Condition: used, core drilling diameter max. 50-600 mm bore depth 6000 mm table load 6 t turning speeds 50-600 U/min clamping diameter max. 650 mm Boring (pushing) from ID = 50 to 320 Skyving and roller Burnishing from ID = 50 to 300 Gsdey R Ef Tjpfx Almobl Honing from ID = 50 to 320 Extraction system The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: good (used), functionality: fully functional, drilling depth: 1,000 mm, FOR SALE: TBT T 30 – 1000 KT Deep Hole Drilling Machine High-quality German engineering for precision drilling Overview: Available for purchase is a robust and reliable deep hole drilling machine from the renowned German manufacturer TBT Tiefbohrtechnik. As a global leader in deep hole drilling technology, TBT machines provide unmatched precision for long-hole operations. Technical Specifications: Model: T 30 – 1000 KT Year of Manufacture: 1977 Max Drilling Depth: 1000 mm Gedpfjy Rvc Aex Almsbl Drilling Diameter: approx. 4 – 30 mm Rated Power: approx. 20 kW Operating Voltage: 380 V / 50 Hz Machine Type: Knee-table (KT) design for flexible clamping. Key Benefits: Solid Construction: German heavy-duty build ensures superior stability and accuracy. High Performance: The 20 kW motor provides ample power for various metal alloys. Versatile Application: Ideal for drilling shafts, molds, and other long workpieces.

Condition: ready for operation (used), Year of construction: 1976, functionality: fully functional, drilling depth: 1,500 mm, feed length X-axis: 2,030 mm, feed length Y-axis: 1,800 mm, feed length Z-axis: 1,700 mm, table length: 2,200 mm, table width: 1,800 mm, table load: 12,000 kg, Deep hole drilling machine Ixion (drilling depth 1,500 mm, X 2,030 mm, Y 1,800 mm, Z 1,700 mm) Year of manufacture: 1976 Retrofit and conversion to TLB: 1996 2024 Overhaul (spindle bearings replaced, drill bush carrier/coolant supply disassembled and cleaned, hydraulic system for tool clamping repaired, coolant system and hydraulic unit cleaned and checked, etc.) Travel paths: - X-axis (longitudinal): 2,030 mm - Y-axis (drilling unit vertical): 1,800 mm - Z-axis: 1,700 mm - Drilling depth in a single stroke: 1,500 mm - B-axis (rotary table): 0–360° Drilling unit: - Main spindle: ISO40 - Spindle speed: 60–6,000 rpm - Drive power at 100% duty cycle: 7.5 kW NC Rotary Table (B axis): - Table area: 2,200 x 1,800 mm - Rotary axis: 0–360° - Max. table load: 12,000 kg Godpfx Alsy Rhzwemobl - Positioning accuracy: +/- 15 arc seconds Coolant system/chip conveyor: - Tank capacity: approx. 1,000 l - Coolant pressure: max. 80 bar - Flow rate: max. 46 l/min - Paper belt filter - Scraper conveyor/chip conveyor CNC Control: - Mitsubishi M325 with 14" color display - Integrated tool breakage monitoring via main spindle torque detection - Real-time process value visualization of spindle torque - Deep hole drilling technology programs - Portable electronic handwheel

Condition: excellent (used), Year of construction: 1985, Drilling depth 750 mm Solid drilling in steel approx. 30 mm Maximum spindle speed 5,700 rpm Clamping table 1280 x 420 mm Gedpfx Aey N Ecpelmebl Cross-slide table Coolant tank Various accessories (drills, bushings)

Condition: excellent (used), Year of construction: 2013, 4mm Dia. - 16mm Dia Range of Drilling; Up to 3,000mm Length of Component; Double Axis; Overall Length Approx 11 Metres x 900mm Wide, (2) Sections - Headstock Bed Length Approx 5 Metres, Drilling Length Bed Approx 6 Metres; (1) 500mm Dia 4-Jaw Chuck, 120mm Bore with Troyke DL-20-B, 4th Axis, 500mm Dia. Precision Rotary Table; Pendant Control; Stand Alone Electrical Cabinet (Dimensions Approx 3,000mm x 500mm x 1,900mm High); Technidrill Coolant Filtration System consisting of LNS 'Turbo HB' Swarf Conveyor, FSI 'CBFP 11' Filter System & Oil Tank with High Pressure Delivery Pumps; Stand Alone Dimplex Koolant Koolers Chiller Unit with Controls (Dimensions Approx 700mm x 1,300mm x 1,850mm High, 2012); Gjdpfx Ajy Ey E Rslmobl

