Industrieservice Edel

Condition: new, Year of construction: 2024, functionality: fully functional, turning diameter over cross slide: 475 mm, spindle bore: 65 mm, turning length: 1,600 mm, turning diameter: 300 mm, turning diameter over bed slide: 240 mm, quill stroke: 150 mm, quill diameter: 80 mm, rapid traverse X-axis: 13 m/min, rapid traverse Z-axis: 13 m/min, spindle speed (min.): 100 rpm, spindle speed (max.): 2,600 rpm, center height over cross slide: 240 mm, feed rate X-axis: 2 m/min, feed rate Z-axis: 13 m/min, total length: 4,703 mm, total width: 3,137 mm, total height: 2,388 mm, type of input current: three-phase, spindle motor power: 11,000 W, overall weight: 3,850 kg, rotational speed (min.): 100 rpm, rotational speed (max.): 2,600 rpm, torque: 305 Nm, travel distance X-axis: 300 mm, travel distance Z-axis: 1,600 mm, Turning diameter in gap: 710 mm, controller manufacturer: Milltronics, controller model: 9000 DGI, input voltage: 400 V, drill spindle diameter: 65 mm, nominal power (apparent): 24 kVA, number of spindles: 1, spindle nose: D1-6, tailstock quill diameter: 80 mm, tailstock quill mount: MK 5, tailstock quill stroke: 150 mm, number of slots in tool magazine: 8, Equipment: rotational speed infinitely variable, LIST PRICE of the machine incl. delivery and installation: €123,500.00!!!!! The machine is NEW and immediately available. Unloading and on-site positioning of the machine to be carried out by the buyer. Machine details: - CNC control Milltronics 9000-DGI - 15" LCD color touchscreen - Ethernet interface - USB interface - Productivity software: DSA, MSV, Bidirectional turning cycle, 9000-DGI Desktop - Connection for external keyboard - Electronic handwheels for manual operation, teaching, or automatic mode - Custom macros available - Override potentiometer for axes and spindle - Spindle load monitoring - Key switch to lock EDIT function - Indicator lights for operating status - Additional "M" function with CNC wait channel - Constant surface speed - Rigid tapping - Spindle speed 100–2600 rpm - Spindle motor 11 kW - Spindle nose type D1-6 - 8-position tool turret, 25 mm - 1 axial tool holder for standard tools 25 x 25 mm Kdjdpfxjxwy A De Aayjw - 1 tool holder for boring bars 32 mm - Automatic lubrication system - Full enclosure with sliding doors - Coolant system with pump - CE certification - Instruction manual, spare parts list, and wiring diagrams in digital format - Operating and maintenance manuals in digital format - Transformer for standard industrial power supply, 400 V, 3 phase - Lifting brackets for crane handling Optional accessories: - Manual 3-jaw chuck 300 mm - Hydraulic tailstock quill (only with hydraulic chuck) - Hydraulic 3-jaw chuck with hydraulic unit (diameter 300 mm, bore 70 mm) - Fixed steady rest with rollers, range 20–200 mm - Fixed steady rest with rollers, range 180–410 mm - Travelling steady rest with brass pads, range 20–200 mm - 38 mm boring bar holder for turret - 25 mm axial tool holder - Hinged belt chip conveyor instead of drawers - Programming manual (hard copy) - Machine manual (hard copy) - Floor mat with Milltronics logo

Condition: like new (used), Year of construction: 2014, Lead and feed screw lathe Kern Turning length: 2000 mm Turning diameter: 650 mm Diameter over cross slide: 420 mm Fixed and travelling steady rest Multifix toolholder size C Kdjdpfx Aaoxwm Rboyjw

Condition: good (used), Year of construction: 1994, functionality: fully functional, turning diameter: 410 mm, spindle bore: 54 mm, rotational speed (max.): 3,000 rpm, total height: 1,800 mm, total length: 2,200 mm, total width: 1,500 mm, workpiece weight (max.): 700 kg, overall weight: 2,100 kg, For sale is a Weiler E35 lathe. The machine is in good condition and fully operational. Technical data: Year of manufacture: 1994 Control: Siemens Sinumerik 805 Centre height: 200 mm Kdodpfx Asxu Ehgeayew Between centres: 950 mm Max. turning diameter over bed: 410 mm Max. turning diameter over cross slide: 200 mm Max. spindle speed: 3,000 rpm Tool changer: Multifix Spindle bore: 54 mm Max. workpiece weight: 700 kg Dimensions (approx.): 2,200 x 1,500 x 1,800 mm Weight (approx.): 2,100 kg Transport and loading can be organized Europe-wide for an additional charge, upon request. Prices are exclusive of VAT. Inspection possible by prior appointment. Please contact us – our team will be happy to assist you. Trade-in or exchange possible! Machinery purchase / sales PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MORE. Are you looking for a high-quality but affordable metalworking machine for your production? Or do you want to sell yours? For further information or contact options, please visit our website.

