LOEWE IndustrieOfenBau GmbH

Condition: as good as new (ex-display), functionality: fully functional, input voltage: 400 V, input frequency: 50 Hz, workpiece height (max.): 8 mm, workpiece width (max.): 60 mm, workpiece length (max.): 140 mm,

Condition: excellent (used), functionality: fully functional, Equipment: documentation/manual, BIESSE Jade 340 Edgebanding Machine Pre-milling unit Glue application unit Trimming and corner rounding unit Profile sanding unit Edge sanding unit Polishing units Fgjdpfxezcxyyj Accec Spray valves, front and rear Additional replaceable glue pot Machine in continuous use. Year of manufacture: 10/2018.

Condition: ready for operation (used), Year of construction: 2009, Edgebander manufactured in 2009. This IMA Novimat/I/680/650/R3 features joint milling, a gluing section, and a pressure zone. It also includes trimming, flush milling, a multi-profile milling unit, and a sanding unit. If you are looking to get high-quality edge banding capabilities, consider the IMA Novimat/I/680/650/R3 machine we have for sale. Contact us for further details. • Technical features: • Joint milling • Gluing section • Pressure zone • Trimming Fsdezcxlcspfx Accegc • Flush milling • Multi-profile milling unit • KFA unit • Multi-profile scraper • Surface scraper • Sanding unit • 2 NC-controlled grooving units Additional equipment • Workpiece return

Condition: used, Year of construction: 2013, Max. edge thickness: 3/8 mm Max. workpiece height: approx. 40/50 mm Min. workpiece length: approx. 250/300 mm Min. workpiece width: approx. 70 mm Feed rate: approx. 10 m/min Ready for operation: approx. 6 min Fodpfozcw Amjx Accsgc Power consumption: 6.5 kW Working height: 880 mm Dimensions: 3600 x 1300 x 1500 mm Weight: approx. 660 kg Storage location: Supplier

Condition: excellent (used), Year of construction: 2023, functionality: fully functional, Working height: 8–60 mm Strip edge thickness: 0.4–8 mm Roll edge thickness: 0.4–3 mm Spacer on the infeed guide “EASY SIZE” device Fodpfxjzcwmfj Accogc Grinding unit Infrared ceramic lamp “VC-S4.1” gluing unit “SGP” glue tank with CNC dosing, replacing the standard tank Pressure roller unit “RT-V” edge trimming unit Head trimming unit “K/SEL” Flush trimming unit “R-HP Multiedge 2R” Rounding unit “ROUND X Multiedge” Edge scraper unit “RAS-HP Multiedge 2R” Glue scraper unit for surfaces “RC-N” Brush unit “SP-V” Anti-adhesive spray unit “AAR” Spray unit for final edge finishing Spray unit for delicate edges “Maestro Active Edge” control system “eye-M” operator console with integrated PC Provision for barcode reader Internal lighting of the cabin and gluing area Touch-up rollers for “Nesting” processing Compliance with European safety regulations Approximate weight: 1829 kg Only 17,304 meters of edge material processed Installed in August 2024 Available in July 2026

