Condition: ready for operation (used), Year of construction: 1998, operating hours: 4,197 h, functionality: fully functional, saw blade diameter: 850 mm, saw blade bore: 10 mm, TECHNICAL DETAILS Saw Blade Diameter (without loader): 80 – 850 mm Saw Blade Diameter (with loader): 250 – 450 mm Bore Diameter (from): 10 mm Saw Blade Magazine: up to 40 pcs Control and Software Bjdpoypbx Ejfx Ah Ield Control: Industrial PC with Siemens standard PLC Software: For all tooth shapes, including special profiles Grinding Process Sequence 1st Step: After starting, the vacuum gripper picks the topmost saw blade from Magazine 1. It is transferred to the Woodtronic NC4, the guard is opened. 2nd Step: The loader returns. The Woodtronic NC4 is closed and the grinding program is initiated. The loader removes the spacer ring from Magazine 1 and transfers it to Magazine 2. Waiting position. 3rd Step: After the grinding process and the opening of the Woodtronic, the loader removes the ground saw blade and transfers it to Magazine 2. Process Repetition Steps 1 to 3 are repeated until the grinding operation is completed. Pre-programming possible: Grinding can run without interruption even while programming the next magazine. The Woodtronic NC4 can be pre-programmed during the day and performs automatic grinding at night. Measurable with WALTER Saw Check: Rake angles, clearance angles, diameter, number of teeth Tooth shape: manual input required EQUIPMENT - Automatic loader - Walter Saw Check - Measuring device for carbide-tipped circular saw blades

Condition: used, Year of construction: 2021, Suitable for connection to a Vollmer CHD 250/CHD 251/CHD 270, CHF 270/CHF 350 carbide sawblade grinding machine. Loading system for sawblades with a diameter of up to 840 mm. Accessories: Bledoymydzspfx Ah Ijd 2 loading trolleys Data entry station DES 400 Oil collection tray Simplest stack circular saw blade outside diameter: 200 to 840 mm double stack: 200 to 410 mm maximum saw blade weight single-sided occupancy: 20 kg double-sided occupancy: 11 kg Bore diameter: 16 to 180 mm sheet thickness: up to 5 mm Stack height: < 300 mm Connected load approx.: 3,2 kVA (400 V / 50 Hz) Weight approx: 1680 kg colour: Gray RAL 7035

Condition: used, Year of construction: 1989, functionality: fully functional, Used in good condition Bodpfeymlr Rex Ah Ield

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, saw blade diameter: 650 mm, Central suction needed, with oil cooling Bljdpfx Ahoymlrde Iod

Condition: used, Year of construction: 2007, Suitable for attachment to a carbide saw blade grinding machine of the type Vollmer CHD 250/CHD 251/CHD 270, CHF 270/CHF 350, loading system for saw blades with up to 630 mm diameter. Accessories: Data input station DES 300 2 loading carts oil collection pan, automatic central lubrication, control cabinet cooler. Simplest stack circular saw blade outside diameter: 100 to 630 mm double stack: 100 to 305 mm maximum saw blade weight single-sided occupancy: 9 kg double-sided occupancy: 6 kg Bore diameter: 16 to 180 mm sheet thickness: up to 5 mm Stack height: < 300 mm Connected load approx.: 1,8 kVA (400 V / 50 Hz) Dimensions W x D x H approx.: 3130 x 1660 x 2000 mm Blodpfxoylh Ske Ah Ijd Weight approx: 1250 kg colour: Grey RAL 7035

Condition: used, Year of construction: 2014, Suitable for attachment to a carbide saw blade grinding machine of the type Vollmer CHD 250/CHD 251/CHD 270, CHF 270/CHF 350, loading system for saw blades with up to 630 mm diameter. Accessories: DES 300 data input station 3 loading trolleys Oil collection tray, Automatic central lubrication, Control cabinet cooler. Simplest stack circular saw blade outside diameter: 100 to 630 mm double stack: 100 to 305 mm maximum saw blade weight single-sided occupancy: 9 kg double-sided occupancy: 6 kg Blodpfx Aeylhtuoh Isd Bore diameter: 16 to 180 mm sheet thickness: up to 5 mm Stack height: < 300 mm Connected load approx.: 1.8 kVA (400 V / 60 Hz) Weight approx: 1400 kg colour: Gray RAL 7035

