Condition: used, Year of construction: 2000, x-travel 560 mm y-travel 560 mm z-travel 625 mm Iedpfx Adoxyaccs Detp control OSP-U100M Fanuc spindle speeds 15000 U/min spindle drive 15/11 kW rapid travel x/y/z 30 mm/min Number of tool station 40 SK40 Pallet dimension 2 x 400x400 mm table load 0,4 t table index 1 ° total power requirement 49 kVA weight of the machine ca. 11 t dimensions of the machine ca. 3,2 x 2 x 2,5 m Control OSP-U100M (Fanuc), 60 tool stations, it has trough spindle coolant, chip conveyor and two paletts.

Condition: used, Year of construction: 1999, x-travel 560 mm Itodpfexyabxex Ad Dsp y-travel 510 mm z-travel 510 mm control Fanuc MSC 501 (Fanuc 16i) spindle speeds 10000 U/min spindle drive 22 kW rapid travel x/y/z 32 mm/min Number of tool station 40 SK40 Pallet dimension 2 x 400x400 mm table load 0,5 t table index 1 ° total power requirement 56 kVA weight of the machine ca. 8,7 t dimensions of the machine ca. 2,9x4,1x3 m Control Fanuc MSD 501, 40 tool stations, it has trough spindle coolant, chip conveyor and two paletts.

Condition: excellent (used), MATSUURA H. PLUS 300 is a Horizontal machining center with high precision, excellent accuracy and reliability. Travels X/Y/Z 500 mm; workpieces Ø 530 mm, h 700 mm; pallets 300×300 mm (10), max workpiece 250 kg, change 7 s. Spindle BT40 50–15,000 rpm, 95.4 Nm, 15/22 kW; feeds 1–50,000 mm/min, rapid 50 m/min; 3×380 V 50 Hz; weight ≈7000 kg; dims 3660×2463×2445 mm. Tool magazine 90 pos., tool change 2 s, chip-to-chip 2.9 s. Coolant 1500 l, chip conveyor, toolholder set, spindle oil cooler. Suited to tight tolerances in automotive, aerospace, medical, watchmaking and mould/die. Iodpfx Aoxyaabod Dotp

Condition: used, MORI SEIKI NH 4000 DCG is a Horizontal machining center by MORI SEIKI designed to deliver precision, high accuracy and operational reliability. Working capacities (travels, diameters, workpiece lengths) are not provided. Main technical specifications (spindle speeds, feed rates, power supply, dimensions, weight) are not provided. Accessory and equipment details are not specified. Built to achieve tight tolerances, suitable for automotive, aerospace, medical, watchmaking and machine tool applications Ijdpexx U Htofx Ad Detp

Condition: ready for operation (used), Year of construction: 1992, General Data Machine weight 10000 kg Movement X-Axis Movement 560 mm Z-Axis Movement 625 mm Y-Axis Movement 610 mm Ijdpfx Adoxx Dypj Dotp This 4-axis Okuma MA 400 HA horizontal machining center was manufactured in 1992. It features a 400 × 400 mm working surface, 560 mm X-axis travel, 610 mm Y-axis travel, and 625 mm Z-axis travel. The machine supports a maximum table load of 400 kg and offers rapid feeds up to 60 m/min. Consider the opportunity to buy this Okuma MA 400 HA horizontal machining center. Contact us for more information about this machine. Application Types Milling

Condition: ready for operation (used), Year of construction: 1998, Main Drive Number of axis 3 Spindle Speed 12000 RPM Ijdjxxngyjpfx Ad Dotp Tool taper BT 40 Movement X-Axis Movement 560 mm Z-Axis Movement 510 mm Y-Axis Movement 510 mm This 4-axis MORI SEIKI SH400 was manufactured in 1998. A robust twin pallet horizontal machining center from Japan, it features a 12,000rpm spindle, BT40 tool taper, and a 60 tool position magazine. Additional attributes include a 1-degree indexing table and a chip conveyor. If you are looking to get high-quality machining capabilities consider the MORI SEIKI SH400 machine we have for sale. Contact us for more information about this machine. Application Types Milling

