1,250 mm, spindle speed (max.): 24,000 rpm, table load: 15,000 kg, Submitting a bid obliges the buyer to collect the machine by the deadline of 27.11.2025! The machine can still be inspected under power until week 47. The new spindle was installed in 2025! Additionally, the tool changer was retrofitted in 2025. The CNC control was upgraded in 2014! TECHNICAL DETAILS Working Areas X-axis: 6,000 mm Y-axis: 2,700 mm Z-axis: 1,250 mm Clamping Table Table dimensions (L x W x H): 6,600 x 2,740 x 520 mm Table load capacity: max. 15,000 kg T-slots and spacing: 10 x 22H8 / 255 mm Spindle Spindle power: 10 kW Spindle speed: 24,000 rpm Tool holder: HSK 63F Tool clamping: pneumatic Torque: 8.7 (S1) and 10.5 (S6) Nm Suitable materials: wood, plastic, aluminium Linear Axis Drives Feed rate X, Y, Z axes: max. 20 m/min Axis acceleration: max. 1.5 m/s² MACHINE DETAILS Control: Heidenhain iTNC530 with electronic handwheel Kdodpexr U Drjfx Aayew Connection Data Power requirement: 28 kW Main fuse: 63 A Dimensions & Weight Required floor space: 10,000 x 5,000 x 4,500 mm Total weight: 28,000 kg EQUIPMENT Double-sided enclosure with two doors 6-position tool changer

Condition: good (used), Year of construction: 2005, travel distance X-axis: 3,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,000 mm, Unisign Uniport 6000 portal milling machine, year of manufacture 2005, Siemens 840 D control, travel range X/Y/Z 3000/3000/1000 mm, C axis for turning operations, table Ø 2500 x 2000 mm, Kdjdpfx Aaexqmduoysw max. turning diameter Ø 3000 x 2500 mm, max. turning height 1000 mm, angle head for lateral machining, 2.5° Hirth coupling, spindle speed up to 6,000 rpm, spindle power 36 kW, taper HSK 100, tool changer with 30 positions, 3D measuring probe, chip conveyor, faceplate Ø 2000 mm, max. faceplate load 10,000 kg, machine weight 45,000 kg,

Condition: good (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 6,000 mm, travel distance Y-axis: 3,400 mm, travel distance Z-axis: 1,500 mm, table length: 6,000 mm, table width: 3,000 mm, spindle speed (min.): 3,000 rpm, A CNC portal milling machine FKD-Feichter with double column is available. Travel range X/Y/Z/W: 6000mm/4800mm/1500mm/1300mm, table dimensions X/Y/Z: 6000mm/3000mm, max. workpiece weight: 115,000kg, max. table load: 6,400kg/m², total machine bed length: 14,500mm, portal dimensions X/Y: 3,000mm/4,400mm, C-axis: 360°, A-axis: +/-120°, ram section: 700mm/700mm, feed rate: 10m/min. Total system dimensions X/Y/Z: approx. 15,100mm/6,100mm/7,000mm, total system weight: approx. 115,000kg, control system: Heidenhain. Includes chip guard, coolant system, and hydraulic unit. The machine was built at the site in 2022. The ram and spindle have been freshly overhauled. Documentation is available. On-site inspection is possible. Immediately available. Kodjxp Rgkopfx Aayodw Three heads: Fork milling head with A-axis, 90-degree angular head, spindle extension – straight head, tool holder SK 50.

Condition: like new (used), Year of construction: 2014, functionality: fully functional, Milling, Turning, 5-Axis Simultaneous Machining Siemens 840D sl General X travel: 2300 mm Y travel: 1600 mm Z travel: 900 mm Swivel Head Type: 1-axis continuously adjustable swivel head or full interpolation Swivel movement: via B-axis B-axis swivel range: 0° to -90° Indexing: 0.001° Swivel radius (pivot point to spindle nose): 290 mm Machine Table Clamping surface rotary table: Diameter 1600 mm NC Rotary Table: AXA RTA 6D, faceplate 1600 mm T-slots: 18 mm H9, reference slot H7 T-slot layout: radial/star-shaped T-slot spacing: 80 mm Table load – positioning mode: Max. 5000 kg at max. 10 rpm Table load – rotary mode: Up to 2500 kg Rotary speed: Up to max. 250 rpm Measuring system: Direct measuring system, accuracy +/- 1 second Tool Changer (SK50) Type: Side-mounted chain magazine, located outside the working area Tool holder: SK 50, DIN ISO 7388-1 AD / DIN ISO 7388-3 AD Tool stations: 60 (Tower 1 / 1st chain = 30 places, Tower 2 / 1st chain = 30 places) Max. tool diameter (standard): Max. 110 mm Tool diameter with adjacent stations free: Max. 180 mm Tool length: Max. 400 mm Tool weight: Max. 15 kg per tool Weight in gripper: Max. 15 kg Tool Changer (CAPTO C6) Type: Second magazine chain in XTS turret for turning tools Tool holder: CAPTO C6 Tool stations: Tower 1 / 2nd chain = 12 places Max. tool diameter (standard): Max. 85 mm Tool diameter with adjacent stations free: Max. 135 mm Tool length: Max. 400 mm Tool weight: Max. 8 kg per tool Spindle & Drives Feed force X/Y/Z: Max. 9000 N Rapid traverse X/Y/Z: 30/30/25 m/min Feed rate X/Y/Z: Standard 1 - 9999 mm/min Power: Max. 56 kW at 40% duty cycle Torque: Max. 355 Nm at 40% duty cycle Kdodpfx Aaoxp Izfeysw Speed range: Up to max. 9000 rpm Critical speed: 1500 rpm Other features: Two hinged belt chip conveyors, rear discharge. Discharge height approx. 1250 mm. Internal coolant supply through the spindle. Suitable for coolant pressure up to 30 bar. Complete machine enclosure with powered doors Further details available upon request The technical specifications were prepared to the best of our knowledge. No liability is assumed for correctness. We recommend inspecting the machine. Please call to schedule an appointment.