Condition: used, Year of construction: 2014, machine/vehicle number: AH /117836, functionality: fully functional, year of last overhaul: 2025, Equipment: documentation/manual, Ideal machine for edge banding of solid wood panels MACHINING CAPABILITIES: - Panel height (thickness) to be machined: 8 to 60 mm - Router pass: max. 90mm², 0 to 3 mm - Minimum panel length to be machined: 140 mm with an edge thickness >3 mm 200 mm with an edge thickness between 3 and 12 mm - Panel width to be machined: up to 2000 mm - Edge thickness: 0.4 to 3 mm in coil form, up to 12 mm in strip form Panel overhang relative to the chain (part protrusion): min. 30 mm - Edge width: recommended overhang: panel thickness + 4 mm - Feed system (2 feed speeds) 18 m/min for thin edges 12 m/min for strip edges (solid wood) - Distance between parts (depending on feed speed): recommended min. 800 mm MACHINE COMPOSITION: - Unwinding table, useful diameter: Ø780 mm - Electric positioning infeed guide - Chain conveyor belt, work surface height from the ground: 96 cm - Front extension table with rollers (serves as a support up to 2 m) - RT-E sanding unit (edge trimmers or routers) 2 x 4 kW, 9000 rpm - VC gluing unit Infrared preheating of the edge Pre-feeder for EVA granules, indicative consumption 8.5 kg/h "Fastblock" glue pot, pneumatic pre-cutting shear Pressing with 4 rollers, including 1 motorized roller, pressure with electric adjustment - K-SEL end trimming unit Rotation speed: 12000 rpm, motor inclination from 0 to 15° - RFK top/bottom flush trimming unit Rotation speed: 12000 rpm - RI 800 chamfering/flush trimming unit with copy pad Rotation speed: 12000 rpm, spindle inclination from 0 to 25° - GLC compact sanding unit, 1400 rpm Belt: 75 x 2700 mm, inclination from 0 to 5°, adjustable pneumatic pressure - SPN polishing station with textile polishing brush - Motorized operator return, useful width 1 m, with 2 roller tracks, spacing 34 cm Air cushion track and belt conveyor. Arrival height from the ground: 79 cm OTHER CHARACTERISTICS: - General power supply: 400 V, three-phase + N + T, 50 Hz - Installed power: IN 52 A nominal - Pneumatic supply: 8 - 10 bars, dry air, working pressure: 6 bars - Extraction: 6 x Ø50 mm, 1 x Ø80 mm, minimum flow rate 3000 m3/h - CE marking, lockable disconnect switch, emergency stop buttons Fodpfxjzcpixo Accjgc

Condition: used, OTT Tornado - TOP Control system – via a 15-inch color touch monitor for full automation and maximum ease of operation CM-CombiMelt adhesive application system suitable for processing EVA and PUR hot melt adhesives, as well as all common cleaning granules Joint processing unit for attaching chipboard Automatic roll magazine Automatic edge magazine Double-head unit with automatic pivoting 0° / 3° Flush trimming unit – for flush trimming – 12 mm Fine milling unit RADIUS – radius milling – profile cutter R2 – R5 Automated copy milling – corner rounding Pull blade unit – radius – bevel Surface pull blade unit Lubricant spray device – PU Cleaning set with fine scrubbing device Very stable workpiece support with roller conveyors – FRONT with scissor lift Complete tool set included Machine is in EXCELLENT CONDITION Fjdpfx Aozcm Dyoccogc Machine from a craft business Few operating hours Available from the Lieboch warehouse

Condition: used, machine/vehicle number: 008605, Type of edging: Thin edge, Thick edge Gluing System: EVA Hotmelt Premilling Unit: yes Corner Rounding Unit: yes Grooving Unit: yes Max feed speed: 40 m/min Maximum panel thickness: 60 mm Operating Units: 9 nr Fsdpfx Ajzcmppeccsgc

Condition: new, CATALOG NUMBER HL001 - New machine, in stock – Pre-milling unit – Radial scraper + polishers TECHNICAL DATA - Panel thickness: 45mm - Edge thickness: 0.4 mm – 3 mm - Min panel width: 90mm - Min panel length: 90mm - Feed speed: 7m/min - Pre-milling: 9000 rpm - Top/bottom: 10500 rpm - Front/back: 8800 rpm - Polishing: 2800 rpm - Main motor: 6kW - Feed power: 0.75kW - Pre-milling power: 1.5kW - Glue spindle power: 0.25kW - Top-bottom milling power: 0.18kW Fsdpfx Aozccuujccsgc - Top milling power: 0.55kW - Top polishing motor: 3-phase 0.12 kW, 1-phase 0.18 kW - Bottom polishing motor: 3-phase 0.12 kW, 1-phase 0.18 kW - Working table height: 856mm, extended support width: 560mm - Extraction connection: 3x100mm - Dimensions (L/W/H): 3200/1200/1200mm, weight: 660kg Net price: 49,900 PLN Net price: 11,880 EUR based on 4.2 EUR exchange rate (Prices may change with significant fluctuations)