Condition: ready for operation (used), Year of construction: 1998, Main Drive Number of axis 4 Spindle Speed 12000 RPM Tool taper BT 40 Movement X-Axis Movement 560 mm Ijdpfxjxxng Ts Ad Detp Z-Axis Movement 510 mm Y-Axis Movement 510 mm This 4-axis MORI SEIKI SH400 was manufactured in 1998. A twin pallet horizontal machining center from Japan, it features a 12,000rpm spindle, BT40 tool taper, and a 60 tool position magazine. Noteworthy are the through-spindle coolant and chip conveyor. Ideal for automated 4-axis machining, though it requires a new X-axis drive and is currently non-operational. Consider the opportunity to buy this MORI SEIKI SH400 horizontal machining center. Contact us for more information about this machine. Application Types Milling

Condition: excellent (used), Year of construction: 2022, x-axis 550 mm y-axis 450 mm z-axis 375 mm control SIEMENS 840D SL spindle turning speed range 1-17.500 U/min weight of the machine ca. 10 t dimensions of the machine ca. H 6,30 x 3,85 x 3,70 m The machine is designed for friction stir welding. Reinforced Z-axis (5000 N) required for the welding process. Itjdpfxsxxmmfo Ad Dsp Spindle speed increased to 1-17,500 rpm. including swivel axis Operating hours: approx. 11,111 h. Spindle running time: approx. 4,116 h.

Condition: ready for operation (used), Year of construction: 2017, Control Unit Brand SIEMENS Model 840D sl Operate with CELOS® Movement X-Axis Movement 560 mm Y-Axis Movement 560 mm Z-Axis Movement 660 mm Media Chip conveyor Yes Additional Equipment Tool breakage control system in the tool magazine Two pallets with threaded holes Automatic turning APC with 2 stations Isdjxwz Afjpfx Ad Djtp Direct distance measuring system Rotating viewing window in the work area door Coolant rinsing gun I/F for oil mist separator Knoll KF110/700 compact filter system Spindle sensor measuring system with optical signal transmission / Cooling unit for spindle Signal light (red, yellow, green, blue) This 4-axis DMG MORI NHX 4000 was manufactured in 2017. A robust horizontal machining center, it features a travel range of 560x560x660 mm and a clamping surface of 400x400 mm. The spindle was completely overhauled in May 2023. It has a tool magazine with 60 slots. The tool Holder is HSK 63 HSK-A63 motor spindle and the spindle speed range is 20 - 20,000 min-1. The machine includes a CELOS® control system with Siemens 840D sl Operate, enhancing usability with a multi-touch screen. For more information about this horizontal machining center, please reach out to us. Application Types Milling

Condition: ready for operation (used), Year of construction: 2002, General Data Measurements width 2700 mm Measurements depth 4200 mm Measurements height 2650 mm Machine weight 11500 kg Control Unit Brand MAZATROL Model PC-FUSION-CNC Movement X-Axis Movement 560 mm Y-Axis Movement 610 mm Z-Axis Movement 560 mm Additional Equipment Maximum Tool Diameter: 150 mm /Maximum Tool Length: 375 mm/ Maximum Tool Weight: 12 kg Tool Capacity: 64 positions Isdpfx Adsxwzx He Dotp This 4-axis Mazak FH-4800 horizontal machining center was manufactured in 2002. It offers robust and precise machining capabilities, ideal for a variety of applications. Consider the opportunity to buy this Mazak FH-4800 horizontal machining center. Contact us for more information about this machine. Application Types Milling