Condition: used, Year of construction: 1996, functionality: fully functional, spindle bore: 55 mm, turning length: 1,250 mm, turning diameter: 400 mm, swing diameter over cross slide: 245 mm, Harrison Alpha 400 in working condition, including external PC with software. Distance between centers: 1250 mm Swing over bed: 400 mm Swing over cross slide: 245 mm Swing in gap: 585 mm Spindle bore: 55 mm Spindle speeds: 15–2500 RPM Kodpfexu Arcsx Aayodw Accessories: - 3-jaw chuck with reversible jaws - Fixed steady rest - Travelling steady rest - Quick-change toolpost - Coolant system

Condition: like new (used), Year of construction: 2022, operating hours: 10 h, functionality: fully functional, turning diameter over cross slide: 430 mm, spindle bore: 80 mm, turning length: 1,500 mm, turning diameter: 430 mm, quill stroke: 150 mm, quill diameter: 70 mm, spindle speed (min.): 3,000 rpm, bed width: 350 mm, total length: 1,900 mm, total width: 1,500 mm, total height: 1,600 mm, spindle motor power: 11 W, overall weight: 3,500 kg, rotational speed (min.): 1 rpm, rotational speed (max.): 3,000 rpm, three-jaw chuck diameter: 250 mm, Equipment: rotational speed infinitely variable, The Seiger SLZ 420K is a conventional lathe known for its robust cast-iron bed, precise slideways, and digital support features. It is well-suited for single-part production, repairs. Kdsdpfxjxr U E Ae Aayow Dimensions and capacities • Swing over bed: 430 mm • Swing over cross slide: 220 mm • Center distance: 1,500 • Bed width: 350 mm Spindle and drive • Spindle bore diameter: 80 mm • Spindle head: DIN 55027, Size 6 • Spindle diameter in front bearing: 110 mm • Main drive: 11 kW • Speed range: 1–3,000 rpm Tailstock • Quill diameter: 70 mm • Quill stroke: 150 mm • Morse taper: MK 5 Control and features • Display: Heidenhain Positip 8016 digital display • Linear scale: Heidenhain linear scales on the X- and Z-axes • Feed rates: V-constant and controllable feed rates via a potentiometer • Rapid traverse: Functionality in both the X- and Z-axes • Handwheels: Mechanical handwheels for manual operation • Bed: High-quality, torsion-resistant cast-iron bed with hardened and precision-ground slideways The Heidenhain Positip 8016 is a digital measuring instrument with a touchscreen, suitable for manually operated milling, drilling, and turning machines. The display offers various functions to increase productivity and accuracy. Key features • Touchscreen operation: The device is equipped with a robust 12.1-inch color TFT touchscreen, which can also be operated while wearing gloves. • Multiple axes: The system can control up to six axes, four of which are standard linear, angular, or coupled axes, and two are optional. • Extensive functions: The Positip 8016 includes features such as drilling patterns, tool radius compensation, a cutting data calculator, and the ability to save positions. • Distance-to-zero function: This function helps you move quickly and accurately to the next position by working towards a zero value. • Programmable: Recurring machining steps can be saved as a program, which speeds up the production of small batches. • Interface: The display features interfaces such as Ethernet and USB for importing and exporting data. • Robust design: The device is specially designed for use in workshop environments and has a sturdy aluminum housing with passive cooling.

Condition: ready for operation (used), Year of construction: 1996, functionality: fully functional, machine/vehicle number: 28958, turning diameter over cross slide: 210 mm, spindle bore: 52 mm, turning diameter over bed slide: 400 mm, rotational speed (max.): 2,300 rpm, controller model: FAGOR 800T, No reserve price – guaranteed sale to the highest bidder! The payment deadline for the machine is 20/11/2025! Placing a bid obligates you to collect the machine on time between 01/12/2025 and 05/12/2025! TECHNICAL DETAILS Swing diameter over cross slide: 210 mm Spindle bore: 52 mm Swing diameter over bed slide: 400 mm Quill diameter: 58 mm Quill travel: 155 mm Center height: 200 mm Bed width: 300 mm Max. spindle speed: 2,300 rpm Center distance: 1,150 mm Swing diameter in gap: 600 mm MACHINE DETAILS Controller model: FAGOR 800T Kjdjxp Nnajpfx Aaysdw Tailstock quill taper: MK 4 EQUIPMENT Tool cabinet with accessories

