Grimatec GmbH & Co KG

Condition: good (used), Year of manufacture: 2015 Machine number: 4051 1015 Type: FS 640 Z CB Grinding length: 600 mm Grinding width: 400 mm Grinding height: 375 mm Table load capacity: 600 kg Magnet size: 600 x 400 mm Table longitudinal stroke: 200 to 650 mm Table drive: hydraulic Table speed: 2 to 28 m/min Distance between table and spindle center: 140 to 525 mm Vertical feed drive: electromechanical with ball screw Vertical speed: 50 to 4,000 mm/min Dodpfsyryf Nox Ah Iscd Vertical adjustment: Smallest feed increment: 0.001 mm Measuring system: motorized measuring system Cross travel max.: 400 mm Drive: electromechanical with ball screw Cross speed: 50 to 4,000 mm/min Cross adjustment: electronic handwheel and directional pushbutton Measuring system: motorized measuring system Grinding spindle: 3.7 kW Grinding wheel dimensions: 300 x 50 x 76.2 mm Grinding wheel speed: 600 to 3,180 rpm Features: separate control cabinet, partial enclosure, dresser Note: Machine is without magnetic separator and cooling system. Was connected to the central system in the factory. Connection: 15 kW Machine weight: 2.4 t

Condition: used, Year of construction: 1982, grinding length: 600 mm, grinding width: 550 mm, total height: 2,490 mm, feed length X-axis: 600 mm, feed length Y-axis: 470 mm, feed length Z-axis: 600 mm, grinding height: 400 mm, grinding wheel diameter: 400 mm, table length: 1,100 mm, table load: 400 kg, table width: 450 mm, grinding wheel width: 100 mm, spindle speed (max.): 1,400 rpm, spindle speed (min.): 1,400 rpm, overall weight: 5,300 kg, travel distance X-axis: 600 mm, travel distance Y-axis: 470 mm, travel distance Z-axis: 600 mm, rotational speed (max.): 1,400 rpm, rotational speed (min.): 1,400 rpm, grinding spindle speed: 1,400 rpm, disc diameter: 400 mm, space requirement height: 2,490 mm, We are offering this used ELB-Schliff Oprimal 3 ND surface grinding machine, year of manufacture 1982. Maximum grinding length: 600 mm Maximum grinding width: 550 mm Working height with new grinding wheel: 400 mm Working height with worn grinding wheel: 600 mm Spindle taper ratio: 1:5 Manual vertical travel of grinding spindle: 600 mm Manual horizontal travel of grinding spindle: 470 mm Swivel range grinding spindle: 1° Clamping table surface: 1100 x 450 mm Small table stroke: 80 mm Number of T-slots: 1 T-slot width: 16H7 mm Cross feed (table): 470 mm Longitudinal feed (table): 600 mm Table load capacity: 400 kg Outside diameter of grinding wheel: 400 mm Inside diameter of grinding wheel: 127 mm Grinding wheel thickness: 100 mm Recess 1 diameter: 190 mm Recess 1 thickness: 20 mm Dsdjyrn Sdopfx Ah Ijcd Recess 2 diameter: 190 mm Recess 2 thickness: 30 mm Machine height: 2.49 m Weight: 4700/5300 kg Direct spindle speed: 1400 min⁻¹ Continuous feed rate, grinding spindle carriage: 1.2 m/min Intermittent feed rate, grinding spindle carriage: 3–60 mm Hydraulic table feed speed: 1–30 m/min If you have any questions or require further information, please feel free to send us a message or call us.