Condition: ready for operation (used), Year of construction: 2009, operating hours: 17,691 h, functionality: fully functional, travel distance X-axis: 560 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 630 mm, workpiece diameter (max.): 630 mm, workpiece weight (max.): 400 kg, TECHNICAL DETAILS Travel Paths & Axes Travel path X-axis: 560 mm Travel path Y-axis: 560 mm Travel path Z-axis: 630 mm B-axis max. rotational speed: 44.4 rpm Rapid Traverse Rapid traverse X-axis: 50 m/min Rapid traverse Y-axis: 50 m/min Rapid traverse Z-axis: 50 m/min Workpiece Dimensions Max. workpiece height: 900 mm Isdexvzt Iopfx Ad Djtp Max. workpiece diameter: 630 mm Max. workpiece weight: 400 kg Spindle & Tools Max. spindle speed: 14,000 rpm Distance spindle center to top of pallet: 80–640 mm Distance spindle nose to center of pallet: 100–730 mm Tool magazine: 60 positions Tool change time: 0.9 s Tool holder: BT 40 Pallets Pallet dimensions: 400 x 400 mm Number of pallets: 2 Pallet change time: 6 s Feed Feed rate X-axis: 50,000 mm/min Feed rate Y-axis: 50,000 mm/min Feed rate Z-axis: 50,000 mm/min Work Table Table width: 400 mm Table length: 400 mm Table load capacity: 400 kg MACHINE DETAILS Control model: MSX-701IV Power consumption: 32.8 kVA Dimensions & Weight Dimensions (L x W x H): 4,000 x 2,400 x 2,600 mm Total weight: 9,800 kg Operating Hours Power-on hours: 46,259 h Operating hours: 26,725 h Machining hours: 17,691 h

Condition: ready for operation (used), Year of construction: 2006, General Data Measurements width 3755 mm Measurements depth 2300 mm Measurements height 2610 mm Machine weight 9600 kg Main Drive Spindle speed range 14000 rpm Tool taper 7/24 Taper No. 40 Number of axis 4 Movement X-Axis Movement 560 mm X-Axis Rapid Traverse 50000 mm/min Y-Axis Movement 560 mm Y-Axis Rapid Traverse 50000 mm/min Z-Axis Movement 630 mm Z-Axis Rapid Traverse 50000 mm/min Itjdpfexuw Hhex Ad Djp Table Outer length 400 mm Outer width 400 mm Table load 400 kg This 4-axis MORI SEIKI NH 4000 DCG was manufactured in 2006 and features a horizontal machining centre with only 1,300 hours on the main spindle, which was overhauled in April 2022. If you are looking to get high-quality milling capabilities, consider the MORI SEIKI NH 4000 DCG machine we have for sale. Contact us for more information. Application Types Milling

Condition: good (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: 81362, travel distance X-axis: 305 mm, travel distance Y-axis: 305 mm, travel distance Z-axis: 330 mm, rapid traverse X-axis: 48 m/min, rapid traverse Y-axis: 48 m/min, rapid traverse Z-axis: 48 m/min, controller model: Fanuc 18i-MB, total height: 3,300 mm, total length: 2,030 mm, total width: 2,300 mm, table width: 250 mm, table length: 250 mm, overall weight: 4,600 kg, spindle speed (max.): 15,000 rpm, number of spindles: 1, number of slots in tool magazine: 40, Equipment: chip conveyor, documentation/manual, Kitamura Mycenter HX250iF, year 2011 Serial No.: 81362 - CNC control unit: Fanuc 18i-MB - Spindle power: 11.2 kW - Spindle speed: 15,000 rpm - Axis travels X/Y/Z: 305 / 305 / 330 mm - Rapid traverse (X/Y/Z): 48 m/min Isdpoxur E Sofx Ad Dstp - Number of tool stations: 40 - Tool holder type: BT30 - Tool change time: 1.2 s - Pallet size: 250 x 250 mm - Number of pallets: 2 - Maximum pallet load: 110 kg - Distance table center/spindle nose: 380 mm - Machine dimensions: 3,300 x 2,030 × 2,300 mm - Machine weight: 4,600 kg Equipment - Handheld remote control - 3-color status signal tower - Coolant tank with high-pressure pump - Oil mist extractor - Chip conveyor - Spindle chiller unit - Renishaw 3D probe - Renishaw tool measurement - Transformer - Approx. 150 tool holders

