neuform-Türenwerk Hans Glock GmbH & Co. KG

Condition: used, Year of construction: 2006, Working area X-Y-Z: 5300 x 1700 x 180 mm Travel length X-Y-Z: 6040 x 1810 x 280 mm Drilling head with 30 + 8 spindles Speed: 6000 rpm Power: 2.2 kW Automatic central lubrication Worktable TV with 10 supports L=1500 4 working zones 2 cross lasers Vacuum pump 250 m³/h PC control Windows Vertical milling unit ISO 30 7.5 kW with tool changer RAPID 14 and vector axis Additional drilling unit (E-axis) Nledpfxjxy Tmzo Ah Dji Dongle for XILOG software Location: Nattheim

Condition: used, Year of construction: 2011, Basic machine Stk Volt 400 EU Stk #93.07.31 Series 800 TV working areas 5020x1905 Stk # 52.19.14 8 Matic supports (Y=1825 mm) with 3 basic modules Stk # 52.19.92 for automatic vacuum suction cups Additional basic module for automatic vacuum suction cups Matic Stk # 52.19.99 4 working areas H= 50 Stk # 52.21.63 Front and rear stops H=50- 8 traverse Stk # 52.24.11 Integrated additional stops H=50 mm for 8 traverse Stk # 52.24.15 Central double rail (removable) with 6 stops Stk # 52.24.18 H=50 mm suction cup TV 145 x 30 H50 Stk # 52.18.69 Suction cup TV 145 x 55 H50 Stk # 52.18.70 Suction cup TV 145 x 145 H50 Stk # 52.18.71 8 Posi-Aids H50 Stk # 52.21.66 Group 800 - Electrospindle Prisma K 11 kW Stk # 52.21.80 Drilling head F50L2 (38V-80X-40Y-L0/90°) Stk # 52.22.51 PBTC-On Pos.3 Electrospindle PB+Rapid 6 Stk # 52.21.96 Tool magazine Rapid 12 on board (X,Y-traveling) Stk # 52.22.90 Stk # 52.22.92 Vacuum pump with 250 (300) M3/H50(60) HZ Item # 52.21.97 Storage Location: Supplier Nlsdpfsxy Tmnex Ah Dsi

Condition: used, Year of construction: 2016, Working area: X=3300 mm Y=1280 mm Z=150 mm Pass-through height. Operator terminal: 24" LED color display. Handheld terminal for controlling axis speeds. Software: "Woodflash". Vacuum pump 90 m³/h, 50 Hz or 108 m³/h, 60 Hz. Milling spindle 12 kW HSK F63 (12,000 rpm). 12-position linear tool changer on the left side of the machine frame + pickup position. Drilling head DH 16 4H 2S: Vertically 12 spindles, horizontally 4 spindles, 2 grooving saws. Storage location: Supplier. Nledpfx Ahjxy Tlwj Dsi

