Condition: good (used), Year of construction: 1990, Ref. -No.: 10301 Manufacturer: TITAN Type: RU 350 x 1-1500 Year of construction: 1990 Type of control: Konventionell Storage location: Halberstadt Fodsxmd Rwepfx Afpjgh Country of origin: USA Max. Grinding length: 1.500 mm Max. Workpiece Weight: 300 kg Grinding Diameter: 350 mm Max. Dia. Of Grinding Wheel: 280-500 mm Grinding Wheel Width: 80-100 mm

Condition: as good as new (ex-display), Year of construction: 1998, functionality: fully functional, workpiece weight (max.): 150 kg, grinding length: 1,000 mm, grinding wheel diameter: 455 mm, grinding diameter: 300 mm, workpiece weight between centers: 150,000 g, type of input current: three-phase, workpiece diameter between centers: 300 mm, grinding wheel width: 75 mm, spindle speed (max.): 500 rpm, spindle speed (min.): 10 rpm, grinding spindle motor power: 7,500 W, overall weight: 5,600 kg, Equipment: rotational speed infinitely variable, OKAMOTO Model OGM-3100 P NC Year of manufacture: 1998 Control system: Fanuc 18 GCA Maximum swing diameter: 320 mm Maximum distance between centers: 1,000 mm Max. workpiece diameter to be ground: 300 mm Max. workpiece weight between centers: 150 kg Grinding wheel: Diameter x Width x Bore: 455 x 75 x 127 mm Wheel speed: Infinitely variable Peripheral speed: 45 m/sec Grinding spindle stock (X-axis): Travel max. 300 mm Swivel angle workpiece table: not swivelling Workpiece table (Z-axis): Travel: 1,150 mm Swivel angle: 0 – 10° Workpiece spindle stock: Version fixed/rotating Mounting taper: MK 4 Spindle bore diameter: 20 mm Spindle speed: 10 – 500 rpm Swivel angle grinding spindle: not swivelling Fedpfx Afexma Ifepsgh Tailstock type: with manual fine adjustment of taper Quill travel: 30 mm Mounting taper: MK 4 Grinding wheel drive: 7.5 kW Dimensions/Weight Length x Width x Height: approx. 4243 x 2490 x 1860 mm Machine weight: approx. 5,600 kg Standard equipment: - Complete FANUC keyboard with radius compensation for creating ISO programs - Workshop programming graphical software for grinding and dressing cycles with teach function - GAP eliminator - Shoulder positioning - Lamp - Documentation - Levelling screws and base plates Accessories: - Marposs measurement control ø 8 – 92 mm - Various flanges - Various grinding wheels - Band filter All information is non-binding, subject to prior sale. Prices: plus VAT Terms of payment: strictly net, before loading.

Condition: ready for operation (used), Max. grinding length: 1000mm Fsdpsxl Rumefx Afpsgh Max. grinding diameter: 320mm