Condition: good (used), Year of construction: 2020, operating hours: 22,000 h, functionality: fully functional, machine/vehicle number: 2080594, travel distance X-axis: 600 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 400 mm, operating hours of spindle: 9,500 h, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, CNC Control SIEMENS 840D SL Electrical Connection Connection voltage: 3 × 400 V / 50 Hz (grounded) Network type: TN-S or TN-C system Total connected load: 133 kVA Power factor: 0.6 Protection: 200 A gG (5 s) Weight Machine operating weight: 20,000 kg Transport weight: 16,000 kg Tool Magazine Tool change system: Pick-up system Tool management: Fixed-coded tool positions Capacity: 84 tools (2 × 42) Maximum total tool weight: 350 kg Feed Drives Drive type: Three-phase synchronous motors Travel measuring system X/Y/Z: Direct, absolute Itsdpfoxt D Ezjx Ad Djp X Axes (X1 and X2) Rapid traverse: 100 m/min Max. acceleration: 12 m/s² Kv factor: 7 Peak force: 2 × 10,000 N Continuous force: 2 × 5,000 N Positioning accuracy: Tp = 0.008 mm Y Axis Rapid traverse: 100 m/min Max. acceleration: 10 m/s² Kv factor: 7 Peak force: 10,000 N Continuous force: 5,000 N Positioning accuracy: Tp = 0.008 mm Z Axes (Z1 and Z2) Rapid traverse: 100 m/min Max. acceleration: 20 m/s² Kv factor: 7 Peak force: 2 × 5,000 N Continuous force: 2 × 2,500 N Positioning accuracy: Tp = 0.008 mm Main Spindles Spindle arrangement: Horizontal, twin-spindle configuration Motor spindles, liquid-cooled, synchronous drive Spindle diameter: 40 mm Tool interface: HSK-A63 Lubrication: Minimal quantity lubrication (oil) Mechanical clamping force: > 18 kN Wear limit: 16 kN Speed range: 1 – 17,500 rpm Acceleration time: 0.7 s Power: 2 × 35 kW at 4,200 rpm (40% duty cycle) Rated power: 2 × 26 kW at 4,200 rpm Torque: 2 × 80 Nm (40% duty cycle) / 2 × 60 Nm (rated torque) Machining Area Spindle distance: 600 mm Travel Paths: - X axis: 600 mm - Y axis: 600 mm (optionally 875 mm) - Z axis: 500 mm Workpiece Clamping / Table System Swiveling mount with two separate rotary tables for installation of clamping bridges Swivel time 0–180°: 3.5 s Max. asymmetric load: 800 Nm Rotary table Ø 800 mm, repeatability: < 0.008 mm Maximum workpiece weight: 600 kg Peak torque: 981 Nm Rated torque: 698 Nm Max. table rotation speed: 50 rpm Angular acceleration: 2.5 – 10 rev/s² Positioning accuracy: ±5″ Tangential torque: 4,500 Nm Max. loading moment: 500 Nm Tool Change Times Chip-to-chip for n < 10,000 rpm: > 2.75 s Chip-to-chip for n < 17,500 rpm: > 3.15 s Note The system is delivered without product-specific tools, fixtures, or robot grippers.