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, edge thickness (max.): 25 mm, height adjustment type: pneumatic, actuation type: electric, total height: 1,950 mm, total length: 8,000 mm, total width: 1,300 mm, overall weight: 7,500 kg, This high-performance SCM Stefani Solution XD is engineered for high-volume multi-shift industrial manufacturing, delivering continuous accuracy and a flawless edge finish even on the most sensitive high-gloss or thin-film materials. Equipped with a solid monolithic structure and advanced NC electronic touch controls, this specific 4-cabinet configuration maximizes stability and houses a comprehensive setup of high-end processing aggregates. Manufacturer: SCM Group (Italy) Model: Stefani Solution XD Configuration: Right-Hand Feeding Condition: Excellent, Fully Operational Location: Plovdiv, Bulgaria Availability: Immediate Estimated Footprint & Shipping Dimensions Total Machine Length: Approx 8,000 mm Total Transport Length: Approx. 8,300 mm (including extended infeed guides) Machine Width: Approx. 1,300 mm (transport width with side panel supports retracted) Machine Height: Approx. 1,950 mm (with safety hoods closed) Estimated Operating Weight: 7,500 kg Technical Specifications Feed Speed: Up to 25 – 30 m/min (NC-controlled variable track speed) Panel Thickness Capacity: 8 mm to 60 mm Edgeband Thickness Capacity: 0.3 mm to 22 mm Max Coiled Edge Capacity: 3 mm Actuation Type: Pneumatic & Multi-Axis Electronic Servo Motors Height Adjustment: NC-Motorized Automatic Top Belt Pressure Beam Fgsdpszcccrjfx Accec Pneumatic Requirement: 6 bar Control System Software: Maestro Pro-Edge / Active Edge Interface Premium Installed Working Units (Aggregates) This machine features a robust multi-station arrangement with a multi-hose high-efficiency central dust extraction layout: Pre-Milling Unit: High-capacity dual cutter block layout utilizing Hydro-Lock tool connections to guarantee zero vibration during panel edge squaring. Advanced Gluing Station (VC-600): Plasma-treated glue pot capable of rapid EVA and PUR hot-melt changes, backed by rapid pre-melting technology. End-Trimming & Fine Trimming Units: Rigid, low-inertia dynamic structures built to ensure zero scoring on fragile surfaces. Round 4 Corner-Rounding Unit: Multi-axis 4-motor high-speed profile rounding unit processing at up to 30 m/min. Finishing Stations: Multi-edge profiling scrapers, glue scrapers, and motorized buffing units for an out-of-the-box clean edge. Automated Axis Positioning: Complete machine changeovers happen in minutes directly from the touchscreen console, maximizing uptime. Top Track Pressure Belt System: Secures fragile components far better than traditional small-wheel setups to keep protective films pristine. Energy Management Built-In: Programmed with the SAVENERGY system to reduce plant power consumption during cycle idle times.

Condition: refurbished (used), Year of construction: 2022, functionality: fully functional, power: 18 kW (24.47 HP), workpiece height (max.): 60 mm, edge thickness (max.): 15 mm, height adjustment type: electric, actuation type: electric, overall weight: 3,000 kg, Equipment: CE marking, OTT Tornado + Like new, with belt-driven pressure system Full equipment including TextureFinish Fgedpjzcb Dhefx Accoc Narrow parts package Spray system for PUR processing Free space for, e.g., a grooving unit Overhang milling cutter for increased edge material Horizontal cutting unit Solid wood edges up to 15 mm Inspection by appointment.