Condition: reconditioned (used), Year of construction: 2006, functionality: fully functional, center height: 175 mm, type of input current: three-phase, feed length X-axis: 285 mm, feed length Z-axis: 1,150 mm, overall weight: 5,700 kg, year of last overhaul: 2025, input voltage: 400 V, workpiece spindle speed (max.): 1,500 rpm, CNC Cylindrical grinder STUDER S33 TECHNICAL CHARACTERISTICS: Year of manufacturing: 2006 CNC control: FANUC 21i-TB Software installed: StuderGrind Centre distance: 1000 [mm] Height of centers: 175 Stroke X axis: 285 [mm] Min. Stroke speed X axis: 0.001 [mm/min] Max. Stroke speed X axis: 5000 [mm/min] Resolution X axis: 0.0001 [mm] Stroke Z axis: 1150 [mm] Min. Stroke speed Z axis: 0.001 [mm/min] Max. Stroke speed Z axis: 10000 [mm/min] Resolution Z axis: 0.0001 [mm] B axis swivelling stroke: -15 [°] / +195 [°] B axis indexing precision: Hirth 1 [°] Automatic B axis: Yes Workpiece spindle nose: MT5 Workpiece spindle min. speed: 1 [rpm] Workpiece spindle max. speed: 1500 [rpm] Max. part weight in part holder headstock between centres: 120 [Kg] Type of attachment tailstock: MT3 Tailstock quill stroke: 35 [mm] Tailstock quill diameter: 50 [mm] Tailstock fine adjustment: +/- 40 [mm] Supply voltage: 400 [V] Total power required: 20 [kVA] Weight: 5700 [Kg] INCLUDED EQUIPMENT: x1 internal grinding spindle type 102540B – speed: 40,000 [rpm] x1 swiveling dressing attachment x1 rotating dressing device DR.KAISER type C42 DC 058 – speed: 25,000 [rpm] – 0.17 [kW] x1 frequency converter MAAS type SPS-9250 x1 pneumatic tailstock lift x1 pneumatic upper-table lift x1 longitudinal slide with rotary table - swiveling up to 8.5 [°] x1 automatic B-axis turret wheelhead – Hirth gearing 1 [°] x1 C-axis for thread and form grinding x1 workpiece probe MOVOMATIC C25 x1 contact control device DITTEL SENSITRON 2 x1 semi-automatic wheel balancing device MPM type 3.BMT100M x1 paper filtration unit STREULI AG x1 mist extraction unit AFS Air Filter Systeme x1 electrical cabinet air conditioner x3 external grinding wheel flanges x2 lifting blocks x1 axis bracket (for transportation of the machine) x1 set of operating manuals (French, English, and German) Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. Fgsdpfx Asxg Ixxofpeh The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Similar machine to the brands Okamoto, ELB, GER, Tacchella, Karstens, Jones & Shipman, Jung, Favretto, Blohm, Studer. Also see surface grinder, lathe, machining center, milling machine.

Condition: reconditioned (used), functionality: fully functional, center height: 250 mm, center width: 1,500 mm, grinding diameter: 500 mm, tailstock quill stroke: 30 mm, Equipment: documentation/manual, The machine has been partially overhauled and includes, among other things, new geometry and a new control cabinet. The bearings have been replaced. TECHNICAL DETAILS Working Area Centre distance: 1,500 mm Centre height: 250 mm Max. grinding diameter: 500 mm Table swivel range: ± 8° Grinding Head Grinding wheel dimensions: 400 x 50 x 127 mm Spindle speeds: 1,500 / 1,700 / 2,200 rpm Bore for internal grinding spindle: 90 mm Workpiece Headstock Workpiece headstock orientation: 180° Spindle speed: 20 - 400 rpm Spindle taper: Morse 5 Tailstock Tailstock taper: Morse 4 Tailstock quill stroke: 30 mm MACHINE DETAILS Drives Fsdjxgrd Sjpfx Afpegh Grinding head motor power: 3 kW Tailstock motor power: 0.9 kW Machine Data Dimensions: 2,860 x 1,680 x 1,670 mm Weight: 2,500 kg EQUIPMENT Automatic working cycle Coolant tank with pump Internal grinding spindle External grinding wheels Dressing device Documentation Note: A digital readout can optionally be purchased for €3,600.

Condition: like new (used), Year of construction: 1984, functionality: fully functional, workpiece weight (max.): 300 kg, grinding length: 1,500 mm, grinding diameter: 320 mm, Cylindrical grinding machine TOS BHU 32A/1500, grinding diameter 320 mm, grinding length 1,500 mm, after our complete overhaul in 2016, in perfect technical and visual condition. Fgsdjxf Hniepfx Afpeh

Condition: used, Year of construction: 2003, grinding diameter 450 mm grinding length 1500 mm centre height 225 mm Fgsdexflcrspfx Afpjh

