Condition: good (used), Year of construction: 2015, 2015 Haas VF 3SS CNC Vertical Machining Centre Table Size 1,219mm x 457mm (5 'T' Slots 16mm Wide x 80mm Pitch). Table Load 794kg. Axis Travel 'X'=1,016mm, 'Y'=508mm, 'Z'=635mm. Distance From Spindle Nose To Table 742-107mm. Rapid Traverse 'X'=35.6m/min, 'Y'=35.6m/min, 'Z'=35.6m/min. Maximum Cutting Feed 21.2m/min. Maximum Spindle Speed 12,000rpm (22.4kW Motor). Spindle Taper BT40. 24 Position ATC. Maximum Tool Ø64mm (Ø127mm Non Adjacent Tool), Maximum Tool Length 330mm, Maximum Tool Weight 5.4kg. S/No. 1119704 (2015). Hfedpjzc Ih Tefx Ac Neh With Coolant Filtration System (208L Tank), Auger Screw Chip Conveyor, Renishaw OTS Tool Setter, Renishaw Spindle Probe, Signal Tower, Handwheel & Manuals. Note: Tooling & Work Holding Not Included.

Condition: excellent (used), Year of construction: 2020, 2020 Haas UMC-750 CNC 5 Axis Vertical Machining Centre Table Dimension Ø500mm (7 'T' Slots). Maximum Table Load 300kg. Axis Travel 'X'=762mm, 'Y'=508mm, 'Z'=508mm, 'B'=-35° To +120°, 'C'=360°. Distance From Spindle Nose To Table 610-102mm. Rapid Traverse 'X'=22.9m/min, 'Y'=22.9m/min, 'Z'=22.9m/min, 'B'=50°/sec, 'C'=50°/sec. Maximum Cutting Feed 16,5m/min. Maximum Spindle Speed 8,100rpm (22.4kW Motor). Spindle Taper BT40. 40 + 1 Position ATC. Maximum Tool Ø64mm (Ø127mm Non Adjacent Tool), Maximum Tool Length 305mm, Maximum Tool Weight 5.4kg. S/No. 1172799 (2020). Hedpfx Acszc Idhe Nefh With Coolant Filtration System (208L Tank), Hennig Chip Conveyor, Renishaw Tool Setter, Renishaw Spindle Probe, Signal Tower, Handwheel & Manuals. Note: Tooling & Work Holding Not Included.

Condition: good (used), Year of construction: 2016, Ref. -No.: 10411 Manufacturer: BROTHER Type: Speedio S700X1 Year of construction: 2016 Type of control: CNC-Steuerung Control: BROTHER CNC Storage location: Halberstadt Country of origin: Germany X-Travel: 700 mm Y-Travel: 400 mm Z-Travel: 300 mm Main spindle drive power: 15,4 kW Main spindle speed range: 16 - 16.000 RPM Table surface: 800 x 400 mm Distance Spindle /Table: 180 - 480 mm Table Load: 300 kg Max. Tool Weight: 25 kg Max. Tool Length: 250 mm Max. Tool Diameter: 110 mm Tool change time: 0,8 s Hfjdezc Dyropfx Ac Noh Tool Taper: BT 30 Tool Piece Magazine With: 21 Pcs./pcs. Feed Speeds X/Y/Z Axis: 10.000 - 20.000 mm / min Rapid Traverse X-Axis: 50 m / min Rapid Travel Y-Axis: 50 m / min Rapid Traverse Z-Axis: 56 m / min X - axis acceleration: 2,0 G Y - Axis acceleration: 1,3 G Z - axis acceleration: 2,2 G Acceleration time: 0,30 sec Machine length: 2360 mm Machine width: 2120 mm Machine Height: 2500 mm Weight Of The Machine Ca.: 2,4 t Further information: THREAD Speed: 6,000 rpm Acceleration time: 0.11 s CUTTING CAPACITY Drilling capacity in aluminum: max. 24 mm / F0.2 Drilling capacity in C45 steel: max. 18 mm / F0.1 Tapping capacity in aluminum: max. M22 Tapping capacity in C45 steel: max. M14 Milling capacity in aluminum: max. 660 cm³/min. Face milling cutter: Ø 100 / depth 2.2 mm / F=3000 Milling capacity in steel C45: max. 48 cm³/min. Face milling cutter: Ø 40 / depth 2.5 mm / F=484 HIGH-SPEED TOOL CHANGER Stations with directional logic: 21 Change time T - T: 0.8 seconds Changeover time C - C at n=10,000 rpm and XYZ positioning: 1.4 seconds Positioning accuracy: ± 0.006 mm Repeat accuracy: ± 0.004 mm Accuracy of thread depth: 0.05 mm Air consumption: 45 l/min Air pressure: 0.5-0.6 MPa Air quality: 99% anhydrous Including FANUC robot / automation Machine can be inspected under power.

