Clau De Misena S.l.

Condition: excellent (used), Year of construction: 2022, operating hours: 766 h, lifting height: 5,000 mm, fuel type: electric, mast type: triplex, total height: 2,460 mm, total length: 4,500 mm, total width: 1,430 mm, color: other, Year of manufacture: 2022 Empty weight: 8.080 kg Lifting capacity: 5.000 kg CE mark: yes Technical condition: very good Visual appearance: very good General Country of production: China Gtodsx U Eqkepfx Aa Ist Condition CE type: CE Fork positioner and side shift, lithium battery with charger, closed cabin

Condition: excellent (used), Year of construction: 2022, operating hours: 205 h, lifting height: 4,800 mm, fuel type: gas, mast type: triplex, total height: 2,230 mm, total length: 2,900 mm, total width: 1,200 mm, color: other, Year of manufacture: 2022 Empty weight: 4.750 kg Gtsdpfx Aaox U Ep To Iot Lifting capacity: 3.000 kg CE mark: yes Technical condition: very good Visual appearance: very good General Country of production: China Condition CE type: CE

Condition: excellent (used), Year of construction: 1996, turning diameter 380 mm turning length 750 mm control HEIDENHAIN ManualPlus total power requirement 9 kW weight of the machine ca. 2 t Gtjdpfx Aaox U Encj Ist dimensions of the machine ca. 2,4 x 1,7 x 1,7 m

Condition: used, Year of construction: 2005, x-travel 800 mm y-travel 550 mm z-travel 550 mm table dimensions 1.150 x 550 mm Control Matsuura G-Tech 30i spindle tunring speed 12.000 U/min tool taper BT 40 In our assessment, the machine is in good used condition and can be inspected under power by appointment. Gsdpfx Asx U Em Eea Iett Technical features & accessories: - Internal coolant supply (ICS) - 4th axis (Nikken) Accessories, tools, and clamping devices shown are only included if specifically stated in the additional information. Technical data and specifications are subject to change without notice. Prior sale is reserved.

Condition: used, mileage: 157,500 km, power: 170 kW (231.14 HP), first registration: 05/2014, fuel type: diesel, empty load weight: 7,640 kg, maximum load weight: 4,350 kg, overall weight: 11,990 kg, tire size: 10R22.5, axle configuration: 4x2, wheelbase: 3,560 mm, next inspection (TÜV): 03/2026, brakes: constant throttle, color: white, driver cabin: day cab, gearing type: automatic, emission class: euro6, suspension: steel, number of seats: 2, loading space length: 4,000 mm, loading space width: 2,350 mm, loading space height: 500 mm, Equipment: ABS, additional headlights, air conditioning, cabin, central locking, crane, cruise control, differential lock, electronic stability program (ESP), fog lights, onboard computer, power assisted steering, seat heater, traction control, trailer coupling, Vehicle location: Bovenden. ClassicSpace cabin, Mercedes PowerShift 3, steel superstructure, designation: house, 1x comfort seat, seat heating, rear window, electric mirrors, heated mirrors, electric window (left), electric window (right), air conditioning, sun visor, cruise control, ABS (anti-lock braking system), traction control (ASR), constant throttle, PTO, frame cover, differential lock, leaf suspension, towing hitch with air, light, and hydraulic connections, lashing eyes, underrun protection, swinging tailgates, roof hatch, crane mounted behind cab, foldable, 2-point hydraulic outriggers, radio remote control, 3x hydraulic extensions, green environmental badge. Wheelbase: 3560 mm. Superstructure: Meiller 3-way tipper with lashing eyes & Palfinger PK 9002 EH B crane with radio remote control. 5.3 t front axle, rear axle hypoid 11 t, crown wheel 390, rear axle differential lock, EBS with ABS and ASR, disc brakes on front axle, drum brakes on rear axle, condensation monitoring for compressed air system, rear axle stabilizer, steel front underrun protection, classic cockpit, pollen filter, ClassicSpace, PSM, reversing alarm, power drive mode, Mercedes PowerShift 3, daytime running lights, High Performance Engine Brake, ESP, Meiller 7-piston pump type 270/45, PTO MB 60-2c MPA low speed. Load chart: 3.9 m – 2200 kg, 5.8 m – 1420 kg, 7.7 m – 1040 kg, 9.7 m – 800 kg. Grab attachments available at extra cost! ACCESSORY INFORMATION WITHOUT GUARANTEE. Subject to change, prior sale, and errors excepted! Gtjdpfex U Emljx Aa Iot