Condition: used, Year of construction: 2016, total length: 4,300 mm, total width: 1,880 mm, total height: 2,350 mm, Empty weight: 1.310 kg Nljdjxy Rk Ropfx Ah Dji - Year: 2016 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: AB/226310 - Transport dimensions: 4300mm x 1880mm x 2350mm (l x w x h) - Transport weight [kg]: 1310kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: used, Year of construction: 2011, · Working area: 2,550 x 1,067 mm · X-Y travel: 2,980 x 1,450 mm · Z-axis travel length: 150 mm · Clearance height: 120 mm Drilling Unit F14: · Drilling head with 8 + 6 spindles · 5 individually selectable vertical spindles in X · 3 individually selectable vertical spindles in Y · 4 horizontal spindles in X (2+2) · 2 horizontal spindles in Y (1+1) · Speed: 4,000 rpm (6,000 rpm available as an option) · Power: 2.2 kW Nedpoxy Ndiofx Ah Djli · Grid: 32 mm · Drill holder: M10 with 11 mm positive fit · Pneumatic feed stroke: 60 mm Grooving saw unit in "X": · Integrated in the drilling head · Grooving saw blade with a maximum diameter of 120 mm Main milling unit: · Tool interface HSK 63F · Speed: 1,500 – 24,000 rpm, infinitely variable via inverter · Motor power: 6.6 kW (9 HP) from 12,000 rpm (S1) · Motor power: 7.5 kW (10 HP) from 12,000 rpm (S6) · Right-/left-hand rotation · Ceramic bearings · Prepared for use with angle drives Tool changer TR10: Automatic lateral tool changer for 10 tools. · Number of tool positions: 10 · Maximum tool diameter: 120 mm · Maximum weight per tool: 4.5 kg · Maximum total tool weight: 28 kg A central extraction port collects all processing units into a single connection with D=200 mm. This reduces the required extraction capacity to approx. 3,200 m³/h. TVF worktable: The worktable is designed to provide the operator with maximum "freedom of movement." The vacuum quick-clamping system offers maximum flexibility for precise positioning and optimal holding of workpieces. · 4 TVF supports, L=1100 mm, infinitely adjustable in X · 12 TVF vacuum cups 120 x 120 mm, infinitely adjustable in Y · 2 stops in X (1 left / 1 right) · 1 stop in Y per support (total 4 pcs.) · Retractable reference stops controlled via CNC Automatic central lubrication: The correct amount of lubricating grease is distributed via an electronic CNC control unit (X, Y, Z axes) Vacuum system (base machine): · Vacuum pump: 90 m³/h · Power: 2.2 kW · Max. negative pressure (at pump): 0.9 bar PROGRAMMING SYSTEM XILOG PLUS Software features: - Import of DXF files - Import of ASCII files - User interface in operator’s native language Safety devices with bumpers Machine technical data: · Total connected load max.: 18 kW · Recommended fuse: 64 A · Power supply: 400 V 50-60 Hz · Compressed air: 6-7 bar · System pressure (recommended): 8 bar · Compressed air consumption: 200 Nl/min · Central extraction port Ø: 200 mm · Extraction speed: 30 m/sec · Air consumption (central extraction): 3,200 m³/h · Negative pressure: 3,000 Pascal · Weight: approx. 2,500 kg Remote control of machine functions 6 TVF supports L=1,100 mm and 18 vacuum cups 120x120 mm Cross lasers for vacuum cup positioning Two cross lasers mounted on the unit carrier allow for easy positioning of the vacuum cups. Location: Nattheim

Condition: used, Year of construction: 2025, Working area: X=3500 mm Y=950 mm Z=80 mm 24" LED color display Software: Woodflash CNC board Operation Milling spindle 12 kW HSK F63 Drilling head DH 17 6H 1S 11 vertical spindles 6 horizontal spindles 1 grooving saw in X-direction Double clamp drive X-axis controlled central extraction Automatic central lubrication Storage location: customer Nodpfx Aexymahoh Djli

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, machine/vehicle number: 01-2142-054, travel distance X-axis: 4,200 mm, travel distance Y-axis: 2,100 mm, number of spindles: 17, Nesting machining center with automatic unloading! TECHNICAL DETAILS Travel range X-axis: 4,200 mm Travel range Y-axis: 2,100 mm Drilling head: 17 vertical spindles Tool changer positions: 6 MACHINE DETAILS Electrospindle power: 9 kW Vacuum pump capacity per pump: 250 m³/h EQUIPMENT Nesting worktable Automatic unloading system with motorized conveyor belt System for printing and applying adhesive labels with labeler Protection and safety system with surrounding fences Safety system with front safety mats Nlodjxx Sltopfx Ah Dei Automatic lubrication system Air conditioning for cooling and cleaning the machine control

Condition: good (used), Year of construction: 2013, functionality: fully functional, Working area: X-axis 3,200 mm (support extensions available) Y-axis 900 mm Workpiece handling via collet chuck Automatic workpiece length measurement Drilling unit: 10 individually selectable vertical drilling spindles 6 individually selectable horizontal drilling spindles Nledpfx Ahjxxpmzj Dsi Grooving saw unit in X-direction Milling unit with 4.5 kW motor, fitted with ER32 collet chuck (no ISO 30 quick-change system) BIESSE WORKS EDITOR Second BIESSE WORKS dongle for office workstation

