Condition: ready for operation (used), Year of construction: 2008, operating hours: 12,125 h, Control Unit Brand SIEMENS Model SINUMERIK 840D Controller Brand SINUMERIK 840D Main Drive Spindle speed range 0-5000 rpm Ksdpfx Aaexyl Tgeqond Spindle motor power 29 kW Number of axis 6 Additional Equipment Tool turret: 12-position tool VDI 30 radial with directional logic for up to 12 driven tool stations B-PowerMill: Motorised milling spindle with 24-position tool magazine, 210° swivelling range Optional tool package: Includes stationary and driven tool holders, collet chuck holders, reducing sleeves, and operating spanners Hollow clamping cylinder with draw tube / Part ejector and flushing through the counter spindle / Part pick-up device for finished parts Part pick-up device for finished parts / Coolant device in the chip conveyor / High-pressure pump (14 bar) and fine filter Flushing pumps (3.7 bar) / Control cabinet air conditioning unit / Electrostatic oil mist separator Hydraulic unit / Machine light / Interface for foot switch / Signal lamp Documentation including handwheel, PC keyboard, network preparation, tool monitoring, turning window, cleaning gun Clamping device for main spindle: Hainbuch BZI 80 centre pull / This 6-axis EMCO Hyperturn 665MC Plus turn-mill centre was manufactured in 2008. It features a multi-axis CNC system with Y-axis and B-axis for complete machining of turned and milled parts. Equipped with integrated spindle motors on both main and counter spindles, it offers a spindle speed up to 5000 min-1 for the main and 7000 min-1 for the counter spindle. Includes a 24-position tool magazine and SINUMERIK 840D control. If you are looking to get high quality turning and milling capabilities consider the EMCO Hyperturn 665MC Plus machine we have for sale. Contact us for more information about this machine. Application Types Turning

Condition: good (used), Year of construction: 2004, weight max. 1,5 t weight of the machine ca. 400 kg Knedpfx Ajxylq Soaqsd Accessories for a 4th axis machining center used on a HEDELIUS machine

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, Chip conveyor, Bar feeder interface, Tooling, EIA ISO, Rigid tapping Knedsxykpaepfx Aaqsd

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: NL201FC1175, spindle speed (max.): 6,000 rpm, travel distance X-axis: 260 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 590 mm, controller model: MSX-850 III CONTROL, The machine has only been used for plastics! TECHNICAL DETAILS Travel X-axis: 260 mm Travel Y-axis: 100 mm (+/- 50 mm) Knodpfoxyidpex Aaqjd Travel Z-axis: 590 mm C-axis movement: 0.001 Max. main spindle speed: 6,000 rpm Maximum turning diameter: 356 mm Number of driven tools: 3 Tool turret: 16-position Bar capacity: 65 mm Axes: 4 MACHINE DETAILS Control: MSX-850 III CONTROL Dimensions & Weight Dimensions (L x W x H): 2,705 mm x 2,000 mm x 2,120 mm Weight: 5,800 kg EQUIPMENT Parts catcher chuck Driven tools Tailstock Parts catcher Tool setting probe Dust extraction system

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, Options: Steady rest SMW K4 steady rest Chip conveyor High-pressure pump 15 bar Tool Eye Tailstock Kodpfjxyf Udox Aaqsnd EIA/ISO Overload detector Synchronized tapping Tooling

Condition: ready for operation (used), Year of construction: 2015, Control Unit Brand MAZATROL Model Matrix 2 Movement Z-Axis Movement 1585 mm Y-Axis Movement 260 mm This 5-axis Mazak Integrex i-400 ST was manufactured in 2015. A robust turn-mill centre, it features a main spindle power of 30 kW and sub spindle power of 26 kW, with bar capacities of 102 mm and 80 mm respectively. It includes a high-pressure system at 70 bar, Matrix 2 CNC control, and additional equipment like an automatic door and robot interface. If you are looking to get high-quality turning and milling capabilities, consider the Mazak Integrex i-400 ST machine we have for sale. Contact us for more information. Kjdpfoxyay Isx Aaqond Application Types Turning

Condition: new, Japa® 505 PRO – Top Performance and Versatility for the Highest Demands The Japa® 505 PRO with PTO and electric drive is the ideal choice for demanding professionals who require maximum performance and consistently first-class firewood. This PRO model combines all the advantages of the basic Japa® 505 model – such as the precise Perfect Cut saw system – with enhanced features that take functionality and operating comfort to an entirely new level. ⚙️ Technical data: Log diameter: 500 mm Splitting force: 16 t Splitting wedge: 6-way Log length: up to 50 cm Oil capacity: 100 l Kedjxx T Aajpfx Aaqend PTO speed: 500 rpm Motor output S1: 15 kW / 400 V Gear oil: 80W 90 Conveyor length: 4,400 mm Weight: 2,330 kg Original photos & honest descriptions. Shipping by arrangement. Fair prices. ❓If you have any questions, just contact us – we respond quickly & courteously!