Condition: good (used), Year of construction: 2006, Haas VF-5B/40HE vertical machining center, year 2006. Hjdpfxezcu Imj Ac Nofh

Condition: like new (used), Year of construction: 2023, functionality: fully functional, travel distance X-axis: 770 mm, travel distance Y-axis: 410 mm, travel distance Z-axis: 510 mm, rapid traverse X-axis: 36 m/min, rapid traverse Y-axis: 36 m/min, rapid traverse Z-axis: 36 m/min, total height: 2,661 mm, total length: 2,300 mm, total width: 2,400 mm, overall weight: 4,100 kg, spindle speed (max.): 12,000 rpm, spindle motor power: 7,500 W, Equipment: chip conveyor, rotational speed infinitely variable, Vertical CNC machining center Control: FANUC F0MF+ Accessories: Chip conveyor, hinged belt type, manufactured by Cromar CNC AutoDoor Hfedpfx Aezcpgwoc Njh

Condition: ready for operation (used), Year of construction: 2008, operating hours: 10,294 h, travel distance X-axis: 700 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 330 mm, controller manufacturer: FANUC, controller model: 31i-A5, total height: 2,336 mm, total width: 1,565 mm, table width: 400 mm, table length: 650 mm, table load: 300 kg, overall weight: 2,000 kg, spindle speed (max.): 10,000 rpm, spindle motor power: 5,500 W, number of slots in tool magazine: 21, tool weight: 2,000 g, product length (max.): 2,027 mm, number of axes: 3, This 3-axis FANUC ROBODRILL Alpha-T21iFL was manufactured in 2008. It features an X-axis travel of 700 mm, Y-axis travel of 400 mm, and Z-axis travel of 330 mm. The machine has a rapid traverse rate of 54,000 mm/min and a spindle speed of 10,000 RPM. If you are looking to get high-quality drilling, tapping, and milling capabilities, consider the FANUC ROBODRILL Alpha-T21iFL vertical machining centre we have for sale. Contact us for further details. • Control Model: FANUC 31i-A5 • Table T-Slots: 3 • T-Slot Size: 14 mm • T-Slot Pitch: 125 mm • Distance Table to Spindle Nose: 250 – 580 mm • Rapid Traverse Rate: 54,000 mm/min • Feed Rate: 1 – 30,000 mm/min • Acceleration: 1.5 G • Continuous Spindle Power: 3.7 kW • Spindle Taper: BBT30 Big Plus • Tool Holder: BT30 • Tool Magazine Capacity: 21 • Maximum Tool Length: 250 mm • Tool Change Time: 1.6 sec • Positioning Accuracy: 0.006 mm / 300 mm • Repeatability: ±0.002 mm • Memory Capacity: 512 KB • Display Size: 10.4 in • Signal Lamp Hfsdpfx Acezb Iq Ss Neh • Coolant Tank Capacity: 200 L • Power Supply: 400 V / 50 Hz • Air Pressure Requirement: 0.35 – 0.5 MPa • Power-On Hours: 24,133 h • Run Time: 10,294 h • Application: High-Speed Drilling, Tapping and Milling of Precision Components