Condition: excellent (used), Year of construction: 2018, sheet width 1040 mm plate thickness 3.00 mm ST diameter of upper rolls 100 mm side roll diameter 100 mm diameter of lower rolls 100 mm speed 6.0 m/min semi-automatic operated FM 2.1R voltage 400 V total power requirement 2.2 kW weight of the machine ca. 740 kg range L-W-H 2250 x 825 x 1910 mm Gtsdjx U Emfopfx Aa Iet Very well-kept condition (almost as good as new)! current new price including accessories ~ 28.000 Euro special price on request Start and finish rounding is very easy with this machine thanks to the special concept, the extensive accessories and the robust construction. Machine for for one-off production and series production = extremely universal and economical. Equipment: - Robust electro-mechanical three-roll round bending machine - Driven by spur gear brake motor Primary reduction gear - Top roller Side roller electrically driven - Asymmetrical roll arrangement - Manual bottom roll adjustment * with analog position indicator - FASTI control unit "FM 2.1R" * Setting max./min. max./min. travel value side roller - Swing-out top roller, with hinged bearing - Conical bending device - 1x freely movable double foot switch * Right / left rotation of the rollers - Electrical safety device (cable) - original operating instructions

Condition: excellent (used), Year of construction: 2018, plate thickness 2.0 mm throat max. 400 mm Roller center distance min/max 100/120 mm piston stroke max. 20.0 mm turning speeds 3.0 - 15.0 U/min voltage 400 V total power requirement 2.95 kW weight of the machine ca. 385 kg range L-W-H 1200 x 800 x 1200 mm very good condition (almost like new) !!! Equipment: - heavy / robust electro-motorized beading machine - electro-motor drive - infinitely variable speed adjustment - internal gear brake motor - electro-hydraulic infeed of the top roller - 1x adjustable stop plate Gjdpfxex U El Us Aa Iett - 1x freely movable double foot switch (R/L run) - 2x set of beading/conveyor rollers - original operating instructions

Condition: excellent (used), Year of construction: 2023, tube diameter 42.0 x 3.0 STAHL mm tube diameter 30.0 x 2.0 EDELST mm bending angle max. 180 ° bending radius max. 100 mm bending speed 2.0 U/min. Control NC voltage 400 V total power requirement 0.55 kW weight of the machine ca. 115 kg Current new price approx. 4.200 Euro Very good condition / with machine base Description: - NC electro-motor tube bending machine - mandrelless * up to 50 programs can be stored - Automatically returns to the starting position - Maximum bending capacity for 42 x 3.0 mm steel tubes - Excellent bending quality with very tight bending radii (from 2x tube diameter) . and bending angles between 0° and 180° Gtedex U El Ispfx Aa Iet - Easy operation - High accuracy and reliability - Quick tool change (within seconds) - Easy to transport - Includes machine base