Condition: used, Holz Her STREAMER 1057 XL FÜ + PU Edge thickness 0.4 - 6 mm Fjdezcau Eepfx Accjgc Modern control system with selector switch for adjusting the units Fully automatic edge magazine for roll and strip material GLU-JET adhesive application station, cartridges + PU adhesive Adhesive application using nozzle technology Sensor-controlled nozzle Workpiece height 6-60 mm Automatic adhesive height adjustment High-quality 3-roller pressure unit, 1st roller motorized Trimming unit, pneumatically controlled for roll and strip material up to 6 mm edge thickness With pneumatic adjustment of the trimming saw angle from 0-10° Routing unit, flush trimming 6 mm, radius routing - chamfer routing - 15° Corner copying unit - 3 mm edge thickness Scraping unit for chamfers and radii with 2 scraping blade holders Surface scraping unit - finishing Buffing unit Spray device in the infeed and outfeed area, as well as for PU Machine with all processing tools Machine is WORKSHOP TESTED From a craft business First delivery 2019 Available from stock in Lieboch

Condition: good (used), Year of construction: 2011, Single-sided edge banding machine in right-hand configuration with workpiece return, for hot melt or/and PU gluing, used, manufactured in 2011; approx. 8700 operating hours Edge thickness: 0.4 – 10 mm Workpiece dimensions: Width min.: 70 mm Height min.: 8 mm Height max.: 60 mm Length min.: 150 mm Feed speed: 14 – 20 m/min, stepless Glue application: Glue application roller with Vario-melt metering system Working height: 900 mm Machine dimensions: Machine height: 1,600 mm Machine width: 1,100 mm Machine length: 8,200 mm Machine weight: 4,000 kg Machine equipped with: -Double roller pressure with electronic positioning Fgodpfxszb Iuqo Accsc -Pneumatic control of all units from the central touch screen control via Beckhoff industrial PC -CM – CombiMelt gluing system: Processing units: -Fk -JOINT PROCESSING UNIT for attaching chipboard with 2 HF motors, 2.2 kW, 200 Hz, 12000 rpm, operating in forward and reverse direction, length-controlled. Tool: DIA joint set Ø 85 x 45 x 30, z 3, for board thicknesses up to 42 mm -AKM – Edge magazine for the automatic feeding of strip edges, with spiked roller feed and pneumatic. pressure bar. Including optical edge monitoring -M4+1 – Four-fold magazine, automatic roller retraction. For holding four edge rolls. With variable edge shaft for interchangeable edge. With automatic selection menu. -K 13 – DOUBLE TRIMMING UNIT with 2 HF motors 0.6 kW, 200 Hz, 12000 rpm, motors and saw blades pneumatically adjustable 0/5° -K 160 2 HM saw blades 140 x 3.2 x 16 mm, Z 36 -Bfc – FLUSH TRIMMING UNIT for pre-trimming the glued edges in the reverse direction. Sensing on one side, feed via program control. 2 HF motors 0.7 kW, 200 Hz, 12,000 rpm Tool: 2 HM – reversible cutting heads Ø 70 x 20 x 16 mm, z 4 (HF70). -HFt – FINE TRIMMING UNIT for radius trimming of the glued edges in the reverse direction. Sensing on both sides, automatically adjusted to edge thickness via program control. With 2 HF motors 0.3 kW, 200 kW, 12,000 rpm Tool: 2 HM reversible cutting heads Ø 70 x 20 x 16 mm, Z 4 (HF70), can also be fitted with radius tools -HFt – FINE TRIMMING UNIT for radius trimming of the glued edges in the reverse direction. Sensing on both sides, automatically adjusted to edge thickness via program control. With 2 HF motors 0.3 kW, 200 kW, 12,000 rpm Tool: 2 HM radius reversible knife heads (AR 73), Ø 73 x 16 x 16, z 3 for reversible inserts R 1 – R 3. -AKF – Automated COPY MILLING with two separate working spindles for top and bottom. 2 HF motors 0.37 kW, 200 Hz, 12000 rpm Tool: 2 PCD diamond radius tools Ø 73 x 13 x Ø 16. With integrated extraction. -AZK 4 – autom. operated SCRAPE BLADE CHANGING UNIT -ZKf – SURFACE SCRAPE BLADE UNIT with fine sensing device for removing residual hot melt adhesive in the joint area – with extraction. Additional equipment: -AS – Antistatic spray device, double, on glue joint -GS Lubricant spray device for spraying antistatic lubricant onto the edge surface, electronically controlled -RS – Cleaning set with 4-fold spray device and fine wiping device for cleaning the surface -KEO-c – EDGE CLEANING, oscillating and automatically adjustable. 2 motors 0.2 kW, with 2 cloth disks -WE – Angle insertion aid as a sliding carriage, foldable. For narrow parts. Interface for workpiece return Ligmatech ZHR 05 or comparable