Condition: good (used), Year of construction: 2019, operating hours: 8,173 h, functionality: fully functional, turning length: 12,025 mm, turning diameter: 480 mm, spindle speed (max.): 3,250 rpm, travel distance X-axis: 308 mm, travel distance Y-axis: 120 mm, travel distance Z-axis: 1,240 mm, bar passage: 102 mm, overall weight: 7,200 kg, controller model: DMG MORI SLIMline Multi-Touch Control, control type: CNC control, CLX 550 V6 2-axis universal lathe with driven tools incl. C-axis, Y-axis, and counter spindle Standard equipment: 1. Ergonomic DMG MORI SLIMline operating panel 2. Main spindle A2-8 with AC motor, drive power 22 / 33 kW (100/40% DC), 3,250 rpm 3. Counter spindle A2-6 with ISM 52 synchro, drive power 13 / 14 kW, torque 171.5/192 Nm (100/40% DC), 5,000 rpm 4. 12-position servo turret, VDI 40 mounting with Trifix® precision interface and 12 driven tool stations per DIN 5480 5. Y-axis ± 60 mm 6. Chip tray 7. Hollow clamping device, max. bar capacity D 80 mm 8. Electronic handwheel Drive power (100%/40% DC) 22/33 kW Hydraulic clamping device with bar capacity diameter 102 mm, surcharge Differential pressure clamping for main spindle Bar package & interface option includes: - Workpiece unloader for parts up to D 80 x 200 mm long (D 100 x 200 mm with option C-B7000G) Max. workpiece weight 4 kg - Interface for bar loader or bar feed unit (DMG MORI standard interface) - Hinged belt chip conveyor instead of chip tray - 4-color signal tower Recommended additional option: Double cartridge filter for coolant, especially for production environments with very high chip volumes. Automatic workpiece ejector for counter spindle with internal coolant supply for clamping device flushing. Note: Option recommended for machines with workpiece unloader option. External flushing for counter spindle, option recommended for machines with automation Differential pressure clamping for counter spindle Knodpfjxx Tcmsx Aaqjd Tailstock function for counter spindle, mechatronic force control programmable in the software (force 250-600 daN), including foot switch (only for CLX 550 V6) Direct measuring system for X- and Y-axis (option only available for V4 and V6 versions) Manual tool measuring device in the working area, brand Marposs Documentation according to 'Technical Documentation Delivery List' – included in the machine price. Software option: DXF import for converting DXF files into NC programs (SIEMENS control) Tool monitoring system: Easy Tool Monitor 1.0, monitors each cutting operation against a set limit. Simple learning function for determining the monitoring limit per tool and cutting operation; manual adjustment/correction possible. Technology cycle: Alternating speed (turning) for vibration-sensitive applications Note: We offer flexible financing solutions for all machines as well as a professional relocation service. Dismantling, transport, and professional installation – everything from a single source. Billing based on individual terms and duration. Contact us for your personal offer.

Condition: good (used), Year of construction: 2007, functionality: fully functional, Technical details turning diameter 600 mm turning length 2000 mm control Siemens 840 D powerline Kodpfx Aasxx R D Isqend main spindle speeds: 2500 1/min. total power requirement 72 kVA weight of the machine ca. 12 t Additional information 2-axis CNC universal lathe Equipment: Siemens Sinumerik 840 D powerline CNC control Tailstock 12-station turret SMW AUTOBLOK steady rest Power chuck SMW Autoblok KNCS-N-400-128 Chip conveyor IFS oil mist extraction system