Condition: used, Year of construction: 2023, Technical Data Working Area I.M.S. I.U. Working area X axis 5515 mm (217") Working area Y axis 1620 mm (63¾") Material passage Y 1900 mm (74¾") Material passage Z 250 mm (9¾") Workpiece length for pendulum processing 2600 + 2600 mm (102" + 102") Traverse speed of X-Y axes PRO-SPACE 56 m/min (184 ft/min); Traverse speed of X-Y axes PRO-SPEED 78 m/min (256 ft/min). *For further details, please refer to the corresponding machine layout. With the 5-axis motor, the Y working area increases to 1680 mm (66") for JQX motor, or 1720 mm (67½") for KS/KT motor. Max. loadable panel width during horizontal drilling, spindle oriented vertically only, with no middle reference stops. Installation Data I.M.S. I.U.: Nledexwht Djpfx Ah Dji Installed power: 23 – 28.5 KVA Electrical specifications: 400 V, 50 Hz, 3 phases Air consumption: 450 Nl/min Compressed air consumption: 4500 m³/h (2650 CFM) Extraction air speed: 30 m/s Extraction port diameter: 250 mm (9.8") Noise level VSA* / LAV*: Drilling 72.2 dB(A) / 74.6 dB(A), Milling 74.3 dB(A) / 80.7 dB(A) Reference standard: EN ISO 11202:1995 *VSA = without load and without extraction *LAV = in operation, with extraction Location: Nattheim

Condition: used, Year of construction: 2014, BIESSE Bre.Ma VEKTOR 15-13 CNC Drilling and Insertion Machine Art. No. BCDR14530 Manufacturer: BIESSE / Bre.Ma Nlodpfjxwd I Rox Ah Dsi Model: VEKTOR 15-13 Year of manufacture: 2014 Description: The Bre.Ma VEKTOR 15-13 is a vertical CNC-controlled drilling and insertion machine designed for precise machining of panel materials of various sizes. Thanks to its compact design and ergonomic configuration, it ensures top processing quality while requiring minimal floor space. The machine is specifically designed for flexible production requirements—ideal for furniture manufacturers and subcontractors focusing on custom batch sizes. Technical Data: • Model: VEKTOR 15-13 • Year: 2014 • Serial number: BCDR14530 • Control: CNC • Installed power: 11 kW • Air consumption: approx. 200 NL/min • Extraction capacity: approx. 4,500 m³/h • Air pressure: 6–7 bar • Workpiece thickness: up to 80 mm • Max. workpiece width: 1,300 mm • Min. workpiece size: 240 × 40 × 8 mm • Turret tool changer: 10 positions • Spindle speed: up to 18,000 rpm • Weight: approx. 2,800 kg Field of Application: Vertical processing of furniture and cabinet components: drilling, milling, grooving, glue injection, and dowel insertion in a single pass. Ideally suited for industrial production lines with automated part handling. Highlights: • Compact design requiring minimal floor space • Superior processing quality due to vertical panel orientation • 10-position turret tool changer (NC-controlled, < 2 seconds) • Laser-based zero-point detection system • Optional integration into production lines with robot systems (ROS) • Full compatibility with Biesse SmartConnection and Sophia IoT system

Condition: as good as new (ex-display), Year of construction: 2024, functionality: fully functional, Programmable drilling machine with easy-smart-touch software, 3 controlled axes. Panel handling with triple suction cup. Machine built according to CE regulations. STANDARD EQUIPMENT MAIN UNIT: Head with independent spindles No. 7 vertical lines No. 1 TH1 horizontal double spindle (X-axis) for front/rear drilling Manual panel alignment END PANEL READER for perfect matching Nedpsxwb Tdjfx Ah Doli Remote assistance software Suction flange Scratch-resistant BRUSH TOP to prevent dust and chip accumulation Working MODE selectable from the operator’s side or in continuous cycle HARDWARE & SOFTWARE 12" touchscreen with MAGGI patented NO TEXT system USB and Ethernet port for file import, online support, and software updates Linux-kernel-based system Fobmsu U Hgiegku S Hepp CNC memory for up to 1,000 programs to buy call: 0031634707163 Almelo