Condition: excellent (used), Year of construction: 2003, Universal cylindrical grinding machine with internal grinding attachment Year of manufacture: 1991, geometrically overhauled in 2003 Technical Specifications: Table: Center height 180 mm Max. grinding diameter 360 mm Distance between centers 1500 mm Max. automatic table travel 1580 mm Hydraulic table speed 0 – 3000 mm/min Max. table swivel range ± 5° Workpiece Head: Workpiece spindle speeds 30 – 300 rpm Workpiece spindle taper MT 5 Tailstock taper MT 4 Max. swivel range 90° Fgodpfx Afsxama Uopjh Grinding Spindle Head: Spindle speeds 1450 – 1600 rpm Grinding wheel diameter / bore 450 x 127 mm Min. / Max. grinding wheel width 20 – 50 mm Max. swivel range 90° Min. automatic grinding head feed 0.005 mm Internal Grinding Attachment: Spindle speed 17,000 rpm Spindle diameter 60 mm Min. / Max. internal grinding diameter 18 – 100 mm Max. grinding depth (with large grinding diameter) 130 mm Motor power: Grinding spindle head 5.5 HP Internal grinding attachment 1 HP Dimensions and Weight: Machine dimensions (L x W x H) 4200 x 1400 x 1500 mm Machine weight 3300 kg Accessories / Special Features: • Manual or automatic operation • Internal grinding attachment • Three-jaw chuck • 1 fixed steady rest • Wheel dresser • 2 additional grinding wheel flanges • Balancing arbor • Wet grinding unit Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 510-1986, CYLINDRICAL GRINDER JOTES SCHAUDT A440X1500 Specifications Maximum longitudinal travel: 1500 mm Grinding diameter: 298 mm External grinding: Yes Internal grinding: Yes Dimensions (L x W x H): 5400 × 2400 × 1600 mm Weight: 4800 kg Operating hours: — Power-on hours: — Condition: Rebuilt Compliant with local standards: — Status: Under power Technical features - Grinding length [mm]: 1500 - Grinding diameter [mm]: 300 - Manual table displacement [mm/rev]: 10 - Table speed range [mm/s]: 0.01–5 - Smallest table stroke [mm]: 3 - Wheelhead swivel [°]: ±90 - Centre sleeve taper [Morse No.]: 4 - Grinding wheel dimensions [mm]: 500 x 63 x 203 - Spindle speed [rpm]: 32–500 - Grinding wheel drive motor power [kW]: 5.5 - Workpiece drive motor power [kW]: 0.75 - Hydraulic pump motor power [kW]: 1.5 - Grinding attachment drive motor power [kW]: 0.75 Fgedpfjw T Ti Dsx Afpeh - Machine dimensions [mm]: L=5400 / W=2400 / H=1580 / Machine weight [kg]: 4800

Condition: good (used), Center height: 175mm Max. workpiece diameter: 350mm Max. grinding length: 1000mm Fodpfx Afjw Tyr Sopsgh YOM: 1993

Condition: used, functionality: unexamined, Danobat Universal Grinder model 1200 RP with automatic diamond dressing device, capable of working in automatic cycle, maximum grinding diameter 270mm, maximum wheel diameter 400mm, maximum wheel width 60mm, head power 12 HP. Fgodpfx Afjw Iv Huepoh

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: GD08004, Roll grinder. It was used in a steel service center in Germany for sharpening circular knives. It features CE marking. In good condition, ready for operation. The machine has its own coolant filtration system. It is partially packed and ready for shipping, but it is possible to start up the components for inspection. The system on the computer is in German. Full manufacturer documentation and operation records are available. Fedjwzu T Uepfx Afpsgh