Condition: excellent (used), Year of construction: 2023, turning length: 1,500 mm, Mazak Quick Turn 350 MY - Turning & Milling Center, year of manufacture 2023, Mazatrol Smooth G control, travel X/Z 270/1625 mm, Y-axis travel 150 mm, C-axis 0.0001°, through-spindle coolant 15 bar, maximum bar diameter main spindle 102 mm, spindle speed 3,300 rpm, 12-station turret, driven tools, programmable tailstock, chip conveyor, prepared for bar feeder, steady rest, high-pressure cooling, Tooleye, parts catcher, automatic on/off with warm-up function. Knjdpfx Aexx Nyneaqed

Condition: excellent (used), Year of construction: 2010, turning length: 230 mm, turning diameter: 230 mm, spindle speed (max.): 5,000 rpm, spindle bore: 68 mm, spindle nose: A2-6, DOOSAN PUMA TT1800 SY Kodpsxx Nc Nofx Aaqsnd

Condition: ready for operation (used), Year of construction: 2005, Main Drive Number of axis 3 Spindle Speed 3000 RPM Spindle motor power 18.5 kW Movement X-Axis Movement 230 mm Z-Axis Movement 1130 mm This DMC DL 30 M turn-mill centre was manufactured in 2005. It features a max turning diameter of 400 mm, a max swing diameter of 610 mm, and a max turning length of 1080 mm. The spindle supports speeds up to 3000 RPM with a power of 15/18.5 kW. It includes a 12-position motorized tool turret. Consider the opportunity to buy this DMC DL 30 M turn-mill centre. Contact us for more information. Knjdpfx Aajxx Dwzeqed Application Types Turning

Condition: good (used), Year of construction: 2019, Machine type: CNC turning center Model: CTX beta 1250 TC Manufacturer: DMG MORI Control: DMG MORI CELOS with Siemens 840D sl Operate Year of manufacture: 2019 Location: Germany Maximum turning diameter spindle 1+2: approx. 630 mm Standard turning diameter spindle 1+2: approx. 630 mm Maximum bar diameter spindle 1: approx. 102 mm / spindle 2: approx. 76 mm X-axis travel: approx. 650 mm Z-axis travel (+ ATC): approx. 1300 mm Y-axis travel: approx. ±150 mm A-axis (spindle 2): approx. 1,160 mm B-axis: approx. 240° (±120°) Knedpjxxz S Nsfx Aaqsd B-axis indexing: approx. 0.0001° Spindle speed 1+2: approx. 4,000/5,000 rpm Milling spindle speed: approx. 12,000 rpm Rapid traverse X/Y/Z: approx. 40/40/30 m/min Rapid traverse A (spindle 2): approx. 30 m/min Rapid traverse B-axis: approx. 100 m/min Spindle power 1+2: approx. 40/32 kW Milling spindle power: approx. 22.5 kW Main spindle as integrated spindle motor, ISM102 – sub spindle as integrated spindle motor, ISM76 – tailstock function for sub spindle – differential pressure clamping (main spindle) – milling spindle 12,000 rpm – HSK63 – hinged belt chip conveyor – coolant system 40 bar – through-spindle coolant supply (sub spindle) – coolant spray gun – mechanical oil mist separator (Subject to errors in technical data and specifications)

Condition: good (used), Year of construction: 2004, Gildemeister Twin 42, year of manufacture 2006, Siemens 840 D control, X/Z travel 300/650 mm, main spindle, counter spindle, 1 x Y axis, 2 x C axes, 2 turrets with 12 stations / all stations driven, driven tools up to 6,000 rpm, Irco SiMag 42 bar feeder, chip conveyor, tailstock on counter spindle slide, Knedpfexxyfnex Aaqjd

Condition: as good as new (ex-display), Coolant pistol for retrofitting! Pump + high-pressure hose (5m) + pistol + filter + magnetic holder Simply place the pre-filter into the existing coolant tank of the machine. Fill the filter at the pump with coolant. Plug the pump’s power cable into a standard socket. The pump is now ready for operation. The pump only runs when the trigger on the pistol is pressed. It switches off when the trigger is released and pressure has built up in the pump (approx. 3 seconds). The coolant pistol jet is adjustable! Longer hoses are available at extra cost. Knsdexxvf Djpfx Aaqed

Condition: good (used), Year of construction: 2006, turning length: 1,000 mm, spindle speed (max.): 5,000 rpm, rotational speed (min.): 12,000 rpm, We offer you: Manufacturer: MORI SEIKI Model: NT 4200/1000S Year of manufacture: 2006 Control: MITSUBISHI M-720BM (MAPPS 2) Technical specifications: Bed length: 1000 mm Spindle speed: 5,000 rpm Spindle bore: 73 mm Number of tool stations: 100 Milling spindle speed: 12,000 rpm Kedpfxsxxraqs Aaqsnd - Counter spindle defective Accessories, depicted tools, and clamping devices are only included in the scope of delivery if specified in the additional information. Subject to changes and errors in technical data and specifications as well as prior sale!