Condition: used, Year of construction: 1980, functionality: fully functional, Sharpening machine for circular saw blades, with bevel grinding Blodjyi Ek Sepfx Ah Iod

Condition: good (used), Year of construction: 1977, functionality: fully functional, Sharpening machine for HSS saw blades, SCHMIDT-TEMPO ASG500A Bedpfx Ahjyizv Re Ield Technical Features The machine is characterized by the following key specifications: Grinding range: Suitable for saw blade diameters from approx. 20 mm to 500 mm. Drive: Mechanically controlled feed (often using change gears for different tooth counts). Tooth profiles: Generally suitable for standard tooth profiles such as A, B, and C.

Condition: good (used), Year of construction: 1990, functionality: fully functional, saw blade diameter: 1,600 mm, Sharpening Machine for Metal HSS Saw Blades. Technical Specifications: - Saw blade diameter: approx. 20 mm to 500 mm (other sources state capacities from 20–400 mm). - Saw blade thickness: maximum 6 mm. - Working speed: steplessly adjustable from approx. 40 to 140 strokes per minute. - Grinding wheel diameter: max. 200 mm. - Tooth count: electronically pre-selectable from 20 to 999 teeth. - Weight: depending on configuration, between approx. 900 kg and up to 1.2 t. Bsdpfx Ahsyfumzj Ield Functions and Adjustment Options: The machine offers comprehensive machining options for different tooth geometries: - Supported tooth forms: Alternate top bevel tooth, high arc tooth, and flat arc tooth according to DIN 1840 (tooth forms A, B, BW, C). - Automation: Automatic infeed of the grinding wheel and an automatic dressing device. - Grinding modes: Supports relief grinding, oscillating grinding, and cylindrical grinding. Control: - Equipped with an LED display and error notification panel for monitoring the grinding process. Drive: - Separate motors for the indexing mechanism and the grinding wheel. Space requirements: - The dimensions for used models are specified at approx. 1200 mm width.

Condition: excellent (used), for grinding saw blade diameters from 30 up to max. 300 mm Bodpfoycqmlox Ah Iold Grinding wheel diameter 150 mm, lots of accessories good, well-maintained condition Operating manual is available

Condition: ready for operation (used), Year of construction: 1988, functionality: fully functional, We are selling the EMS 10 U machine, year 1988, no. 187. Bedpfjycfy Hjx Ah Isld It is in good condition – see photos! The technical specifications can be found in the operating manual; please refer to the documents at the link below! The machine was used in our facility for frame saw blades. The original operating manual is included as well. Please feel free to make us an offer! Pickup in 6858 Schwarzach.

Condition: good (used), Year of construction: 2016, operating hours: 3,000 h, Dinaco grinding machine, for sharpening band saw blades. The machine is refurbished, features automatic grinding wheel alignment, water cooling, and allows for grinding of vario tooth shapes. Bjdpfx Ahjx Tguhs Iold

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: CHD 251R2, grinding wheel diameter: 200 mm, input current: 380 A, We offer this excellent condition Vollmer CHD 251R2 ND300 saw-blade sharpening machine. The CHD 251 R2 automatic grinding machine with ND 230 Robot system as a service for fully automatic machining with 5 bay loading. Year of construction 2002. Manufacturer: Vollmer Werke Maschinenfabrik GmbH Model: CHD 251R2 ND300 Year of manufacture: 2002 Serial number: 575 Bledpjx R Eydsfx Ah Iod Available Now If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: excellent (used), Year of construction: 1994, VOLLMER CHP 025 with Hollow face teeth and cheap breaker teeth device Bsdpfx Ajx Rrilsh Iold

Condition: excellent (used), Grinding Machine LOROCH type: AK very good condition Blsdpfx Aexn Uitsh Isd loaded on a truck fixed price