Condition: used, Year of construction: 2018, functionality: fully functional, X-axis: approx. 3,100 mm Y-axis: approx. 2,100 mm Z-axis: approx. 1,000 mm A-axis: ±110° C-axis: ±360° Control unit: Heidenhain TNC 640 with HR 520 handwheel Clamping table Clamping surface: approx. 3,100 x 2,100 x 213 mm Aluminum with transverse T-slots at 250 mm intervals Max load: 1,000 kg evenly distributed across the entire surface 2-axis milling head ST8 Spindle power: 15 kW Spindle speed: max. 24,000 rpm Torque: 20.9 Nm Tool holder: HSK 63F Tool release: pneumatic Blow air: external Linear axis drives Feed rate X and Y axes: up to 60 m/min Feed rate Z axis: up to 40 m/min Accuracies Positioning accuracy: 0.10 mm Repeatability: 0.05 mm Colour Enclosure, gantry, control cabinet: light grey Z-carriage and milling head: blue Additional equipment - 15-position tool changer - Oriented milling spindle (e.g. for thread cutting) - Direct path measuring system on all 5 axes - Double-sided enclosure - Heidenhain TT140 (optional, at extra cost) - Heidenhain TS260 (optional, at extra cost) - 3D machine model (optional, at extra cost) Kdodpfexm Tv Asx Aayew Machine condition Fully functional, immediately available, still under power until November 2025

Condition: new, Year of construction: 2025, Ref. -No.: 10463 Manufacturer: IGREK Type: FR 3500 XL Year of construction: 2025 Type of control: CNC Control: Siemens 840 D / Heidenhain iTNC 640 Storage location: Istanbul Country of origin: Türkiye X-Travel: 6500 mm Y-Travel: 3500 mm Z-Travel: 1400 mm A-Axis: +/- 115 ° C-Axis: 360 ° Turning Speeds: 12500 RPM Max. Torque: 235 Nm Rapid Traverse X/Y/Z: 30 m / min Table-Size (Lxw): 2290 - 6490 x 3580mm mm Drive power spindle: 54 kW Table load max.: 4000 kg Tool Taper: HSK-A100 Machine length: 11500 mm Machine width: 7400 mm Machine Height: 6600 mm Weight: 120 t Further information: IGREK FR 3500 XL – Precision and performance at the highest level The IGREK FR 3500 XL is a CNC-controlled 5-axis portal milling machine of the latest generation (year of manufacture 2024). It was specially developed for the demanding machining of large workpieces and impresses with its versatility and precision. With a modern control system from Siemens 840D or Heidenhain iTNC 640 and a robust construction, the machine offers optimal conditions for manufacturing in a wide range of industries. Key features: Large machining areas: With travel distances of 6,500 mm (X), 3,500 mm (Y) and 1,400 mm (Z), the machine is ideal for machining large components. 5-axis simultaneous machining: The A-axis with a swivel range of +/- 115° and the C-axis with a rotation of 360° enable highly precise machining of complex geometries. Powerful spindle: The spindle reaches speeds of up to 12,500 rpm and a maximum torque of 235 Nm – perfect for demanding milling work. High stability: The machine weight of 120 tons and the table load of up to 4,000 kg ensure low-vibration machining even with heavy workpieces. Flexible tool holding fixture: The HSK-A100 tool holding fixture enables quick tool changes and optimal process times. Rapid feed rate: High productivity is achieved with 30 m/min in the X, Y and Z directions. Kdsdpfx Aasxmd Szjyew Technical data at a glance: Table size: 2,290 – 6,490 x 3,580 mm Spindle power: 54 kW Max. torque: 235 Nm Tool holder: HSK-A100 Machine dimensions (LxWxH): 11,500 x 7,400 x 6,600 mm Max. table load: 4,000 kg The IGREK FR 3500 XL sets new standards in the machining of large parts. It is available immediately and offers comprehensive warranties and services directly from the manufacturer, internationally and across the board. Use the latest technology for your production – contact us for further details!