Condition: excellent (used), Year of construction: 2017, Brandt KDF 1440 Edition Only 1700 operating hours – in very good condition – can also be supplied with a preheating station. XES 200 autonomous unit (+ €4500) available. SUMMARY OF MACHINE EQUIPMENT: JOINTER HEAD 2 X 2.2 KW 200 HZ Fodpfx Acezb Iggjcjgc GLUING UNIT QA 65 N SAWING UNIT BEVEL/STRAIGHT 2 X 0.18 KW PNEUMATIC ADJUSTMENT FOR SAWING BEVEL/STRAIGHT MULTI-STAGE MILLING HEAD MS 40 COUNTER-ROTATING PNEUMATIC 2-POINT ADJUSTMENT SHAPED MILLING HEAD 1 X 0.35 KW WD 60; also for structural flooring PNEUMATIC 2-POINT ADJUSTMENT RADIUS/BEVEL MULTI-STAGE SCRAPER HEAD MZ 40 GLUE JOINT SCRAPER EDGE TRIMMING UNIT Overpressure: PU rollers instead of standard rollers Additional application unit QA 65 N (interchangeable) Release agent spray unit for workpiece Automatic edge infeed Multi-roller scanning for multi-stage milling head MS 40 + multi-stage scraper MZ 40 Cleaning agent spray unit WORKPIECE AND EDGE PARAMETERS: – Workpiece width min: – For workpiece thickness 8-22 mm ¦ 70 mm* – For workpiece thickness 23-40 mm ¦ 120 mm* – For workpiece thickness 41-60 mm ¦ 150 mm* *Depending on workpiece length – Workpiece overhang ¦ 38 mm – Workpiece thickness ¦ 8 – 60 mm – Edge height max. = workpiece height ¦ + 6 mm – Edge material, roll ¦ 0.4 – 3 mm – Edge cross-section max. – For PVC ¦ 135 mm² – For veneer ¦ 100 mm² – Roller diameter max. ¦ 830 mm – Edge material, strip ¦ 0.4 – 8 mm – Edge cross-section max. – For strips ¦ 360 mm² – Feed rate ¦ 8 – 14 m/min – Max. feed rate with shaped milling head ¦ 11 m/min – Working height ¦ 950 mm – Pneumatic connection ¦ min. 6 bar – Overall length ¦ 5,573 mm Complete description: see PDF

Condition: ready for operation (used), Year of construction: 2024, workpiece height (max.): 60 mm, feed rate X-axis: 10 m/min, spindle speed (max.): 16,000 rpm, control type: PLC-controlled, The machine has already been disassembled and stored by a specialist. TECHNICAL DETAILS Rotational speed of the miter saw station: approx. 16,000 rpm Rotational speed of the milling station: approx. 16,000 rpm Maximum milling depth: 3 mm Design for edge thickness: 1 mm Hot melt adhesive specification for edge material max.: 3 mm Feed rate: approx. 10 m/min Maximum workpiece thickness: 60 mm EQUIPMENT Maintenance-free, coated glue basin with provision for interchangeable basins Glue dispensing device Pneumatic milling adjustment Combination design with interchangeable plate cutter Corner rounding milling cutter Radius drawing blade Surface drawing blade with pneumatic extraction device Cleaning station Robust chain drive Fjdpfx Acjzb Idfocogc Ball-bearing mounted double roller pressure pad Aggregate viewing window from the machine's rear and operator side Signal lamp for workpiece sequence Extendable workpiece support ACCESSORIES Hebrock 8 mm version Hebrock quick-change system for corner milling cutter Hebrock jointing up to 60 mm workpiece thickness Hebrock protective spray for edges Hebrock nesting (milling cutter + radius drawing blade) Hebrock Airtronic Note: Accessories are provided without guarantee. The principle applies: "Item purchased as seen." The prospective buyer must verify the completeness of the item on-site.