Condition: like new (used), Year of construction: 2024, functionality: fully functional, grinding length: 1,650 mm, grinding diameter: 400 mm, We offer a new BUB40 x 1500 NC machine equipped with a MITSHUBISHI NC controller. The machine is still under lease with ING Lease. It has been thoroughly refurbished based on the TOS HOSTIVAR BUB 40 model by FAS GŁOWNO. Technical data: Fgodpewzkywefx Afpoh • Maximum workpiece diameter: 400mm • Maximum workpiece length: 1500mm • Centre height: 200mm • Distance between centres: 1500mm • Minimum grindable workpiece diameter with a 380 mm grinding wheel: 20mm • Tailstock quill stroke: 40mm • Maximum tailstock clamping force: 4000N • Spindle headstock centre taper: ISO 296-1991/Morse 5 • Tailstock centre taper: ISO 296-1991/Morse 5 • Maximum workpiece weight between centres: 500kg • Maximum workpiece weight in chuck (including chuck): 100kg • Machine width (with enclosure): 6650mm • Machine depth (with enclosure, without control panel): 2400mm • Machine height (with enclosure): 1850mm • Machine weight: 7000kg • Total power requirement: 38kVA Grinding spindle: • Standard grinding wheel dimensions: 500 x 80 x 203.2mm • Grinding spindle drive motor power: 11kW • Grinding spindle rated speeds (for 430 mm / for >430 mm and 500 mm wheels): 2000 / 1744 rpm • Grinding headstock traverse servo motor power: 2kW • Grinding headstock traverse servo motor torque: 9.5Nm • Maximum continuous X-axis traverse speed: 2m/min • Minimum X-axis grinding wheel increment: 0.001mm • Maximum continuous X-axis traverse speed: 6m/min • Minimum X-axis grinding wheel increment: 0.001mm • Maximum grinding wheel increment in INC mode: 0.1 mm • Table traverse servo motor power: 3.5 kW • Table traverse servo motor torque: 16.7 Nm Workpiece spindle: • Workpiece spindle speed range: 1 – 150 rpm • Workpiece spindle servo motor power: 3.5kW • Workpiece spindle servo motor torque: 16.7Nm More information available upon request via email or phone.

Condition: reconditioned (used), functionality: fully functional, center height: 250 mm, center width: 1,500 mm, grinding diameter: 500 mm, tailstock quill stroke: 30 mm, Equipment: documentation/manual, The machine has been partially overhauled and includes, among other things, new geometry and a new control cabinet. The bearings have been replaced. TECHNICAL DETAILS Machining Area - Distance between centers: 1,500 mm - Center height: 250 mm - Max. grinding diameter: 500 mm - Table swivel: ± 8° Grinding Head - Grinding wheel dimensions: 400 x 50 x 127 mm - Spindle speed: 1,500 / 1,700 / 2,200 rpm - Bore for internal spindle: 90 mm Workpiece Headstock - Headstock orientation: 180° - Spindle speed: 20 - 400 rpm - Spindle taper: Morse 5 Tailstock - Tailstock taper: Morse 4 - Tailstock quill stroke: 30 mm MACHINE DETAILS Drives - Grinding head motor power: 3 kW Fgedpfx Afjwziidspsh - Tailstock motor power: 0.9 kW Machine Data - Dimensions: 2,860 x 1,680 x 1,670 mm - Weight: 2,500 kg EQUIPMENT - Automatic work cycle - Coolant tank with pump - Internal grinding spindle - External grinding wheels - Dressing device - Documentation

Condition: good (used), Year of construction: 2013, grinding diameter 320 mm grinding length 1500 mm centre height 180 mm workpiece weight max. 150 kg grinding wheel size 400 x 50 x 203 mm grinding wheel speeds 1670 U/min grinding head - swivable +/- 30 ° adjustment grinding slide 246 mm workpiece spindle stepless 25-220 U/min grinding wheel adjustment manuell 0,01 / 0,0025 taper in spindle headstock MK 4 taper in spindle tailstock MK 4 Number of working hours ca. 20 h total power requirement 5,5 kW weight of the machine ca. 4,3 t Fgsdpfx Afjwyd S Djpoh dimensions of the machine ca. 4,3 x 2 x 2 m Hydraulic universal cylindrical grinding machine with a machining length of 1500 mm and a grinding diameter of 320 mm, with internal grinding attachment. Rotatable workpiece spindle head and swiveling table, hydraulic longitudinal table movement, hydraulic rapid traverse of the grinding head, hydraulic grinding head feed when reversing the table, manual + hydraulic adjustment of the tailstock quill. For further details, see data sheets, pics 9 and 10. Commissioning 2015: The machine was only used for a FEW HOURS on special workpieces, and then the orders dried up!