Condition: good (used), Year of construction: 2014, operating hours: 48,000 h, functionality: fully functional, machine/vehicle number: 2080233, travel distance X-axis: 600 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 400 mm, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, CNC Control SIEMENS 840D Electrical Connection Connection voltage: 3 × 400 V / 50 Hz (grounded) Network type: TN-S or TN-C system Total connected load: 133 kVA Power factor: 0.6 Fuse rating: 190 A gG (5 s) Weight Operating weight of machine: 20,000 kg Transport weight: 16,000 kg Tool Magazine Tool change system: Pick-up system Tool management: Fixed-coded tool positions Capacity: 84 tools (2 × 42) Maximum total tool weight: 350 kg Feed Drives Drive type: Three-phase synchronous motors Linear measuring system X/Y/Z: Direct, absolute X-Axis Rapid traverse: 100 m/min Max. acceleration: 12 m/s² Kv factor: 7 Peak force: 10,000 N Continuous force: 5,000 N Positioning accuracy: Tp = 0.008 mm Y-Axis Rapid traverse: 100 m/min Max. acceleration: 10 m/s² Kv factor: 7 Peak force: 10,000 N Continuous force: 5,000 N Positioning accuracy: Tp = 0.008 mm Z Axes (Z1, Z2) Rapid traverse: 100 m/min Max. acceleration: 20 m/s² Kv factor: 7 Peak force: 2 × 5,000 N Continuous force: 2 × 2,500 N Positioning accuracy: Tp = 0.008 mm Main Spindles Itodpfxoxt D Ebo Ad Dep Spindle arrangement: Horizontal, twin spindles side by side Motor spindles, liquid-cooled, synchronous technology Spindle diameter: 40 mm Tool interface: HSK-A63 Lubrication: Minimum quantity lubrication (oil) Mechanical clamping force: > 18 kN Wear limit: 16 kN Speed range: 1 – 17,500 rpm Acceleration time: 0.7 s Power: 2 × 35 kW at 4,200 rpm (40% duty cycle) Rated power: 2 × 26 kW at 4,200 rpm Torque: 2 × 80 Nm (40% duty cycle) / 2 × 60 Nm (rated torque) Machining Area Spindle distance: 600 mm Travel paths: X-Axis: 600 mm Y-Axis: 600 mm (optional 875 mm) Z-Axis: 500 mm Workpiece Clamping / Table System OP1: Tilting support with two separate tilting tables for fixture bridges OP2: Double tilting carrier (Q-axis) with two direct-drive NC rotary tables (A-/U-axes) Double-sided gearing on the tilting carrier Swivel time 0–180°: 3.5 s Max. asymmetric load: 800 Nm Repeatability Ø 800 mm: < 0.008 mm Max. clamping device and workpiece diameter: Ø 675 mm × 1,430 mm Max. workpiece weight: 600 kg Peak torque: 981 Nm Rated torque: 698 Nm Max. table speed: 50 rpm Angular acceleration: 2.5 – 10 rev/s² Indexing accuracy: ±5" Tangential moment: 4,500 Nm Max. load moment: 500 Nm Tool Change Times Chip-to-chip at n < 10,000 rpm: > 2.75 s Chip-to-chip at n < 17,500 rpm: > 3.15 s