Condition: excellent (used), Year of construction: 2022, Manufacturer: BIESSE Model: AKRON 1440 A Category: Edge banding machine Year of manufacture: 2022 Availability: short notice Operational status: disassembled/stored Technical data Maximum edge banding thickness: 12 mm Maximum panel thickness: 60 mm Maximum thickness of roller material: 3 mm Minimum workpiece length: 140 mm Minimum workpiece width: 50 mm Minimum feed rate: 12 m/min Maximum feed rate: 18 m/min Feed rate: stepless Height adjustment: motorized Belt overpressure Gluing system: granulate Glue reservoir: top Quick-change glue reservoir Suitable for PUR adhesives Strip magazine Spraying device Edge trimming unit Preheating zone Pressure zone, NC-controlled Miter saw unit: 2 motors Edge trimming/radius/chamfer stations: 1 Corner copying unit: 2 motors Pulling blade unit Profile pulling blade, flat pulling blade Smoothing unit Nesting equipment Edge trimming/radius/chamfer stations, profile pulling blade Units controlled by timer NC axis(es) Profile change: automatic Edge trimming/radius/chamfer stations Design: left-hand machine Machine length: 5,610 mm Control system: BIESSE SMART TOUCH 23" Conformity marking: CE marking, EAC marking Fgsdpfx Acozb Aicjcoc Total connection: 13 kW Weight approx.: 2,250 kg Location: at customer's site - available immediately - As it is disassembled/stored.

Condition: used, Year of construction: 2017, functionality: fully functional, input voltage: 400 V, input current: 23 A, input frequency: 50 Hz, type of input current: three-phase, edge thickness (max.): 6 mm, feed rate X-axis: 11 m/min, total length: 4,200 mm, overall weight: 1,430 kg, Equipment: CE marking, documentation/manual, We offer this used SCM Olimpic K 360 T-ER1 machine, manufactured in 2017. Feed speed: 11 m/min Panel thickness: 8-60 mm Edge thickness: 0.4-6 mm Edge material in rolls: 0-3 mm Edge material in strips: up to 6 mm Compressed air pressure: 6 bar Minimum part length: 140 mm Minimum part width: 90 mm Distance between parts: 600 mm Power supply: 400V Weight: 1430 kg Machine length: approximately 4.10-4.20 m Equipment: 1. Pre-milling unit - 2 counter-rotating diamond milling heads - material removal of up to approximately 3 mm before edging 2. EVA gluing unit - Teflon tank Fgodjzb Aahjpfx Accsc - fast heating - option to use interchangeable tanks 3. Pressing zone - driven roller + 2 pressing rollers 4. K-2 end trimming unit - straight or bevel cutting - automatic mode switching 5. Upper/lower milling unit - edge processing: flush, radius, or bevel 6. Corner rounding unit - processing of front and rear corners - radius R1/R2 7. Profile scraper - finishing of edge radius 8. Flat scraper - removing glue residue 9. Polishing unit - removing glue residue 10. Anti-adhesive fluid system - 2 types of fluids for easier removal of glue residue The machine is in fully working condition. It has been in continuous operation. Testing is possible. If you have any questions or need additional information, please contact us.

Condition: excellent (used), Year of construction: 2000, Technical data: • Manufacturer: Hebrock GmbH (Made in Germany) • Type: EURO 2000 • Year of manufacture: 2000 • Voltage: 230 / 400 V • Frequency: 50 Hz • Power: 7 kW • Current consumption: 13.6 A Working range: • Workpiece thickness: approx. 10 – 50 mm • Edge thickness: approx. 0.5 – 3 mm • Minimum workpiece length: approx. 250 mm • Minimum workpiece width: approx. 70 mm • Feed rate: approx. 10 m/min Fodpfxezbyvae Accogc • Compressed air connection required (approx. 6–7 bar) Location: in stock at warehouse 54634 Bitburg - immediately available -

Condition: used, machine/vehicle number: 008494, Position 1: Single Edgebanders HOLZHER-LUMINA + MASTER 5510 Position 2: Panel Return Systems HOLZHER-LUMINA + MASTER 5510 Fodjzbxznspfx Accegc