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, travel distance X-axis: 1,660 mm, travel distance Y-axis: 760 mm, travel distance Z-axis: 660 mm, table load: 1,200 kg, rotational speed (max.): 8,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range X-axis: 1,660 mm Travel range Y-axis: 760 mm Travel range Z-axis: 660 mm Table size: 760 x 2,000 mm Table load capacity max.: 1,200 kg Tool holder: SK 40 Tool changer: 2 x 24 Tool diameter max.: 80 mm Tool diameter with free adjacent slot max.: 110 mm Tool length max.: 350 mm Rapid traverse (X/Y/Z): 24 / 24 / 30 m/min MACHINE DETAILS Control system: MAZATROL M-PLUS Hfsdpfszb D N Rex Ac Neh Dimensions & Weight Space requirement: approx. 6.0 x 4.0 x 3.5 m Machine weight: approx. 8.1 t Total power requirement: 32.8 kVA The machine has been regularly serviced.

Condition: ready for operation (used), Year of construction: 2015, travel distance X-axis: 762 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 508 mm, overall weight: 3,500 kg, spindle speed (max.): 8,100 rpm, number of axes: 3, This 3-axis HAAS VF-2YT was manufactured in 2015. It features an X-axis travel of 762 mm, Y-axis travel of 508 mm, and Z-axis travel of 508 mm. The machine includes a table size of 914 x 457 mm and a spindle speed of 8,100 RPM. If you are looking to get high-quality machining capabilities, consider the HAAS VF-2YT vertical machining centre we have for sale. Contact us for further details. Hfjdoza Umkspfx Ac Njh • Table size: 36" × 18" (914 × 457 mm) • Spindle taper: CT40 • Spindle motor: 30 hp • Tool changer: 40 ATC • Rapid traverse (X/Y/Z): 1000 ipm • Preparedness: 4th axis drive pre-wired; prepared for 4th/5th axis integration • Notes: Optional direct-drive spindle and high-torque gearbox mentioned as available options (to be confirmed if included) Additional equipment • High-pressure through-spindle coolant (1000 psi) • High-pressure flood coolant • Multi-auger chip removal system • 95-gallon coolant tank

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: 037611, Equipment: chip conveyor, documentation/manual, Offering a used Wemas Turn 400 in very good condition. Hfsdpfx Ajzav H Eec Nsh

Condition: excellent (used), Year of construction: 2019, Control system: Heidenhain TNC 620 Travel range X/Y/Z: 700/500/500 mm Spindle speed: 12,000 rpm Coolant pressure: 30 bar Chip filtration system Measuring probe Hedozatnajpfx Ac Nsfh Tool magazine for 30 tools, SK 40 Chip conveyor

Condition: like new (used), Year of construction: 2014, functionality: fully functional, machine/vehicle number: 1110809, HAAS Mini Mill 2 CNC Machining Center – Year of Manufacture 2014 For sale: a HAAS Mini Mill 2 CNC vertical machining center from 2014. This compact and versatile machine is suitable for precision machining of small to medium-sized workpieces and is widely used in machine construction, component manufacturing, and general machining. Technical specifications: Manufacturer: Haas Model: Mini Mill 2 Year of Manufacture: 2014 Control: Haas CNC Control Travel (X/Y/Z): approx. 406 x 356 x 508 mm Tool changer: 10 positions Taper: CT40 Coolant system included Special features: The machine was taken out of production approximately three years ago and has not been used since. Hedpfszai T Sex Ac Nefh It was fully operational before being decommissioned. The control system has the latest available Haas software update. The machine is offered complete, including standard equipment and tooling. Condition: The machine is in good optical and technical condition. The machine has been thoroughly inspected by a Haas dealer. Availability: The machine is available immediately. Inspection is possible by appointment. Please contact us for additional information, photos, or a price quote.