Condition: used, Year of construction: 2020, operating hours: 23,000 h, functionality: fully functional, machine/vehicle number: 2630079, travel distance X-axis: 800 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 650 mm, rapid traverse Y-axis: 120 m/min, rapid traverse Z-axis: 120 m/min, controller manufacturer: Siemens, controller model: 840D sl, workpiece diameter (max.): 1,830 mm, workpiece weight (max.): 800 kg, rotational speed (max.): 40 rpm, overall weight: 28,000 kg, spindle speed (min.): 1 rpm, spindle speed (max.): 17,500 rpm, operating hours of spindle: 11,000 h, distance between spindles: 800 mm, number of spindles: 2, number of slots in tool magazine: 84, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, This high-precision twin-spindle machining center from the SW series is designed for maximum productivity in mass production, especially in the automotive and supplier industries. The machine features two symmetrically arranged motor spindles, a twin NC rotary carrier, and two direct drive rotary tables, enabling simultaneous 5-axis machining and parallel metal cutting operations. Equipped with a Siemens 840D sl CNC control, minimum quantity lubrication, high-dynamic feed drives, and an 84-position tool magazine, the system provides dynamic, precise, and energy-efficient machining processes. The compact design and pick-up capable tool system ensure short chip-to-chip times and high machine availability. This machine is ideal for demanding precision machining tasks such as housings, structural components, gear parts, and components made from aluminum, cast iron, and steel in high-volume production. CNC Control SIEMENS 840D SL Electrical connection Supply voltage: 3 × 400 V / 50 Hz (grounded) Network type: TN-S or TN-C network Total connected load: 152 kVA Power factor: 0.6 Protection: 250 A gG (5 s) Weight Machine operating weight: 28,000 kg Transport weight: 24,500 kg Tool Magazine Tool change: Pick-up system Tool management: Fixed coded tool positions Capacity: 84 tools (2 × 42) Max. total tool weight: 400 kg Feed Drives Drive type: Three-phase synchronous motors Travel measurement system X/Y/Z: Direct, absolute X1- and X2-Axis Rapid traverse: 120 m/min Max. acceleration: 10 m/s² Kv factor: 6 Peak force: 2 × 6,000 N Continuous force: 2 × 3,000 N Positioning accuracy: Tp = 0.008 mm Y-Axis Rapid traverse: 120 m/min Max. acceleration: 11 m/s² Kv factor: 6 Peak force: 20,000 N Continuous force: 10,000 N Positioning accuracy: Tp = 0.008 mm Z1- and Z2-Axis Rapid traverse: 120 m/min Max. acceleration: 20 m/s² Kv factor: 6 Peak force: 2 × 6,000 N Continuous force: 2 × 3,000 N Positioning accuracy: Tp = 0.008 mm Main Spindles Spindle arrangement: Horizontal, twin spindles side by side Spindle diameter: 40 mm Tool interface: HSK-A63 Cooling: Liquid-cooled motor spindles Lubrication: Minimum quantity lubrication (oil) Mechanical clamping force: > 18 kN Wear limit: 16 kN Speed range: 1 – 17,500 rpm Acceleration time: 0.7 s Power: 2 × 35 kW at 4,200 rpm (40% duty cycle) Rated power: 2 × 26 kW at 4,200 rpm Torque: 2 × 80 Nm (40% duty cycle) / 2 × 60 Nm (nominal torque) Machining Area Spindle distance: 800 mm Traverse paths: - X-axis: 800 mm - Y-axis: 900 mm (optional 1,200 mm) - Z-axis: 650 mm Difference coupled Z axes: < 1.0 mm Difference coupled X axes: < 1.0 mm Workpiece Clamping / Table System Itsdpfx Ajxt D D Red Dsp Twin rotary carrier (Q axis) with two direct drive NC rotary tables (A/U axes) Swivel time 0–180°: 5.0 s Max. asymmetric load: 1,600 Nm Rotary table Ø 800 mm, repeatability: < 0.008 mm Max. workpiece weight: 800 kg Peak torque: 1,900 Nm Nominal torque: 1,300 Nm Max. table rotation speed: 40 rpm Tool Change Times: Chip-to-chip with n < 10,000 rpm: > 3.0 s Chip-to-chip with n < 17,500 rpm: > 3.15 s Note The system is supplied without product-specific tools, clamping devices or robot grippers.

Condition: ready for operation (used), Year of construction: 2007, Control Unit Brand OKUMA Model OSP-P200M Main Drive Spindle speed range 15000 rpm Movement Itedpfsxq Hr Eox Ad Djp X-Axis Movement 560 Y-Axis Movement 610 Z-Axis Movement 625 This 4-axis Okuma MA-400HA horizontal machining center was manufactured in 2007. It features a 560mm X-axis, 610mm Y-axis, 625mm Z-axis, and a table size of 400x400mm. The machine includes a 15,000 rpm spindle, 100-tool matrix magazine, and OSP-P200M control. It also boasts a 6 APC/pallet pool and a Mayfran Consep 2000 chip conveyor. Consider the opportunity to buy this Okuma MA-400HA horizontal machining center. Contact us for more information about this machine. Application Types Milling

Condition: ready for operation (used), Year of construction: 2001, Main Drive Number of axis 4 Movement X-Axis Movement 560 mm Y-Axis Movement 610 mm Z-Axis Movement 560 mm This 4-axis Okuma MA-40HA horizontal machining centre was manufactured in 2001. It features a robust OSP 100U control system and a generous automatic tool changer with 60 magazine slots (ISO40). Ideal for complex machining tasks with its 560 mm travel in X, Y, and Z axes. Contact us for more information about this machine. Application Types Ijdpfjxqtc Djx Ad Djtp Milling