Condition: good (used), Year of construction: 2011, x-travel 1020 mm y-travel 610 mm z-travel 610 mm control Heidenhain iTNC 530 table surface area 1200 x 600 mm table load capacity 500 kg spindle drive 25 kW max. torque on the milling spindle 159 Nm spindle turning speed - stepless 30 - 12.000 U/min numbers of tools in magazin 60 Stck. / pcs tool taper SK 40 Big Plus rapid traverse 40 / 40 / 36 m/min total power requirement 25 kVA weight of the machine ca. 8,0 t dimensions of the machine ca. 5,50 x 3,50 x 2,90 m Gsdox U Elzepfx Aa Iett Universal machining center for complete machining in good condition:(perfect for low-manpower / unmanned production) Equipment: • Heidenhain iTNC 530 cnc control system • 60-position tool changer with double-arm gripper • LEHMANN 5-axis precision rotary table mounted on machine table • INDUMATIC - Light25 workpiece pallet changer • Automatic system for loading and unloading up to 50 workpieces • Storage and retrieval station • INDUNORM setup truck – mobile setup station • 3D measuring probe for workpiece and tool measurement (wireless) • Coolant supply through the spindle 50 bar / switchable 20/50 bar • Oil mist extraction system • Spindle oil cooler • 2 internal spiral conveyors inside • 1 Chip conveyor • Portable electric handwheel The machine can be inspected under power!

Condition: good (used), mileage: 747,637 km, power: 345 kW (469.07 HP), first registration: 02/2016, fuel type: diesel, axle configuration: 4x2, fuel: diesel, brakes: retarder, color: white, driver cabin: sleeper cab, gearing type: automatic, emission class: euro6, suspension: steel-air, Year of construction: 2016, Equipment: AdBlue, Bluetooth, EBS, air conditioning, cruise control, electric window regulation, fog lights, parking heater, power mirror, retarder, second fuel tank, soot filter, spoiler, = Additional Options and Equipment = - Aluminum fuel tank - Bluetooth - Power brake booster - EPS (Electronic Power Steering) - Low noise emissions - Particulate filter - Radio/CD player - Rain sensor - Sunroof - Sleeper cab - Side door - Auxiliary heater - Toolbox = Additional Information = Front axle: Steering; Suspension: Leaf spring Rear axle: Suspension: Air suspension Unladen weight: 7,791 kg Payload: 11,209 kg Gross vehicle weight: 19,000 kg Periodic technical inspection (APK): valid until 03/2026 Technical condition: good Visual condition: good Please contact Emad Al Shogran for further information. Vehicle number: 108 Renault T 460 / Retarder / 2 x Tank / Euro 6 VIN: VF611A16XGD014753 Transmission: Automatic Suspension: Leaf/Air Air conditioning Retarder Auxiliary heater Adaptive cruise control 2 x Tank Gedpfxsx U Elus Aa Iott Euro 6 = Company Information = Al Shogran GmbH An der Glashütte 15 41516 Grevenbroich Tel.: Mobile: Ms. Sabine Faust Email:

Condition: new, neu ca. 12 - 14 Wochen ab Auf Türkei 269588 € 3 kW Wechseltisch 16 mm 8 mm 8 mm 5 mm 8 mm 29,9 (mit Absaugung) kW 6100 x 2070 mm 6100 mm 2070 mm 125 mm 6096 x 2032 mm 240 (für 3 - 12kW) / 400 kg/m² 5800 (für 3 - 12kW) / 960 kg 100 m/min 100 m/min 141 m/min 14 m/s² +/- 0,05 mm +/- 0,05 mm 42 s The HD-FN has two tables which are automatically switched alternately to enable simultaneous cutting and loading/unloading. The shuttle table is positioned longitudinally, which results in the best possible accessibility for optional loading and unloading systems. Control, laser source and cooling are integrated into the machine. The cutting head has automatic focus adjustment. The system consists of the following components: Shuttle table (positioned longitudinally for best possible accessibility for optional loading and unloading systems) Encapsulated cutting room with protective glazing CNC graphic control with touchscreen Laser source Brilase Premium Cutting head with automatic focus adjustment Integrated cooling unit for cutting head and laser source CAD/CAM software Lantek for programming including autonesting Positioning laser Sheet check system (automatic detection of sheet position and dimensions) Automatic nozzle cleaning Central lubrication Slug box Working area lighting Multi-chamber suction system Light barrier protection for the changing table Remote maintenance access Air condition for electrical cabinet Equipped according to CE guidelines ALTERNATIVE LASER SOURCES: Material 4 kW 6 kW 12 kW 15 kW 20 kW Mild steelS235 20 25 30 35 40 Stainless steel(304) 10 15 25 35 40 Gjdpfxex U Elno Aa Iett Aluminium (5083) 12 20 30 35 40 Copper 6 10 15 15 15 Brass(CuZn39 Pb3) 10 12 20 20 20 OPTIONS: Suction unit with filter Automatic nozzle change