Condition: excellent (used), Year of construction: 1996, completely overhauled in 2005 Number of spindles: 2 Drilling capacity per spindle, steel: 1-6 mm Drilling depth: max. 350 mm Z travel: 350 mm W travel: 350 mm Drive power per spindle - 100% duty cycle: 3.7 kW - 50% duty cycle: 5.5 kW Spindle speed: 3,000 - 27,000 rpm Spindle mounting: Ø 10 - 60 mm Coolant pressure: max. 150 bar Coolant flow: 48 l/min Coolant volume: 1,000 l Gbedpfx Aoy Eykgjlmsl Compact band filter High-pressure pump

Condition: repair required (used), Year of construction: 1990, functionality: not functional, machine/vehicle number: 418.364.077, drilling depth: 800 mm, feed length Z-axis: 1,000 mm, total length: 4,200 mm, total width: 2,100 mm, total height: 2,800 mm, workpiece weight (max.): 500 kg, overall weight: 7,000 kg, travel distance X-axis: 800 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 1,050 mm, spindle speed (max.): 7,000 rpm, drill diameter: 25 mm, type of input current: three-phase, number of spindles: 1, feed length W-axis: 120 mm, TBT - Deep hole drilling machine, single spindle, with CNC cross table, "x/y" axes and "W" positioning slide! Control: EST - Error in CPU rack. Machine is not operational. All actuators/hardware were functional until decommissioning. The rack error occurred during the downtime after decommissioning. Power electronics/inverter: Bosch Clamping table and various accessories Dismantling preferably by the buyer; machine components (control cabinet, body, oil tank) can be placed onto machinery skates using the existing hall crane, but loading inside the hall is not possible! Dismantling and loading upon agreement. Gsdpfx Aoyz Rd Nolmobl Transport exclusively by the buyer.

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, drilling depth: 1,500 mm, feed length X-axis: 3,250 mm, feed length Y-axis: 1,500 mm, spindle speed (max.): 4,200 rpm, table load: 35,000 kg, CNC SELCA 4040 DH Maximum drilling depth in single cycle, V axis: 1,500 mm Column, longitudinal travel X axis: 3,250 mm Vertical travel Y axis: 1,500 mm Drilling slide, workpiece support movement W axis: 500 mm Maximum workpiece height: 2,400 mm Clamping table and workpiece approach movement U axis: 1,000 mm Controlled radial resolution, B axis: 360,000 divisions/rev Clamping table, rotating surface size: 1,600 x 1,800 mm Clamping table, max load with rotating workpiece: 20,000 kg Standard T-slot size: 22 mm Minimum–maximum solid drilling diameter: 5 – 50 mm Rapid feed rate, adjustable max speed: 8,000 mm/min Drilling spindle rotation speed, adjustable: 1 – 4,200 rpm Drilling spindle motor power: 15 kW Gun drill tool holders: Shank for drill Ø < 6 mm: Ø 10 x 40 mm Shank for drill 6 mm < Ø < 25 mm: Ø 25 x 70 mm Shank for drill Ø > 25 mm: Ø 40 x 70 mm Dimensions and weights Width x Length x Height MF 1500 BB: 5,900 x 7,600 x 3,850 mm Total weight: 42,000 kg Oil tank capacity: 600 – 1,200 liters WORK SLIDE TILTING Minimum / maximum vertical inclination – A axis: +20° / -20° Continuous controlled radial resolution: 0.001° MILLING HEAD – ISO 50 spindle connection Max horizontal working stroke – Z + W axes: 1,000 mm Column longitudinal travel – X axis: 3,250 mm Drilling slide vertical travel – Y axis: 1,500 mm Spindle rotation speed, adjustable max: 2,500 rpm Spindle power (S1 duty): 17 kW Maximum spindle torque: 680 Nm ROTO-TRANSLATING CLAMPING TABLE Max clamping surface: 2,000 x 2,000 mm Gbsdpfx Asyymdislmol Max horizontal travel – U axis: 1,000 mm Continuous controlled radial resolution: 0.001° Max rotating workpiece load: 35,000 kg Standard T-slot size: 22 mm Machine complete with: • Remote electronic handwheel • ISO 50 tool changer magazine with 10 positions • Many tools and working equipment • Rack with various drills • User manual, maintenance manual, and CE conformity declaration