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Technical details grinding length 600 mm grinding width 400 mm workpiece height 400 mm weight of the machine ca. 4,5 t dimensions of the machine ca. 3400 x 2647 x 2203 mm Additional information Horizontal surface grinder in almost new condition with few operating hours! Operating hours: see image PC control Okamoto Travel X-axis: 600 mm Travel Y-axis: 22.5 – 497 mm Travel Z-axis: 400 mm Speed range rpm: 1-2800 (stepless) Rapid traverse mm/min: 4000 Main drive kW: 7.5 Maximum table load in kg: 1000 Accessories: - Electro-permanent magnetic clamping plate: 400 x 600 P13 mm, height 80 mm (make Wagner) Djdpfjyrnn Eox Ah Ijcd - 2 grinding wheel flanges - Table dresser - Automatic straight dresser, spindle box mounted - Automatic compensation of the wheel dressing amount - Automatic central lubrication - Ball screw in the Y and Z axes with AC servo motor and measuring system - Coolant system with belt filter system

Condition: ready for operation (used), empty load weight: 39,000 kg, Thompson X:3000 - Y: 1000mm Worklength with magnetic table: 3000 mm Grindingwidth: 1000 mm Longitudinal travel X-axis (autom.): 3000 mm Travel Z-axis (autom.): 1000 mm Dimensions of the table: 3090 x 920 mm Max dia grindingstone: 450 x 150 mm Dodpfx Aeyriwheh Iscd Motorpower: 16,5 kW

Condition: used, grinding length 1350 mm grinding width 660 mm workpiece height 522 mm control mit Steuerung surface area 1500x750 mm grinding wheel size 350x60 mm Djdpfoyqv Nbex Ah Iscd turning speeds 1500 U/min power capacity 11 kW The tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 84310 € 1593.46 € 460 mm 395 mm 460 x 200 mm 450 x 200 mm 0 - 20 m/min 0 - 3000 mm/min 0,001 mm 220 mm 290 mm 0 - 3000 mm/min 0.001 mm 1000 - 7000 1/min 3 kW 2280 mm 2205 mm 2020 mm 1500 kg 1060 mm 175 kg 210 kg Dm. 205 x 12,7 x 31,75 mm 1,1 kW 2.4 kW 0,004 mm 0,003 mm Smart i control with 10.4" touchscreen on a swiveling panel, with electronic wired handwheel Djdpeynnc Ijfx Ah Iecd - RS232, USB I/O connection - SMART Grind Cam (dxf transfer in G code) -PC based control with graphical dialog programming or G-code programming Infinitely variable speed Surface grinding cycle, cross grinding cycle, plunge grinding cycle, multiple groove grinding cycle, contour grinding cycle, dressing cycle Spindle with 4 angular contact ball bearings (P4, checkout 7) Longitudinal guides with double V shape, with Turcite-B coating All 3 axix with precision ball screws (class C2) and AC servo motors Fully enclosed splash guard with lamp Electromagnetic chuck plate Coolant system with automatic paper filter and magnetic separator autom. dressing attachment table mounted with compensation * Grinding wheel Grinding wheel flange Grinding wheel balancing stand Machine and equipment in accordance with CE regulations Operating manual in GERMAN or ENGLISH * The exact configuration of the dresser must be clarified before ordering

Condition: used, Year of construction: 2004, grinding length 600 mm grinding width 400 mm Dcodpfeym D A Isx Ah Ijd workpiece height 375 mm digital readout 2 Achsen HEIDENHAIN table-size 650 x 350 mm max. table load 400 kg magnetic clamping plate 600 x 350 mm dist. center of grinding spindle - table 525 mm table travel longitudinal 650 mm table travel cross 350 mm table feed 2 - 28 m/min grinding wheel size 300 x 30 x 76,2 mm dressing device Kopfabrichter voltage 400 V total power requirement 11,0 kW weight of the machine ca. 2,1 t dimensions of the machine ca. 2,20 x 1,70 x 2,25 m band filter unit 1,00 x 0,75 x 0,80 m electric cabinet 0,90 x 0,40 x 2,25 m - Serial-No.: 25940604 - Automatic vertical feed - Electric handwheel - HEIDENHAIN digital display, 2 axes - Head dresser with compensation - Coolant device - Belt filter system

Condition: ready for operation (used), Surface grinder, travel (mm): X485, Y170, Z350, hydraulic, grinding wheel diameter 177.8 mm, 1.5 kW, 2800 rpm, with digital readout. Dcjdpsympg Sjfx Ah Iod