Condition: new, neu ca. 12 - 14 Wochen ab Auf Türkei 174688 € 3301.6 € 3 kW Gtsdpex U Elhjfx Aa Iot Manueller Tisch 16 mm 8 mm 8 mm 5 mm 8 mm 3060 x 1530 mm 3060 mm 1530 mm 140 mm 3048 x 1524 mm 160 kg/m² 90 m/min 90 m/min 127 m/min 14 m/s² +/- 0,05 mm +/- 0,05 mm The HD-FO is our compact entry-level model. Control, laser source and cooling are integrated into the systemto keep the overall dimensions as small as possible. The manually extendable table is moved out of the side of the machine for loading and unloading. The cutting head has automatic focus adjustment. This makes the system a particularly economical, fast and very easy to operate production machine. The system consists of the following components: Manual loading and unloading table Encapsulated cutting room with protective glazing CNC graphic control with touchscreen Laser source Brilase Premium DRM-8 F150 Cutting head with automatic focus adjustment Integrated cooling unit for cutting head and laser source CAD/CAM software LANTEK for programming including autonesting Positioning laser Sheet check system (automatic detection of sheet position and dimensions) Automatic nozzle cleaning Slug box Working area lighting Multi-chamber suction system Remote maintenance access Aircondition for electrical cabinet Equipped according to CE guidelines ALTERNATIVE LASER SOURCES: Material 4 kW 6 kW Mild steelS235 20 25 Stainless steel(304) 10 15 Aluminium (5083) 12 20 Copper 6 10 Brass(CuZn39 Pb3) 10 12 OPTIONS: Suction unit with filter Shuttle table

Condition: new, neu ca. 12 - 14 Wochen ab Auf Türkei 188488 € 3562.42 € 3 kW Wechseltisch 16 mm 8 mm 8 mm 5 mm 8 mm 26,4 (mit Absaugung) kW 3100 x 1525 mm 3100 mm 1525 mm 125 mm 3084 x 1524 mm 240 (für 3 - 12 kW) / 400 kg/m² 2200 (für 3 - 12kW) / 360 kg 100 m/min 100 m/min 141 m/min 14 m/s² +/- 0,05 mm +/- 0,05 mm 25 s The HD-FN has two tables which are automatically switched alternately to enable simultaneous cutting and loading/unloading. The shuttle table is positioned longitudinally, which results in the best possible accessibility for optional loading and unloading systems. Control, laser source and cooling are integrated into the machine. The cutting head has automatic focus adjustment. The system consists of the following components: Shuttle table (positioned longitudinally for best possible accessibility for optional loading and unloading systems) Encapsulated cutting room with protective glazing CNC graphic control with touchscreen Laser source Brilase Premium Cutting head with automatic focus adjustment Integrated cooling unit for cutting head and laser source CAD/CAM software Lantek for programming including autonesting Positioning laser Sheet check system (automatic detection of sheet position and dimensions) Automatic nozzle cleaning Central lubrication Slug box Working area lighting Multi-chamber suction system Light barrier protection for the changing table Remote maintenance access Air condition for electrical cabinet Equipped according to CE guidelines ALTERNATIVE LASER SOURCES: Material 4 kW 6 kW 12 kW 15 kW 20 kW Mild steelS235 20 25 30 35 40 Stainless steel(304) 10 15 25 35 40 Aluminium (5083) 12 20 30 35 40 Copper 6 10 15 15 15 Brass(CuZn39 Pb3) 10 12 20 20 20 OPTIONS: Suction unit with filter Sheet handling systems Automatic nozzle change Gtedpfx Aajx U Elbo Iet