Condition: good (used), Year of construction: 2015, functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,000 mm, feed rate X-axis: 85 m/min, feed rate Y-axis: 85 m/min, feed rate Z-axis: 40 m/min, table length: 3,500 mm, table width: 2,000 mm, spindle speed (max.): 28,000 rpm, table height: 250 mm, rapid traverse X-axis: 85 m/min, rapid traverse Y-axis: 85 m/min, rapid traverse Z-axis: 40 m/min, table load: 5,000 kg, torque: 70 Nm, rotational speed (max.): 28,000 rpm, overall weight: 22,000 kg, Equipment: rotational speed infinitely variable, Year of manufacture: 2015 X-axis: approx. 2,500 mm Y-axis: approx. 3,000 mm Z-axis: approx. 1,000 mm A-axis: +/- 115° C-axis: +/- 270° Control system: SIEMENS SINUMERIK 840D SL Clamping table, subfloor Length x Width x Height: approx. 3,500 x 2,000 x 250 mm (cast iron) Table load: max. 5,000 kg/m² T-slots: 22H12 T-slot spacing: 250 mm Milling spindle Spindle power S1 / S6: 40 / 54 kW Spindle speed: max. 28,000 rpm Tool holder: HSK 63A Torque S1 / S6: 51 / 70 Nm Linear axis drives Feed rate X and Y axes: up to 85 m/min Feed rate Z axis: up to 40 m/min Connection data Connected load: approx. 55 kW Line protection: 45 A Dimensions, weights Machine footprint: approx. 6,650 x 6,200 x 5,000 mm Total weight: 21,000 kg Description: Additional equipment - 2x chip conveyors - Protective bellows with compressed air sealing - 40 bar ICS coolant supply with belt filter system - Minimum quantity lubrication - 30-position tool changer Optional - Renishaw RMP60 Condition of the machine Fully functional condition, regularly serviced by the manufacturer. Immediately available and still connected to power. Special note Kdodpfx Aexl Tl Usayew The machine requires a special foundation so that the table and chip conveyors can be recessed into the floor.

Condition: excellent (used), Year of construction: 2008, operating hours: 82,500 h, functionality: fully functional, travel distance X-axis: 5,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,750 mm, feed rate X-axis: 65 m/min, feed rate Y-axis: 65 m/min, feed rate Z-axis: 65 m/min, spindle speed (max.): 20,000 rpm, rapid traverse X-axis: 65 m/min, rapid traverse Y-axis: 65 m/min, rapid traverse Z-axis: 65 m/min, torque: 63 Nm, overall weight: 90,000 kg, Equipment: rotational speed infinitely variable, First commissioning: 2008 Control system: Heidenhain iTNC 530 incl. HR420 handwheel X-axis: approx. 5,000 mm Y-axis: approx. 3,000 mm Z-axis: approx. 1,750 mm A-axis: -120 / +95° C-axis: ±360° Maximum workpiece dimensions 3,800 mm (X-direction) 1,800 mm (Y-direction) 1,150 mm (Z-direction) 5-axis machining is possible in a single setup with a 300 mm long tool (A-axis at 90° swivel). Machine operating hours: approx. 82,500 h Total spindle hours: approx. 36,500 h Kdsdoxl R Hvjpfx Aaysw Clamping table No machine table is included in the delivery. However, we are happy to offer a customer-specific solution at extra cost. 2-axis fork-type milling head 5 Spindle power: 20 kW Spindle speed: max. 20,000 rpm Torque: max. 63 Nm Tool holder: HSK 63A Tool release: hydraulic Holding torque (clamped) A & C axis: 2,000 Nm Drives, linear axes Feed rate X, Y, and Z axis: up to 65 m/min Axis acceleration X, Y, and Z: up to 5 m/s² Connection data Voltage: 400 V Frequency: 50 Hz Power requirement: 130 kW Dimensions, weight Space required machine without peripherals: approx. 7,500 x 8,500 x 6,600 mm Total weight: approx. 90,000 kg Colour Enclosure, portal, control cabinet: RAL 7035 light grey Milling head and applications: RAL 5002 aquamarine blue Additional equipment - Minimum quantity lubrication - 50-fold tool changer - Work area enclosure Optionally available at extra cost: - Renishaw RMP60 probe - BLUM LaserControl NT mini Condition of the machine Fully functional, in very good condition. Can be inspected under power until April 2026.