Condition: ready for operation (used), Year of construction: 2008, operating hours: 5,557 h, travel distance X-axis: 706 mm, travel distance Y-axis: 406 mm, travel distance Z-axis: 508 mm, controller manufacturer: HAAS, table width: 914 mm, table length: 356 mm, table load: 1,361 kg, spindle speed (max.): 8,100 rpm, number of axes: 3, This HAAS VF-2, manufactured in 2008, offers strong machining capability with 706 mm of X-axis travel, 406 mm on the Y-axis, and 508 mm on the Z-axis. Equipped with a spindle speed of 8100 rpm and a powerful 22.4 kW spindle motor, it is well suited for demanding milling applications. The visual and technical condition of the machine is very good for its age. Contact us for more information. • Table: 356 x 914 mm • Tool magazine capacity: 20 tools Hedpfx Ajzaam Noc Nefh Additional equipment • Chip conveyor • Documentation / operating manual

Condition: good (used), Year of construction: 2008, operating hours: 11,870 h, functionality: fully functional, Controller WINMAX DSM Double screen Table size 1020 x 510 mm Table load max 1350 kgs X travel 762 mm Y travel 510 mm Z travel 610 mm A axis -35/+110 degree C axis 0 - 360 degree Spindle speed 12000 rpm Spindle taper SK40 Spindel power 11/15 kW Weight 4900 kgs Dimensions LxWxH = 2300 x 2400 x 2600 mm Accessories, features - KITAGAWA TT251 nc round table - Coolant through spindle 20 bar - Coolant unit - Spindle cooler - Chip conveyor Hfsdpjy U Hvhefx Ac Nsh - SW options: 3D, DXF, pocket islands, rigid tapping, NCPP, ISNC, realistic graphics, material and tool databank, surface selection, - machine mounths - external hydraulics The machine is still under power and can be inspected in operation.

Condition: ready for operation (used), Year of construction: 2006, travel distance X-axis: 762 mm, travel distance Y-axis: 460 mm, travel distance Z-axis: 460 mm, total height: 3,000 mm, total width: 3,270 mm, table load: 400 kg, overall weight: 8,000 kg, spindle speed (max.): 15,000 rpm, spindle motor power: 22,000 W, number of slots in tool magazine: 32, tool weight: 8,000 g, product length (max.): 300 mm, number of axes: 3, This 3-axis Okuma ACE CENTER MF-46VA was manufactured in 2006. It features an X-axis travel of 762 mm, Y-axis travel of 460 mm, and Z-axis travel of 460 mm. The machine is equipped with a maximum spindle speed of 15,000 rpm and an automatic tool changer with 32 stations. If you are looking to get high-quality machining capabilities, consider the Okuma ACE CENTER MF-46VA vertical machining centre we have for sale. Contact us for further details. • Distance table to spindle nose: 180–640 mm • Rapid traverse (X/Y): 40 m/min • Rapid traverse (Z): 32 m/min • Maximum cutting feed: 32,000 mm/min • Positioning accuracy (X/Y/Z): ±0.004 mm (JIS) • Repeatability (X/Y/Z): ±0.0015 mm (JIS) • Pallet changer: 2 pallets, rotary automatic pallet changer • Pallet size: 760 × 460 mm • Pallet T-slots: 3 × 18 mm, 125 mm pitch • Pallet change time: 6.0 s • Spindle speed: 15,000 rpm (upgrade from 8,000 rpm) • Spindle motor power: 22 / 18.5 kW • Max spindle torque: 199 Nm • Thermal compensation: TAS-S (spindle) and TAS-C (structure) • ATC capacity: 32 tools (upgrade from 20), random management • Tool change time (adjacent): 1.2 s • Max tool diameter: 90 mm (125 mm with adjacent pockets empty) • Max tool length: 300 mm • CNC functions: Hi-2 NC with NURBS, Super Hi 2 NC profile management, synchronized rigid tapping, helical cutting, spindle cutting load monitor, IGF conversational programming, RS-232-C interface, 3.5" floppy drive • 4th axis capability: prepared for 4th axis integration • Documentation: operator manuals and CE declaration of conformity included Additional equipment Hodpfx Acoy Uxuis Nsfh • Tool breakage detection sensor (table-side mounted) • Prepared for Renishaw zero-offset part probe (probe not included) • “Shower” type work area coolant wash system • Belt-type oil skimmer on coolant tank Technical Specification Taper Size BT 40