Condition: used, mileage: 500,610 km, power: 213 kW (289.60 HP), first registration: 08/2008, fuel type: diesel, tire size: 315/80R22,5, axle configuration: 4x2, wheelbase: 4,800 mm, fuel: diesel, color: white, gearing type: mechanical, number of gears: 8, emission class: euro4, suspension: steel, loading space length: 5,230 mm, loading space width: 2,480 mm, loading space height: 600 mm, Year of construction: 2008, Equipment: crane, electric window regulation, Drivetrain Drive: Wheel Gtodsx U Ek Rspfx Aa Ist Axle configuration Tyre size: 315/80R22,5 Suspension: leaf suspension Rear axle: Double wheels Weights Empty weight: 10.590 kg Carrying capacity: 8.410 kg GVW: 19.000 kg Functional Mast: telescopic (1 part) Make of bodywork: FASSI F110A21 Tipper: Back

Condition: used, mileage: 357,418 km, power: 316 kW (429.64 HP), first registration: 06/2018, fuel type: diesel, tire size: 385/65R22.5, axle configuration: 6x4, wheelbase: 3,300 mm, fuel: diesel, fuel tank capacity: 290 l, color: grey, gearing type: automatic, emission class: euro6, suspension: steel-air, Year of construction: 2018, Equipment: air conditioning, electric window regulation, Front axle: Tyre size: 385/65R22.5; Suspension: leaf suspension Gjdpfxex U Ek Do Aa Iott Rear axle 1: Tyre size: 315/80R22.5; Double wheels; Suspension: air suspension Rear axle 2: Tyre size: 315/80R22.5; Double wheels; Suspension: air suspension Drive: Wheel Number of cylinders: 6 Engine capacity: 10.677 cc GVW: 26.000 kg Make of engine: Mercedes-Benz

Condition: used, color: yellow, tire size: 10x24, axle configuration: 4x4, first registration: 12/2017, Year of construction: 2017, operating hours: 11,400 h, Equipment: all wheel drive, Tyre size: 10x24 Gtsdpfx Aex U Ekwea Iot Wheelbase: 260 cm

Condition: used, mileage: 371,321 km, power: 132 kW (179.47 HP), first registration: 11/2004, fuel type: diesel, tire size: 225/75/r17,5, axle configuration: 4x2, wheelbase: 2,700 mm, fuel: diesel, color: white, gearing type: mechanical, suspension: steel, loading space volume: 6 m³, Year of construction: 2004, Equipment: air conditioning, electric window regulation, General information Applicable material: Fuel Technical information Number of cylinders: 4 Drivetrain Gjdpfx Aaex U Ekqj Ijtt Drive: Wheel Make of engine: Renault Axle configuration Tyre size: 225/75/r17,5 Suspension: leaf suspension Rear axle: Double wheels Weights Empty weight: 4.600 kg Carrying capacity: 5.400 kg GVW: 10.000 kg Functional Number of compartments: 3

Condition: used, mileage: 255,545 km, power: 90 kW (122.37 HP), first registration: 12/2020, fuel type: diesel, tire size: 215/65r16c, axle configuration: 4x2, wheelbase: 3,250 mm, fuel: diesel, color: grey, gearing type: mechanical, number of gears: 6, emission class: euro6, suspension: steel, Year of construction: 2020, Equipment: air conditioning, electric window regulation, Tyre size: 215/65r16c Suspension: leaf suspension Drive: Wheel Number of cylinders: 4 Engine capacity: 1.997 cc Empty weight: 1.810 kg Gtodpfex U Eitox Aa Ist Carrying capacity: 1.290 kg GVW: 3.100 kg