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, Working dimmensions of workpeace: - 250 mm - 2400 mm in lenght - 240 mm - 800 mm in weidh - 12 mm-60 mm thickness AGREGAT 2V19 HIGH SPEED 7500 2 vertical drilling units with 19 drilling spindles (individually controllable with variable speed range). Spindle clamping for secure achivement of drilling depth AUTOMATIC GROOVING SAW, 90* PIVOTABLE Nledoxvy H Hopfx Ah Dsi GLUE APPLICATION UNIT for applying glue into construction drill holes from above. Unit with six glue nozzles nozzles manually adjustable in y direction in a 32 mm grid Glue supply via a glue pump, pressure regulator, glue filter, and cleaning tray for the glue nozzles MACHINE LINKING FOR HOMAG GROUP MACHINES Workpiece transport infeed: 4-stand timing belt conveyor for workpiece transport, center distance: 3,100 mm -POWERCONTROL SYSTEM - HAND CONTROL UNIT - SOFTWARE WOODWOP 5.5

Condition: good (used), For sale is a fully automatic, computer-controlled woodworking machine for carpentry elements by HUNDEGGER. This is a patented system, recognized as unrivaled on the market, guaranteeing precision, flexibility, and cost-efficiency in both serial and individual production. Planing dimensions 30x30. Nsdpfx Ahexvnk He Deli

Condition: used, Year of construction: 2007, operating hours: 151,620 h, functionality: fully functional, machine/vehicle number: 0-250-04-2835, THE MACHINE IS USED FOR THE PRODUCTION OF PANEL FURNITURE. - LARGE WORKING AREA ALLOWS FOR MACHINING OF LARGER PANELS AND COMPONENTS - FAST AXES, WHICH CAN INCREASE PRODUCTIVITY WITH GOOD PROCESS ORGANIZATION Nodpfx Ahsxuhlno Doli - HIGH-QUALITY VACUUM CLAMPING TECHNOLOGY – SUITABLE FOR PROCESSING PANELS AND FURNITURE - WELL-KNOWN BRAND AND SERIES IN THE WOODWORKING/WOOD PROCESSING INDUSTRY, MAKING IT EASIER TO FIND SPARE PARTS AND SERVICE

Condition: like new (used), Year of construction: 2024, functionality: fully functional, machine/vehicle number: 6610231000922, Fully functional CNC drilling machine (like new). Nsdpjxt Na Rofx Ah Deli

Condition: like new (used), Year of construction: 2015, I sell the automatic CNC working centre for wooden constructions Hundegger K2i. Almost new machine. Year 2011. Under-table rotary saw with saw blade from 750 mm to 800 mm, 360 degree rotation, servohydraulic tilting 0 – 65 degrees universal 5-axis unit equipped with cylindrical milling cutter, end mill and end mill, milling head diameter 350 mm x 100 mm end mill Nlodpfsxtxkxjx Ah Dsi combi support for at least 5 tools with horizontal drilling device up to power from 2.5 to 3.0 kW, drilling diameter max 24 mm, drill length min 460 mm, machining depth min 300 mm combi support for at least 5 tools with horizontal drilling device up to power from 2.5 to 3.0 kW, drilling diameter max 24 mm, drill length min. 460 mm, machining depth min. 300 mm positioning and gripping of the material using arms, which, while the material is measured, transported to the desired location, the arms keep the processed element as close as possible to the tool that processes it for stability. the processed material can be rotated automatically tolerance +/- 2 mm at a length of 13 m Fully automatic wood input with input roller track and input and sliding cross conveyor K2i: Under-table tilting cross-cut saw K2i: Universal milling unit – 4-axis (UF4) K2i: Kombisupport for vertically working tools K2i: Drilling device (2.2 kW) – vertical drilling direction K2i: Kombisupport for horizontally working tools K2i: Drilling device (2.2 kW) – horizontal drilling direction K2i: Marking tool (rear or on the user side) K2i: Fully automatic element rotation – hydraulic K2i: Transport and positioning system “two-hand system” K2i: Electronic connection K2i: Roller track for removal wooden elements with a pusher K2i: 5-arm storage table K2i: Safety device K2i: Higher quality upper surface of the machine K2i: Extension of the K2i frame to 13.56 m K2i: 5-axis universal milling unit - UF5 (increase to 4-axis) K2i: Remote maintenance (including portable video camera) K2i: Dovetail milling machine (with rotating knives) 60x28x16.5 Suitable for wooden house constructions! Available immediately.