Condition: repair required (used), Year of construction: 2003, Kern lathe CD 402 Baij 2003 in top condition but with control system issues. Kdodpfx Aaexn Axceysw

Condition: excellent (used), Professional stereo microscope KERN OZT 464 from the renowned German manufacturer KERN & Sohn GmbH, designed for industrial, laboratory, electronics, and research applications. Equipped with a high-quality ODC824 digital camera (3.1 MP CMOS, USB 2.0), enabling direct image transfer to a PC – an ideal solution for documentation, inspection, and analysis. Technical specifications: • Microscope model: KERN OZT 464 Kdjdpfx Aoxmlfioaysw • Type: stereo, binocular with trinocular camera port • Eyepiece: widefield WF 10x/20 mm • Magnification: approx. 7x – 45x (standard) • Illumination: adjustable LED, upper and lower • Power supply: 100–240 V, 50/60 Hz • Camera: KERN ODC824, 3.1 MP, 1/2” Aptina CMOS, USB 2.0 • Image capture and analysis software (Windows compatible) • Includes power and USB cables Condition: • Device in very good condition, fully functional • Clear and sharp image, smooth mechanical operation • Complete set with all cables, protective cover, and digital camera Applications: • Research and industrial laboratories • Quality control and metrology • Electronics servicing and micromounting • Education, science, and microscopic documentation

Condition: good (used), Year of construction: 2001, Lathe – cycle-controlled Manufacturer: WEILER Kodpfx Aajxl Ulpjyedw Machine Model: E 35 Control: Siemens / Weiler D2 Year of manufacture: 2001 TECHNICAL DATA Distance between centers (mm): 950 Center height (mm): 200 Max. turning diameter over cross-slide (mm): 200 Max. turning diameter over bed (mm): 410 Spindle - Max. speed (rpm): 3,000 Tailstock - Internal taper: MT 4 Connected load (kW): 10 DIMENSIONS & WEIGHT Length x width x height approx. (mm): 2,300 x 1,400 x 1,700 Weight approx. (kg): 2,100 Specifications and data are subject to change and errors.

Condition: used, Year of construction: 2002, Technical details: turning diameter: 475 mm turning length: 1500 mm control: HEIDENHAIN MANUAL PLUS 4110 turning diameter over slide: 260 mm turning speeds: 3000 U/min turret head: 12 Pos. spindle bore: 78 mm Kdsdpfxoxhqqme Aayew quill stroke: 120 mm weight of the machine ca.: 3,1 t dimensions of the machine ca.: 3,2 x 2 x 1,9 m SAUTER turret 12 pos. , VDI 30 chipconveyor, 4-jaw chuck approx. 74.000h "machine on" *

Condition: used, Year of construction: 2001, turning diameter over bed 320 mm turning diameter over slide rest 150 mm Kdsdexfwcqspfx Aayjw turning length 750 mm cross movement 185 mm turning speeds 14 - 3550 U/min centre height 160 mm spindle bore 52 mm tailstock quill taper MT 5 MK tailstock travel 120 mm tailstock quill diameter 70 mm rapid traverse X-axis 2000 mm/min rapid traverse Z-axis 2000 mm/min Control SINUMERIK 810 spindle drive 7,0 kW total power requirement 11,0 kW weight of the machine ca. 2,0 t dimensions 2,6 x 1,4 x 1,4 m Cycle lathe - 200mm chuck with reversible jaws - Multifix tool post - Machine feet - Documentation