Condition: excellent (used), Year of construction: 2013, Siemens Sinumerik 840D control Max. workpiece diameter: 250 mm Max. workpiece length: 1500 mm Max. workpiece weight: 150 kg Internal grinding device Fgsdpfx Aswwtq Djfpsh Paper band filter Centre tip Diamond dressing plate Grinding wheel change assist

Condition: used, Year of construction: 2005, grinding diameter 500 mm grinding length 1500 mm centre height 250 mm Control GRINDplusIT Maschine wird teilüberholt mit Messprotokoll und Gewährleistung Fjdswulrhopfx Afpsgh innerhalb Deutschlands und Anrainerstaaten geliefert. 1 UR-RS 175 / 1500 standard version (T1, T2, T5, T7) 1 grinding wheel set T1 400x63x127mm 1 grinding wheel set T2 400x63x127mm 1 grinding wheel set T5 400x63x127mm 1 internal grinding device T7 0120 mm for HF spindles 1 centre height 250 mm 2 grinding head motor: drive power 10.0 kW 1 CNC control Heidenhain GRINDplusIT 1 Kel-ASSIST 100 PLUS (includes Kel-Assist 100 and thread calculation) 1 KEL-POLY, out-of-round grinding 1 KEL-NET for CNC control GRINDplusIT 1 B-AXIS GRINDplusIT: ‘CNC-controlled B-axis’ (standard) 1 GRINDplusIT: v constant 35m/s or 45m/s_adjustment of grinding spindle via control 1 T1, T2, T5, T7: T1 and T2: v=constant, T5: v=variable (Danfoss), T7: HF spindle 1 operating unit for 1x MFM or MFV spindles, VACON 22kW 1 x HF internal grinding spindle Fischer MFM 1224/42/31 re. HJND 21 1 x HF internal grinding spindle MFV 1260/4 re 1 x HF internal grinding spindle IBAG HF 33 S 60 P 1 tailstock with manual retraction 1 MICRO-ADJUSTMENT: tailstock lower section with micro-adjustment 1 spring-loaded quill insert 1 pneumatic relief for the tailstock 1 upper table flooding (standard) 1 reinforced workpiece spindle MK 5 DIN 55026 size 5’ 1 C-AXIS: CNC-controlled C-axis to workpiece spindle box reinforced 1 lower part FIXED for the workpiece spindle box reinforced 1 KELPOS: Active longitudinal positioning MOVOMATIC, mounted on the grinding head 1 diameter measuring head Movomatic; DU200 1 measuring control unit Movomatic ES124 / digital 1 KELSET: KELSET tool measurement system, MARPOSS 1 Basic module for KEL-TOUCH cut-off sensor and KEL-BALANCE balancing device 1 KEL-TOUCH, cut-off sensor for diagonal/tandem 1 Full emulsion enclosure 1 Coolant cleaning gun connected to the table 1 Emulsion grinding mist extraction system 1 lubricant for initial filling HF dressing device type IBAG on OT Data from state of delivery without guarantee

Condition: refurbished (used), Kellenberger internal & external universal cylindrical grinding machine Kellenberger 1000 U - 175 (including internal grinding device) Distance between centers: 1000 mm - Center height: 175 mm Fgedjwqlykspfx Afpjh Kellenberger 1500 U - 175 (including internal grinding device) Distance between centers: 1500 mm - Center height: 175 mm Both available with various accessories. Availability: by arrangement (both machines in overhaul process)

Condition: used, Year of construction: 2017, grinding length 1000 mm centre height 180 mm length 3600 mm width 1650 mm Fgodpfxowp Tume Afpsh height 1800 mm weight of the machine ca. 3,7 t