Condition: excellent (used), 5-axis machining center ALBERTI model POLAR EVOLUTION – Maximum working area 3500 x 1637 mm – Z-axis travel 600 mm, workpiece thickness on suction cups up to 160 mm – 2 phenolic resin work tables measuring 1600 x 1630 mm each: designed for alternating or synchronous operation, 'vacuum free' type, with holes connected to the vacuum system, reference points and retractable stops controlled by CNC, equipped with 13 double-chamber suction blocks (hoseless type) Nedoxr Ntnepfx Ah Deli – 250 m³/h vacuum pump – Automatic lubrication, optimized and centralized dust extraction – Electronic control with TPA and ALBATROS software, program display in Windows environment, EDI32-TPA editor (3D CAD-CAM) – Machine compliant with CE standards, with dual front retractable barriers (for loading/unloading both tables) and perimeter safety guards – Machine dimensions with safety guards installed: width approx. 7.7 m length approx. 7 m (including 2-m loading area) height approx. 3.5 m machine weight approx. 6500 kg Operating groups: 5-axis electrospindle HSK63F, power 8.5 kW (11 HP) with inverter, speed range 1,000–18,000 rpm – 12-position tool magazine at the rear – Automatic tool pick-up and changer with R.T.T. shuttle (very fast, independent and controlled movement of 2 carriages: one for receiving the tool from unloading and one for supplying the loading tool) – 2 drilling units mounted on the sides of the 5-axis head, a total of 17 vertical spindles plus a head with 2 horizontal spindles

Condition: used, Year of construction: 1994, functionality: fully functional, machine/vehicle number: 1232, total length: 23,000 mm, total width: 7,200 mm, total height: 2,550 mm, workpiece height (max.): 260 mm, type of input current: AC, space requirement width: 7,200 mm, space requirement length: 23,000 mm, space requirement height: 2,550 mm, workpiece width (max.): 400 mm, table width: 400 mm, air pressure: 8 bar, overall weight: 14,000 kg, Sales Description: Hundegger ABM-B P10 Joinery Line + HMC Planing Machine Manufacturer: Hundegger Model: ABM-B P10 incl. HMC Year of manufacture: 1994 Condition: Used, fully operational Location: Germany Technical Specifications: Processing range: Up to 260 x 400 mm Saw unit: With block separator and open base Milling units: Notch milling unit with right/left milling head Half-lap milling unit with right/left milling head Finger milling unit Vertical milling unit (ø 300 x 100 mm) Drilling units: Vertical drilling device Horizontal drilling device Rafter nail drill Chain mortiser: Vertical top/bottom with automatic chain lubrication Horizontal with combination unit Additional equipment: Marking device at the stop Positioning chain feed Nlsdpexrbizjfx Ah Doi Horizontal cross conveyor (2.2 m) Transfer cross conveyor (2.9 m) Ejector with storage supports Scraper control Planing Machine HMC (included): Year: 1994 4 feed motors 4 planing motors (7.5 kW) 4 bevelling motors Automatic centering unit Special Features: Fully automatic processing of single and series parts Control: PC-based with carpenter-friendly graphical interface + USB stick as floppy drive (BV transfer) Machine inspection under power possible Notes: All documentation available Self-collection only, ex works, without overhaul No warranty or guarantee Subject to prior sale