Condition: new, Spiral mixer S 75 Ital Form Mixer dimensions: 1250x810x1410mm Bowl dimensions: 750x440mm Gsdox U Eigopfx Aa Istt Dough capacity: 120kg Flour capacity: 75kg Mixer power: 9kW Bowl power: 1.2kW Voltage: 380V / 50Hz Mixer speed: 123-245rpm Bowl speed: 20rpm Net weight: 376kg

Condition: used, Single-Column Eccentric Press RASTER ZEULENRODA Type PDA 100 Year of manufacture: 1995 Pressing force: 100 tons Throat depth: approx. 360 mm Table size: 1200 x 710 mm Ram area: 900 x 500 mm Table opening: 400 x 120 mm Stroke adjustment: 6 to 82 mm Ram adjustment: 100 mm Installation height, max. stroke, ram Top Dead Center (TDC): max. 469 mm Installation height, max. stroke, ram Bottom Dead Center (BDC): max. 387 mm Strokes per minute: 50-200 s.p.m. Main drive motor power: 18.5 kW Power supply: 400 Volt, 50 Hz - Hydraulically actuated multiple-disc wet clutch and spring-loaded safety brake - Infinitely variable drive via PIV gearbox with inching mode for automatic stroke adjustment and setup operations - Hydraulic overload protection in the ram - Press force and process monitoring via UNIDOR APS - Pneumatic, steplessly adjustable ram weight compensation - Roller feeder MABU WE16, 160 x 3 mm, programmable feed length - Central grease lubrication - Operating manual and documentation for the press Included: Godpfx Asx U Eiasa Iott Roller feed unit MABU Type WE16 Strip width: 160 mm Strip thickness: max. 3 mm Strip cross-section: max. 300 mm² Roller diameter: 63 mm Strip speed: 40 m/min - Adjacent feeder control MABU Space requirements for eccentric press L x W x H: 270 x 240 x 350 cm Weight of the press: 13.5 tons

Condition: used, Mechanical scissor lift table with roller device - welding positioner, vessel rotator Ideal base for 3D welding table Load capacity 800 kg (maximum load with fixed castors) Load capacity 2000 kg (maximum load without fixed castors) Platform size 1800 x 860 mm Usable lift max. 690 mm Table height - bottom position 770 mm (without top frame) Table height - top position 1460 mm (without top frame) Table height - bottom with locking bolt 830 mm (without top frame) Table height - top with locking bolt 1080 mm (without top frame) Top frame height 80 mm Load capacity of rotator approx. 400 kg Roller spacing / axle spacing 155 to 685 mm Gtjdpfxox U Eh Ns Aa Ist Axle distance to top frame 190 mm Roller diameter 100 mm Roller width 40 mm - Scissor lift table is ideal as workbench, assembly fixture, welding table base, or with vessel rotator for pipe welding - Mobile on 4 polyamide rigid castors Ø 125 mm, 2 of which are swiveling with brakes - Height adjustment via trapezoidal screw spindle and hand crank - 4 locking bolts for height adjustment, hole spacing 50 mm - Removable table top with forklift pockets - Roller spacing of polyurethane rollers on rotator adjustable in perforated pattern - Very robust construction made of square profiles with 5 mm to 10 mm wall thickness Required space (L x W x H): 1800 x 860 x 1200 mm Weight without rotator 470 kg Weight with rotator 620 kg Very good condition

Condition: new, Spiral mixer S 50 Ital Form Mixer dimensions: 1200x410x1370mm Bowl dimensions: 670x400mm Dough capacity: 80kg Gtedpfx Ajx U Eh Aja Iet Flour capacity: 50kg Mixer power: 7.5kW Bowl power: 1.0kW Voltage: 380V / 50Hz Mixer speed: 123-245rpm Bowl speed: 20rpm Net weight: 376kg

Condition: new, Spiral mixer S 38 Ital Form Mixer dimensions: 1000x610x1300mm Dough capacity: 60kg Flour capacity: 38kg Mixer power: 3.75kW Bowl power: 0.4kW Godjx U Eg Eepfx Aa Iott Voltage: 200 / 440V / 50Hz / 3N/PE Net weight: 295kg