Condition: new, Year of construction: 2025, The ZM101 is a pioneering product in our lineup, designed to sharpen sawblades with widths of up to 100 mm at a remarkable rate of 65 teeth per minute. This efficiency enables it to simultaneously service 3-4 bandsaw/sawmill machines. Equipped with an abrasive ceramic disk, the ZM101 can expertly sharpen all teeth with profiles. Its robust construction allows it to perform reliably under the most demanding conditions, making it a favorite among our customers. Additionally, its straightforward design ensures ease of use and low maintenance costs, further enhancing its appeal. Technical characteristics: Maximum length of the blade: 6000 (8000) mm Minimum width of the blade: 20 mm Maximum width of the blade: 100 mm Bjdpsxligujfx Ah Ijld Maximum height of the tooth: 12 mm Front angle of the tooth: 0÷25° Tooth pitch: Profile N: 10, 12.5, 15, 20, 25 mm Profile WM: 22, 25 mm Working capacity: 65 teeth/min Size of the abrasive disc: Cut-in sharpening, profile N: ø200 x 10 x ø32, ø200 x 13 x ø32 mm Profile sharpening, profile WM: ø200 x 8 x ø32, ø200 x 10 x ø32 mm Voltage: 380 V Power of the electric motors: 0.09 and 0.37 kW Size: Without band saw holder (L x W x H): 750 x 550 x 1100 mm With band saw holder (L x W x H): 2000 (3000) x 1000 x 1100 mm

Condition: new, Year of construction: 2025, The ZM101 is a pioneering product in our lineup, designed to sharpen sawblades with widths of up to 100 mm at a remarkable rate of 65 teeth per minute. This efficiency enables it to simultaneously service 3-4 bandsaw/sawmill machines. Equipped with an abrasive ceramic disk, the ZM101 can expertly sharpen all teeth with profiles. Its robust construction allows it to perform reliably under the most demanding conditions, making it a favorite among our customers. Additionally, its straightforward design ensures ease of use and low maintenance costs, further enhancing its appeal. Technical characteristics: Maximum length of the blade: 6000 (8000) mm Minimum width of the blade: 20 mm Maximum width of the blade: 100 mm Maximum height of the tooth: 12 mm Front angle of the tooth: 0÷25° Tooth pitch: Profile N: 10, 12.5, 15, 20, 25 mm Profile WM: 22, 25 mm Bodpfexlfwpox Ah Ield Working capacity: 65 teeth/min Size of the abrasive disc: Cut-in sharpening, profile N: ø200 x 10 x ø32, ø200 x 13 x ø32 mm Profile sharpening, profile WM: ø200 x 8 x ø32, ø200 x 10 x ø32 mm Voltage: 380 V Power of the electric motors: 0.09 and 0.37 kW Size: Without band saw holder (L x W x H): 750 x 550 x 1100 mm With band saw holder (L x W x H): 2000 (3000) x 1000 x 1100 mm

Condition: excellent (used), Year of construction: 2014, Manufacturer: Henrik WINTER HOLZTECHNIK GmbH (Leipzig, Germany) Model / type: SAWMAX 600 Year of manufacture: 2014 Serial number: 130705-28 Power supply: 3×400 V, 50 Hz Maximum power: 1.69 kW Bsdpfsw R E Slox Ah Ijld Weight: 650 kg Certificate: CE

Condition: used, Year of construction: 2004, Suitable for automatic grinding or re-serration and chamfering of HSS and segment saw blades as well as solid carbide saws with ceramic grinding wheels and deep grinding with CBN or diamond grinding wheels. Accessories: Total enclosure, Sawblade magazine with 3 saw blade stacks each with a stack height of 250 mm (for approx. 35 saw blades each) #9007511, Device for automatic chamfering of sawblades from Ø 145 mm, Automatic threading of the grinding wheel, Automatic fire extinguishing system, Automatic central lubrication, Bedpfx Ahew I Sk Ne Isld Coolant system 400 L with coolant tank with filter system, Machine lamp, Oil collecting tray, 3 sawblade mandrels (loader). Saw diameter: 40-710mm Tooth pitch: 1 - 55mm Number of teeth: 2 - 998 Saw blade thickness: max. 8 mm Grinding wheel diameter: 200x32mm Connected load: 10kW (400V / 50Hz) mass: about 3200 kg Dimensions: L x W x H = 1198 x 1750 x 2015 mm colour: blue/grey RAL 7047 / blue RAL 250-50-20.