Condition: good (used), Year of construction: 2019, CNC through-feed center with dual clamp drive in X-direction and gantry design in Y-direction. The second gripper enables trimming down to 15 mm as well as continuous milling movement along the X-axis. The workpiece length is measured (X-direction) via sensor measurement. Working area: X-axis: 3,500 mm Y-axis: 950 mm Z-axis: 80 mm Milling spindle 12 kW HSK-F63, up to 24,000 rpm max. 4-position linear tool changer for milling tools. Max. tool diameter: 120 mm Max. tool length: 100 mm Single pick-up station for ergonomic insertion or removal of tools into the machine. Additionally usable as extra tool positions for up to 11 virtual tools. Automatic length measuring system for tools in Z-direction. Drilling head DH 25 8H 1S - 17 vertical spindles - 8 horizontal spindles - Grooving saw in X-direction Dowel insertion unit with 2 tools Dowel diameter: 8 mm, lengths: 20-25-30-35 or 40 mm Air cushion tables at front and rear, foldable Machine software WOODFLASH with: - CNC Board (general machine operation) - Tool database (Tecno-Manager) - Programming editor External workstation license Nledpfx Ajxrahcjh Dji Dongle upgrade: 3D simulator with collision check for WOODFLASH at the machine Release of workpiece at the rear side of the machine Machine is supplied without tools and HSK holders

Condition: used, Year of construction: 2015, POWER PC 85 + WOODWOP 6.0 control (updated in 2023) Working dimensions: 3050 x 850 mm Working thickness: 12 - 60 mm Drilling head with 19 independent spindles arranged as follows: - 8 vertical spindles on the X-axis - 5 vertical spindles on the Y-axis - 4 horizontal spindles on the X-axis - 2 horizontal spindles on the Y-axis 1 3-axis vertical router with automatic tool change 4-position automatic tool change 1 integrated blade unit - diameter: 100 mm Total installed power: 12 kW Weight: 1450 kg Nodpfxsxp Rqis Ah Djli

Condition: good (used), Year of construction: 2019, functionality: fully functional, feed length X-axis: 3,050 mm, feed length Y-axis: 850 mm, feed length Z-axis: 56 mm, power: 10 kW (13.60 HP), Homag drilling and milling machine Very compact machine Commissioned 6/2/2019, first owner Always maintained by Optimat, all invoices available Barcode scanner 13 vertical drills, quick-change system (left / right) 4 horizontal drills in X direction (left / right) 2 vertical drills in Y direction (left / right) 1 groove saw 100mm in X direction 4 tool changer positions for HSK63 router 10kW Workpiece length 200mm to 3050mm Workpiece width 70mm to 850mm Workpiece thickness (8)12mm to 56mm Machine measures each workpiece on X Y and Z, so incorrect workpieces cannot be input. Woodwop control Works perfectly, can be seen in operation. Available January 2026 Selling due to purchase of V310 Tools not included Nljdpfxjxpnkge Ah Doi 400V Can be loaded with forklift. Price 44,500 excl. VAT

Condition: ready for operation (used), Year of construction: 2020, functionality: fully functional, machine/vehicle number: 435.046, workpiece weight (max.): 75 kg, workpiece height (max.): 60 mm, rotational speed (max.): 20,000 rpm, workpiece length (max.): 5,600 mm, working width: 1,300 mm, TECHNICAL DETAILS Working width: 1,300 mm Workpiece dimensions Workpiece width (X): 60 - 1,300 mm Workpiece thickness (Z): 6 - 60 mm Workpiece length (Y): 263 - 5,600 mm Workpiece weight: max. 75 kg Drilling spindles: 13 vertical, 6 horizontal in Y, 2 horizontal in X Grooving unit: 1 in Y Milling unit motor power: 5.5 kW (S1) Speed range: 1,000–20,000 rpm Tool holder: HSK63F Maximum cutter length: 130 mm MACHINE DETAILS Electrical connection: 400 V, 3 phases, 50 Hz, 12 kVA, 17.5 A Nlodpfx Aexnyn Ieh Dji Air supply: 7 bar EQUIPMENT Counter-pressure device for 1,300 mm working width Foldable roller table 765 mm for front and rear of the machine, width 500 mm Auxiliary stop 600 mm with integrated rollers for roller tables Additional safety device with lamella curtain Extraction distributor: ∅ 160 mm / ∅ 80-80-80 mm, spacing 196 mm Documentation