Condition: excellent (used), Year of construction: 2004, Control: with Weiler D2 cycle control Centre distance: 950 mm Centre height: 200 mm Swing diameter over bed: 410 mm Swing diameter over cross slide: 200 mm Bed width: 330 mm Cross slide travel: 230 mm Top slide travel: 120 mm Cross slide length: 630 mm Cross slide width: 195 mm Bed carriage guide length: 480 mm Tool cross-section (height/width): 25 x 25 mm Spindle Spindle nose according to DIN 55027: Size 6 Front bearing spindle diameter: 90 mm Spindle bore: 54 mm Main spindle taper: 6 MT Main drive Drive power 60% / 100% duty cycle: 9 / 7.5 kW Max. spindle torque: 700 Nm Total speed range: 1 – 3000 rpm Speed range gear stage I: 1 – 750 rpm Ksdpjw Ufg Refx Aayedw Speed range gear stage II: 4 – 3000 rpm Feed drive Three-phase servo drives Feed range longitudinal and facing: 0 – 20 mm/rev Feed force longitudinal: 8000 N Feed force facing: 5000 N Rapid traverse speed longitudinal/facing: 10 / 5 m/min Tailstock Quill diameter: 65 mm Quill stroke: 120 mm Quill taper: 4 MT Thread cutting range Metric threads: 0.1 – 400 mm Inch threads: 1/4 - 56 TPI / 1" Module threads: 0.125 – 28 mm pitch DP threads: 1 – 224 TPI Machine dimensions Total length: 2300 mm Total width: 1400 mm Total height: 1700 mm Machine weight: 2100 kg Fixed steady rest (option) Clamping range: 12 – 150 mm Travelling steady rest (option) Clamping range: 10 – 160 mm

Condition: good (used), Year of construction: 2008, operating hours: 7,840 h, functionality: fully functional, machine/vehicle number: 3212.08, turning diameter over cross slide: 260 mm, spindle bore: 106 mm, turning length: 2,000 mm, turning diameter: 475 mm, center width: 2,000 mm, turning diameter over bed slide: 475 mm, CNC LATHE – Cycle Lathe CD480 Manufacturer: DMT Kern Model: CD480 x 2000 Control: HEIDENHAIN "MANUALplus 620" Year of manufacture: 2008 Condition: Good / Very good Operating hours: 7,840h Kedpfsw Exlvox Aayedw Scope of delivery: - Original documentation - Tailstock - Automatic twelve-position turret with driven tools Tool mounting DIN 69880, Q5 30mm, mounted on the rear cross-slide - Additionally, Multifix B at the front - Main spindle with DIN 55026/A8 mount, bore 106mm, spindle bearing diameter at the front 140mm - Special speed range, max. 2,500 rpm - Fixed steady rest with roller jaws - … and many other factory-fitted special features (see description) - Tool holders, various lathe chucks, mounts for the tool turret, driven tools etc. can be purchased as an extra package and are not included in the main machine delivery!

Condition: as good as new (ex-display), Year of construction: 2025, Machine is in the exhibition and was only used for demonstration purposes. Optiturn L44 CNC Premium CNC lathe direct from the manufacturer. Kdsdpfew Ea Tusx Aayew L44 CNC - The OPTIMUM Premium CNC milling machine with Siemens SINUMERIK 828D control is characterized by performance, speed, precision and long service life. Dimensions and weights Width/depth max. 2300 mm Length approx. 2530 mm Width/depth approx. 1595 mm Height approx. 1795 mm Weight approx. 2600 kg Working areas Lathe chuck diameter 150 mm Lathe chuck Hydraulic control of the clamping movement Center height 223 mm Center width 850 mm Swing diameter over machine bed 446 mm Swing diameter in the bed bridge 520 mm Swing diameter over cross slide 240 mm Bed width 300 mm Motor torque X-axis 6 Nm Z-axis 8.5 Nm Speed range Number of speed ranges 1 Speed range 10 - 3000 min¯¹ Electrical data Drive motor power 7 kW Supply voltage 400 V Mains frequency 50 Hz Electrical connection Total connected load 23 kVA Accuracy Repeat accuracy ± 0.005 mm Positioning accuracy ± 0.005 mm Hydraulic system Motor output 0.75 kW Tank capacity 50 l Coolant system Coolant pump output 270 W Tank capacity 90 l Machine data Chuck opening diameter 40 mm Motor(s) Torque drive motor 33 Nm Tailstock Mounting MK 4 Quill stroke 165 mm Quill diameter 52 mm Spindle Spindle holder DIN ISO 702-1 No. 5 Spindle bore/bar passage diameter 52 mm Control system Type Sinumerik 828D PPU 240 System software SW 24 CNC memory 3 MB Look Ahead 50 Block change time 3 ms Number of tools 128 Travel distance X-axis 250 mm Z-axis 760 mm Vertical spindle Power drive motor continuous operation S1 7 kW Power drive motor S6-30 % operation 16 kW Drive motor torque 33 Nm Drive motor S6-30 % operation 80 Nm Feed rate Speed X-axis 15000 mm/min Z-axis 15000 mm/min Feed force Feed force X-axis 7.5 kN Feed force Z-axis 5.3 kN Tool changer Hydraulic type; VDI 30 Number of tool positions 8 pcs Mounting height, width square max. 20 x 20 mm Boring bar mounting diameter max. 25 mm SIEMENS SAFETY INTEGRATED Equipment Main spindle - Solid design Machine bed - Heavily ribbed - High rigidity and durability Guideways - Stable flat bed guide Recirculating ball screw - For high rapid traverse speeds in all axes - Less wear and tear - For high positioning and repeat accuracy Cast body - Hardened HRC48-52 and heat-treated Machine feet - Six pieces - Optimum alignment of the machine Heat exchanger - Closed switch cabinet with intelligent cooling management - Optimum temperature even at high outside temperatures Tool changing system - Eight tool stations - Hydraulic VDI30 tool changer - Pick-up height max. 20 mm Hydraulic unit - Motor power 750 W - Tank capacity 50 liters - Clamping pressure / operating pressure 2,500 - 2,942 kPa Three-jaw chuck - Hydraulic three-jaw lathe chuck Ø 150 mm - Hydraulic loosening and clamping via foot switch - Simple clamping of workpieces - Hard and soft block jaws Central lubrication system - Automatic supply at intervals - Reduces wear on bearings, ledges and ball screws - With float switch. An acoustic signal sounds if the oil level is too low

Condition: used, Year of construction: 1996, CNC lathe Padovani, year 1996, including stainless steel tray. CNC Lathe PADOVANI Labor E255x1500 Year of manufacture: 1996 Drive power: 20 kW Spindle drive power: 17.5 kW Spindle bore: 77 mm Röhm chuck Ø 250 mm Turning diameter over bed: Ø 510 mm Over cross slide: Ø 330 mm Centre distance: 1500 mm Tool holder: Multifix size C, steel holder included Control: Siemens Sinumerik 805 Weight: 3,000 kg Kdsdpsxurbgefx Aayow Speed up to 2,500 rpm Condition: good, including stainless steel tray

Condition: ready for operation (used), Year of construction: 2013, functionality: fully functional, spindle bore: 80 mm, turning length: 1,000 mm, turning diameter: 430 mm, swing diameter over bed slide: 430 mm, spindle speed (max.): 3,600 rpm, TECHNICAL DETAILS Machining Area Turning diameter: 430 mm Turning length: 1,000 mm Swing diameter over bed: 430 mm Swing diameter over carriage: 220 mm Spindle bore: 80 mm Quill taper: 5 MT Spindle and Feeds Speed: 1 – 3,600 rpm Rapid traverse: 10/7 m/min Stepless feed: 0 – 5,000 mm/rev Kodpfx Aow A Rp Usayedw Control: Heidenhain MPlus 620 HSCI MACHINE DETAILS Electrical Data Drive power: 16 kW Total power requirement: 16.5 kW Dimensions & Weight Dimensions: 2,800 x 2,100 x 1,900 mm Weight: 3,300 kg

Condition: good (used), Year of construction: 2004, Swing over bed Ø 320 mm Swing over cross slide Ø 150 mm DBC Turning Length 750 mm Spindle bore 52 mm Spindle power 16 kW Tailstock spindle Ø 60 Ø Kjdpfswu Dq Aex Aayjdw Stroke pinole 140 mm Spindle taper 4 Mk Speeds / ranges 3000 Rpm Feed rate X-Axis 1000 mm/min. Feed rate Z-Axis 2000 mm/min.

Condition: used, New 2007 Seimens Sinumerik control Swing over bed Ø460 mm Swing over cross slide Ø258 mm Swing in the gap Ø670 mm Turning Length 1500 mm Spindle bore 58 mm Spindle power 7.5 kW Kdedpswtpzqofx Aayew Spindle taper 4 Mt Speeds ranges 3000 Rpm Feed rate X-Axis 5000 mm/min. Feed rate Z-Axis 5000 mm/min.