Condition: used, Year of construction: 2018, DMG Mori Sprint 32/8 CNC Swiss Lathe Mfd. 2018 Control: Fanuc 32-B Plus 8-Axis Power: 75 HP RPM 8,500 Diameter: 32mm With 12-ft Patriot 338 Bar Feed Equipped as pictured Machine concept Number of linear axes + C-axes 6 + 2 Number of spindles 2 Number of channels 2 Main spindle Maximum bar capacity mm | in 32 | 1.26 Speed rpm 8,500 Power (S2 30 min/S1) kW | hp 7.5/5.5 | 10.1/7.4 S2 15 min/S1 Torque (S2 30 min/S1) Nm | ft lbs 51.9/40.4 | 38.3/29.8 S2 15 min/S1 Counter spindle Maximum bar capacity mm | in 32 | 1.26 C-axis (0.001°) Speed rpm 8,500 Knodpfjxxm A Tox Aaqsd Power (S2 30 min/S1) kW | hp 3.7/2.2 | 5.0/3.0 Torque (S2 30 min/S1) Nm | ft lbs 23.6/14 | 17.4/10.3 Working area/ travels Z1 travel (spindle travel) mm | in 100 | 3.94 Rapid traverse speed on linear axes X1, Z1, X2, Z2/Y1, Y2 m / min | in/ min 40/30 | 131/98 Acceleration in linear axes m /s² | ft 5 | 0.02 Tool holder on slide 1 Fixed turning tools 6 Tools for front machining/back-working 4/4 Driven tools 2 + 2 Maximum speed rpm 6,000 Power (S3 40 % /S1) kW | hp 1.9/1 | 2.5/1.3 Maximum torque (S3 40 % /S1) Nm | ft lbs 3. The 2018 DMG Mori Sprint 32/8 is a high-performance CNC screw machine built for precision, speed, and versatility in complex small-part production. Featuring an 8-axis configuration with 6 linear axes and 2 C-axes, the machine is powered by the FANUC 32i-B Plus control system with a 10.4” color display. The Sprint 32/8 is designed with dual spindles capable of 8,500 RPM, with the main spindle delivering 7.4 hp and 29.8 ft-lbs of torque, and the counter spindle generating 3 hp and 10.3 ft-lbs. Both spindles handle bar stock up to 32mm (1.26"), making it ideal for precise machining in medical, aerospace, and automotive industries. The machine supports simultaneous machining with up to 2 tools and offers advanced back-working capabilities. The working area includes Z1, X1/Y1, and X2/Z2/Y2 travels, allowing for intricate multi-sided operations. Tooling includes 8 driven tool stations and multiple configurations for both front and back machining, with speeds up to 6,000 RPM and torque of 2.2 ft-lbs. The Tool Monitoring System offers graphical tool load display, aiding in predictive maintenance and minimizing downtime. Additional features include high-pressure coolant and an integrated air handler, contributing to stable thermal conditions and chip evacuation. Its compact footprint of 30.1 ft² and total weight of 7,826 lbs make the Sprint 32/8 a space-efficient and powerful addition to any high-volume CNC shop. This machine is engineered to streamline part production while ensuring repeatable accuracy, robust power, and operational efficiency.