Condition: used, Year of construction: 2010, Suction nozzle diameter: 200 mm Rated airflow: 2262 m³/h Max. airflow: 3500 m³/h Filter area: 12.65 m² Cleaning system: vibration motor Chip disposal: 2 collection containers Collection volume: 330 liters Filter material: polyester needle felt Negative pressure at nominal flow: 2750 Pa Installation: mobile Approx. weight: 450 kg Motor power: 4 kW Power connection approx.: 400 Volt/50Hz Gtsdpfx Aaox U Egxj Ijt Storage location: with customer

Condition: used, Year of construction: 2025, Filter system, immediately available! NEW in original packaging! 1.1. STfp-rFan DER4 450/550/18.5-2 | incl. backdraft damperExtraction fan, "DER4" series for clean air-side installation, single-sided suction, direct drive. Main design features: Spiral housing made of galvanized steel, pre-configured for horizontal installation in MultiStar series filters IEC standard motor High-performance impeller with backward-curved blades, designed for clean-air extraction operation Suction nozzle with spark protection Impeller made of welded steel, statically and dynamically balanced For explosion protection reasons, the fan is not suitable for conveying explosive dust/air mixtures! Technical data and performance:Volume flow (max. permitted): 15,000 m3/hTotal pressure increase: 3,000 PaInlet nozzle: 450 mm diameterOutlet nozzle: 450 mm x 355 mmDrive motor: 18.50 kW, 3000 rpm at 50 Hz | 3600 rpm at 60 HzVoltage / Frequency: 400 V, 50 HzMotor efficiency class: IE3, Premium EfficiencyWeight, approx.: 330 kgRotation direction: RD 0 1.1.1. STcold conductor 18.5 kW 1.2. STMultiStar VR 6.6-195.25317AMultiStar modular filter system, with vibration cleaning, for installation outside explosion hazard zones. Design features:Galvanized, self-supporting sheet steel constructionPressure surge resistance 200 mbar (type tested, Dekra-Exam 342863200a-23ExA-Sip)Housing negative pressure resistance max. 5500 Pa (avoid fluctuating stress)EU type-tested rupture discsWeather protection cladding of the filter section with inspection door(s) and required number of exhaust nozzles (depending on air volume) Fire resistance EW 90ef, MPA-tested Clean-air nozzle, as per project drawing BG-tested needle felt filter material, suitable for wood and paper dust and many other types of dust Filter bags, externally pressurized, with reusable internal support elements Filter cleaning occurs during operation breaks Expansion chamber for pre-separation The permissible fill level of the expansion chamber strongly depends on the material properties (bulk density, grain size, tendency to form bridges, etc.) and is approximately 400...700mm. Inspection door with viewing window and limit switch Connection shaft for rotary valve, or similar. Technical data and dimensions:Filter area: 195 m²Filter bags: 144 pcsFilter bag length: 2530 mmBag diameter: 170 mmShake-off: 0.18 kW, 400 V, 50 Hz - 1 unitAgitator drive: 1.50 kW, 400 V, 50 HzFootprint, L x W: 2880 mm x 2880 mmSpace requirement, L x W: Space requirement as per system drawingHeight: 9110 mm Additionally included in delivery: Dry fire-extinguishing line, consisting of: o C-hose connection with blind coupling * o Riser pipe from filter base o Distributor pipe system with sprinkler nozzles o Notice sign Note: According to DIN EN 12779:2016 sec. 5.4.2.3, the water connection must be arranged 0.4 m to 0.8 m above the floor and, in the event of a fire, be safe and easily accessible for connecting a fire-fighting hose. The BGHM additionally recommends installing a dirt trap in the riser. The components, installation materials, and labor required for this are not included in the basic price of the dry extinguishing line. These can optionally be provided by the customer or as a custom-built stand = 3000 mm special height. The base frame is not included in the scope of delivery and will be designed and specified separately.1.2.3. Additional S Gjdpsx U Egrofx Aa Iott