Condition: excellent (used), Year of construction: 1986, machine/vehicle number: 00127634, functionality: fully functional, High-speed bench drill, Made in Germany - Clamping table: 290 x 225 mm - Travel: 150 mm with hand crank - Spindle fitting: Drill chuck included - Drilling capacity in steel Ø 1 - 6 mm - Throat depth: 180 mm - Speeds: 900 - 10,000 rpm, 8 steps - Column: diameter 75 mm - Spindle stroke: 60 mm, with fine stop - Voltage: 380 V - Dimensions: 640/330/H740 mm - Weight: 92 kg Gbedpfxsyx Dzpe Almel

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, drilling depth: 1,600 mm, feed length X-axis: 3,000 mm, feed length Y-axis: 2,100 mm, feed length Z-axis: 1,500 mm, overall weight: 50,000 kg, feed rate X-axis: 10,000 m/min, feed rate Y-axis: 10,000 m/min, feed rate Z-axis: 10,000 m/min, spindle speed (max.): 4,500 rpm, drill diameter: 40 mm, table length: 2,100 mm, table width: 1,900 mm, CNC Heidenhain iTNC 640 AXES OF MOVEMENT Gbjdpfoywnr Nsx Almsl Maximum drilling depth in a single operation (V axis): mm 1,600 Table travel, horizontal movement (X axis): mm 3,000 Vertical movement (Y axis): mm 2,100 Column approach movement (milling) (Z axis): mm 1,500 Drilling slide tilting (resolution 0.001°) (A axis): +30° / -15° Table rotation (resolution 0.001°) (B axis): 360° Max axis feed rate: mm/min 10,000 DEEP HOLE DRILLING AND MILLING SPINDLE – ISO 50 Solid drilling capacity: mm 5 – 25 Maximum drilling diameter: mm 40 Adjustable spindle speed: rpm 1 – 4,500 Spindle power S1: kW 17 Spindle torque: Nm 324 Standard drilling tool holder: mm Ø 25 x 70 Maximum internal spindle pressure: bar 120 Taper type: ISO 50 DIN 69871/A Coolant system: Yes ROTARY TABLE Rotary table dimensions: mm 1,900 x 2,100 Table rotation (resolution 0.001°) (B axis): 360° Table load capacity in rotation: kg 20,000 T-slots: mm 22 OIL SYSTEM Hydraulic pump motor power: kW 4 – 7.5 Self-regulated oil pressure: bar 15 – 120 Self-regulated oil flow rate: l/min 5 – 80 Oil tank capacity: L 800 – 1,000 Cooled oil temperature: 25 – 32 °C Filtration grade: micron 16 MACHINE DIMENSIONS AND WEIGHT Width x Length x Height: mm 7,000 x 7,900 x4,700h Machine weight: kg 50,000 DRILLING CAPABILITIES WITH GUN DRILLS Maximum depth: mm 1,600 Maximum rotation speed: rpm 4,500 Minimum drilling diameter: mm 6 Maximum drilling diameter: mm 40 THREADING HEAD “IMSASISTEM” WORKING FEATURES Max rotation speed: rpm 4,500 Maximum threading on C40 steel: M36 Machine equipped with: • Remote electronic handwheel Heidenhain • ISO 50 tool changer magazine with 40 positions • Fume extraction system 4,000 m³/hour • Through-spindle air/oil system • M24 threads on table side • Various tools and equipment • Tool rack with assorted gun drills • User and maintenance manual and CE declaration of conformity

Condition: good (used), Year of construction: 2001, Technical details are shown on picture. Gbodpsyuykdjfx Almsl Deep hole boring machine with many additional equipement.

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, drilling depth: 2,250 mm, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 700 mm, spindle speed (max.): 4,500 rpm, drill diameter: 40 mm, table length: 1,600 mm, table width: 1,300 mm, table load: 20,000 kg, Deep Hole Drilling, Milling and Tapping Machine 5 linear axes X, Y, Y1, Z, W Rotary table axis B Equipped with 3D CAD simulation, WISE PLUS system, electrical cabinet cooling, and fume extraction system. Capacity Gun drilling capacity: 40 mm Table X-axis stroke: 2000 mm Ram Y-axis stroke: 1500 mm Column Z-axis stroke: 700 mm Spindle taper: ISO 50 – DIN 69871 Motor power: 22 / 33 kW Table size: 1600 × 1300 mm Technical Specifications Drilling diameter range: Ø 5 – Ø 40 mm Maximum drilling depth: 2250 mm Milling capacity with cutting tools up to: Ø 60 mm Drilling axis inclination: W -15° / +25° Milling capacity: 400 cm³/min Filtration and cooling system tank capacity: 2000 L Maximum pressure: 80 bar Direct gun drilling with guide bushings: up to Ø 20 mm Rotary table load capacity: 20,000 kg Positioning: 360,000 positions 9 T-slots 18 H12 P=140 Gbsdpfx Aleyuc Rtsmsl Positioning accuracy: ± 0.2 sec Linear Axes X: 2000 mm Y: 1500 mm Z: 700 mm W: 1630 mm