Condition: like new (used), Year of construction: 2011, functionality: fully functional, turning length: 1,090 mm, spindle speed (min.): 4,500 rpm, travel distance X-axis: 455 mm, travel distance Z-axis: 1,090 mm, spindle nose: A 2-6, CNC Turning Milling Centre with 2nd spindle and lower turret Control Fanuc 31i Model A Turning diameter 170 / 245 mm Turning length 1090 mm Spindle bore diameter 71 / 51 mm Spindle nose A 2-6 Spindle nose sub spindle A 2-5 Turning speed 4.500 R/min Turning speed sub spindle 6.000 R/min Milling head speed 12.000 R/min Movement X-axis 455 mm Movement Y-axis +70/-70 mm Movement Z-axis 1090 mm B-Axis travel 230° C-Axis indexing 0,001° Tool Taper Capto C6 Tools in tool magazine 40 Bar feeder: LNS Alpha SL65 Knjdpfx Aoxxlpleaqsd If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: excellent (used), Year of construction: 2007, TECHNICAL DETAILS CNC Control: FANUC 18i-TB X1/X2 Axis mm: 555/185 Z1/Z2 Axis mm: 1,095/1,140 Y Axis mm: 160 (+/- 80) B Axis mm: 240 (+/- 120) Maximum Turning Diameter mm: 550 C Axis Increment: 0.001° Maximum Turning Length mm: 1,020 Cutting Feed Rate mm/min X,Z,Y: 500 Rapid Traverse Speed mm/min: X1, Z1: 24,000 Y: 16,000 B: 27,000 C: 200 (Z2: 24,000) (X2: 24,000) Swing Over Bed mm: Ø 750 Swing Over Cross Slide mm: Ø 600 Bar Capacity mm: Ø 65 (main) / Ø - (sub) Knsdpfx Ajxxdmijaqod Max. Rapid Traverse m/min X,Z,B-Y: - Spindle / Sub-Spindle: - Spindle Speed rpm: 5,000 Spindle Power kW: 22/15 Torque Nm: - Main Spindle Bore: - Main Spindle Nose: A2-6 Milling Head: - Spindle Speed rpm: 10,000 Spindle Power kW: 15/11 Torque Nm: - Taper Type: CAPTO C6 Number of Tools in Magazine: 40 Turret: - Turret Positions: - Number of Driven Tool Stations: - Driven Tool Speed rpm: - Driven Tool Power: - EQUIPMENT Chip Conveyor, Hinged Belt Type: Included Bar Feeder Interface Adjustment Control: Included MACHINE DIMENSIONS Length mm: 6,070 Width mm: 2,682 Height mm: 3,011 Weight kg: 15,500

Condition: excellent (used), Year of construction: 2000, EMCO VMC 600, Siemens Year of manufacture: 2000 Ksdpfjxxakwox Aaqjnd

Condition: excellent (used), functionality: fully functional, Machine type: CNC Turning-Milling Center Manufacturer: Okuma Model: Multus U4000 2SC 1500 Year of Commissioning: 2017 (as ex-stock machine) Control: OSP P300S Spindle Hours: approx. 3,000 Included: Various tools and chuck jaws Condition: Very good Delivery: Short lead time – as agreed Equipment and technical details: ▪ Enlarged main spindle KK size 11 Kjdpfxjxw Thmo Aaqjnd Front bearing Ø 160 mm Speed range: 3,000 rpm Bore diameter: Ø 112 mm Motor power: 32 kW Torque: 955 Nm ▪ Hollow power chuck cylinder Ø 127mm, SMW VNK 320-127 with Ø 127 mm bore ▪ Pressure reducing valve, adjustable range 8-70 bar ▪ Tailstock ▪ Turning length approx. 1,500 mm ▪ H1 turret (1 station) ▪ Y-axis ▪ B-axis 0.001° ▪ 40-station tool magazine ▪ Additional lower turret with 12 stations ▪ Tool spindle 12,000 rpm ▪ Hinge belt chip conveyor: Heavy-duty chip conveyor with low-maintenance self-cleaning function ▪ Drum sump filter TMF300 with clean fluid tank 980 L ▪ Supply pump TC160/740, 8 bar ▪ Supply pump RSP 20/32-070-1-1-0, 70 bar ▪ Self-centering steady rest on the lower turret (not possible in combination with driven tools for lower turret) ▪ Door automation ▪ Robot interface Type E for connecting additional loading/unloading systems to single-spindle machines ▪ 3D machine model for simulation in CAM system Main drive (Okuma motor spindle): 22kW / 700 Nm / 50–4,200 rpm Spindle nose KK size 8 Front spindle bearing Ø 140 mm Spindle bore Ø 91 mm Speed range: 2 steps Range switching at full speed ▪ Lower turret: 12 stations ZB-axis with cylindrical roller guide XB-axis with slideways ▪ Real-time Collision Avoidance System (CAS) ▪ 19" color LCD TFT (1280x1024) with 3D color graphics as touch screen/panel with vertical display and adjustable tilt keyboard ▪ Second operating system Windows 7 for operation and data communication, open and freely usable for Windows 7 compatible applications ▪ Programmable tailstock on W-axis with hydraulic quill ▪ Tool magazine 40 stations ▪ C-axis 360°, 0.001° positioning ▪ Y-axis travel +150 mm / -150 mm = 300 mm ▪ B-axis 240°, 0.001° positioning ▪ Tool spindle (Okuma motor spindle): 22 kW / 120 Nm / 12,000 rpm ▪ Internal coolant supply for rotating tools, pump with max. 20 bar pressure Including bag filter, external cooling of tool spindle, pump with max. 3 bar pressure ▪ Tool system: HSK-A63 ▪ Tool monitoring system for tool life and breakage ▪ Tool measurement device (using standard chuck) for safe setup ▪ Machine management MacMan with integrated BDE (operating data acquisition) ▪ Part program memory 2 GB ▪ Max. length of individual part program: 2 MB ▪ 2 USB 2.0 ports ▪ Ethernet interface with browser and DNC-T1 for program transmission ▪ Harmonic speed oscillation via periodic speed change ▪ Tool height correction on Y-axis for turning tools ▪ Circular thread milling X/Z/Y/B (helical interpolation) Including eccentric milling X/Y/C ▪ Hi-Cut Pro high speed control for rotary tools ▪ 10 workpiece zero points (coordinate system selection) ▪ Coordinate conversion (shift, rotate) ▪ Electronic spindle orientation +/- 0.1° Optional: ▪ Transport organization and implementation ▪ Machine installation and setup ▪ Commissioning of the machine