Condition: used, Year of construction: 1997, - Year: 1997 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 270 - Drive system: Teach-in - Centre height [mm]: 210 - Swing over bed [mm]: 420 - Distance between centres [mm]: 900 - Spindle bore [mm]: 55 - Min. spindle speed [rpm]: 4 - Max. spindle speed [rpm]: 3000 - Options: Digital readout - Type of digital readout: Weiler - Control: CNC Financial information VAT: The price shown is exclusive of VAT Kjdpfownh I Sox Aaysdw VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 2006, Technical details: turning diameter: 490 mm turning length: 2000 mm total power requirement: 15/20 kW weight of the machine ca.: 3,6 t Kdsdpfxowmcx Ao Aayew dimensions of the machine ca.: 2,8 x1,85 x 1,9 m In like new condition Heidenhain cycle control Torsion-resistant bed, made of high-quality cast iron with hardened, precision-ground guideways and a glass scale on the X-axis Safety clutch on the Z and X axes Sealing air with carbon filter in direct position measuring system High accuracy and rigidity of the lathe spindle thanks to precision spindle bearings, spindle bore Ø 93 mm standard, optional Ø up to 130 mm Solid tailstock, quill Ø 90 mm with internal taper MK5 Large overhang above the facing slide for easy accessibility during shaft machining. The machine has Teach-in CNC Programms. Control: MC420. Tool holder: SAUTER. *

Condition: reconditioned (used), Year of construction: 2013, Cycle-controlled lathe WEILER E 40 With Siemens Sinumerik cycle control WEILER 840 D /SL 1 Year of manufacture: 2013 Spindle bore: 66 mm Center distance: 1000 mm Turn over bed: 435 mm Turn over cross slide: 200 mm Center height: 210 mm Speed range: 1 – 3500 rpm continuously variable Ksdpfowfm Tbsx Aayedw With the following accessories: Sliding guard with interior lighting 8-station SAUTER turret 3-jaw RÖHM chuck, Ø 200 mm Tailstock with extendable drilling sleeve Coolant system Coolant spray gun Chip collection tray 5 height-adjustable machine mounts Operating manual

Condition: good (used), Year of construction: 1998, mas masturn 40 cnc teach-in Heidenhain control 1998 Kdjdpfx Aaewbputoysw max. turning diameter 400 mm max. turning diameter over bed 250 mm max. turning length 800 mm spindle 1 - 2400 rpm spindle bore 61 mm 11 kW including accessories and documentation machine is powered up for inspection.

Condition: good (used), Year of construction: 2008, functionality: fully functional, spindle bore: 56 mm, turning length: 1,310 mm, feed length X-axis: 280 mm, feed length Z-axis: 1,310 mm, For sale is a Richyoung RIC-TC1860 cycle-controlled lathe with an 8-station tool changer and Sauter body. This special price is valid for pickup by March 28, 2025. The machine is in very good condition and fully functional. Only one-off orders have been processed on it. The machine has been regularly cleaned and well maintained. Technical Specifications: Year of Manufacture: 2008 Control: Fagor Bed Suspension: 460 mm Swing Diameter over Cross Slide: 230 mm Center Distance: 1,500 mm Ksdpfx Aaov Tc Dtsyjdw Spindle Nose: D1-6 Spindle Bore: Ø 56 mm Spindle Speed: Max. 3,100 rpm X-Axis Travel: 280 mm Z-Axis Travel: 1,310 mm Spindle Motor: 5.5 kW Tool Changer: Sauter Tool Positions: 8 Tool Holder: VDI 30 Included: Chip tray, tool changer, 3-jaw chuck including 4 * 3 interchangeable jaws, live center Also Available: 2* collets, tool holder including collets, various centering centers 4* various 3-jaw chucks, various Interchangeable jaws for chucks, 8 * boring bar holders, 10 * radial tool holders on the right, 3 * drill chucks, soft boring jaws Transport and loading can be arranged throughout Europe upon request for an additional charge. Prices exclude VAT. Viewings are available by appointment. Contact us; our team will be happy to assist you. Trade-ins or exchanges are possible! Machine Purchase / Sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality, yet affordable metalworking machine for your production? Or do you want to sell yours? For further information or to contact us, visit our website

Condition: excellent (used), Year of construction: 2004, Model: BNC-1840 Control: FAGOR 8055 FL Year: 2004 Kdedpfsv Rxglsx Aayew Swing over Bed: 475mm Distance between centres: 1000mm Spindle Speeds: 100 – 4500 RPM Spindle Bore: 65mm Machine with: Quick Change Toolpost Filtermist Unit 3-jaw chuck Dimensions: 3000 x 1850 x 2000mm high Weight: 3000 kgs

Condition: used, Year of construction: 2007, self-learning lathe 230x1000 bar passage 58mm cnc FAGOR 8055 year of construction 2007 complete with: self-centering chip conveyor manual turret CAPTO C4 attachment tool holder series clamps series Kdodpfx Asv Nquleayow manual and CE certificate