Condition: ready for operation (used), Year of construction: 2001, travel distance X-axis: 760 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 510 mm, overall weight: 3,800 kg, Fanuc 18M control BT40 spindle, 8000 RPM 24-tool changer Travel: 760 x 450 x 510 mm Table: 800 x 480 mm Chip conveyor Weight: 3800 kg Hfsdpfx Acjy Uvido Noh

Condition: ready for operation (used), Year of construction: 2014, travel distance X-axis: 762 mm, travel distance Y-axis: 435 mm, travel distance Z-axis: 510 mm, controller manufacturer: SIEMENS, controller model: Sinumerik 828D, table load: 600 kg, spindle speed (max.): 12,000 rpm, spindle motor power: 18,500 W, number of slots in tool magazine: 30, tool weight: 8,000 g, number of axes: 3, This 3-axis DOOSAN DNM 400 II was manufactured in 2014. It features an X-axis travel of 762 mm, Y-axis travel of 435 mm, and Z-axis travel of 510 mm. The machine includes a worktable with dimensions of 920 mm x 435 mm and a maximum table load of 600 kg. If you are looking to get high-quality machining capabilities, consider the DOOSAN DNM 400 II vertical machining centre we have for sale. Contact us for further details. • Capacity and travels: • Spindle nose to table: 150–660 mm • Worktable: • Size: 920 x 435 mm (36.2" x 17.1") • Spindle: • Max torque: 117 N·m (86.3 ft-lbs) • Taper: BIG-PLUS Dual Contact #40 (BT40 / CAT40) • Cooling: Through-spindle coolant (included) • Automatic Tool Changer (ATC): • Capacity: 30 tools (cam-type double arm) • Tool-to-tool time: 1.3 s • Max tool length: 300 mm • Feed rates and motion: Hfodpfx Aoy T I Snec Neh • Rapid traverse (X/Y): 36 m/min (1,417 IPM) • Rapid traverse (Z): 30 m/min (1,181 IPM) • Max cutting feedrate: 10,000 mm/min Additional equipment • Workpiece clamps, tools, and toolholders available at additional cost (not included) Technical Specification Taper Size BT 40

Condition: not inspected (used), Year of construction: 2000, travel distance X-axis: 610 mm, travel distance Y-axis: 405 mm, travel distance Z-axis: 510 mm, overall weight: 4,000 kg, spindle speed (max.): 8,000 rpm, Ultimax control system Table: 760 x 400 mm Travel: 610 x 405 x 510 mm Tool changer: 24 tools Maximum spindle speed: 8,000 rpm Weight: 4,000 kg Hodsy T Ekbspfx Ac Nefh

Condition: used, TECHNICAL DETAILS Hfsdpfx Ajy Tzcyjc Neh - Number of axes : 3 MILLING SPINDLE - Tool holder type : BT40 - Spindle power : 15 [kW] - Spindle speeds : 10000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 762 x 516 x 570 [mm] - Rapid traverses rates (X/Y/Z) : 40 / 40 / 36 [m/min] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 30 - Tool exchange time : 1,3 [sec] PALLET CHANGER - Pallet size : 860 x 570 [mm] - Pallets number : 2 - Pallet exchange time : 5 [sec] POWER SUPPLY - Supply voltage : 200 [V] - Total installed power : 40,25 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3130x3260 [mm] - Machine height : 3130 [mm] - Machine weight : 9200 [kg] EQUIPMENT - CNC : Fanuc 0i-MD Interface : PCMCIA, RS232 / RJ45 - 3 colors status lamp - Coolant tank * with high-pressure pump : 20 [bars] - Coolant through spindle - Spindle cooling unit - Chips conveyor - Electric transformer