Condition: ready for operation (used), Year of construction: 1993, External cylindrical grinding machine Manufacturer: TOS Type: BUB 40-1000 Year: 1993 Control: Cetos K 51 WORKING AREA CYLINDRICAL GRINDING Max. swing diameter 400 mm Workpiece weight between centers (max) 500 kg Workpiece weight one-side clamped (max) 100 kg WORKING AREA EXTERNAL GRINDING Max. grinding diameter 400 mm Min. grinding diameter 10 mm Grinding length 1000 mm TABLE – CYLINDRICAL GRINDING Swiveling (B-direction) from 8.5 ° Rotation range B-axis up to -4.5 ° Longitudinal travel 1200 mm WORKPIECE SPINDLE STOCK Swiveling (B-direction) from 0 ° Rotation range B-axis up to 90 ° Spindle bore 40 mm Number of gear stages 2 Drive power 9.5 kW Tool holder MK 5 TAILSTOCK Quill stroke 40 mm Quill fitting MK 5 Contact force (max.) 4 kN GRINDING SPINDLE STOCK Swiveling (B-direction) from -15 ° Rotation range B-axis up to 45 ° GRINDING WHEEL Type: grinding wheel, disc Diameter (max) 500 mm Bore: diameter 203 mm Width 80 mm ELECTRICAL CONNECTION DATA Connected load 16 kVA Connection voltage 400 V Network frequency 50 Hz DIMENSIONS / WEIGHTS Required space -left/right- 4700 mm Required space -front/back- 2050 mm Total height 1900 mm Total weight approx. 5400 kg Fjdpfewp D Ausx Afpogh ADDITIONAL EQUIPMENT (GRINDING) Balancing device yes Machine in well-maintained condition Workpiece spindle stock swivels 90° Grinding spindle stock swivels -15°, +45° Table swivels +8°30' - 4°30' Accessories: - hydrostatic spindle - various corundum grinding wheels - 2 diamond grinding wheels - Balancing head MPM, renewed in 2021 - Filter system - Extraction system

Condition: used, Year of construction: 2017, grinding length 1500 mm Fsdpfx Ajwm Rqgjfpegh centre height 180 mm weight of the machine ca. 3,9 t dimensions of the machine ca. L: 4900 x 1650x 1800 m

Condition: used, functionality: fully functional, Maximum workpiece length: 500 mm Minimum workpiece length approx.: 5 mm Maximum workpiece length for plunge grinding: 50 mm Max. grinding diameter without steady rests: 100 mm Max. diameter: 240 mm Workpiece Swivel: 90° Grinding spindle slide Fedpfx Aswhp D Uefpsgh Min./max. swivel: 30° Min./max. transverse movement including 300 mm quick adjustment: 100 mm Wheel diameter after rotation 1st degree: 320 - 400 mm 2nd degree: 260 - 320 mm Max. workpiece weight between centers: 60 kg Max. workpiece weight in chuck: 20 kg Max. workpiece weight in faceplate: 20 kg 8 workpiece spindle speeds: 45 - 500 rpm Min./max. Tilt: 12° Min./max. longitudinal travel: 2 - 500 mm Infinitely variable table travel: 0.5 - 5 m/min Handwheel adjustment: 2 and 20/rev

Condition: used, functionality: fully functional, Grinding length: 973 mm Center height: 250 mm Maximum worktable tilt: +6° / -9° Centering center: MT5 Fgjdpfjwhp Dnsx Afpeh Maximum grinding head travel: 100 mm Maximum grinding head tilt: +45° / -30° Maximum grinding wheel diameter: 500 mm Speed range: 32 - 600 rpm Maximum workpiece weight between centers: 400 kg Maximum internal grinding device grindable bore: 160 mm Machine weight: approx. 5,000 kg

Condition: used, Year of construction: 2007, oil mist extraction ja Fsdpfx Ajwgi Rfefpogh serial number 2342-11

Condition: repair required (used), functionality: not functional, workpiece weight (max.): 300 kg, grinding length: 2,000 mm, Used Cylindrical grinding machine TOS BHU 32A/2000 Fgjdjwbiw Ijpfx Afpeh grinding diameter 320 mm, grinding length 2,000 mm, without electrics, in need of repair, ideal for companies specializing in general overhauls.