Condition: used, Year of construction: 1971, core drilling diameter max. 50-355 mm bore depth 4000 mm swing diameter 1000 mm Gbsdpfeyt Rz Dsx Almjl centre height 500 mm full boring 18-100 mm main spindle bore 163 mm turning speeds 56-710 U/min workpiece weight 6,3/10 t Tailstock 70-600 mm Drill pipes, guide block, drill head, rolling steady rest, support bearing drill heads, jaws 21- 240 mm, Holder, tools, shelves, cupboards The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: excellent (used), IMSA DEEP HOLE DRILLING MACHINE MODEL MF 1000 BB TRAVELS: LONGITUDINAL AXIS: 1250 mm CROSS AXIS (MILLING QUILL): 380 mm Gbsdpsytff Dofx Almsl CROSS TRAVEL OF HEAD: 500 mm VERTICAL TRAVEL: 1000 mm ROTARY TABLE SIZE: 1000x800 mm TOTAL MACHINE WEIGHT: 20,000 kg

Condition: used, Year of construction: 2006, full boring 150 mm Gbjdoyqvcnepfx Almjl bore depth 13000 mm full boring 150 mm workpiece weight 80 t control Siemens type S 7 workpiece dia. 1250 mm 0 2000 mm borehole diameter 450 mm weight of the machine ca. 160 t Headstock adjustment 10,000mm Headstock bed bed width 1600mm, guideway width 360 Center height of headstock 1600 mm Face plate 1750 mm Drive 60 KW Speed ??2.62-200 rpm Bed for drilling unit Bed length 27,000 mm Bed width 1320 mm Guideway width 290 mm height of the bed 670 mm Drill motor 60 KW Drilling unit Sph 920 mm The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, faceplate diameter 3100 mm swing diameter 3600 mm turning height 3600 mm control Fagor 8035 table load 35 t turning speeds 0,32 - 40 U/min max. ram stroke 3000 mm table load 35 t turning speeds 0,32-40 U/min total power requirement 70 kW 2x Ram head 250 x 250 mm Chip conveyor Mist extraction unit Coolant system Gsdpfx Aeyqt Hdolmjbl The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: excellent (used), Year of construction: 2008, operating hours: 39,000 h, functionality: fully functional, drilling depth: 1,800 mm, drill diameter: 30 mm, Manufacturer: SFT Model: TBM 3-1500 Machine type: Deep hole drilling machine with BTA system Gsdpfx Aoynui Ielmobl Drilling diameter: 15 – 30 mm Drilling depth: 1800 mm Chip conveyor: included Control: SFT / PS 100 incl. control cabinet Frequency inverter: included Oil sump: included Coolant tank: 2,500 liters oil Coolant pumps: 3 units, each adjustable to 40 liters, 100 bar Signal beacon: included Tailstock: rotating and adjustable according to drilling length Clamping: hydraulic clamping operation Drill spindle: speed regulation available Paintwork: light grey / blue Loading station: automatic door Machine footprint: 7,000 x 1,200 mm Filter footprint: 3,000 x 800 x 1,250 mm Commissioned: late 2007 Recurring maintenance according to manufacturer’s specifications Available: end of March 2026 Operation: 2/3-shift operation

Condition: used, Year of construction: 2005, Lot consists of: (1) 5-Axis Oil Hole Boring Machining Center Technical Details: Gbodpfx Aoym Snxolmsl X/Y/Z 500/150/765 mm, B-axis rotary table with A-axis unit for part size 630 x dia 190 mm, spindle 8,000 rpm / HSK-63-A, 12-position automatic tool changer (ATC), CNC GE-FANUC 160i-MB, dimensions (LxWxH) approx. 2x4x3 m

Condition: excellent (used), drilling depth: 10,000 mm, MGA (Romanian) Deep Hole Boring Machine Max Boring Dia: 187mm Max Boring Length: 10,000mm Chuck Diameter: 813mm Chuck Bore: 152mm Machine had a complete retrofit in 2007 to enable CNC or manual mode operation Controls: Bosh Rexroth Electric Drives Software Winstudio At the moment the machine is set to bore 3000mm length Has 5 other bed sections to increase this 12 Various Boring Tubes 30 Various Boring Heads 5 Supporting Steadies Godpoyk Tcfofx Almobl 2 Pressure Heads