Condition: used, TECHNICAL DETAILS - Number of axes : 5 MILLING SPINDLE - Tool holder type : HSK63 - Spindle speeds : 18000 [rpm] - Spindle power : 25 [kW] LINEAR AXES - Travels on X/Y/Z axes : 760 / 510 / 520 [mm] - Rapid traverses rates (X/Y/Z) : 45 / 45 / 40 [mm/min] A ROTARY AXIS - Travel : -110 / +30 [°] - C ROTARY AXIS - Travel : 360 [°] - Rapid traverse rate : 25 [rpm] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 40 TABLE - Table dimensions : Ø248 [mm] - Maximum weight upon table : 200 [kg] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 48 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3.940 x 4.060 [mm] - Machine height : 2.865 [mm] - Machine weight : 6000 [kg] Hjdpfx Acoy Tzcte Njfh EQUIPMENT - CNC : Hurco WinMax / MAX5 - Interactive programming - Electronic handwheel - Coolant tank * with high-pressure pump - Coolant through spindle - Chips conveyor - Spindle cooling unit

Condition: used, Year of construction: 2008, x-travel 700 mm y-travel 420 mm z-travel 610 mm Control Heidenhain output 22 kVA weight ca. 5.200 kg Hfjdpfxey Ty Izs Ac Noh In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, as well as the tools and clamping devices shown in the images, are included in the scope of delivery only if explicitly noted in the additional information. Subject to changes, errors in technical data and specifications, and prior sale!

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, travel distance X-axis: 700 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 330 mm, controller manufacturer: FANUC, controller model: 31iB5, table width: 410 mm, table length: 850 mm, number of slots in tool magazine: 21, Equipment: documentation/manual, FANUC ROBODRILL ALPHA D21LiB5 MACHINING CENTER, YEAR OF MANUFACTURE 2016 Hsdjy Tvfcopfx Ac Njfh EQUIPPED WITH FANUC 31iB5 CONTROL ELECTRONIC HANDWHEEL TRAVEL: X 700, Y 400, Z 330 MM TABLE SURFACE: 850 x 410 MM DIRECT DRIVE MOTORIZED SPINDLE, BBT 30, 10,000 RPM 21-TOOL AUTOMATIC TOOL CHANGER 4TH-AXIS DIVIDER WITH DIRECT DRIVE LASER PROBE FOR TOOL MEASUREMENT INTERNAL COOLANT SYSTEM SPINDLE CHILLER

Condition: used, Year of construction: 2023, operating hours: 120 h, Nearly brand-new Haas TRT210 two-axis rotary table with only approximately 120 operating hours. The table was exclusively used on a Haas VF-4 (see separate listing) and is in visually and technically flawless condition. Hfodpfx Ajy Tp Hgsc Njh The TRT210 is Haas's compact 5-axis solution for medium-sized VMCs and takes up minimal space at one end of the machine table – the rest of the clamping area remains free for vices or other fixtures. Plug-and-play connection to any Haas milling machine with 4/5-axis drives and the corresponding NGC control software. In addition to the rotary table itself, the scope of supply includes the matching toe clamp kit for direct mounting on the machine table, as well as a Renishaw riser block for the side mounting of the radio receiver (OMI/OMP) – this ensures reliable signal transmission to the measuring probe even over the entire A-axis swivel range. Available from approximately week 32. Inspection possible by appointment. Shipping can be arranged. Technical data: - Table diameter: 230 mm (9.10") - Max. circle diameter: 368 mm (14.5") - Max. workpiece weight on table: up to approx. 90 kg - Hole pattern: 2 x 6-hole pattern A-axis (swivel): - Swivel range: ±120° - Max. speed: 80°/s - Max. torque: approx. 407 Nm (300 ft-lb) - Braking torque at 6.9 bar: approx. 540 Nm - Accuracy: ±25 arc-sec - Repeatability: 10 arc-sec - Resolution: 0.001° B-axis (rotation): - Rotation range: 360°/continuous - Max. speed: 100°/s - Max. torque: approx. 285 Nm (210 ft-lb) - Braking torque at 6.9 bar: approx. 270 Nm - Maximum runout: 0.013 mm (0.0005") - Accuracy: ±15 arc-sec - Repeatability: 10 arc-sec - Resolution: 0.001° General: - Connection voltage: 115 VAC, approx. 15 A - Max. compressed air: approx. 10 bar (150 psi) - Weight: approx. 220 kg Scope of supply: - Haas TRT210 rotary table, complete - Original Haas servo connection cable for A- and B-axes - Toe clamp kit (for mounting on the machine table) - Renishaw riser block for side receiver mounting - Original documentation

Condition: used, Year of construction: 2023, operating hours: 259 h, functionality: fully functional, machine/vehicle number: 1200002, travel distance X-axis: 1,270 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 635 mm, Like-new Haas VF-4-EU CNC vertical machining center with only 259 operating hours. The machine is in excellent optical and technical condition. The VF-4 is factory-equipped and fully prepared for 4/5-axis operation – the comprehensive 5th-AXIS package is installed: - Axis cards for the 4th and 5th axes - Dynamic workpiece offset - Tool center point control - High-speed machining - Programmable coolant nozzle - Wireless Renishaw measuring probe and tool probe In addition, the machine is exceptionally well-equipped: - TSC – internal coolant supply with 21 bar - Spiral chip conveyor - Complete coolant maintenance package (automatic refilling, oil separator, mist collector) - Fast 30+1 tool changer - Spindle with 10,000 rpm The control system is the current Haas Next Generation Control with touchscreen, WLAN, Ethernet and HaasConnect remote monitoring. This makes the machine immediately ready for demanding machining tasks. The original shipping securing devices are available. An original Haas tool cart for SK40 is also included. Available from approximately week 32. Inspection and demonstration under power can be arranged at any time. Loading and transport can be organized. A suitable TRT-210 CNC rotary table is offered in a separate listing and can be included in the package upon request. The LANG baseplates are not included in the scope of supply. Technical data: - Travel ranges X / Y / Z: 1,270 × 508 × 635 mm - Spindle nose to table: 107 – 742 mm - Table: 1,321 × 457 mm, 5 T-slots (16 mm), max. table load 1,588 kg - Spindle: 10,000 min⁻¹, BT/CT 40, inline direct drive, liquid-cooled - Drive power: 22.4 kW - Max. torque: 122 Nm at 2,000 min⁻¹ - Rapid traverse X / Y / Z: 25.4 m/min - Feed rate max.: 16.5 m/min - Tool changer: Side SMTC, 30+1 positions - Tool max. diameter / length / weight: 64 mm / 330 mm / 5.4 kg - Tool change time (chip-to-chip): approx. 3.6 s - Connection voltage: 400 V / 50 Hz, 3-phase (internal transformer installed) - Compressed air: approx. 113 l/min at 6.9 bar - Coolant tank: 208 l - Weight: approx. 6,260 kg (with conveyor) Control system: - Haas Next Generation Control with touchscreen - 1 GB program memory, Ethernet + WLAN - HaasConnect (remote monitoring), HaasDrop (wireless file transfer) - M130 media display, Safe Run, synchronized thread drilling - Early detection module for power failure, surge protection - Equipment / options (all factory-installed) - 5-axis package VF-YT (4th + 5th axis drive-side prepared, DWO/TCPC, high-speed machining, programmable coolant nozzle) - Wireless Renishaw measuring probe system (intuitive) - TSC – internal coolant supply through the spindle, 21 bar - Spiral chip conveyor - Coolant maintenance package (automatic refilling, oil separator, mist collector) - Additional coolant filter (bag filter 25 µm) - Filter set for chip tray (200 µ) - Variable coolant flow (M-code controlled) Hfjdpoy Tp E Aofx Ac Nsh - Blowing of the inside of the machine door - Lifting eyes, touchscreen, door lock

Condition: ready for operation (used), Year of construction: 2001, travel distance X-axis: 700 mm, travel distance Y-axis: 480 mm, travel distance Z-axis: 640 mm, controller manufacturer: SIEMENS, controller model: Sinumerik 840D, total height: 3,260 mm, total width: 3,360 mm, table load: 600 kg, overall weight: 5,500 kg, spindle speed (max.): 10,000 rpm, spindle motor power: 18,500 W, number of slots in tool magazine: 30, tool weight: 6,000 g, product length (max.): 3,320 mm, number of axes: 3, This 3-axis FAMUP MCP70 E was manufactured in 2001. It features an X-axis travel of 700 mm, Y-axis travel of 480 mm, and Z-axis travel of 640 mm. The machine includes a table size of 600 x 450 mm and a maximum table load of 300 kg. If you are looking to get high-quality machining capabilities, consider the FAMUP MCP70 E vertical machining centre we have for sale. Contact us for further details. • Table / Pallet • Table size: 600 x 450 mm • T-slots: 5 x 14 x 80 mm • Central bore: Ø50 H6 • Pallet change time: 9 sec • Axis performance • Working feedrate X/Y/Z: 10,000 mm/min • Rapid feedrate X/Y/Z: 30,000 mm/min • Working thrust S1 X/Y: 4,800 N • Working thrust S1 Z: 7,200 N • Measurement system • Indirect measuring system • Accuracy • Positioning accuracy X/Y/Z: ±5 µm • Repeatability X/Y/Z: ±1.5 µm • Reversal accuracy: 3 µm • Tool changer • Positions: 30 • Selection: Bidirectional • Max. tool diameter: Ø75 mm • Max. tool length: 280 mm • Tool change time: 1.7 sec Hsdpfx Acey Tlwzo Njfh • Chip-to-chip time: 3.5 sec Technical Specification Taper Size ISO 40

Condition: ready for operation (used), Year of construction: 2024, travel distance X-axis: 780 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 650 mm, controller manufacturer: FANUC, controller model: 0iMF, table load: 700 kg, overall weight: 6,800 kg, spindle speed (max.): 8,000 rpm, spindle motor power: 7,500 W, tool weight: 6,000 g, number of axes: 4, This 4-axis Finetech SMV 1060 H3L was manufactured in 2024. It features an impressive X-axis travel of 780 mm, Y-axis travel of 600 mm, and Z-axis travel of 650 mm. The machine includes a robust table size of 1100 x 600 mm and a maximum table load of 700 kg. If you are looking to get high-quality machining capabilities, consider the Finetech SMV 1060 H3L vertical machining centre. Contact us for further details. • Structure: Cast iron structure; roller linear guideways • Control: FANUC 0iMF; 10.5" monitor; remote electronic handwheel • Table: 1100 x 600 mm; 5 T-slots; T-slot size 18 mm; T-slot pitch 100 mm • Distances: Spindle nose to table 130–780 mm Hfjdpfxsy Tlpwe Ac Njh • Spindle: taper No. 40 • Tool changer (ATC): Tool holder taper ISO40 DIN69871; 24-position magazine; max tool Ø 80 mm; max tool length 300 mm; bidirectional selection; tool-to-tool 3 s; chip-to-chip 6 s • Feedrates: Rapids X/Y/Z 36/36/32 m/min; working feedrate X/Y/Z 1–12,000 mm/min • Coolant/utilities: Coolant tank 380 L; working pressure 4 bar; total installed power 25 kVA • Dimensions & weight: 2900 x 2500 x 2800 mm • Standard features: Rigid tapping; full safety enclosure; random bidirectional ATC arm; 24-position tool magazine; oil spindle cooling unit; Z-axis gas balancing system; automatic guide lubrication; electrical cabinet heat exchanger; working area lamp; service keys; transformer; manuals and CE declaration Additional equipment • Chip conveyor (screw type) • Optional 40-tool chain-type magazine: BT40/CAT40; max tool Ø 75 mm with adjacent pockets occupied, Ø 152 mm with adjacent pockets empty; max tool weight 8 kg; max total tool weight 160 kg; air pressure required 5–6 kg/cm² Technical Specification Taper Size ISO 40