Condition: used, Year of construction: 2005, CNC Horizontal Machining Center OKUMA MA-400H (Year 2005) Condition: Good, the machine is connected and can be seen in operation. Manufacturer: OKUMA Corporation (Japan) Model: MA-400H Year of manufacture: 2005 Scope of supply: Complete with Tsubakimoto / Mayfran Inc. chip conveyor and full assembly system. High-class CNC horizontal machining center designed for precise milling, drilling, and tapping of metal parts. An excellent choice for series production where performance, accuracy, and reliability are critical. Main technical specifications: (based on OKUMA MA-400H model specification) Control system: OKUMA OSP-E100H Working travel (X / Y / Z): 560 × 560 × 625 mm Table: 400 × 400 mm (2-position pallet changer) Max. workpiece diameter: 630 mm Max. workpiece height: 900 mm Max. table load: 400 kg Spindle speed: up to 15,000 rpm Spindle taper: BT40 Spindle motor: 15/11 kW Tool changer: 60 positions (automatic) Chip conveyor: Tsubakimoto / Mayfran Inc. – integrated Cooling: integrated cooling system Approximate weight: 11,000 kg Application: The OKUMA MA-400H is intended for the machining of medium and high-precision components in the automotive, mold, tooling, machine-building, and metal industries. Ideally suited for versatile machining – with automatic pallet changing, it enables operator-free production. Itedpsxql Dasfx Ad Djp If you have any further questions, please feel free to contact us.

Condition: ready for operation (used), Year of construction: 2005, operating hours: 15,756 h, functionality: fully functional, machine/vehicle number: 16252, travel distance X-axis: 500 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, controller model: FANUC 30i, workpiece weight (max.): 250 kg, TECHNICAL DETAILS Travel X-axis travel: 500 mm Y-axis travel: 500 mm Z-axis travel: 500 mm Work Table Pallet size: 300 x 300 mm Max. workpiece weight: 250 kg Rotary table: 360° x 0.001° Minimum/maximum spindle to table center distance: 120/620 mm Minimum/maximum spindle to table surface distance: 80/580 mm Max. workpiece size: 500 x 500 mm Spindle speeds: 50 - 15,000 rpm Spindle taper: ISO 40 Spindle drive power: 15/7.5 kW Feed rates X/Y/Z: 1 - 50,000 mm/min Rapid traverse: 50 m/min Rapid traverse B-axis: 33.3 rpm MACHINE DETAILS Control: FANUC 30i Total connected load: 38 kVA Weight: 10,000 kg Iodpfsxnwy Isx Ad Detp Operating Hours Running time: 15,756 h Control on-time: 116,776 h

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, machine/vehicle number: 40543, travel distance X-axis: 425 mm, travel distance Y-axis: 425 mm, travel distance Z-axis: 400 mm, overall weight: 8,500 kg, spindle speed (max.): 10,000 rpm, number of slots in tool magazine: 100, TECHNICAL DETAILS X-axis: 425 mm Y-axis: 425 mm Ijdpsxnwkgefx Ad Dstp Z-axis: 400 mm Pallet size: 300 x 300 mm Feed Rates Rapid traverse: 36,000 mm/min Cutting feed rate: 0–10,000 mm/min Tool Magazine Capacity: 100 ATC Spindle speed: 10,000 rpm Tool diameter: 95 mm Maximum tool length: 350 mm Maximum tool weight: 10 kg Max. tool weight (with tool holder): 10 kg Tool change time: 1.7 s Chip-to-chip time: min. 7 s Control: Fanuc 15M Pallet indexing: Full 4th axis MACHINE DETAILS Installation dimensions: approx. 3,690 x 4,614 x 2,475 mm Transport dimensions of the machine: 2.4 x 3.80 x 2.8 m Connected load: 20 kVA Phases: 3 Frequency: 50/60 Hz EQUIPMENT - Chip conveyor - Through-spindle coolant Note: The robot is equipped with 40 pallets. Spare pallets are also available.