Condition: like new (used), Year of construction: 2010, Retrofitted: 2025/2026 Numerical control: HEIDENHAIN TNC-i530 Ksdjxllilspfx Aayedw Technical features Dimensions Table dimensions: 8500 x 2500 mmNumber of T slots: 17T slots dimensions: 22 mm Traverses of axis X axis traverse: 8000 mmY axis traverse: 3800 mmZ axis traverse: 1500 mmVertical capacity (VC): 168 / 1668 mmDistance between columns: 3100 mm Milling head Auto-indexing differential head UAD (every 0,02º)Tool clamping system: HydraulicTaper nose: ISO50 (DIN69871) / Pull stud: DIN69872Speed range: 6000 rpmSpindle power: 30 kW Feedrates Rapid feedrate (X / Y,Z): 7200 / 12000 mm/min Weight and dimensions Maximum weight on table: 35000 kgMachine weight approximate: 79000 KgMachine dimensions approximate: 22700 x 7660 x 6800 mm Accesories Guarding: 2 sliding doors with a new perimetral wire-mesh safety fenceAutomatic tool changer: ATC-60Chip conveyor: 2longitudinal hinge typeElectronic handwheel: New HR-510Coolant: External internal high pressure through spindle Sales conditions Guarantee: 6 months mechanical spare partsPrice and sale conditions: On request View all technical features

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 6,000 mm, travel distance Y-axis: 3,200 mm, travel distance Z-axis: 1,400 mm, table length: 6,000 mm, table width: 3,000 mm, spindle speed (max.): 24,000 rpm, distance between stands: 4,000 mm, Technical Specifications Kdodpfx Asxlip Ajayew • Table clamping area: 6,000 × 3,000 mm • X-axis (longitudinal travel): 6,000 mm • Y-axis (cross travel): 3,200 mm • Z-axis (vertical travel): 1,400 mm • Distance between columns: 4,000 mm • Feed speed: 30,000 mm/min • Table load: 4,000 kg/m² • Max. spindle speed: 24,000 rpm • Max. spindle power (S1-100%): 42 kW • Max. spindle torque (S1-100%): 67 Nm • Tool holder: HSK63A • Tool changer: 24 positions • C-axis: ±360° • A-axis: +95° / -110°

Condition: as good as new (ex-display), Year of construction: 2023, operating hours: 1,700 h, functionality: fully functional, machine/vehicle number: MP7/5/P, travel distance X-axis: 730 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 400 mm, feed length X-axis: 585 mm, feed length Y-axis: 250 mm, feed length Z-axis: 400 mm, feed rate X-axis: 50 m/min, feed rate Y-axis: 50 m/min, feed rate Z-axis: 50 m/min, spindle speed (min.): 1 rpm, spindle speed (max.): 42,000 rpm, rapid traverse X-axis: 80 m/min, rapid traverse Y-axis: 80 m/min, rapid traverse Z-axis: 80 m/min, type of input current: three-phase, table load: 60 kg, workpiece weight (max.): 60 kg, overall weight: 8,000 kg, MP7-5 Axis with integrated pallet changer 5-axis with rotary/swivel axis Travel range X/Y/Z 585x250x400 mm Travel range B +/- 105 degrees Travel range C continuous Workpiece weight 60 kg Distance machine table to spindle nose 450 mm Machine dimensions (W x D x H) 2845 x 2370 x 3000 mm Kdedpfxsxlctbe Aayow Machine weight 8000 kg Spindle speed 42,000 rpm Equipment: Control: Heidenhain TNC640 Main spindle: HVC140 HSK-E40 with rotary union for internal media supply - Max. speed 42,000 rpm - Milling power S1/S6 10 kW / 13 kW - For internal coolant supply, air and emulsion Oil mist extraction for oil/emulsion Dust extraction: L-CUT Machine-integrated workpiece changer for 36x EROWA ITS50 or 18x EROWA ITS115 Hand-held control unit with electronic handwheel and enabling switch Measuring probe system: Renishaw OMP400 Aerosol DRY LUBRICATION (ADL) - Precise dosage of media externally and through the tool Rotary table chuck: EROWA PowerChuck P on 5-axis Blum laser: LC50 Media distributor: MHT Tool changer 90 positions, HSK E40 Warranty: 12 months Transport Initial commissioning on site Training

Condition: used, Year of construction: 1993, operating hours: 23,927 h, functionality: fully functional, machine/vehicle number: 85280, travel distance X-axis: 3,200 mm, travel distance Y-axis: 1,350 mm, travel distance Z-axis: 350 mm, overall weight: 23,000 kg, spindle mount: MK 4, Control: Siemens Sinumerik with magnetic clamping table, dimensions 4,000x1,500 mm, due to insolvency. Can be inspected under power. Kedoxk U T Ropfx Aayodw