Condition: excellent (used), Year of construction: 2004, CNC Control: MSG-501 X axis mm: 900 Y axis mm: 800 Z axis mm: 980 B axis mm: 0.001 Pallet size mm: 630 x 630 Number of pallets: 2 Table load capacity kg: 1,200 Cutting feed mm/min X,Y,Z: 50,000 Max. rapid traverse m/min X, Y, Z: 50, 50, 50 Spindle speed rpm: 10,000 Spindle power kW: 30/25 Taper type: BT-50 Torque Nm: - Tool changer type: Chain Tool changer positions: 60 Max. tool diameter mm: 110 Max. tool diameter with adjacent positions empty: 320 Max. tool length mm: 600 Max. tool weight kg: 30 Coolant tank capacity l: 930 Through spindle cooling bar: Yes EQUIPMENT Chip conveyor Internal cooling Rigid tapping Manuals, electrical diagram, etc. Knodpfxexw Rg He Aaqjd MACHINE DIMENSIONS Length mm: 3,670 Width mm: 5,300 Height mm: 3,270 Weight kg: 19,000

Condition: used, Year of construction: 2012, functionality: fully functional, machine/vehicle number: ML0107-000373, Doosan PUMA 2600 L Kjdpfx Aaoxw Ilmsqsnd Swing 780mm X-Axis 260 mm Z-Axis 1350 mm FANUC i Series Swarf conveyour Renishaw Toolsetter

Condition: used, Year of construction: 2015, turning diameter 410 mm turning length 800 mm Knsdpfx Ajxwzadoaqsd control Sinumerik 840D sl Siemens greates pass round over bed 700 mm centre distance 975 mm travel -x axis 300 mm travel -z axis 850 mm turning speed range - spindle 25 - 5.000 U/min chuck 260-81 mm bar material dia. 65 mm spindle bearing diameter 130 mm power capacity 40% ED = 34 kW power capacity 100 % ED = 25 kW max. Torque 380 / 280 Nm C-Axis 0,01 ° turret (x-stations) 16 tool taper VDI 30 DIN 69880-30 driven statition 16 pos Spindle speed driven tools ~ 4.000 min -1 power capacity - driven tools 40% ED = 11,3 kW power capacity - driven tools 100 % ED = 5,6 kW rapid traverse X-axis 30 m/min rapid traverse Z-axis 30 m/min tailstock adjustment 800 mm morse taper MK 5 total power requirement 65 kVA weight of the machine ca. 6,2 t dimensions of the machine ca. 5,5 x 3,0 x 2,5 m CNC Turning- and Milling Center GILDEMEISTER - CTX beta 800 - only 14.061 Spindle hours - WITHOUT tools - WITHOUT dust extraction - Good condition

Condition: used, Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Kodexwxzxopfx Aaqjnd Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler
