Murix

Condition: used, Year of construction: 2004, functionality: fully functional, CNC gear hobbing machine Control: Siemens 840 D Power Line Technical data: Max. workpiece diameter: 150 mm Table diameter: 145 mm Max. table speed: 800 rpm Distance between centers: 10 – 200 mm Max. axial travel: 250 mm Swivel angle of milling head: +/- 45° Max. tailstock travel: 300 mm Max. rapid traverse rate: 17,000 mm/min Drive power of milling head: 19 kW Max. module: 3 mm Max. speed of milling spindle / tool speed: 4,500 rpm Max. diameter of hobbing cutter: 80 mm Max. length of hobbing cutter: 200 mm Dimensions approx.: 5.5 x 3.7 x 3.1 m Weight approx.: 9,500 kg Equipment: Chip conveyor Oil mist extraction / oil extraction Oil cooler Steady rest with lowering device and vertical adjustment Rotary ring loader with two workpiece grippers Loading belt system for automatic feeding 5 milling arbors / hobbing cutter holders: 1 x Ø 22 mm 2 x Ø 27 mm Gusdpfxozkwvns Adtjg 1 x Ø 32 mm 1 x Ø 40 mm Other: Video recordings via WhatsApp

Condition: like new (used), Year of construction: 2024, operating hours: 7,556 h, functionality: fully functional, 4 x LIEBHERR LC 280 DC Gear Hobbing Machines For sale are 4 identical LIEBHERR LC 280 DC gear hobbing machines, all manufactured in 2024. Manufacturer: Liebherr Verzahntechnik GmbH Model: LC 280 DC Machine Type: CNC gear hobbing machine with integrated ChamferCut unit Quantity Available: 4 units Year of Manufacture: 2024 Example Machine No.: XXX Control: Siemens CNC / HMI user interface Technical Data: Max. Workpiece Diameter: 280 mm Max. Module: 6 mm / 4 mm depending on the version Axial Travel: 400 mm Shift Travel: 200 mm Max. Hob Diameter: 150 mm Hob Speed: 2,250 / 6,000 rpm Table Speed: 250 / 800 rpm Max. Module ChamferCut: 5 mm Max. Tool Speed ChamferCut: 2,000 rpm Max. Tool Diameter ChamferCut: 130 mm Max. Tool Clamping Length Drilling Tool: 236 mm Max. Tool Clamping Length Shank Tool: 360 mm The LC 280 DC is a compact gear hobbing machine for workpieces up to 280 mm in diameter and integrated ChamferCut machining; according to Liebherr, it is designed for gear hobbing and parallel, defined deburring/chamfering. ([Liebherr][1]) Equipment: Integrated ChamferCut unit Automatic workpiece handling / round magazine Siemens CNC control Liebherr HMI / production interface Workpiece spindle Hobbing head Deburring/chamfering unit Full protection cabin Work area lighting Automation interface CE marking Machine suitable for dry and wet machining, depending on equipment and process Electrical data per machine according to the nameplate: 400 V AC 50 Hz Control voltage: 24 V AC Installed power: 29 kVA Rated current: 42 A cos φ: 0.81 Fuse: 63 A gL Control cabinet weight: 900 kg Guedpfx Adezdv Upjtjg All 4 machines are identical, manufactured in 2024, and come from modern industrial series production. Technical data according to nameplate, manufacturer's specifications, and photo documentation. Subject to errors and prior sale.

Condition: used, Year of construction: 2006, Technical details: max. wheel diameter: 300 mm max. module: 7 weight of the machine ca.: 15 t table turning speeds: 100 U/min table diameter: 180 mm hob turning speeds: 750 U/min max. hob diameter: 300 cutter length max.: 230 mm Liebherr LC300 with loading automation Machine including counter holder The machine used to work with emulsion Gedpfx Ajyz Sd Rsdteug *

Condition: used, Year of construction: 1999, Technical details: max. wheel diameter: 180 mm max. module: 7 hob turning speeds: 200-2000 U/min min. number of teeth: 4 Gsdpfxsyzxbij Adtoug excluding conveyor belt *

Condition: used, Year of construction: 1999, Technical details: max. wheel diameter: 280 mm max. module: 7 weight of the machine ca.: 13 t table turning speeds: 100 U/min table diameter: 250 mm min. number of teeth: 4 hob turning speeds: 1500 U/min max. hob diameter: 160 cutter length max.: 230 mm Machine in good condition. Available 01.08.2024 Gsdpfx Aoyzxbcedtsug *

Condition: excellent (used), Mikron Gear Hobbing Machine A33/0 – for Module 0.5 to 2.5 – rarely used Manufacturer: Mikron Model: A33/0 – Gear Hobbing Machine (vertical) Version: Base machine with standard milling head Condition: used, very good condition, machine has been rarely operated Color: green Technical Data Max. workpiece diameter: approx. 80 mm Max. hobbing length: approx. 150 mm Module range: approx. 0.5 – 2.5 Ideal for small gears in the module range 0.5 – 1.0 Main drive: 3 kW Electrical connection: 3 x 380 V AC, 50 Hz Total power consumption: approx. 9.5 kVA Dimensions & Weight L x W x H: approx. 1,450 x 1,380 x 2,080 mm Weight: approx. 2,200 kg Guodsx A D Izspfx Adtjg Special Features Very well-suited for manufacturing small gears (module 0.5 – 1.0) Machine was rarely used in production, therefore minimal wear Availability / Service Detailed photos and operating video available upon request Quotation including price, delivery terms, and lead time possible Subject to prior sale and errors.

Condition: used, Year of construction: 2004, Technical details: max. wheel diameter: 200 mm gear width: 60 mm max. module: 7 Gjdsxc E H Sopfx Adtoug weight of the machine ca.: 15 t table diameter: 180 mm table turning speeds: 100 U/min hob turning speeds: 750 U/min Machine in good condition, without feed, without automation Available 24.08.2024 *