Condition: refurbished (used), Year of construction: 1992, functionality: fully functional, WE OFFER AN NICE CONDITION DEEP HOLE DRILLING IXION WITH BRAND NEW CONTROLS Godpfxeyk Ixbo Almebl

Condition: excellent (used), Year of construction: 2009, drilling depth: 350 mm, workpiece weight (max.): 1,600 kg, table load: 1,600 kg, Deep hole drilling machine Mollart - LD8 - 150 Pellet Die Godpsyilgdsfx Almsbl Number of Spindles 8 Gun Drilling Diameter Range 1.5mm-10mm (Per Spindle) Maximum Drilling Depth 150mm Drill Spindle Stroke 350mm Pellet Die Diameter 500mm-1550mm B-Axis Accuracy +/- 6 Arc Seconds Y-Axis Vertical Travel 400mm Gun Drill Speed Range 0-14,000 RPM Max. drill Ø steel 1.5 - 10 mm Drilling depth 350 mm Table load 1600 Speeds / ranges 14000 Rpm Dimensions (Estimate) Length 4500 mm Width 4500 mm Height 2300 mm Weight 12000 kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: ready for operation (used), Year of construction: 1983, operating hours: 6,348 h, functionality: fully functional, drilling depth: 1,500 mm, travel distance X-axis: 1,250 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 900 mm, drill diameter: 50 mm, The machine was overhauled in 2009! TECHNICAL DETAILS Drilling depth: 1,500 mm Drill diameter: 5 - 50 mm Travel X-axis: 1,250 mm Travel Y-axis: 900 mm Travel Z-axis: 900 mm Table length: 1,000 mm Table width: 1,000 mm Max. table load: 3,000 kg Spindle speed: 100 - 6,000 rpm Spindle taper: SK 40 MACHINE DETAILS Control: Siemens 802 D Dimensions & Weight Dimensions (L x W x H): 5,000 x 2,600 x 2,000 mm Weight: 6,000 kg Operating hours: 6,348 h Gbsdpfx Alsyfhcismol

Condition: good (used), Year of construction: 2004, IXION AUERBACH IA2 TLF-1200.4 Year of manufacture: 2004 Factory overhauled: 2023 CNC control: HEIDENHAIN 430M Travel X (table, longitudinal): 1,200 mm Travel Y (deep hole drilling-milling unit, vertical): 1,200 mm Travel Z (turret, horizontal): 700 mm Travel W (deep hole drilling-milling unit, horizontal): 1,200 mm A-axis (swivel of deep hole drilling-milling unit): +25°/-15° B-axis (NC rotary table): 360° NC rotary table with 5 T-slots: 1,000 x 1,000 mm Max. workpiece weight: 7,000 kg Rated drive power (S1 / S6): 12 / 18.5 kW Torque: 115 Nm Speed range: 60 - 6,000 rpm Max. drilling depth (in one pass): 1,200 mm (with 2 traveling steady rests) High-pressure coolant system for deep hole drilling oil: 100 bar & 42 l/min Tool changer for 24 tools With spindle air blast Max. tool length: 300 mm Max. tool weight: 3.5 kg Tool diameter Without adjacent free space: max. 90.0 mm With adjacent free space: max. 160.0 mm Equipment inside work area: Godpfx Aeydmuuelmsbl - Fully enclosed working area with roof - Oil mist extraction - Chip conveyor Required floor space: 5,150 x 5,350 x 4,020 mm

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, drilling depth: 660 mm, travel distance X-axis: 700 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 1,000 mm, drill diameter: 30 mm, TECHNICAL DETAILS Drilling depth: 660 mm Drill diameter: 30 mm X-axis travel: 700 mm Y-axis travel: 500 mm Z-axis travel: 1,000 mm W-axis travel: 250 mm Spindle speed: 60 - 60,000 rpm Table length: 900 mm Table width: 500 mm Table load capacity: 2,000 kg MACHINE DETAILS Control system: Heidenhain iTNC530 Dimensions & Weight Dimensions (L x W x H): 3,706 x 3,960 x 2,650 mm Total weight: 8,000 kg EQUIPMENT CNC rotary table (4th axis) Gbodpeya U U Ujfx Almsl Chip conveyor Paper band filter Electronic handwheel Original documentation

Condition: excellent (used), Deep hole drilling machine tools DEGEN - UTB MACH-ID 9188 Make: DEGEN Type: UTB Year: 2005 Gjdpfx Alsx Tp Ahsmebl