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: 86731, saw blade diameter: 760 mm, tooth pitch: 25 mm, grinding wheel diameter: 200 mm, saw blade width: 8 mm, grinding wheel width: 32 mm, No reserve price – guaranteed sale to the highest bidder! Placing a bid commits you to collect the machine on time between 28.07.2025 and 31.07.2025. TECHNICAL SPECIFICATIONS Saw blade diameter: 140 – 760 mm Saw blade tooth pitch: 1 – 25 mm Number of teeth: 2 – 998 Saw blade thickness: up to 8 mm Grinding wheel dimensions: 200 x 32 mm Bledewvi S Ujpfx Ah Isd MACHINE DETAILS Overall width: 1,500 mm Overall length: 1,500 mm Overall height: 2,000 mm Total weight: 1,500 kg Voltage: 400 V Frequency: 50 Hz Rated power: 8 kVA Current consumption: 16 A

Condition: used, Year of construction: 1974, Technical details: Bjdpfjwqplkjx Ah Isld total power requirement: 1,65 kW weight of the machine approx.: 620 kg Saw Blade Sharpening Machine Machine not complete - grinding spindle motor missing! for sale as spare part dispenser! *

Condition: used, Year of construction: 2010, Suitable for automatic grinding of tooth faces, tooth backs, and bases on carbide-tipped circular saw blades in a single setup. All common tooth geometries (flat, alternate, trapezoidal, etc.) can be ground automatically and in a single pass. Accessories: Full enclosure Measuring probe Grinding device with oil cooling Automatic fire extinguishing system Grinding mist extraction system N 183 Alphanumeric keypad Oil drip tray Machine light saw diameter: 80-840 mm Bore diameter: from 10 mm Blsdpfxjwp Ebls Ah Ied sheet thickness: < 8 mm Tooth pitch: 6 - 120 mm Cutting length:

Condition: excellent (used), Year of construction: 1984, functionality: fully functional, machine/vehicle number: 137, total width: 2,800 mm, total length: 700 mm, total height: 1,700 mm, type of input current: three-phase, Bandsaw grinding machine Risstaler riv Rivo 200 GA Year of manufacture 1984 Bjdpfxswd N Daj Ah Ijld Various tooth shapes available Operating instructions included Feed rate 30 or 60 teeth per minute

Condition: new, Year of construction: 2026, functionality: fully functional, BAS 100 (STA) – Upsetting machine for band and gang saws, automatically hydraulically controlled Upsetting the saw teeth, in addition to setting, is another method to ensure free cutting of the saw during machining. During the upsetting process, an upsetting pin is positioned in front of the saw tooth, while the tooth is held against an anvil. By rotating the eccentric upsetting pin, the saw blade material is displaced toward the tip of the tooth. Once the upsetting process is completed, the upsetting pin automatically returns to its original position. Bsdpfx Aov Tqzyoh Ield

Condition: new, Year of construction: 2026, functionality: fully functional, Automatic Sharpening Machine for Frame Saws – GAP 100 (Machine available from January 2026) The automatic profile grinding machine GAP 100 has been specially developed for the precise sharpening of frame saws. Its compact and highly robust design guarantees a long service life and maximum reliability in daily operation. Equipped with advanced technology and an easy-to-use control system, the GAP 100 offers high functionality – both for standard applications and for demanding grinding tasks. An excellent price-performance ratio, minimal maintenance requirements, and intuitive operation make this machine the ideal choice for sawmills that value quality, efficiency, and cost-effectiveness. Bedpjv Tl Arsfx Ah Iold The GAP 100 consistently delivers precise grinding results, reduces your operating costs, and sustainably increases your productivity.