Condition: ready for operation (used), Year of construction: 2007, General Data Measurements width 6000 mm Measurements depth 5500 mm Measurements height 3000 mm Machine weight 22000 kg Itodpsxnr Elsfx Ad Djp Main Drive Number of spindles 2 Spindle speed range 4200–16000 Movement X-Axis Movement 450 mm X-Axis Feed Force 8000 N X-Axis Rapid Traverse 60000 mm/min Y-Axis Feed Force 8000 N Y-Axis Rapid Traverse 60000 mm/min Z-Axis Movement 450 mm Z-Axis Feed Force 8000 N Z-Axis Rapid Traverse 60000 mm/min Tools Max weight 8 kg Max tool diameter 80 mm Max tool length 320 mm This 3-axis SAMAG MFZ 2-2 was manufactured in 2007, featuring a line voltage of 400V, frequency of 50 Hz, and a control voltage of DC 24 V. With a power consumption of 72kW and a weight of 700kg, it includes optional 3D data of the clamping tower. Consider the opportunity to buy this SAMAG MFZ 2-2 horizontal machining centre. Contact us for more information about this machine. Application Types Milling

Condition: ready for operation (used), Year of construction: 2006, General Data Measurements width 6000 mm Measurements depth 5500 mm Measurements height 3000 mm Machine weight 22000 kg Itodpfoxnr D Uox Ad Dop Main Drive Number of spindles 2 Spindle speed range 4200–16000 Movement X-Axis Movement 450 mm X-Axis Feed Force 8000 N X-Axis Rapid Traverse 60000 mm/min Y-Axis Feed Force 8000 N Y-Axis Rapid Traverse 60000 mm/min Z-Axis Movement 450 mm Z-Axis Feed Force 8000 N Z-Axis Rapid Traverse 60000 mm/min Tools Max weight 8 kg Max tool diameter 80 mm Max tool length 320 mm This SAMAG MFZ 2-2 was manufactured in 2006. A robust horizontal machining centre, it features a power rating of 72 kW and operates on a 400V mains voltage with a 50 Hz frequency. Weighing 700 kg, it includes optional 3D data for clamping towers and spare parts. Consider the opportunity to buy this SAMAG MFZ 2-2 horizontal machining centre. Contact us for more information. Application Types Milling

Condition: new, functionality: fully functional, feed length X-axis: 510 mm, feed length Y-axis: 510 mm, feed length Z-axis: 510 mm, feed rate X-axis: 60 m/min, feed rate Y-axis: 60 m/min, feed rate Z-axis: 60 m/min, 📄 Product Description Itsdpfoxnizdsx Ad Dop The Tongtai SH-4000P is a high-speed, high-rigidity horizontal machining center designed for efficient machining of aluminum and light metal workpieces. It features a compact structure, three-point support bed, high rapid traverse speed, and optional APC (Automatic Pallet Changer). The built-in spindle provides high speed and precision, ideal for automotive and general manufacturing industries. ⚙️ Technical Parameters Strokes on X/Y/Z: 510/510/510mm B axis rotary table: 0,001º indexing table Rapid traverse on X/Y/Z: 60/60/60 m/min Pallet size: 2 x (400x400mm) Maximum load on the table (pallet): 2 x 400kgs Maximum workpiece dimension (diameter x height): Ø 550 x H 800mm Spindle speed: 15.000 rpm Built in spindle motor: 18.5/26/37 kW Machine size (Width x Depth x Height): 1.750x5.060x2.720mm Machine weight: 8.700kgs Fanuc controller model 0i-MF with Manual guide i and 10,4''LCD monitor Tool shank: BBT-40 ATC with 60 tools CTS ( coolant through spindle): 70bar Chip Conveyor integrated type with trolley Oil Skimmer

Condition: used, Year of construction: 1998, x-travel 560 mm y-travel 560 mm z-travel 560 mm number of spindles 1 spindle tunring speed 12000 U/min torque 294 Nm tool changing time 1 sec rapid traverse x/y/z 40 m/min Kind of drive Kugelrollspindel tool numbers 40 tool length - max. 300 mm workpiece weight max. 8 kg tool taper HSK 63 tool change unit Palettenausführung tables 2 Loading weight 400 kg plate size 400 x 400 mm control Fanuc Professional 3 total power requirement 22 kW weight of the machine ca. 9 t Scope of delivery: - chip conveyor - ICZ Changes and errors in the technical data and information as well Subject to prior sale! Itsdpfx Aexndb Esd Dop