Condition: used, total height: 1,700 mm, total length: 1,540 mm, total width: 1,280 mm, Empty weight: 1.000 kg - Documentation available: No - CE certificate present: No - Drive system: Conventional Dcjdpfx Aeyml Apsh Ied - Number of axes [pcs]: 3 - X-axis travel [mm]: 600 - Y-axis travel [mm]: 250 - Z-axis travel [mm]: 320 - Table width [mm]: 760 - Table depth [mm]: 210 - Magnet width [mm]: 460 - Magnet depth [mm]: 250 - Max. grinding wheel diameter [mm]: 210 - Max. grinding wheel thickness [mm]: 30 - Options: Dresser - Transport dimensions: 1540mm x 1280mm x 1700mm (l x w x h) - Transport weight [kg]: 1000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: refurbished (used), functionality: fully functional, grinding length: 680 mm, grinding width: 350 mm, grinding height: 300 mm, table length: 600 mm, table width: 300 mm, grinding wheel width: 50 mm, spindle speed (max.): 1,400 rpm, CAPACITY Max. longitudinal table travel: mm 680 Max. cross travel of grinding wheel: mm 300 Max. grinding width: mm 350 Dcjdpfxeymlcvo Ah Iod Max. grinding height with standard wheel: mm 300 TABLE Table surface dimensions: mm 600 x 300 Length of T-slots: mm 850 Size and center distance of the three T-slots: mm 16 x 100 Continuously variable speed: m/min 2 – 30 GRINDING WHEEL Standard dimensions (diameter x bore): mm 356 x 127 Standard width: mm 50 Max. permissible width: mm 76 Max. external diameter – upon request: mm 406 Speed with 50 Hz motor: rpm 1,400 Incremental cross feeds: mm 1 – 10 Continuously variable cross movements: m/min 0.1 – 6 Automatic vertical feeds – upon request: mm/min 0.005 – 0.05 MOTORS, three-phase AC – 50 Hz: Grinding wheel rotation, 4 poles: kW (HP) 5.5 (7.5) Hydraulic unit, 2 poles: kW 2.2 (3) Rapid vertical movements, 4 poles – upon request: kW 0.37 (0.5) Coolant unit, 2 poles: kW 0.22 (0.3) MISCELLANEOUS Overall floor dimensions, machine in operation: mm 2780 x 1240 Height from floor, standard machine: mm 1960 Machine height with raised column – upon request: mm 2110 Approx. net weight: kg 2,500

Condition: ready for operation (used), Year of construction: 1988, Horizontal surface grinding machine Okamoto Model PSG 63 – UAN Year of manufacture 1988 Grinding length 600 mm Grinding width 320 mm Maximum workpiece height 500 mm Djdpjyl T Tasfx Ah Ijcd Table longitudinal travel 750 mm Table cross travel 340 mm Grinding wheel diameter 350 mm Grinding wheel width 40 mm Spindle speed 1,500 rpm Rapid vertical traverse 400 mm/min Power 3.7 kW Automatic feed Magnetic chuck Coolant system Weight 2,500 kg Price: €2,500 plus VAT, ex-site

Condition: like new (used), A real gem! If it weren’t for the nameplate, you’d think the machine was brand new – and that’s exactly the condition it’s in. The previous owner is renowned in Switzerland as one of the top grinders in the industry. The machine has been maintained and treated accordingly. Ideal for young toolmakers looking to start their own business. Djdpfx Aheyl Apdj Iecd 💰 Financing model (only for German customers): Down payment: €5,000 Then: 5 monthly installments of €500 each, which can conveniently be paid from the grinder’s earnings. An excellent opportunity to start earning money immediately with a high-quality machine.

Condition: used, Year of construction: 2015, Lot consists of: (1) Surface grinding machine Technical Details: Dcjdpfoylaizex Ah Ijd Power supply: 400 V; Frequency: 50 Hz; Rated current: 4 A; 1.5 kW; Net weight: 920 kg

Condition: used, Year of construction: 1980, Technical details: grinding length: 600 mm grinding width: 300 mm total power requirement: 7,5 kW number of spindle speeds: 0-3000 grinding wheel motor: 7,5 kW grinding wheel diameter: 300 mm dimensions of grinding wheel: 76 x 20 mm ABA magnetic table flat grinding machine Dsdpfoyk Utfjx Ah Iscd *

Condition: as good as new (ex-display), Year of construction: 2023, functionality: fully functional, grinding length: 600 mm, grinding width: 300 mm, total height: 2,300 mm, total length: 2,450 mm, total width: 3,000 mm, feed length X-axis: 650 mm, feed length Y-axis: 730 mm, feed length Z-axis: 340 mm, workpiece weight (max.): 400 kg, grinding height: 420 mm, feed rate X-axis: 20 m/min, feed rate Y-axis: 1 m/min, feed rate Z-axis: 1 m/min, grinding wheel diameter: 305 mm, distance table to spindle center: 580 mm, table speed: 20,000 mm/min, table load: 400 kg, type of input current: three-phase, grinding wheel width: 25 mm, spindle speed (max.): 2,100 rpm, spindle speed (min.): 1 rpm, overall weight: 2,300 kg, distance stand to spindle center: 30 mm, grinding spindle motor power: 7,500 W, Fully automatic surface grinding machine with touchscreen control. Simple, user-friendly operation with a grinding cycle including roughing, finishing, and spark-out. Intermediate spark-out possible. Optional with dressing device and compensation. The machine can be inspected under power and is available at short notice. For further information, please inquire. Dsdpfx Aeyk Un Noh Iecd

Condition: new, Year of construction: 2026, grinding length: 560 mm, grinding width: 240 mm, total height: 2,150 mm, total length: 2,250 mm, total width: 1,720 mm, workpiece weight (max.): 180 kg, feed rate X-axis: 25 m/min, grinding wheel diameter: 220 mm, distance table to spindle center: 450 mm, table length: 508 mm, type of input current: three-phase, table width: 200 mm, grinding wheel width: 20 mm, overall weight: 1,800 kg, rotational speed (max.): 2,850 rpm, power: 5 kW (6.80 HP), input voltage: 400 V, Equipment: documentation/manual, Siemens PLC control Touchscreen Electronic handwheel Digitally controlled automatic vertical feed with servomotor SINO 2-axis digital readout Electromagnetic clamping plate Cooling system LED lighting Grinding wheel Flange Central oil lubrication Table size ----- 200 x 508 mm T-slot width / quantity ----- 14 / 1 mm Electromagnetic clamping plate ----- 200 x 460 mm Max. longitudinal travel of table ----- 560 mm Max. cross travel of table ----- 240 mm Table speed, hydraulic ----- 5~25 m/min Max. distance spindle - table ----- 450 mm Max. permissible workpiece weight ----- 180 kg Grinding wheel ----- 220 × 20 × 31.75 mm Cross travel Automatic feed, cross ----- 0.2~8 mm / stroke Rapid traverse, cross ----- 990 mm/min Feed per handwheel revolution, cross ----- 4 mm/rev Handwheel graduation ----- 0.02 mm Dcjdpfx Ahoykvkxs Ijd Vertical travel Automatic feed, vertical ----- 0.005 / 0.01 / 0.02 / 0.03 / 0.04 / 0.05 mm Rapid traverse, vertical ----- 480 mm/min Feed per handwheel revolution, vertical ----- 1 mm/rev Handwheel graduation ----- 0.005 mm Main motor ----- 2.2 kW Hydraulic pump motor ----- 0.75 kW Vertical feed motor ----- 0.5 kW Weight ----- 1800 kg Machine dimensions ----- 2250 x 1720 mm

Condition: used, Year of construction: 2007, grinding length 600 mm grinding width 400 mm workpiece height 375 mm Gewartet und Längsachse neu eingeschabt Glasmaßstäbe in der Senkrecht- und der Quer-Achse Schleifscheine 300/50/76,2 mm Magnetspannplatte 600x400mm mit Haftkraftregelung Dcsdpfxeykmqvs Ah Isd Universal-Papaierfilterautomat UPF100 mit 280l Tankinhalt.

Condition: ready for operation (used), grinding length: 457 mm, grinding width: 152 mm, total height: 504 mm, grinding wheel speed: 2,640 rpm, Equipment: CE marking, documentation/manual, JONES & SHIPMAN 540 X Surface Grinder Grinding capacity: 152 x 457 mm Standard wheel dimensions: 200 x 20 x 31.75 mm Spindle speed: 2,640 rpm Machine complete with magnetic table 360 x 150 mm Wheel dresser Dcodoyi Trdopfx Ah Isd Coolant tank Operation and maintenance manuals CE declaration of conformity

Condition: ready for operation (used), Year of construction: 1988, grinding length: 400 mm, grinding width: 154 mm, Heidenhain visual display Optidress Facstor diamond dresser Travel 400 x 154 mm Magnetic chuck 350 x 150 mm Grinding wheel covers Dsdpsyh N Tlefx Ah Iocd

Condition: good (used), Year of construction: 1988, functionality: fully functional, Surface grinding machine Geibel&Hotz Type FS 40 Primus SA Dcjdpfx Ahjyh Hutj Iod Condition: good Fully functional

Condition: used, total height: 1,620 mm, total length: 1,750 mm, total width: 1,400 mm, Empty weight: 2.500 kg - Documentation available: No - CE certificate present: No Dedpfxoyh Amlj Ah Iscd - Drive system: Conventional - Number of axes [pcs]: 3 - X-axis travel [mm]: 500 - Y-axis travel [mm]: 230 - Z-axis travel [mm]: 330 - Table width [mm]: 720 - Table depth [mm]: 200 - Magnet width [mm]: 460 - Magnet depth [mm]: 180 - Options: External cooling - Transport dimensions: 1750mm x 1400mm x 1620mm (l x w x h) - Transport weight [kg]: 2500kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: good (used), 1x electromagnet with coolant connection, 500 x 200 x height 125 mm, and 1x electromagnet without coolant connection. Items are sold individually. Dcedpfx Ahoyhy Exe Ijd

Condition: used, Technical details: Magnetic plate: 900 x 450 mm Heidenhain measuring system Automatic feed Cross movement electrically and manually via handwheel Vertical movement electrically and manually via handwheel Dedpfeyhwhwsx Ah Iecd Longitudinal movement hydraulically and manually via handwheel Grinding spindle with plain bearings

Condition: good (used), Stock number: 3071 Manufacturer: WMW Mikromat Machine number: 3402-1/21.29 Type / Model: SFW 200 x 600 Table size: 200 x 600 mm Grinding area: 600 x 200 mm Maximum grinding height: 400 mm Magnet: 600 x 200 mm Grinding wheels: 200 x 20 x 51 mm Table speed: 2 to 18 m/min Automatic cross feed of table: 0.1 to 2 mm Max. distance table to spindle center: 500 mm Grinding wheel speed: 2,800 rpm Dcedpfxjygl Tno Ah Isd Power connection: 3.5 kW Accessories/Equipment: Electromagnet Condition: Good Weight: 1.1 t Machine dimensions: 1,600 x 1,000 x 1,800 mm Dimensions incl. control panel: 2,400 x 1,000 x 1,800 mm

Condition: like new (used), Year of construction: 2012, operating hours: 344 h, functionality: fully functional, grinding length: 850 mm, grinding width: 400 mm, total height: 505 mm, overall weight: 3,500 kg, Equipment: documentation/manual, Base machine Type Linea Iron 6.3 Preparation for magnetic chuck with safety function Magnetic chuck 600 x 300 x 70 mm Paper band filter unit with manual paper unwind Air cooling for hydraulic oil Dressing fixture at the end of the table, incl. space for lateral diamond 2x grinding wheel flanges with manual weights Djdpfoygap Rjx Ah Ijcd Machine grinding range: Longitudinal 850 mm. Cross 400 mm including max. B (50 mm) grinding wheel. Height distance table to spindle center 505 mm. Weight 3,500 kg.