Condition: used, Year of construction: 2016, MORBIDELLI AUTHOR M400 MAIN FEATURES 5-AXIS MACHINING UNIT "PRISMA: QUALITY AND PRODUCTIVITY AT THE HIGHEST LEVEL XILOG MAESTRO SOFTWARE: EXTREMELY SIMPLE MATIC PROGRAMMING" WORKTABLE: ONE POSITIONING FOR MULTIPLE MACHINING OPERATIONS TECHNICAL DATA AUTHOR M400 AXES Working area X-axis (inside stop) mm 3,680 Working area Y-axis (max. loadable piece on rear stops) mm 1,680 Workpiece passage Z / number of Z axes mm 170 / 1 Workpiece length with pendulum machining mm 1,650 Travel speed X-Y axes Pro-Speed m/min 85 Z-axis speed m/min 30 INSTALLATION Installed power KVA 62÷82 Compressed air requirement NL/min 400 Extraction air requirement m³/h 4,430 Extraction air speed m/s 25 Extraction nozzle diameter mm 250 GENERAL CHARACTERISTICS CNC-controlled drilling and milling center in gantry design and work table with workpiece supports, for carrying out: - vertical drilling on the panel surface - horizontal drilling on all four sides of the workpiece - groove milling with disc milling cutters - general milling work 3-4-5 axes MACHINE STRUCTURE The basic structure is a monolithic construction made of thick-walled steel. It is stiffened by welded reinforcements across the entire machine bed, making it extremely stable. The table shape used, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user optimal workflow with a minimum of space requirements. The mobile gantry support is made of a solid monoblock. It is positioned in the X direction on prismatic ground guides via recirculating ball slides. On this mobile unit carrier, the work unit is mounted on prismatic, ground guides and recirculating ball slides. All axes are moved on large-section prism linear guides and recirculating ball bearings with a large contact surface, ensuring optimal gliding even at the highest speeds and accelerations. Precise and rapid positioning of the movable gantry (X-axis) is achieved by a pinion and rack with helical teeth. Large-section recirculating ball screws ensure precise positioning of the work unit along the movable gantry (Y and Z axes). MOTORS, DRIVES AND INVERTERS Perfect mechanical dynamics and maximum positioning accuracy are controlled by high-quality drives and brushless motors, designed to achieve speeds of up to 90 m/min while ensuring the best finishing quality. CONTROL The control unit consists of a numerical control for milling and drilling machines with "Xilog Maestro" graphical user interface based on the Windows 7 Office operating system. 17-inch LCD color screen. QWERTY keyboard. Tilting control panel. Machine interface with Xilog Maestro software. Xilog Maestro Features Programming Parametric graphic programming Import of DXF files (2D; SPLINE, POLYLINE 3D geometries), linear or circular interpolation in three axes, linear in space, spiral in the selected plane. Programming with graphic and syntax aids for drilling and milling operations Automatic optimization of drilling operations and tool change cycles Possibility of Plate zero point shift for drilling on inclined or curved plate sides Nlsdpjxnldbjfx Ah Dei

Condition: used, Year of construction: 2019, Operating hours: approx. 27,500, with 8-position tool changer, travel distances (X/Y): 3,080 x 2,200 mm, vacuum clamping table approx. 300 x 250 cm, with roller conveyor approx. 350 x 220 cm, elevated with extraction beam, extraction connection, spindle cooling, safety light barrier and safety fence, protective cabinet, operator terminal, spindle speed approx. 22,000 rpm, 1 scissor lift table approx. 286 x 220 cm, 2 vacuum lifters, 1 cooling unit, 3 vacuum pumps, 1 PC terminal with PC, 1 HP E230 flat screen, keyboard and mouse. Nledpfx Asxnamqoh Dsi

Condition: used, Year of construction: 2007, with 3 drilling stations, workpiece dimensions: length: 18.5-120 cm, width: 9-70 cm, thickness: 1.2-3.2 cm, with loading station PBA-22-CNC, serial no.: 1823, unloading station PBA-22-CNC, serial no.: 1825, vacuum lifter, roller conveyor, safety enclosure Nedpfx Ahjxnadij Dsli