Condition: used, machine/vehicle number: 008247, Type of edging: Thin edge, Thick edge Gluing System: PUR Premilling Unit: yes Corner Rounding Unit: yes Grooving Unit: yes Max feed speed: 25 m/min Fedpezbrn Uofx Accogc Maximum panel thickness: 60 mm Operating Units: 9 nr

Condition: used, machine/vehicle number: 008516, Type of edging: Thin edge, Thick edge, Solid wood Gluing System: EVA Hotmelt, PUR Premilling Unit: yes Corner Rounding Unit: yes Fsdpfx Aezbrn Ieccjgc Max feed speed: 18 m/min Maximum panel thickness: 60 mm Operating Units: 7 nr

Condition: used, machine/vehicle number: 008249, Type of edging: Thin edge, Thick edge Gluing System: PUR Premilling Unit: yes Corner Rounding Unit: yes Fgodpfx Ajzbrl Toccjc Max feed speed: 25 m/min Maximum panel thickness: 60 mm Operating Units: 8 nr

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, Header unit Gluing system Edge pressing unit Fgjdpfxszbicpe Accsc Edge trimming unit Rounding unit Edge scraper unit Glue scraper unit Available in May 2026

Condition: used, Year of construction: 2008, used Manufacturer: SCM Type: OLIMPIc K 200 Year of manufacture: 2008 Machine number: AF / 3623 CE type-tested: yes Feed rate m/min: 10 Cutting from the roll up to mm: yes Swiveling cutting unit 0° 3° 5° 20°: 90° Flush and radius milling with pneumatic feed: yes Radius cutting blade controlled / fixed: yes Edge thickness mm: 0.4 - 3.0 Workpiece height mm min / max: 8 - 50 Fedpfx Aezbc Edeccjgc Workpiece width mm min: 65 Space requirement approx. L x W x H mm: 2950 x 1250 x 1350 Weight approx. kg: 525 Storage location 97447 Gerolzhofen, free loading, unpacked Handover in the current condition as inspected, without warranty

Condition: new, Year of construction: 2023, functionality: fully functional, Machine is new, packed and ready for transport in Sellers warehouse in Croatia ! OLIMPIC k 560 composition "T-ER2" (40) - European safety regulations (CE norms) - ”StarTouch" electronic control with 12" display touchscreen n° 100 working programs which can be customized - "RT-V1" pre-milling unit - "VC-VM" gluing unit (Installed power: 3 Kw, Heating time: 12 min , Glue pot capacity: 1,5 kg) Fedpfx Acsza U H Rjcsgc - "SGP" - Smart Gluing Pot - "K/SEL" end cutting unit (Motors power: 0,35 kW, Speed of tools: 12.000 rpm) - "R-K" trimming unit (Motor power: 0 ,55 kW, Speed of cutters: 12.000 rpm, Exceeding material to the panel thickness: 2+2 mm, Min. panel thickness with radius: 12 mm, Vertical/front copying devices: disc/pad, Tool radius: 2 mm) - "ROUND X" rounding unit (Motor power: 0,35 kW, Speed of cutters: 12.000 rpm, Edge thickness: 0,4 3 mm, Panel thickness with a straight angle: 10 50 mm, Panel thickness with a shaped angle according to the profile): 10 30/40 mm, Tool radius: 2 mm) - "RAS-HP MULTIEDGE 2R" edge scraping unit - "Nesting" copying device TECHNICAL DATA Variable track feed speed m/min 12 -18 Panel thickness mm 8-60 Thickness of edges in strips mm 0,4-6 Thickness of rolled edges mm 0,4-3 Max. section of rolled edges mm² 135 Distance between two successive panels mm 600 Minimum panel length (100 mm min. width) mm 140 Min. length of edge in rolls mm 180 Min. length of edge in strips mm 220 Min. panel width (210 mm min. length) mm 95 Opening for panel support roller mm 500 Worktable height mm 900 MACHINE DIMENSIONS (transport): lenght: 5.005 mm wide: 1.000 mm height: 1.950 mm
